PRODUCT CATALOGUE 2018 AIR CONDITIONERS LINEUP
OUR SOLUTION FOR ALL LIFE SCENES 002
Fujitsu General provides comfortable and
economical air conditioning systems
that fit architectural trends and environmental
awareness in Europe
– from business scene to lifestyle scene.
INDEX
004 OUR MESSAGE
INNOVATION & GLOBALIZATION
006 DESIGN FOR COMFORT
008 DESIGN FOR CONTROL
010 DESIGN FOR FUTURE
012 HISTORY
014 WORLD WIDE LOCATIONS
016 GLOBAL BUSINESS ACTIVITIES
018 PROJECT REFERENCES
020 GLOBAL DEVELOPMENT & PRODUCTION BASES
022 HIGH QUALITY DEVELOPMENT & PRODUCTION FACILITIES
024 2018 NEW PRODUCTS
026 SOLUTIONS
028 For LIGHT COMMERCIAL
036 For COMMERCIAL
038 For RESIDENTIAL
040 PRODUCT LINEUP
040 SPLIT & MULTI SPLIT
For LIGHT COMMERCIAL, RESIDENTIAL
136 VRF
For LIGHT COMMERCIAL, COMMERCIAL, RESIDENTIAL
186 CONTROL SYSTEM & OPTIONAL PARTS
238 AIR TO WATER
256 SUPPORT
258 AIRSTAGE™ SUPPORT
260 AIRSTAGE™/RAC SUPPORT TOOL
262 WATERSTAGE™ SUPPORT TOOL
264 QUICK SERVICE & MAINTENANCE
266 SERVICE TOOL
267 WEB MONITORING TOOL
