5G Intelligent Service
Operations
© 2018 TM Forum | 1
© 2018 TM Forum | 2
© 2018 TM Forum | 3
The Race - What’s Happening?
• Running from Saturday July 7th to Sunday July 29th 2018, the 105th Tour de France includes 21 stages
• These stages cover a total distance of 3,329 kilometers (a little more than the driving distance between New York
and Albuquerque, NM).
• 22 teams, 176 riders, Many MILLIONS of Spectators (10-12 million at the roadside on 2016)
• Rider’s telemetry and big data (from 2015…). For instance - Total calories spent: 23,940,000 or 85,807
hamburgers….
• Much more than just bicycles…
– GPS/Telemetry data: Comes from trackers on the cycles - contains the timestamp, latitude, longitude and the speed of the
rider.
– Race data: Provided at beginning of race
– Timing data: Data from official timing provider regarding results, photo finish etc.
– Environmental data: From third party sources, uses ordnance data as well hyper-localized weather data.
– Social Media data: from handles like @letour and @letourdata
– Media: Photos, videos and other data
– And a lot of crazy fans doing crazy fan stuff…
© 2018 TM Forum | 4
The Race, the Hub Where the Future Meets the Future…
• Drones
– Already utilized in coverage of massive sport events
– Getting better, steadier, longer-lived, faster
• 5G Slices
– eMBB for video
– uRLLC for controls
– mMTC/eMBB for telemetry
– E2E slice management
• More and more telemetry and big data
– Geolocation (location, speed, cadence, acceleration, power)
– Weather and environment
– Biotelemetry (wearables, ingestible, implantables, injectables)
• Analytics and ML
– For network self-healing
– For consumer data
– For medical surveillance and anti-doping control
© 2018 TM Forum | 5
Catalyst Drivers
Drivers Details
• INCREASE THE VOLUME AND CHOICE OF • Tour De France is a very popular event worldwide and viewers
want to be able to watch any part of the race live depending on
CONTENT AVAILABLE TO VIEWERS their inclination e.g watch a team they follow. Also there is a
market for recorded content for different aspects of the race.
• Every Tour De France location is different. Operators don't want to
• LOW COST OF DEPLOYMENT AND OPERATION invest a huge amount in infrastructure that is useful only for one
event. It is imperative that the infrastructure is dynamic and
operations are automated.
• Traditional revenue streams are dwindling with commoditisation.
• NEW REVENUE STREAMS New revenue streams have to be found to sustain the business.
• Customers now demand superb customer experience - be it
innovative products and services, ease of use, flexibility of use,
• IMPROVE CUSTOMER EXPERIENCE excellent performance at the right price point. Online and real
time experiences are now table stakes.
• Sport viewers are not content with just passively watching the
event. They want to experience being in the event. This could
• GET IMMERSIVE EXPERIENCE OF SPORTING include watching the event with friends and family online, or
EVENT getting real-time data about their favourite participating sports
person including hear rate, speed, listen to conversations on the
field or even experience the race from the perspective of the riders
using VR.
• ENSURE SAFETY AND SECURITY • Safety and security of the people on the field as well as data is
really important.
© 2018 TM Forum | 6
The Story
• Thursday, 26 July 2018 – At 172 kilometers, the 18th stage of the Tour de France runs from Trie-
sur-Baïse to Pau.
• Relatively flat stage, will serve as an opportunity for sprinters to catch up
• A 5G operator provides (and assures) multiple slices
– eMBB slice for 4K drone video
– uRLLC slice for drone control
– eMBB slice for video and data (DL/UL) for roadside users and sport portal fans
– eMBB slice for rider’s telemetry
• Different SLAs are established between different parties, for different slices:
– 5G operator – Drone operator (coverage, latency)
– 5G operator – Broadcasting company (video quality, event coverage)
– 5G operator – Sorts Portal Provider (availability, quality)
– 5G Operator – Sport Organization/Sport Teams (latency, availability)
© 2018 TM Forum | 7
Products – Services - Slices
Products
Drones Based
Sports App Teams Telemetry Riders Network
Broadcast
Services
Drones Based Riders
Sports App Teams Telemetry
Broadcast Service
Service Service
Service
Drones
management
Slices
Drones Drones Control Bikes & Relay Subscribers Telemetry Riders
Broadcast Slice Slice Broadcast Slice Slice Slice Slice
© 2018 TM Forum | 8
Implemented Slices
© 2018 TM Forum | 9
Use Case 1 – Drones based broadcast: additional drones
Flow: New drone is raised into the air to cover the accident => slice loaded => threshold crossed => policy applied => slice parameters
changed (#supported UEs) => new drone is put back into standby state => slice scaled back (#supported UEs)
© 2018 TM Forum | 10Use Case 2 – Drones based broadcast: restricted flight zone
Flow: Drones get near the restricted flight zone around Pau’s airport => as they evade this zone they get into an area of bad or no 5G
coverage => Proactive policy is applied to move some drones to 4G => as the drones circumvent the restricted flight zone, they get back to
© 2018 TM Forum | 11
full 5G coverageUse Case 3 – Graphical description – Roadside Users
Live Streaming
Mobile Users Network Videos
(4G/5G) Race Stats
Fan’s Portal
A Local Rider is leading the stage and is in a VERY good position to win the event.
Road-side users density is massively increasing on the route, especially towards the finish line.
Steps Taken:
=> slice becomes heavily loaded
=> Broadcasted Video Quality degraded
=> Subscriber Mobile Broadband Service Impacting and RCA
=> MEC Application is overloaded
=> Policy is applied to Increase Max allowed UE on the slice and Scale MEC application and ensure Subscribers are well served
© 2018 TM Forum | 12Use Case 4 – Graphical description – Roadside Users
Rider’s Analytics
Application Server
(OTT or CSP ) Network
Below-seat
pod
Teams
UCI telemetry
Director
An OTT application using Team’s Telemetry network Slice and providing Race Analytics gets flooded having an impact
on on telemetry measurements reliability and generating Radio Access Bearer errors on the 5G NR Cells
=> Policy is applied to recommend OTT application scaling
© 2018 TM Forum | 13Congestion Map
Uplink Mainly an
intra-slice
usage type
conflict
(within
roadside • Drone slices
users) • Drone controls - light
• Drone slices • Roadside
• Drone Video – • Roadside downloads –
Heavy Medium to high (portal
• Control ‘acks’ – usage/other usage)
very light • Rider’s Telemetry
• Roadside • Very Light (’acks’)
• Roadside media
uploads – Medium
• Rider’s Telemetry Mainly an
• Very Light inter- slice
device type
conflict
(drone vs.
Downlink
roadside
devices)
© 2018 TM Forum | 14Congestion maps – Competition on Resources
Uplink: Inter – slice competition between device types
Potential ‘collateral’
Potential ‘collateral’
damage, impact on
damage, impact on
Telemetry slice
Control slice
Roadside Smartphones/
Drones
tablets
Downlink: Intra-slice competition between usage types
Roadside – Sports Portal Roadside – ‘Regular‘ 5G
Usage Usage
© 2018 TM Forum | 15Catalyst Technical Architecture
BSS
Order Management
ONAP Policy Service Assurance
Service Orchestration
Management
OSS &
Orchestration
E2E Slice Management
Transport
Core Slice Management RAN Slice Management Slice Management
Telemetry
Drones
Network
5G Network (BT Lab) Control
© 2018 TM Forum | 16Converged Orchestration
• Single view of service across
SDN, NFV, physical and
Cloud
• Zero-touch operational flows
• End-to-end lifecycle across
design and execution
• Simplifies integration with
traditional BSS/OSS
© 2018 TM Forum | 17End-to-End 5G solution: Real-time Operations & Orchestration
• Distributed real-time orchestration of diverse
complex services across all network domains,
including vCore and intelligent edge (e.g. MEC)
• End-to-end management of hybrid virtual and
physical cross-generation access, aggregation,
and core infrastructure
• Real-time QoS management with closed-loop
and analytics-driven service assurance tools
• Dedicated M2M/ IoT Platform for vendor-
agnostic device and data management
© 2018 TM Forum | 18Catalyst Technical Aspects & Contributions
• Impact of 5G Modelling
• New Integrations
TMF 641 – Service Order ONAP – Policy management Integration
Management
Slice Operations
• Slice creation (SLA params)
• Slice modification(SLA params)
• Slice KPIs monitoring
Data model Tosca data model Based on real slice-management
• Cross layers, Products to Slices • Orchestration to Assurance APIs
• Communication & IoT • Slice level and up © 2018 TM Forum | 195G Intelligent Service Operations Catalyst Benefits
• The catalyst proposes and explores new services and innovation areas, creating new engaging end-
customer services and experiences, also considering the multi-provider within B2B Business model.
• The catalyst proposes and explores slicing concepts and mechanisms, covering practically all the 5G
requirements, enabling the network service provider to dynamically balance capacity and resource
allocation according to real-time dynamically changing loads onto the range of slices. This can be used as
a tool to support Operations team to effectively manage QoE and the offered service levels. Such
alignment of expectations is key to well-managed customer experience.
• The insights into operational aspect around Service Orchestrator and Service Assurance with closed
control loop is a key enabler for 5G.
• Key takeaways and main finding generated by this Catalyst could be used as input to standardization work
© 2018 TM Forum | 20Thanks!
