JANUARY 2020
MARCA ITALIA
Technical Molding & Products Engineering
ROMANIA
MARCA ROMANIA
Technical Molding & Assembly
ITALIA
STAMPI SETTE
Design & Mold construction
MARCA ITALIA
HISTORY PRODUCT
1971 – Marca was founded Design and mould maker for plastic materials and
2002 – opening of a Romanian Plant precision moulding of technical part
2004 – obtaining the ISO TS 16949:2000 certification
2011 – opening pad-painting and laser marking dpt.
2012 – obtaining the certification as UL moulder
2015 – add MuCell® process by Trexel SERVICES
2016 – the production starts in the NEW ITALIAN plant
(6.500 m2 covered + 15.000 m2 uncovered) The MARCA R&D is able to solve all the technical
2018 – Certification IATF 16949:2016 request about the products:
– Implementation FACTORY 4.0 in all process
part engineering, the choice of the materials and
2019 – installation of Tomography center
solve problems of moulding, also using the
simulation software VISI-FLOW.
SOFTWARE
CAD 2D: AutoCAD
CAD 3D: VISI-Solid + MICROSYSTEM
CAD-CAM 3D: MICROSYSTEM
Simulation POM: CAMDO (Du Pont)
Mould simulation: VISI-FLOW
MARCA ITALIA
TOMOGRAPHY CENTER
Maker: WERTH
Model: TOMOSCOPER-XS
- Measure Completely and Accurately
- Implementation on production process
- Implementation on new product process
- Technology:
X-Ray
- Max Part Dimension:
Dmax 205 mm
Lmax = 98 mm
- Maximum permissible length INSTALLATION
measurement error: ON JUNE 2019
Down to 6.5 µm
MARCA ITALIA
CERTIFICATE
INSTALLATION
ON JUNE 2019
IATF 16949:2016 UNI ISO 9001:2015
MARCA ITALIA
CERTIFICATE UL
Marca in 2012 acquired the UL certification as
a producer of articles (category QMMY2) and is
therefore qualified partner for all customers who
have products with UL mark
INSTALLATION
ON JUNE 2019
MARCA ITALIA
PRODUCTION UNIT QUALITY
Thermoplastic Dept. Quality Device for dimensional control:
Presses: from 10 to 250 ton. Our High Quality is guaranteed by - Tridimensional contact control
Part weight: from 0.1 to 300 gr. severe controls - Tridimensional optical control
Raw material: Automatic feeding and drying process Control device on finished part - Gears control device
Handling: Cartesian robot on all presses & plastic material - Blocks with SIT certificate
Special: MuCell® process by Trexel on 150 ton - Caliber e micrometer
Special: Automatic rework or packaging - Melt index for amorphous, PBT,PET
Factory 4.0: all presses and devices are linked to - Viscosimeter for PA Special dimensional control:
infomratic system manager - Humidity check by Karl Fischer method
- Internal Tomography Center (Rx Ray)
- Ash control device (hoven)
Thermoset Dept. - Balance to obtain the specific weight
- Balance to determinate the raw material humidity
Press injection, transfer e compression from - Roughness control device
50 to 300 ton.
Roughness control device Gears control device
MARCA ITALIA
MAINTENANCE HUMAN RESOURCE FINAL PROCESSING
Maintenance equipements Our team: 54 units We also provide different kinds of
final processing.
- n° 2 milling machines - R&D, 5
- Assembly
- n° 2 erosion (wire and die sinking) - Mantenance, 5
- Laser Marking
- n° 3 grindings - Moulding, 26 - Pad printing
- n° 2 ultrasonic washing machines - Logistic, 5 - Painting
- n° 1 cold welding machines - Quality, 6 - Ultrasonic Welding
With our advanced equipment we can - Commercial, 5
provide all maintenance needs. - Administration, 2
Laser Marking
Ultrasonic Welding
Maintenance Automatic rework
Roughness control device Pad Printing Painting
TURNOVER FOR COMMERCES FIELDS GROUP TURNOVER
28,97
27,88
Different Electronic Home appliance Electric Automotive
27,9
26,5
22,4
Different
19%
Automotive
Electronic 2014 2015 2016 2017 2018
45%
13%
TURNOVER [mln €]
Home appliance
14%
Electric Marca Italia* 18,219 17.849 16,900 17,350
9%
Marca Romania 7,394 9.180 11,180 9,460
Stampi Sette 0,900 0,910 0,890 1,070
*Project Cube from 2017 is included in Marca ITALIA
OUR PRODUCTS
AUTOMOTIVEOUR PRODUCTS
ELECTRICAL
DIFFERENTOUR PRODUCTS
STAMPI SETTE
Tooling dept
HISTORY
Stampisette s.r.l. born in 2006 by the division
Tooling of Marca s.r.l. leader in the design and
construction of molds for plastics engineers.
Product unit specialized as mould maker of high
precision tools.
OUR MISSION
Our organization has the objective constant
customer satisfaction through quality products and
service.STAMPI SETTE
OUR TEAM MACHINERIES
Our team: 7 units Our team has the most modern CNC tools:
- CAM, 2 - N°2 Wire electroerosion CNC (Robofil)
- N°2 Die-sinking electroerosion CNC Copper and Graphite (Roboform & Makino)
- Tooling operator, 5 - N°4 high speed milling for Cupper and Graphite (Makino & Mikron)
- Control device for copper electrodes
TOOLING - Control device and pre-setting tools
- Sharpening
The most representative machines are: - Round grinding
- wire electroerosion cnc, - Planar grinding
- die-sinking electroerosion,
- high speed 3 axes milling,
- turning cnc, vertical drill,
- high speed drill,
- planar and round grinding with diaform.
AND MORE OTHER TOOL
- Turning
- Pantograph
- High deep drilling
- Different traditional toolsMARCA ROMANIA
MARCA ROMANIA
HISTORY COMPANY PROFILE
2003 – opening of a production site in Romania for the Design and manufacture of plastic material molds
thermoplastic and thermosetting MOLDING and molding of Thermoplastic and Thermosetting
high precision technical articles
2004 – opening of ASSEMBLY dept.
2005 – opening of TOOLING dept.
2006 – certification ISO TS 16949:2002
MISSION
2009 – started the construction of new factory Provide quality products, moulds and assemblies at
2012 – NEW FACTORY ready to go… low price
2014 – expansion of 2.000 m2
2018 – certification IATF 16949 2016MARCA ROMANIA
INSTALLATION
ON JUNE 2019
IATF 16949:2016 UNI ISO 9001:2015NEW FACTORY THERMOPLASTIC DEPT.
More than 6.500 m2 N°58 Press from 10 to 370 ton (Part weight from 0,1 gr to 1.000 gr)
N°2 Bi-injection press 120 Ton
N°4 Vertical press 80 Ton with rotative plate
N°2 Vertical press 60 Ton with linear table
N°1 Babypress
MARCA ROMANIA
HUMAN RESOURCE
Our team: 250 units - Mould making & Mantenance, 14
Moulding dpt - Moulding dpt., 66
- Asembly dpt., 143
- Logistic, 7
- Quality, 10
- Office / Administration, 10
SERVICES
MOULDS MAKING PAD PRINTING FINISHING
MOULDING WELDING
Assembly dpt. ASSEMBLY OVERMOLDINGMARCA ROMANIA
TOOL SHOP METROLOGY
- 2 Wire Electroerosion CNC - 1 Milling SUPERMAX
- 3 Die Sinking Electroerosion - 2 Planar grinding
- 1 High Speed Mill -1 Rotatory grinding
- 2 Milling CNC KELLENBERGER
- 1 Drilling horizontal - 3 Lathes
- 2 Welding devices
3D Optical 3D contact
Tool shop Electroerosion
Automotive PRODUCTS DifferentMARCA ROMANIA
LOCATION
MARCA ROMANIA BUCHAREST
Sat Ciresu, Comuna Cateasca - A1 Km 94; Iesire
PITESTI
Ciresu
100 KmCONTACTS
MARCA srl
MARCA Via Ticino 74, 20014 Nerviano (MI) Italia
ITALIA Tel. +39 0331.406311 E-mail: info@marcagroup.it
www.marcagroup.it
SC MARCA ROMANIA srl
MARCA Cateasca, Coseri 144D Arges 117220, Pitesti-ROMANIA
ROMANIA Tel. +40 248.661099 Fax: +40 248.661199 E-mail: : info@marcagroup.it
www.marcagroup.it
STAMPI SETTE s.r.l.
STAMPI Via 1° Maggio 25, 20014 Nerviano (MI) Italia
Tel. +39 0331.588864 E-mail: stampisette@stampisette.it
SETTE www.stampisette.itYou can also read
