ELECTRICAL, LIGHTING,
INDUSTRIAL & CABLE
PRODUCT PROFILE
www.voltex.co.za
1
INDEX
PRODUCT PROFILE
POWER DISTRIBUTION 2
Conduit/Piping 2
Cable and Wiring Accessories 3
Switchgear 4
Distribution Boards, Enclosures and Kiosks 7
Motor Control 8
CABLE AND WIRE 13
Domestic and Light Industrial 13
Industrial 16
Agricultural 19
Low Voltage 20
GENERAL ELECTRICAL 22
LIGHTING 24
Domestic 24
Commercial and Industrial 27
Lamps and Discharge Lamps 29
SPECIALISED 31
ACCESSORIES AND CONSUMABLES 34
CHARTS AND TABLES 37
Ingress Protection (IP) Rating Guide 37
Gland and Cable Rating Chart 38
Earth Wire Table 39
3 - Phase Formulas 40
Cable Splicing Guide 41
CCG Charts 42
2
POWER DISTRIBUTION
Conduit/Piping
PRODUCT PROFILE
PVC Conduit and Accessories
· Straight lengths (4m)
· Full range available in: 20, 25, 40 and 50mmØ
· Bends 90°
· Inspection elbows 45°
· Round boxes
· Adaptors
· Couplings
· PVC glue
· Bending springs
· Strap saddles
· Spacer bar saddles
· Meterbox pipes
· Flexible conduit
Galvanised Steel Conduit
· Straight lengths
· Full range available in: 20, 25, 40 and 50mmØ
· Bends 90°
· Entry boxes: Side entry
Spout (bottom entry)
· Couplings
· Adaptors
· Retaining compound
· Pipe bender
· Strap saddles
· Spacer bar saddles
Extension and Wall Boxes
Available in: Metal/PVC
Sizes: 4x2/4x4
Closed/open back/back-to-back
Draw boxes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
3
POWER DISTRIBUTION
Cable and Wiring Accessories
PRODUCT PROFILE
Cable Termination
· Glands: PVC glands
Glands
· Compression glands
· BW (IP20)
· FLP (Flame Proof)
· Shrouds: Neoprene/PVC
No 0-9
· Barrier glands
· Junction and utility boxes
· Photovoltaics
· Sleeving and spiral binding
· Heat shrink and end caps
· Joint kits
Wire Accessories
· Cable clips
· Cable ties
· Line taps
· Lugs and ferrules
· PVC glands
· Strip connectors
· Wire strippers
· Stainless steel strapping tools
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
4
POWER DISTRIBUTION
Switchgear
PRODUCT PROFILE
Air Circuit Breakers (ACB)
A device used to provide overcurrent and short
circuit protection for circuits ranging from 800A to
10 000A. Usually used in low voltage applications
below 450 Volts.
Available for circuits ranging from 1250A to 6300A.
Miniature and Moulded Case Circuit Breakers
Miniature Circuit Breakers: A device which protects
an electric circuit from an overcurrent. The
overcurrent may result from short circuit, overload or
faulty design.
Available in the range of 1A to 125A.
Moulded Case Circuit Breakers: A device which
protects an electric circuit from an overcurrent or a
short circuit. Their primary functions are to provide a
means to manually open a circuit and automatically
open a circuit under overload or short circuit
conditions.
Available for circuits ranging from 100A to 1600A.
Time Switches
A time switch (also called a timer switch or a timer) is
a device that operates an electric switch controlled
by a timing mechanism.
Samite and DIN Rail/Mini Rail
A metal rail of a standard type widely used for
mounting circuit breakers and industrial control
equipment inside equipment racks. These products
are typically made from cold rolled carbon steel
sheet.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
5
POWER DISTRIBUTION
Switchgear
PRODUCT PROFILE
Busbars
In electric power distribution, a busbar is a copper
strip or bar typically housed inside switchgear, panel
boards and busway enclosures for local high current
power distribution.
Electricity Meters
A device that measures the amount of electric
energy consumed by a residence, a business or an
electrically powered device.
Earth Leakage
A safety device used to prevent shock in electrical
installations with high earth impedance. It detects
small stray voltages and interrupts the circuit if a
dangerous voltage is detected.
Available with overcurrent protection functionality
on request.
Miniature and Moulded Case Isolators
Miniature Case Isolators: A manually operated
mechanical switch which separates the circuit from
the power main so that repairs can be done without
danger.
Moulded Case Isolators: Commonly used as either
a feeder breaker or a single circuit breaker where
disconnecting, shortcircuit and thermal protection
functionality is required.
When ordering, please specify thermal/magnetic trip
units required.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
6
POWER DISTRIBUTION
Switchgear
PRODUCT PROFILE
Surge Protection Device (SPD)
A device used to protect against surge currents or
voltages in a circuit caused by external (lightning) or
internal (switching) events.
When ordering, please specify protection class
required.
Please Note:
Please provide the following information when placing an order so as to ensure
we supply the correct switchgear:
· DIN/Samite
· Single (1P) or three (3P) phase
· kA rating (e.g. 3kA/6kA)
· Current rating (Amp)
· Fixed/Draw type
· Curve (C/D)
· Cable size: 16/25mm²
OR
· Supplier/Voltex Code
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
7
POWER DISTRIBUTION
Distribution Boards, Enclosures and Kiosks
PRODUCT PROFILE
Distribution boards and enclosures are available in various sizes, materials,
colours, types, protection ratings and applications.
We also offer pre-populated boards and Telkom distribution boards.
Please Note:
Please provide the following information when placing an order:
· DIN/Samite
· Flush/Surface mount
· Number of modules required
· Material e.g. PVC, mild steel/galvanised steel/stainless steel
· IP rating required (see page 37)
· Shock resistance required
OR
· Supplier/Voltex code
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.
8
POWER DISTRIBUTION
Motor Control
PRODUCT PROFILE
A motor controller is a device or group of devices that manages the performance
of an electric motor.
It might include a manual or automatic means for starting and stopping a motor,
selecting forward or reverse rotation, selecting and regulating speed, regulating
or limiting torque and protecting against overloads and faults.
Please allow for extra lead times when ordering as not all motor control
accessories are standard stock items.
Contactors
A contactor is an electrically controlled switch used
for continuously establishing and interrupting an
electric power circuit.
Select an application:
AC1 (no constant switching - On/Off)
AC2 (plugging and inching)
AC3 (breaking during normal running)
AC4 (breaking during normal running, plugging
and inching)
Direct Online Starters (DOLs)
The simplest type of motor starter, a Direct Online
Starter (DOL) applies the full line voltage to the motor
terminals.
Smaller sizes are manually operated whereas larger
sizes use an electromechanical contactor (relay) to
switch the motor circuit.
Manual Motor Starters
Manual motor starters are primarily used to manually
switch motors On/Off and to provide fuseless
protection against shortcircuit, overload and phase
failures.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.9
POWER DISTRIBUTION
Motor Control
PRODUCT PROFILE
Star/Delta Starters
A very common type of starter and widely used, a
star/delta is used for a cage motor designed to run
normally on the delta connected stator winding.
Thermal Overload Relays
Thermal overload relays offer reliable protection for
motors in the event of overload or phase failure.
Designed to cut power if the motor draws too much
current for an extended period of time.
Can be ordered to meet specific requirements.
Push Buttons
· Push and Stop/Start buttons
· Selector switches/key switches
· Pilot light complete units
· Stop/Start combination buttons
Motor Control Accessories
· Coils
· Surge units
· Auxiliaries
· Interlocks
· Timers
· Capacitor units
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.10
POWER DISTRIBUTION
Motor Control
PRODUCT PROFILE
Terminals
A terminal is a point at which a conductor from an
electrical component, device or network comes
to an end and provides a point of connection to
external circuits.
A terminal may simply be the end of a wire or it may
be fitted with a connector or fastener.
Types of terminals:
· Splices
· Cups
· Hooks
· Solder lugs
· Tongue crimp terminals (ring terminals)
· Turrets
· Test probes (pogo terminals)
· Clips
· Screw terminals
· Tab terminals (quick connect, quick disconnect)
· Wire nuts
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.11
POWER DISTRIBUTION
Motor Control
PRODUCT PROFILE
LV Distribution and Motor Control
Voltex can custom design industrial and commercial
floor standing low voltage electrical panels including
electrical equipment, wiring and busbars to suit most
applications.
MV Distribution and Motor Control Panels
Simoprime air-insulated, medium voltage, type
tested distribution boards are designed for standard
applications in the power utilities and industrial
sectors.
Variable Speed Drives and Soft Starters
Motors often require large amounts of energy when
quickly accelerating to full speed. Soft starters and
variable speed drives can both be used to reduce
inrush currents and limit torque, protecting your
valuable equipment and extending the life of your
motor by reducing motor heating caused by
frequent starts and stops.
Choosing between a soft starter and a variable
speed drive would depend on the application,
system requirements and cost (both for initial startup
and over the lifecycle of the system).
Voltex offers a wide variety of both.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.12
POWER DISTRIBUTION
Motor Control
PRODUCT PROFILE
Programmable Logic Controllers (PLCs)
A Programmable Logic Controller is a digital
computer used for the automation of industrial
processes such as the control of machinery on
factory assembly lines.
It is designed for multiple input and output
arrangements, extended temperature ranges,
immunity to electrical noise and resistance to
vibration and impact.
Human Machine Interfaces (HMIs)
Human Machine Interface is the user interface in a
manufacturing or process control system. It provides
a graphics-based visualisation of an industrial
control and monitoring system.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.13
CABLE AND WIRING
Domestic and Light Industrial
PRODUCT PROFILE
SINGLE CORE GP WIRE (Slipdac) PANEL FLEX
NAME
SANS 1507-2 and SANS 1507-3 SANS 1574-3
Computer Input SG (e.g. SG 01 for 1mm²) SJ
Quotation Description S/SCORE CU PVC Housewire (colour) S/CORE CU Flex Panel Wire
Industrial buildings, housing, control panels, Control panels, light fittings, communication
Application
parallel cabling. panels, appliances.
1.0 - 95mm² 0.5 - 35mm²
Sizes
(bigger sizes on special request) 1.0mm² (comes in solid)
White, red, blue, yellow, black, violet, orange, Red, blue, yellow, black, violet, orange,
Colours
green/yellow green/yellow
Cores 1C 1C
Conductor Copper (Class 2) Copper (Class 5)
Insulation PVC PVC
Voltage 600/1000V 300/500V and 600/1000V
100m coils
100m coils (up to 70mm²) 500m drums (on special request)
Packaging
300m drums (over 70mm²) Cardboard barrels available on special
request depending on size.
Cut to Size – Atlas Yes (from 25mm²) No
Cut to Size – Voltex Yes Yes
FLAT TWIN AND EARTH SURFIX (Norsk)
NAME
SANS 1507-2 SANS 1507-2
Computer Input SF SK
Quotation Description (Size) (Cores) Flat twin and earth (Size) (Core) + Earth surfix (Colour)
Surface/internal wiring, under-plaster wiring, Surface/external wiring, under-plaster wiring,
Application
wiring in hollow walls/roof spaces. wiring in hollow walls/roof spaces.
Sizes 1 - 16mm² 1.5 - 10mm²
Colours Black and white White and black
Cores 2C and 3C 2C, 3C and 4C
Conductor Copper Copper
Bare tinned copper and aluminium
Earth Conductor Bare copper
laminate
Insulation PVC (UV stable sheath) PVC (UV stable sheath)
Voltage 300/500V 300/500V
Packaging 100m coils and drums 100m coils and drums
Cut to Size – Atlas No No
Cut to Size – Voltex Yes Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.14
CABLE AND WIRING
Domestic and Light Industrial
PRODUCT PROFILE
CABTYRE ABC (Aerial Bundle Conductor)
NAME
SANS 1574 SANS 1418 Part 1 and 2
Computer Input SY TT/ABC
Quotation Description (Core) CU PVC CABTYRE (Size) (Core) + (Bare/INS) Neutral
Power tools, electric lawnmowers,
Aerial distribution cables, farms, low cost
extension leads and multiplugs, small
Application distribution, rural electrification, street lighting.
industrial machinery, household
French and German system available.
appliances.
Sizes 0.5 - 4mm² 25 - 150mm²
Colours Black, white and grey Black
Cores 2C, 3C, 4C, 5C and 7C Variable
Conductor Copper (Class 5 flexibility) Aluminium
Insulation PVC (UV stable sheath) XLPE (UV stable)
300/300V (Light duty)
Voltage 600/1000V
300/500V (Normal duty)
100mm coils
Packaging 500/1000m drums
500/1000m drums (on special request)
Cut to Size - Atlas No No
Cut to Size - Voltex Yes Yes
AIRDAC SNE (Separate Neutral AIRDAC CNE (Combined Neutral Earth)*
NAME
Earth)* SANS 1507-6 SANS 1507-6
Computer Input TT/SNE TT/CNE
Quotation Description AIRDAC SNE + Pilots AIRDAC CNE (pilots available on request)
House service connections. Low cost housing projects.
Application Feeding power to houses with Overhead supply to houses without prepaid
prepaid meters. meters.
Sizes 4, 10 and 16mm² 4, 10 and 16mm²
Conductor Hard drawn copper Hard drawn copper
Insulation XLPE XLPE
Voltage 600/1000V 600/1000V
Packaging 500m drums 500m drums
Pilots Yes No (available on request)
Insulated with black insulation
Neutral Bare
(PE - Polyethylene)
Sheath UV Stable PE UV Stable PE
Cut to Size - Atlas No No
* ABC is intended for aerial use ONLY. However, where AIRDAC is concerned, SANS 10142 does give provision for it to be used
underground provided proper de-rating factors are applied.
Wire Packaging (mm2) 0.5 0.75 1.0 2.5 4.0 6.0 10.0 16.0 25.0
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.15
CABLE AND WIRING
Domestic and Light Industrial
PRODUCT PROFILE
NAME SILICONE CABTYRE SILICONE SC FLEXIBLE WIRE
Computer Input SC (01, 2/4) SS (01, 2/4)
Quotation Description (Size) (Core) Silicone Cabtyre (Colour) (Size) SC Silicone Flexible Wire (Colour)
Used where cable will be exposed to
Used where cable will be exposed to higher
Application higher temperatures, e.g. stoves and
temperatures, e.g. stoves and kitchen appliances.
kitchen appliances.
Sizes 1.5, 2.5 and 4.0mm² 1.5, 2.5 and 4.0mm²
Colours Outer sheath black/red White, brown, red, grey, yellow and green
Cores 3C and 4C 1C
Conductor Copper Copper
Insulation Silicone Silicone
Voltage 600/1000V 600/1000V
100m coils 100m coils
Packaging
1000m drums on special request 1000m drums on special request
Armouring None None
Cut to Size No No
Wire Packaging (mm2) 0.5 0.75 1.0 2.5 4.0 6.0 10.0 16.0 25.0
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.16
CABLE AND WIRING
Industrial
PRODUCT PROFILE
BARE COPPER EARTH WIRE (BCEW) MULTICORE LV (ARMOURED)
NAME
SANS 1411-1 SANS 1507-3
Computer Input SB (Coils)/TX (Drums) TC (from 7C)
Quotation Description (Size) Bare Copper PVC PVC SWA PVC 600/1000V
For wiring of earthing circuits where Control panels and small industrial
Application
general house wiring is used. machinery requiring signalling.
1.5mm² - 2 to 37 core
Sizes 1.5 - 240mm² 2.5mm² - 2 to 37 core
4.0mm² - 2 to 19 core
Cores N/A 2 - 37C
Conductor Copper Copper
Insulation None PVC
Voltage N/A 600/1000V
1.5 - 6mm² - 5kg and 25kg coils
Packaging 10 - 16mm² - 25kg and 500kg drums 500m drums
25 - 240mm² - 500kg drums
Bedding N/A PVC
Armouring N/A SWA (Steel Wire Armoured)
Sheath N/A PVC
Cut to Size Yes (from 6mm²) Yes (on special request)
SINGLE CORE PVC PVC SINGLE CORE XLPE PVC (AWA)
NAME
SANS 1507-3 SANS 1507-4
Computer Input TS TS
CU XLPE (AWA/Amoured) PVC PVC
Quotation Description CU PVC PVC (Unarmoured) (Voltage)
(Voltage)
Single core distribution cables for distribution
Single core distribution cables armoured/
of higher currents.
unarmoured.
Application Industrial buildings and control panels.
Wiring of industrial buildings and control
Note: For underground use, otherwise
panels.
request UV stabalised.
Sizes 95 - 630mm² 95 - 630mm²
Conductor Copper Copper
Insulation PVC XLPE
Voltage 1.9/3.3kV 1.9/3.3kV
Packaging 300/500m drums 300/500m drums
Armouring Unarmoured AWA (Aluminium Wire Armoured)
Sheath PVC PVC
Cut to Size Yes Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.17
CABLE AND WIRING
Industrial
PRODUCT PROFILE
BELLS and MAINS ECC (EARTH CONTINUITY CONDUCTOR)
NAME SANS 1507-3 PVC Insulated SANS 1507-3 PVC Insulated
SANS 1507-4 XLPE Insulated SANS 1507-4 XLPE Insulated
Computer Input TA (Bells) TB (Mains) TV
(Size) (Core) CU XLPE/PVC ECC SWA PVC
Quotation Description PVC PVC SWA PVC (CU/ALU)
600/1000V
Supply of the main power to the circuits.
Underground installations. An ECC (Earth Continuity Conductor) cable
is a bells or mains cable wherein some of the
steel armour wires are substituted with tinned
Application
copper wires. Used mainly at the coast but
the demand is increasing inland due to the
copper theft of earth wires.
1.5 - 16mm² x 4C (Bells) 1.5 - 70mm² - Brown stripe
Sizes
25.0 - 300mm² x 4C (Mains) 95 - 300mm² - Red stripe
2C, 3C or 4C
Cores 2C, 3C or 4C
(bigger also available)
Conductor Copper/Aluminium Copper/Aluminium
Insulation PVC/XLPE PVC/XLPE
Voltage 600/1000V 600/1000V and higher
Packaging 500m drums 500m drums
Bedding PVC PVC
SWA (Steel Wire Armoured) SWA (Steel Wire Armoured) and tinned
Armouring
Unarmoured available copper wires
Cut to Size Yes Yes
RNF TRAILING CABLE H07
NAME RNF TRAILING CABLE H07 MULTICORE
SINGLE CORE
Computer Input H07 H07
Quotation Description (Size) RNF trailing cable single core (Size) X (Core) RNF trailing cable multicore
Used for wiring where armouring is not
Application Used for wiring of big generator sets.
required (e.g. motors, indoor applications).
Sizes 25 - 300mm² 7, 12 and 19mm²
Cores 1C 3C and 4C
Conductor Copper Copper
Insulation Rubber Rubber
Voltage 750V 750V
Packaging 500m drums 500m drums
Armouring None None
Cut to size Yes Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.18
CABLE AND WIRING
Industrial
PRODUCT PROFILE
PVC NITRILE (Panelling/Welding) NITRILE TRAILING
NAME
SANS 1574-3 SANS 1574
Computer Input SN SU
Quotation Description S/Core CU PVC Nitrile 450/1000V 4C CU PVC Nitrile Trailing Cable 1000V
Distribution boards, motor control centres, LV Power to industrial machinery, e.g. water
Application transformer connections and 100V welding pumps, pool lights and water features.
applications. Mobile and stationary industrial machinery.
Sizes 16 - 185mm² 1.5 - 25mm²
Colours Red, yellow, black or blue Red, yellow, black or blue
Conductor Copper (Class 5) Copper (Class 5 flexibility)
Insulation PVC PVC
600/1000V
Voltage 600/1000V
100V for welding
16 - 70mm² - 100m Coils
Packaging 500 Drums
300/500m Drums (on special request)
Sheath PVC Nitrile PVC/Nitrile orange
Cut to Size Yes Yes
NAME RUBBER/EPM WELDING CABLE
Computer Input SE
Quotation Description (SIZE) Rubber/EPM Welding Cable (Colour)
Application Indoor/outdoor electric welding equipment
Sizes 16 - 120mm²
• 16mm² - Green
• 25mm² - Blue
• 35mm² - Grey
Colours • 50mm² - Red
• 70mm² - Brown
• 95mm² - Yellow
• 120mm² - Black
Conductor Copper
Insulation EPM/CM or EPM/CR
Voltage 100V AC/DC to earth for welding applications
Packaging 100m coils
Cut to Size Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.19
CABLE AND WIRING
Agricultural
PRODUCT PROFILE
NAME SUBMERSIBLE PUMP CABLE SWA/ARMADAC
SANS 1574
Computer Input SU ARM
Quotation Description (Size) (Core) Sub Pump Cable (Size) ARMADAC
Farms, quarries, boreholes, de-watering, Power transfer over long distances e.g. game
Application
cleaning and sewerage extraction plants. lodges and farms.
Sizes 1.5 - 16mm² 10 - 25mm²
3C - Blue
Cores 3C
4C - Green
Conductor Copper (Class 5) Copper (Class 2)
Insulation PVC (flexible grade and waterproof) PVC
Voltage 600/1000V 1.9/3.3kV
Packaging 500m drums 500m drums
Bedding N/A PVC
Armouring N/A SWA (Steel Wire Armoured)
Sheath Water PVC PVC
Cut to Size Yes Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.20
CABLE AND WIRING
Low Voltage
PRODUCT PROFILE
AUDIO/RIP CORD MONSTER CABLE
NAME
SANS 1411-2 SANS 1411-2
Computer Input SI MONSTER
Quotation Description (Size) Ripcord (Colour) (Size) Monster Cable
Intercoms, alarm systems, solar power Audio and audio visual equipment (loud
Application
systems, audio and audio visual equipment. speaker leads) and solar power industry.
Sizes 0.2 - 4.0mm² 1.0, 1.6 and 3.0mm²
White, brown, grey, black, transparent red
Colours Transparent blue stripe
with black stripe
Cores 2C 2C
Conductor Copper (Class 5 Flexibility) Copper (Class 5 Flexibility)
Insulation PVC PVC
Voltage 48V 48V
100m coils 100m coils
Packaging
500m drums on special request 500m drums on special request
Cut to Size - Atlas No No
Cut to Size - Voltex Yes No
ILLUMINATION CABLE HRQ INSULATED CABLE
NAME
SANS 1507 AFAA SANS 1507-2
Computer Input ILLUMINATION SU
Quotation Description 2C Illumination Cable (Colour) HRQ Insulated Cable
Flexible wiring for festive, decorative and High conductivity solid copper conductor.
outdoor lighting productions. Insulated with D5 high temp PVC 105º.
Application
Other applications where quick fit lamp For wiring capacitor tails and ballasts for
holders are used or required. fluorescent lights.
Sizes 2.5mm² 0.5mm²
White, black,yellow, brown, red, orange, tan,
light blue and white with a choice of either
Colours Black or red
yellow, orange, red, black, blue or brown
stripes
Conductor Copper (Class 5) Solid Copper (Class 1)
Insulation PVC PVC D5 high temperature
Voltage 300/500V 300/500V
100m coils
Packaging 700m cardboard lengths
1000m drums on special request
Cut to Size - Atlas No No
Cut to Size - Voltex Yes Yes
Cut to Size Yes Yes
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.21
CABLE AND WIRING
Low Voltage
PRODUCT PROFILE
PAPER INSULATED LEAD COVERED (PILC) CROSS LINKED POLYETHYLENE (XLPE)
NAME
SANS 97 SANS 97
SWA (Steel Wire Armour)
Computer Input XLPE
DSTA (Double Steel Tape Armour)
SWA - 3C CU PILC SWA PVC (V) (Table)
Quotation Description 3C CU XLPE PVC SWA PVC 6.35/11KFR
DTSA - 3C CU PILC DSTA PVC (V) (Table)
PILC are insulated with layers of
(oil impregnated) papers and are
XLPE are always circular and individually
collectively screened up to 11kV and
screened.
individually screened up to 11kV+.
Long distance electricity transmission, industrial
Application Used for long distance electricity
motors, compressors, etc.
transmission, industrial motors,
Supplies power to sub-stations and mine shafts.
compressors, submarine cables, etc.
Supplies power to sub-stations and mine
shafts.
Sizes 25 - 1000mm² 25 - 500mm²
1C (up to 1000mm²) 1C (up to 500mm²)
Cores
3C (up to 400mm²) 3C (up to 300mm²)
Stranded copper or
Conductor Copper/Aluminium
Stranded aluminium
Insulation Paper XLPE
3.8/6.6kV, 3.35/11kV, 8.7/15kV, 12.7/22kV or
Voltage 3.3kV, 6.6kV, 11kV, 22kV or 33kV
19/33kV, 42kV
Electric Field Belted or Screened N/A
Bedding Jute, Hessian, PVC, EVA, MDPE or HDPE PVC
Armouring Aluminium, steel tape or steel wire SWA/DSTA
Max. Operating Temp 70ºC 90ºC
Type A 3C
XLPE insulated, individually copper tape
Table 19 (Screened) screened, PVC bedded, steel wire armoured,
• Rated 6.35/11kV PVC sheath
• Individually screened
• Radial electric field Type A 1C
• Earthed systems XLPE insulated, copper tape screened, PVC
bedded, aluminium wire armoured, PVC sheath
Types Table 18 (Belted)
Type B 3C
• Rated 11/11kV XLPE insulated, individually copper tape
• Collectively screened screened, unarmoured, PVC sheathed
• Non-radial electric
• Un-earthed systems Type B 1C
XLPE insulated, copper single tape screened,
Other tables on request. unarmoured, PVC sheathed.
Special types available on request.
300m drums
Packaging 300m drums on special request
500m drums on special request
Cut to Size - Atlas No - min. 900m Yes
There are many other specialised cables available on request. Please provide specification sheet for quotation purposes.
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.22
GENERAL ELECTRICAL
PRODUCT PROFILE
OUTDOOR
Bells and chimes
DBs and enclosures BEDROOM LOUNGE
Door phones
Switches and sockets Switches and sockets
Daylite switches
Air conditioners Air conditioners
Switches and sockets
Ceiling and wall fans Ceiling and wall fans
Insect killers
Heaters Heaters
Pool timers
Insect killers Insect killers
Pool transformers
Motion sensors Motion sensors
Pool isolators
Occupancy sensors Occupancy sensors
Pumps
Surge protection Surge protection
Gate motors
Electric fencing
Solar sensor security lights
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.23
PRODUCT PROFILE
ENERGY SAVING
AND BACKUP POWER
BATHROOM WATER HEATING SOLUTIONS
KITCHEN Extractor fans Geyser isolators Generators
Switches and sockets Hand dryers Sprague tubing Change-over switches
Pop-up sockets Heaters Solar geysers Motion sensors
Surge protection Switches and sockets Geyser elements Occupancy sensors
Shower heads Inverters/UPSs
Solar lights
Smart metering
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.24
LIGHTING
Domestic
PRODUCT PROFILE
Bedroom
· Mirror lights
· Picture lighting
· Ceiling/wall fittings
· Chandeliers
· Cove ligthing
· LED strips
· Downlights
· Desk lamps
Lounge
· Under-counter lighting
· LED/fluorescent fittings
· Cove lighting
· Starlights
· Downlights
· Chandeliers
· Picture lighting
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.25
LIGHTING
Domestic
PRODUCT PROFILE
Kitchen
· Mirror lights
· Ceiling/wall fittings
· Chandeliers
· Cove lights
· Downlights
· Under-counter lighting
Bathroom
· Mirror lights
· Ceiling/wall fittings
· Chandeliers
· Cove lighting
· LED strips
· Downlights
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.26
LIGHTING
Domestic
PRODUCT PROFILE
Outdoors
· Bollards
· Bulkheads
· Deck lights
· Downlights (IP65)
· Floodlights and spotlights
· Garden spikes
· Poles and tops
· Ropelights
· Solar floodlights
· Wall lanterns/fittings
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.27
LIGHTING
Commercial and Industrial
PRODUCT PROFILE
Offices
· Bulkheads · Prismatic fittings
· Cove lighting · Recessed fittings
· Channels (LBR)
· Dimmers · Spotlights
· Downlights · Sound sensors
· Floodlights · Vapour proof
· Fluorescent fittings fittings
T5/T8 LED · Under-counter
· LED panels lighting
· Luminaires
· Occupancy sensors
Factories
· Floodlights
· Low/High bays
· LED/Fluorescent fittings/Tubes
· High Pressure Sodium (HPS)
lamps
· C-Bays (ideal for food industry)
· S-Bays
· T-Bays
· Industrial bulkheads
· Tamper-proof fittings
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.28
LIGHTING
Commercial and Industrial
PRODUCT PROFILE
Streets and Parks
· Street light fittings
· Solar street lights
· Floodlights
· Solar floodlights
· Tamper-proof fittings
· Masts
· Decorative area lights
· Bollards
Specialised
· Aviation warning beacons
· Food industry luminaires
· Mining and hazardous area
luminaires
· Explosion proof luminaires
· Emergency and exit luminaires
· Ultraviolet lamps
· Infrared lamps
· Sunbeds and sunbed lamps
· Gravel dryers
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.29
LIGHTING
Lamps Discharge Lamps
PRODUCT PROFILE
High-Pressured
A60/GLS Candle
Sodium
GU10 Golf Ball Metal Halide
Mercury Vapour
MR16/GU5.3 Downlight (needs control
gear to operate)
Mercury Blended
R63 PAR38 (no control gear
to operate)
Compact
R50
Fluorescent Lamps
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.30
LIGHTING
PRODUCT PROFILE
Tubes
· T5/T8
· Standard fluorescent/LED
· Length: 2ft/4ft/5ft
· Wattage
Colour Comparison Chart
Basic LED Reference Example
7000K 10000K
10000K +: Blue Sky
9000K
5700K 8000K
7000K
4000K 6000K - 6500K: Cool White LED
6000K
5000K
3500K 4800K: Direct Sunlight
4000K - 4500k: Natural LED
4000K
2800K - 3000K: 100W Light Bulb
3000K 3000K 2700K - 3500K: Warm White LED
2000K
1900K: A burning Candle
2700K 1000K
Lamp Base Types
GU10 MR16 B22/BC E14/SES E27/ES B40/GES
Bayonet Intermediate Medium Large
Screw-in Screw-in Screw-in
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.31
SPECIALISED
PRODUCT PROFILE
Reticulation Support
· Cable trays
· Cable ladders
· Cantilever arms
· Floor and wall reticulation
· Aluminium/PVC/galvanised steel power skirting
· Station master utility poles
· Ultra/Cab-Strut metal framing
· Wire hanger system
· Trunking
· Fasteners and anchors
· Outlets and accessories
Maintenance Chemicals
· Lubricants
· Penetrants
· Corrosion inhibitors
· Cleaners
· Silicone
· PVC glue
· Epoxy compound
· Grease
· Food grade products
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.32
SPECIALISED
PRODUCT PROFILE
Overhead Line Equipment
· ABC/Airdac fittings and accessories
· Aluminium alloy/die-cast fittings
· Clamps
· Cutouts and ABC fuse switches
· Enclosures
· House connections
· Insulators
· Lugs, ferrules and tee connectors
· Mini-subs
· Overhead steel hardware
· Pre-formed wire products
· Surge arresters
· Transformers
· Wooden creosote treated crossarms
Industrial and Mining
· Alarms and sounders
· Crane and lift equipment
· Commercial switches and sockets
· Fire bells
· Fireman switches
· Industrial switches and sockets
· Sirens
· Mine lights
· Gravel dryers
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.33
SPECIALISED
PRODUCT PROFILE
Power Quality Solutions
· PQ metering and protection
· PQ software
· PQSCADA Sapphire
· PQ solutions
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.34
ACCESSORIES AND CONSUMABLES
PRODUCT PROFILE
Tools and Accessories
· Batteries · Ladders
· Bushes · Levels
· Cable marker printers and accessories · Locknuts
· Chalk lines · Measuring tools
· Clamp meters · Multimeters
· Crimping tools · Nail-in anchors
· Copper earth tape · Pipe benders
· Cutters · Pliers
· Cutting discs · Plugs, cords and multiplugs
· Draw wire · Pop rivet tools
LOUNGE
· Drills and drill bits · Pop rivets
· Earth spikes, clamps and couplings · PVC strip connectors/helacons
· Fish tape/wiremate · Screwdrivers and sets
· Flexible tubing · Soldering equipment
· Glue guns and sticks · Spanners
· Grinders · Testers
· Hacksaws and cutters · Thermal cameras
· Hammers · Timers
· Hole saws · Toolbags and boxes
· Insulation tape · Utility knives
· Labelling equipment
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.35
ACCESSORIES AND CONSUMABLES
PRODUCT PROFILE
Lighting and Accessories
· Ballasts
· Caravan lights
· Chokes
· Daylite switches
· Dimmer switches
· Lamp holders
· Light switches
· Emergency exit lights
· Pull switches
· Fluorescent starters
· Foot switches
· Galleries
· Headlights
· Leadlights
· Light transformers
· Ready lights
· Rechargeable lanterns
· Ropelights
· Seasonal lights
· Slab boxes
· Torches
· Watertight fittings
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.36
ACCESSORIES AND CONSUMABLES
PRODUCT PROFILE
Sound and Accessories
· Bells
· Chimes
· Bell push presses
· Door phones
Miscellaneous
· Barrier tape and fencing
· Fans
· Float switches
· Heaters
· Insect killers
· KWH meters
· Safety equipment
· Swimming pool transformers and timers
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.37
CHARTS AND TABLES
Ingress Protection (IP) Rating Guide
PRODUCT PROFILE
IP ? ?
Liquids
Protection against Liquid Bodies
Type Description Rating
Number
Solids
No protection 0
Protection against Solid Bodies
Protected against
Rating vertically falling
Type Description Number water droplets 1
(condensation)
No protection 0 Protected against
water droplets
deflected at up to 2
15º from vertical
Protected against
solid bodies larger than 1
50mm (e.g. a hand)
Protected against
rainwater at up to 3
60º from vertical
Protected against
solid bodies larger
than 12mm 2
(e.g. a finger) Protected against
water spray from 4
all directions
Protected against
solid bodies larger
than 2,5mm 3
(tools, wires) Protected against
low-pressure water 5
jets from all directions
Protected against
solid bodies larger
than 1mm (fine tools,
4 Protected against
small wires) powerful water jets 6
from all directions
Protected against dust
(no harmful deposits) 5 Protected against the
7
effects of immersion
Protected against
prolonged effects
Totally dust tight 6 of immersion
8
under pressure
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.38
CHARTS AND TABLES
Gland and Cable Rating Chart
PRODUCT PROFILE
Cable construction: Plain annealed stranded copper conductors, PVC insulated, PVC bedded, galvanised steel wire
armoured, PVC sheathed (600/1000V). SABS 1507/1000.
Approximate Dimensions and Nett Volt Gland Clamp
Sustained Current Ratings
Mass Per 100m Drop to Suit to Suit
Number of Max. Overall
Rated Area Nett Mass In Air Laid Direct In Ducts Per m/Amp Size Size
Cores Diamter
mm 2
- mm kg amp amp amp mV - -
1.5 2 14.0 39 23 29 28 29 0 E26
3 14.5 44 20 24 20 25 0 E27
4 15.5 49 20 24 20 25 0 E27
2.5 2 15 45 31 37 31 18 0 E27
3 15.5 50 26 32 26 15 0 E28
4 16.5 58 26 32 26 15 0-1 E28
4 2 17 59 41 50 41 11 0-1 E28
3 17.5 66 36 42 34 9.5 1 E28
4 18.5 77 36 42 34 9.5 1 E28
6 2 17.5 67 53 62 51 7.3 1 E28
3 18.5 78 45 53 43 6.4 1 E28
4 20.0 91 45 53 43 6.4 2 E30
10 2 21 89 72 83 68 4.4 2 E30
3 22 102 62 70 58 3.8 2 E30
4 23.5 120 62 70 58 3.8 2 E30
16 2 18.5 93 96 107 88 2.8 2 E30
3 20.5 114 82 91 75 2.4 2 E30
4 23 140 82 91 75 2.4 3 E32
25 2 21.5 120 128 142 116 1.75 2-3 E30
3 24.5 160 109 119 96 1.50 3 E32
4 27.5 200 109 119 96 1.50 3 E32
35 2 23 142 156 171 139 1.25 3 E30
3 27.5 200 133 143 116 1.10 3 E32
4 29.5 247 133 143 116 1.10 3-4 E34
50 3 29.5 250 162 169 138 0.81 4 E34
4 34 338 162 169 138 0.81 4 E34
70 3 33 344 205 210 171 5.57 4 E34
4 39.5 470 205 210 171 0.57 4-5 E35
95 3 38.5 482 252 251 205 0.43 4-5 E36
4 45 612 252 251 205 0.43 5 E36
120 3 42.5 590 291 285 234 0.35 5 E36
4 47 752 291 285 234 0.34 5 E38
150 3 45 705 334 320 263 0.29 5-6 E38
4 53 960 334 320 263 0.29 6 E40
185 3 52 910 383 361 298 0.25 6 E40
4 58 1150 383 361 298 0.25 6 E42
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.39
CHARTS AND TABLES
PRODUCT PROFILE
Useful Facts
• 1HP = 746 Watts • 1” = 25.4mm
• 1kW = 1.341 HP • 1kg = 2.2 lb
• 1 meter = 39.37” • 1lb = 0.4545kg
Earth Wire Table
Earth Wire Kg per 1000m Earth Wire Kg per 1000m
1.5mm2 14.0 35.0mm2 319.5
2.5mm2 23.6 50.0mm2 454.5
4.0mm 2
37.0 70.0mm 2
632.9
6.0mm2 54.9 95.0mm2 840.3
10.0mm 2
94.7 120.0mm 2
1 099.0
16.0mm2 144.7 150.0mm2 1 370.0
25.0mm 2
230.8 185.0mm 2
1 613.0
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.40
CHARTS AND TABLES
PRODUCT PROFILE
3-Phase Formulas
(1) Voltage drop = 1.73 x 1 x R
Where 1 = Line current per phase
R = Resistance of one core only
(2)
kW = kVA x Power Factor
kW = LINE AMPS x LINE VOLTS x 1.73 x POWER FACTOR
1000
kW = HORSE POWER x 746
1000 x EFFICIENCY
(3) kVA = kW
POWER FACTOR
kVA = LINE AMPS x LINE VOLTS x 1.73
1000
kVA = HORSE POWER x 746
1000 x EFFICIENCY x POWER FACTOR
(4) LINE AMPS = kW x 1000
LINE VOLTS x 1.73 x POWER FACTOR
LINE AMPS = kW x 1000
LINE VOLTS x 1.73
LINE AMPS = kW x 1000
LINE VOLTS x 1.73 x POWER FACTOR
x EFFICIENCY
kW = KiloWatt kVA = KiloVolt Amps Power Factor = Cos ø
Disclaimer: Subject to any applicable laws from time to time: (1) All the product images shown in this catalogue are for marketing purposes and may differ from the actual product.
(2) All factual information in this catalogue was correct at the time of going to print and is subject to change without prior notice. Errors and Omissions Excepted. Voltex and its Marketing
Agency do not accept responsibility or liability for any incorrect listing of any merchandise or information. Voltex Terms & Conditions of Sale which can be found at www.voltex.co.za apply.You can also read
