Flair series The best ventilation for your home!
“Our dream is to make you flourish in life by providing you with the most excellent air possible. Day in, day out.”
Flair series
Successor of Excellent series:
• Excellent 180 Flair 225
• Excellent 300 Flair 325/400
• Excellent 400 Flair 450
• New Flair 600
Flair 225 Flair 325/400 Flair 450/600
Flair 225
• The smallest unit in the Flair range:
600 x 400 x 650mm
• Flow range: 225m3/h
• Targeted at small (rental) housing
• Use of new technologies, developed
for the Flair series for best
performances in the market
• Great performance, small size
• Development until 2020
Flair 325/400
• Fully new developed HRV unit.
• Most compact units in its class
• Use of all new technologies to have
the best performance in the market.
• Developed for 325 m3/h to be the
successor of the Excellent 300
• The Flair 400 as a boost version to
fill in the demand in certain markets
Flair 450/600
• Flow range: 450m3/h and 600m3/h.
• Successor of the Excellent 400 with
competitive performances in the top
range.
• The Flair 600 to complete the range
in the top of residential housing.
• Use of all the new technologies
developed for the Flair series.
• Development until 2020 /2021
Flair 325/400 Benefits for home owners
Flair 325/400 In-depth information
USP’s Flair 325 and Flair 400
- Most compact units in its class.
- Available in 4/0 and 2/2 version.
- A very high thermal efficiency according to
EN-13141-7 combined with the lowest
electrical energy consumption in the market
results in the most efficient unit there is.
USP’s Flair 325 and Flair 400
- Even at maximum flow, the noise level is
easily kept below the required level.
- Everything on board for the digital
communication that is the standard today
and tomorrow.
- New Touch display with clear menu
structure, including installation and
maintenance wizards.USP’s Flair 325 and Flair 400
- Most accurate constant flow that is
conceivable, which guarantees 100% balance
in supply and exhaust .
- Supplied with ball siphon for robust
condensate drainage.
- Very easy to maintain due to a minimum
number of service parts which can be
disassembled in minutes.
- Environmentally friendly packaging in one
material and therefore easy to dispose.Design For the new Flair unit we strived to create the most user friendly product and communicate excellence in performance with respect to the Brink legacy. In our opinion we have succeeded creating a product which installers and home owners will be pleased to use and own.
History
1984 2011
Renovent I Renovent
Brink produces first 1999 Excellent
Dutch heat recovery Renovent HR CF Improved
ventilation unit Constant Flow performance
1996 2004 2018
Renovent HR Renovent HR Medium New Flair series
First counter flow heat First unit with display New constant flow
exchanger Best performance
Extensive connectionsContinues improvement
Renovent HR Renovent Excellent Flair
Heat recovery + + ++
Power consumption + ++ ++++
Noise level - + ++
Connection options - + ++
Maintenance time + + +++Compact size
Easy maintenance • Access at front side • All major components replaceable • All wiring with connectors • No pressure tubes • One screwdriver is all you need • Disassembly time:
Flair 325/400 Key innovations
BYPASS PRE HEATER
DUCT CONNECTION DISPLAY
HEAT EXCHANGER
FAN
FILTERHeat exchanger
Holmak TST 35
• Larger surface
• Lower pressure loss (Pa)
• Higher Thermal Efficiency
• Material: PETG or B2 class
• Guiding sleeves (long term
air-tightness)Fans
High efficient EC Fan
Brink specified
Radial fan backward-
curved (Radical)
Spare-part contains
complete fan
Constant-Flow (easy exchangeable)
(Vane-Anemometer)
Ultra precise and fast
flow-measurement100% Bypass
Double soft sealing lip
for 100% air tight fit
Optimal flow
guiding vanes for
equal air-flow over
total heat
exchanger
Robust design
Tool free maintenance free DC motor
maintenancePre-heater
New Aerodynamic design
• Larger surface (cooling
ribs)
• Double safety switch max
temp
• New aerodynamic design
• Guiding vanes for equal
air-flow over heat
exchangerSiphon
Included in each unit
Tool free quick
lock geometry
Double sealing
* The encapsulated ball
prevents the backflow of air
from the drainage system
Air escapeDuct connections
Double soft sealing lip
for 100% air tight fit
Quick lock geometryFull color touch screen Installation and control –TFT Color touch-screen –New clear menu structure –Installation Wizard for quick and proper commissioning –Filter wizard with instructions how to clean and replace filter –Filter / error messages, also via LED –4-way Speed-Switch build in, for temporarily use
Connectivity
Standard PCB Plus PCB
- RJ12 (wired switch) - New: (W)LAN (App control & Brink Home portal)
- eBus (Air Control / Master-Slave / Service-Tool) - Analogue Inputs (0-10V)
- New: Modbus - Digital Inputs (Potential-free contacts)
- New: USB-slot for RF - Input temperature sensor (Pre heater)
- New: 24VDC Output for external accessories
- New: 24VDC Switched output (Failure-filter
messages)New packaging – 99% cardboard – Easy to unpack – Special covers to protect the connections during construction
Modern communications
The Flair 325 will feature everything that you need for
state-of-the-art communication so it can be linked to
the outside world in various ways.
- Brink Home. Online control through App or web
portal.
- Modbus. Ensures an easy link with building
management systems.
- Extensive control options, RF functionality.Accessories - Wired 4-way switch with filter indication - Digital remote control (Air Control) - Existing RF switch - eBus CO2 Sensor - RH sensor - Demand-control ventilation (2-zones) - ISO PM1 filter (former F7) - Option PCB (Plus) - Enthalpy heat exchanger (also as unit version) - Mounting chair - Post- and pre-heater - Active carbon filter (2019)
Technical specifications Flair 325 Dimensions (HxWxD): 650 x 750 x 560 mm Versions: 4/0 and 2/2, both Left and Right Duct connections: 160 mm Ventilation capacity: 50 - 325 m3/h Constant-Flow: Yes, Vane-Anemometer (very high accuracy) Frost protection: Intelligent frost protection with build-in pre-heater Nominal resistance: 150 Pa Heat Recovery - EN13141-7: 91 % (Exc. was 84,9% ) SPI (W/m3/h) - EN13141-7: 0,15 (Exc. was 0,21) Heat Recovery - PHI: 91 % (Exc. was 84%) SPI (W/m3/h) – PHI: 0,21 (Exc. was 0,26)
Technical specifications Flair 400 Dimensions (HxWxD): 650 x 750 x 560 mm Versions: 4/0 and 2/2, both Left and Right Duct connections: 180 mm Ventilation capacity: 50 - 400 m3/h Constant-Flow: Yes, Vane-Anemometer (very high accuracy) Frost protection: Intelligent frost protection with build-in pre-heater Nominal resistance: 150 Pa Heat Recovery - EN13141-7: 89-90% (Exc. was 85,2% ) SPI (W/m3/h) - EN13141-7: 0,18 (Exc. was 0,22) Heat Recovery - PHI: 89% (Exc. was 84%) SPI (W/m3/h) – PHI: 0,20 (Exc. was 0,29)
Certifications
Flair 325/400 Brink service & support
Service
Personal support
for all advanced
questions
Research & Development Knowledge centre
Elaborate testing facilities and Advanced knowledge about
continues development on new domestic climate control and
and existing products ventilation legislations
Quality control
Ensuring a high level of quality
and working on continues
improvement of our processesThank you!
