2018 Housetype and Apartment Portfolio
1
Introduction
ilke Homes aims to help address the UK’s chronic shortfall in housing, creating consistently high-
quality, energy-efficient modular homes at scale for the people that need them most. Using precision
engineering and inspiring designs, we look forward to working with you to create future homes for
families across the UK.
The ilke Homes 2018 Housetype and Apartment Portfolio showcases the range of homes we are
building this year from our factory in Yorkshire. Our range now includes 7 NDSS (Nationally De-
scribed Space Standard) and M4-2 (Category 2 – Accessibility & Adaptable Dwellings) compliant
housetypes as well as 8 open market sale house types. The layouts and elevations of our house types
open up the opportunity for end customers to customise the layout of their future homes prior to
manufacture, for example by offering the choice of open plan living or a separate living room. Our
designs and portfolio enable large tenure blind developments to be built using our British modular
housing solution in record time, with homes installed at a rate of 2 to 6 homes per crane, per day.
As shown on the following pages, ilke homes can be clad in a wide range of traditional and contem-
porary external finishes and rooflines to suit the local vernacular or to transform and regenerate a
Björn Conway, Chief Executive site. All ilke homes have a 2.5m floor to ceiling height with large windows as standard which provide
excellent daylight. ilke Homes cost 20% less to heat than other new homes and less than half the cost
to run than the average UK home. Acoustic tests have also shown ilke homes to be significantly
At ilke, our mission is to build better homes in a quieter than traditional new builds. Our homes are fully mortgageable with all the standard
warranties available including NHBC Buildmark and BLP Secure.
better way. We are delighted to now also include our Apartment Portfolio which showcases our solution for
low and medium rise apartments up to 6 storeys, adding a range of designs to suit a wide variety of
needs and tenures.
+ Desirable, affordable, energy efficient homes I hope you enjoy looking through our portfolio and we look forward to working with you.
that people enjoy living in
+ Build quality homes right first time, in half Björn Conway
the time Chief Executive
2 3
2018 Housetype and Apartment Portfolio Example Scheme Layout
A wide range of housetypes and internal layouts are available to deliver a range of schemes, from small infill sites to large developments that meet different tenures and The following layout demonstrates how ilke Homes’ portfolio can be used to plot full sites of mixed tenure, low rise, medium density
standards. This includes homes designed for open market sale and private rent as well as those which meet Nationally Described Space Standard (NDSS), London Housing residential developments.
SPG (2016) and ADM4(2).
London Arrangement Internal dimensions (mm) External (mm)
Arrangement Internal dimensions (mm) External (mm) See
Name Housetype Summary Reference NDSS M4(2) London
SPG Variance Semi- Wide Corner See
Name Housetype Summary Reference SPG
NDSS M4(2) (2016) Variance Detached Semi- Terraced Wide Corner En-suite Width Depth Fl-Cl m2 �2 Width^ Depth^ page:
Detached Detached Terraced Fronted Turner En-suite Width Depth Fl-Cl m2 �2 Width^ Depth^ page:
(2016) Detached Fronted Turner
The Haldon 2b4p 2 storey house 60_2b_F Yes Yes 4.063 7.536 2.510 61.2 659 4.495 8.090 6
The Haldon 2b4p 2 storey house 60_2b_F Yes Yes 4.063 7.536 2.510 61.2 659 4.495 8.090 6
The Holt 2b4p 2 storey house 80_2b_F Yes Yes Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 8
The Holt 2b4p 2 storey house 80_2b_F Yes Yes Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 8
The Cardinham 2b4p 2 storey house 80_2b_W Yes Yes Yes wide fronted Yes Yes Yes Yes 8.934 4.400 2.510 80 861 9.488 4.954 10
The Cardinham 2b4p 2 storey house 80_2b_W Yes Yes Yes wide fronted Yes Yes Yes Yes 8.934 4.400 2.510 80 861 9.488 4.954 10
The Dean 2b4p 2 storey house 80_2b_R Yes Yes Yes rear kitchen Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 12
The Dean 2b4p 2 storey house 80_2b_R Yes Yes Yes rear kitchen Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 12
The Dalby 3b5p 2 storey house 80_3b_F Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 14
The Dalby 3b5p 2 storey house 80_3b_F Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 14
The Weston 3b5p 2 storey house 80_3b_W wide fronted Yes Yes Yes Yes Yes 8.934 4.400 2.510 78.6 846 9.488 4.954 16
The Weston 3b5p 2 storey house 80_3b_W wide fronted Yes Yes Yes Yes Yes 8.934 4.400 2.510 78.6 846 9.488 4.954 16
The Kielder 3b5p 2 storey house 80_3b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 18
The Kielder 3b5p 2 storey house 80_3b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 81 872 4.954 9.488 18
The The�ord 3b5p 2.5 storey house 100_3b_F Yes Yes Yes Yes Yes Op�on 4.522 8.934 2.510 103.5 1114 4.954 9.488 20
The The�ord 3b5p 2.5 storey house 100_3b_F Yes Yes Yes Yes Yes Op�on 4.522 8.934 2.510 103.5 1114 4.954 9.488 20
The Houghton 3b5p 2.5 storey house 100_3b_R Yes Yes Yes rear kitchen Yes Yes Op�on 4.522 8.934 2.510 103.5 1114 4.954 9.488 22
The Houghton 3b5p 2.5 storey house 100_3b_R Yes Yes Yes rear kitchen Yes Yes Op�on 4.522 8.934 2.510 103.5 1114 4.954 9.488 22
The Bedgebury 4b7p 2.5 storey house 100_4b_F Yes Yes Yes 4.522 8.934 2.510 103.5 1114 4.954 9.488 24
The Bedgebury 4b7p 2.5 storey house 100_4b_F Yes Yes Yes 4.522 8.934 2.510 103.5 1114 4.954 9.488 24
The Sherwood 4b7p 2.5 storey house 100_4b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 103.5 1114 4.954 9.488 26
The Sherwood 4b7p 2.5 storey house 100_4b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 103.5 1114 4.954 9.488 26
The Rockingham 4b7p 3 storey house 121_4b_F Yes Yes Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 28
The Rockingham 4b7p 3 storey house 121_4b_F Yes Yes Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 28
The Delamere 4b7p 3 storey house 121_4b_R Yes Yes Yes rear kitchen Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 30
The Delamere 4b7p 3 storey house 121_4b_R Yes Yes Yes rear kitchen Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 30
The Newborough 5b8p 3 storey house 121_5b_F Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 32
The Newborough 5b8p 3 storey house 121_5b_F Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 32
The Drummond 5b8p 3 storey house 121_5b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 34
The Drummond 5b8p 3 storey house 121_5b_R rear kitchen Yes Yes Yes 4.522 8.934 2.510 121.5 1308 4.954 9.488 34
The Ribble 1b1p 2-6 storey apartment 37_1b_A 4.053 9.121 2.510 37 398 4.617 9.675 40
The Ribble 1b1p 2-6 storey apartment 37_1b_A 4.053 9.121 2.510 37 398 4.617 9.675 40
The Calder 1b2p 2-6 storey apartment 40_1b_A1 9.121 4.386 2.510 40.2 433 9.675 4.940 40
The Calder 1b2p 2-6 storey apartment 40_1b_A1 9.121 4.386 2.510 40.2 433 9.675 4.940 40
The Clyde 1b2p or 1b1p 2-6 storey apartment 40_1b_A2 Yes Yes Yes shape 8.436 5.200 2.510 42.2 454 8.990 5.754 40
The Clyde 1b2p or 1b1p 2-6 storey apartment 40_1b_A2 Yes Yes Yes shape 8.436 5.200 2.510 42.2 454 8.990 5.754 40
The Avon 1b2p 2-6 storey apartment 50_1b_A1 Yes Yes Yes 8.436 7.536 2.510 51.8 558 8.990 8.090 40
The Avon 1b2p 2-6 storey apartment 50_1b_A1 Yes Yes Yes
entrance loca�on
8.436 7.536 2.510 51.8 558 8.990 8.090 40
The Aire 1b2p 2-6 storey apartment 50_2b_A2 Yes Yes Yes 8.436 7.536 2.510 51.8 558 8.990 8.090 40
The Aire 1b2p 2-6 storey apartment 50_2b_A2 Yes Yes Yes entrance loca�on 8.436 7.536 2.510 51.8 558 8.990 8.090 40
The Medway 2b4p or 2b3p 2-6 storey apartment 60_2b_A1 * * * 8.436 7.536 2.510 61.4 661 8.990 8.090 40
The Medway 2b4p or 2b3p 2-6 storey apartment 60_2b_A1 * * * 8.436 7.536 2.510 61.4 661 8.990 8.090 40
The Mersey 2b4p or 2b3p 2-6 storey apartment 60_2b_A2 * * * entrance loca�on 8.436 7.536 2.510 61.4 661 8.990 8.090 40
The Mersey 2b4p or 2b3p 2-6 storey apartment 60_2b_A2 * * * entrance loca�on 8.436 7.536 2.510 61.4 661 8.990 8.090 40
The Tees 2b4p 2-6 storey apartment 70_2b_A1 Yes Yes Yes 12.799 7.536 2.510 73.1 787 13.393 8.090 41
The Tees 2b4p 2-6 storey apartment 70_2b_A1 Yes Yes Yes 12.799 7.536 2.510 73.1 787 13.393 8.090 41
The Tweed 2b4p 2-6 storey apartment 70_2b_A2 Yes Yes Yes shape 8.749 9.121 2.510 70.7 761 9.303 9.675 41
The Tweed 2b4p 2-6 storey apartment 70_2b_A2 Yes Yes Yes shape 8.749 9.121 2.510 70.7 761 9.303 9.675 41
The Trent 2b4p 2-6 storey apartment 70_2b_A3 Yes Yes Yes layout 8.749 9.121 2.510 70.7 761 9.303 9.675 41
The Trent 2b4p 2-6 storey apartment 70_2b_A3 Yes Yes Yes layout 8.749 9.121 2.510 70.7 761 9.303 9.675 41
The Thames 2b4p 2-6 storey apartment 70_2b_A4 Yes Yes Yes entrance loca�on 8.749 9.121 2.510 70.7 761 9.303 9.675 41
The Thames 2b4p 2-6 storey apartment 70_2b_A4 Yes Yes Yes entrance loca�on 8.749 9.121 2.510 70.7 761 9.303 9.675 41
External Finishes 44
External Finishes 44
Internal Finishes 46
Internal Finishes 46
Technical Specifica�on 48
Technical Specifica�on 48
^ Excludes party wall cavity of 40mm between proper�es
^ Excludes party wall cavity of 40mm between proper�es
* Can be made to 2B3P NDSS/M4(2) with addi�onal storage
* Can be made to 2B3P NDSS/M4(2) with addi�onal storage
4 5
The Haldon
2 Bedroom 4 Person, 2 Storey House
The first of our two bedroom
homes, The Haldon, is ideal for first
time buyers. The ground floor is
fully open plan with kitchen, dining
and lounge areas. The living area
boasts french doors leading onto
a rear garden. There is also a con-
venient downstairs w.c. and storage
space. Upstairs is the master bed-
room, a second double bedroom,
family bathroom and additional
storage space.
Ground Floor Plan First Floor Plan
Key features
• Two bedroom home ideal for first
time buyers
• Highly energy efficient
• Open plan kitchen, dining room
and lounge Room Size Schedule
• Lounge with french doors
opening onto the rear garden
• Downstairs W.C
• Master bedroom
• Second double bedroom
• Family bathroom
• Additional storage space
Floor Area Schedule
Example of customised elevation Front Elevation Side Elevation Rear Elevation
