RECLAIM YOUR NETWORK™ Administrator’s Guide Barracuda VPN Client for Linux/Mac OS/OpenBSD Barracuda Networks Technical Documentation Version 2.8

Administrator's Guide

Copyright Notice Copyright (c) 2004-2011, Barracuda Networks, Inc., 3175 S. Winchester Blvd, Campbell, CA 95008 USA www.barracuda.com v2.8-070213-12-0321 All rights reserved. Use of this product and this manual is subject to license. Information in this document is subject to change without notice. Trademarks Barracuda NG Firewall is a trademark of Barracuda Networks. All other brand and product names mentioned in this document are registered trademarks or trademarks of their respective holders.

3 Chapter 1 Installation 1.1 General The following explains how to install and configure the Barracuda VPN client on your client computer running under Linux, OpenBSD or Mac OS X. You need to know these configuration parameters:
  • IP address and port of the Barracuda VPN server
  • local password for your license
  • server password
  • several connection-dependent parameters explained below
  • For the VPN client installation the following requirements are essential:
  • recent linux-distribution
  • required license (one of the following, depending on authentication type):
  • Barracuda personal license
  • x.509 certificate
  • no license required for user/password authentication 1.2 Procedure 1.) Get the appropriate installation package
  • RPM package based Linux systems For RPM package based Linux systems (Novell/SuSE or RedHat/Fedora), there are two RPM packages: barracudavpn-20-SP2.i386.rpm contains the dynamically linked Barracuda VPN client for Linux, barracudavpn-2.0-SP2_STATIC.i386.rpm the statically linked one. Use the statically linked client, if some dependencies of the dynamically linked one are not satisfied on the target system.

Install the package as root with the command rpm -Uh barracudavpn-2.0-SP2.i386.rpm You can get all thers information from your network administrator. If there is an older version of the Barracuda VPN Client installed, it must be removed manually using rm /usr/local/bin/barracudavpn, since older versions were not package based, and thus the installation of Barracuda VPN Client will fail.

  • 4 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide (rpm -Uh barracudavpn-2.0-SP2_STATIC.i386.rpm for the statically linked version).
  • Debian For Debian Linux the package is called barracudavpn_2.0-SP2_i386.deb. Install the package as root with the command dpkg -i barracudavpn_2.0-SP2_i386.deb.
  • OpenBSD The package for the OpenBSD client is called barracudavpn-2.0-SP2.tgz. Install the package as root with the command pkg_add barracudavpn-2.0-SP2.tgz.
  • Mac OS X The installation file for the Mac client is called barracudaVPN_setup.command. For installation open a terminal, change to the superuser with sudo su and start the installation in the directory where the package is located with the command ./barracudaVPN_setup.command .
  • 2.) Installing the License file On Linux and OpenBSD license files have to be saved to the directory /etc/barracudavpn. On Mac OS X license files have to be saved to the directory /System/Library/barracudavpn. Depending on the type of authentication and certificate, the copying procedure slightly differs:
  • Barracuda Authentication If a vpnpers.lic is provided, this file has to be copied to /etc/barracudavpn/ or /System/Library/barracudavpn respectively.
  • x.509 Certificate This type of certificate offers two possible ways of delivery: either a p12-file or a packet of three files (cert.pem, key.pem and ca.pem).
  • p12-file If a p12-file (cert.p12) is provided, this file has to be copied to /etc/barracudavpn/ or /System/Library/barracudavpn respectively.
  • packet If a certificate packet is provided, copy the files as described in the following:
  • Linux and OpenBSD cert.pem to /etc/barracudavpn/ key.pem to /etc/barracudavpn/ ca.pem to /etc/barracudavpn/ca/
  • Mac OS X cert.pem to /System/Library/barracudavpn/ key.pem to /System/Library/barracudavpn/ barracudavpn-2.0-SP2.tgz is an OpenBSD package and not just a tar.gz. Do NOT install using tar.
5 Chapter 2 Update 2.1 General 2.2 Procedure The binary for updating the Barracuda VPN Client for Linux can be received in two different ways:
  • Via User Interface: Your network administrator is able to provide you with client updates. If there exists such an update, you can load them onto your machine and install them. For this function you have to be connected. Your download will be saved under /tmp/. You need to install the update likewise you installed the original client.
  • Conventional distribution (email, floppy, etc.): You need to install the update likewise you installed the original client. Disconnect before installing your new client.

Fig. 2–1 Update client download dialogue

6 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide

7 Chapter 3 Configuration 3.1 General 3.2 Configuration Paramters When starting the VPN client for the first time (barracudavpn), you will have to configure your client. The orange entry boxes are mandatory ones. Depending on your type of connection there are more or less boxes to fill. The symbol indicates entries where you can select several values from a list by pressing < or >. To run the VPN client you need to be either root (or equivalent) or the binary has to have the setuid-flag set (command line: chmod 4755 /usr/sbin/barracudavpn).

If you have used a client prior version 2, your old configuration will not get moved over to the new client. Your old configuration will not get modified though. Fig. 3–1 Configuration dialogue

  • 8 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide
  • Authentication This parameter defines the type of authentication that has to be used for successful connection. For details on the required authentication method, please contact your administrator. Available settings are:
  • Public Key
  • X509 Cert
  • X509 Cert+User/Pass
  • User/Pass only
  • Server Address / Server Port IP address(es) and server port of the VPN server(s).
  • Proxy Type Depending on your connection several settings are possible:
  • NO PROXY use a direct connection to your VPN server
  • HTTP connect via a HTTP Proxy (example: squid)
  • SOCKS4 connect via a SOCKS4 server
  • SOCKS5 connect via a SOCKS5 server Section EXPERT SETTINGS (USE WITH CARE) This section contains some options for fine tuning the VPN client. Not all entries are mandatory. Some entries depend on the used Proxy type.
  • Special Mode Following modes are available:
  • NONE normal operation
  • SILENT deactivate keep-alive packets to the VPN server. This mode allows adapters such as ISDN cards to hang-up the line during idle time. Otherwise the communication between client and server would always trigger a connection.
  • Source IP to use IP address to be used as source for your client. Use a comma as address separator. You have to provide IP address, port number and, if needed, a username. If a password is required, you will be prompted for it when connecting. Common port numbers are 3128 or 8080. Your network administrator will be able to provide the correct values.
  • Tunnel Mode The available modes are UDP, TCP and Hybrid. The mode Hybrid combines the best of both connection types: reliability of TCP and response of UDP.
  • Tunnel Rekey Time Time in minutes after which client and server exchange new keys.
  • Tunnel Encryption Several different encryption schemes, such as AES, CAST, Blowfish, etc.
  • Tap device Defines the tap device used for the VPN tunnel. Linux now uses the universal TUN/TAP driver. Therefore use /dev/net/tun as tap device.
  • Keepalive This parameter defines the timeout for re-connecting the tunnel. When having a GPRS connection this value should be increased to avoid permanently reconnects due to dropouts.
  • Configure DNS With Yes selected the system’s DNS configuration is replaced with the VPN provided one, and the VPN domain configured on the VPN server is added to the search path in /etc/resolv.conf. With No selected, the VPN provided DNS configuration is ignored. Merge effects that the VPN provided DNS configuration is merged to the system’s DNS configuration.

On Linux and OpenBSD the configuration is saved to the plain text ASCII-file /etc/barracudavpn/barracudavpn2.conf. On Mac OS X The configuration is saved to the plain text ASCII-file /System/Library/barracudavpn/barracudavpn2.conf. Tampering with this option can alter the usability of applications, i.e. from weird effects to crashes with data loss.

10 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide

11 Chapter 4 Start 4.1 Dialogue Starting the Barracuda VPN client for Linux by entering barracudavpn, opens a window similar to:. 4.2 Options The following options are available:
  • Open Connection opens a VPN connection
  • Close Connection stops a VPN connection
  • Configure Client opens the configuration dialogue; for changes to take effect the connection has to be terminated and reopened.
  • Connection Status Fig. 4–1 Main menu
  • 12 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide displays some information such as throughput, IP, Routes, Gateway, DNS and your license
  • Change Server Password change your Server password, which is needed for connecting
  • Change Local Password change the password used to protect your license file
  • Update Client Your network administrator is able to provide you with client updates. If there exists such an update, you can load them onto your machine and install them. For this function you have to be connected. Your download will be saved under /tmp/. You need to install the update likewise you installed the original client.

Fig. 4–2 Connection Status Disconnect before installing the new client.

  • Exit exits the VPN client. Fig. 4–3 Update client download dialogue This leaves an already established connection open. barracudavpn forks a background process, which keeps running even if you exit the main client. This is needed for controlling the connection. As soon as you close the connection this second process will die, too.

14 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide

15 Chapter 5 Command Line 5.1 Usage barracudavpn [options] where options are: -s --start Start VPN tunnel -p --stop Stop VPN tunnel -t --status Show tunnel status -k --keypwd Password for local key -r --serverpwd Server password -c --config Path name to configuration -V --version Print VPN client version -v --verbose Show debug output -h --help this help

16 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide

  • 17 Chapter 6 Uninstall 6.1 General 6.2 Procedure 1.) Removing Barracuda VPN binary
  • RPM package based Linux systems For RPM package based Linux systems as root enter rpm -e barracudavpn.
  • Debian For Debian Linux as root enter dpkg -r barracudavpn.
  • OpenBSD For OpenBSD as root enter pkg_delete barracudaVPN-2.0-SP2.
  • Mac OS X For Mac OS X remove the shortcut in the Dock and execute rm /usr/local/bin/barracudavpn in a terminal. 2.) Removing certificates and licenses (optional) Removing the certificates is done by entering the following command line:
  • On Linux and OpenBSD: rm -rf /etc/barracudavpn
  • On Mac OS X: rm -rf /System/Library/barracudavpn Prior to uninstalling the Barracuda VPN Client, close all running VPN connections.

18 Barracuda VPN Client for Linux/Mac OS/OpenBSD - Administrator’s Guide
