THE ONLY
PRACTICAL
SOLUTION
Aluminium Decking
Introducing The Worlds First, Fully Compliant Aluminium, Patented, Domestic
& Commercial, Complete, Decking System, Fire Rated to A2-s1,d0 & A2fl-s1.
USES INCLUDE:
Balconies • Walkways
Bridges • Steps
Commercial dining areas
Temporary platforms
1
Tel: 01622 235 672 www.alideck.co.uk
ALIDECK STANDARD INTERLOCKING
BOARD WITH SUPA JOIST AND
ADJUSTABLE PEDESTALS
An introduction to the
ALIDECK SYSTEM 2
Introducing the world’s first, Original, Patent Contents Page
Pending, Slip Resistant, Non Combustible,
Why AliDeck? 3
Aluminium, A-Rated, decking system from AliDeck. Fire Performance 4
The Timber Replacement Solution 5
This diverse, complete decking system has 3 types The Concrete Balcony Solution 6
of deck boards, 3 different support systems and The Senior Balcony Board 7-8
3 very different fixing system for every type of The Junior Balcony Board 9-10
bespoke installation requirement. It has been The Senior Balcony Flat Board 11
specifically designed with installation efficiency, The Junior Balcony Flat Board 12
The Lite Balcony Board 13-14
aesthetics durability and longevity in mind.
The Interlocking Board 15
Class B Slip Resistant Board 16
ALIDECK IS IDEAL FOR HIGH
Balcony Drainage System
The Supa Joist
17-18
19
RISE DEVELOPMENTS, STEEL
The Low Joist
The Lite Joist
20
21
OR CONCRETE BALCONIES OR Triple Bolt Channel 22
The Adjustable Pedestal 23
RETROFIT TIMBER REPLACEMENTS. Low Profile Adjustable Brackets 24
The Nosing Profile 25-26
What We Do 27-28
Maintenance & Installation 29
The Environment 30
Tel: 01622 235 672 www.alideck.co.uk
Why ALIDECK?
AliDeck is a UK company that is part of the Milwood Group. We are extrusion specialists and have
been in the industry for over 25 years. We launched our first patented aluminium decking system 5
years ago and have since added more designs to the range due to popular demand.
We are well equipped to supply your large volume projects and keep over 150 unique dies and
profiles in stock, ready as extruded, coated and ready to ship. This includes our full range of decking
boards, deck platforms, aluminium planters, stair profiles and subframe systems.
Service is paramount to us, we go and London distribution is located
much further than just being a product in Rochester, Kent and our main
supplier, we continually improve our distribution warehouse is based in
systems and products to make sure Leicestershire in the centre of England
we offer the best service and decking for prompt delivery timescales.
systems available in the UK. Our
customer focussed ethos is what drives We offer you a wide range of services
us to be the very best to ensure you with our products, they include;
come back to us time and time again. installation training for our customers,
in-house CAD team to help ensure we
We have offices and warehouses across are offering the best possible solution to
the UK in Essex, Kent and Leicestershire your project, custom extrusion options
3 and employ over 50 staff, many of to most of our decking products to help
which have been with the group for reduce waste, and, designated estimation
over 10 years. The AliDeck Head Office and call off service.
Why Use the AliDeck Range of Products?
The benefits of Aluminium speak for
themselves, these engineered, stable
solutions have been specifically
designed for balconies, platforms,
walkways and terraces of all kinds.
By choosing the AliDeck range of
products you will be able to install
decking platforms that last and in
record time… Our senior range of
products can span as much as 1200mm
on a 4kN loading, this gives you 3
times the span of traditional timber or
composite offerings.
We believe the key to our success is
listening to our customers and work in
partnership with industry professionals
from a varied and diverse backgrounds to
ask them what works for them, we have
worked with the UK’s most prolific balcony
fabrication companies, builders, developers Our Systems have the best possible coating solutions and come with
and main contractors to develop the
most diverse range of solutions for every
a 30 year adhesion warranty and a 60 year design life for complete
potential required solution. peace of mind (see the qualicoat specification on page 4)
Tel: 01622 235 672 www.alideck.co.uk
FIRE PERFORMANCE
In December 2018 the UK government introduced new legislation in England and Wales to ban the use
of combustible materials including cladding and balcony components on new builds over 18 metres
high, the housing commission are also recommending the removal of ALL combustible materials from
the external façades of buildings. Balconies are, for the first time, counted as part of the external wall;
classified as a “specified attachment”.
The AliDeck System has been independently tested to EN 13823, EN 13501 and EN ISO 1716
and achieves A2-s1, d0 and A2fl-s1 which makes AliDeck
products fully compliant, and can be used as a flooring,
cladding and soffit system if required. STANDARD COLOURS
TEXTURED TEXTURED
SILVER GREY SAND
AliDeck uses Qualicoat
The AliDeck system uses a powdercoat QUALICOAT 2.2: Gloss level check to QUALICOAT 2.14: Polymerisation test 4
process called QUALICOAT: Qualicoat is within 5% +/- of the manufacturer’s (Wipe with MEK for 30 seconds)
a quality label organisation committed to stated level. [EN ISO 2813] QUALICOAT 2.16: Resistance to boiling
maintaining and promoting the quality of water in a pressure cooker. Duration 1
coating on aluminium and its alloys for QUALICOAT 2.4.1: Cross Hatch cuts are hour 100Kpa
architectural applications. made at 2mm spacing with one being at
90° to the other cut, tape is then applied, QUALICOAT 2.18: Sawing and drilling
BS 6496:1984: Specification for powder left for 2 minutes and removed to check to ensure that there is no flaking after
organic coatings for application and for adhesion of paint. [EN ISO 2409 2013] cutting (using sharp tools)
stoving to aluminium alloy extrusions,
sheet and preformed sections for QUALICOAT 2.3: Thickness checks to see Curing Oven temperatures are checked
external architectural purposes, and for that the material is coated with at least and recorded on a daily basis External
the finish on aluminium alloy extrusions. 60 microns of powder, average. [EN ISO checks carried out by the powder
2360] suppliers and our Laboratory in Belgium
AliDeck extrusions are finished using the on random samples of extrusion:
following EN standards: QUALICOAT 2.6: Cupping test is carried
out to check for adhesion with the ISO9227: Acetic Acid Salt Spray Test
EN 12206-1:2004: Paints and varnishes. substrate [EN ISO 1520]
Coating of aluminium and aluminium EN ISO 3231: Resistance to humid
alloys for architectural purposes. Coatings QUALICOAT 2.8: Impact test with an atmospheres containing Sulphur Dioxide
prepared from coating powder energy of 2.5Nm to ensure that the
coating adheres to the substrate [EN ISO EN ISO 11341: Accelerated weathering test
EN ISO 2409:2013: Paints and Varnishes, 6272 / ASTM D2794]
Cross Cut Test. EN ISO 2810: Natural weathering test (Florida
QUALICOAT 2.7: Bend test on a 5mm Test). (Carried out on Powder type)
Our quality department also perform the Mandrel to ensure adhesion after bending
following tests on our powder coated [EN ISO 1519] EN ISO 12206-1: Resistance to mortar
profiles. (Carried out on Powder type)
QUALICOAT 2.11: Machu test (Accelerated
QUALICOAT 2.1: Visual inspection at corrosion test) in a solution made up EN ISO 6270-2: Constant Climate
3 metres for internal and 5 metres for of Sodium Chloride, Acetic Acid and Condensation Water test
external extrusions (Our Inspectors Hydrogen Peroxide at 37°C. Duration 48
visually inspect at 1 metre as standard) hours Our aluminium is sent through a variety
of pre-treatment chemical baths that
remove a very fine layer off the surface
before powder coating.
Tel: 01622 235 672 www.alideck.co.uk
THE TIMBER
REPLACEMENT
SOLUTION
The AliDeck range of systems have been designed alongside some of the UK’s most prolific balcony
fabrication companies to ensure we have a solution that is perfect for your requirements, when
considering timber replacements it is important that you have a diverse range of options that can
be worked on site to create the perfect solution, whatever the existing timber make up. Call our
technical team today who will advise you on the best support system to meet your span criteria,
finish or budget today.
EXISTING TIMBER
5 JOISTS
NEW ALIDECK
30MM DECKING
EXISTING TIMBER
DECKING
EXISTING
STEELWORK
NEW ALIDECK
LOW JOIST
Tel: 01622 235 672 www.alideck.co.uk
THE CONCRETE
BALCONY &
TERRACE SOLUTION
When deciding on the best options to choose for concrete balconies or terrace areas it is
important to have a range of solutions to deal with differing height build ups, we have developed
systems that can be installed on to waterproof membranes that are either level or laid to fall, we
have systems that can cope with fragile point loads, multi-directional falls or even extremely low
build up heights, and what’s more all of our systems are compliant to A2-s1, d0 and A2fl-s1 for
complete peace of mind.
EXISTING CONCRETE
BALCONY STRUCTURE
6
ALIDECK
WATERPROOFING
NEW ALIDECK
LOW JOIST
LOW PROFILE BRACKETS
CAN BE USED WITH
ADHESIVE TAPE
Tel: 01622 235 672 www.alideck.co.uk
A2-s1, d0
PRODUCT SPECIFICATION A2fl-s1
FIRE
• Fire Rated: A2-s1, d0 & A2fl-s1 RATED
• Dimensions: 120mm x 30mm
• Compliance: Commercial Tread Specification
• Material: 6063 T6 aluminium 30% minimum recycled
• Colours: Textured Silver Grey / Textured Sand
• Stock Extrusion Length: 4m & 6m
• Span: 1m
• Slip Resistance Tested – Exceeds minimum wet
and dry
STAINLESS STEEL
MACHINE SCREWS
TOP FIX IN
COVER
END COVER
PLATE
7
DESIGNED TO SPAN
1200mm CENTRE TO CENTRE FIRE RESISTANT BALCONY SOLUTION
Tel: 01622 235 672 www.alideck.co.uk
ALSO
The AliDeck AVAILABLE IN
FLAT DESIGN
SENIOR
(SEE PAGE 11)
BALCONY BOARD
Benefits include: The AliDeck Balcony board is an engineered solution specifically
for balcony installations, it is 120mm wide and 30mm deep it has
the following features:
ALL ALUMINIUM • The ability to cut it to the correct width
• It is fire resistant to A2-s1, d0 and A2fl-s1
• You can install 90% of the deck board prior to the installation of the balcony
if required, once the balcony is installed you can then install the remaining boards
HEAT RESISTANT
• The ability to be installed on to existing sub frame sections without having to
drill additional holes
• Drainage between the boards
DURABLE 8
TEXTURED FINISH
We have designed this board to • The ability to install onto your
have the ability to cut the board down existing sub frame section without
the length and still be structurally having to drill additional holes.
LOW stable under point load, we have also We have designed a 3 way extrusion,
MAINTENANCE increased the radius on the underside 2 up 1 down, this gives you the option
of the board to stiffen the board in the to make sure a bolt can pass through
right place to cope with a point load. the box section on the existing
balcony at any point along the box
Fire resistance, these deck boards are section and then be secured, we then
RECYCLABLE manufactured from structural grade decide on the channels to slide the
T6 (6063) aluminium, and combined bolts into depending on the position
with a special textured slip resistant of the decking in relation to the
coating they achieve a fire rating of position of the box section, you
STABLE IN ALL
A2-s1, d0 & A2fl-s1 and have been need only choose one bolt channel
WEATHER CONDITIONS
independently tested to EN 13501, EN but having 2 gives the option to never
13823 and EN ISO 1716. have to drill the decking.
• Installing 90% of the deck boards • Drainage between the boards.
prior to the installation of the balcony You have the ability to choose the
A2-s1, d0 & A2fl-s1
means you would spend less time on space between the boards, depending
FIRE RATED
site if you are installing balconies. on how quickly you want the water
The board is designed to be installed to run off you can choose between
from the top, with a “Slotted” 4mm to 10mm between boards (We
machined centre section, this is recommend 6mm as standard).
designed to enable us to pick up on
Dimensions at least one of the bolt channels in
the 3 way bolt channel to alleviate the
The board has a cover strip on the
top of the board which has a positive
need for on-site drilling, you can then click into both sides of the board, it’s
120mm drop the deck board into place once a long leg so that any point load and
the balcony is installed using the bolt downward loading is adequate, this is a
channels and the threads facing up quick fit option that removes most of the
30mm and simply apply the nuts and problems associated with other composite
tighten up. decking products when installed.
.
Tel: 01622 235 672 www.alideck.co.uk
ALSO
The AliDeck AVAILABLE IN
FLAT DESIGN
JUNIOR
(SEE PAGE 12)
BALCONY BOARD
Benefits include: The AliDeck Junior Balcony board is an engineered solution
specifically for balcony installations, it is 120mm wide and
20mm deep it has the following features:
ALL ALUMINIUM
• The ability to cut it to the correct width
• It is fire resistant to A2-s1, d0 and A2fl-s1
• You can install 90% of the deck board prior to the installation of the balcony
if required, once the balcony is installed you can then install the remaining boards
HEAT RESISTANT
• The ability to be installed on to existing sub frame sections without having to
drill additional holes
• Drainage between the boards
9 DURABLE
TEXTURED FINISH
We have designed this board to • The ability to install onto your
have the ability to cut the board down existing sub frame section without
the length and still be structurally having to drill additional holes.
LOW stable under point load, we have also We have designed a 3 way extrusion,
MAINTENANCE increased the radius on the underside 2 up 1 down, this gives you the option
of the board to stiffen the board in the to make sure a bolt can pass through
right place to cope with a point load. the box section on the existing
balcony at any point along the box
Fire resistance, these deck boards are section and then be secured, we then
RECYCLABLE
manufactured from structural grade decide on the channels to slide the
T6 (6063) aluminium, and combined bolts into depending on the position
with a special textured slip resistant of the decking in relation to the
coating they achieve a fire rating of position of the box section, you
STABLE IN ALL A2-s1, d0 & A2fl-s1 and have been need only choose one bolt channel
WEATHER CONDITIONS independently tested to EN 13501, EN but having 2 gives the option to never
13823 and EN ISO 1716. have to drill the decking.
• Installing 90% of the deck boards • Drainage between the boards.
A2-s1, d0 & A2fl-s1 prior to the installation of the balcony You have the ability to choose the
FIRE RATED means you would spend less time on space between the boards, depending
site if you are installing balconies. on how quickly you want the water
The board is designed to be installed to run off you can choose between
from the top, with a “Slotted” 4mm to 10mm between boards (We
machined centre section, this is recommend 6mm as standard).
designed to enable us to pick up on
Dimensions at least one of the bolt channels in
the 3 way bolt channel to alleviate the
The board has a cover strip on the
top of the board which has a positive
need for on-site drilling, you can then click into both sides of the board, it’s
120mm drop the deck board into place once a long leg so that any point load and
the balcony is installed using the bolt downward loading is adequate, this is a
20mm channels and the threads facing up quick fit option that removes most of the
and simply apply the nuts and problems associated with other composite
tighten up. decking products when installed.
.
Tel: 01622 235 672 www.alideck.co.ukA2-s1, d0
A2fl-s1
PRODUCT SPECIFICATION
FIRE
• Fire Rated: A2-s1, d0 & A2fl-s1 RATED
• Dimensions: 120mm x 20mm
• Compliance: Commercial Tread Specification
• Material: 6063 T6 aluminium 30% minimum recycled
• Colours: Textured Silver Grey / Textured Sand
• Stock Extrusion Length: 4m & 6m
• Span: 500mm
• Slip Resistance Tested – Exceeds minimum
wet and dry
STAINLESS STEEL
MACHINE SCREWS
TOP FIX IN
COVER
END COVER
PLATE
DESIGNED TO SPAN
600mm CENTRE TO CENTRE
10
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
SENIOR BALCONY
FLAT BOARD
Benefits include: The Senior Flat board has been designed with aesthetics
in mind, this stylish balcony board complies with the HSE’s
stringent requirements for slip resistance and yet blends
seamlessly with the surroundings.
ALL ALUMINIUM
TOP FIX IN
A2-s1, d0 COVER
A2fl-s1
HEAT RESISTANT FIRE
RATED
11 DURABLE
TEXTURED FINISH
END COVER
PLATE
LOW
MAINTENANCE
RECYCLABLE
STAINLESS STEEL
MACHINE SCREWS
STABLE IN ALL
WEATHER CONDITIONS
PRODUCT SPECIFICATION
A2-s1, d0 & A2fl-s1 • Fire Rated: A2-s1, d0 & A2fl-s1
FIRE RATED • Dimensions: 120mm x 30mm
• Compliance: Commercial Tread Specification
• Material: 6063 T6 aluminium 30% minimum recycled
• Colours: Textured Silver Grey / Textured Sand
• Stock Extrusion Length: 4m & 6m
Dimensions •
•
Span: 1m
Slip Resistance Tested – Exceeds minimum wet
and dry
120mm
30mm DESIGNED TO SPAN
1200mm CENTRE TO CENTRE
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
JUNIOR BALCONY
FLAT BOARD
Benefits include: The Junior Flat board has been designed with aesthetics in mind,
this stylish balcony board complies with the HSE’s stringent
requirements for slip resistance and yet blends seamlessly with
the surroundings.
ALL ALUMINIUM
TOP FIX IN
COVER
A2-s1, d0
A2fl-s1
HEAT RESISTANT FIRE
RATED
DURABLE 12
TEXTURED FINISH
END COVER
PLATE
LOW
MAINTENANCE
RECYCLABLE
STAINLESS STEEL
MACHINE SCREWS
STABLE IN ALL
WEATHER CONDITIONS
PRODUCT SPECIFICATION
A2-s1, d0 & A2fl-s1 • Fire Rated: A2-s1, d0 & A2fl-s1
FIRE RATED • Dimensions: 120mm x 20mm
• Compliance: Commercial Tread Specification
• Material: 6063 T6 aluminium 30% minimum recycled
• Colours: Textured Silver Grey / Textured Sand
• Stock Extrusion Length: 4m & 6m
Dimensions •
•
Span: 600mm
Slip Resistance Tested – Exceeds minimum wet
and dry
120mm
20mm DESIGNED TO SPAN
600mm CENTRE TO CENTRE
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
LITE BOARD
Benefits include: The AliDeck Lite board has been specifically designed to be an
entry level system that is perfect for the retrofit or replacement
market, this product will span 400mm between supports on
a 4kN distributed load, it can be used with all of our support
ALL ALUMINIUM
systems and gutter systems if required. We have designed this
system to be fast and efficient to install and has a unique clip
down solution to make it easy and quick to install.
HEAT RESISTANT
A2-s1, d0
A2fl-s1
DURABLE FIRE
TEXTURED FINISH RATED
13 LOW
MAINTENANCE
FIXING CLIP
RECYCLABLE
TEXTURED
SURFACE
STABLE IN ALL
WEATHER CONDITIONS
A2-s1, d0 & A2fl-s1
FIRE RATED
PRODUCT SPECIFICATION
• Fire Rated: A2-s1, d0 & A2fl-s1
• Dimensions 120mm x 20mm
Dimensions •
•
Material: 6063 T6 aluminium 30% minimum recycled
Colours: Textured Silver Grey / Textured Sand (other
available on request)
120mm • Stock Extrusion lengths 4m and 6m
• Span 400mm
20mm • Slip Resistance Tested – Exceeds minimum wet
and dry
DESIGNED TO SPAN
400mm CENTRE TO CENTRE
Tel: 01622 235 672 www.alideck.co.uk14
CITYSCAPE BALCONY USING ALIDECK
LITE BOARD IN TEXTURED SILVER / GREY
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
INTERLOCKING
BOARD
INTERLOCKING
BOARDS
The AliDeck interlocking board is a quick fit solution that
locks together to give you a strong, non-combustible
deck platform without drainage. It is made from 100% aluminium, 30% from recycled sources so
it’s extremely environmentally friendly. The aluminium construction makes this a fully fire resistant
decking solution. Our boards that are treated with a durable powder coating and are fire rated to
A2-s1, d0 these boards also have no contribution to fire. The AliDeck interlocking decking is supplied
with a 30 year warranty and a 60 year life expectancy for complete peace of mind.
TEXTURED
PRODUCT SPECIFICATION FINISH
• Fire Rated: A2-s1, d0 & A2fl-s1
15 • Dimensions: 120mm x 30mm
• Compliance: Commercial Tread Specification
• Material: 6063 T6 aluminium 30% minimum recycled
• Colours: Textured Silver Grey / Textured Sand
• Stock Extrusion Length: 6m A2-s1, d0
• Span: 1.2m A2fl-s1
• Slip Resistance Tested – Exceeds minimum FIRE
wet and dry RATED
Benefits include:
STAINLESS STEEL
MACHINE SCREWS
END COVER
ALL ALUMINIUM RECYCLABLE PLATE
HEAT RESISTANT
STABLE IN ALL
Dimensions
WEATHER CONDITIONS
120mm
NO GAPS 30mm
DURABLE
TEXTURED FINISH BETWEEN BOARDS
LOW A2-s1, d0 & A2fl-s1
MAINTENANCE FIRE RATED DESIGNED TO SPAN
1200mm CENTRE TO CENTRE
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck Class B
SLIP RESISTANT BOARD
This revolutionary Slip Resistant Deck board has been designed to provide a safe and durable solution
to both commercial and domestic applications. Traditionally this market is flooded with both
composite and timber offerings, both of which have been known to cause accidents and injuries
mainly due to lack of maintenance. The Slip Resistant Deck board has been designed to be installed in
conjunction with the AliDeck Supa Joist (see page 19) which makes the system far quicker to install
and promotes even greater longevity.
This is the only Aluminium Slip Resistant system on the market. solutions, it’s perfect for dining areas in both commercial and
AliDeck does not need an expansion gap between boards due domestic applications, there is no possibility of food or debris
to the fact that aluminium is far more stable than other decking getting between the boards, which can attract unwanted vermin.
FIRE SLIP RESISTANT
INSERTS
RATED
CLASS B
16
END COVER
PLATE
Benefits include:
STAINLESS STEEL
SLIP RESISTANT RECYCLABLE MACHINE SCREWS
ALL ALUMINIUM
STABLE IN ALL
WEATHER CONDITIONS
Dimensions
120mm
NO GAPS 30mm
HEAT RESISTANT BETWEEN BOARDS
Please note that the Slip Resistant
DURABLE CLASS B board is not suitable for high rise
TEXTURED FINISH FIRE RATED buildings over 18 metres.
LOW DESIGNED TO SPAN
MAINTENANCE
1200mm CENTRE TO CENTRE
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
BALCONY
DRAINAGE SYSTEM
Benefits include: This practical and yet simple drainage solution fits between
and towards the edge of the boards to minimise the potential
for rain water, hot fluids or unwanted debris from falling
ALL ALUMINIUM
between the boards.
A2-s1, d0
A2fl-s1
HEAT RESISTANT
FIRE
RATED
17
DURABLE
TEXTURED FINISH
LOW
MAINTENANCE
RECYCLABLE
STABLE IN ALL
WEATHER CONDITIONS
A2-s1, d0 & A2fl-s1
Dimensions
FIRE RATED
32mm
32mm
28mm 18mm
Tel: 01622 235 672 www.alideck.co.ukBALCONY BOARD
18
DRAINAGE
CHANNEL
DRAINAGE
GUTTERING
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck SUPA JOIST
The AliDeck Supa-Joist is an integral part of the AliDeck System! This clever extrusion is designed
to act as both a support post and big span joist. The connection plates allow for super fast
installation and can be adjusted to suit most applications and conditions. It has also been designed to
be connected together to give additional strength for applications where larger spans are required.
All of our spanning criteria has been based
on the standards of EN 1991-1-1-1:2002
“Actions on Structures”.
Supa Joist span capabilities:
The Supa Joist can span a maximum of 3
metres between pedestals on a 4kN Loading.
19
Benefits include: Dimensions
80mm
INCREASED SPAN CAPABILITIES
LOW
AGAINST TIMBER OR COMPOSITE
MAINTENANCE
OPTIONS BY OVER 300%
105mm
ALL ALUMINIUM RECYCLABLE
QUICK AND EASY STABLE IN ALL
TO INSTALL WEATHER CONDITIONS
COLOUR MATCHED
TO THE DECK BOARDS
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck LOW JOIST
The AliDeck Low Joist is an integral part of the AliDeck System! This extrusion is designed to act a
support and a joist for the junior and big span balcony board specifically on concrete balconies and
terrace areas that require adjustable heights. This joist in designed to work in conjunction with the
AliDeck adjustable pedestal and the rest of the AliDeck deck board range.
All of our spanning criteria has been based
on the standards of EN 1991-1-1-1:2002
“Actions on Structures”.
Low Joist span capabilities:
The Low Joist can span a maximum of 1200
mm between pedestals on a 4kN loading.
20
ADJUSTABLE
LOW JOIST
BRACKETS
Benefits include: Dimensions
80mm
INCREASED SPAN CAPABILITIES
LOW
AGAINST TIMBER OR COMPOSITE
MAINTENANCE
OPTIONS BY OVER 300%
50mm
ALL ALUMINIUM RECYCLABLE
QUICK AND EASY STABLE IN ALL
TO INSTALL WEATHER CONDITIONS
COLOUR MATCHED
TO THE DECK BOARDS
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck LITE JOIST
The AliDeck Lite Joist is an integral part of the AliDeck system! This extrusion has been designed for
installations where you have a very low threshold situation, if you require a minimum build up height
of 50mm or above this is the perfect solution (when used with our 20mm range of boards) This joist
can be used with either our adjustable pedestal brackets or our multi-directional adjustable pedestals
for complete height adjustment.
All of our spanning criteria has been based
on the standards of EN 1991-1-1-1:2002
“Actions on Structures”.
Lite Joist span capabilities:
The Lite Joist can span a maximum of 800mm
between pedestals on a 4kN loading.
21
Benefits include:
INCREASED SPAN CAPABILITIES
LOW
AGAINST TIMBER OR COMPOSITE
MAINTENANCE
OPTIONS BY OVER 300%
Dimensions
ALL ALUMINIUM RECYCLABLE
80mm
30mm
QUICK AND EASY STABLE IN ALL
TO INSTALL WEATHER CONDITIONS
COLOUR MATCHED
TO THE DECK BOARDS
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
TRIPLE BOLT
CHANNEL
Benefits include: The Triple Bolt channel has been designed to be used in
conjunction with our Balcony or Junior Balcony deck boards
to give you the ability to install deck platforms in record time,
without the need for drilling the steel balcony every time you
ALL ALUMINIUM
install a deck board. Meaning super fast installation time.
M8
STAINLESS
HEAT RESISTANT CHANNEL STEEL BOLTS
DURABLE 22
TEXTURED FINISH
LOW
MAINTENANCE
6063 T6 STRUCTURAL
GRADE ALUMINIUM
RECYCLABLE
FIRE RATED
A2-s1, d0 &
STABLE IN ALL A2fl-s1 WHEN
WEATHER CONDITIONS COATED
Dimensions
A2-s1, d0 & A2fl-s1 50mm
FIRE RATED
10mm
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck The AliDeck adjustable pedestal is a
solution driven product, specifically
ADJUSTABLE
designed for installations where it is
key that non-combustible products
are installed, this A1 fire rated
product is manufactured from 3
PEDESTAL
aluminium extrusions, which makes
it cost effective and quick to install.
It works seamlessly with all of the
products in our range and gives you
the adjustment that is required.
EASY FIX SUPPORT HEAD
FIRE
RATED
CLASS A1
REMOVEABLE ADJUSTER TOOL
23 THREAD HEIGHT ADJUSTER
EASY FIX BASE SUPPORT
Dimensions Additional Bespoke Sizes
Available On Request 80mm
10.8mm 50mm
120mm
JOIST
235mm
165mm
120mm
90mm
70mm
235 TO 300mm 165 TO 235mm 120 TO 165mm 90 TO 120mm 70 TO 90mm
From floor to underside of joist From floor to underside of joist From floor to underside of joist From floor to underside of joist From floor to underside of joist
Code: ADP 235-300 Code: ADP 165-235 Code: ADP 120-165 Code: ADP 90-120 Code: ADP 70-90
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
LOW PROFILE BRACKETS CAN
BE USED WITH
ADHESIVE TAPE
ADJUSTABLE
BRACKETS
Benefits include: Our adjustable brackets work in conjunction with all 3 joists,
available in 3 distinct sizes and can be manufactured to suit
any specific build up height. (minimum order required) they
are adjusted to allow insulation to fall underneath and will
ALL ALUMINIUM
allow water to pass underneath the joist system, you also
have the option to choose a self-adhesive
fire resistant fixing pad which has 24
HEAT RESISTANT
been tested for compatibility
with most waterproofing
membranes and
finishes.
DURABLE
TEXTURED FINISH
LOW
MAINTENANCE
RECYCLABLE
Dimensions
180mm
FIRE
RATED
STABLE IN ALL
CLASS A1
WEATHER CONDITIONS 65mm
180mm
A1 FIRE RATED 180mm
80mm 95mm
Tel: 01622 235 672 www.alideck.co.ukThe AliDeck
NOSING PROFILE
Benefits include: The AliDeck Nosing Extrusion has been designed to work in
conjunction with all other Ali-Deck extrusions. When used
with two of our deck boards it is commercially compliant for
ALL ALUMINIUM tread specification. (280mm)
TEXTURED
SURFACE
HEAT RESISTANT
FITS TO THE
SUPA JOIST AND
BALCONY BOARD
DURABLE
TEXTURED FINISH
LOW
25 MAINTENANCE
RECYCLABLE
STABLE IN ALL
WEATHER CONDITIONS
CURVED NOSING
Dimensions 40mm
The Nosing Profiles are modular and
work with the AliDeck Standard
Board, Slip Resistant Board, Balcony
Board, Junior Balcony Board and
Supa & Low Joists.
80mm
Tel: 01622 235 672 www.alideck.co.ukThis commercially compliant nosing solution is available, in 6m lengths and available in the same
standard colours as the rest of the range (textured silver grey and textured sand) It is perfect for the
retrofit timber replacement markets where timber had deteriorated to the point of replacement, due
to it being a structural grade aluminium is naturally comes to you with a 60 year design life.
This extrusion can be used with all of our 30mm boards and includes the senior, the standard, the flat
board and the interlocking board, and if you are happy with a class B fire rated products it works with
our slip resistant board too.
DECK BOARD
NOSING
26
ANGLE BRACKETS
SUPA JOIST
Tel: 01622 235 672 www.alideck.co.ukWHAT WE DO
Customer service is at the heart of what we do, we focus
on your needs, when dealing with AliDeck you can be
assured of an in-house technical knowledge base that
is second to none, we train each and every employee
to understand all capabilities, span criteria and product
details to ensure we direct you to the most efficient
solution for your project.
27
This customer-focused expertise, teamed with an estimation department that is happy to call off the
particular requirements and a CAD design department that uses the latest version of Solidworks 3D
Design to visualise specific elements of your project gives you a service that works! We also have a
dedicated team of research and development engineers who will trial new products in order to ensure
they work seamlessly for you.
If you are interested in receiving an AliDeck
sample box please contact us on 01622 235 672
or email: info@alideck.co.uk
Tel: 01622 235 672 www.alideck.co.uk28 Tel: 01622 235 672 www.alideck.co.uk
MAINTENANCE
AliDeck aluminium decking requires
minimal maintenance due to the
natural rust resistance that aluminium
features along with the high durability
of our special Qualicoat applied
powder coating. Download our
maintenance schedule for instructions
for maintaining the aluminium decking
boards to uphold the warranty and
the expected lifespan of the decking.
(available from our website -
www.alideck.co.uk)
29
INSTALLATION
TRAINING
The AliDeck training academy was introduced so that our clients
can attend a single day training session and walk away feeling
educated and confident installing our aluminium decking systems
themselves. Each attendee will receive a certificate to confirm
their attendance and completion of the training.
If you would like to attend one of our The training academy is very popular
training sessions either for yourself and can become fully booked quickly
or with your staff, please contact us. so please contact us with the dates
We can train up to 6 persons at a time you have in mind and we will let you
to ensure we thoroughly train each know what’s available. We advise you
individual, making the training more to book a training session before your
personal and intensive. This high-level order arrives so you can feel confident
installation training will help you installing the aluminium decking, saving
and your staff become experts in our you time and money on site as you will
products, enabling you to install them have experience with the system.
with ease and confidence.
Tel: 01622 235 672 www.alideck.co.ukThe ENVIRONMENT
Our Recycled Aluminium Decking products will naturally be
more environmentally friendly than other decking products
like timber and composite.
AliDeck will last a lot longer than Some people of course do not use any
timber or composite, reducing the chemicals to preserve their wooden
need to be replaced as often, there decking, but in those cases it is often
is also no need to maintain the surface seen that the decking surface and
of AliDeck, unlike Wooden Decking for subframe is often replaced more often
example. due to natural weathering, which will
not be the case for AliDeck.
Wooden decking is often treated with
environmentally harmful chemicals Composite decking has become
that are used as a preservative, or as a popular in the past, but is not generally
method of applying an anti-slip coating. recyclable due its composite make up
of wood, plastic and additives.
AliDeck will last a lot longer than
timber or composite.
30
FAQ’S
1. Does AliDeck warp?
No, it’s completely made from Aluminium and so does not expand or
contract anywhere near the same as composite or timber decking.
2. Is it quick to install?
Yes, with the Supa Joist it is 50% quicker to install than any other deck.
3. Does it require maintenance like timber decking?
No, it is powder-coated and is not porous and does not expand or
contract like timber so the coating lasts for a minimum of 5 years in
high traffic areas and 10 years in normal areas…expected service life 25 years.
4. Can I recycle it?
Yes, it is 100% recyclable.
5. Does it get hot in direct sunlight?
As the system is aluminium it dissipates heat quicker than timber and
composite decking.
6. Can you cut the Decking?
Yes, Aluminium decking can easily be cut to the shape or length required.
Tel: 01622 235 672 www.alideck.co.ukThe Original, A Rated, Quick
Fit, Complete Aluminium
Decking Solution
Rochester Airport Trading Estate Tel: 01622 235 672
27 Laker Road Email: info@alideck.co.uk
Rochester www.alideck.co.uk
Kent ME1 3QX
Aluminium DeckingYou can also read
