What makes SOLO lawnmowers so unique? 40
SOLO was the first to produce a rotary mower.
Today, our product range comprises quiet electric
mowers, convenient petrol mowers with electric
start and rear wheel drive, and even a powerful
mower for professional use with aluminium
diecast deck for use in particularly arduous
conditions as well as comfortable lawn tractors
that make easy work of even the largest lawns.
No surprise then that, in consumer tests, SOLO is
always near the top.
Technical innovation together with the experience
that comes with being a German lawnmower
pioneer. The high quality standards claimed by
SOLO provide the mower user with assurance for
faithful service over many years.
41
Decision-making aids
How large is your lawn?
Answering this question is the first important criterion in
reaching your decision as to which lawnmower suits
you best?
Our light-weight and agile lawnmower models offer
themselves for smaller and medium-sized lawns
up to 800 m2.
Mowers with greater cutting widths, self-drive and extensive
accessories offer benefits for lawns up to 3 000 m2.
Petrol or electric?
Do you have a lawn of not more than 800m2 without too
many obstacles for an electric mower and the power
supply is handy?
In that case the light and compact SOLO electric mowers
offer themselves as an alternative to petrol mowers.
Electric mowers are a little quieter and mow without giving
off exhaust fumes.
Should your lawns be somewhat larger and feature
obstacles, then one of our range of powerful petrol mowers
will undoubtedly hit the mark. Without having to consider
cables and power supply, they can manage rather
larger areas.
Collecting or mulching?
All lawnmowers in the SOLO range with rear discharge
are equipped with collector bags with generous capacity.
Assisted by the SOLO Aeromatic system, the grass
collector is filled to the brim – even when the grass is a
little damp.
Select a mulching kit if you want to treat your lawn by
returning some natural nutrients into the grass.
Many models can be turned into a mulching mower with
this conversion kit. The discharge chute is closed off, and
special mulching blades are used when lawnmowers are
operated without a grass collector. The finely chopped
grass falls back onto the lawn – no need to dispose
of cuttings.
42
SOLO Technology in detail
Ergonomically optimised
controls for easy handling
and safe control.
Folding handle with practical
quick-acting locks.
Central variable height adjust-
ment.
Robust grass collectors
with dust protection
system.
Deck made from high grade
diecast aluminium or from
impact-resistant plastic.
Only from SOLO: The SOLO
Aeromatic system for optimum
filling, even when grass is wet.
An impeller positively supports
the propulsion of cuttings into
the grass collector.
Ball bearing wheels ensure
extra light movement.
Rear wheel drive with
robust smooth gearbox.
Comfortable
electric start.
*All equipment details serve as examples for different models
43
Electric mowers
SOLO electric mowers
for small and medium-
sized areas are quiet and
environmentally-friendly,
yet still powerful.
All mowers are fitted with
motor overload protection
and feature a large grass
collector as well as easy
height adjustment.
586 587 589 The most uncompromising quality product amongst elec-
tric mowers: 1 600 W rating, an unusually thick-walled
plastic deck and ball bearing wheels.
These are just a few of its obvious quality features.
The perfect match between impeller (Aeromatic) and
deck shape also ensures truly outstanding collection
characteristics.
The SOLO Aeromatic ensures
the grass collector is filled to
the brim – even if the grass is
damp.
The ideal electric mower The ideal electric mower Model
Part no.
for small and medium-sized lawns even for larger lawns from
up to 250 m². 250 to 500 m² near the house. Electric motor (E) / four-stroke (type)
Power kW electric / cubic capacity cm3
Driving speed km/h
Cutting width cm
Cutting height mm / steps / variable
Wheel bearings friction bearing / ball bearing
Wheel diameter mm v / h
Deck plastic / steel / diecast aluminium
Folding handle
Grass collector bag capacity litres
Noise level LWA/dB(A)
Weight kg
Mulching kit Part no. (mulching blades + mulching wedge) option
44
The X series of lawnmowers
The X range are the entry models
amongst SOLO motor mowers.
Light but robust decks, ball
bearing wheels for easy
movement, and powerful engines
of the latest generation with large
displacement and high torque
guarantee making mowing a
genuine pleasure.
The ideal manoeuvrable
540 X mower for small and medium-
Fig. l.h.
sized lawns up to 300 m².
Practical emptying of
grass collector with
easy-grip handle.
Individual single wheel
height adjustment.
547 X 547 RX
551 RX 548 RX 553 RX
586 587 589 540 X 547 X 547 RX 551 RX 548 RX 553 RX
5000186 5000187 5000189 5000140 500014701 500014702 500015103 500014804 500015301
E E E B&S 550 SERIES 4.0 B&S 625 SERIES 5.0 B&S 625 SERIES 5.0 B&S 625 SERIES 5.0 B&S 625 SERIES 5.0 B&S 675 SERIES 6.0
1.4 1.5 1.6 158 190 190 190 190 190 R-Start
– – – - - 3.5 3.5 3.5 3.5
37 40 40 40 47 47 51 48 53
22-55 / 3 / – 30 - 75 / 5 / – 25 - 75 / – / 20 - 65 / 5 / - 30 - 75 / 5 / - 30 - 75 / 5 / - 30 - 80 / 5 / - 30 - 90 / - / 30 - 90 / - /
/– –/ –/ –/ –/ –/ –/ -/ -/
140/175 175/175 150/200 150/180 200/200 200/200 200/200 180/230 180/230
/ – / – /–/– /–/– –/ /– –/ /– –/ /– –/ /– -/-/ -/-/
35 45 40 55 55 55 70 70 70
96 96 93 96 96 96 98 96 100
16 18 23 24.5 31 34 37.4 40 44
- - 5900826 - 5900426 5900426 5900427 - -
45
Lawnmowers with plastic deck
Only from SOLO: Only from SOLO:
SOLO Aeromatic SOLO Aeromatic
An impeller positively An impeller positively
supports the propulsion of cut- supports the propulsion of cut-
tings into the grass collector tings into the grass collector
– even when grass is damp. 582 – even when grass is damp.
Central height adjustment with The central height
one rotary adjuster affecting adjustment affects all
all wheels. wheels simultaneously.
Practical deck handle,
Stable deck handles. spring-loaded.
No tools required to Air filter lid can be opened
open the filter lid. without tools.
Ask your dealer for our attractive The simple yet very robust mower with excellent Grass cuttings can be coll-
special model. grass catching characteristics. ected or simply spread onto
The ideal mower for lawns up to approx. 600 m², the lawn – the choice
is yours.
aimed at users who value exceptional quality
These mowers can be conver-
582 SM more than fancy features.
ted to side discharge with only
A mulching set for simple and quick conversion a few steps.
of the 582 into a mulching mower is available
separately.
Deflector for conversion to side discharge mower
Series 546 Part no. 5900800
46
Excellent workmanship and the
use of robust materials are given
top priority in the development
and manufacture of SOLO
lawnmowers.
Proven technology, practical, well
thought-out details, high levels
of convenience and the bullish
power make mowing your lawn
with the compact SOLO mowers
from this range a real pleasure.
The SOLO Aeromatic collector
system turns these lawnmowers
into ideal leaf collectors too.
Leaves are finely chopped,
leaving them ready to convert
to compost or for use as mulch
to retain moisture and warmth
around plants.
546 546 R 546 RS electric start
The classic amongst the collection of SOLO Its single-speed drive and primarily its The self-drive and the stress-free ReadyStart
mowers without self-drive offers a cutting extremely robust plastic deck with excellent make light work of frequent mowing, even of
width of 46 cm. grass collecting characteristics make the 546 R larger areas.
This robust all-round talent is ideal for lawns an ideal mower for lawns between 400 and The electric start provides additional conveni-
between 400 and 800 m². 1 000 m². ence: Simply turn the key, just like starting a car.
47
Technical overview Lawnmower
with plastic deck
Model 582 582 SM 546
Part no. 5000182 500018206 5000146
B&S 650 SERIES B&S 500 SERIES B&S 650 SERIES
Engine
5.5 HP R-Start 4.0 HP 5.5 HP R-Start
Displacement cm3 190 158 190
Starter Recoil / ReadyStart / Electric / – / – / – / – / / –
Drive speed km/h / 1 speed / Vario – – –
Cutting width cm 40 40 46
Cutting height mm / variable / central 30 - 75 / / 30 - 75 / / 30 - 75 / /
Deck Plastic / Diecast aluminium / – / – / –
Ergonomic handle / folding / / /
Dust protection collector / Collector / Capacity litres / – / 40 –/ / 40 / – / 50
Ball bearing wheel
Wheel Ø mm front/back 150/200 150/200 180/200
Noise level LWA/dB(A) 96 96 96
Weight kg 26 23 28
Mulching option
Accessories
5900824 5900824 5900830
Mulching kit Part no.
Option
Lower speeds possible – – –
Your dealer
will make you
a great offer
9386 Solo Catalogue page EN Q7 1.qxd:Layout 1 24/10/08 08:55 Page 1
EASIEST STARTING – NOW GUARANTEED
Briggs & Stratton guarantees on all our ReadyStart®
equipped engines S2 Guarantee. This guarantee offers
peace of mind that the engine will start within two pulls
every time, or we will fix it for free!
The Briggs & Stratton ReadyStart® technology is the
standard for easy starting. No Priming. No Chocking.
No Worries. Starts in 2 pulls – Guaranteed.
To find out more please visit us on
http://www.briggsandstratton.com/eu/en
BRIGGS & STRATTON AG
ZÜRCHERSTRASSE 4, CH - 8852 ALTENDORF
tel: +41 (0)55 451 63 63 fax: +41 (0)55 451 63 64
48
BRIGGSANDSTRATTON.COM
Lawnmower
with diecast aluminium deck
546 R 546 RS 550 550 R 550 HR 550 RS
500014602 500014605 5000150 500015002 500015003 500015005
B&S 650 SERIES B&S 650 SERIES B&S 675 SERIES B&S DOV 700 SERIES Honda GCV 160 B&S 650 SERIES
5.5 HP R-Start 5.5 HP E-Start 6.0 HP R-Start 6.0 HP R-Start 5.5 HP 5.5 HP E-Start
190 190 190 160 160 190
/ / – / / / / – / / – / – / – / /
3.5 / / – 3.5 / / – – 3.5 / / – 2.6 - 4.8 / – / 2.6 - 4.8 / – /
46 46 48 48 48 48
30 - 75 / / 30 - 75 / / 30 - 80 / / 30 - 80 / / 30 - 80 / / 30 - 80 / /
/ – / – –/ –/ –/ –/
/ / / / / /
/ – / 50 / – / 50 / – / 62 / – / 62 / – / 62 / – / 62
180/200 180/200 180/200 180/200 180/200 180/200
96 96 96 96 96 96
31 34 35 38 42 40
5900830 5900830 5900835 5900835 5900835 5900835
– – –
PERFORMANCE DRIVEN
BY TECHNOLOGY
SEE
THE DIFFERENCE
HEAR
THE DIFFERENCE
The new DOV® engine introduces a
FEEL
state-of-the-art technology, which
you not only feel and hear but also
see. Elegant Design combined with
THE DIFFERENCE less noise and vibration.
49Lawnmowers with diecast aluminium deck
Ergonomically
optimised controls.
Practical
quick-acting closures.
550 550 R
Central
height adjustment.
Dust protection
grass collector bag.
Only from SOLO: The premier SOLO lawnmower without self The versatile all-rounder with self-drive for
SOLO Aeromatic propulsion. With its diecast aluminium deck, the large areas or hilly terrain between 600 and
for optimum filling, even 550 is practically indestructible. 1 200m2.
when grass is damp. The 550 the ideal mower for users demanding With its diecast aluminium deck, the 550 R is
An impeller positively top quality, for lawns between 600 – 1 000 m²; almost indestructible and is, therefore, the ide-
supports the propulsion for work on slopes select the self-drive version al long term choice for customers who value
of cuttings into the grass (550 R). quality and a long service life.
collector.
50Flagship amongst the SOLO lawnmower
collection for private users.
The long lasting high grade SOLO
mowers leave nothing to be desired, even
for the most discerning user.
This class of SOLO lawnmowers offers
features, from easy rolling wheels
to a convenient constant or variable
speed self-drive, plus the revolutionary
ReadyStart system.
For you this means comfortable mowing
on large lawns and easy, safe mowing in
hilly terrain.
NEW!
Optimised gearbox with
aluminium body.
NEW!
Gearbox maintenance
550 HR 550 RS and service flap.
Tyre profile for good grip
and optimum forward
movement.
A well equipped mower for large areas or hilly After turning the ignition key, the 550 RS quietly Grass cuttings can be
terrain from approx. 600 to 1 200 m². purrs away. All you need to do now is to engage collected or simply spread
Match the speed of the mower to your personal the self-drive and your SOLO lawnmower draws onto the lawn – the choice
requirements using its Vario drive. Real conveni- its accurate stripes across your lawn. is yours.
ence at your fingertips. Match the speed of the mower to your preferred These mowers can be
working rate using its Vario drive. converted to side dischar-
ge with only a
few steps.
51Professional rear-discharge mowers
Our rear discharge mowers – the
best combis in the professional
range.
Professional mowing with optional
side or rear discharge*.
Tough everyday work with
compliant handling is standard
for these powerful mowers.
These extra-wide mowers with
53 cm cutting width are designed
for a very long service life and
are, therefore, equipped with
special protective armour and
reinforcement for tough
continuous use.
These high grade rear-discharge
mowers can cover huge areas
in large private gardens or in
public parks.
Central height adjustment 553 S 553 SL
(553 S). Individual speed selec-
Separate height adjustment on tion through the Vario
individual wheels (553 SL). De- gearbox.
eply profiled wheels for excellent
forward motion.
The reinforced handle support
ensures low vibrations.
The folding handle is secured
with two knurled nuts.
Large grass collector with ad-
ditional discharge flap for rapid Model 553 S 553 SL
emptying. Part no. 50001531 50001532
Engine B&S 675 SERIES 6.0 HP B&S 825 SERIES 6.5 HP
Displacement cm3 190 R-Start 190
Recoil starter
Diecast aluminium deck, optimi-
Cutting width cm 53 53
sed for easy transfer of cuttings
into the grass collector. Cutting height mm / Steps / Variable 25 -95 / 8 / - 25 - 95 / 8 / -
Central / Individual /- -/
Diecast aluminium deck
Grass collector Capacity litres 70 70
Vario drive / 3-speed /- -/
Grass cuttings can be collected Driving speed km/h 2.6 - 4.8 2.6 - 4.8
or simply spread onto the Wheel Ø mm v/h 200/230 200/230
lawn – the choice is yours.
Ball bearing wheels
These professional mowers can
Noise dB(A) 98 98
be converted to side discharge
with only a few steps. Weight kg 52 58.5
Reinforced handle, steel insert,
Reinforced handle,
edge protection, metal wheels,
*Deflector for conversion to side discharge mower Special features may be converted to
may be converted to side
553 S, 553 SL Part no. 5900803 side discharge
discharge
52You can also read
