Chain for Confectionary Production
Renold supplies a comprehensive range hygiene are catered for as well as Standard and non-standard attachments
of chain to meet the demands of considerations such as corrosion and are available to suit your needs. Renold
manufacturing confectionary products. wear resistance. has the experience to provide products
Environmental requirements such as and support to keep your high volume
production lines operational.
Renold Chocolate and Confectionary I3
Renold has the answers
Renold helps you to avoid costly downtime.
Renold helps you to reduce waste chocolate.
Renold provides a whole range of chain solutions.
™ Renold Synergy
• High performance, long lasting
roller chain
• Unbeatable wear and fatigue resistance
• Virtually dry-to-the-touch
• Easy to handle and install
Renold Syno
™ • The leading maintenance free
chain range
• Does not require relubrication
• Dry-to-the-touch
• Used worldwide in food industry
Renold takes care of everything
Hydro-Service Stainless Steel Klik-Top Attachment chain Lubrication options
Superior corrosion Tried and tested Tough and easy Widest variety, Food industry-approved
resistance to install anything you need options available
4 I Renold Chocolate and Confectionary
At every stage of the process Renold
provides exactly what you need.
Precision in our chain ensures accurate
indexing of moulds along a production line,
minimising waste chocolate.
Mould Mould Cooler Demoulder
heater shaker
Chocolate Mould Backing Packaging
depositor inversion depositor
We don’t just provide products that make a difference;
you get the best services from Renold too!
Renold Chocolate and Confectionary I5
Services
We’re not just here to sell you chain;
we can help you increase your efficiency in many ways.
Onsite Consultation & Specification Site Surveys Attachment chain
• Expert advice & assistance • Personalised CD of your chain inventory Whether you need standard attachment
• Calculations based on your application • Helping you clarify your specific chain or attachments for Renold Synergy
chain requirements and Renold Syno, we have the capability
• Technical advice on torque, force to replicate any attachment form and can
and loads • Consolidating your purchasing efficiency provide bespoke solutions.
• Customised solutions and • Simplifying your inventory
savings assessments • Working in partnership with customers
• Reducing onsite maintenance costs
& time
Condition Monitoring Technical / Design Helpline Online Chain Training Centre
• Analyse the performance of your drives • Talk to us about your application • Chain information tailored to
• Unique technology to Renold requirements differing knowledge levels
• Electronic data logging • Experienced engineers to answer • Basic principles explained
your queries • Useful tips and considerations
• Ensures optimum drive set-up
• Experienced in 1000’s of applications -
including yours!
6 I Renold Chocolate and Confectionary
Accuracy
Renold have developed Confectionery simultaneously co-ordinate the position of exactly the right place once the machine
Chain Matching, which is for use when the mould at several different stages. is set up. In these applications the
simultaneous operation(s) need to be For example, while one mould is being uniformity of chain length over any given
carried out at different positions in a filled with chocolate, another mould, section of its length is essential.
drive. An example of this would be which could be several hundred feet of When you need chain for an indexing
chocolate moulding machinery, where chain away, is being emptied after cooling. application like this, our quality control
2 parallel chains are generally used to In order to ensure proper deposition of the delivers exactly what you need.
transport a large number of moulds chocolate and release from the moulds it
through the system. In this application it is essential that the moulds stop in
is necessary for the chain to
Condition Monitoring
The importance of correct system set-up cannot be Data logging technology unique to Renold can diagnose
taken for granted any problems that may be occurring and shed light
• Correct chain specification on possible solutions.
• Alignment of shafts and sprockets
• No obstructions within the system
Smartlink data logger recording the performance of a mould indexing line.
