PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)


PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
APPLICATION FOR ENVIRONMENTAL CLEARANCE
                                    OF
 “PROPOSED INFRASTRUCTURE FOR
 BUILDINGS AT CISF CAMPUS (GBS)”

                                    At
                        Mahipalpur, New Delhi

                         Being Developed By: -
             CENTRAL INDUSTRIAL SECURITY FORCE

                  16/11, Jam Nagar House, New Delhi-110011

                              Prepared by:
                         Environmental Consultant
           M/S PERFACT ENVIRO SOLUTIONS PVT. LTD.
(NABET Registered wide list of accredited consultants organizations/ Rev 26/
                     8th January, 2015 at S.No-110)
           502-507, NN Mall, Sector-3, Rohini, New-Delhi-85
         Phone: 011-47528467; 011-47021086, Fax: - 011-47528434
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                                    By Central Industrial Security Force
                                                       TABLE OF CONTENTS
                        FORM 1 & 1A ......................................................................................................... 4

                        CONCEPTUAL PLAN .............................................................................................. 37

             INTRODUCTION........................................................................................................................... 38
             ACTIVITIES/ AMENITIES ................................................................................................................ 38
             SITE LOCATION ........................................................................................................................... 38
             TYPE OF PROJECT ........................................................................................................................ 38
             PROJECT DETAILS ........................................................................................................................ 38
             POPULATION DETAILS .................................................................................................................. 39
             WATER MANAGEMENT ................................................................................................................ 39
             RAIN WATER COLLECTION DETAILS ................................................................................................. 39
             POWER REQUIREMENT& BACK-UP ................................................................................................. 39
             SOLID & HAZARDOUS WASTE MANAGEMENT .................................................................................. 39
             PARKING MANAGEMENT .............................................................................................................. 40
             GREEN AREA DEVELOPMENT......................................................................................................... 40

                        ENVIRONMENT REPORT ....................................................................................... 41

          EXECUTIVE SUMMARY OF THE PROJECT ................................................................................ 43
     3.1.1   Activities: ........................................................................................................................... 43
     3.1.2   Description & Details of Project: ........................................................................................ 43
          INTRODUCTION OF THE BACKGROUND INFORMATION......................................................... 44
     3.2.1 Brief Description of the Nature of the Project: .................................................................. 44
          PROJECT DESCRIPTION ........................................................................................................... 44
     3.3.1 Land Use and Ownership of the site land .......................................................................... 44
     3.3.2 Location of the project with connectivity........................................................................... 45
          RESOURCES ............................................................................................................................... 47
     3.4.1 Water Resource Management........................................................................................... 47
     3.4.2 Energy Resource Management .......................................................................................... 49
          SITE ANALYSIS ........................................................................................................................ 49
     3.5.1 Eco-sensitive areas with distance from project location ................................................... 49
     3.5.2 Annual Windrose Diagram ................................................................................................ 50
     3.5.3 Social Infrastructure available ........................................................................................... 50
          PROPOSED INFRASTRUCTURE ................................................................................................ 51
     3.6.1 Types of Buildings & Activities Proposed ........................................................................... 51
          ENVIRONMENT MANAGEMENT PLAN ................................................................................... 51
     3.7.1 ENVIRONMENT MANAGEMENT DURING CONSTRUCTION................................................ 52
     3.7.2 ENVIRONMENT MANAGEMENT DURING OPERATION ...................................................... 53
          ANTICIPITATED IMPACT & MITIGATION MEASURES .............................................................. 61
     3.8.1 DURING CONSTRUCTION PHASE........................................................................................ 61
     3.8.2 DURING OPERATION PHASE .............................................................................................. 62
          ENVIRONMENT MONITORING PLAN ...................................................................................... 63

                        DISCLOSURE OF THE CONSULTANT....................................................................... 65

                        LAND PAPERS ....................................................................................................... 67

                        LANDSCAPE PLAN................................................................................................. 68

                        RAIN WATER HARVESTING PLAN.......................................................................... 69

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                                                                    2
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                              By Central Industrial Security Force
                    DUAL PLUMBING PLAN ........................................................................................ 70

                    FIRE FIGHTING PLAN ............................................................................................ 71

                       FIRE EVACUATION PLAN ................................................................................... 72

                       SURFACE PARKING PLAN .................................................................................. 73

                       AAI APROVAL ................................................................................................... 74

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                                                    3
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force

                                                 FORM 1 & 1A

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           4
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                               APPENDIX I
                                            (See paragraph – 6)
                                                 FORM 1

      (I) Basic Information

 S.No.      Item                                      Details

 1.         Name of the project/s                     Proposed Infrastructure for Buildings at CISF
                                                      campus (GBS)

 2.         S. No. in the schedule                    8(a)
 3.         Proposed               capacity/          Plot Area-62100 sqm
            area/length/ tonnage to be                Built-up area- 47455.37 sqm
            handled/ command area/
            lease area/ number of wells to
            be drilled
 4.         New/                 Expansion/           New
            Modernization
 5.         Existing Capacity/ Area etc.              No
 6.         Category of Project i.e. ‘A’ or           B
            ‘B’
 7.         Does it attract the general               No
            condition? If yes, please
            specify.
 8.         Does it attract the specific              No
            condition? If yes, please
            specify.
 9.         Location                                  Mahipalpur
            Plot/ Survey/ Khasra No.                  -
            Village                                   Mahipalpur
            Tehsil                                    South West Delhi
            District                                  South West Delhi
            State                                     New Delhi
            Nearest      railway    station/          New Delhi Railway Station- 13.5 km- NE
 10.        airport along with distance in            IGI Airport- 2km- NE
            kms.
            Nearest Town, city, District              Project is in Delhi itself.
 11.        Headquarters along with
            distance in kms.

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           5
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
            Village   Panchayats,    Zilla            Municipal Corporation of Delhi in South
            Parishad,           Municipal             Delhi.
            Corporation,   Local   body
 12.
            (complete postal addresses
            with telephone nos. to be
            given)
 13.        Name of the applicant                     Central Industrial Security Force
            Registered Address                        16/11, Jam Nagar House, New Delhi-
 14.
                                                      110011
            Address for correspondence:               16/11, Jam Nagar House, New Delhi-
 15.
                                                      110011
            Name                                      J.W. Khan
            Designation                               DIG (GBS)
            (Owner/Partner/CEO)
            Address                                   16/11, Jam Nagar House, New Delhi
            Pin Code                                  110011
            E-mail                                    sgagoffice@gmail.com
            Telephone No.                             0120-2552217
            Fax no.                                   0120-2552217
 16.        Details of Alternative Sites              The land is allotted by DDA vide allotment
            examined, if any. Location of             letter no. F20(3)72/IL Dated 21/11/2005 to
            these sites should be shown on            CISF.
            a topo sheet.
 17.        Interlinked Projects                      No
 18.        Whether separate application              Not Applicable
            of interlinked project has been
            submitted?
 19.        If yes, date of submission                Not Applicable
 20.        If no, reason                             Not applicable
 21.        Whether the proposal involves
            approval/clearance under: if
            yes, details of the same and
            their status to be given.
            (a) The Forest (Conservation)             Not Applicable
                 Act, 1980?
            (b) The Wildlife (Protection)             Not Applicable
                 Act, 1972?
            (c) The C.R.Z. Notification,              Not Applicable
                 1991?

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           6
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 22.        Whether       there     is   any Delhi Master Plan 2021 is applicable.
            Government Order/ Policy
            relevant/ relating to the site?
 23.        Forest land involved (hectares) No forest land is involved.
 24.        Whether there is any litigation
            pending against the project Nil
            and/ or land in which the
            project is propose to be set up?
                (a) Name of the Court
                (b) Case No.
                (c) Orders/ directions of
                    the Court, if any and its
                    relevance with the
                    proposed project.

    (II) Activity
1. Construction, operation or decommissioning of the Project involving actions,
   which will cause physical changes in the locality (topography, land use, changes
   in water bodies, etc.)

 S.No. Information/Checklist                          Yes/No        Details      thereof     (with
       confirmation                                                 approximate quantities /rates,
                                                                    wherever possible) with source
                                                                    of information data
 1.1       Permanent or temporary Yes                               This project is a construction of
           change in land use, land cover                           “Proposed Infrastructure for
           or     topography       including                        buildings at CISF campus (GBS)”
           increase in intensity of land use                        at Mahipalpur. The land has
           (with respect to local land use                          been allotted by DDA for
           plan)                                                    development of Infrastructure
                                                                    for buildings at CISF campus
                                                                    (GBS) vide allotment letter no.
                                                                    F20(3)72/IL dated 21/11/2005.
                                                                    Thus the land use will be
                                                                    changed from open land to a
                                                                    developed Infrastructure for
                                                                    buildings at CISF campus (GBS).

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           7
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 1.2       Clearance of existing land, No                           The existing land is an open land.
           vegetation and buildings?

 1.3       Creation of new land uses?                 No            The land use will be changed
                                                                    from open land to a developed
                                                                    Infrastructure for buildings at
                                                                    CISF campus (GBS).
 1.4       Pre-construction investigations                          Soil Investigation report shall be
                                           Yes
           e.g. bore houses, soil testing?                          submitted.
 1.5       Construction works?                                      Construction will be done as per
                                           Yes                      approved Building Plan/ Master
                                                                    Plan.
 1.6       Demolition works?                          No            Demolition work is not required
                                                                    as there are no buildings at the
                                                                    site.
 1.7       Temporary sites used for                   No            Not required as the labour will
           construction works or housing                            be hired from nearby area.
           of construction workers?
 1.8       Above       ground,    buildings,          Yes           Proposed:-
           structures     or    earthworks                          No of Blocks:- 7
           including linear structures, cut                         No of Floors:- G+3
           and fill or excavations
 1.9       Underground works including                No            Not applicable
           mining or tunnelling?
 1.10      Reclamation works?                         No            Not applicable
 1.11      Dredging?                                  No            Not applicable
 1.12      Offshore structures?                       No            Not applicable

 1.13      Production and manufacturing No                         No production or manufacturing
           processes?                                              will be done.
 1.14      Facilities for storage of goods Yes                     During Construction Phase:
           or materials?                                           Separate raw material yard will
                                                                   be made within the project site.
                                                                   Cement will be separately
                                                                   stored under cover in bales.
                                                                   Sand will be stacked neatly
                                                                   under tarpaulin cover. Bricks
                                                                   and steel will be laid in open.
                                                                   During Operation Phase: As the
                                                                   project    is      a     proposed

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           8
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                                   Infrastructure for Buildings at
                                                                   CISF Campus (GBS), the raw
                                                                   material will be food, stationary
                                                                   & other items which will be
                                                                   stored in respective units.
 1.15      Facilities for treatment or                             The excavated earth will be used
           disposal of solid waste or liquid                       to the extent possible and rest
           effluents?                                              will be disposed at authorized
                                                      Yes          landfills site.
                                                                   For the liquid effluent STP is
                                                                   proposed. Details of STP given in
                                                                   EMP.
 1.16      Facilities for long term housing                        The workers during construction
           of operational workers?                                 phase will be hired from nearby
                                                      No           areas and hence no need of
                                                                   housing. Only temporary rest
                                                                   rooms are provided.
 1.17      New road, rail or sea traffic No                        Not applicable
           during      construction      or
           operation?
 1.18      New road, rail, air waterborne No                        Exiting Transportation near to
           or        other        transport                         the site:
           infrastructure including new or                           • Express Highway NH-8, SE-
           altered routes and stations,                                 500 m
                                                                     • Airport- IGI Airport NW- 3 Km
           ports, airports etc?
                                                                     • New Delhi Railway Station-
                                                                        NE- 13.5 Km
                                                                     ● Old Delhi Railway Station-
                                                                    NE- 15.5 Km

 1.19      Closure or diversion of existing No                      No such closure or diversion of
           transport        routes       or                         existing transport will be
           infrastructure     leading    to                         required.
           changes in traffic movements?
 1.20      New or diverted transmission                             No new or diversion of
           lines or pipelines?          No                          transmission lines or pipelines
                                                                    will be done.
 1.21      Impoundment,         damming,                            No impoundment, damming,
           culverting, realignment or                               culverting, realignment or other
                                          No
           other changes to the hydrology                           changes to the hydrology of
           of watercourses or aquifers?                             surface watercourse is required.

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                           9
PROPOSED INFRASTRUCTURE FOR BUILDINGS AT CISF CAMPUS (GBS)
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 1.22      Stream crossings?                                        No stream crosses at the project
                                                      No
                                                                    site.
 1.23      Abstraction or transfers of                              No abstraction of ground water
           water from ground or surface                             is required. Abstraction of
           waters?                      No                          ground water if required will be
                                                                    done    only     after   getting
                                                                    permission from CGWA.
 1.24      Changes in water bodies or the                           There will be no changes in
           land surface affecting drainage No                       water bodies on the land and
           or run-off?                                              drainage or run-off.
 1.25      Transport of personnel or Yes                            Materials during construction
           materials for construction,                              phase will be transported by
           operation                or                              truck, trolley etc.
           decommissioning?                                         Trucks, Cars, two wheelers etc.
                                                                    will be used during operation
                                                                    phase.
 1.26      Long-term dismantling or                   No            Not Applicable
           decommissioning               or
           restoration works?
 1.27      Ongoing      activity    during            No            Not Applicable
           decommissioning which could
           have an impact on the
           environment?
 1.28      Influx of people to an area in             Yes           Temporary influx of construction
           either      temporarily       or                         labours.
           permanently?
 1.29      Introduction of alien species?             No            As on date, there is no history of
                                                                    alien species at the proposed
                                                                    site.
 1.30      Loss of native species or No                             There is no loss in native species
           genetic diversity?                                       or genetic diversity at site.

 1.31      Any other actions?                         No            Not Applicable

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          10
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                             By Central Industrial Security Force
2. Use of Natural resources for construction or operation of the Project (such as land,
water, materials or energy, especially any resources which are non-renewable or in
short supply):
  S.No. Information/checklist                          Yes/No Details      thereof     (with
        confirmation                                          approximate quantities /rates,
                                                              wherever possible) with source
                                                              of information data

  2.1       Land especially undeveloped Yes                         62100 sq m of land is allotted by
            or agricultural land (ha)                               DDA to development of proposed
                                                                    Infrastructure for Buildings at
                                                                    CISF Campus (GBS).
  2.2       Water (expected source &                                Source – Delhi Jal Boad
            competing users) unit: KLD Yes                          Total Water Required- 255 KLD

  2.3       Minerals (MT)                              No           Not Applicable

  2.4       Construction material – stone, Yes                      Building materials will be
            aggregates, sand / soil                                 sourced from indigenous supply.
            (expected source – MT)
            Forests and timber (source –                            Wood for Doors shutters/
  2.5
            MT)                                                     furniture, windows will be used
                                                       Yes          as per the requirement and as
                                                                    per the approved standards.
  2.6       Energy including electricity and Yes                    Source of power supply – BSES
            fuels (source, competing users)                         Power requirement: 2000 KVA
            Unit: fuel (MT), energy (MW)                            DG Sets: 3 x 500 KVA for
                                                                    emergency backup only.
                                                                    Fuel: Low sulphur Diesel

  2.7       Any other natural resources No                          Not Applicable
            (use appropriate standard
            units)

 3. Use, storage, transport, handling or production of substances or materials, which
 could be harmful to human health or the environment or raise concerns about
 actual or perceived risks to human health.

  S.No. Information/Checklist                               Yes/No Details there of (with
        confirmation                                               approximate
                                                                   quantities/rates, wherever

 Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          11
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                                       possible) with source of
                                                                       information data
 3.1       Use of substances or materials, No                          Proper management of Used
           which are hazardous (as per                                 oil, and E-waste will be done.
           MSIHC rules) to human health or
           the environment (flora, fauna, and
           water supplies)
 3.2       Changes in occurrence of disease No                         Suitable drainage and waste
           or affect disease vectors (e.g.                             management measures will
           insect or water borne diseases)                             be       adopted         during
                                                                       operational phase. There will
                                                                       be no stagnation of water or
                                                                       accumulation       of     water
                                                                       outside or within the
                                                                       complex.
 3.3       Affect the welfare of people e.g. No                        During Construction phase:
           by changing living conditions?                              Employment opportunities
                                                                       provided due to the project
                                                                       has lead to better quality of
                                                                       life & have also set a standard
                                                                       for future developments in
                                                                       the area. Moreover this
                                                                       project     have       provided
                                                                       employment to about 150 no.
                                                                       of local labors during
                                                                       construction phase.
                                                                       During Operation Phase:
                                                                       As project is a proposed
                                                                       infrastructure for buildings at
                                                                       CISF Campus (GBS), there
                                                                       shall be several services
                                                                       required which will generate
                                                                       direct & indirect employment
                                                                       for the people of nearby area.
 3.4       Vulnerable groups of people who No                          No vulnerable groups of
           could be affected by the project                            people will be affected.
           e.g. hospital patients, children, the
           elderly etc.,
 3.5       Any other causes                      No                    None

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          12
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
4. Production of solid wastes during construction or operation or decommissioning
(MT/month)

 S.No.      Information/Checklist                     Yes/No Details     thereof  (with
            confirmation                                     approximate
                                                             quantities/rates, wherever
                                                             possible) with source of
                                                             information data
 4.1        Spoil, overburden or                 mine        Not applicable
                                                      No
            wastes
 4.2        Municipal waste (domestic and                              Domestic       waste    during
            or commercial    wastes)                                   construction – 23 kg/day
                                                                       During operation – 677
                                                          Yes          kg/day of Municipal Solid
                                                                       waste.
                                                                       Detailed       Solid    Waste
                                                                       Management is given in EMP.
 4.3        Hazardous wastes               (as per Yes                 Used oil from D.G. Set will be
            Hazardous                         Waste                    carefully stored in HDPE
            Management Rules)                                          drums in isolated covered
                                                                       facility. The used oil will be
                                                                       sold to vendors authorized by
                                                                       Central Pollution Control
                                                                       Board for the treatment of
                                                                       the same.
                                                                       Suitable care will be taken so
                                                                       that spills / leaks of used oil
                                                                       from storage could be
                                                                       avoided.
 4.4        Other industrial process wastes No                         Not applicable
 4.5        Surplus product                 No                         Not applicable
 4.6        Sewage sludge or other sludge Yes                          About 11 Kg / day dried
            from effluent treatment
                                                                       sludge will be generated from
                                                                       STP within complex and this
                                                                       sludge will be passed through
                                                                       filter press where it will be
                                                                       dewatered/ dried & form a
                                                                       cake and then will be used as
                                                                       manure in green areas and

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          13
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                                       excess will be given to
                                                                       farmers/ nurseries.
 4.7        Construction          or     demolition Yes
                                                                       Excavation soil generated is
            wastes
                                                                       approx. 7282 Cubic Meter
                                                                       which shall be used for
                                                                       backfilling and levelling of
                                                                       land. Excess soil shall be
                                                                       disposed off in approved site.
 4.8        Redundant      machinery or No                             Not applicable
            equipment
 4.9        Contaminated soils or other                                Not applicable
                                        No
            materials
 4.10       Agricultural wastes         No                             Not applicable
 4.11       Other solid wastes          Yes                            E- waste from the complex
                                                                       which will be given to service
                                                                       provider.

                                                                       Battery waste generated from
                                                                       UPS, inverters, etc. will be
                                                                       managed as per the Batteries
                                                                       (Management & Handling)
                                                                       Rules, 2001.

5. Release of pollutants or any hazardous, toxic or noxious substances to air (Kg/hr)

 S.No.      Information/Checklist            Yes/No Details     thereof      (with
            confirmation                            approximate
                                                    quantities/rates, wherever
                                                    possible) with source of
                                                    information data
 5.1        Emissions from combustion of No         No burning will be done.
            fossil fuels from stationary or
            mobile sources
 5.2        Emissions from production No            Not Applicable
            processes
 5.3        Emissions      from    materials        Dust will be generated during
            handling including storage or           construction      from     the
                                             Yes
            transport                               movement       of    transport
                                                    vehicles. The effect will be

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          14
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                                      restricted to construction
                                                                      phase only. Water sprinklers
                                                                      will be used for dust
                                                                      suppression.
 5.4        Emissions from construction                               No Batching Plant will be
            activities including plant and                            installed at the project site
            equipment                                                 hence no emissions will be
                                                         No
                                                                      generated       from      the
                                                                      machineries. RMC will be
                                                                      used.
 5.5        Dust or odours from handling of                           During loading & unloading of
            materials including construction                          construction material, dust
            materials, sewage and waste                               will be generated. Water will
                                                                      be sprinkled and tarpaulin
                                                         Yes          cover will be provided over
                                                                      stored raw material to reduce
                                                                      dust emission. Treated water
                                                                      will be used within the
                                                                      complex.
 5.6        Emissions from incineration of                            Not applicable
                                               No
            waste.
 5.7        Emissions from burning of waste                           Not applicable
            in open air (e.g. slash materials, No
            construction debris).
 5.8        Emissions from any other                                  Not applicable
                                               No
            sources.

6.     Generation of Noise and Vibration, and Emissions of Light and Heat:

 S.No. Information/Checklist                Yes/No Details       thereof     (with
       confirmation                                approximate quantities/rates,
                                                   wherever possible) with source
                                                   of information data with source
                                                   of information data
 6.1       From operation of equipment Yes         During      construction,   the
           e.g. engines, ventilation plant,        equipment such as mixer
           crushers                                machines, bulldozers, cranes,
                                                   compactors will be used which is
                                                   of highest standard and adhered
                                                   to international standards.

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          15
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                                   These standards itself will take
                                                                   care of noise pollution control/
                                                                   vibration control and air
                                                                   emission control. Hence an
                                                                   insignificant impact due to
                                                                   construction     machinery      is
                                                                   envisaged.
                                                                   Apart      from     this,    the
                                                                   construction activities will be
                                                                   restricted to daytime only.
                                                                   Source of noise in the
                                                                   operational phase will be DG
                                                                   sets. However, the D.G. Sets
                                                                   installed    shall   be     kept
                                                                   acoustically enclosed and will be
                                                                   used during Power failure only.
 6.2       From industrial or similar
                                      No                           Not applicable
           processes
 6.3       From      construction  or                              Due to the various activities
           demolition                                              there will be short-term noise
                                                                   impacts in the immediate
                                                      Yes
                                                                   vicinity of the project site.
                                                                   It will be restricted to day time
                                                                   only.
 6.4       From blasting or piling                  No             Not Applicable
 6.5       From      construction                or Yes            Some amount of noise will be
           operational traffic                                     generated       from      vehicular
                                                                   movement in construction as
                                                                   well as operational phase.
 6.6       From lighting or cooling                                Not Applicable
                                    No
           systems
 6.7        From any other sources  No                             None

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          16
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
7. Risks of contamination of land or water from releases of pollutants into
   the ground or into sewers, surface waters, groundwater, coastal waters
   or the sea:

  S.No. Information/Checklist                               Yes/No       Details     thereof   (with
        confirmation                                                     approximate
                                                                         quantities/rates, wherever
                                                                         possible) with source of
                                                                         information data
  7.1      From handling, storage, use or                                Used oil is the hazardous
           spillage of hazardous materials                               material proposed to be
                                                                         used in the complex. It will
                                                                         be stored in HDPE drums
                                                                         and kept in covered rooms
                                                            No
                                                                         under lock & key and will be
                                                                         sold to authorize vendors
                                                                         only. Special care will be
                                                                         taken to prevent leakages
                                                                         and spills.
  7.2      From discharge of sewage or other No                          109 KLD of Treated water
           effluents to water or the land                                will be used within the
           (expected mode and place of                                   building.
           discharge)
  7.3      By deposition of pollutants emitted                           Not Applicable
                                               No
           to air into the land or into water
  7.4      From any other sources              No                        None
  7.5      Is there a risk of long term build up No                      None
           of pollutants in the environment
           from these sources?

8.    Risk of accidents during construction or operation of the Project,
     which could affect human health or the environment.

  S.No.      Information/Checklist                    Yes/No       Details      thereof     (with
             confirmation                                          approximate quantities/rates,
                                                                   wherever possible) with source
                                                                   of information data

  8.1        From explosions, spillages,                           All appropriate measures are
             fires etc from storage, No                            being taken during construction
                                                                   phase. Proper fire fighting

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          17
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                             By Central Industrial Security Force
              handling, use or production of                        system will be installed at site,
              hazardous substances                                  for operation phase.
  8.2         From any other causes          No                     None
  8.3         Could the project be affected                         The area under study falls in
              by natural disasters causing                          Zone-IV, according to the Indian
              environmental damage (e.g.                            Standard Seismic Zoning Map.
              floods,          earthquakes,                         Suitable seismic coefficients in
              landslides, cloudburst etc)?                          horizontal      and      vertical
                                                                    directions respectively, will be
                                                       Yes          adopted while designing the
                                                                    structure.
                                                                    For reasons of earthquake:
                                                                    Earthquake measures will be
                                                                    incorporated in the building
                                                                    design. However, the area is not
                                                                    prone to flood and landslide etc.

9. Factors which should be considered (such as consequential
development) which could lead to environmental effects or the potential for
cumulative impacts with      other existing or planned activities in the
locality.

  S. No.      Information/Checklist                          Yes/No Details there of (with
              confirmation                                          approximate
                                                                    quantities/rates, wherever
                                                                    possible) with source of
                                                                    information data
  9.1         Lead to development of                                     All supporting infrastructure
              supporting facilities, ancillary                           exists near site.
              development or development
              stimulated by the project which
              could have impact on the
              environment e.g.:                                          STP of 180 KLD will be
              • Supporting infrastructure                    No          installed to treat the
              (roads, power supply, waste or                             wastewater
              waste water treatment, etc.)
                • Housing development                        No          None
                • Extractive industries                      No          None
                • Supply industries                          No          None

 Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          18
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
               • Other                                     No           None
 9.2         Lead to after-use of the site,                             Proper care shall be taken to
             which could have an impact on No                           avoid any adverse impact on
             the environment                                            the environment
 9.3         Set a precedent for later                                  Proper     and        planned
             developments                                               development        of     the
                                            Yes                         proposed infrastructure for
                                                                        Buildings At CISF Campus
                                                                        (GBS).
 9.4         Have cumulative effects due to No                          No impact
             proximity to other existing or
             planned projects with similar
             effects

(III)    Environmental Sensitivity

 S.No. Areas                                  Name/                                Aerial distance
                                              Identity                             (within 15 km.)
                                                                                   Proposed project
                                                                                   location boundary
 1          Areas protected under             Rastrapati Bhawan                    3 Km. NE
           international                      Red Fort                             5 Km. NE
           conventions, national              India Gate                           3.5 Km. NE
           or local legislation for
                                              Jama Masjid                          5 Km. NE
           their ecological,
           landscape, cultural or             Jantar Mantar                        3.5 Km. NE
           other related value                Raj Ghat                             4.5 Km. NE
                                              Tuglakabad Fort                      10 Km. E
                                              Qutoub Minar                         5.5 Km. SE

 2         Areas which are                    Water sources or other
           important or sensitive             bodies
           for ecological reasons -           River Yamuna                         12.5 Km. E
           Wetlands,
           watercourses or other              Forests
           water bodies, coastal              Sanjay van                           4.8 Km. SE
           zone, biospheres,                  Asola wild life sanctuary            12.5 Km. SE
           mountains, forests                 Central ridge                        4.5 Km. NE
                                              Rijokari PF                          2 Km. S

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          19
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 3         Areas used by                      Sanjay van                           4.8 Km. SE
           protected, important or            Asola wild life sanctuary            12.5 Km. SE
           sensitive species of               Central ridge                        4.5 Km. NE
           flora or fauna for                 Rijokari PF                          2 Km. S
           breeding, nesting,
           foraging, resting, over
 4         wintering,  migration
           Inland, coastal, marine            None
           or underground waters
 5          State, National                   State Boundary-Haryana               5 Km, SW
           boundaries
 6         Routes or facilities used          None                                 None
           by the public for access
           to recreation or other
           tourist, pilgrim areas
 7          Defense installations             Delhi Kantt              Adjacent
 8         Densely populated or               Nearby area is moderated
           built-up area                      populated area

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          20
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 9          Areas occupied by                 Hospitals
           sensitive man-made                 Civil Hospital                       2 Km. N
           land uses (hospitals,              Sanjay Gandhi Memorial               1 Km. NE
           schools, places of                 Hospital
           worship, community                 Girdharilal Memorial
           facilities)                        Hospital                             1 Km. W

                                              Schools
                                              Fine arts polytechnic                0.5 Km. E
                                              college for women                    2.5 Km. E
                                              JNU                                  5.5 Km. E
                                              IIT
                                                                                   2 Km. W
                                              School of Dwarka

                                              Places of Worship
                                              Hanuman Mandir at                    3 Km. NE
                                              Madangiri                            1 Km. W
                                              Dadadev Mandir at
                                              Rajnagar

                                              Community Facilities

                                              Police station Kapashera             2.5 Km. S
                                              ATM                                  Within the Airport

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          21
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 10        Areas containing                   Forests
           important, high quality            Sanjay van                           4.8 Km. SE
           or scarce resources                Asola wild life sanctuary            12.5 Km. SE
            (Ground water
                                              Central ridge                        4.5 Km. NE
           resources, surface
           resources, forestry,               Rijokari PF                          2 Km. S
           agriculture, fisheries,
           tourism, minerals)                 Tourism
                                              Rastrapati Bhawan                    3 Km. NE
                                              Red Fort                             5 Km. NE
                                              India Gate                           3.5 Km. NE
                                              Jama Masjid                          5 Km. NE
                                              Jantar Mantar                        3.5 Km. NE
                                              Raj Ghat                             4.5 Km. NE
                                              Tuglakabad Fort                      10 Km. E
                                              Qutub Minar                          5.5 Km. SE

 11         Areas already                                                          There will be no
           subjected to pollution             None                                 adverse impacts
           or environmental                                                        from propose
           damage. (Those where                                                    project.
           existing legal
           environmental
           standards are
           exceeded)
 12         Areas susceptible to              Area falls in seismic zone
           natural hazard which               IV according to seismic
           could cause the                    zone map of India. No
           project to present                 flooding in the area
           environmental                      according to previous
           problems                           record
           (Earthquakes,
           subsidence, landslides,
           erosion, flooding or
           extreme or adverse
           climatic conditions)

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          22
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                APPENDIX II
                                            (See paragraph 6)
    FORM-1 A (only for construction projects listed under item 8 of the Schedule)
                           CHECK LIST OF ENVIRONMENTAL IMPACTS
    (Project proponents are required to provide full information and wherever
necessary attach explanatory notes with the Form and submit along with proposed
           environmental management plan & monitoring programme)
1. LAND ENVIRONMENT
   (Attach panoramic view of the project site and the vicinity.
 1.1 Will the existing land use get The project is construction of “Proposed
      significantly altered from the Infrastructure for buildings at CISF Campus
      project that is not consistent (GBS)”
      with      the     surroundings?
      (Proposed land use must Development will be done as per
      conform to the approved development plan of area.
      Master Plan / Development
      Plan of the area. Change of
      land use if any and the
      statutory approval from the
      competent authority be
      submitted).
      Attach Maps of
      (i)          Site location        The site location is enclosed in EMP.
      (ii) Surrounding features of Location Map enclosed in EMP.
      the proposed site (within 500
      meters)
      (iii) The site (indicating levels Conceptual plan is enclosed in EMP.
      & contours) to appropriate
      scales. If not available attach
      only conceptual plans.
 1.2 List out all the major project
      requirements in terms of the
      Land area,                        Plot Area –62100 sq m
      Built up area                     47455.37 sq m
      Water consumption                 255 KLD
      Power requirement                 2000 KVA
      Connectivity                      NH-8- 500 m SE
      Parking needs etc.                Parking Required:- 252 ECS
                                        Parking Provided:- 252 ECS
 1.3 What are the likely impacts of During construction of building, proper care
     the proposed activity on the will be taken to minimize the dust effects.
                                    There would be no such impacts of the

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          23
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
     existing facilities adjacent to                  proposed activity on the existing facilities
     the proposed site?                               adjacent to the proposed site.
     (Such as open spaces,
     community facilities, details
     of the existing land use, and
     disturbance to the local
     ecology).
 1.4 Will there be any significant                    Soil Type:
     land disturbance resulting in                    Silt Loam
     erosion,     subsidence       &                  Slope Analysis:
     instability?                                     The project area possesses fairly plain terrain.
     (Details of soil type, slope
     analysis, vulnerability to                       Erosion / Subsidence:
     subsidence, seismicity etc                       Proper greening & paving of area will not
     may be given).                                   cause any soil erosion problem and
                                                      subsidence.

                                     Seismicity:
                                     Seismic zone-IV, for which appropriate safety
                                     measures shall be taken.
 1.5 Will the proposal involve At the proposed site sewer line and storm
     alteration of natural drainage water drainage connection is available. Thus
     systems?                        the proposed project activities will not cause
     (Give details on a contour any alteration of natural drainage system.
     map showing the natural
     drainage near the proposed
     project site)
 1.6 What are the quantities of During construction phase about 7282 Cubic
     earthwork involved in the Meter (Approx.) will be extracted in order to
     construction activity cutting, provide foundation. This excavated soil/ rock
     filling, reclamation etc.       will be properly stacked within the site under
     (Give details of the quantities tarpaulin cover and will be reused for
     of      earthwork     involved, backfilling purpose. The top soil will be
     transport of fill materials preserved separately and will be used for
     from outside the site etc.)     landscaping purpose only and the excess
                                     excavated soil will be disposed off to approve
                                     Municipal Filling Ground. Hence, no
                                     immediate adverse impacts on the land
                                     environment are envisaged.
 1.7 Give details regarding water Water Supply:
     supply, waste handling etc During construction stage, water will be taken
     during the construction from existing water supply.
     period.                         Waste Generation / Handling:
                                     Soil excavated will be reused for backfilling
                                     and the fertile top soil will be reused for
                                     horticultural purpose.

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          24
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                      For construction labourers, proper sanitary
                                                      facilities & wash areas will be constructed and
                                                      good hygienic conditions will be maintained.
 1.8 Will the low lying areas &                       No low lying and wetland area is present in
     wetlands get altered?                            and around the project site.
     (Provide details of how low
     lying and wetlands are getting
     modified from the proposed
     activity)
 1.9 Whether construction debris                      The excavated soil from the project is
     & waste during construction                      common in nature and does not cause any
     cause health hazard? (Give                       health hazard to associate and nearby
     quantities of various types of                   population. The construction debris will be
     wastes generated during                          used for land levelling / back filling. Steel
     construction including the                       scrap will be sent for recycling.
     construction labour and the                      Mobile toilets & drinking water for
     means of disposal)                               construction labour will be provided. The
                                                      sewage and waste water generated during
                                                      construction phase will be channelized to
                                                      sewer line of the area.

2. WATER ENVIRONMENT
 2.1 Give the total quantity of water                       The total quantity of water requirement
      requirement for the proposed                          will be 255 KLD. The break-up details
      project with the breakup of                           are given in EMP.
      requirements for various uses.
      How will the water requirement                        Water requirement will be met by DJB
      met?                                                  Water Supply.
      State the sources & quantities and                    Water Balance Diagram is given in EMP.
      furnish a water balance statement.
 2.2 What is the capacity (dependable                       DJB is the proposed source of water
      flow or yield) of the proposed                        supply.
      source of water?
 2.3 What is the quality of water                           The quality of water complying with IS
      required, in case, the supply is not                  10500 is required. In case, if municipal
      from a municipal source? (Provide                     water is not available, ground water will
      physical, chemical, biological                        be taken after permission from CGWB.
      characteristics with class of water
      quality)

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          25
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 2.4      How much of the water               The total waste water generation will
          requirement can be met from the     be 178 KLD which will be treated in
          recycling of treated wastewater?    Sewage Treatment Plant of 180 KLD
          (Give the details of quantities,    capacity, which will be installed within
          sources and usage)                  the premises. The treated recycled
                                              water from the S.T.P. will be used in
                                              gardening and other purpose within the
                                              project premises.
 2.5      Will there be diversion of water There will not be any substantial effect
          from other users?                   on water demand of this region.
          (Please assess the impacts of the
          project on other existing uses and
          quantities of consumption)
 2.6      What is the incremental pollution The total waste water generation from
          load from wastewater generated the complex will be 178 KLD which will
          from the proposed activity?         be treated in S.T.P of capacity 180 KLD.
                                              109 KLD of the treated water will be
                                              reused for gardening and purposes.
                                              42.7 % of treated water will be recycled
          (Give details of the quantities and for use.
          composition       of   wastewater
          generated from the proposed
          activity)

 2.7      Give details of the water                       There will be 5 rain water harvesting
          requirements met from water                     pits at the proposed site.
          harvesting? Furnish details of the
          facilities created.
 2.8      What would be the impact of the                 As the land is not having any
          land use changes occurring due to               construction so surface run off creates
          the proposed project on the runoff              water logging during rainy days,
          characteristics (quantitative as                however after construction of complex;
          well as qualitative) of the area in             the same will be used to recharge the
          the post construction phase on a                ground.
          long-term basis?
          Would it aggravate the problems
          of flooding or water logging in any
                                            No, it will not aggravate the problem of
          way?                              flooding or water logging in any way,
                                            rather will reduce the same.
 2.9      What are the impacts of the Rain water harvesting will recharge the
          proposal on the ground water?     ground water; therefore there is no
          (Will there be tapping of ground adverse impact on the ground water.
          water; give the details of ground
          water table, recharging capacity,
          and approvals obtained from
          competent authority, if any)

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          26
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 2.10 What precautions/measures are                       During the construction phase, runoff
      taken to prevent the run-off from                   from the construction site is not
      construction activities polluting                   allowed into the roadside. Adequate
      land & aquifers?                                    measures will be taken to channelize
      (Give details of quantities and the                 such run off and the same will be
      measures taken to avoid the                         disposed through existing storm water
      adverse impacts)                                    drainage network.
 2.11 How is the storm water from                         Adequate measures will be taken to
      within the site managed?                            channelize such storm water and the
      (State the provisions made to                       same will be disposed through existing
      avoid flooding of the area, details                 storm water drainage network.
      of the drainage facilities provided
      along with a site layout indication
      contour levels)
 2.12 Will      the      deployment      of               Proper sanitary facilities like temporary
      construction labourers particularly                 toilets etc. will be provided to
      in the peak period lead to                          labourers.
      unsanitary conditions around the
      project site (Justify with proper
      explanation)
 2.13 What on-site facilities are providedThe total waste water generation will
      for the collection, treatment &     be 178 KLD. Waste water will be treated
      safe disposal of sewage?            in Sewage Treatment Plant of 180 KLD
      (Give details of the quantities of  capacity, which will be installed within
      wastewater generation, treatment    the premises. The treated recycled
      capacities with technology &        water from the S.T.P. will be used in
      facilities for recycling and disposal)
                                          flushing and other purpose within the
                                          project premises. Details of STP are
                                          given in EMP.
 2.14 Give details of dual plumbing Dual Plumbing line for using treated
      system if treated waste used is water use will be provided in the
      used for flushing of toilets or any complex.
      other use.

3. VEGETATION
 3.1 Is there any threat of the project  No threat to bio-diversity is envisaged.
      to the biodiversity?
      (Give a description of the local
      ecosystem with its unique
      features, if any)
 3.2 Will the construction involve No clearing or modification of
      extensive clearing or modification vegetation was required.
      of vegetation?

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          27
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
     (Provide a detailed account of the
     trees & vegetation affected by the
     project)
 3.3 What are the measures proposed The green belt for the proposed project
     to be taken to minimize the likely is planned to provide a clean, healthy
     impacts on important site features and beautiful green environment.
     (Give details of proposal for tree
     plantation, landscaping, creation of
     water bodies etc along with a
     layout plan to an appropriate scale)

4. FAUNA

 4.1 Is there likely to be any                        No faunal species exists at site.
     displacement of fauna- both
     terrestrial and aquatic or
     creation of barriers for their
     movement? Provide the
     details.
 4.2 Any direct or indirect impacts                   No, there is no direct or indirect impact on
     on the avifauna of the area?                     the avifauna of the area.
     Provide details.
 4.3 Prescribe measures such as                       Not Applicable
     corridors, fish ladders etc. to
     mitigate adverse impacts on
     fauna

5. AIR ENVIRONMENT
 5.1 Will the project increase The air quality of the area will be measured.
       atmospheric concentration of Ambient air quality report will be submitted.
       gases & result in heat islands?
                                       The traffic will increase due to operation of
       (Give details of background proposed          project.    Increased    traffic
       air quality levels with generation of vehicles due to project will not
       predicted values based on cause increase in atmospheric concentration
       dispersion models taking into of gases and do not result in heat island
       account the increased traffic formation.
       generation as a result of the
       proposed constructions)

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          28
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 5.2 What are the impacts on                          No dust, odour will be generated at site.
     generation of dust, smoke,                       Smoke will be generated from operation of
     odorous fumes or other                           DG sets. Proper emission standards will be
     hazardous gases? Give details                    maintained as per CPCB guidelines.
     in relation to all the
     meteorological parameters.

 5.3 Will the proposal create                         The optimum parking provision is proposed.
     shortage of parking space for                    Hence there will be no shortage of parking
     vehicles? Furnish details of                     space for vehicles. Total parking provision of
     the present level of transport                   complex is 252 ECS.
     infrastructure and measures
     proposed for improvement
     including       the       traffic
     management at the entry &
     exit to the project site.

 5.4 Provide details of the                           Maximum capacity of parking shall be
     movement patterns with                           provided on surface and a proper route shall
     internal roads, bicycle tracks,                  be provided for the traffic movement as well
     pedestrian          pathways,                    as pedestrian movement.
     footpaths etc., with areas
     under each category.

 5.5 Will there be significant To reduce/ avoid traffic following steps will be
     increase in traffic noise & taken:
     vibrations? Give details of the
     sources and the measures        1. Two way traffic movement
     proposed for mitigation of      2. No honking zone
     the above.
                                     3. No vehicle movement in specified
                                        areas.
                                                      The foundation will be made very hard and
                                                      paved with rubber flooring to minimize the
                                                      vibration, also all other measures to reduce
                                                      vibration will be adopted during designing of
                                                      new buildings.
 5.6 What will be the impact of DG DG Sets:
     sets & other equipment on
                                   3 x 500 KVA
     noise levels & vibration in &
     ambient air quality around Fuel: Low sulphur H.S.D

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          29
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
        the project site? Provide Location of DG sets:
        details.
                                  All shall be of the latest technology as per
                                  current practices & bought acoustically
                                  enclosed & placed in acoustically enclosed
                                  room to reduce the noise from D.G. Sets with
                                  proper stack height as per C.P.C.B. norms to
                                  reduce the impacts on air quality around the
                                  project site. The noise emissions from D.G.
                                  Sets shall be meeting the noise level as per
                                  C.PC.B guidelines. Low Sulphur fuel will be
                                  used to run these D.G. Sets. Vibrator pads will
                                  be used in DG sets to minimize the vibration
                                  effect.

6.    AESTHETICS

 6.1 Will       the      proposed                 No, the proposed construction in any way
     constructions in any way                     does not result in the obstruction of view,
     result in the obstruction of a               scenic amenity. However proper landscaping
     view, scenic amenity or                      will be done. This will enhance the scenic
     landscapes?                                  beauty.
        Are these considerations Yes, all the considerations have been taken
        taken into account by the into account.
        proponents?

 6.2 Will there be any adverse The construction of this project is being done
     impacts      from        new as per approved building plan. Hence no
     constructions on the existing adverse impact is anticipated.
     structures? What are the
     considerations taken into
     account?

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          30
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force

 6.3 Whether there are any local None
     considerations of urban form
     & urban design influencing
     the design criteria? They may
     be explicitly spelt out.
        Are         there                 any No, there is no anthropological or
        anthropological                    or archaeological site or artifacts in the site and
        archaeological    sites            or in the close/ nearby proximity of the site.
        artifacts nearby?
        State if any other significant
        features in the vicinity of the
        proposed site have been
        considered.

7. SOCIO-ECONOMIC ASPECTS

 7.1    Will the proposal result in any
                                     The project is a “Proposed Infrastructure for
        changes to the demographic   buildings at CISF Campus” & thus there will be
        structure of local population?
                                     influx of population in the form of residents,
        Provide the details.         staffs & visitors. Thus there will be some
                                     change in the demographic structure of the
                                     area.
 7.2    Give details of the existing The social infrastructures exist
        social infrastructure around in the area are:
        the proposed project.        Post office                      1.5 Km

                                                  Temple                                      3 Km

                                                  Hospitals                                   4 Km

 7.3    Will the project cause No sacred site or other cultural value site
        adverse effects on local exists in the complex. Hence no adverse
        communities, disturbance to impact is envisaged.
        sacred sites or other cultural
        values? What are the
        safeguards proposed?

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          31
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
8. BUILDING MATERIALS

 8.1    May involve the use of The major materials required for construction
        building materials with high- of the project will be steel, cement, bricks,
        embodied energy.                flooring tiles / stones, sanitary and hardware
                                        items, electrical fittings, water, etc.
        Are      the       construction
        materials produced with Energy efficient Building material will be used.
        energy efficient processes?
        (Give details of energy Details of Energy Conservation measures
        conservation measures in the given in EMP.
        selection of building materials
        and their energy efficiency
 8.2    Transport and handling of Yes, transportation and handling of material
        materials during construction results in pollution, noise however it will be
        may result in pollution, noise minimized by covering material by the
        & public nuisance.              tarpaulin and ensuring PUC certificate of
        What measures are taken to vehicles and good condition silencers.
        minimize the impacts?
 8.3    Are recycled materials used in Not applicable.
        roads and structures?
        State the extent of savings
        achieved?
 8.4    Give details of the methods of This solid waste will be disposed off as per
        collection, segregation & municipal solid waste management and
        disposal of the garbage handling norms. Details given in EMP.
        generated        during     the
        operation phases of the
        project.

9. ENERGY CONSERVATION
 9.1     Give details of the power                    Power Requirement: 2000 KVA
         requirements, source of                      Source of Power: BSES
         supply, backup source etc.
         What     is    the     energy                Back-up Source: DG Sets:
         consumption assumed per                      3 x 500KVA
         square foot of built-up area?
         How have you tried to                        Fuel: Low sulphur Diesel
         minimize               energy                DG sets shall be bought acoustically enclosed
         consumption?                                 and with residential silencers.

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          32
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                        Appropriate energy conservation measures &
                                        management plan shall be adopted in order to
                                        minimize the consumptions of non-renewable
                                        fuel. Details given in EMP.
 9.2     What type of and capacity of DG Sets:
         power back-up do you plan 3 x 500 KVA
         to provide?                    Fuel: Low sulphur Diesel
                                        All shall be installed to provide power backup
                                        during power failures.
 9.3     What are the characteristics Double insulated glass for external facade shall
         of the glass you plan to use? be provided.
         Provide specifications of its
         characteristics related to
         both short wave and long
         wave radiation?
 9.4     What        passive      solar Building design and envelope will be optimized
         architectural features are through selection of appropriate wall and roof
         being used in the building?    construction and through adoption of solar
         Illustrate the applications measures.
         made in the proposed Yes, the layout of building has been designed to
         project.
                                        maximize the potential for use of solar lighting
                                        per day devices.
 9.5     Does the layout of streets &                 Yes, the layout of building has been designed to
         buildings maximize the                       maximize the potential for use of solar lighting
         potential for solar energy                   per day devices.
         devices?
         Have you considered the use
         of street lighting, emergency
         lighting and solar hot water
         systems for use in the
         building? Substantiate with
         details.
 9.6     Is shading effectively used to               Architectural measures will be adopted to
         reduce         cooling/heating               provide shading devices for windows and roof
         loads? What principles have                  which would effectively reduce heating up of
         been used to maximize the                    building envelope. Louvers and sunshades will
         shading of Walls on the East                 be used around windows in order to protect
         and the West and the Roof?                   from direct sunlight.
         How much energy saving has
         been effected?

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          33
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
 9.7     Do the structures use energy-                Suitable energy optimization will be adopted
         efficient space conditioning,                during the calculation of energy load of the
         lighting and mechanical                      proposed project. The space heating load will
         systems? Provide technical                   be minimized using solar structure and suitable
         details.                                     buildings envelop material. Uses of
         Provide details of the                       incandescent lamp and halogen lamps will be
         transformers and motor                       avoided and energy efficient compact
         efficiencies, lighting intensity             fluorescent lamps & LED will be used for all
         and air-conditioning load                    common area.
         assumptions?
         Are you using CFC and HCFC
         free     chillers?      Provide
         specifications

 9.8     What are the likely effects of               No significant effect is envisaged on the
         the building activity in                     surrounding environment of project. Increased
         altering the micro-climates?                 traffic generation and use of D.G. Sets in the
         Provide a self assessment on                 project will not cause any significant increase in
         the likely impacts of the                    atmospheric concentration of gases and will
         proposed construction on                     not result in heat island formation.
         creation of heat island &
         inversion effects?
 9.9     What are the thermal                         Brickwork, plaster, stone work,                  double
         characteristics of the building              insulated glass for external façade
         envelope? (a) roof; (b)                          S.     BUILDING MATERIAL         ‘R’ Values       ‘U’ Values
         external walls; and (c)                          No     PROPOSED                  (in Sq m. Deg    (in Watts/ Sq m.
                                                                 WITH U & R VALUES         C/ Watts )       Deg C)
         fenestration?
         Give details of the material                     1.     Wall                      2.27             0.44
                                                                 Brick & ACC Blocks wall
         used and the U-values or the
                                                                 (230 mm thick), both
         R values of the individual                              side thick sand cement
         components.                                             plaster      (12-18mm)
                                                                 with insulation.

                                                          2.     Roof                      3.83             0.26
                                                                 200 mm RCC slab with
                                                                 mud phuska & clay tiles
                                                                 with 75 mm insulation.

                                                          3.     Glass                     0.30             3.3
                                                                 (Double      insulated
                                                                 glass)

 9.1     What precautions & safety                    Fire storage tank with fire pumps like Hydrant
 0       measures are proposed                        pump, Jockey Pump, Pressure vessel & Diesel
         against fire hazards? Furnish                Engine Driven Pump will be installed in the
         details of emergency plans.                  plant room.

                                                      Fire Hydrant System:

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          34
“Proposed Infrastructure for Buildings at CISF campus (GBS)” Mahipalpur, New Delhi
                                                                            By Central Industrial Security Force
                                                      The hydrant ring main from fire pumps header
                                                      are running all around the buildings with yard
                                                      hydrants at suitable intervals. Wet risers will be
                                                      tapped from ring main and run along the shaft.
                                                      Fire hose cabinet is provided on all floors with
                                                      accessories.

                                                      Sprinkler System :
                                                      It will be provided on all floor areas except
                                                      electrical rooms, server rooms.
                                                      Overhead water storage tank at roof will be
                                                      connected to sprinkler system.

                                                      Fire Extinguishers :
                                                      Portable type class A, B & C fire extinguishers
                                                      will be provided at all fire sensitive places.

 9.1     If you are using glass as wall               All fenestration with U-factors, SHGC, or visible
 1       material provides details and                light transmittance determined, certified, and
         specifications        including              labelled in accordance ISO 15099 shall be
         emissive       and     thermal               adopted.
         characteristics.
 9.1     What is the rate of air                      The rate of air infiltration into the buildings will
 2       infiltration into the building?              be negligible.
         Provide details of how you
         are mitigating the effects of
         infiltration.
 9.1     To what extent the non-                      Solar energy will be used. It is proposed to
 3       conventional            energy               install solar Heater system.
         technologies are utilized in
         the        overall      energy
         consumption?
         Provide details of the
         renewable               energy
         technologies used.

10. ENVIRONMENT MANAGEMENT PLAN

 10.1 The Environment Management Environment Management                                            Plan     is
      Plan would consist of all enclosed in EMP.
      mitigation measures for each
      item wise activity to be
      undertaken       during     the
      construction, operation and the

Prepared by:-M/s Perfact Enviro Solutions Pvt. Ltd.                                                          35
You can also read
NEXT SLIDES ... Cancel
