POOL DEHUMIDIFIERS
Pool dehumidifiers
Efficient room climate
for private pool and wellness areas
1-2014
Quality with systems
POOL DEHUMIDIFIERS
SLE series
The exclusive dehumidifier
for private whirlpool and bathroom areas
REMKO SLE 20
REMKO SLE 20
In addition to heating, the humidity in the air is an important Protect yourself from damaging moisture and upgrade with low
factor for your well-being. If the air is too damp, then it is maintenance pool dehumidifiers from REMKO.
perceived as muggy and unpleasant. In addition, excessive
humidity can damage the building substance and provide
spores and fungus with an ideal place to grow. Easy installation Very quiet operation
The REMKO SLE 20 removes excessive humidity from the air Easy-to-service structure Eliminates formation of
and thereby provides a balanced and healthy room climate. Our spores and moulds
Up to 60% more economical
modern dehumidifier systems are up to 60% more economical
than the traditional ventila- Prevents condensation on
than traditional ventilation and heating. The easy-to-install and
tion and heating systems windows, walls, and pool
almost noiseless units with their decorative design can be used
fixtures
for your exclusive pool and private whirlpool area. Modern design
Ideal for your exclusive pool Great for whirlpool spas
2
Areas of application
Exclusive swimming pools
Whirlpool areas
Fitness studios
Basements
Technical data
Series SLE 20
Daily dehumidification capacity at 30°C and 80% relative humidity Litre/day 10.5
Daily dehumidification capacity at 30°C and 60% relative humidity Litre/day 7.5
Operating temperature range °C 3-30
Operating humidity range % relative humidity 40-100
Air capacity m³/h 220
Voltage supply V/Hz 230/1~/50
Max. power consumption kW 0.39
Max. current consumption A 2.1
Refrigerant R134a
Refrigerant, filling quantity kg 0.17
Noise level* dB(A) 46
Depth mm 240
Width mm 535
Height mm 600
Weight kg 28
Ref. no. 615200
Other accessories
Condensate container, 6 litres
Ref.. no. 1011405
REMKO SLE 20 with condensate * Distance 1 m
container
3
POOL DEHUMIDIFIERS
SLE series
The exclusive dehumidifier
for private pool and wellness areas
REMKO
SLE 60
REMKO SLE 40-80
Series SLE 40-80 has been designed for private pools, larger Easy installation Very quiet operation
whirlpool installations, and other rooms with high humidity.
Easy-to-service structure Eliminates formation of
The unit removes excessive humidity from the air and thereby
spores and moulds
provides a balanced and healthy room climate. With their Up to 60% more economical
modern design, the devices integrate discreetly into every room. than traditional ventilation Prevents condensation on
You can update your pool without any problems with the low and heating windows, walls, and
maintenance pool dehumidifiers from REMKO. bathroom fixtures
Modern design
Integrated hygrostat
Problem-free continuous
operation
The technology in detail
The moist air from the pool
area is drawn in with the aid
of a quiet fan. The air cools
below the dew point as it passes
through the evaporator and
Warmer, dry air the water vapour condenses
into water, which can then be
REMKO discharged. The air, which is
SLE series
now dry, then flows through the
condenser and is heated and
returned to the pool building or
Warm, humid air bathroom.
The units can be easily cleaned
by removing the front cover.
Pool area
4
Areas of application
Private pool areas
Wellness spas
Fitness studios
Storage rooms, archives
Museums
Technical data
Series SLE 40 SLE 60 SLE 80
Daily dehumidification capacity at 30°C and 80% relative humidity Litre/day 50.4 70.8 100.8
Daily dehumidification capacity at 30°C and 60% relative humidity Litre/day 32.2 43.2 64.0
Operating temperature range °C 10-36 10-36 10-36
% relative
Operating humidity range 40-100 40-100 40-100
humidity
Air capacity m³/h 250 500 750
Voltage supply V/Hz 230/1~/50 230/1~/50 230/1~/50
Max. power consumption kW 0.72 1.05 1.65
Max. current consumption A 2.8 4.3 7.2
Refrigerant R407C R407C R407C
Refrigerant, filling quantity kg 0.60 0.95 1.60
Noise level* dB(A) 47 49 51
Depth mm 315 315 315
Width mm 950 1260 1800
Height mm 800 800 800
Weight kg 60 74 101
Ref. no. 615400 615600 615800
Other accessories
Room hygrostat, Type HR-2
Ref. no. 1011400 1011400 1011400
Stand support, set
Ref. no. 1011410 1011410 1011415
* Distance 1 m
5
POOL DEHUMIDIFIERS
SLN series
Strong in capacity
Easy installation in the next room
REMKO SLN 60
REMKO SLN 40-80 Orientation for device selection in the pool area.
For easy installation in the next
room.
Size of the pool in
m2 Areas of application
With the SLN Series, you have SLE 40 / SLN 40
the possibility to install the units ■ Private pool areas ■ Storage rooms
SLE 60 / SLN 60
in the room next to the room to
■ Wellness spas ■ Archives
be dehumidified. The connec- SLE 80 / SLN 80
tion between the device and 10 20 30 40
■ Fitness studios ■ Museums
the room to be dehumidified
is established through the air
channel. Only ventilation
louvres are visible in the pool Next- room set
area. Technically, the SLN Series The next-room set consists of:
Swimming pool Next room 1 x grille fitting connection for
does not differ from the SLE a non-screwed clamp fitting
series. 2 x appliance connection
of the recirculation-air grille
adapters with an additional mounting
The correct unit selection including pressure-tight frame for a recirculation-air
plastic profile lips filter
The correct selection of a unit
2 x wall connections 2 x air grilles made of alumin-
depends mainly on the water REMKO consisting of surface-coated ium with a perimeter front
surface of the pool. The graphic SLN steel plate for a wall thick- frame and fixed horizontal
(right) is only intended for ness of max. 240 mm profile fins
simplistic orientation. The exact 1 x grille fitting connection for 1 x recirculationair intake filter
selection of a unit depends on a non-screwed clamp fitting
several factors, such as air and of the supply-air grille
water temperature and frequency
of use, as well as whether a
cover is used over the pool area. Dimensions supply-air/circulation-air channel*
For that reason, the selection Series SLN 40 SLN 60 SLN 80
should always be calculated by Height mm 126 126 126
qualified expert personnel. Width mm 407 717 1255
Length mm 235 235 235
* Wall opening circular 5 mm larger
6
Technical data
Series SLN 40 SLN 60 SLN 80
Daily dehumidification capacity at 30°C and 80% relative humidity Litre/day 50.4 70.8 100.8
Daily dehumidification capacity at 30°C and 60% relative humidity Litre/day 32.2 43.2 64.0
Operating temperature range °C 10-36 10-36 10-36
Operating humidity range % relative humidity 40-100 40-100 40-100
Air capacity m³/h 250 500 750
Voltage supply V/Hz 230/1~/50 230/1~/50 230/1~/50
Max. power consumption kW 0.72 1.05 1.65
Max. current consumption A 2.8 4.3 7.2
Refrigerant R407C R407C R407C
Refrigerant, filling quantity kg 0.6 0.95 1.6
Noise level* dB(A) 44 46 48
Depth mm 280 280 280
Width mm 890 1192 1732
Height mm 680 677 677
Weight kg 57 68 95
Ref. no. 615405 615605 615805
Other accessories
Room hygrostat, Type HR-2
Ref. no. 1011400 1011400 1011400
Next-room set SLN: Multi-part next-room set consisting of surface
compensated steel plate for recirculation air/supply air, including an
aluminium air grille and a circulation air filter
Ref. no. 1011435 1011440 1011445
* Distance 1 m
7
