Simple • Low Cost • Robust
RollsAIRTM & RollsAIRTM HS-STP®: Offering
versatility and consistent high performance for
multi-family residential and large commercial
properties. The RollsAIR™ and the RollsAIR™
HS-STP® offer a cost effective method to treat
larger flows for a multitude of applications:
RESIDENTIAL
• Multi-Family Properties
• Clustered Subdivisions
• Housing Developments
• Recreational Facilities
• Apartment Complexes
• Military Facilities
• Communities/Villages
• Small Municipalities
COMMERCIAL
• Restaurants
• Schools/Universities
• RV & Mobile Home Parks
• Office Parks
• Resort Areas/Hotels
• Highway Rest Areas
• Country Club/Golf Courses
• Shopping Centers
• Grocery stores
• Food/Beverage Facilities
Mighty Tough
on Cleaning!
Use Mighty Mike® environmentally-friendly maintenance products
to effectively clean without damage or leaving residues! Call
1-866-652-4539 or email solutions@sciencofast.com
Extended Aeration System
The RollsAIR™ Extended Aeration System is pre-engineered with
non-corrosive, simple to install, robust performance, easy to maintain
proprietary devices. As an “Activated Sludge” treatment system utilizing
an aerobic, suspended growth treatment process, it is designed to be
the most simple, low cost, robust system of it’s type.
The complete RollsAIR™ System uses the MyTEE® in the “headworks”
zone, to screen trash and settle grit. The MyTEE® Screen deflects non-
soluble solids to stay in the vault. All non-biological screened and settled
items require periodic- NOT daily maintenance from the MyTEE® Vault.
The easy maintenance of the MyTEE®’s patented Clean-in-Place swab
alleviates the need for manual raking from non-biological solids.
All items within the plant are operated by simple, robust, quiet, low
maintenance blowers mounted within engineered enclosures.
The Lixor® devices are submerged aeration systems that mix and aerate
the wastewater, creating the environment for aerobic bacteria and other
microorganisms to quickly biodegrade and digest incoming organic
matter. The unique features of Lixor are:
• Low Maintenance
• Highly Effective
• Non-Clogging, Venuri-Style Design
• Low Cost Aeration System
The non-clogging LIXOR® aerators do not require cleaning or replacement at regular intervals.
The submerged effluent clarifier weir does not require regular brushing of scum or algae.
General Product Information
Treatment capacity: Individual module capacities are rated based on biological (BOD),
hydraulic and other project-specific considerations. All rated capacities are given
as guidelines for suggested use. Actual capacity may vary with local conditions and
performance goals.
A.) After the MyTEE® Vault, the waste water flows into
Volume/People per module: Please note that only residential applications or those
the Rollsair™ Extended Aeration zone. applications requiring treatment for only sanitary wastewater may be designed from the
volume and number of people per module. Actual capacity may vary with local conditions
and performance goals.
B.) With simple, robust non-clog LIXOR® aerators, the
Module dimensions/weight provided only for shipping specifications. Please see design
aeration zone provides large amounts of oxygen and specifications for recommended exterior tankage sizing. Treatment modules shall be
installed inside tanks that are locally approved and manufactured using watertight
mixing to rapidly grow aerobic bacteria. The mixing action materials.
is from one or both sides of the zone creating a “rolling Electrical Options: Electrical components are available to meet all worldwide electrical
specifications (volt/phase/frequency).
action” movement mixing action. The flow though the
length of the aeration zone is “Plug Flow,” which begins the
treatment process at the front end of the zone continuing
as the water flows to the back end of the zone prior to the
submerged header, 60 degree hopper clarifier(s).
C.) After the clarifiers, the solids settle to the bottom of the
hopper clarifier and are pumped into the Sludge Holding
Tank or to be returned to the aeration zone to maintain
healthy bacteria. The sludge holding tank further digests
A B
wasted sludge to an inert substance for ease of disposal.
The sludge will be entirely biological with no plastic, metal,
rubber, or other non-biological matter. Digester aeration
C
also uses the simple, robust, non-clog LIXOR aerator.
Futhermore, the excess water is removed with an air
operated decant system to be sent to the aeration zone B
for further processing.
Maximum Treatment Capacity*
Systems Volume Approximate People Served
RollsAIR™ 2.0 20000 GPD (75.7 m3/d) up to 400
RollsAIR™ 4.0 40000 GPD (150 m3/d) up to 600
RollsAIR™ 6.0 60000 GPD (225 m3/d) up to 900
RollsAIR™ 8.0 80000 GPD (300 m3/d) up to 1200
RollsAIR™ 12.0 120000 GPD (450 m3/d) up to 1900
RollsAIR™ 16.0 160000 GPD (600 m3/d) up to 2500
Larger Applications >160000 GPD, consult factory. Other systems and accessories can be used in parallel and/or series for additional flow or desired treatment levels.
Bio-Microbics...Better Water. Better World.® www.biomicrobics.comOther Systems and Products available to
suit your particular needs:
FAST® Wastewater Treatment Systems
• RetroFAST®
• MicroFAST®
• NitriFAST®
• HighStrengthFAST®
• MyFAST®
Horizontal Trickling Filter Technology
How does the RollsAIR TM
system work? • SeptiTech® STAARTM Residential
• SeptiTech® STAARTM Commercial
1 Wastewater enters the treatment system Membrane BioReactors (MBRs)
• BioBarrier® MBR
2 Natural separation and settling processes occur in the • BioBarrier® HSMBR®
primary settling zone. Stormwater Treatment Solutions
• BioSTORM® System
3 In the primary settling zone for most large residential and • StormTEE® Litter Control
commercial applications, a MyTEE® device is used to Marine Sanitation Technology
prevent large solids from entering the treatment zone. • MarineFAST® LX-Series
• MarineFAST® M-&MX-Series
4 A remote, above-ground blower introduces air (oxygen) • MarineFAST® DV-Series
into the treatment module to facilitate a robust circulation of
Influent/Effluent Screening Solutions
wastewater rolling side to side with plug flow path. • BioSTEP® Screened Pumping Systems
• MyTEE® Grit Control Screen
5 Bacteria in the aeration zone become abundant, diverse, • SaniTEE® Wastewater Screen
self-regulating population of microbes consistently
Other Management Solutions
metabolize the incoming waste. • Lixor® Submerged Aeration Systems
• FOGHog® Traps & Tablets
6 Clear, odorless, treated water is ready for standard or • ABC®-N Clarifiers & Devices
innovative dispersal.
Water Treatment Solutions
• SciCHLOR® Hypochlorite Generators
• SciBRINE® BrineMakers
• Mighty Mike® CPT Tablets
4
1 3 5 6
2With over 50,000 installations in more than 60 countries, our Fixed Integrated Treatment Technologies (FITT®)
are the result of decades of experience, research & development, and real world operating history.
Awards, Technology Approvals, and Certifications
• 2015 Ingenuity Award Winner, Ingenuity Central (IC) K-State Olathe, showcases the • IMO (International Maritime Organization) – MARPOL 73/78 (50 BOD5, 50 TSS, 250
newest thinking driving our community & growing our economy fecal) and MARPOL 2010 (25 BOD5, 35 TSS, 125 COD, 100 fecal) – FAST® Technology
• 2015 Innovation in Marine Environmental Technology Offshore Excellence Award, • Massachusetts Title 5 Innovative/Alternative System - Technologies Listed under
based on environmental impact with marine sanitation devices and technology “General Use Permit for Nitrogen Reduction”, “Provisional Use,” & “Remedial Use”
• 2014 “BEST of GreenBuild” Editor’s Choice Award, U.S. Builder’s Review, “Creating • NSF/ANSI Std 40, class 1 Certified Systems 500 to 1500 GPD
Better Water Treatment Solutions for a Better World”
• NSF/ANSI Std 245 (Nitrogen Reduction) Certified – MicroFAST®, BioBarrier®-N
• 2012 President’s “E” Award for Excellence in Exports, granted by the President of the
MBR, BioBarrier® MBR and SeptiTech® Systems up to 1500 GPD
United States, presented by the U.S. Department of Commerce
• NSF/ANSI Std 350 class R (Water Reuse) Certified – BioBarrier® MBR 0.5, 1.0, & 1.5
• 2011 Technology Innovation Award (Decentralized Commercial Outlets) – Frost &
Sullivan – FAST® Technology • PDI (Plumbing & Drainage Institute) Certified – Standard PDI-WH201 and PDI-G101
• 2011 New Product of the Year Award – Recycling Category. Environmental Protection grease interceptors – promotes the advancement of innovative plumbing products.
Magazine (EPonline.com) “The financial, environmental and social benefits of • Poland – Aprobata Techniczna (Technology Approval) ze Instytut Ochrony
‘recycling’ are indisputable.” – BioBarrier® MBR Technology Srodowiska (Institute of Environmental Protection)
• 2011 Kansas Governor’s Exporter of the Year – presented by the Governor of KS, • România – Avizează Favorabil – Consiliul Tehnic Permanent Pentru Constructii –
KS Dept. of Commerce Ministerul Dezvoltarii Regionale Si Turismului
• 2010 North American Technology Innovation Award (Water/Wastewater) – Frost &
• Russia – Федеральная Служба По Надзору В Сфере Защиты Прав Потребителей
Sullivan – FAST® Technology
И Благополучия Человка (Federal Service of Environmental Protection)
• 2009 Technology Merit Business Achievement Award, Water/Wastewater –
• Russia – CPT Свидетельство о Pоссийских Стандартах (Certification of Russian
Environmental Business Journal (EBJ) – BioBarrier® MBR Technology
Standards) – BioSTORM® – All sizes
• 2002 U.S. Export Achievement Certificate, US Dept. of Commerce, US & Foreign
Commercial Service • Russia – PMPC (Russian Maritime Register of Shipping) МЕжДYНAРОДНОЕ
СВИДЕТЕЛЬСТВО О ПРЕДОТВРАЩЕНИИ ЗАГРЯЗНЕНИЯ СТОЧНЫМИ
• 2000 U.S. EPA Environmental Technology Innovator Award – U.S. EPA, Region 1 –
ВОДАМИ - International Sewage Pollution Prevention Certificate
SeptiTech® Technology
• SASO (Saudi Arabian Standards Organization) Certified
• Australian Dept of Transportation & Royal Australian Navy - Technology Approval
• ETL (UL) – Listed to US electrical certification requirements
• Canadian Great Lakes (CGL) Maritime Certification – Canadian Coast Guard
• Canadian Standards Association (CSA) International Electrical Certification • U.K. – United Kingdom Department of Trade – FAST® Technology Approval
• CE – European Electrical Systems (including a “Tropical Certification Rating”) • U.S. Coast Guard – 33CFR159, MEPC.159(55) – FAST® Technology Approval for
Type II MSD (Marine Sanitation Devices)
• China Classification Society (CCS) 中国船级社 – FAST Technology Approval ®
• U.S. EPA–ETV (Environmental Technology Verification) – RetroFAST®, No. 03/08/
• EN 12566-3, Packaged and/or site assembled domestic wastewater treatment plants
WQPC-SWP – SeptiTech®, Report No. 02/04/WQPC-SWP
for up to 50 People, PIA GmbH tested - BioBarrier® MBR 0.5, 1.0, & 1.5
...and MORE!
• GreenSpec® (BuildingGreen.com Product Directory) listed
