    Auger Kits                                                                                                                Augers

    Hand Auger Kit 50mm                                                                                                       Auger Sand
    A kit consists of a full set of equipment packed securely in                                                              These were originally designed to sample for minerals in
    a carry bag such as an auger, extension rods and handle,                                                                  beach sands but now are used extensively for drilling and
    and tommy bars.                                                                                                           sampling in very sandy friable soils. A 75mm diameter sand
    This kit contains:                                                                                                        auger will penetrate 30cm in about four turns, which fills

                                                                                                                                                                                                                                                                   Exploration Geology and Field Equipment
    1 x 50mm Sand Auger                                                                                                       the auger. Now also available in a heavy duty version (made
    1 x 50mm Soil Auger                                                                                                       from thicker steel) for contaminated sand that has roots or
    1 x T-handle                                                                                                              soil or shells, please enquire with our sales team.
    6 x Aluminium Extension Rods
                                                                                                                                       SKU                DIAMETER                 LENGTH
    1 x pair Tommy Bars
    1 x 1.0mtr Carry Bag                                                                                                           1101-00254               50mm                   1.0mtr
                                                                                                                                   1101-00256               62mm                   1.0mtr
          SKU                        DESCRIPTION                                                                                   1101-00258               75mm                   1.0mtr
      1101-00239                 Hand Auger Kit 50mm                                                                               1101-00252              100mm                   1.0mtr

    Hand Auger Kit 62mm
    A kit consists of a full set of equipment packed securely in
    a carry bag such as an auger, extension rods and handle,                                                                  Auger Soil GP
    and tommy bars.                                                                                                           This is our most popular auger which is a general purpose
    This kit contains:                                                                                                        design to handle most soil conditions, even very sandy soils.
    1 x 62mm Soil Auger                                                                                                       In stiff dry clay penetration can be improved by adding a little
    1 x 62mm Spiral Auger                                                                                                     water to the hole. It is a 2 slot, 2 cutter, with a spiral tip design.
    1 x T-handle
                                                                                                                                       SKU                DIAMETER                 LENGTH
    1 x Star Drill
    6 x Steel Extension Rods                                                                                                       1101-00290               50mm                   1.0mtr
    1 x pair Tommy Bars                                                                                                            1101-00291               62mm                   1.0mtr
    1 x 1.0mtr Carry Bag                                                                                                           1101-00292               75mm                   1.0mtr
                                                                                                                                   1101-00289              100mm                   1.0mtr
          SKU                        DESCRIPTION
      1101-00240                 Hand Auger Kit 62mm

1       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                Exploration Geology and Field Equipment · Section 05     2

                               C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                       s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
                                                                                                                                            Asbestos Bags
    Auger Accessories                                                                                                                            Highly durable material
                                                                                                                                                 UV-stabilised for long life expectancy
                                                                                                                                                 Cautionary signs printed in bright red
    Capstan Steel                                                                                                                                Tough plastic ensures security
    The Capstan is used to replace the T-handle when insuffi-                                                                                    A variety of sizes available
    cient clearances prevent the T-handle from being used. The                                                                                   Easily identifiable
    Capstan allows short movements by incremental turns                                                                                          Puncture-resistant
    using our Tommy Bars in the holes in the Capstan.
                                                                                                                                            All our manufacturers abide by the ETI code.
                               SKU
                            1101-00202                                                                                                           SKU        THICKNESS (um)          SIZE (LxW)          UOM
                                                                                                                                             1107-00101           200           900 x 600mm          Carton of 50

                                                                                                                                                                                                                                                                                       Exploration Geology and Field Equipment
                                                                                                                                             1107-00102           200           1100 x 700mm         Carton of 50
    Extension Rod                                                                                                                            1107-00103           200           1200 x 900mm          Roll of 50
    Aluminium tubes and threads are light weight and resis-                                                                                  1107-00104           200          1500 x 1000mm         Carton of 25
    tant to corrosion. Steel tubes and threads are ideal for                                                                                 1107-00105           200          1600 x 1180mm         Carton of 25
    strength and rigidity.

           SKU              TYPE           DIAMETER      LENGTH
        1101-00226       Aluminium          40mm          1.0m
        1101-00228       Aluminium          40mm          1.5m                                                                              Our Asbestos Bags
        1101-00227          Steel           40mm          1.0m                                                                              Westernex sources their plastic asbestos bags from trusted suppliers who follow strict standards. We have been supplying
        1101-00229          Steel           40mm          1.5m                                                                              mining sample bags for over 25 years so know what is expected of our quality. Our bags are UV stabilised to ensure the life
                                                                                                                                            expectancy in the field.

    Handle
    For manual turning of the auger.

           SKU            DESCRIPTION                LENGTH
                                                                                                                                            Asbestos Handling
        1101-00305       Standard Length              470mm
        1101-00303      Extra Long Length             600mm                                                                                 Duct Tape
                                                                                                                                            Multi-purpose. Can also be used to join up builder's film
                                                                                                                                            in order to cover large surface areas.
    Tommy Bars                                                                                                                                       SKU                 COLOUR                      SIZE
    To undo the threaded joints and to hold the "drill string"
                                                                                                                                                 1213-00030                Silver                48mm x 30mtr
    to prevent it from falling down the hole. Also used to
    remove the sample from the auger or for turning the
    Capstan. Sold in pairs (2 bars).                                                                                                                                                                                                    A

           SKU                DESCRIPTION                UOM
                                                                                                                                            Asbestos Safety Signs and Stickers
        1101-00300       Pair of spring steel bars        Pair                                                                                    SKU                   DESCRIPTION                         SIZE
                                                                                                                                        A    1706-00038           "Danger Asbestos" - Sign           450 x 300mm
                                                                                                                                        B    1706-00001      "Caution Asbestos Do Not Disturb"        80 x 50mm                                                              B
                                                                                                                                                                         - Sticker
                                                                                                                                            Westernex also offers the option to have customised signs and stickers
                                                                                                                                            made in various sizes and materials.
                                     Dormer Soil Samplers is a small Australian owned business that specialises in the design and
                                     manufacture of portable, hand operated soil sampling and drilling equipment for use in soils
                                     and sands, both dry and wet. They have been manufacturing this equipment in Australia
                                     since 1953 and have a worldwide reputation for excellent quality and simplicity of use.                Asbestos Safety Tape
                                     Their equipment is in 92 countries. Dormer Soil Samplers manufactures many styles of hand                       SKU                                 SIZE
                                                                                                                                                                                                                                  C
                                     auger, soil auger, sand auger, soil drill, soil samplers, earth auger, earth drill, sand sampler   C        1708-00029                         48mm x 100mtr
                                     and wet soil sampler. These are used to: sample soil; sample sand; sample below water; and         D        1708-00109                         75mm x 300mtr
                                     hand drill soil and sand.                                                                                                                                                                                                                     D

3       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                                Exploration Geology and Field Equipment · Section 05         4

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                                         s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
    Asbestos Handling                                                                                                      Asbestos Handling
                                                                                                                           Arax Dry Grip Gloves
    Westernex also provides the option to                                                                                  » EN 388 Level 3 Abrasion Resistance
    assemble custom asbestos safety kits to                                                                                » EN 388 Level 4 Tear Resistance (the highest tear
                                                                                                                             resistance rating in accordance with Australian
    suit any customer specification for                                                                                      Standards)
    various applications of any size.                                                                                      » EN 388 Level 3 Puncture Resistance
                                                                                                                           » ProChoice's Bare Hand Technology (BHT) for
                                                                                                                             improved dexterity and sensitivity
    For more information, get in touch with                                                                                » Contact heat resistant to 100°C
                                                                                                                           » Quick and easy donning and doffing
    one of our friendly sales team members.                                                                                » Workforce tested and approved
    Email us at:

                                                                                                                                                                                                                                                      Exploration Geology and Field Equipment
                                                                                                                                  SKU                         SIZE
                                                                                                                               1704-00633                       8
    supply@westernex.com.au                                                                                                    1704-00624                       9
                                                                                                                               1704-00631                      10
                                                                                                                               1704-00632                      11

    Asbestos/Dust Respirator Kit
    Respiratory kit designed for asbestos removal and envi-
    ronments containing dust.                                                                                              Extra Heavy Duty Nitrile Glove
    Kit contains:                                                                                                          » Made from 100% extra heavy duty nitrile
    » 1 x 3M™ Half Face Respirator 7500 Series                                                                             » Improved protection from oils, grease, fuels,
                                                                                                                             cleaners, solvents, chemicals, & transmission fluid
    » 2 x pairs of 3M™ Particulate Filters 6035 P2/P3*
                                                                                                                           » This glove has hypoallergenic properties for sensitive
    » 1 x pair of 3M™ SecureFit™ 200 Series Safety Glasses,                                                                  skin types
      AS/NZS1337.1 Medium Impact                                                                                           » Low odour nitrile glove
    » 4 x 3M™ Respirator Cleaning Wipes 504                                                                                » Latex free and vinyl free glove material delivers
    » 1 x 3M™ No-Touch™ Foam Earplugs P2000, Class 4                                                                         superior comfort for extended wear
      (SLC80: 25dB)                                                                                                        » Ambidextrous glove with textured palm and fingers
    » Handy Storage Container                                                                                                for enhanced grip in wet and dry conditions

                              SKU                                                                                                 SKU                         SIZE
                           1711-00035                                                                                         1704-06003-S                      S
                                                                                                                              1704-06003-M                     M
                                                                                                                              1704-06003-L                      L

    Provek Disposable Coveralls                                                                                               1704-06003-XL                    XL

    » Made from a polyethylene (Olefin) film laminated to
      a polypropylene spun bound non-woven substrate
      that is lightweight and soft with excellent strength
    » Water vapour permeable and water repellent                                                                           Stinga Glove
    » Excellent barrier to dust and broad range of chemicals                                                               » (BHT) Bare Hand Technology
    » Type 5 - Particle tight clothing, Type 6 - Limited                                                                   » Seamless 15 gauge, 100% apparel grade nylon shell
      splash particle tight clothing                                                                                       » PVC foam coating provides water repellency, comfort
    » Lint-free and good opacity                                                                                             and enhanced gripping power in wet and dry conditions
    » Two way zipper for when nature calls                                                                                 » Woodworking, light fabrication, construction,
                                                                                                                             whitegoods, petroleum industry, general purpose
           SKU              COLOUR                 SIZE                                                                      handling, automotive manufacturing, shipping and
        1701-00406           White                  S                                                                        assembly
        1701-00407           White                  M
                                                                                                                                  SKU                         SIZE
        1701-00408           White                  L
                                                                                                                               1704-00621                       S
        1701-00409           White                 XL
                                                                                                                               1704-03145                      M
        1701-00410           White                 XXL
                                                                                                                               1704-00623                       L
        1701-00411           White                XXXL
                                                                                                                               1704-03147                      XL
                                                                                                                               1704-03148                      XXL

5       Section 05 · Exploration Geology and Field Equipment                                                                                                                                   Exploration Geology and Field Equipment · Section 05     6

                            C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                             s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020

    Bulky Bags                                                                                                                                    Bulky Bags
    Duffle Top (DT): A Duffle Top is an extension of the
    bag itself and is folded down to make the top of                                                                                              Bulk Bag Forklift/Crane Jib
    the bag completely open.
                                                                                                                                                  The bulk bag jib is designed to safely handle and move
    Spout Top (ST): A spout top is primarily when bags                                                                                            bulk bags by both forklift and overhead crane.
    are being filled by a machine.
    Flat/Closed Bottom (CB): The flat bottom bag is                                                                                               » Versatile design allows easy transfer from forklift to
    exactly that, a closed bottom. It is completely shut                                                                                            crane and vice versa
    off with no openings for product to escape at all.                                                                                            » Fitted with four safety swivel hooks for securing the
                                                                                                                                                    bulk bag straps at 800mm centres
    Spout Bottom (SB): The spout bottom has a spout                                                                                               » Allows for one handed connection and disconnection
    on the bottom of the bag that, when being filled,                                                                                               of straps
    is tied up to give the bag a smooth, flat bottom.                                                                                             » Certified to relevant Australian Standards
    The Spout is used to discharge the product from                                                                                               » Zinc finish

                                                                                                                                                                                                                                                                                Exploration Geology and Field Equipment
    the bag by pulling open the spout and allowing the
    product to flow out. The spout can be used to only                                                                                            » Pocket Size: 185 x 85mm
    empty a portion of the bag (by tying it off ) leaving                                                                                         » Pocket Centres: 500mm
    the bag partly filled, or it can be used to slow the                                                                                          » Working Load Limit (WLL): 2000kg
    rate at which the bags empties.                                                                                                               » Unit Weight: 60kg
                                                                                                                                                  » Load Centre: 450mm
                                                                                                                                                  » Hook Centres: 800mm
    All our manufacturers abide by the ETI code and
    are SWL rated.                                                                                                                                                            SKU
                                                                                                                                                                           1204-00302

    Bulky Bag
         SKU          DESCRIPTION*        CAPACITY        SIZE (cm)**
     1102-00014           DT-CB                500kg      90 x 90 x 50
     1102-00013           DT-CB                1.5T       90 x 90 x 120
     1102-00064            DT-SB               1.2T       90 x 90 x 120                                 Duffle Top                  Spout Top
     1102-00071            ST-SB               1.2T       90 x 90 x 120
    *Duffle Top (DT), Spout Top (ST), Closed Bottom (CB), Spout Bottom (SB)
    **Other sizes available on request.
                                                                                                                                                  Bulk Bag Filling Frame
                                                                                                                                                  The bulk bag filling frame saves hours of labour and
                                                                                                                                                  reduces risk of injury. This frame is designed to safely hook
                                                                                                                                                  open a bulk bag and fill with free-flowing bulk products
                                                                                                Flat/Closed Bottom                 Spout Bottom   such as sand and gravel etc, removing the need for the
    Bulky Bag Local Print Numbering                                                                                                               operator to hold the bag open or manually fill themselves.
    Westernex can number your bags in a multitude of ways, the                                                                                    » Bulk bag can be held in position by either the bag
    options are endless, please call to discuss your requirements.                                                                                  retaining pin mounts allowing for easy removal by
                                                                                                                                                    forklift or pallet jack, or the adjustable bag restraining
         SKU                             DESCRIPTION                                                                                                chains allowing bag to be positioned at optimal height
                                                                                                                                                  » 3 adjustable height settings allow optimal removal of
        BBN01                             50mm Text                                                                                                 filled bags to suit your operational requirements
                                                                                                                                                  » Fork pockets fitted for easy transport around the worksite
                                                                                                                                                  » Optional clamshell gate for maximum material flow
                                                                                                                                                    and control
                                                                                                                                                  » Optional spill guard
                                                                                                                                                  » Supplied with 4 safety swivel hooks and retaining pin
                                                                                                                                                    mounts
    Large Tag                                                                                                                                     » Enamel paint finish
    These tags are built from sturdy and durable material.                                                                                        » Working Load Limit (WLL): 1000kg
                                                                                                                                                  » Load Centre: 900mm
    They are suitable for use in the field. These tags can be                                                                                     » Dimensions: 1800 x 1150mm
    sequentially barcoded and numbered according to your                                                                                          » Adjustable Height Settings: 3
                                                                                        A           B
    desired configuration.                                                                                                  C                     » Unit Height: 1700 - 2195mm
                                                                                                                                                  » Unit Weight: 270kg
             SKU               DESCRIPTION                  SIZE                                                                                  » Fork Pocket Size: 140 x 65mm
                                                                                                                                                  » Fork Pocket Centres: 850mm
A        1156-00001                Large Tag           121mm x 76mm
B        1156-00002            Locking Device                ---                                                                                                              SKU
C        1156-00003            Tag Applicator                ---                                                                                                           1102-00121

7        Section 05 · Exploration Geology and Field Equipment                                                                                                                                                            Exploration Geology and Field Equipment · Section 05     8

                                    C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                               s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
                                                                                                                                   Calico Bags
    Calico Bags
        A wide variety of bag options and sizes
        Manufactured from high quality fabrics and materials                                                                       Bag Calico Draw String
        Reinforced stitching with overlocked seam                                                                                  String is sewn into top of bag, pull to close the bag and the
                                                                                                                                   wrap string around to seal once again.
        ISO and ETI Code approved
        Different weave options available                                                                                              SKU          TYPE                   SIZE
                                                                                                                                      B23-STD      Standard      8" x 12" - 200mm x 300mm
                                                                                                                                     B23-FINE        Fine        8" x 12" - 200mm x 300mm
                                                                                                                                      B24-STD      Standard      10" x 14" - 250mm x 350mm

                                                                                                                                                                                                                                                                   Exploration Geology and Field Equipment
    All our manufacturers abide by the ETI code.                                                                                     B24-FINE        Fine        10" x 14" - 250mm x 350mm
                                                                                                                                      B25-STD      Standard      12" x 15" - 300mm x 375mm
                                                                                                                                     B25-FINE        Fine        12" x 15" - 300mm x 375mm
                                                                                                                                      B26-STD      Standard      12" x 18" - 300mm x 450mm
                                                                                                                                     B26-FINE        Fine        12" x 18" - 300mm x 450mm
                                                                                                                                      B27-STD      Standard      14" x 24" - 350mm x 600mm
                                                                                                                                     B27-FINE        Fine        14" x 24" - 350mm x 600mm
                                                                                                                                    B34DS-STD      Standard      18" x 30" - 450mm x 750mm
                                                                                                                                    B34DS-FINE       Fine        18" x 30" - 450mm x 750mm
                                                                                                                                     B35C-STD      Standard     24" x 36" - 600mm x 900mm
                                                                                                                                   Other sizes available upon request. MOQ may apply.

    Our Calico Bags
    Westernex has been supplying calico sample bags to the exploration & mining sector for over 30 years, our bags have been
    tried and tested and leave all other bags on the market in the dust. With thanks to our valued customer base we have evolved
    our bags to be the most superior in the field. As we manufacture our own bags in our own overseas facility, we have the
    ability to customise to your requirements, please feel to ask for any of your requirements.
                                                                                                                                   Bag Calico Tape Tie
                                                                                                                                   Tape ties are sewn onto the side of the bag and you use
                                                                                                                                   this to close the bag.

                                                                                                                                       SKU          TYPE                   SIZE
                                                                                                                                     B29-FINE        Fine        8" x 12" - 200mm x 300mm
                                                                                                                                     B30-FINE        Fine        10" x 14" - 250mm x 350mm
                                                                                                                                     B31-FINE        Fine        12" x 15" - 300mm x 375mm
                                                                                                                                     B32-FINE        Fine        12" x 18" - 300mm x 450mm
                                                                                                                                     B33-FINE        Fine        14" x 24" - 350mm x 600mm
                                                                                                                                     B34-FINE        Fine        18" x 30" - 450mm x 750mm
                                                                                                                                     B35-FINE        Fine        24" x 36" - 600mm x 900mm
                                                                                                                                   Other sizes available upon request. MOQ may apply.

                                                                                                                                   Calico Bag Opener
                                                                                                                                             SKU                        DIAMETER
                                                                                                                                         1103-30000                      130mm
                                                                                                                                         1103-30001                      160mm
                                                                                                                                         1103-30002                      180mm
                       Standard Calico Bags                                           Fine Calico Bags                                   1103-30003                      200mm
                     Suited for majority of sampling applications.              Suited for all types of sampling, these have             1103-30004                      470mm
                       Strong for holding sharp rock. They are               extremely fine weave and so are suited for very
                      made for the budget-conscious while still               fine samples. It also eliminates the chances of
                                  retaining quality.                         cross contamination of samples, and the loss of
                                                                                               fines in samples.

9       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                Exploration Geology and Field Equipment · Section 05   10

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                        s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
     Calico Bags Local Numbering                                                                                                  Calico Bags Local Numbering
         Ideal for smaller scale quantities                                                                                           Ideal for smaller scale quantities
         Select your bag type                                                                                                         Select your bag type
         Select your bag numbering size                                                                                               Select your bag numbering size
         Select your numbering, ticket or tag type                                                                                    Select your numbering, ticket or tag type

                                                                                                                                  Calico Bag Local Tag Numbering
     Calico Bag Local Stamp Numbering                                                                                             Westernex can supply hard tags with or without barcodes,
     Locally stamped bags are only available in 15mm heights.                                                                     these can also be applied to bags ready for use.
                                                                                                                                  Numbered one face only: up to 8 characters

                                                                                                                                                                                                                                                                Exploration Geology and Field Equipment
         SKU                        DESCRIPTION                                                                                   Numbered and barcoded: barcode and up to 8 characters
        CBN17           7 Digit - 8x12cm to 12x18cm Calico Bags
                                                                                                                                       SKU                      DESCRIPTION
        CBN18           8 Digit - 8x12cm to 12x18cm Calico Bags
                                                                                                                                    1156-10000                 Numbered Only
        CBN27          7 Digit - 18x30cm to 24x36cm Calico Bags
                                                                                                                                    1156-10001          Barcoded & Numbered, 8 Digits
        CBN28          8 Digit - 18x30cm to 24x36cm Calico Bags
                                                                                                                                    BNBARON                   Tag Applied to Bag
     Other variations are available such as out of sequence
     numbers.                                                                                                                     Attachment of numbering tags can be arranged upon
                                                                                                                                  request or, if customers would prefer to attach tags
                                                                                                                                  themselves, Westernex also supplies the products nec-
                                                                                                                                  essary for the job.

                                                                                                                              B
                                                                                                                                  Examples of Local Calico Bag Numbering, Ticketing & Tagging
                                                                             A
     Calico Bag Local Print Numbering
     Locally printed bags available in two heights.

         SKU                        DESCRIPTION
A       CBN03                         25mm Text
B       CBN04                         50mm Text

     Calico Bag Local Ticket Numbering
     Westernex can supply tickets with or without barcodes,
     these can also be applied to bags ready for use.

          SKU                        DESCRIPTION
       1112-00057                 Number Only Tickets
       1112-00058              Barcode & Number Tickets
       BNITNOBN                   Ticket Applied to Bag
     Attachment of numbering tickets can be arranged upon
     request or, if customers would prefer to attach tags
     themselves, Westernex also supplies the products nec-
     essary for the job.

     Other types of numbering is available                                                                                                                                                                       Other types of numbering is available
     upon request. Minimum order quantities                                                                                                                                                                      upon request. Minimum order quantities
     may apply. Get in touch today.                                                                                                                                                                              may apply. Get in touch today.
11       Section 05 · Exploration Geology and Field Equipment                                                                                                                                            Exploration Geology and Field Equipment · Section 05   12

                               C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                    s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
     Calico Bags Factory Numbering                                                                                               Calico Bag Configurations
         Ideal for larger scale quantities                                                                                       Other options available upon request. Minimum order quantities may apply. Get in touch with a friendly
         Select your bag type                                                                                                    team member today, email us supply@westernex.com.au.
         Select your bag numbering size
         Select your numbering, ticket or tag type
                                                                            B

                                                                                                                             A

                                                                                                                                                                                                                                                                Exploration Geology and Field Equipment
     Calico Bag Factory Print Numbering
     We offer two font sizes on our factory printed bags. Other
     sizes may be available upon request.
                                                                                                                                 Supply Plain Bags                                                     Supply Plain Bags with Sequential Number
          SKU                       DESCRIPTION
A       CBN21-20                     20mm Text
B       CBN21-50                     50mm Text

                                                                                                                                 Supply Plain Bags with Sequential Number & Bar                        Supply Plain Bags with Sequential Number & Ticket
                                                                                                                                 Code (scanner & software also available)
                                                                       D
                                                                                                                                                                                                                                       (Other colour options)

     Calico Bag Factory Ticket Numbering
     Factory barcode labels and tickets are ordered in bulk for
     you long term drill programs.

          SKU                       DESCRIPTION
C        CBN20          Barcode & Number Ticket Sewn into Bag
D        CBN25       Barcode & Number Ticket 7x7cm Sewn into Bag
     There are lead times on the factory numbering/ticketed
     bags as they are made overseas. Speak to one of our                                                                         Supply Plain Bags with Sequential Number & Tag                        Supply Plain Bags with Coloured Strings
     sales team members about your requirements. We
     stock a number of different numbered bags for cus-
     tomers that draw off them as required.
                                                                                                                                  *Our product.                                                         *Opposition’s product.

     Westernex also offers customisable
     scanners and software for this                                                   C
     product. Please refer to our sections
     on Barcode Scanner Bags.
                                                                                                                                 Fine Calico Bags                                                      Fine Calico Bags (opposition)

13       Section 05 · Exploration Geology and Field Equipment                                                                                                                                     Exploration Geology and Field Equipment · Section 05          14

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                              s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
                                                                                                                                     Geochem Bags
     Geochem Bags
          Come in an array of sizes depending on your needs
          Two bag options: wire tie or plain
          Composed of high quality materials                                                                                         Geochem Carton
          Sturdy and high-strength paper will protect samples
                                                                                                                                                    APPROX. BAG
          Designed for both wet and dry samples                                                                                         SKU          CAPACITY                    SIZE (LxWxH)
                                                                                                                                                      (FILLED)
          Our bags come with corresponding Geochem Cartons
                                                                                                                                      CTN21118        25 bags                   21" x 11" x 8"
          Westernex offers a multitude of labelling options                                                                                                            Inside Dims: 535 x 280 x 205mm

                                                                                                                                                                                                                                                                               Exploration Geology and Field Equipment
          For storage of samples                                                                                                      CTN5315         25 bags                   15" x 3" x 5"
                                                                                                                                                                       Inside Dims: 362 x 83 x 124mm
                                                                                                                                      CTN8415         20 bags                    15" x 4" x 8"
                                                                                                                                                                       Inside Dims: 381 x 128 x 206mm
     All our manufacturers abide by the ETI code.

                                                                                                                                     Geochem Barcode Numbering Stickers
     Our Geochem Bags                                                                                                                Westernex also provides barcode stickers for your Geo-
     With over 25 years in the game, Westernex has provided the Exploration & Mining sector with top quality sample bags. Our        chem Bag labelling needs. Our barcode stickers are printed
     Geochem Bags have been specifically designed and created for both wet and dry samples. We have tried and tested it, and         on matte stock with permanent adhesive. They come in
     we know our bags deliver. Our Geochem bags are made from sturdy and high-strength paper in order to provide great pro-          two sizes to suit the different sized Geochem Bags you
     tection for your precious samples. And just like our Geochem Bags, our Geochem Cartons are also composed of high quality        might have.
     materials that provide support and security for your bags. Both our Geochem Bags and Cartons come in an array of sizes as
                                                                                                                                              SKU                   SIZE                    UOM
     well as two bag type options; one being a wire tie and one plain.
                                                                                                                                        1112-00201-GL            50 x 40mm                Thousand
                                                                                                                                        1112-00201-GS            35 x 25mm                Thousand

                                                                                                                                              SKU               DESCRIPTION                 UOM
                                                                                                                                         1112-00202              Apply label              Thousand
                                                                                                                                     Please note: Westernex supplies barcode stickers for the
                                                                                                                                     end user to apply however, we do offer to apply the stickers
                                                                                                                                     for the customer if required.

     Geochem Bags
              SKU               TYPE                  SIZE
             GCB-1             No Tie          3”x 5”- 75 x 125mm
                                                                                                                                                                                                                                   A                                       B
            GCB-3              No Tie          4”x 8”- 100 x 200mm
            GCB-4              No Tie         5”x 10”- 125 x 250mm
              B37             Wire Tie         3" x 5" - 75 x 125mm
              B38             Wire Tie        4" x 8" - 100 x 200mm                                                                  Geochem Bag Local Numbering
              B47             Wire Tie        6" x 5" - 125 x 150mm                                                                  We also give customers the option to have your Geochem
              B36             Wire Tie        5" x 10" - 125 x 250mm                                                                 Bags stamped with a sequential number.
     UOM: All bags come in cartons of 1000.
                                                                                                                                           SKU                         SIZE                       UOM
                                                                                                                                         GBN17            Up to 7 digits, 1-line stamp          Thousand
                                                                                                                                 A
                                                                                                                                         GBN18            Up to 14 digits, 2-line stamp         Thousand
                                                                                                                                 B       GBN20                      12mm Print                  Thousand

                                                                                                                                                                                                                            Other types of numbering is available
                                                                                                                                                                                                                            upon request. Minimum order quantities
                                                                                                                                                                                                                            may apply. Get in touch today.
15        Section 05 · Exploration Geology and Field Equipment                                                                                                                                                      Exploration Geology and Field Equipment · Section 05       16

                                  C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                            s u p p l y@ we s t e r n e x .c o m . a u
Exploration Geology & Field Equipment - CATALOGUE www.westernex.com.au
CATALOGUE 2020
                                                                                                                                              Plastic Bags
     Plastic Bags
          Manufactured from highly durable plastic
          Longer life even when exposed to sunlight
          White panels for labelling                                                                                                          Green Plastic Bags with White Panel
          UV stabilisation ensures longer life expectancy                                                                                          SKU             SIZE          THICKNESS     CARTON QTY
          Diverse range of sizes for various sampling needs                                                                                       B16-P         150 x 230mm       150um        Carton of 1000
          Durability allows optimum security for samples                                                                                          B07-P         200 x 300mm        90um        Carton of 1000
          Wide array of colour options for all needs                                                                                              B08-P         250 x 380mm       125um        Carton of 500
          Puncture-resistant                                                                                                                      B09-P         300 x 450mm       125um        Carton of 400

                                                                                                                                                                                                                                                                                Exploration Geology and Field Equipment
                                                                                                                                                1107-00500      300 x 450mm       200um        Carton of 250
     All our manufacturers abide by the ETI code.                                                                                                 B14-P         355 x 460mm       125um        Carton of 500
                                                                                                                                                  B10-P         400 x 600mm       125um        Carton of 250
                                                                                                                                                1107-00501      400 x 600mm       200um        Carton of 200

     Green colour ex stock. All other colour options to order.                                                                                    B05-P         450 x 750mm        90um        Carton of 250
                                                                                                                                                  B11-P         450 x 750mm       150um        Carton of 200
                                                                                                                                                1107-00502      450 x 750mm       200um        Carton of 200
                                                                                                                                                  B06-P         600 x 900mm        90um        Carton of 150

     Our Plastic Bags                                                                                                                             B12-P         600 x 900mm       150um        Carton of 100

     Westernex manufactures their own plastic bags to our strict standards. We have been supplying mining sample bags for over
     25 years so know what is expected of our quality. Our bags are UV stabilised to ensure the life expectancy in the field. With
     over 25 years in the game we have had a lot of input from our customer base to ensure ours bags dominate the market.

            SIZE (mm)                SIZE (in)              THICKNESS (um)             SAMPLE CAPACITY (kg)                 CARTON QUANTITY

            150 x 230                  6x9                            150                      2 to 4                              1000       Clear Plastic Bags
                                                                                                                                              Our clear plastic bags without the white panel are ex stock.
            200 x 300                  8 x 12                         125                      1 to 2                              1000       Clear plastic bags with white panels can be made to order.
            250 x 380                 10 x 15                         125                      2 to 4                              500
                                                                                                                                                   SKU             SIZE          THICKNESS     CARTON QTY
            300 x 450                 12 x 18                         125                      4 to 8                              300
                                                                                                                                                1107-00203      300 x 375mm       150um        Carton of 500
            400 x 600                 16 x 24                         150                     18 to 20                             250          B09CLEAR        300 x 450mm       125um        Carton of 400

            450 x 750                 18 x 30                      90 or 150                  25 to 30                             200             B14C         355 x 460mm       125um        Carton of 300
                                                                                                                                                1107-00204      435 x 850mm       200um        Carton of 100
            600 x 900                 24 x 36                    90, 150 or 200               30 to 50                             100
                                                                                                                                                B11-CLEAR       450 x 750mm       120um        Carton of 200
                                                                                                                Plastic Bags guide

                                                                                                                                              Black Plastic Bags with White Panel
                                                                                                                                                      SKU                 SIZE       THICKNESS    CARTON QTY
                                                                                                                                                  PB450-BLACK       450 x 750mm        200um      Carton of 120
                                                                                                                                               PB450X750X200UM      450 x 750mm        200um      Carton of 100
                                                                                                                                                      B18           600 x 900mm        150um      Carton of 100
                                                                                                                                                     B03-P          600 x 900mm        200um      Carton of 100

                                                                                                                                                                  UV stabilised mining bags in a range of sizes and thicknesses. Bags can be made
                                                                                                                                                                                       to order (minimum quantities apply).

17        Section 05 · Exploration Geology and Field Equipment                                                                                                                                                           Exploration Geology and Field Equipment · Section 05   18

                                    C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                               s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Plastic Bags                                                                                                            Plastic Bags
                                                                                                                             We also offer customisable numbering and labelling options for our bags, get in
     Plastic Bag Local Print Numbering                                                                                       touch for more information:
     Westernex can number your plastic bags in a multitude of
     ways, the options are endless, please call to discuss your
     requirements.

         SKU                       DESCRIPTION
        PBN17                15mm, 7 Digit - Small Bags
        PBN18                15mm, 8 Digit - Small Bags
        PBN01                 25mm Text - Small Bags

                                                                                                                                                                                                                                                                 Exploration Geology and Field Equipment
        PBN02                 25mm Text - Large Bags
        PBN05                 50mm Text - Large Bags

     Other types of numbering is available
     upon request. Minimum order quantities                                                                                  Single line print on green and black plastic bags                     Numbering and barcode labelling on green plastic bags
     may apply. Get in touch today.                                                                                          and self seal bags

     Plastic Bag Labels
     Label adhesive with barcode and number.

               SKU                 SIZE                    UOM
        1112-00200-PL          100 x 150mm                Hundred
        1112-00200-PS          100 x 50mm                 Hundred

               SKU                      DESCRIPTION
            PBN04               Apply adhesive to plastic bags

                                                                                                                             Double line print on green and black plastic bags                     Custom, out of sequence single and double line numbering on
                                                                                                                             and self seal bags                                                    green plastic bags
     Numbered Roo Tags
     Sturdy seals numbered in sequences of a hundred.

                SKU                           UOM
            1156-00032                       Hundred

     Plastic Pulltight Seal Numbered
     Single moulded easy to apply adjustable security seal with
     gripping ribs.

            SKU                            UOM
         1156-00030                       Thousand
                                                                                                                             Handwritten labelling on green and black plastic bags                 Numbering on green plastic bags
                                                                                                                             and self seal bags

19       Section 05 · Exploration Geology and Field Equipment                                                                                                                                      Exploration Geology and Field Equipment · Section 05          20

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                               s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Plastic Bags                                                                                                                 Miscellaneous Bags
                                                                                                                                  Trash Pack Bag & Frame
                                                                                                                                  These bags are made of a stiff woven high density polye-
                                                                                                                                  thelene (HDPE) with double stitched edge. Also available
     Round Aluminium Scoop                                                                                                        is the trash pack frame.
            SKU                 SIZE                 UOM
                                                                                                                                         SKU           DESCRIPTION                SIZE                                                                        C
         1003-03110        140g / 5oz                Each
                                                                                                                              A       1108-00103       Trash Pack Bag     710 x 710 x 960mm
         1003-03111        340g / 12oz               Each
                                                                                                                              B       1108-00104            Frame to Suit Trash Pack Bag
         1003-03112        680g / 24oz               Each
         1003-03113        1kg / 38oz                Each
         1003-03114       1.6kg / 57oz               Each                                                                         Wool Bale Fastener

                                                                                                                                                                                                                                                                          Exploration Geology and Field Equipment
         1003-03115       2.3kg / 84oz               Each                                                                         Pressed cut to ensure the finest point. Penetrates fabric
                                                                                                                                  first time. Galvanised for long life.

                                                                                                                                                             SKU
                                                                                                                              C                          1108-00108

     Cable Ties
     » High Quality 66UL Nylon
     » UL94V-2 Flammable rating                                                                                                                                                                                                                                    B
     » UV-stabilised to resist material breakdown and to
       increase service life

           SKU        COLOUR              SIZE           UOM
       1303-00100      Black           150 x 3.6mm     Hundred
       1303-00101      Black           200 x 4.8mm     Hundred
       1303-00102      Black           250 x 4.8mm     Hundred
       1303-00103      Black           300 x 4.8mm     Hundred
       1303-00104      Black           370 x 4.8mm     Hundred
       1303-00105      Black           450 x 8.0mm     Hundred
       1303-00106      Black           550 x 8.0mm     Hundred

     We offer customiseable configurations for
     sample ticket books depending on the
     required application. For more information
     please refer to our Tickets section.

                                                                                                                                                                                         A

21       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                      Exploration Geology and Field Equipment · Section 05   22

                               C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                              s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
                                                                                                                                             Polywoven Bags Numbering
     Polywoven Bags
         Manufactured from highly durable plastic
         Longer life even when exposed to sunlight
         White panels for labelling
         UV stabilisation ensures longer life expectancy
         Diverse range of sizes for various sampling needs
         Durability allows optimum security for samples                                                                                      Polywoven Bag Local Print Numbering
         Puncture-resistant                                                                                                                  Westernex can number your bags in a multitude of ways, the
                                                                                                                                             options are endless, please call to discuss your requirements.

                                                                                                                                                                                                                                                                             Exploration Geology and Field Equipment
                                                                                                                                                 SKU                        DESCRIPTION
     All our manufacturers abide by the ETI code.                                                                                              PWBN01                        50mm Text
                                                                                                                                               PWBN02                        25mm Text

     Our Polywoven Bags
     Westernex manufactures their own polywoven bags to our strict standards. We have been supplying mining sample bags for
     over 25 years so know what is expected of our quality. Our bags are UV stabilised to ensure the life expectancy in the field.
     Bundled in lots of 100 and baled in lots of 500.                                                                                        Polywoven Bag Local Tag Numbering
                                                                                                                                             Westernex can supply hard tags with or without barcodes,
                  SKU                                                 SIZE                                                CAPACITY           these can also be applied to bags ready for use.
                  B39                                     18" x 30" - 450mm x 750mm                                           20-25kg        Numbered one face only: up to 8 characters
                  B40                                     20" x 34" - 500mm x 850mm                                           20-25kg
                                                                                                                                             Numbered and barcoded: barcode and up to 8 characters
                  B41                                     22" x 39" - 550mm x 975mm                                           45-50kg             SKU                        DESCRIPTION
              PWB6101040                                  24" x 41" - 600mm x 1025mm                                          45-50kg         1156-10000-P                  Numbered Only
             PWB750X1225                                  30" x 49" - 750mm x 1225mm                                          45-50kg         1156-10001-P           Barcoded & Numbered, 8 Digits
                                                                                                                                               BNBARON-P                   Tag Applied to Bag
                                                                                                                                             Attachment of numbering tags can be arranged upon
                                                                                                                                             request or, if customers would prefer to attach tags
                                                                                                                                             themselves, Westernex also supplies the products nec-
                                                                                                                                             essary for the job.
     Wire Tie Tool                                                                            A
     An ideal ratchet action tool for quick tying of polywoven
     sacks, large plastic and calico bags. Smooth spiral action.
     Rubber comfort grip.
                                                                                                                      B
            SKU                       DESCRIPTION
A        1303-00107                   Wire Tie Tool
                                                                                                        C
B        1303-00107                     Wire Ties
C        1303-00107         UV Nylon Cable Ties, 370 x 7.6mmm

23       Section 05 · Exploration Geology and Field Equipment                                                                           23                                                                            Exploration Geology and Field Equipment · Section 05   24

                              CIVIL | MINING
                                           s u|p pE lXy@
                                                       PL O
                                                          weR AT
                                                              s t eI rOnNe x|.cI N
                                                                                 omDU
                                                                                    . aSuT R I A L | C O N S T RU C T I O N                                                                 s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
                                                                                                                                 Zip Seal Bags
     Zip Seal Bags
         Manufactured from highly durable plastic
         Longer life even when exposed to sunlight
         White panels for labelling
         UV stabilisation ensures longer life expectancy
         Diverse range of sizes for various sampling needs                                                                       Plastic Bag Local
         Durability allows optimum security for samples
                                                                                                                                 Print/Stamp Numbering
                                                                                                                                 Westernex can number your plastic bags in a multitude of
                                                                                                                                 ways, the options are endless, please call to discuss your
                                                                                                                                 requirements.

                                                                                                                                                                                                                                                                 Exploration Geology and Field Equipment
                                                                                                                                     SKU                        DESCRIPTION
     All our manufacturers abide by the ETI code.
                                                                                                                                    SSB01                          12mm Print
                                                                                                                                    SSB02                7 Digit - 300 x 450mm Bags
                                                                                                                                    SSB03                8 Digit - 300 x 450mm Bags

     Our Zip Seal Bags
     A panelled range of self-sealing bags with white write-on panels so you can label contents with a pen. These bags are the
     standard 40-50um quality for everyday use. Reusable, resealable storage for small parts & samples. (Our 100um range have
     white panels and may be numbered or bar-coded upon customer’s request).

     Zip Seal Bags 40-50um
            SKU                           SIZE
          SS32-50                3" x 2" - 75mm x 50mm
          SS34-50               3" x 4" - 75mm x 100mm
          SS35-50               3" x 5" - 75mm x 125mm
          SS46-50               4" x 6" - 100mm x 150mm
          SS47-50               4" x 7" - 100mm x 175mm                                                                          Zip Seal Bags Barcode
          SS58-50               5" x 8" - 125mm x 200mm                                                                          Numbering Stickers
          SS68-50               6" x 8" - 150mm x 200mm                                                                          Westernex also provides barcode stickers for your Zip
          SS69-50               6" x 9" - 150mm x 230mm                                                                          Seal Bag labelling needs. Our barcode stickers are printed
                                                                                                                                 on matte stock with permanent adhesive. They come in
          SS912-50             9" x 12" - 230mm x 300mm
                                                                                                                                 two sizes to suit the different sized Zip Seal Bags you
         SS1416-50             16" x 14" - 400mm x 355mm
                                                                                                                                 might have.

                                                                                                                                         SKU                SIZE                  UOM
                                                                                                                                    1112-00203-SL        50 x 40mm              Thousand
     Zip Seal Bags 100um                                                                                                            1112-00203-SS        35 x 25mm              Thousand
             SKU                           SIZE
           SS34-100               3" x 4" - 75mm x 100mm                                                                                 SKU            DESCRIPTION               UOM

           SS35-100               3" x 5" - 75mm x 125mm                                                                             1112-00204          Apply label            Thousand

           SS46-100              4" x 6" - 100mm x 150mm                                                                         Please note: Westernex supplies barcode stickers for the
                                                                                                                                 end user to apply however, we do offer to apply the stickers
           SS47-100              4" x 7" - 100mm x 175mm                                                                         for the customer if required.
           SS56-100              5" x 6" - 125mm x 150mm
           SS57-100              5" x 7" - 125mm x 175mm
           SS58-100              5" x 8" - 125mm x 200mm
           SS69-100              6" x 9" - 150mm x 230mm
                                                                                                                                 Other types of numbering is available upon
          SS810-100             8" x 10" - 200mm x 250mm                                                                         request. Minimum order quantities may apply.
          SS912-100             9" x 12" - 230mm x 300mm                                                                         Get in touch today.
          SS1115-100            11" x 15" - 275mm x 375mm
          SS1212-100            12" x 12" - 300mm x 300mm

25       Section 05 · Exploration Geology and Field Equipment                                                                                                                                             Exploration Geology and Field Equipment · Section 05   26

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                      s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Tickets                                                                                                                 Tickets

     Sample Ticket Books                                                                                                     Stapler Pliers
     Westernex has standard ticket books available. We carry                                                                 » Case hardened steel components for extreme durability
     both 2 ticket booklets and 3 ticket booklets with generic                                                               » Ergonomic design and patented easy squeeze bearing
     numbering. Custom tickets can be ordered to your spec-                      A
                                                                                                                               system for easy of use
     ifications and layouts, including company logos and
     custom numbering. Please let one of our sales team                                                                      » Quick-load magazine
     members know your requirements.                                                                                         » Pneumatic assembly available
                                                                                                                             » Bearing system allows an easy squeeze action across
               SKU                        SIZE                                                                                 entire operating sequence creating a quicker, tighter

                                                                                                                                                                                                                                                             Exploration Geology and Field Equipment
A           1112-00301             2 Part 50 x 160mm                                                                           clinch with less strain
B         1112-00300               3 Part 50 x 240mm                                                                         » Coated top-load magazine permits faster, smoother
                                                                                                                               staple loading
C           1112-50002              1 Part 50 x 90mm
D         1112-00302               2 Part 85 x 185mm                                                                                 SKU            DESCRIPTION                  SIZE
E         1112-00303               3 Part 115 x 100mm                            B                                               1153-00010         Stapler Pliers               ---
F         1112-00304               3 Part 75 x 240mm                                                                             1153-00013            Staples                   6mm
G         1112-00305               3 Part 80 x 190mm                                                                             1153-00011            Staples                 10mm
                                                                                                                                 1153-00012            Staples                 12mm

                                                                                                     E
                                                                                                                             Calico Numbering Tickets
                                                                                                                             Westernex can supply tickets with or without barcodes,
                                         D                                                                                   these can also be applied to bags ready for use.
      C
                                                                                                                                     SKU              DESCRIPTION                  SIZE
                                                                                                                                 1112-00057            Number Only             75 x 78.5mm
                                                                                                                                 1112-00053         Barcode & Number           75 x 78.5mm

        F                                                                       G

                                                                                                                             Tag Applicator
                                                                                                                             A single shot applicator, used for applying flexi tags. It is
                                                                                                                             easy to tag and reload in seconds.

                                                                                                                                                          SKU
                                                                                                                                                      1156-10002

                                                                                                                             Plastic Tags
                                                                                                                             Westernex can supply hard tags with or without barcodes,
                                                                                                                             these can also be applied to bags ready for use.
                                                                                                                             Numbered one face only: up to 8 characters
                                                                                                                             Numbered and barcoded: barcode and up to 8 characters

                                                                                                                                     SKU                         DESCRIPTION
                                                                                                                                 1156-10000                      Numbered Only
                                                                                                                                 1156-10001            Barcoded & Numbered 8 Digits

27          Section 05 · Exploration Geology and Field Equipment                                                                                                                                      Exploration Geology and Field Equipment · Section 05   28

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                  s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Batteries

                                                                             A             B

                                                                                                           C                D
     Energizer Battery Alkaline
            SKU                             SIZE
A        1111-00020                      1.5V AAA
B        1111-00021                        1.5V AA
C        1111-00022                        1.5V C
D        1111-00023                        1.5V D

                                                                                                                                                                                                                                                                                                         Exploration Geology and Field Equipment
E        1111-00025                          6V                                            E                   F
F        1111-00024                          9V

     Energizer Battery Lithium
            SKU               UOM                         SIZE
G
H
         1111-00110
         1111-00123
                             2 Pack
                             2 Pack
                                                          AAA
                                                          AA
                                                                                               G               H
                                                                                                                                           Westernex
                                                                                                                                           is a proud
                                                                                                                                          distributor of
     Energizer Battery Rechargeable NimH
     These batteries are made with economical and high energy
                                                                                                                                        the full range of
     nickel. The 800mAh (AAA) batteries can hold charge for
     up to six months, while the 2300 mAh (AA) batteries can
     do so for up to 1 year. They can be charged hundreds and
                                                                                                                                          Dixon Mining                                      Insist On Dixon Quality
     hundreds of times and are suitable for digital cameras,
     gaming and audio devices.                                                                 I               J                            products.                                       Westernex is a distributor of the full range of Dixon Mining products
                                                                                                                                                                                            for material transfer applications including Air, Water, Chemical, Fuel,
              SKU                 UOM                       SIZE
                                                                                                                                                                                            Slurry, Oils and Fluids.
           1111-00028             2 Pack                    AAA
I
           1111-00029             4 Pack                    AAA
           1111-00026             2 Pack                    AA                                                                                                                              Dixon is the exclusive manufacturer of Minsup™ fittings and a
J                                                                                                                                                                                           supplier of Plasson® compression fittings, FloMAX fueling systems,
           1111-00027             4 Pack                    AA
                                                                                                                                                                                            Bayco tank equipment and Dixon fire equipment. Dixon also provides
                                                                                                                                                                                            safe, fully integrated made-to-order assemblies for a wide range of
                                                                                                                                                                                            material transfer applications.

     Battery Charger (Suitable For 9V, AA,
     AAA, C, D)
     Recharges up to 6 batteries at one time. Automatically
     adjusts charging rates depending on battery type.
     Desktop housing. Fitted with Aust/NZ mains plug.
     Batteries not included.

            SKU                             SIZE
         1111-00030                   9V, AA, AAA, C, D

                                                                                                                                Uncommon Excellence • Uncommon Excellence • Uncommon Excellence • Uncommon Excellence • Uncommon Excellence • Uncommon Excellence • Uncom

29       Section 05 · Exploration Geology and Field Equipment                                                                           1300 134 651 • dixonvalve.com.au •                                    Exploration Geology and Field Equipment · Section 05
                                                                                                                                                                                                                                               ©2018 Dixon Valve & Coupling, LLC. All rights reserved.   30

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                           s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Shelter                                                                                                                 Shelter

     Deluxe 3.0 Gazebo                                                                                                       12x15 Canvas Tent Cabin
     » 300 x 300cm ground and canopy coverage                                                                                » Features & Benefits
     » Fire retardant 300 Denier UVtex treated polyester                                                                     » Your choice of 2 or 3 rooms with a removable
       canopy with internal silver coating that blocks more                                                                    hanging room divider included
       than 98% of UV radiation                                                                                              » Excellent ventilation via double front D doors plus full
     » Certified by Australian Engineers to Building Code of                                                                   size side doors and large side and rear windows
       Australia for sufficiency of design for temporary                                                                     » Plenty of head and shoulder room provided by a near
       shade structures                                                                                                        vertical wall design
     » High quality powder coated steel folding frame with                                                                   » Large side shade awnings that zip closed over the
       ABS componentry for strength                                                                                            doors for added weather security
     » Triple layer 600 Denier polyester reinforcing points in                                                               » Commune awning to connect your awning to another

                                                                                                                                                                                                                                                         Exploration Geology and Field Equipment
       key wear locations                                                                                                      tent’s awning for a double size sunroom
     » Heavy duty 32mm tubular steel leg sections with a                                                                     » Handy canvas multi-pocket, organiser, lantern loop &
       two stage system for a space conscious pack size                                                                        power cord guides
     » Oversized moulded buttons for easy height                                                                             » Carry bag for tent & poles provided
       adjustment
     » Externally bound roof line seams to improve tension
                                                                                                                                    SKU                 SIZE             WEIGHT
       in the canopy and large roof vents for improved and
       wind dissipation                                                                                                          1001-00254        Fits 12 adults         73kg
     » Heavy duty wheeled carry bag for easy
       transportation and protected storage
     » Portable, quick to erect powder coated frame with no
       assembly required

            SKU                SIZE                WEIGHT
         1001-00112        300 x 300cm              23kg
                                                                                                                             Tourer 9 Person Canvas Tent
                                                                                                                             » Single one touch centre pole for easy erection
                                                                                                                             » Excellent ventilation with large side windows, front
                                                                                                                               and rear doors
                                                                                                                             » Large front awning plus window awnings that zip
     Sturt Expedition Single Swag                                                                                              closed for added weather security
     » Tough 230gsm SatProofTM 600+ ripstop canvas with                                                                      » Convenient lantern loop and power cord guides
       a PVC vinyl base                                                                                                      » Carry bag for tent & poles provided
     » An alloy front pole with fibreglass rear poles
     » Protective head awning with No-See-Um mesh panels                                                                            SKU                 SIZE             WEIGHT
       for ventilation                                                                                                           1001-14010         Fits 4 adults         18kg
     » 5cm high density open-cell foam mattress
     » Easy access half-length zip for easy entry

            SKU                SIZE                WEIGHT
         1001-13001         Fits 1 adult             6kg

                                                                                                                             Tourer 10 Person Plus Canvas Tent
                                                                                                                             » Single one touch centre pole for easy erection plus an
     Mitchell Expedition Double Swag                                                                                           external rear support pole
                                                                                                                             » Exceptional ventilation with a large front door, full
     » Tough 230gsm SatProofTM 600+ Ripstop Canvas with                                                                        length side windows plus a rear all weather gusseted
       PVC vinyl shield floor                                                                                                  window
     » 3 pole dome style construction with generous height                                                                   » Large front awning plus window awnings that zip
       and protective head and foot awnings for all weather                                                                    closed for added weather security
       ventilation                                                                                                           » Convenient lantern loop and power cord guides
     » High-tensile DuralliumTM 7001 alloy poles                                                                             » Innovative Invisible Bucket HDPE floor design so
     » No-See-Um mesh for total insect control                                                                                 seams are elevated away from water
     » 5cm high density open-cell foam mattress                                                                              » 3 layer Insulcell Roof for summer cool and winter
                                                                                                                               warmth
            SKU                SIZE                WEIGHT                                                                    » Carry bag for tent & poles provided
         1001-13008        Fits 2 adults            9.2kg
                                                                                                                                    SKU                 SIZE             WEIGHT
                                                                                                                                 1001-14006         Fits 8 adults         26kg

31       Section 05 · Exploration Geology and Field Equipment                                                                                                                                     Exploration Geology and Field Equipment · Section 05   32

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                              s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
                                                                                                                                 Snake Protection
                                                                         Hottap Outing
                                                                         Perfect for pumping directly from a creek or lake.
                                                                         If you’re pumping water from a bucket or reservoir,
                                                                         chances are that you’ll empty it. The pump won’t be
                                                                         damaged by running dry.*
                                                                         » Water flow of up to 6L/min, which is to be
                                                                           compared to the maximum of less than 4.5L/min of
                                                                           weaker all-in-one designs
                                                                         » Backlit LED display will show you the exact degrees
                                                                           of hot water

                                                                                                                                                                                                                                                                             Exploration Geology and Field Equipment
                                                                         » Built-in battery indicator lets you know in advance
                                                                           if the D-cell batteries are running low
                                                                         » Internal micro-processor prevents the water
                                                                           temperature from going above +50°C, protecting
                                                                           family and pets

                                                                                                      SKU
                                                                                                   1001-00454

                                                                                *The powerful pump self-primes with water to     SnakeProtex durable and lightweight gaiters are scientifically proven to protect the wearer from the world’s most venomous
                                                                                a height (head) of up to 1.8m from the source    snakes. They outperform similar products currently available on the market globally. Developed in Australia, home of some
                                                                                - and can push up to 30m up a slope.             of the world’s deadliest snakes, SnakeProtex™ have been hugely popular amongst campers, hikers, council workers, surveyors,
                                                                                                                                 hunters, and home gardeners — and now, they have been improved even further!
                                                                                                                                 The all new SnakeProtex Extreme sports a range of features such as adjustable boot straps allowing for a better fit amongst a
                                                                                                                                 larger range of different boots and shoes. Adjustable top leg straps allow for a firmer, closer, and safer fit. A new press tab installed
                                                                                                                                 to clip over the zipper provides better security stopping the zip from moving whilst walking, working or out having fun.
     Joolca Range
                                                                                                                                 With its water-repellent tendencies and tougher 900 weight denier external black fabric, the new gaiters now offer you even
          SKU                    DESCRIPTION
                                                                                                                                 better protection from snake strikes while looking like every day work-wear and lasting the distance.
       1001-00450                   Hottap
       1001-00451                 Hottap Bag
       1001-00452
       1001-00453
                                 Hottap Jacket
                            Hottap Drawbar Mount
                                                                                                                                 SnakeProtex Extreme Protective Chaps
       1001-00455             Flotap 12V Pump Kit                                                                                        SKU                            SIZE

       1001-00456              Ensuite Plumbing                                                                                      1001-11305-S                       Small

       1001-00457              Outback Plumbing                                                                                     1001-11305-M                      Medium

       1001-00458             Gasknect Couple Set                                                                                    1001-11305-L                       Large

       1001-00459                 Ensuite Tent                                                                                      1001-11305-XL                    Extra Large

       1001-00460            Ensuite Shower Stand
                                                                                                                                 Size Guide
                                                                                                                                      SIZE       CIRCUMFERENCE     LENGTH          TO FIT LEG
                                                                                                                                                     AT KNEE                    CIRCUMFERENCE
                                                                                                                                     Small           430mm         385mm              410mm
                                                                                                                                    Medium           490mm         400mm              470mm
                                                                                                                                     Large           550mm         400mm              530mm
                                                                                                                                   Extra Large       600mm         400mm             580mm

33     Section 05 · Exploration Geology and Field Equipment                                                                                                                                                  Exploration Geology and Field Equipment · Section 05            34

                         C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                              s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Coolers & Eskies                                                                                                       Coolers & Eskies

     Water Cooler 12L
     »   Push button tap
     »   Lock down handle                                                                                                   Willow Cooler Jug Alpine 2.5L
     »   Internal Size: 240ø x 270Hmm                                                                                       Smaller sized jug is ideal for picnics and day trips. Sturdy
     »   External Size: 335ø x 350Hmm                                                                                       drinking cup. Insulated with dense polyurethane to keep
     »   Weight: 2.42kg                                                                                                     drinks cooler for longer. BPA free.

                                                                                                                                                                                                                                                          Exploration Geology and Field Equipment
             SKU                         SIZE                                                                                       SKU                          SIZE
          1005-00020                      12L                                                                                   1005-00015                       2.5L

     Water Cooler 36L                                                                                                       Willow Cooler Jug with Tap 5L
     »   Push button tap                                                                                                    High performance cooling capabilities. Rubber feel
     »   Robust side handles                                                                                                button on tap. Large press lock pourer cover to protect
     »   Internal Size: 320ø x 465Hmm                                                                                       the area from dirt, eliminating dirt contamination. Finger
                                                                                                                            grip on the bottom of jug to assist in holding the jug while
     »   External Size: 450ø x 555Hmm                                                                                       pouring. Insulated with dense polyurethane to keep
     »   Weight: 4.64kg                                                                                                     drinks cooler for longer. BPA free.
             SKU                         SIZE                                                                                       SKU                          SIZE
          1005-00021                      36L                                                                                   1005-00016                        5L

     Water Cooler 57L                                                                                                       Coleman Cooler Jug 7.6L
     »   Push button tap                                                                                                    Patented, dripless tap. Instant on/off, fast flow tap means
     »   Robust side handles                                                                                                no messy dripping and fast refreshment. Ideal size for
     »   Internal Size: 390ø x 525Hmm                                                                                       picnics, trips, camping and parties. Flip spout, for easy
                                                                                                                            pouring and sipping. Durable polyethylene case resists
     »   External Size: 540ø x 625Hmm                                                                                       dents, scratches and fading. Wide-mouth, screw-on cap
     »   Weight: 7.36kg                                                                                                     for easy filling and cleaning.
             SKU                         SIZE                                                                                       SKU                          SIZE
          1005-00022                      57L                                                                                   1005-00206                        7.6L

35        Section 05 · Exploration Geology and Field Equipment                                                                                                                                     Exploration Geology and Field Equipment · Section 05   36

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Coolers & Eskies                                                                                                       Coolers & Eskies

     Coleman Cooler 5L Take 6
     Holds 6 cans. FlipLid™ Top reverses to become a serving
     tray with two molded cup holders. Wide bottom for
     added stability and cold-keeping capability ThermO-
     ZONE™ Insulation contains no CFCs, HFCs or HCFCs,                                                                      Coleman Cooler 42L Wheeled
     which deplete the ozone.

                                                                                                                                                                                                                                                         Exploration Geology and Field Equipment
                                                                                                                            Stock up on all your favourite bevvies for a week away
                                                                                                                            with the Coleman Wheeled Cooler – 42L. Accommodat-
            SKU                          SIZE                                                                               ing up to 113kg on top so you can use it as an extra seat,
         1005-00010                       5L                                                                                the Wheeled Cooler is easy to cart around wherever
                                                                                                                            you might be!

                                                                                                                                   SKU                           SIZE
                                                                                                                                1005-00006                       42L

     Foam Esky 6 Pack with Rope
            SKU                          SIZE
         1005-00018                     6 Pack

                                                                                                                            Coleman Cooler 45L Chest
                                                                                                                            Keep your food and drinks cold for an extended time, and
                                                                                                                            make the fun last longer, when you bring a Coleman® 45L
                                                                                                                            Chest Cooler. Insulated will keep your items cold for up to
                                                                                                                            3 days. Large enough to hold 65 cans, you'll have plenty
                                                                                                                            of space for refreshments for the entire party.

                                                                                                                                   SKU                           SIZE
                                                                                                                                1005-00007                       45L
     Coleman Esky 10L
     Compact size makes it the ideal one-person cooler. Easy
     lift carry handle. Handy lunch box size to take lunch to
     work. Hinged lid for easy opening. CFC free polyure-
     thane insulation.

            SKU                          SIZE
         1005-00019                       10L

37       Section 05 · Exploration Geology and Field Equipment                                                                                                                                     Exploration Geology and Field Equipment · Section 05   38

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                               s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Jerry Can                                                                                                                  Repellants
                                                                                                                                Nature's Botanical Insect Repellant
                                                                                                                                Nature’s Botanical is an essential oil based personal insect
                                                                                                                                repellent. It repels flies, sandflies (aka midges) and mos-
                                                                                                                                quitoes. Does NOT contain chemicals such as DEET or
                                                                                                                                Picaradin. Customers report that it can also soothes itches
                                                                                                                                if it’s too late. Essential oil ingredients include rosemary
     Water Jerry Can Plastic 20L                                                                                                oil and cedarwood oil.                                                                               C
     Australian made. Heavy duty plastic. As used by the Aus-
     tralian Army.                                                                                                                      SKU            DESCRIPTION              SIZE
                                                                                                                                                                                                             B
                                                                                                                                    1001-11439            Cream                 100g
            SKU               COLOUR                 SIZE                                                                   A

                                                                                                                                                                                                                                                               Exploration Geology and Field Equipment
                                                                                                                                    1001-11422            Cream                 260g
         1001-11516             Blue                 20L
                                                                                                                            B       1001-11423           Roll On                50mL
                                                                                                                            C       1001-11403            Spray                500mL

                                                                                                                                                                  A

                                                                                                                                Aerogard Repellant Pump Spray 135mL
                                                                                                                                Aerogard low-irritant protects you and your family against
     Jerry Can Plastic 20L                                                                                                      disease carrying insects with a low scent formula.

            SKU            TYPE         COLOUR          SIZE                                                                           SKU                            SIZE
         1001-11500        Diesel        Yellow            20L                                                                      1001-11405                        135mL
         1001-11501       Gasoline        Red              20L

                                                                                                                                Aerogard Repellant Tropical Strength
                                                                                                                                Aerogard Tropical Strength provides 6 hour protection
                                                                                                                                against mosquitoes. Also repels flies, sand-flies, leeches,
                                                                                                                                ticks and other annoying and biting insects.

                                                                                                                                        SKU                            SIZE
                                                                                                                                    1001-11408                        150g
                                                                                                                                    1001-11409                        300g

39       Section 05 · Exploration Geology and Field Equipment                                                                                                                                           Exploration Geology and Field Equipment · Section 05   40

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                     s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Repellants                                                                                                                  Repellants

                                                                                                                                 Thermacell Halo Tabletop Repeller
     Thermacell Portable Repeller                                                                                                with Refill
     with Refill                                                                                                                 The Thermacell Insect Repellent provides a 21m² zone of
     The Thermacell Insect Repellent provides a 21m² zone of                                                                     protection from pesky mosquitoes, black flies, and other
     protection from pesky mosquitoes, black flies, and other                                                                    biting insects - perfect to keep you comfortable and insect-
     biting insects - perfect to keep you comfortable and insect-                                                                free as you enjoy your backyard, patio, picnic, fishing,
     free as you enjoy your backyard, patio, picnic, fishing,                                                                    camping and more.

                                                                                                                                                                                                                                                                       Exploration Geology and Field Equipment
     camping and more.
                                                                                                                                 » Turn it on…mosquitoes gone
     » Turn it on…mosquitoes gone                                                                                                » Provides a 21m² zone of protection
     » Provides a 21m² zone of protection                                                                                        » Proven 98% effective
     » Works with all Thermacell repeller mats and refills                                                                       » No messy sprays or oily lotions, no open flame, no
     » Proven 98% effective                                                                                                         smoky or smelly candles
     » Patented technology                                                                                                       » Features ZoneCheck Monitor so you know the unit is
     » Portable, lightweight and odourless                                                                                          working
     » Includes Thermacell Repeller, 3x 4 hour repeller mats,                                                                    » Long-lasting 48-hour fuel system with 4x fuel
        1x 12 hour butane cartridge                                                                                                 capacity can run on any number of 1 to 4 butane
                                                                                                                                    cartridges
          SKU            COLOUR                   SIZE (LxWxH)                                                                   » Silent, virtually odour-free, no open flame
      1001-11442           Grey                 57 x 159 x 267mm                                                                 » 12 hour fuel system – can accommodate 1x 12 hour
                                                                                                                                    butane cartridge
                                                                                                                                 » Weather-resistant
                                                                                                                                 » Works with all Thermacell refills
                                                                                                                                 » Includes: Mini Halo Repeller, 3x 4 hour repellent mats
                                                                                                                                    and 1x 12 hour butane cartridge

                                                                                                                                        SKU                 COLOUR                SIZE (LxWxH)
                                                                                                                                   1001-11446-GRY              Grey            140 x 150 x 230mm
                                                                                                                                  1001-11446-WHT            White              140 x 150 x 230mm

     Thermacell Rugged Repeller with Refill
     The Thermacell Insect Repellent provides a 21m² zone of
     protection from pesky mosquitoes, black flies, and other
     biting insects - perfect to keep you comfortable and insect-
     free as you enjoy your backyard, patio, picnic, fishing,
     camping and more.
     » Turn it on…mosquitoes gone                                                                                                Thermacell Repeller Refill
     » Provides a 21m² zone of protection
     » Proven 98% effective                                                                                                      Ensure you maintain a 21m² zone of protection from pesky
     » No messy sprays or oily lotions, no open flame, no                                                                        mosquitoes, black flies, and other biting insects - perfect to
        smoky or smelly candles                                                                                                  keep you comfortable and insect-free as you enjoy your
     » Features ZoneCheck indicator (powered by CR2032                                                                           backyard, patio, picnic, fishing, camping and more.
        battery included) so you know the unit is working                                                                        » Provides a 21m² zone of protection
     » Accessory mounting system with belt clip (included)                                                                       » Proven 98% effective
     » Durable rubber armoured                                                                                                   » Patented technology
     » Ergonomic design – one-handed operation                                                                                   » Each cartridge lasts up to 12 hours
     » Silent, virtually odour-free, no open flame                                                                               » Cartridges can be stored for long periods of time
     » Includes: Rugged Repeller, belt clip, 3x 4 hour                                                                           » A cartridge can be used for short periods of time;
        repellent mats and 1x 12 hour butane cartridge                                                                             turn unit off and restart when ready
                                                                                                                                 » Fits all Thermacell appliances and lanterns except the
          SKU            COLOUR                   SIZE (LxWxH)                                                                     Backpacker, as that unit operates on camping gas
       1001-11443          Grey                 60 x 150 x 270mm
                                                                                                                                   cartridges

                                                                                                                                      SKU            TYPE                      CONTAINS
                                                                                                                                   1001-11447       12 hours      3x 4 hour mats, 1x butane cartridge
                                                                                                                                   1001-11448       48 hours      12x 4 hour mats, 4x butane cartridges

41       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                   Exploration Geology and Field Equipment · Section 05   42

                                  C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                        s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
                                                                                                                                Chip Trays
     Head Nets                                                                                                                       Designed for use in the field
                                                                                                                                     Available in black, white and natural
                                                                                                                                     Securely stores samples
                                                                                                                                     Composed of UV-resistant plastic
                                                                                                                                     Wide compartments

                                                                                                                                All our manufacturers abide by the ETI code.
                                                                                                                                                                                                         A

                                                                                                                                Sample Percussion Tray
                                                                                                                                The compartment chip trays are specifically designed with field
                                                                                                                                use in mind. Our chip trays are available in black, white or
                                                                                                                                natural with the black & white trays providing longer field life

                                                                                                                                                                                                                                                                        Exploration Geology and Field Equipment
                                                                                                                                with improved UV resistance, particularly in the black trays,
     Head Net Fine Cotton Mesh                                                                                                  should the trays be required to sit in the field for a period prior
     » Heavy duty                                                                                                               to being collected for analysis. Tray is sealed by a continuous
     » Fits over most headwear including hard hats                                                                              hinge secured by 5 latches. Tough UV resistant plastic.
     » Made from 100% polyester                                                                                                                                                                              B
                                                                                                                                    SKU       COLOUR         SIZE (LxWxH)        COMPARTMENT
                                                                                                                                                                                    WIDTH
                               SKU
                                                                                                                                   SPT-B       Black       510 x 50 x 30mm            25mm
                            1001-00048
                                                                                                                            A      SPT-N      Natural      510 x 50 x 30mm            25mm
                                                                                                                                   SPT-W       White       510 x 50 x 30mm            25mm                                               C

                                                                                                                                Chip Box Inspection Plates
                                                                                                                                This flat stainless steel inspection tray with two folded
                                                                                                                                edges is designed to remove and inspect rock chips with
                                                                                                                                minimal spillage. After inspection the chips can be easily
                                                                                                                                returned to their original compartment without contam-
                                                                                                                                inating adjacent compartments. Ideal for microscopic                             D
                                                                                                                                inspection of drill chips.                                                                                                          F

                                                                                                                                                               SKU
                                                                                                                            B                              SPT-INSPECT

                                                                                                                                Chip Tray Funnel
     Head Net Closed Top Black                                                                                                  Our chip tray funnel was specifically designed for filling
     Avoid and prevent annoying insects, sandflies, mosquitos                                                                   our 10 compartment and 20 compartment rock chip trays.
     and other flies from disturbing you by wearing a mosquito                                                                  The funnels even have a thumb tab to make them easier
     net. The insect net comes with an elasticised neck for a                                                                   to hold while filling the rock chip trays.
     comfortable seal around the neck. Wear it over your hat,                                                                                                                                                              E
     cap, helmet or directly on your head.                                                                                                                     SKU

            SKU                           SIZE                                                                              C                              SPT-FUNNEL

       1001-00287-REG                    Regular
       1001-00287-LGE                    Large
                                                                                                                                                                                                                                                                    G

                                                                                                                                Chip Tray
                                                                                                                                Made from durable plastic, seal-fast, fixed-lid compart-
                                                                                                                                ments. Your samples' contamination risk will be minimised.

                                                                                                                                     SKU           SIZE (LxWxH)          COMPARTMENT WIDTH
                                                                                                                            D    1118-30000       282 x 52 x 22mm                25mm
                                                                                                                            E      SPT-10-D      508 x 50 x 25mm                50mm
                                                                                                                            F    1118-30001      255 x 120 x 30mm              2x 25mm
                                                                                                                            G       SPT-40        580 x 52 x 27mm                11mm

43       Section 05 · Exploration Geology and Field Equipment                                                                                                                                                Exploration Geology and Field Equipment · Section 05       44

                             C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                         s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Chip Trays                                                                                                               Chip Trays

                                                                                                                              MDF Racking
     Chip Tray Storage Module                                                                                                 Each bay of racking will hold 42 cartons of 30 trays,
                                                                                                                              making this 1260 sample chip trays.
     Wall Mount
     The frames are 2400mm high and 4000mm wide with a                                                                        20ft Containers: 7,560 sample chip trays
     400mm depth and holds approx 2390 chip trays. Lugs allow                                                                 40ft Containers: 15,120 sample chip trays
     these frames to be secured to the wall and floor. No backing
     plate required as the trays will push up against the wall.                                                                      SKU                DESCRIPTION                 UOM

                                                                                                                                                                                                                                                               Exploration Geology and Field Equipment
                                                                                                                                  1118-20003       MDF Racking to suit 20ft         6 Bays
             SKU                       DESCRIPTION
                                                                                                                                  1118-20004       MDF Racking to suit 40ft        12 Bays
         1118-20006                2400 x 4000 x 400mm
                                                                                                                              Please note that the carton used for these calculations is
                                                                                                                              referring to SKU: CTN21118 (see previous page).

     Chip Tray Storage Module
     Free Standing
     The frames are 2400mm high and 4000mm wide with a
     400mm depth. They hold approx. 2390 chip trays. Lugs
     allow these frames to be secured to the floor. Incorporates
     a backing plate so that trays don't get push through.

             SKU                       DESCRIPTION
         1118-20005                2400 x 4000 x 400mm

     Chip Tray Carton
     Cartons are available in a couple of sizes. Available flat-
     packed for transport. Other custom sizes can be sourced,
     please contact our sales team with your requirements.

             SKU           DESCRIPTION               SIZE
          CTN21118        Holds 30 trays     525 x 275 x 200mm
         1159-00400       Holds 100 trays    550 x 360 x 530mm

45       Section 05 · Exploration Geology and Field Equipment                                                                                                                                           Exploration Geology and Field Equipment · Section 05   46

                               C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                   s u p p l y@ we s t e r n e x .c o m . a u
CATALOGUE 2020
     Chip Trays                                                                                                              Chip Trays
                                                                                                                             Sample Storage Clear Trays
                                                                                                                             This system was designed to overcome several problems
                                                                                                                             in sample collection and storage. The thin plastic and
     Mesh Racking                                                                                                            paper envelopes previously used were found to be
                                                                                                                             non-transparent for viewing purposes, often split, were
     To supply a 20ft container will require 2x 2500mm units                                                                 lost, frequently too bulky for efficient storage, and difficult
     for each side plus 1x 1250mm for the back wall. Holds over                                                              to access for in-house geological reviews.
     6000 chip trays.
                                                                                                                             The sample trays are manufactured in a durable plastic
     To supply a 40ft container will require 4x 2500mm units                                                                 called GP Styrene, which has excellent clarity for micro-
     for each side plus 1x 1250mm for the back wall. Holds over                                                              scopic examination, and the fluorescence in oilfield
     10 000 chip trays.                                                                                                      samples can be reliably seen under ultraviolet light. The

                                                                                                                                                                                                                                                               Exploration Geology and Field Equipment
                                                                                                                             trays are stackable, allow easy access, reasonably strong,
            SKU                        DESCRIPTION
                                                                                                                             and will not deteriorate over long storage periods.
       1118-20007-20FT      5 Piece Kit to suit 20ft Sea Container                                                           This system is suitable for a variety of professions and
       1118-20007-40FT      9 Piece Kit to suit 40ft Sea Container                                                           hobbies including: coin collectors, embroiderers, fisher-
     Please note, neither of these products include the sea                                                                  men, fossil collectors, prospectors, and mineral museums.
     container, these can be arranged separately.
                                                                                                                             »   Excellent clarity for microscopic examination
                                                                                                                             »   Reliable visibility of the sample fluorescence under UV light
                                                                                                                             »   Stackable, allow easy access, and reasonably strong
                                                                                                                             »   Will not deteriorate over long storage periods
                                                                                                                             »   Will not degrade under sunlight

     Configuration within the sea containers                                                                                 Small Sample Storage Clear Trays
                                                                                                                             »   Contains: 5 compartments
                                                                                                                             »   Capacity: 25g per compartment
                              B                                 B                                                            »   Material: GP Styrene
                                                                                                                             »   Weight: 33g
                                                                                              A
                                                                                                                  B
                                                                                                                                                            SKU
                                                                                                                                                        1118-40004

      A                  20 FOOT SEA CONTAINER
                                                                                                                             Large Sample Storage Clear Trays
                                                                                                                             »   Contains: 5 compartments
                                                                                                                             »   Capacity: 50g per compartment
                              B                                 B                                                            »   Material: GP Styrene
                                                                                                                             »   Weight: 48g

                              B                                 B                         B                              B                                  SKU
                                                                                                                                                        1118-40005

                                                                                                                             Jumbo Sample Storage Clear Trays
      A                  40 FOOT SEA CONTAINER                                                                               »   Contains: 2 compartments
                                                                                                                             »   Capacity: 75g per compartment
                                                                                                                             »   Material: GP Styrene
                                                                                                                             »   Weight: 45g

                                                                                                                                                            SKU
                              B                                 B                         B                              B
                                                                                                                                                        1118-40006

47        Section 05 · Exploration Geology and Field Equipment                                                                                                                                          Exploration Geology and Field Equipment · Section 05   48

                              C I V I L | M I N I N G | E X PL O R AT I O N | I N D U S T R I A L | C O N S T RU C T I O N                                                    s u p p l y@ we s t e r n e x .c o m . a u
You can also read
