Company Presentation
AXTAL GmbH & Co. KG
June 2018 1
About
b AXTAL
“AXTAL” stands for ”Advanced XTAL Products” , where "XTAL" is a common abbreviation of "crystal"
AXTAL GmbH & Co. KG is a fully privately owned company, founded in November 2003 by Bernd Neubig*
and Brigitte Neubig. Facility location is in Mosbach/Baden in Southern Germany.
AXTAL GmbH & Co. KG’s core business comprises advanced Frequency Control Products (FCP), i.e. mainly
crystal oscillators and frequency & time modules. All products are ITAR‐free.
AXTAL GmbH & Co. KG main focus is on high‐reliability
high reliability oscillators for Military, Aerospace and Space, with
high requirements for environmental conditions, ultra‐low noise oscillators, for applications like Radar,
Aerospace and Space, and crystal‐controlled modules in the GHz range
AXTAL GmbH & Co. KG incorporates the full value chain including R&D, design, manufacturing, screening
and testing of our products from samples to production quantities completely in‐house.
AXTAL GmbH & Co. KG products manufactured in Germany are 100% ITAR free.
AXTAL GmbH & Co. KG’s product portfolio furthermore covers quartz crystal units, crystal filters,
Rubidium frequency standards, piezoelectric material, and piezoelectric sensors.
AXTAL GmbH & Co Co. KG possesses an assured crystal supply through a close cooperation with ISO 9001
and Space certified companies in Europe, Canada and China
AXTAL CONSULTING is a Sister Company for Design and Consulting Services in the Field of Frequency
Control Products and Piezoelectric Sensors, established by Bernd Neubig in April 2002
_________________________________________________
*Personal profile of the founder see at the end of the presentation
June 2018 2
Location
AXTAL GmbH & Co
Co. KG
AXTAL CONSULTING
Principal Office,
Office Administration:
(Billing address)
Buchfinkenweg 8
D‐74931 Lobbach
Mosbach Facility:
(Shipping address)
Roemerring 9
D‐74821
D 74821 Mosbach
Germany
Phone: +49(6261)939834 E‐Mail: General: info@axtal.com
Fax: +49(6261)939836 Sales & customer service: sales@ axtal.com
Website: www axtal com
www.axtal.com
June 2018 3
Company Profile: Consulting
AXTAL Consulting is an independent Consulting Company and Test House
AXTAL Consulting offers Consulting Services for application and design of Frequency Control
Products (FCP), i.e. quartz crystal units, LGS and GaPO4 crystal resonators, crystal oscillators, filters,
and piezoelectric sensors
AXTAL Consulting helps suppliers and users to optimise the match between product and
application, and thus reduces the risk of failures in the volume application and in the field in an
early stage
AXTAL Consulting provides failure analyses, suggests corrective actions, and assists its customers in
process audits of manufacturing lines
AXTAL Consulting offers testing, screening , qualification of Frequency Control Products according
g IEC‐,, MIL‐,, ESA‐ and Automotive Standards,, e.g.
to acknowledged g
measurement of linear and non‐linear electrical parameters,
temperature tests,
phase noise and short‐term stability tests
aging
g g tests
mechanical and environmental tests
AXTAL Consulting offers screening & upscreening services of FCP for Space applications
ESA ESCC3501 and MIL‐PRF‐3098 (quartz crystals)
MIL PRF 55310 ((crystall oscillators)
MIL‐PRF‐55310 ill )
June 2018 4Markets served
RF & Microwave Industry
Military
Avionics/Aerospace
Marine
Satellite Communication
Space
RF Test & Measurement Equipment
Medical instrumentation
Research
Industrial Electronics
June 2018 5Main countries
Germany
France
Italy
United Kingdom
Scandinavia
China
India
Russia
Singapore
Israel
USA
June 2018 6Quality Management
Since 2008: Quality management system in accordance with ISO 9001:2015,
certified by TUEV SUED
100 % Incoming inspection of quality‐critical
components (crystals,
( l Hi‐Rell components, PCB, etc.))
Active & passive pre‐aging of quartz crystals
Thorough intermediate testing (production line)
C
Computer‐controlled
t t ll d test
t t equipment
i t
100 % final test of all key & critical parameters
Optional screening to MIL‐PRF55310 or ESA
Traceability of test and measurement results
Product marking with serial no. and date code
Traceable instrument calibration
Workmanship to J‐STD‐001 and IPC‐A‐610,
IPC‐A‐610 Class 3
ESA‐certified personnel for space products
June 2018 7Customer Audits
(not complete)
Airbus ((EADS Defence/Cassidian)
/ ) Ulm/Germany
/ y
Selex Galileo Luton/UK
Diehl Aerospace Frankfurt Ulm/Germany
TESAT Spacecom Backnang /Germany
CAST (China Association for Science &Technology)
CASC (China Aerospace Science & Technology Corporation)
June 2018 8Oscillator Qualification
Qualification testing based on IEC 60679‐4
60679‐4, MIL‐PRF‐55310,
MIL‐PRF‐55310 MIL‐
STD‐883, MIL‐STD‐202, ESA Standards or Customer Specification
Frequency stability over various parameters
Output waveform & spectrum
Frequency control, linearity, modulation response
Start‐up behaviour, start‐up time
S bili i time,
Stabilization i re‐trace, time‐domain
i d i
Phase noise, short term stability (Allan deviation)
G‐sensitivity, Phase noise under vibration
Temperature tests ‐55°C ~ +125°C, activity dips
Aging tests ‐ passive and active
Leak test
In‐house environmental tests: shock, vibration
(sine and random), thermal shock,
High temperature storage etc.
June 2018 9AXTAL Products‐ Overview
Type Description Features
SPXO Fixed‐frequency Crystal Oscillators, ‐ Small size clocks
Clocks ‐ Low Noise & high frequency
up to 1300 MHz
VCXO Voltage Controlled Crystal Oscillator ‐ Wide‐pull with tuning range up to
±5000 ppm and up to 400 MHz
‐ High frequency up to 1300 MHz
TCXO Temperature Compensated Crystal ‐ Low Noise & high frequency
Oscillator up to 10 GHz
OCXO Oven Controlled Crystal Oscillator ‐ Ultra‐low noise
‐ Low g‐sensitivity
‐ Vibration isolated
‐ Low power / very fast warm
warm‐up
up
‐ Very high stability
‐ High frequency up to 1500 MHz
June 2018 10AXTAL Products – Overview II
Type Description Features
Space OCXO Ultra‐low noise space qualified ‐ 100 MHz & 120 MHz models
(USO) Oven Controlled Crystal Oscillator ‐ 100 krad TID / SEL immune
‐ ESA EPPL listed / Space Heritage
‐ 30 krad Space COTS version
available
PSO, VCSO, SAW Oscillators (Fixed, Voltage & ‐ High frequency up to 2 GHz
OCSO O
Oven Controlled)
C t ll d) ‐ Low
L noisei & hi
high
h spectral
t l purity
it
FCXO / Phase‐Locked Crystal Oscillators ‐ Internal TCXO / OCXO reference
PLXO with external or internal reference ‐ High frequency up to 10 GHz
‐ Customized modules
Microwave Crystal‐Controlled Microwave ‐ Multiple frequency outputs
Oscillators ‐ PLL or Multiplication ‐ High frequency up to 10 GHz
G d
Gated G d Crystal
Gated C l / SAW O
Oscillators
ill ‐ IFF
I Transponder
d Applications
A li i
‐ Frequency up to 1532 MHz
DA Distribution Amplifier 19” rack 1 HU ‐ 10 MHz with up to 16 outputs
‐ Opt.
Opt OCXO reference in 19” rack
June 2018 11OCXO = AXIOM Series
Oven Controlled AXTAL Oscillators (OCXO)
Use of AT‐ and SC‐cut resonators in Cold‐weld packages
for very low aging / low phase noise down to < ‐183 dBc/Hz
Frequency range up to 1500 MHz
High‐Performance OCXO (± 0.1 ppb stability) in 20x20 mm package
Fast warm‐up, low power OCXO in DIL14 (CO 02) and DIL8 package
Connectorised OCXO (optional with multiple outputs)
OCXO with low G‐sensitivity
OCXO with low phase noise, also under random vibration
OCXO in ruggedised vibration isolated packages
OCXO for Aerospace and for Space Applications
For more details please refer to our catalogue
June 2018 12(S)PXO = AXE Series
Packaged AXTAL Oscillators, Clocks (SPXO)
Low phase noise,
noise low jitter
High stability through hermetically sealed resonators
High Output Frequencies (up to >2 GHz) by using
Low Noise Frequency Multiplication
Phase‐Locked Loop (PLL)
SAW resonators (PSO)
Microwave Oscillators for MIL, Satcom & Airborne
For more details please refer to our catalogue
June 2018 13VCXO = AXIS Series
V l
Voltage C
Controlled
ll d AXTAL Oscillators
O ill (VCXO)
Low phase noise, low jitter
High Frequency VCXO by using
Low Noise Frequency multiplication
Phase‐locked loop
SAW resonators (VCSO)
Wide pulling range up to ±5000 ppm using LGS crystals
Microwave VCXO for MIL, Satcom & Airborne
For more details please refer to our catalogue
June 2018 14TCXO = AXLE Series
Temperature Compensated AXTAL Oscillators (TCXO)
Low aging through hermetically sealed resonators
Low phase noise & jitter
High frequency up to >10 GHz
Wide operating temperature range –55°C to 90°C
Hybrid packages, hermetically sealed metal packages,
ceramic packages
Ultra‐high stability TCXO up to ±0.05 ppm ‐40°C~+85°C
For more details please refer to our catalogue
June 2018 15Special Oscillators
FCXO / PLXO (Phase Locked Crystal Oscillators)
Output frequency = M/N∙ Input frequency (PLL)
Low phase noise, low transfer jitter
Microwave Oscillators
SPXO, VCXO, TCXO and OCXO with PLL or
Multiplication up to 10 GHz
Gated Crystal Oscillators (IFF applications)
SAW Oscillators (PSO and VCSO) up to 2 GHz
Multi‐Channel Switchable crystal oscillators
Special Oscillators Modules for MIL applications
For more details please refer to our catalogue
June 2018 16Other Frequency Control Products
Quartz Crystal Filters
Di
Discrete
t Filt
Filters
Monolithic Filters (Duals)
Polylithic Filters
Surface Acoustic Wave (SAW) devices
SAW Resonators up to 2 GHz
SAW Filters up to 2 GHz
SAW Oscillators (PSO, VCSO, OCSO) up to 2 GHz
June 2018 17Frequency Distribution Units
AXDA9000 – Low Noise Selective Distribution Amplifier
AXIOM9000 – Very High Stability Ultra‐Low Noise Reference (D)OCXO
AXDO9000 – AXIOM9000 Reference with integrated distribution amplifier
AXGPS9000 – GPS‐disciplined OCXO Frequency Reference
AXRB9000 – High Stability Low Noise Rubidium Frequency Reference
AXPLO9000 – Masterclocks with Customized Frequency Modules
and external reference input
For more details please refer to our catalogue
June 2018 18Special Oscillators ‐ Space
Oscillators (PXO, VCXO, TCXO and OCXO) for Space Application*
100 MHz OCXO listed in EPPL (ESA Preferred Parts List) / Space Heritage
Use of radiation resistant ECSS‐Q‐ST‐60C class 1 components
(QPL or other approved sources)
Material selection based on ECSS‐Q‐ST‐70C and ECSS‐Q‐70‐71
Usage of quartz crystal resonators manufactured from swept
quartz material for high radiation resistance IAW with ESCC 3501
Oscillator manufacturing in Clean‐Room environment (ISO Class 3)
in accordance with ECSS‐Q‐ST‐70‐08C and ECSS‐Q‐ST‐70‐38C
P
Pre‐cap i ti off quartz
inspection t crystal
t l prior
i tot sealing
li
Soldering and assembly by ESA certified personnel
Pre‐cap inspection of oscillator assembly prior to sealing
Screening and testing to ESA,
ESA NASA and customer specifications
Complete traceability of all materials and manufacturing steps
Engineering Models, Qualification Models, Flight Models, LAT Models
*For more details please refer to our separate SPACE presentation
June 2018 19AXTAL Products
Crystal Sensors
Quartz Crystal Microbalances (QCM)
Crystal Temperature Sensors
y
Crystal p
pressure sensors
Pressure transducer modules with temperature transducer
Crystal Wafers and Blanks
Langasite (LGS) Wafers
Langatate (LGT) Wafers
LGS, LGT and CTGS blanks
LGT and CTGS rings
Other LGS family crystals
YCOB crystals
Q t crystal
Quartz t l wafers
f & rings
i
June 2018 20AXTAL Test Systems
CRYSTALS
CRYSTALS:
OSCILLATORS:
Automatic Temperature Test system for crystals
(THD and SMD) with NWA
Automatic Temperature Test Systems for VCXO and Automatic RT Test system for crystals (THD and
TCXO (pre‐compensation and final temp test)
SMD) with Network Analyzer
Automatic Temperature Test Systems for OCXO
Automatic crystal Test Systems 8 kHz ~ 200 MHz
Automatic OCXO Test System
(Saunders)
Automatic Aging Test System
Automatic Crystal Test System (Kolinker)
Cyclic‐Power
Cyclic Power Oscillator Stress Test System
Automatic Oscillator Final Test System Active Crystal Aging System (Proprietary)
Phase Noise Test systems (R&S, Agilent & NoiseXT) Network Analyzers (HP/Agilent)
Frequency & Time Interval Analyser
Short‐Term
Short Term Frequency Stability Test System
Modulation Analyzer (R&S)
GENERAL
GENERAL:
Spectrum Analyzers (R&S, Tektronix) Leak test system (Trio‐Tech), He pressure vessel
Oscilloscopes (Tektronix, HP/Agilent) Burn‐In system
Rubidium and Caesium Frequency Standards & Vacuum Bake‐out system
y (Heraeus)
( )
GPS‐disciplined Rubidium standards Vibration & Shock Test System (TIRA)
Frequency Counters (HP/Agilent, Philips) Temperature Shock Test System (Thermostream)
Low –Noise Frequency Synthesizer (R&S) Inspection systems (Vision Engineering etc.)
EMI Shield room
Stereo Microscopes with camera
June 2018Equipment for Manufacturing
Stencil Printer (Essemtec)
Semi‐Automatic SMD Pick & Place System (Essemtec)
Fully‐automatic SMD Pick & Place System (Essemtec)
M
Manual l SSolder
ld DiDispenser & SMD assembly
bl station
i
Convection Reflow Oven (Essemtec)
Vapour Phase Reflow Soldering System (IBL)
Manual soldering stations (Tip Soldering, Hot‐Jet Soldering)
Automatic Ultrasonic Cleaning system
Rework stations (Metcal, Weller)
Grey Room with Laminar‐Flowbox (Class 1000 /ISO Class 3)
Resistance Welding Systems (Soudax, Pyramid)
Laser Markingg System
y
Tape & Reel System
Thermosealing machine (Vacuum and/or N2)
Mechanical tool shop
June 2018Personal Profile
Bernd Neubig
Prior to founding AXTAL in 2003, Bernd Neubig was Vice President of Tele Quarz (TQ) (later Oak Frequency
Control → Corning Frequency Control → Vectron → Microsemi, now Microchip) since 1983. He established
the oscillator and filter product line at Tele Quarz, with full responsibility for R&D, operations and engineering.
Prior to jjoiningg TQ,
Q, Bernd Neubigg was 7 years
y with KVG ((Kristallverarbeitungg Neckarbischofsheim),
), a
manufacturer of frequency controlled products. He held positions as crystal design engineer and later R&D
manager for oscillators and filters.
1969 Graduation as Diplom Engineer (Dipl.‐Ing.) for Telecommunications at the University of Applied Sciences
in Berlin.
Study of Physics at the Technical University in Berlin,
Berlin graduation as Diplom Physicist (Dipl
(Dipl.‐Phys
Phys.)) in 1975
1975.
Chairman of the German Section of IEC TC 49 Standardization Committee
Member of the Scientific Committee of the European Time and Frequency Forum (EFTF).
Member of the Technical Program Committee of the IEEE Frequency Control Symposium (FCS)
Co‐author
More than 30 scientific and technical publications, Co author of a book on Frequency Control components
(„Das Grosse Quarzkochbuch“, 1997)
Lecturer of seminars on quartz crystals, oscillators, filters and related frequency control components
November 2004: Recipient of the IEC 1906 Award from the International Electro technical Commission (IEC)
June 2006:
2006 Recipient of the David P.
P Larsen Award of the Piezoelectric
Pie oelectric Devices Association (PDA) USA
April 2010: Recipient of the DKE Needle Award for long‐term voluntary engagement and for the contributions
to the standardization in the field of Frequency Control.
April 2015: Recipient of the Marcel‐Ecabert‐Award issued by the European Time & Frequency Forum (EFTF)
May 2016: Recipient of the W.G. Cady Award by the IEEE Frequency Control Symposium (IFCS)
June 2018 23AXTAL Website
For latest updates:
Visit our Website
www.axtal.com
Roemerring 9
D‐74821 Mosbach / Germanyy
fon: +49(6261)939834
fax: +49(6261)939836
E‐Mail: info@axtal.com
June 2018 24You can also read
