Digital Radio Standards
By Sandra Wendelken, Editor
The past few years have seen the development of several
new digital radio technologies and the continued maturity and
evolution of other digital radio standards, some of which have
been on the market for more than 20 years. This e-book
serves as a guide for four of the most typical standards in the
Americas — Digital Mobile Radio (DMR), NXDN, Project 25 (P25) and
TETRA. In addition, digital Private Mobile Radio (dPMR) technology is
beginning to expand into some South American markets.
With the new digital radio standards and the established technologies,
interoperability and competition have become more central for users. From
industries such as utilities, energy and private wireless to public-safety
systems, open standards are allowing users to buy equipment from the
vendor that best meets their needs for each component of the network.
Mission-critical voice networks continue to be one of the most important
tools for mission-critical companies and agencies. New broadband initiatives
are on the horizon, but those networks are years away and likely won’t have Sponsored by
mission-critical voice capability for a decade or more. In fact, many users
take advantage of the mission-critical data capabilities available through the
digital radio standards highlighted in this e-book.
This e-book covers the features and specifics of each of the four
technologies, along with articles on system upgrades, interoperability and
open procurements. In addition, each vertical industry has a case study that
demonstrates how a particular digital radio standard worked to fulfill that
user’s needs and requirements. Following an overview section with general
information on the standards and how users can take advantage of their
various features, the next three sections each highlight a digital vertical
market — critical infrastructure industries (CII), private wireless/enterprise
and public safety.
Each sponsor of this resource contributes to one or more of the digital
radio platforms in some way so take a close look at their offerings when you
are ready to move forward with your next digital radio technology purchase.
Each sponsor is a leader in its market and would welcome a chance to ex-
plain its products and services.
