Front Cover Story
Fall arrest protection: where, when and
how to choose Self-Retracting Lifelines
a manner that a fall can occur, but the
There are many scenarios where working at height is simply
fall is arrested within acceptable force
unavoidable and some of the most hazardous work sees operatives and clearance margins. A suitable
working on top of an elevated surface or structure. It’s here where rescue procedure would then need to be
implemented.
selecting the correct fall arrest solution is critical.
Why self-retracting lifelines?
One of the most effective and widely used fall
arrest solutions today is the Self-Retracting
Lifeline (SRL). Accounting for around a fifth of the
420 million Euro fall protection market , SRLs are
replacing lanyards and rope grabs as they typically
last longer, retract on movement, offer faster lock
on and are easier to store.
A synthetic line or metallic cable attached to
the worker’s harness automatically extends
and retracts from a floor or overhead anchored
container unit as the worker moves. In the event
of a sudden fall, the product will ‘lock on’ to arrest
the force of the fall, and an energy absorption
system will then limit the impact of that force on
the body of the worker in the harness.
Jon Rowan, Product Line Manager at MSA Safety, falling through fragile roofs .
explores where, when and how Self-Retracting
SRL systems and the working
Lifelines (SRLs) should be deployed for vertical Hierarchy of control - identifying the situation
environment
fall arrest protection, and looks at the features that The hierarchy of fall protection is the starting point
define the most reliable, robust and best lifetime- to determine what type of approach to working at
One of the first factors to consider when specifying
value equipment. height and/or fall protection system is required -
the correct SRL system is the application
and why.
and environment. What are the atmospheric
Despite significant advances in risk awareness
and safety technology, falls from height remain a 1. The preferred solution to all fall hazards is conditions? In a coastal location, for instance,
significant cause of injury and death. According to elimination. continuous exposure to saltwater vapour poses
the HSE’s figures for fatal injuries in Great Britain 2. 2Passive fall protection: Physical barriers like the risk of accelerated corrosion for metal parts.
for 2019-20, 29 workers suffered fatal injuries as a guardrails around unprotected edges, for Similar corrosive hazards can be present in
result of falling from height - that’s just over 26% example. petrochemical sites, posing potential degradation
of all UK fatalities in the workplace. Over the last 3. Fall restraint systems are erected in such risks for SRL plastics and composites. SRL
five years, falls from a height have accounted for a manner that a fall cannot occur. They specification options available from MSA, for
26% of all fatal accident injuries (an average of use PPE to restrict the worker’s range of example, include the use of sealed SRL casings,
37 fatal injuries per year) . Over 60% of deaths movement so they cannot physically travel to military-grade plastics and high-grade S4
when working at height involve falls from ladders, the fall hazard. stainless steel components that provide additional
scaffolds, working platforms, roof edges and 4. Fall arrest systems are erected in such barriers against corrosion.
4 HES Magazine | July/Aug 2021
Front Cover Story
SRLs are also inherently versatile and used Safety incorporate several innovative features in
Understanding SRL anchors across a wide range of industries and horizontal, the V-Series range that add value. By fabricating
overhead, and leading edge applications. From the outer casing in clear, engineering-grade
An SRL is there to provide a fall arrest point. It will vertical access via pylons, turbines, water towers plastic, it’s easy to quickly inspect the drum
always be attached to an anchor which may be in and confined spaces in general, to loading and and mechanism inside. For leading edge SRL
different locations: maintenance bays, assembly lines, silos, rooftops products, an integrated roll cage protects
and the building and construction industry at housing when used in foot-level tie off. Internal
• Overhead anchor point: this is the standard large, SRLs can help to take the guesswork out of components like the cable, energy absorber
way to attach an SRL - to a carabiner or equipment selection.
and retraction dampener can be replaced on
point above the workspace. This approach
site – reducing maintenance and repair times and
is traditionally seen when there has been an
Another factor to consider is fall clearance - the
eliminating the need for holding backup devices.
investment in infrastructure, and the benefit
minimum vertical distance required between a
is that in the case of a slip or trip, there is less The energy-absorbing technology also requires
worker’s feet and a lower level, which can also
distance to fall. no additional calibration or adjustment, whilst
vary at different points on the working area. A self-
• Foot level anchor point: a foot or deck level retraction dampening limits the cable speed
retracting lifeline can accommodate significant
tie off - positioned at foot level, with the SRL protecting internal parts from wear and damage.
variance since it remains under tension and
attached. This is a more common approach
and is in many ways easier to use as nothing automatically adjusts the line. As an example, the
Making safety a mission
needs to be lifted overhead. However, it does latest addition to MSA Safety’s V-Series SRL range
mean that if the worker falls, the product is at offers a new maximum line extension of 30m.
For more than 105 years, MSA’s mission has
a 90-degree angle to the fall. On many sites centred around developing protection solutions
edges of roofs and structures can be sharp, How quality design enhances lifetime
that allow employees to return home safely at
so a foot level anchor must always be tested performance and reduces cost
the end of every working day. Our portfolio of
and ‘edge rated’.
products has been considered and developed
Ultimately, the design of an SRL directly impacts
carefully, over time, listening to the industry and
Understanding your anchor point is the first step safety and whole service-life cost. Human life
responding to their challenges and concerns.
in making an appropriate product choice - you
is priceless, and employers have a duty of care
need to consider where the anchor is, how far it is
to reduce risks faced by their workers. While
To optimise your investment whilst ensuring
away from the working point and how far away it is
technically all products are certified to the same
from the edge. Being conscious of fall clearance workers enjoy access to versatile, best-of-breed
standard, the reality is that not all are created
is also vital – having knowledge of distance means protection whatever the job, it always pays to
equal. Entry-level, economy priced PPE is
you can allow enough space for a fall to happen scrutinise the quality and pedigree of PPE.
much less likely to offer the same performance
in the safest way possible. Once these things
and durability as higher quality, more premium
are understood, you can then make an informed
choice on safety equipment, such as SRLs. solutions.
The all-new MSA V-TEC® 30m SRL
Match the solution to the application and Trying to minimise expenditure at the outset
The V-TEC 30m SRL completes MSA’s
value of product can be a false economy. Investing in the best V-TEC range of overhead SRLs. This 30m
equipment can yield lifetime savings and result product is an extension of the existing
There are a vast number of situations where in lower total cost of ownership. For example, range of SRLs. A patented radial energy
fall protection is necessary, and it’s important equipment that is inherently designed to be absorber technology is utilised along with
to consider the individual differences between serviceable in the field and minimise repair times clear windows for inspection, retraction
applications. For example, working with solar
can dramatically reduce costly downtime and dampening and In Situ maintenance to
panels on a rooftop or servicing an aircraft wing
delays. Smart retraction dampening technology round off the portfolio in style.
will require care to prevent equipment causing
which, in some instances can reduce cable
damage. Using a synthetic web lifeline will
retraction speed by up to 3m/s, can also not only The innovative 30M SRL brings with it ease
minimise the risk of damaging products and
increase safety but limit damage to the product of use, effortless maintenance and low total
surfaces. Conversely the presence of sharp edges
and surroundings, thus minimising downtime and cost of ownership - adding value to any fall
that could sever a fabric line necessitates use of
further maximising product lifespan. protection eco-system.
a high-grade steel cable. Similarly, a construction
site may have abrasive concrete dust that will
By placing this philosophy of quality front-of- To find out more go to: bit.ly/V-TECSRL
degrade synthetic lines, requiring a steel cabled
solution. mind, standard and leading edge SRLs by MSA
HES Magazine | July/Aug 2021 5
News & Products
Prime opportunity to end sloppy ventilation
according to Elta Group
A renewed focus on the quality of indoor environments is an The importance of ventilation in the context
of COVID19 was highlighted in a Government
opportunity to weed out “ventilation cowboys” according to an air
whitepaper in October last year. It echoed Elta
quality expert at Elta Group.
Group’s assertion that industry must move beyond
simply achieving minimum air change rates and
air quality. Instead, systems must provide the
most appropriate ventilation for the welfare and
productivity of occupants, alongside building/
room usage.
David continues: “Modern UK ventilation systems
need to be right first time, as well as sustainable
and long-lasting. Choosing the right fan for the
right application is paramount, which is why
it’s important to be up to speed on specific
characteristics and benefits of fans and their
constituent parts. This means that contractors and
their customers must ensure they are in a position
to be a source of expertise, and adhere to best
practice installation principles.”
According to Elta Group, there is no one-size-fits-
all solution and best practice installation considers
a balancing act between air flow, energy
efficiency, and thermal comfort.
To aid this process, Elta Group has developed
an educational tool for contractors to help solve
design issues and overcome any misconceptions.
The transmission of COVID19 has propelled the David comments: “Unfortunately we have seen The ‘Give a Fan a Chance’ guide outlines key
topics of indoor air quality (IAQ) and calibre of an increase in substandard systems installed considerations and provides practical tips on
ventilation systems under the public spotlight over delivering optimal ventilation solutions. In turn,
in buildings over recent years, mainly due to
this provides a number of simple steps to improve
the past year.
end-users challenging critical elements in quotes
design, focusing on critical elements such as
and subsequently opting for ventilation cowboys. energy efficiency, noise control, air quality, and
According to David Millward, Group Product
However, as the general population becomes reduction of leakage.
Manager at Elta Group, this is a prime opportunity
increasingly knowledgeable about the importance
for industries to raise the standard of installation To find out more, download Elta Fans’
of good IAQ, end-users are likely to expect, and
across the board, following a number of years Give a Fan a Chance guide at:
of corner-cutting due to price wars and time appreciate, a higher standard of installation and
www.eltafans.com/resources
constraints. specification of ventilation systems.”
6 HES Magazine | July/Aug 2021
News & Products
New EU distribution channel for faster Pyroban parts service
Safety company Pyroban has appointed a distributor for parts in Europe to
optimise the logistics process following Brexit. AI2C based near Marseille in
France will now act as Pyroban’s European Parts Distribution Centre.
EU customers can now buy Pyroban approved parts now providing a complete EU transport service for
directly from AI2C which holds stock locally of all fast forklift trucks coming from the EU to the UK for ATEX
moving Pyroban parts to allow rapid shipment. AI2C conversion, and then going back again to the EU. The
will also take care of the import of bespoke and non- new parts distribution channel with AI2C complements
stocked parts from Pyroban’s manufacturing facility in this service to ensure customers are supported France which will speed up the delivery time for the
the UK and handle onward shipment to the customer. quickly with parts across the EU. customer. AI2C has good experience in Ex products
and works with customers in the same industries as
Steve Noakes, Managing Director of Pyroban, a Customers will still have the choice to either purchase
Pyroban, so we believe we are well placed to support
safety business that provides explosion protection replacement parts from Pyroban UK or through AI2C.
the existing Pyroban customers and also develop new
conversions for forklifts and other equipment, said:
customers for the Pyroban products.”
“AI2C has a good position in the market with
“We have listened to our European customers and
experience in Ex applications and also serves the
the problems they experience with some Pyroban
same end users as Pyroban’s customers,” says For more information about AI2C visit
parts orders, extended shipping times and payment
Steve. AI2C also represents Pyroban’s sister brand https://www.ai2c-combustion.com,
difficulties since Brexit. Establishing an EU parts
Pyropress and other well-known brands. email info@ai2c-combustion.com or call
distribution channel is another milestone in the range
(France) +33 04 94 65 80 17. For more
of services we now offer to support our customers.”
Christian Golfier, President of AI2C commented: information about Pyroban visit www.
“We welcomed the opportunity to become an pyroban.com, email sales@pyroban.com
The news comes after Pyroban announced improved
official distributor for Pyroban to support European or call (UK) +44 (0)1273 456800.
lead times and simplified shipping arrangements
customers since Brexit. We will hold stock locally in
for entire forklift truck conversions. Pyroban is
HES Magazine | July/Aug 2021 7
News & Products
ST75V Hydrogen (H2) Cooling Thermal Flow Meter
Supports Gas Safety for Power Plant Generators
calibrated to laboratory standards for a wide range
Safety of a No-Moving Parts Design With Built-In Flow Conditioner for Accuracy of gases. The no-moving parts construction makes
the ST75V meter the safe choice for combustible
gases.
Ideal for demanding, rugged power plant
environments, the ST75V Flow Meter features
remote mounting capabilities for hazardous or
crowded plant environments. The remote mount
transmitter, which includes a full digital display, can
be mounted up to 50 feet (15 meters) away from its
thermal mass flow sensor in the process piping and
connected via two 0.50-inch FNPT or M conduit
connections.
The ST75V Flow Meter’s fully scalable dual 4-20mA
standard outputs are user assignable to flow rate
and/or temperature and a 0-1kHz pulse output of
total flow. The instrument can be ordered for input
power with either 18 to 36 Vdc or 85 to 265 Vac, with
or without a built-in LCD digital display.
Offering direct-flow measurement for higher
performance at a lower cost with proven thermal
The advanced, compact ST75V Air/Gas Flow Meter potentially dangerously combustible and its flow dispersion technology, the ST75V Flow Meter
from Fluid Components International (FCI) is the must be monitored closely to detect and prevent gas eliminates the need for additional pressure and
perfect solution to monitor the potentially volatile, leak conditions. temperature sensors, flow computers, or other
hydrogen (H2) gas necessary to help large electric
devices that are required with orifice plates,
plant power generators keep their cool as they FCI’s ST75V Flow Meter with its built-in Vortab Flow
Venturis, Vortex shedding, and other volumetric
produce electricity serving customers large and Conditioner is equally well suited for both H2 low
meters. The ST75V Flow Meter also requires virtually
small across the power grid. flow and high flow measurement in the monitoring
no maintenance for both a low installed and low
of electric power generator chambers. It operates
Power generation is a high-temperature, hazardous life-cycle cost.
over a wide flow range, from 0.01 to 559 SCFM (0.01
process. At the front-end, there are natural gas to 950 NCMH) depending on line size. For variable
The FM and CSA approved ST75V Flow Meter is
fueled steam boilers that drive power turbines. At the process conditions, the ST75V is factory preset to a
enclosed in a rugged, all-metal, dust and water
back end of the process, where the electric current wide turndown range at 10:1 to 100:1.
resistant NEMA Type 4X (IP66/67) rated package
is generated, there is a large amount of heat that designed for Class 1, Div 1 hazardous area
With built-in temperature compensation, the ST75V
must be managed in order to keep the generator’s Flow Meter maintains consistent performance installations and includes a rugged sensing element
wire coils cool enough to avoid degradation or in rugged, hot electric power plant generation constructed with all welded 316 stainless steel and
failure. environments. The basic ST75 model features Hastelloy-C22 tips. ATEX/IECEx approvals include:
accuracy to ±2% of reading with ±0.5% repeatability Zone 1, II 2 G Ex db IIC T6 . . . T1 and Zone 21, II 2 D
Depending on the MVA size of the power generator, over varying process temperatures in line sizes from Ex tb IIIC, IP66/67 T85º°C . . . T300.
hydrogen (H2), air or water is typically used to 0.25 to 2 inches (6 to 51 mm). With the integral
provide generator coil cooling. In all electric power Vortab Flow Conditioner added as a built-in spool FCI solves flow and level measurement applications
piece, the Models ST75V or ST75AV are ideal with advanced thermal dispersion technologies.
generators, the wire coils will otherwise quickly
for installations with limited straight-run such as With 50+ years’ experience and the largest installed
overheat and degrade if they are not continuously
crowded power plant generator areas and/or for base of thermal flow meters, flow switches and level
cooled during operation.
operating in transitional flow ranges with accuracy of switches, count on FCI to know your application and
H2 is the industry’s most efficient coolant, ± 1% reading, ± 0.5% full scale. have the solutions.
particularly for large generators (over 100 mW);
The ST75V Flow Meter’s precision flow element
because hydrogen has a 15 times higher heat/ has a no-moving parts flow sensor design that For more information visit:
thermal conductivity efficiency compared to air. employs platinum RTD sensors embedded in equal www.fluidcomponents.com
The downside of using H2 as a coolant is that it’s mass thermowells with microprocessor electronics
8 HES Magazine | July/Aug 2021
News & Products
Intrinsically Safe Product Marking Files Explained
If you look at any intrinsically safe (IS) portable LED lighting product, you'll notice it has a printed or raised
section of text on it. This safety requirement lets users see if the product they plan to use is safe to take into a
potentially hazardous environment.
Let's take a look at one example of a marking file and explain what it means. If you are unsure what safety requirements you need, consult with a
This example shows a very high safety rating for a global market and thus reputable manufacturer or distributor of IS LED products. Ideally, you
has a very complex marking file. should purchase all IS LED lighting from a single manufacturer to ensure
safety and quality across the entire product line. Because of the knowledge
and expense required to engineer and produce IS products, a very limited
number of companies can provide this.
Nightstick has over fifty IS products to meet all your needs, from pocket-
sized penlights to wide-area floodlights; for use above ground or below,
Nightstick has you covered. Focus on your job with confidence, knowing
your equipment has the highest safety levels. When your Life Depends on
Light, choose Nightstick!
Find the certification level you require at nightstick.com
HES Magazine | July/Aug 2021 9
News & Products
SFC Energy: Member of the Bundestag and Chairman of the
Bündnis 90/Die Grünen Parliamentary Group Dr Anton Hofreiter
visited SFC Energy production and development site
SFC Energy AG (F3C:DE, ISIN: DE0007568578), a leading supplier
of hydrogen and methanol fuel cells for stationary and mobile hybrid
power solutions, welcomed Bundestag member and parliamentary cells are essential success factors. I am confident
that we can achieve our goals with a firm will and
group leader of Bündnis 90/Die Grünen Dr Anton Hofreiter to the
broad consensus across company and party
company's headquarter in Brunnthal, Munich.
boundaries," says Dr Peter Podesser, CEO of SFC
Energy AG.
Dr Hofreiter gained a deeper insight into the is the large-scale replacement of conventional
production of environmentally friendly, hybrid diesel generators with environmentally friendly fuel "It is time to act if we still want to achieve the
energy supply solutions alongside SFC Energy cell complete solutions from a single source. climate protection goals. It is therefore crucial
CEO Dr Peter Podesser. A visit to the SFC to deepen the constructive dialogue between
The clear advantage here is the emission-free
development centre was also on the agenda, policy-makers and businesses. I was especially
and efficient energy supply. In contrast to diesel
where Dr Hofreiter also learned about the interested in getting information about the status
generators, hydrogen fuel cells like the EFOY
advantages of the recently launched EFOY of fuel cell technology during my visit. It functions
Hydrogen by SFC Energy do not emit any harmful
Hydrogen hydrogen fuel cell. as a key technology if we want to make the energy
exhaust gases such as carbon dioxide (CO2),
supply more decentralised and environmentally
With Dr Hofreiter, a proven hydrogen expert nitrogen oxides (NOx), carbon monoxide (CO)
friendly. Wherever direct use of electricity from
in federal politics visited the fuel cell pioneer or fine dust. It operates quietly during operation
renewable energy sources is possible, we should
SFC Energy. In several discussions, debate and is extremely low-wear and low-maintenance
do so. For all off-grid and stationary applications,
contributions and media interviews, the leader due to the small number of moving parts. This
hydrogen as an energy storage medium and
of the parliamentary group in the Bundestag has ensures a long life cycle of the unit. Furthermore,
the fuel cell as a reliable and environmentally
already decisively dealt with an environmentally fuel cells by SFC Energy are 95% recyclable. As
friendly conversion technology open up great
friendly energy supply in general and the almost a fuel cell pioneer, SFC Energy is already making
opportunities for us to replace diesel generators
inexhaustible potential of hydrogen and fuel cells an important contribution to a low-carbon society
- in industry, mobility or at home. In Germany, we
in particular. He points out the great opportunities and the Race To Zero.
have technology leaders like SFC Energy AG. It
of hydrogen and fuel cell technology for energy-
"We are extremely pleased about Dr Hofreiter's is time we leverage this know-how much more
intensive industries, alternative mobility concepts
visit. We agree that broadly rolled out funding decisively to tackle climate change," says Dr
and for decentralised energy storage.
programmes such as the National Hydrogen Anton Hofreiter, parliamentary group leader in the
For more than 20 years, SFC Energy has stood for Strategy provide strong support and set the Bundestag.
innovative fuel cell technology and offers hybrid right impulses. At the same time, we also agree
For more information on SFC Energy's
energy supply solutions for numerous industrial that we as a society still have a long way to go
Clean Energy and Clean Power
applications and the leisure sector. A cornerstone to climate neutrality, in which environmentally
Management solutions, visit sfc.com.
of SFC Energy's sustainable corporate strategy friendly technologies such as hydrogen and fuel
10 HES Magazine | July/Aug 2021News & Products HES Magazine | July/Aug 2021 11
ATEX & UKCA
2019/1020/EU – New Market Surveillance and Compliance
of Products Regulation impact on ATEX
On 16 of July 2021, the new regulation 2019/1020/EU – Market Surveillance
and Compliance of Products Regulation came into effect.
It aims to strengthen the requirements for market and is the point of contact for these products, an
surveillance by Member States and will lead to “Authorized Representative”
far more checking of technical files and self- More general information on general CE/UKCA
declarations including ATEX Category 3 (and UKCA Ex Marking remains unaffected (currently)
Using the UKCA marking - GOV.UK
probably UKCA CAT 3 as the UK will probably as this regulation came into force after the UK
(www.gov.uk)
follow or reciprocate the more stringent checking
left the EU, however, there are many cases
requirements). ExVeritas can help with converting ATEX to
in the UKCA system where an “Authorized
UKCA Ex and do not offer any guidance on other
ATEX products manufactured outside of the Representative” is required.
Directives or importing/exporting and advice
European Union cannot be sold in the EU without
should be taken from the appropriate legislation/
an Authorized Representative within the EU as Do you need a UKCA Ex Certificate for
Directives for this. All we need to help you is
of July 16, 2021. Both the Manufacturer and the your UKCA Declaration?
details of any ATEX Certificates you had issued or
Authorised Representative (if used) must sign the
ATEX Files you had lodged with a Notified Body.
D of C. Simply put, if you needed Notified Body
involvement for ‘ATEX’ Certification before,
This legislation makes it very clear that there is
you now need UKCA Ex Certification from a www.exveritas.com
a requirement to have someone always present
in the European Union who takes responsibility Government Appointed Body (which we are)
12 HES Magazine | July/Aug 2021ATEX & UKCA
APEX is ATEX as standard
ATEX rating has traditionally been a difficulty for many machine
applications which have the requirements for operating in potentially
hazardous environments, where explosive gases or dust could be pres-
ent. Examples of such environments are printshops, food processing,
wood- or other organic processing, car paintshops, nuclear and the
petrochemical industry.
ATEX certification on machine components has historically come at a
substantial additional cost and with extended lead times and
to some customers it feels like manufacturers are treating
this requirement as a license to print money.
With Apex Dynamics servo gearboxes this is not the
case. The ATEX requirements were incorporated during the
early design phase and with some of our patents have enabled Apex to achieve
Category II 2 GD c T6 classification on our standard gearbox ranges, to the latest
ATEX DIRECTIVE 2014/34/EU.
This means that our ATEX gearboxes are still available in our standard 3-week lead
time with our unique 5 year warranty and can be ATEX- labelled on request at no
additional cost. The ATEX Certificate and SIRA certifying authority documents can
be downloaded from our Website. www.apexdynauk.com
Call Now for a Quote 0121 737 1170
or Email:sales@apexdynauk.com
HES Magazine | July/Aug 2021 13Fumes, Dust & Extraction
BVC – British Vacuum Cleaners
for Hazardous Environments
Henry Cecil Booth registered the British Vacuum Cleaner Company in 1903
to exploit his patented innovation, the first mechanically-powered vacuum
cleaner. Nearly 120 years later the BVC range of industrial vacuum cleaners,
ATEX rated motors, stainless steel (non-sparking)
now manufactured by Quirepace Ltd, continues to deliver innovative and
inlets, antistatic filters and tools and conductive
robust vacuum cleaning solutions to Industry.
hoses. In addition, some of the units in our ATEX
range can also be certified as “Type H”, which
means that they are not only suitable for operation
in a potentially hazardous environment; they
are also suitable for use where the dust itself is
hazardous. For example our Type H ATEX Zone
22 Industrial Vacuum Cleaners are approved by
the MOD for use on indoor firing ranges where the
potential hazards are both propellant residue and
lead dust.
It is important to make the distinction between
Industrial Vacuum Cleaners suitable for use within
an ATEX rated environment, and vacuum cleaners
capable of handling hazardous products. The
hazards associated with the product itself must
BVC equipment is manufactured to meet the combustible dust in air is not likely to occur in be individually risk assessed by the operator. For
specific requirements of our customers; machines normal operation but, if it does occur, will persist example, some products, such as some finely
can be configured with many different options for a short period only”. Such an environment powdered metals cannot be cleaned by vacuum
to meet specific demands. One of the most is very common in many workplaces, and an
cleaner at all because their Minimum Ignition
important sectors of the market is for ATEX rated appropriate risk assessment should conclude
Energy is too low. It must always be appreciated
machines capable of operating in hazardous that even if the risk is very low, if there is any
that the ATEX rating refers to the environment
environments. perceivable risk, ATEX rated vacuum cleaners
should be used when cleaning. in which the equipment operates and not the
The hazards of combustible dusts and fumes
environment inside the machine itself when
within the industrial workplace are well known. Quirepace manufacture a full range of ATEX rated
product is recovered by vacuum cleaning.
Companies whose core business involves creating Industrial Vacuum Cleaners from 1kW to large 3
large quantities of flammable dusts, such as phase 15kW units. The BVC range is manufactured
For both ATEX and non-ATEX rated environments
wood processing and flour mills are well aware in the UK in our own factory. BVC machines
there will be a suitable Industrial Vacuum
of the risks, and take appropriate precautions. retain the traditional qualities of robust British
Cleaner in the BVC range. Call us and talk to
However, in Quirepace’s experience there are Engineering. This means that you will find very
many environments where hazardous dusts are little plastic on BVC equipment. We manufacture our specialists, who will guide you towards the
not necessarily found in day to day operations, but predominantly from castings, robust metal optimum solution.
where appropriate precautions must still be taken. sections and metal pressings from our own press-
shop; our equipment is built to last, and we offer a
Most of the BVC ATEX rated product range is Quirepace Ltd
5 year parts guarantee to end-user customers.
designed to operate in dust zone 22. The HSE 023 9260 3700
describes zone 22 as “A place in which an Our Zone 22 ATEX rated machines incorporate
www.quirepace.co.uk
explosive atmosphere in the form of a cloud of ATEX rated control panels and motor starters,
14 HES Magazine | July/Aug 2021Fumes, Dust & Extraction
Aggregating Combustible Dust Airbench Releases Vertex VX – Cross-
Incidents from Around the World Draught System For Hazardous Areas
For the fifth year in a row, the team at Dust Safety Science AirBench, the UK’s leading manufacturer of downdraught
has compiled and analyzed combustible dust incidents from benches and cross-draught systems, is pleased to announce the
around the world. release of VertEx VX – an ATEX rated version of the popular
VertEx cross-draught system.
As of December 31, 2020, they captured
almost 1000 incidents in their incident reports
Suitable for zone 22 applications, VX uses
along with a detailed analysis of the materials,
industries and equipment involved. the same principles as the VA range but
applies ATEX fans and electrical systems
Dust Safety Science aggregates their reports
alongside fully earthed filtration.
twice a year, and this most recent report
includes all incidents they have captured from VertEx VX can be installed alongside
January 1, 2020, to December 31, 2020. These the VB booth system, allowing the
are broken into fires and explosions occurring
construction of full dust containment
both in North America and internationally throughout the world.
booths in zone 22 hazardous areas.
To download the full report, click the link below.
http://bit.ly/Dustsafetyreport2020 For more information visit:
For more information visit:DustSafetyScience.com https://www.airbench.com
HES Magazine | July/Aug 2021 15Fumes, Dust & Extraction
Monitoring Of Indoor Air Quality Needs To
Measure More Than Just CO2
With ventilation continuing to dominate the news agenda, a leading
ventilation specialist is stressing the importance of monitoring
pollutants beyond just CO2. compounds (TVOCs). Given the main source of
some of these, natural ventilation such as opening
a window can actually have adverse effects
in certain locations e.g., city centres. In these
circumstances, mechanical ventilation offers the
most protection for building occupants.
Alongside pollutants, there is also the issue of
relative humidity (RH). Humidity levels in indoor
spaces play an important role, from supporting
good human health and wellbeing, to helping
preserve stored food, electronic equipment,
artwork etc. Too high humidity levels can cause
damp and condensation problems, and at the
opposite end of the scale, too low levels of
humidity can lead to a dryness of the skin, eyes,
nose and throat.
This is crucial, as the human body's first line of
defence against airborne agents (both chemical
and biological) is the mucosa lining at the top
airways (nose and throat), and if this dries out, the
CO2 is a widely used indicator of room occupancy past 18 months has been a renewed focus on
body's immune response becomes compromised.
and the need to ventilate, which according to IAQ, and how we can improve the health of our
Thus, achieving healthy levels of humidity within
Elta Fans has proved useful in encouraging more buildings. CO2 has served as a useful proxy to
an occupied space is an important step towards
engagement with improving IAQ. However, as measure progress in this, but we now need to
delivering optimum levels of IAQ for good health
structures become increasingly energy efficient work towards a more sophisticated approach.
and wellbeing.
and airtight, there is a danger that other types of
outdoor air pollution will become trapped in these “Other pollutants can come from a range of
Ana concludes: “We have seen some positive
spaces. sources – everything from general traffic,
steps in the right direction over the past 18
industrial, commercial, agricultural, and domestic
months, as awareness surrounding the effects of
There is the risk that if these are not monitored, activities. As structures become better insulated,
IAQ increases. However, we need to ensure that
they will build up to unsafe levels, ultimately we have to ensure that our ventilation systems
this progress continues, and that we start to adopt
undermining the journey towards healthier indoor are equipped to meet this challenge. One cannot
a more sophisticated approach to monitoring the
air. A more sophisticated approach is therefore mitigate against the invisible, which is where more
air inside our buildings.”
required to move beyond merely measuring CO2, advanced monitoring becomes key.”
and take into account a wider array of pollutants.
Some of the most health-critical pollutants to For more information, please visit:
Ana Cross, AHU product manager at Elta Fans, address are particulate matter (PM), ozone (O3), https://eltagroup.com
comments: “One of the defining features of the nitrogen dioxide (NO2), and total volatile organic
16 HES Magazine | July/Aug 2021News & Products
Keeping medical environments safe, sterile, and protected
from VOC exposure with multisite sensor PID technology
create a complete VOC monitoring solution for
Medical environments, whether that’s the development, manufacture or packing of
them. The Falco fixed fenceline detector has been
pharmaceuticals and medical equipment, must be monitored to the highest levels to
chosen to monitor their European facilities as the
ensure complete compliance and safety for staff and end-users. ION Science’s range of latest and most advanced fixed VOC detection
fixed PID sensors can measure VOC outputs on multiple large sites or single key areas, equipment available. With eight sites identified for
upgrading, three were fitted as a priority in 2021,
using world-leading gas detection technology.
with between 15 and 25 Falco units fitted at each
facility due to their large size.
Having this many Falco units means the customer
has complete monitoring assurance of VOCs
at every stage of production and as fixed units,
the Falco needs little in the way of maintenance
and will reliably record data on VOC exposure
wherever needed. The Falco is enabled with
both Modbus and 4-20mA output protocols for
site-wide networking capabilities. This gives
the customer total confidence that all products
and site locations are sterilised within the legal
requirements
Not only does the Falco fixed fenceline detector
provide complete assurance across sites of
any size, other benefits include a user-friendly
interface and an easy-fit and service design. The
internal lamp comes with a minimum of a one-year
lifespan, giving customers reliability and peace of
One of the most important areas for VOC (volatile that the correct levels are being adhered to at
mind. Falco has four detection ranges available,
organic compounds) monitoring is sterilisation particular stages, but also there is a requirement
including 0–10ppm, 0–50ppm, 0–1,000ppm and
and packaging. Many medical manufacturers to have many sensors on and around the site so
0–3,000ppm, ideal for any level of sensitivity
use ethylene oxide for decontamination of any potentially harmful levels are detected quickly.
monitoring.
products prior to leaving the site. While this is a
highly effective method, it is a harmful VOC and The Falco fixed fenceline detector from ION
ION Science is proud to be supporting the
needs careful monitoring via PID (photoionisation Science, a leading global OEM of gas detection
medical and pharmaceutical sectors with their
detection) technology to ensure the right levels equipment, is ideal for medical applications
advanced PID technology and VOC gas detection
are used to remove potential contaminants, but thanks to its excellent VOC sensitivity, advanced
instruments for safe working environments and
also so that the ethylene oxide is removed safely PID technology and large detection range.
end-products. By working with customers on the
prior to distribution. What makes it especially suitable for medical
and pharmaceutical applications is not only this ground to equip their sites and find solutions, ION
For manufacturers that handle large volumes of technology, but also ION Science’s in-depth Science continues to advance and develop their
products or operate across multiple sites, ethylene knowledge and experience of the sector. portfolio to improve safety and health for all.
oxide will be used frequently and at many stages
of the manufacturing cycle. This requires not ION Science is currently working with a global www.ionscience.com
only highly sensitive levels of detection to ensure sterilisation and medical equipment specialist to
HES Magazine | July/Aug 2021 17Explosion Protection
No more paper: efficient mobile access
management with tablets for hazardous areas
The security aspect of the SHE system also
As part of a digitization offensive, a petrochemical company in East
includes managing access authorisations to the
Asia searched for the perfect mobile device for its access management. petrochemical plants, not only for the company's
Ease of use, efficiency and security – the Tab-Ex® tablet series for own employees, but also for suppliers or service
providers. The modernization of this process
hazardous areas from ECOM Instruments scores well on all of these
is part of the company’s digitization campaign.
criteria and helped to significantly speed up the processes. Until now, this process has been analogue: the
data required for access authorisation were
recorded manually and passed on in paper form
to the respective plant managers for approval.
With subcontractors for example, this includes
the order, authorization, expected duration and
exact location within the plant (hazardous or
non-hazardous area). Depending on the current
location and workload of the plant manager, this
authentication process involved long waiting
periods for the external workers deployed.
The new digital SHE platform is designed to
significantly speed up and streamline this process.
The plant managers receive the applications
of external workers, including all relevant
information, digitally and can approve them in real
time, regardless of location.
Secure helper for process digitisation
As part of the digitalisation process, the
South Korea's industry is going digital – one system (SHE). Existing analogue processes petrochemical company went in search of a
reason for this change are definitely the incentives are gradually being replaced by more efficient, flexible terminal certified for hazardous areas
provided by the South Korean government. For that met the requirements of the digital platform.
digital alternatives, while artificial intelligence
companies in the oil and gas industry as well as The first choice to make was the choice between
and big data are to help with the future-oriented
in the petrochemical industry, the challenge is to smartphone and tablet. The company decided on
optimisation of processes. Goal is this to result in a
adapt the technologies required for the digitization using tablet, as the larger display offered more
significant increase in efficiency in the processes,
of processes to their special requirements convenient operation for their specific needs.
also through faster and uncomplicated availability
especially in terms of safety. The devices have Looking at general compatibility, Android showed
of all relevant data and information. Since the
to be certified for DZ1 and DZ2, to name just one to be the preferred operating system harmonising
start of the digitization offensive in 2017, many
challenge. best with the proprietary digital platform. LTE and
areas now use cutting-edge technology: drones 4G connectivity were also an important criteria to
and thermal imaging cameras are used for the be independent of Wi-Fi even in remote locations.
Core of the planned digitalisation strategy of
inspection of petrochemical plants; maintenance The main decisive factors were IT security, fast
a petrochemical company in South Korea is
the development of a digital platform for the is carried out predictively and risk-oriented on-site support and the possibility to carry out
safety, health and environment management flagged by intelligent systems. configuration and software updates over-the-air.
18 HES Magazine | July/Aug 2021Explosion Protection
Access management made efficient requested, they can easily apply for the extension
of their stay digitally. Through mapping functions
All these requirements are met by the intrinsically
A total of 70 Tab-Ex® tablets now support the
on the integrated software solution as well as the
safe Tab-Ex® tablets by the Pepperl+Fuchs brand
digital workflows in the petrochemical plants.
push-to-talk function (PTT), which enables rapid
ECOM Instruments. Based on the Samsung Tab
Employees, suppliers, external workers and
Active tablet and Android as operating system, communication even in case of an emergency,
other visitors no longer apply for access to the
Tab-Ex® reliably covers updates, configuration Tab-Ex® ensures the safety of the workers
petrochemical plants on paper, but register
and OEM support from Samsung in a user- throughout the entire assignment.
digitally in the associated software on the tablets.
friendly manner. Highest IT security standards are
All the data required for the authentication
ensured by Samsung Knox – the most popular
procedure, including the qualifications and a This not only significantly speeds up the
cybersecurity solution on the Korean market.
picture of the respective person, are stored there. authentication process, but also ensures
Last but not least, the Tab-Ex® series opens up
The site managers receive the access request
a multitude of additional application scenarios complete traceability of data and thus security
digitally in real time on their own ECOM tablet. This
in line with the company's digitization strategy within the facility. With the help of the new digital
way they have an overview at all times of which
by supporting augmented reality (AR), RFID and solution and ECOM's tablets, plant managers not
persons with which qualifications are entering
barcode scanning.
the facility for what reason, for what period of only save time but also save 10 percent in costs.
time and for what activity. Those responsible can At the same time they are saving on space and
process these requests quickly on the tablet, even
resources: fewer paper documents need to be
remotely. The access authorisations, including
properly stored on site or transported between
all data and documents required for them, are
locations.
centrally saved on the company's digital platform.
Tab-Ex® also accompanies workers for the For more information, please visit
duration of their assignment. If, for example,
ECOM’s website: www.ecom-ex.com
service providers need to stay on the company
and www.pepperl-fuchs.com
premises for a specific task longer than originally
HES Magazine | July/Aug 2021 19News & Products 20 HES Magazine | July/Aug 2021
Explosion Protection
Early and central fire gas detection
GSMX-P: Fire gas detection in filter systems
The handling of bulk solids poses many challenges. One of these challenges is the
enormous amount of dust that is created by conveying and processing the different
products. In order not to unnecessarily strain the process and employees on site and to
expose them to risks, these enormous amounts of dust get extracted.
Fig. 1: Phases if fire development
Fig. 2: GSMX-P design
How does the GSMX-P work?
The GSMX-P fire gas detector monitors the entire
cross-section of the clean gas / ventilation line.
For this purpose, it is attached to the line in a
separate housing. Two pipes protruding into the
clean gas / ventilation line generate continuous
air extraction over the entire cross-section using
the Venturi principle. The design not only enables
representative and reproducible monitoring, but
also dispenses with further electrical aids such as
pumps or fans.
Where is such system used?
Almost every process in every industry can be
monitored with a GSMX-P in a filter. Because it
is a complex system for monitoring multiple gas
components, factors such as the following are
considered:
When do which fire gases arise?
This is the first step in the direction of fire and • Air flow rate m³ / h
explosion protection, because dust clouds of • Flow velocity and pipe diameter
Depending on the bulk material, certain fire gases
flammable powders in the right mixture ratio to arise earlier, later or only to a limited extent. In order • The amount of dust in the air
oxygen always represent a great danger. to cover exactly this point, REMBE relies not only • Bulk goods (fire and explosion parameters)
on the measurement of carbon monoxide (CO) The sensor is installed in the process and gets used
Despite accurate dedusting of the machines, there but also on hydrogen (H2), hydrocarbons (HC) to the process and the conditions in the first step.
and nitrogen oxides (Nox). In this way, monitoring
is still a high fire risk with corresponding bulk goods. This makes it possible to create an exact picture of
can be set flexibly and precisely to process and
So how can this risk be contained? the conventional gas concentrations to then find
material.
Filter systems represent a central point in most the optimal limit value for each application. This is
industrial systems because the air extracted from Advantage of a GSMX-P fire gas usually just above the conventional concentrations
the various machines is usually bundled and monitoring system: in order to detect even the smallest deviations and
guided through a pipe / exhaust duct after the filter to prevent a fire.
Fire gases arise at a very early stage of a fire. This
elements. Precise monitoring of fire gases within
means that the GSMX-P does not have to wait for
this pipeline enables fire incidents to be detected For more information visit:
heavy smoke to develop but alerts as soon as the
at an early stage not only in the filter but in all www.rembe.com
gas concentrations in the exhaust air exceed the
connected machines and system parts. conventional range.
HES Magazine | July/Aug 2021 21Explosion Protection
New EJBC series explosion-proof enclosures
for gas group IIC of Cortem Group
starter boxes with various configurations.
The new enclosures of the EJBC series are characterized by a multi-
step joint that allows the installation in areas with danger of explosion These enclosures are customized based on size,
on the number of terminals or cables they are due
and/or fire due to the presence of all the Gases of Group IIA - IIB - to accommodate or considering the number of
IIC classified as Zone 1, 2, 21, 22. cable entries and cabling requirements inside a
system.
All terminals can be fitted with your requested
accessories and mounted on special rails that
are fastened to the enclosure's internal mounting
frames.
Terminal strips can be arranged in various ways,
as specified by the customer and always within the
limits allowed by the certificate.
The options are vertical, horizontal, in several
rows, or on different levels using suitable spacers.
The quality of this product is recognized and
valued the world over for its specific aluminium
alloy and the mechanical property of its finishes.
Plus
• Group IIC: Acetylene (C2H2), Carbon
disulphide, Hydrogen (H2)
• IP66/67
• Stainless steel hinges
• Available with round or square window for
viewing analog or digital instruments
Construction
• Body and lid in low copper content
aluminium alloy
• Stainless steel cover bolts
• Internal/external earth screws
This is the element that distinguishes the new easy opening/closing of the enclosure in case
• RAL 7035 polyester coating
EJBC series enclosures from the historic EJB of maintenance, thanks to the high quality and
series enclosures characterized instead by a flat precision of the mechanical processing. • Galvanized steel mounting brackets
flanged joint and suitable for the IIB + H2 gas
The EJBC series is mostly used as a box to carry • Silicon gasket
group.
terminals and busbars, fuse carriers, transformers,
The multi-step joint has been designed with reactors, and barriers, though it is also used to
For more information visit:
an angle that guarantees not only the precise produce control and signalling boards, light and
www.cortemgroup.com
coupling between body and cover, but also an power boards and surge arresters, and motor
22 HES Magazine | July/Aug 2021HES Teams Chosen Products
Snickers LiteWork Workwear
– making light work of warm weather.
Snickers Workwear = Comfort = Wellbeing and Improved Performance.
The 2021 LITEWork clothing range delivers great comfort and functionality of other Snickers
thermal comfort in warmer months with light, Workwear stretch garments delivering extra
quick drying fabrics that will keep you cool and freedom of movement and improved performance
comfortable all day. on site.
The new range of ‘Rip Stop’ shirts are stretchy Just like high performance sportswear, they’ll also
and breathable, offering UPF50+ sun protection – keep you feeling cool and looking smart whatever
great for craftsmen who work long hours outdoors.
you’re doing and wherever you are on site this Getting more information on the
While 37.5© fabric technology in the mid-and
summer. Snickers Workwear clothing range
base-layer garments have features for efficient is easy. You can call the Helpline
ventilation and moisture transport to keep you on 01484 854788; check out www.
So, to make sure you get the right protection,
comfortable all day. snickersworkwear.co.uk and
flexibility, durability and ventilation, check out the
download a digital catalogue or email
Snickers Workwear LiteWork range for precisely sales@hultaforsgroup.co.uk
The ergonomic, body-mapping Trousers, Shirts,
Shorts, Jackets and Windproofers have all the the right garments to fit your workday.
Keep Your Hands Comfortable and Protected
Work Gloves for Healthy Hands that deliver Precision and Protection
Snickers Workwear now has an extensive What’s more, for specialist use where health and
collection of Work Glove styles in a wide range safety standards are key requirements, the Gloves
of sizes, developed for different workplaces and are EN certified for performance and protection in
tasks - designed for dexterity, durability, comfort hazardous and foul weather environments.
and precision.
Getting more information on the
With advanced features and material
Snickers Workwear Gloves Range
combinations, there’s something to suit a wide
variety of trades, and workplaces, weather is easy. You can call the Helpline on
conditions and hazardous environments.
01484 854788; check out
https://www.snickersworkwear.co.uk/
Added to which the advanced ergonomic designs
products/109 and download a digital
ensure strong, secure grips while sophisticated
patterns, vents and ribs combined with durable catalogue or email
materials deliver cut-protection, ventilation,
sales@hultaforsgroup.co.uk
waterproofing and insulation.
HES Magazine | July/Aug 2021 23HES Teams Chosen Products
Raising and communicating
H&S issues needs to be simple.
potential hazards”.
Providing information and communicating with staff and colleagues in the workplace
is essential, particularly when hazards, incidents or near-misses occur which may Sited at the entrance to the work area, a risk/
impact on others. An effective, low-cost solution to ‘getting the message across’ is the hazard is noted on a card and then placed in the
board alerting everyone who enters that area.
Near Miss / Incident Reporting System available from T Cards Direct which is an easy
Once attended too the card is moved from the
way to manage and document health and safety issues. ‘Issue Raised’ section to the ‘In Progress’ section,
then turned around to green when safe.
Compliance and accountability is essential in the international manufacturer of convenience The Near Miss / Incident Reporting System is
work place and a simple T Board can provide a foods with 22 manufacturing sites in the UK. one of a range of display and information systems
record and history with traceability from the time David Brady, Health and Safety Manager at the available from T Cards Direct who offer over 45
the incident occurred to the issue being signed Greencore Evercreech comments, “Safety is of years of experience in providing effective and
off. All through the process the status is shown paramount importance at our site and identifying affordable information systems.
providing transparency which in turn encourages and communicating potential hazards to all staff is
staff engagement. a crucial part of our health and safety practices”.
David continued, “The T Cards Incident Reporting Visit us here for more information:
A great example of the Near Miss / Incident
System has proven to be an effective and very www.tcardsdirect.co.uk/index.php/
Reporting System making a positive impact
visible way of informing our staff of the situation near-miss-reporting-system.html
has been the Greencore Group plc, a leading
and status of incidents whilst warning them of
24 HES Magazine | July/Aug 2021You can also read
