Building & other structures References 2018
Specialist in the design, manufacturing and installation of steel structures Maeg is an international player in the construction sector. With more than 40 years of experience, Maeg is able to adapt to each project characteristics, so to devise tailor-made and innovative engineering solutions, concretely transforming design into substance.
Ideas Innovative thinking is the engine to dream a different world,
to imagine what could happen further.
Building transforms these ideas into reality: by shaping the space around us,
shape
we are given the possibility to leave a mark and actively contribute to the
social and economic development of countries, communities and people.
the
world
3
References
Hotels, malls, residential, airports, hospitals, stadiums, parking lots, offices, skyscrapers, production factories, warehouses, power plants;
noise-absorbing coverages, gantry and overhead travelling cranes for both industrial and nautical use, domes and temporary pavilions.
The following is a summary of the most notable projects listed by completion date.
Project (civil) Location Period Client Contractor Page
COSO Stadium Yaoundé, Cameroon 2017-ongoing Fédération Camerounaise de Football Gruppo Piccini S.p.A. 5
Al Wakrah Stadium & Precinct Doha, Qatar 2016-ongoing Supreme Committee for Delivery & Legacy Midmac-Purr-Six Construct Joint-Venture (MPS-JV) 7
Termini's station parking lot Rome, Italy 2013-ongoing Grandi Lavori S.p.A. Società Appalti Lavori e Costruzioni SpA (SALC) 9
Moving Walkway VCE Airport Venice, Italy 2015-2016 SAVE S.p.A. E.MA.PRI.CE. S.p.A. 11
Mall of Qatar Doha, Qatar 2015 UrbaCon Trading & Contracting (UCC) - 13
Centre Guido Libreville, Gabon 2013-2014 Groupement Santullo Sericom Gabon S.A. - 15
Garibaldi Complex Milan, Italy 2012 Beni Stabili S.p.A. Impresa Costruzioni Giuseppe Maltauro S.p.A. 17
Center International Conference (CIC) Algeri, Algeria 2010-2012 Government of Algiers China State Construction Engineering Corp. Ltd. (CSCEC) 19
Corinthia Hotel Khartoum Khartoum, Sudan 2005-2006 L.A.F.I.C.O. Cooperativa Muratori And Cementisti (C.M.C.) 21
Project (industrial)
NatGasoline methanol plant Beaumont, USA 2016 Natgasoline LLC Orascom E&C USA, INC 23
New Capital power plant Cairo, Egypt 2016 Army of Egypt Orascom Construction 25
ADD airport new cargo terminals Addis Ababa, Ethiopia 2015 Ethiopian Airlines Safet SpA 27
Cameri military airport Cameri, Italy 2011-2013 Alenia Aeronautica Impresa Costruzioni Giuseppe Maltauro S.p.A. 29
Termal power plant Monfalcone, Italy 2006-2007 Endesa Italia S.p.A. Duro Felguera S.A. 31
Project (other)
Zoo de Beauval tropical dome Saint-Aignan-Sur-Cher, France 2017-ongoing SAS ZooParc de Beauval Constructions Metalliques Florentaies (C.M.F.) 33
Place Vendôme domes Doha, Qatar 2017-ongoing United Development Company (UDC) Construction & Reconstruction Engineering Company (CRC)
35
The Constellation memorial Abu Dhabi, UAE 2017 Private Office of Sheikh Mohamed Bin Al Fara’a Engineering General Contracting
Zayed Al Nahyan 37
Augusta port cranes Augusta, Italy 2017 Autorità Portuale di Augusta Consorzio Valori S.c.a.r.l.
39
Mexico Pavilion Expo 2015 Milan, Italy 2014 ProMéxico Nussli Italia S.r.l.
41
Golden Tulip Plaza Caserta Caserta, Italy 2004 Hotel Marina di Castello S.p.A. -
43
5 Bridges & viaducts Civil buildings Industrial buildings Other structures
COSO
Location The “Complexe sportif d'Olembe” or
Yaoundé, Cameroon COSO stadium will host the 2019 the
Africa Cup of Nations. The steel structu-
stadium
Client res of the stadium of the roof, composed
Fédération Camerounaise by a compression and a tension ring
de Football
supporting the membrane, have an
Contractor overall weight of 8.000 tons.
Gruppo Piccini S.p.A.
With 60.000 seats, a hotel, a shopping
Scope of work mall, gyms and swimming pools, this
Design, supply, erection complex aims to become a new point of
reference for the Cameroonian capital.
Period
2017 - ongoing
7 Bridges & viaducts Civil buildings Industrial buildings Other structures
Al-Wakrah
Location This 40.000 seats stadium will host the
Doha, Qatar 2022 FIFA World Cup. The design of the
structure has been conceived by the
stadium
Client notorious studio Zaha Hadid Architects,
Supreme Committee for and it has been inspired by the sails of
Delivery & Legacy
traditional Dhow boats, used by pearl
Contractor divers from the region in the Persian Gulf.
Midmac-Purr-Six Construct
Joint-Venture (MPSJV) The primary steel structure of the
stadium, divided in two symmetrical
Scope of work halves divided in three shells, has a final
Design, supply, erection weight of 7.500 tons, supporting
secondary structures, the cladding and a
Period retractable roof ensuring a microclimate
2016 - ongoing
to balance the elevated temperature of
the country.
9 Bridges & viaducts Civil buildings Industrial buildings Other structures
Rome Termini
Location This ambitious and vital project for the
Rome, Italy city of Rome aimed to solve the traffic
and parking situation of the main
station parking lot
Client transportation hub of the capital. First of
Grandi Lavori S.p.A. its kind in Europe, it is a three-floors
parking lot built above the railways of
Contractor
Società Appalti Lavori e Termini train station.
Costruzioni SpA (SALC)
The overall surface of 50.000 square
Scope of work meters hosts up 1.337 parking spots and
Design, supply, erection dedicated area for shops and stores. The
40.000 tons steel structure has been
Period assembled and launched from the top of
2013 - ongoing the station, without interfering with the
below train traffic.
11 Bridges & viaducts Civil buildings Industrial buildings Other structures
VCE airport
Location The moving walkway is a contained and
Venice, Italy elevated pedestrian gallery that
connects the VCE airport dock with the
moving walkway
Client parking garage and the passenger
SAVE S.p.A.
terminal.
Contractor
E.MA.PRI.CE. S.p.A. This 605 tons heavy structure is 365
meters long and it is served by five
Scope of work moving walkways reducing the travel
Design, supply, erection distance to only 1s0 minutes. The path,
inspired by the High Line in New York,
Period offers an extensive view framed by a by a
2015-2016 “green” wall made of trees and flowers,
recreating the feeling of being outdoors.
13 Bridges & viaducts Civil buildings Industrial buildings Other structures
Mall of
Location Realization of a 3.000 seats movie
Doha, Qatar theatre with the largest IMAX Laser 3D
projection system in the world, built
Qatar
Client inside the Mall of Qatar for a total weight
UrbaCon Trading & of the steel structures of 1.600 tons.
Contracting (UCC)
Contractor Designed by the internationally known
/ studio of architects Chapman Taylor, this
500.000 square meters mall integrates a
Scope of work shopping, dining and entertainment
Design, supply, erection experience next to the Al Rayyan Sports
Club and 2022 FIFA World Cup Stadium.
Period
2015
15 Bridges & viaducts Civil buildings Industrial buildings Other structures
Centre
Location L-shaped mixed-use building divided into
Libreville, Gabon three structures with a total surface of
6.600 square meters: a south residential
Client
Guido
tower 10 floors high, a commercial north
Groupement Santullo tower 12 floors high a horizontal
Sericom Gabon S.A.
connection hosting parking lots.
Contractor
/ The steel structure has a weight of 1.769
tons, supporting the façade characteri-
Scope of work zed by a regular grid alternating opaque
Design, supply, erection and glazed modules, integrating with the
surrounding environment near the
Period prestigious area of Boulevard Triumphal,
2012-2014 main artery of the city hosting several
ministries and bank offices.17 Bridges & viaducts Civil buildings Industrial buildings Other structures
Garibaldi
Location Since 1984, the Garibaldi towers
Milan, Italy characterize the skyline of the city.
complex
Client In 2008 they have undergone a renova-
Beni Stabili S.p.A. tion including a new body “C” between
the two towers, made entirely of steel for
Contractor
Impresa Costruzioni a total weight of 1.150 tons. This new
Giuseppe Maltauro S.p.A. element is four floors tall and hosts
common spaces and recreational areas.
Scope of work
Design, supply, erection
Period
201219 Bridges & viaducts Civil buildings Industrial buildings Other structures
Centre International
Location The project has been conceived and
Algiers, Algeria financed by the Algerian Government to
step up its position in the international
Conferences (CIC)
Client arena.
Government of Algiers
With an overall surface of more than
Contractor
China State Construction 110.000 square meters able to host up to
Engineering Corp. Ltd. (CSCEC) 10.000 people, it is the biggest conferen-
ce center in North Africa. The 6.613 tons
Scope of work heavy steel structure develops around a
Design, supply central circular body, called T4, with a
diameter of 95 meters realized with
Period reticular trusses made of tubular pipes
2010-2014 with a maximum height of 6 meters.
Around it, the main covering T5 develops
for 330 meters, extending other 150
meters with the coverage T1 and T2.21 Bridges & viaducts Civil buildings Industrial buildings Other structures
Corinthia Hotel
Location One of the first five-star hotels in the
Khartoum, Sudan Sudanese capital, located in one of the
most alive districts of the city in front of
Khartoum
Client the meeting point of the Blue and White
Libyan Arab Foreign Investment Nile.
Company (L.A.F.I.C.O.)
Contractor All the 18 steel floors, 3.700 tons heavy,
Cooperativa Muratori And are irregularly shaped and lean on a
Cementisti (C.M.C.) central core made of reinforced concre-
te: they compose a majestic oval curved
Scope of work façade shaped like a sail with a total
Design, supply, erection covered surface of 60.000 square
meters. The hotel has become a symbol
Period of economic and cultural renovation of
2005-2006
the city.23 Bridges & viaducts Civil buildings Industrial buildings Other structures
NatGasoline
Location Supply of more than 1.800 tons of steel
Beaumont (TX), USA for the realization of a methanol plant
built in a 514-acre land and integrated to
methanol plant
Client an adjacent already existing production
Natgasoline LLC complex.
Contractor
Orascom E&C USA, INC The facility will produce 5.000 tons a day
of this petrochemical liquid coming from
Scope of work natural gas, and it is now the biggest
Design, supply methanol plant in the US, based on the
production capacity.
Period
201625 Bridges & viaducts Civil buildings Industrial buildings Other structures
New Capital
Location Supply of more than 10.400 tons for the
Cairo, Egypt construction of a gas-fired combined
cycle power plant situated in New Capital
power plant
Client City that will supply around 15 million
Army of Egypt Egyptians with electricity.
Contractor
Orascom Construction It sets to become the biggest one in the
world, with 4800 MW power capacity,
Scope of work supporting the energetic renovation that
Design, supply the country has undertaken.
Period
201627 Bridges & viaducts Civil buildings Industrial buildings Other structures
ADD airport
Location New cargo terminals aimed to four-fold
Addis Ababa, Ethiopia the storing surface at the main airport of
Addis Ababa, with a weight of 1.680 tons.
cargo terminals
Client
Ethiopian Airlines To spur export and consequently the
development of the country, the national
Contractor
Safet S.p.A. air company Ethiopian Airlines is
investing on new areas to host and
Scope of work transfer agricultural products destined to
Design, supply, erection foreign countries. This new enlargement
increases the hosting capacity to 1.5
Period million tons of goods per year, making of
2014-2015 it one of the biggest cargo terminals in
the world.29 Bridges & viaducts Civil buildings Industrial buildings Other structures
Cameri
Location Production plant for Final Assembly and
Cameri, Italy Checkout (FACO) of F35-JSF aircrafts,
located within the military airport of
military airport
Client Cameri.
Alenia Aeronautica
The overall surface is 500.000m², in
Contractor
Impresa Costruzioni which there are 20 buildings with a
Giuseppe Maltauro S.p.A. weight of 10.384 tons used for the
construction, maintenance and logistic of
Scope of work Joint Strike Fighter aircrafts on a global
Design, supply, erection level. It had a positive impact on the local
economy as well, creating six thousand
Period new jobs, increasing the demand of
2010-2014 members and beginning a technology
renovation in the local industry.31 Bridges & viaducts Civil buildings Industrial buildings Other structures
Termal Power
Location Placed along the East side of the
Monfalcone, Italy Valentinis Canal, it covers an overall area
of 30 hectares. The weight of the steel
Plant
Client structures reaches 2.300 tons.
Endesa Italia S.p.A.
The Thermal Power Station produces
Contractor
Duro Felguera S.A. electricity and currently has an installed
capacity of 976 MW and fueled by coal
Scope of work and dense fossil fuel oil, with a very low
Design, supply, erection Sulphur content.
Period
2006-200733 Bridges & viaducts Civil buildings Industrial buildings Other structures
Zoo de Beauval
Location Gigantic dome 32 meters tall realised in
Saint-Aignan-Sur-Cher, France the Zoo de Beauval, composed of 38
semi-arches, with a total weight of 780
Client
tropical greenhouse
tons and a diameter of 101 meters.
SAS ZooParc de Beauval
Bigger than a soccer field, it recreates
Contractor
Constructions Metalliques the equatorial habitat ensuring the
Florentaies (C.M.F.) management of the air and of the
temperature hosting up to 3.000 people
Scope of work per day visiting up close the animals. The
Design, supply, erection project will be inaugurated in 2020, for
the fortieth anniversary of the zoo.
Period
2017 - ongoing35 Bridges & viaducts Civil buildings Industrial buildings Other structures
Place Vendôme
Location Place Vendôme is a luxurious mixed-use
Doha, Qatar development of 1 million square meters.
The main mall building consists of 2
Client
domes
parking basements, a lower ground floor
United Development level, an upper ground floor level and 2
Company (UDC)
floors hosting shops. Adjacent are
Contractor developed three 5-star hotels and 2
Construction & Reconstruction parking towers.
Engineering Company (CRC)
Maeg is contributing by realizing the 12
Scope of work iron and glass skylight domes, as
Design, supply, erection supplier for both steel and glass and
proving itself as a competitor in the field
Period of installations of architectural envelops.
2017 - ongoing
Overall, the weight of the steel structure
amount to 7.200 tons, while the glass
surface reaches 35.000 square meters.37 Bridges & viaducts Civil buildings Industrial buildings Other structures
The Constellation
Location The Constellation is a memorial in honor
Abu Dhabi, UAE of sheik Zayed bin Sultan Al Nahyan,
former Abu Dhabi’s emir and former
Client
memorial
president of the UAE.
Private Office of Sheikh Mohamed
Bin Zayed Al Nahyan/ MUSANADA
The pavilion is 30 meters tall and has a
Contractor triangular structure of steel 250 tons
Al Fara’a Engineering heavy from which, with a millimetric
General Contracting tolerance, depart 1.100 inox cables on
which there are 1.327 geometrical
Scope of work elements representing the effigy of the
Design, supply, erection emir, recognizable from any latitude. The
project has a high social value for the
Period country, indeed it has been kept under
2017
secret until the big opening in February
2018.39 Bridges & viaducts Civil buildings Industrial buildings Other structures
Augusta
Location Realization of two container cranes,
Augusta, Italy 1.900 tons heavy, at the Augusta port,
province of Syracuse.
port cranes
Client
Autorità Portuale di Augusta This investment, part of the plan of
adjustment of the docks for mooring of
Contractor
Consorzio Valori S.c.a.r.l the container ships and the mobilisation
of containers in the commercial harbor,
Scope of work aims to help the port becoming an
Design, supply, erection important hub in the containerized
maritime trade in the Mediterranean Sea.
Period
2016-201741 Bridges & viaducts Civil buildings Industrial buildings Other structures
Expo 2015
Location Temporary pavilion at the Expo 2015 -
Milan, Italy Feeding the Planet, Energy for Life.
Mexican pavilion
Client The external structure of the pavilion is
ProMéxico composed of tubular profiles reaching a
height of 14 meters for a weight of 448
Contractor
Nussli Italia S.r.l. tons, wrapped with a membrane made of
canvas, resembling the shape of the
Scope of work corn, base ingredient of the Aztec culture
Design, supply, erection and inspiration of the designer. This
combination, filtering natural light and
Period reducing energy consumption, has been
2015 awarded with the Expo sustainability
prize.43 Bridges & viaducts Civil buildings Industrial buildings Other structures
Golden Tulip
Location This roofing covers the internal courtyard
Caserta, Italy of the luxurious hotel in Caserta.
Plaza Hotel
Client It is the biggest ventilated roof of its type
Hotel Marina di Castello S.p.A. in Italy, and one of the largest in Europe:
it has a surface of 3.600 sqm (58.5m x
Contractor
/ 58.5m). The project had to take into
consideration the seismic of the area,
Scope of work using a truss ends structure (without
Design, supply, erection anchors) connecting the perimeter
buildings with a total weight of 300 tons.
Period The dome, made of shatterproof
2004 laminated glass, could not be assembled
on the ground and has been performed
directly at height beginning from
perimeter beams.Maeg Costruzioni S.p.A. Via Toniolo 40 31028, Vazzola (TV) - Italy +39 0438 441558 www.maegspa.com
You can also read
