EFCO Delivers Great Concrete Construction Results
                by EFCO Chairman of the Board — Al Jennings

 WITH WORLDWIDE CONTINUOUS                                                                        WRAP-AROUND EFCO SUPPORT
 IMPROVEMENTS, EFCO IS BETTER                       successes for our construction contractor      These are all wonderful EFCO attributes
 AND BETTER EVERY DAY                               customers. This work for the concrete          and not to be forgotten but combined
  EFCO is a company built on innovation             construction industry has included             with EFCO’s core value attributes with
  and invention opportunities for concrete          stronger and better concrete mixes and,        the abbreviations: Q-I-I-S for:
  construction process improvements.                of course, stronger reinforcing concrete         Quality – Innovation – Integrity and
                                                    structures.                                                   Super Service
   It all starts with EFCO company employees,                                                      Having a very successful EFCO foundation
   territory manager representatives, not           With EFCO all-steel forms, there can be        of successes with our excellent products
   even a dealer or distributor, listening to       many, many possible additional benefits.       is not enough. Our continuing successes
   and working with our customers. This is          With standard and special EFCO steel           depend upon our continuing corporate
   where and how EFCO got its start some 85         forms, we can deliver many shapes and sizes    heritage of Q-I-I-S given to us by our founder,
   years ago (1936), and it just keeps going and    of architectural concrete configurations.      W. A. Jennings. As an example for quality,
   going, better and better. Can you believe                                                       of course, we take real pride in the quality
   it? The company EFCO has a foundation            The single-line EFCO form joints alone         of our products as we have had years of
   of engineering graduates now working             versus some competitors’ three-line            experience in the business. It is also quality    EFCO engineers deliver solutions for safe
   in its fourth generation, always working         depressed form joints, it is reason enough     in everything we do and touch including, as       formwork and support systems. This work
   with new technologies to leverage more           to go EFCO.                                                                                      includes project specific form erection
                                                                                                   an example, engineering and field service.
                                                                                                                                                     drawings.
                                                                                                   We are just plain quality people, honest and
                                                                                                   straight forward employees.

                                                                                                   As for EFCO’s innovation, our company
                                                                                                   being vertically integrated from design,
                                                                                                   invention, manufacturing, distribution and
                                                                                                   sales, we are very flexible. As I remember
                                                                                                                                                                           Assembly, cycle and
                                  Lowery Avenue Bridge,                                            our founder would say, “Can’t never did                                 safety—it’s all about
                                  Minneapolis, Minnesota                                           anything,” and, of course, innovation has                               EFCO field service.
 Double-branched freeway                                                                           led to new inventions. In the early days,
 overlapping sections of I-80                                                                      our founder would keep us from showing            EFCO CUSTOMER
 and I-29, Council Bluffs, Iowa
                                                                    Pinellas Bayway Bridge,        at trade shows as he would say, “Our              CONSTRUCTION CONTRACTS
                                                                    St. Petersburg, Florida        competitors will just try to copy us.”             EFCO’s customer contracts for rental
                                                                                                                                                      and sales equipment are only direct
                                                                                                   As for integrity, we are financially               from construction contractors, very
                                                                                                   stable and employee-owned. We are also             seldom government. The contact is only
                                                                                                   committed to balancing the interests of our        normally worked face to face with EFCO’s
                                                                                                   customers, employees and stockholders              territory manager (TM). EFCO’s TMs are
                                  Crimson Tide Stadium Expansion,
                                                                                                   and make a promise to our customers to             each backed up by wrap-around support
                                  Tuscaloosa, Alabama
                                                                                                   under-promise and over-deliver.                    teams, including a Customers Solutions
                                                                                                                                                      consultant, field supervisor, engineer
                                                                                                   Now for super service, we have the                 and drafters, sales administrator, and
                                                                                                   best engineering and field service in the          warehouse plant manager, you name it.
                                                                                                   industry supported by our warehousing
                                                                                                   and distribution systems.                          With an ongoing contracted construction
                                                                                                                                                      project with EFCO equipment, a
 Myrtle Woldson Performing Arts                                                                                                                       contractor can be connected with a direct
 Center, Spokane, Washington                                                                                                                          linkage to EFCO field service, engineering,
                                  Roberto Garza Sada Center,        Fertilizer Facility,                                                                                  Continued on page 6...
                                  Monterrey, Mexico                 Madelia, Minnesota
