INDEX PAGE 2 ...................................................................................................... HOUSING SPECIFICATIONS PAGE 3-4.................................................................................................. THE TINY YORKTON HOUSE PAGE 5............................................................................................... CO-OP CONTRACTORS CHOICE PAGE 6.................................................................................................................................. ARCHITECT PAGE 7-8 .........................................................................................................THE LOON LAKE HOUSE PAGE 9..............................................................................................HOUSING THROUGH EDUCATION PAGE 10........................................................................................................ ALL WEATHER WINDOWS PAGE 11-12..............................................................................................................THE PIIKANI HOUSE PAGE 13 ......................................................................................................................ENCAPSULATION PAGE 14.........................................................................................WOOD ART MANUFACTURING INC PAGE 15-16................................................................................................................ THE LAKE HOUSE PAGE 17.....................................................................................................NET ZERO ENERGY HOMES PAGE 18............................................................................................. PASSIVE HOUSE TECHNOLOGY PAGE 19-20....................................................................................................... THE MOUNTAIN HOUSE PAGE 21-22 ................................................................................................................... CONTRACTORS PAGE 23-24........................................................................................................... THE PRAIRIE HOUSE PAGE 25..............................................................................................NATIONAL HOUSING STRATEGY PAGE 26.......................................................................................................... GUARDIAN FIRE SHIELD PAGE 27-28..........................................................................................................THE CHINOOK HOUSE PAGE 29 .................................................................................................................. MOLD IN HOUSING PAGE 30 ............................................................................................................... HOME REMODELING PAGE 31-32 ...................................................................................... LITTLE HOUSE ON THE PRAIRIE PAGE 33........................................................................... SASKATCHEWAN NEW HOME WARRANTY PAGE 34......................................................................................... ALBERTA NEW HOME WARRANTY PAGE 35-36...................................................................................................THE LAKE GREEN HOUSE PAGE 37-38................................................................................................................MERIDIAN SOLAR
HOUSING
Framing Floor • Engineered wood floor syste
S P E C I F I C AT I O N S
Electrical
• 100 amp service
• Solid blocking • Central vac drops, telephone jacks, cable rough-ins
• 3⁄4” sheathing glued and screwed • Standard light fixture allowance
• Sanded plywood underlay – lino areas only • Decora switches & plugs
• LVL around perimeter Exterior Walls • All plugs, switches & lights as per code
• 8’ exterior wall height • Vent fans electrical rough in conduit only (site electrical
• 2 x 6 construction grade spruce contractor to wire all vent fans on)
• 16” o.c.; dbl top plate, single bottom plate
• 3/8” OSB sheathing to bottom of joist Interior Finish Closet
• 2 x 10 window & door headers, inside ply is continuous • Painted – closet shelves c/w one rod & hardware Doors &
Interior Walls Bifolds
• 2 x 4 construction grade spruce 16” O.C.; dbl top plate,
single bottom plate roof • Colonist w/maple, oak, or painted jambs Trim
• Gable roof • 2 1⁄4” maple, oak, (natural colour only, stain colours
• 4/12 roof pitch (extra charge) or painted casings and baseboards Hardware
• Roof trusses @ 24” o.c.; 24” end overhang • Weiser door locks
• 7/16” OSB sheathing w/ clips • Chrome paper holders
Exterior Finish Roof • IKO Cambridge fiberglass shingle Kitchen Cabinets
• Domed vents and metal flashing • Flat panel oak/maple/alder/beech/white
• Continuous eavestrough with downspouts Soffit • 2 1⁄4” crown moulding above upper cabinets
• Prefinished metal fascia & soffits siding • Beveled edge laminate countertop
• KWP Fibre Cement Siding
• House wrap Painting
• 1 prime coat, 2 finish coats; final coat completed
Windows & Exterior Doors Windows P.V.C. • Painting trim as required
• Triple pane low-e/argon, awning, casement/fixed Doors • 2 colours included (Dulux paint)
• Fiberglass insulated; 3’0” exterior doors
Floor Covering
Insulation • Vinyl in kitchen, dining, and bath areas
• R22 walls & R50 ceiling • Good quality carpets
• 6 mil GSB poly, caulking to all required areas • 8lb. undercushion
• Windows & door perimeters spray foam and batt insulated Drywall
• 1⁄2” for walls, 1⁄2” CD for ceiling
• Aquaboard in bathrooms Service
• Knockdown down textured ceiling • 14 riser stair straight run/installed by owner
• Round corner head
• Stairwell walls by owner
Plumbing
• 1-piece bathtub/shower
• Kohler toilets (installed) 1.28 GPF lined tank
• Kohler china sinks
• Double stainless steel kitchen sink
• 1-piece shower c/w chrome glass door
• Ventilation fans as per CAN/CSA-F326 to be installed by heating
contractor
• Kohler single lever Posi-Temp chrome bathroom single lever in shower,
kitchen w/ spray
• Ventilation system rough-in as per CAN/CSA-F326
• All drains to floor joists and water lines to shut-off
• HRV Ventilation
2
28'-0" 4'-0"
10'-6" 9'-4" 8'-2"
60" x 48 1/4"
48" LIVING 48" W x 18" D VANITY
30"X60"
TUB SHOWER
BEDROOM
2
G2
48 1/4" x 40 3/8"
DINING 28"
12'-6"
30"
36"
KITCHEN
8" EXTENDED COUNTER TOP
7'-0"
24" RANGE 30"
REFRIGERATOR
48 1 4" x 60" 36 3/8" x 40 3/8"
3
VENTING SCHEDULE G2
BATH FAN VENT TO EXTERIOR
INSULATION SCHEDULE
THE TINY
CEILING R-40 MIN. FLOOR PLAN
WALL R-20 MIN. 1 SCALE: 1/4"=1'-0"
S
JOISTS PERIMETER R-19 MIN.
E
OS
WINDOW SCHEDULE
P
NUMBER QTY DIMENSIONS WIDTH HEIGHT DESCRIPTION
R
W01 1 58-3/4"X47" 58-3/4" 47" CASEMENT
YORKTON
W02 1 47"X39-1/8" 47" 39-1/8" CASEMENT
PU
W03 1 47"X58-3/4" 47" 58-3/4" CASEMENT
W04 1 35-1/8"X39-1/8" 35-1/8" 39-1/8" CASEMENT
N G
ON
TI
DOOR SCHEDULE
NUMBER QTY DIMENSIONS WIDTH HEIGHT DESCRIPTION
TI
O
D01 1 37-13/16"X82-5/16" 37-13/16" 82-5/16" STEEL DOOR W/ LOCKSET+DEAD BOLT, GLAZING
U
D02 1 28" 28" POCKET DOOR W/ LOCKSET
UC
D03 1 30" 30" POCKET DOOR
NOTE:
Q
TR
-FOR MORE INFO REFER TO QUOTED DOOR AND WINDOW PACKAGE.
O R
NS
Y F
CO
R
HOUSE
A
OR
IN
TF
L IM
NO
P RE
3
FEATURES - AMENITIES & SPECIFICATIONS
CEILING: Vaulted or Recessed (Optional)
TUBED NATURAL LIGHTING (Optional)
WINDOW : Triple Pane
KITCHENS: All Wood , Soft Close Doors and Draws (Optional Granite Marble Counter Top
FLOORING : Standard Vinyl Plank (Optional Hardwood, Tile or Carpet
INSULATION: Ceiling (Blown-in)
WALL: R22
CLOSET ORGANIZERS : Wire Shelf
DECK ,STAIRS or RAILING ( Optional)
GARDEN DOORS: Patio or French Doors
SPECIFICATIONS
FLOOR AREA : 350Sq ft
ROOFING : 25 year
BATHROOMS: 1 STAND UP SHOWER: 1
BEDROOM: 1
UTILITIES LOCATION: Crawl Space
BASEMENT OPTIONS: PWF
ICF PANEL
POURED CONCRETE
4
The CO-OP Contractor’s Choice is an exclusive program that allows the opportunity for the Co-operative Retailing
System to connect with contractors working in the construction industry throughout Western Canada.
Monthly publications Contractor’s Choice e-News provides readers with informative, industry specific stories and
product information relevant to the professional contractor.
Sign up for free online! Members are afforded the additional benefit of special offers only available with each edition.
5
You create it, We’ll Build it!
Start Here!
6
THE
LOON LAKE
HOUSE
7
FEATURES - AMENITIES & SPECIFICATIONS
CEILING: Vaulted or Recessed (Optional)
TUBED NATURAL LIGHTING (Optional)
WINDOW : Triple Pane
KITCHENS: All Wood , Soft Close Doors and Draws (Optional Granite Marble Counter
Top FLOORING : Standard Vinyl Plank (Optional Hardwood, Tile or Carpet
INSULATION: Ceiling (Blown-in)
WALL: R22
CLOSET ORGANIZERS : Wire Shelf
DECK ,STAIRS or RAILING ( Optional)
GARDEN DOORS: Patio or French Doors
SPECIFICATIONS
FLOOR AREA : 459Sq ft
ROOFING : 25 year
BATHROOMS: 1 STAND UP SHOWER: 1
BEDROOM: 1
UTILITIES LOCATION: Crawl Space
BASEMENT OPTIONS: PWF
ICF PANEL
POURED CONCRETE
8
