Radio Frequency Emissions Analysis of Radio Frequency Exposure Associated with Itron Advanced Metering Devices WHITE PAPER
EXECUTIVE SUMMARY Itron-enabled smart grid devices have
“Wireless smart meters, This document provides information undergone extensive testing and
when installed and properly regarding radio frequency (RF) emissions validation during Federal Communications
maintained, result in much and the spectrum of frequencies one Commission (FCC) equipment authorization.
That filing includes Maximum Permissible
smaller levels of radio is exposed to almost daily. Specifically,
we address RF emissions from Itron Exposure (MPE) testing, which can be
frequency exposure than found at http://www.fcc.gov/oet/ea/fccid/.
Advanced Metering Devices for smart
many existing common meter communications. The data indicate that all Itron smart
household electronic devices, With an eye toward resolving concerns
meters present an extremely low-level
particularly cell phones and of RF exposure when compared to the
about RF emissions, this document
regulatory limits established by the Federal
microwave ovens.” presents a framework for RF emissions
Communications Commission (FCC) for
and the critical role it plays in our daily
safe operations.
communication systems, such as police
“Health Impacts of Radio Smart meters transmit for only a fraction
and fire radio systems, pagers, radio
Frequency from Smart and television broadcasts, and cellular of the day for short durations. They are
Meters”. Published April telephones. In our homes, we have grown installed in locations that are isolated from
2011 by California Council on accustomed to cordless phones, wireless residents, which dramatically reduces
exposure levels. In aggregate, actual RF
Science and Technology networks, garage door openers, baby
monitors, microwave ovens, and our PCs – emissions from smart meters are significantly
all of which utilize and emit RF energy. lower than commonly used devices such as
cell phones, laptop computers, microwave
ovens and baby monitors.
Examples of RF fields commonly found in the everyday
environment in relation to Itron-enabled Smart Grid Devices
RF Output Compared to standing two feet
Source
from a Smart Meter
Standing in front of an active microwave oven,
550 times more
two feet from door
Holding a walkie-talkie to your head 55 – 4,600 more times
Holding an active cell phone to your head 3.3 – 1,100 times more
Using a laptop computer 1.1 – 2.2 times more
Sitting in a Wi-Fi cyber café 1.1 – 2.2 times more
A comparison of the expected RF densities near Itron-enabled smart grid devices versus a
sampling of other common devices. Source: Health Impacts of Radio Frequency from Smart
Meters by California Council on Science and Technology, April 2011
Itron continually monitors regulatory and rules, products are tested as if they are
scientific developments related to human constantly transmitting. Many factors
Smart Meter exposure to RF emissions. Itron relies on impact the total smart meter transmission
expert scientific conclusions related to RF schedule during a 24-hour period. The
exposures and potential health effects. frequency of transmission varies widely
According to the Federal Communications depending on network usage, customer
Commission (FCC), the Electric Power configured scheduled reads, and network
Wireless Laptop Research Institute (EPRI) and the California maintenance activities. Itron-enabled smart
1.1 – 2.2 times more Council on Science and Technology (CCST), grid devices not only meet the FFC rules
than smart meters
no adverse short or long-term health but, in actual usage, transmit significantly
effects have been shown to occur from the less frequently.
radio frequency signals produced by smart Based on actual field tests of 88,000 and
meters or other such wireless networks. 50,000 meters, the median transmission
Cellphone Our smart grid networking solution, time is 45 seconds per day (half fall above,
3.3 – 1,100 times more utilizing radio frequency communications, half below). The average transmission
than smart meters
fully complies with the United States time is 60 seconds per day. The total per
Federal Communications Commission’s day transmission time includes meter
Part 15 rules for safe use in publicly read data, network management and
Source: Health Impacts of Radio Frequency unlicensed spectrum. Pursuant to these time synchronization.
from Smart Meters by California Council on
Science and Technology, April 2011
Electromagnetic Spectrum
Frequency in hertz (Hz)
0Hz 10KHz 900MHz 300GHz 1THz 1018Hz
Low Frequency Radio Frequencies Visible Light Ionizing Radiation
Fields Sunshine
AC Outlet Plug
Cell Phone
Infrared
Dog Collar Gamma Ray
Television
Laptop
Computer Baby
Radio Monitor
Remote Ultraviolet
Control X-rays
Power Smart
Lines Meter Tanning Bed
REGULATING SMART METERS VS. guidelines are still in place today and have
CONSUMER PRODUCTS been updated as recently as 2001 to In 1985, the FCC first
In 1985, the FCC first established account for new classes of portable devices established guidelines to
guidelines to limit human exposure and that communicate using radio frequency. limit human exposure and
protect against thermal effects of absorbed According to the FCC guidelines, consumer protect against thermal effects
RF emissions. The guidelines were based products such as cell phones and laptop
on those from the American National
of absorbed RF emissions
computers—devices that are designed
Standards Institute (ANSI) that were issued to be used in contact with or in close
in 1982. In 1996, the FCC modified its proximity to the human body—use specific
guidelines, based on a rulemaking process absorption rate (SAR) as the primary metric
that began in 1993 in response to a 1992 for regulating exposure. This measures the
revision of the ANSI guidelines, as well rate of energy absorbed in units of watts
as findings by the National Council on per kilogram of body mass (W/kg). The
Radiation Protection and Measurements FCC guidelines establish a safe limit of 1.6
(NCRP) and the Institute of Electrical and W/kg for mobile phone devices.
Electronics Engineers (IEEE). The 1996
Unlike consumer products, smart meters SMART METERS AND THE FCC LIMITS power density by a factor of four. That’s a
are typically sited on the sides of homes, Based on years of studying whether major reason why radio waves from a smart
inside of utility closets, and are often exposure to radio waves causes adverse meter, at a distance of 10 feet, are only
protected by walls separating the device health effects, the FCC adopted MPE about one one-thousandth as much as a
from individuals inside of the residence. limits for radio transmitters of all types, typical cell phone. That’s also why powerful
The locations of these devices inherently including smart meters. The FCC MPE but distant radio and TV transmitters are
limit general population exposure. limits for smart meters of 0.6 mW/cm2 not seen as posing any danger.
Consequently, the FCC created a separate includes a prudent margin of safety just in
set of guidelines for stationary devices that TYPES OF EXPOSURE AND
case some health effects are too subtle
operate at least 8 inches away from human EXPOSURE LIMITS
to have been detected. Even so, smart
contact. These guidelines use Maximum meters operate far below the limit. Using a The FCC Rules and Guidelines define two
Permissible Exposure (MPE), which is realistic high-end duty cycle (4%), the MPE types of exposures to RF energy:
conservatively based on a SAR of 4 W/kg level for a typical Itron-enabled residential » Occupational / Controlled Exposure
as the measure of exposure. metering device operating in the unlicensed – persons who are exposed as a
The FCC document detailing how to spectrum 902-928 MHz is 0.01 mW/cm2. consequence of their employment
measure and/or calculate the levels of RF The MPE level for this device configuration and are fully aware of the potential for
radiation titled “Evaluating Compliance with is equivalent to 1.6% of the FCC limit; exposure and have the ability to exercise
FCC Guidelines for Human Exposure to however, actual results may vary depending control over their exposure.
Radio frequency Electromagnetic Fields” on the specific meter integration. » General Population/Uncontrolled
can be found at transition.fcc.gov. Exposure is based on the transmitter’s Exposures – apply when one is exposed
power and the distance from the source. and may not be fully aware of the
In general, doubling your distance cuts the potential for exposure or cannot exercise
control over their exposure.
Examples of RF fields commonly found in the everyday
environment in relation to Itron-enabled Smart Grid Devices
Frequency Range Electronic Field Magnetic Field Power Density (S)
Averaging Time in Minutes
(MHz) Strength (E) Strength (H) (mW/cm2)
0.3–3.0 614 1.63 (100)* 6
3.0–30 1842/f 4.89/f (900/f ) 2
6
30–300 61.4 0.163 1.0 6
300–1,500 – – f/300 6
1,500–100,000 – – 5 6
f=frequency in MHz *Plane-wave equivalent power density Source: FCC OET Bulletin 56–Fourth
LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE
Frequency Range Electronic Field Magnetic Field Power Density (S)
Averaging Time in Minutes
(MHz) Strength (E) Strength (H) (mW/cm2)
0.3–1.34 614 1.63 (100)* 30
1.34–30 842/f 2.19/f (180/f ) 2
30
30–300 27.5 0.073 0.2 30
300–1,500 – – f/1500 30
1,500–100,000 – – 1.0 30
f=frequency in MHz *Plane-wave equivalent power density Source: FCC OET Bulletin 56–Fourth
ITRON NIC IN A RESIDENTIAL
SMART METER PER FCC CERTIFICATION USING REALISTIC (HIGH END) DUTY CYCLE*
FCC Rule 15.247 Transmitter MPE Limit MPE @ 20cm Margin
Environment General Population/Uncontrolled Exposure RFLAN (902MHz) 0.6 mW/cm2 0.01 mW/cm2 1.6% of the limit
Exposure Conditions Minimum 20 centimeters (8 inches) ZigBee (2.4GHz) 1.0 mW/cm2 0.01 mW/cm2 1.0% fo the limit
RFLAN 902-928 MHZ
Frequency Bands
ZigBee 2.4-2.48 GHz
RFLAN 30 dBm (1000 mW) at 902 MHz
Transmit Power
ZigBee 22dBm (160mW) at 2.4 GHz
MPE LIMITS FOR CONTINUOUS EXPOSURE
RFLAN 1.2 dBi (1.3 times) at 902 MHz
Antenna Gain MPE Level
ZigBee 5.6 dBi (3.6 times) at 2.4 GHz
Duty Cycle (Est Max) RFLAN (902MHz) 3.0 mW/cm 2
0.6 mW/cm2
RFLAN 4%
(over 30 min. period) ZigBee* 10% ZigBee (2.4GHz) 8.0 mW/cm 2
1.0mW/cm2
*The 2.4 GHz radio provides connectivity to in-home devices such as *This is a conservative estimate of MPE based on results from a typical
smart thermostats and in-home displays. Customers must opt-in to residential metering device configuration. Actual results may vary
enable the 2.4 GHz radio functionality. depending on the specific meter integration.
CALCULATION OF RF EMISSIONS
Power Density Calculated With Reflection Factor
TransmitterPower [mW] x Antenna Gain[times] x Reflection Factor [times]
PowerDensity [mW/cm2] =
(4 x pi x (Distance[cm])2)
SUMMARY ADDITIONAL INFORMATION
Pursuant to the FCC rules, products are Federal Communications Commission (FCC)
tested in extreme conditions as if they are
» Radio Frequency Safety
constantly transmitting. In actual usage, Itron
enabled devices transmit significantly less » Radio Frequency Safety FAQs
frequently than this. And, our solution meets » Q&A about Biological Effects and
the FCC testing standards even under these Potential Hazards of Radio frequency
stringent testing parameters. Electromagnetic Fields Evaluating
Itron will continue to monitor the regulatory » Compliance with FCC Guidelines for
standards and research related to RF Human Exposure to Radio frequency
exposure to verify that our products are in Electromagnetic Fields
compliance with all applicable legal Federal Drug Administration (FDA)
and regulations.
» Radiation Health
Occupational Health & Safety
Administration (OHSA)
» Radio Frequency and Microwave
Radiation
The National Institute for Occupational
Safety and Health (NIOSH)
» EMF (Electric and Magnetic Fields)
World Health Organization (WHO)
» Electromagnetic fields and public health
California Council on Science and
Technology (CCST)
» Health Impacts of Radio Frequency
Exposure from Smart Meters
