Compact? That's an optical illusion.
                                                                                                        Class-leading loadspace

                                                                                                        With cargo space ranging from 6.0 cubic metres in the L1 H1 (short wheelbase, low roof) to 8.3 cubic metres in the L2 H2
                                                                                                        (long wheelbase, high roof), plus the ability to carry standard 8' x 4' boards face down or standing, the Transit Custom is as
                                                                                                        practical as it is stylish.
    Model shown is a Transit Custom Limited Van L2 (long wheelbase) H2 (high roof) in Moondust Silver
4   metallic paint (option).                                                                                                                                                                                                             5
FORD TRANSIT CUSTOM - John Grose
A flip-up panel in the
    bulkhead allows load-
    through access to the
    underseat storage area,
    allowing items such as pipes
    and ladders of up to 3.4
    metres* in length to be
    transported securely.

    *Items of up to 3.0 metres can be carried in the L1
    (short wheelbase).

         A small detail goes a long way.
                                                     3.4 metres to be precise.
    The Transit Custom L2 (long wheelbase) can carry a range of 3.4 metre long items, thanks to its clever load-through
    bulkhead. (Standard) The flat load floor and near vertical walls help you make the most of all that space. A tough vinyl
    load floor liner provides a highly durable surface that’s easy to clean after the work is done. (Easy To Clean Load Floor is
    standard on Trend, Limited and Sport (vans only), option on ECOnetic and Base (vans only))

    Class-leading loadspace

    There’s no compromise in the most vital consideration for your work: maximising your loadspace and the ease with which
    you can use it.

    ■   From 6.0 to 8.3 cubic metres of space (L1 H1 to L2 H2)        ■   Side-mounted DIN/ISO compliant cargo tie-down points
    ■   3 Europallet capability                                       ■   Full-height or half-height hardboard lining
    ■   3.4 metre load length with load-through bulkhead (3.0 m       ■   Easy To Clean Load Floor
        in L1). Provides an extra 90-litres of space
