PRODUCT GUIDE
    2018/2019
PRODUCT GUIDE 2018/2019 - Datavideo
CONTENTS
    MOBILE VIDEO STUDIOS           7   4K VIRTUAL MULTICAMERA    15   PTZ CAMERAS          23   RECORDERS           30
    OBV-3200    NEW                    PROCESSORS                     PTC-200                   HRS-30
    OBV-2850                           KMU-100                        PTC-150                   HDR-90     NEW
    MS-3200     NEW                    RMC-185                        PTC-150T                  HDR-80     NEW
    MS-2850                            KMU-50     NEW                 PTC-140T   NEW            HDR-70
                                                                                                HDR-60
                                                                                                HDR-1
    PORTABLE VIDEO PRODUCTION      9   MONITORS                  16   NIGHTHAWK CAMERA     25
    STUDIOS                            TLM-170P/PM/PR                 NH-100     NEW
    GO 500 Studio                      TLM-170L/LM/LR                                           REPLAY              33
    GO 650 Studio                      TLM-700K NEW                                             HDR-10
    GO 1200 Studio                     TLM-700HD                      BLOCK CAMERAS        27   RMC-400
    GO KMU-100 Studio   NEW            TLM-430                        BC-200
                                       TLM-102    NEW                 BC-80
                                                                      BC-50                     TV WALL PROCESSOR   35
    HAND CARRY PORTABLE STUDIOS   10                                                            TWP-10
    HS-3200     NEW                    CONVERTERS                18
    HS-2850                            DAC-70                         CAMERA ACCESSORIES   28
    HS-2200                            DAC-60                         HBT-11                    ENCODERS            36
    HS-1600T    NEW                    DAC-50S                        HBT-10                    NVS-40     NEW
    HS-1300     NEW                    DAC-45     NEW                 RMC-300C   NEW            NVS-30
                                       DAC-9P                         RMC-180                   NVS-25
                                       DAC-8P                         SLD-1
    DIGITAL VIDEO SWITCHERS       12                                  WM-1
    SE-3200                                                                                     DECODERS            37
    SE-2850                            CONVERTER ACCESSORIES     20                             NVD-35
    SE-2200                            MB-4                           CAMERA CONTROL       29   NVD-30
    SE-1200MU                          MB-5                           MCU-100J/P/S
    RMC-260                            RMK-2                          RMC-230
    SE-650                                                            CCU-100J/P/S              STREAMING SERVERS   39
    SE-500HD                                                          AD-2P/S/J                 DVS-200
    SE-500MU    NEW                    DISTRIBUTION AMPLIFIERS   21                             NVS-200
                                       VP-840
                                       VP-597
                                       VP-445                                                   INTERCOM            40
                                                                                                ITC-100
                                                                                                ITC-200E

2
PRODUCT GUIDE 2018/2019 - Datavideo
INTERCOM ACCESSORIES        41   CHROMAKEYER ACCESSORIES   47   CHARACTER GENERATORS   55   CABLES    61
ITC-100SL                        MAT-2                          CG-500                      1066
TD-3                             MAT-5                          CG-350                      CA-64
TB-5                             MAT-6                          TC-200                      CAD-02
TB-20                            MAT-7                          TC-100                      DVM2266
HP-1                             TA-1                                                       CB-2
HP-2                             TA-2                                                       CB-7
HP-2A                            TA-3                           POWER DISTRIBUTION     57   CB-8
HP-3                                                            PD-6                        CB-9
CB-3                                                            PD-4A                       CB-10
CB-4                             SAMPLING VECTORSCOPES     49   PD-2A                       CB-14
                                 VS-100                         DDC-4012H                   CB-15D
                                 VS-150                                                     CB-15U
VIRTUAL STUDIO SYSTEMS      43   MB-6                                                       CB-17
TVS-2000A   NEW                                                 REPEATERS              59   CB-19
TVS-1200A                                                       VP-781                      CB-20
TVS-1000A                        AUDIO MIXING AND          50   VP-737                      CB-25
                                 MANAGEMENT                     VP-634                      CB-26
                                 AD-200                         VP-633                      CB-27
VIRTUAL INTERACTIVE BOARD   45   AD-100M                        VP-605H                     CB-28
VGB-500     NEW                  AM-100                                                     CB-29
MGB-5                            BAC-03                                                     CB-40
FS-210                           DAC-80                         ALL IN ONE CABLES      60   CB-41
IEPEN                            DAC-90                         CB-22H                      CB-51
LBK-1                            DAC-91                         CB-23H                      CB-59
                                                                CB-24                       CB-60
                                                                CB-30                       CB-61
CHROMAKEYER                 46   TELEPROMPTERS             52   CB-31                       CB-62
DVK-300HD                                                       CB-43                       CB-64
                                 DVP-100
                                 TP-650                         CB-44
                                 TP-500                         CB-45
                                 TP-300                         CB-46
                                 TP-150                         CB-47
                                 WR-500
                                 LBK-1
                                 LBK-2

                                                                                                           3
PRODUCT GUIDE 2018/2019 - Datavideo
R
                            W
                                AR
                                     RANTY - For
                                                    fu
                                                         rt
                                                              he
                                                                                3 YEAR WARRANTY
                   EA
                                 Register                                       One of the core values of Datavideo is service. To make sure that every
               Y

                   3                                           r
                                                                   de
           3

                                   for                                          user of Datavideo equipment has a trustworthy experience we do our
               E

                                                                   ta
            RE

                                                                                utmost best, day after day, year after year. We are confident that our

                                                                       ils
                                        year
    for a F

                                                                                products give you reliable service and we seal that confidence by a

                                                                        visit
                                                                                one year warranty period.
                                       warranty
                                                                       ww
    -

                                                                                On most products, it’s possible to extend that warranty for extra two
      ct

                                                                          w
            u

                                                                                years after registering. Please make sure to register your Datavideo
                                                                   .d
         od

                                                                   at
              pr

                                                                                product directly after purchasing for a 3-year warranty.
                                                                   a

                                                              vi
                   ur                                    de
                        yo        r           com
                                                    o.
                             iste     - Reg

4
PRODUCT GUIDE 2018/2019 - Datavideo
MISSION STATEMENT
Based in Taipei, Datavideo engineers, designs and manufactures a wide range of innovative technologies for the
Broadcast, AV, Live Events, and Education markets. Datavideo brings high-end product features to customers that
want cost-effective solutions, broadcast quality performance, and world-class reliability. In a fast-changing market
with increasing demands, Datavideo’s innovative solutions that are developed in-house allow users to invest in the
latest technology at affordable prices.

Datavideo has spread globally, with subsidiaries in America, Canada, Netherlands, Singapore, Hong Kong, India,
France, and China. With regional offices in North America, Europe, the Indian sub-continent and South East Asia,
and a global network of distributors, Datavideo delivers full support to resellers, end users, and integrators.

                                                                                                                       5
PRODUCT GUIDE 2018/2019 - Datavideo
6
PRODUCT GUIDE 2018/2019 - Datavideo
MOBILE VIDEO STUDIOS
                                           Video Production On The Road

         OBV-3200                                      OBV-2850                                         MS-3200                                         MS-2850
  12 Input HD OB Van Studio                    8 to 12 Input OB Van Studio                        12 Input Flyaway Studio                      8 to 12 Input Flyaway Studio

• Supports 12 HD inputs in a variety         • Supports up to 12 HD or SD inputs             • Supports 12 HD inputs in a variety            • Supports up to 12 HD or SD inputs
  of configurations                            in a variety of configurations                  of configurations                               in a variety of configurations
• Supports 1080P 50/60 input and             • Supports 1080P 50/60 input and                • Flyaway case design for portability           • Flyaway case design for portability
  output                                       1080P 25/30 output                              (+/- 60kgs depending on                         (+/- 60kgs depending on
• Standard fitted with 8 channel             • Standard fitted with 8 channel                  configuration)                                  configuration)
  intercom up to 14 channel optional           intercom                                      • Standard fitted with 8 channel                • Standard fitted with 8 channel
• Lots of optional accessories               • Lots of optional accessories                    intercom                                        intercom
  available like recorders, audio              available like recorders, audio               • Lots of optional accessories                  • Lots of optional accessories
  mixers, test & measurement tools,            mixers, test & measurement tools,               available like recorders, audio                 available like recorders, audio
  streaming encoders and many more             streaming encoders and many more                mixers, test & measurement tools,               mixers, test & measurement tools,
                                                                                               Digital Intercom and many more                  streaming encoders and many more

                     Mobile Video Studios are all-in-one video production studios in a rugged aluminum flyaway case or a highly customizable OB Van
                    mobile kits. All flyaway and OB Van kits are built around our acclaimed switcher range and these kits contain accessories like monitors,
                     recorders, streaming encoders and measurement tools. Optional car mounting solutions are also available for OB Van kits, and fit to
                                           different vehicles and setups. For predefined configurations please visit www.datavideo.com

                                                                                                                                                                                     7
PRODUCT GUIDE 2018/2019 - Datavideo
8
PRODUCT GUIDE 2018/2019 - Datavideo
PORTABLE VIDEO PRODUCTION STUDIOS
                                          Modular Studios For On The Go

      GO 500 Studio                                   GO 650 Studio                                   GO 1200 Studio                                GO KMU-100 Studio
  4 Input Mixed Resolution                            4 Input HD Studio                               6 Input HD Studio                             Virtual multicam studio
           Studio
• 4 input HD/SD portable video                • 4 input HD portable video                      • 6 input HD portable video                      • Converts two 4K video inputs
  studio with built-in audio mixer              studio with built-in audio mixer                 studio                                           into up to eight HD screen
• Supports up to Full HD 1080p in             • Dual Chromakey and DSK for                     • Dual Chromakey and DSK for                       cutouts
  mixed resolutions/standards                   text overlay                                     text overlay                                   • Switcher interface to seamlessly
• HDMI inputs and outputs                     • "Stinger" animated transitions for             • "Stinger" animated transitions for               switch between the 8 cutouts
• Supports Lumakey for titles                   stunning effects                                 stunning effects                               • Allows video selection by
• H.264 streaming and recording               • Virtual set backgrounds and                    • Virtual set backgrounds and                      joystick, location preset, and
                                                stinger transitions included                     stinger transitions included                     real-time motion path
                                              • SDI and HDMI inputs and                        • SDI and HDMI inputs and                        • Integrated professional audio
                                                outputs                                          outputs                                          mixer for voice synchronization
                                              • H.264 streaming and recording                  • H.264 streaming and recording                  • H.264 streaming and recording

                      Datavideo GoKits are portable, modular all-in-one video production kits that are just ready to go out of the box. With this kit, you can
                      switch, stream, record, audio mixing and monitor your production while a single power source ensures you of convenient operation.
                     The Dual 10.1” LCD monitor is also featured vectorscope and waveform function. All GoKits are safely packed in a protective wheeled
                                                                  suitcase for perfect operability on the road.

                                                                                                                                                                                     9
PRODUCT GUIDE 2018/2019 - Datavideo
HS-3200
       12 Input HD Mobile Studio

     • A complete professional
       broadcasting solution for switching,
       recording, streaming and
       monitoring
     • Supports 12 HD inputs in full
       1080p resolution
     • A grand total of 9 outputs in full
       1080P, 5x SDI and 4x HDMI
     • Up to 8 picture in picture with Flex
       Source support
     • 4x upstream keyers, 2x DSK and
       2x independent logos or dual
       chroma keyer
     • Instant buttons for starting/
       stopping recording and streaming
     • Built-in animated stinger transitions
       and virtual set backgrounds

10
HAND CARRY PORTABLE STUDIOS
                               The World's Most Compact Video Studio

          HS-2850                                        HS-2200                                          HS-1600T                                           HS-1300
8 to 12 Input HD/SD Mobile                         6 Input HD/SD Mobile                             4 Input HDBaseT Mobile                           6 Input HD Mobile Studio
           Studio                                           Studio                                           Studio
• Supports up to 12 HD or                      • Supports up to 6 HD inputs in a                 • Built-in HDBaseT technology                     • A complete solution for
  SD inputs in a variety of                      variety of configurations                         allows you to run power,                          switching, recording, streaming
  configurations                               • 5 SDI and 1 HDMI freely                           uncompressed video, camera                        and monitoring
• 3 SDI and 1 HDMI freely                        assignable output channels with                   control, and tally over a single                • 2 built-in keyers for
  assignable output channels                     matrix switching                                  CAT6 ("network") cable                            chromakeying or lumakeying
• 2 PIP and 2 DSK assignable for               • 2 PIP and 1 DSK assignable for                  • Built-in H.264 streaming encoder                • H.264 recorder and streaming
  luma key or alpha key                          luma key or alpha key                             and recorder for seamless                         encoder for seamless online
• Built-in graphic overlay system              • Built-in graphic overlay system                   broadcasting on the internet                      broadcasting
  for HDMI title input, software                 for HDMI title input, software                  • Supports 3 HDBaseT cameras                      • Instant buttons for starting/
  included                                       included                                          and 1 HDMI input for titles or                    stopping recording and
• Built-in 8 Channel Intercom/                 • Built-in 8 Channel Intercom/                      external source                                   streaming
  Talkback system for                            Talkback system for                             • Built-in camera controller with a               • Built-in animated stinger
  communication with camera                      communication with camera                         joystick and preset buttons                       transitions and virtual set
  crew                                           crew                                            • Built-in audio line in and audio                  backgrounds
• Built-in audio delay for lipsync             • Built-in audio delay for lipsync                  mixer with hardware faders

                     All-in-one hand carry video production studio are super lightweight portable suitcase design mobile video studios, easy to transport, carry
                                                 and feature a convenient safety cover for protection of the backside connectors.

                                                                                                                                                                                       11
SE-3200                             SE-2850                             SE-2200
         12 Input HD Switcher               8 to 12 Input HD/SD               6 Input HD/SD Switcher
                                                  Switcher
     • Supports 12 HD inputs in full    • Supports up to 12 HD or           • Supports 6 HD or SD inputs in a
       1080p resolution                   SD inputs in a variety of           variety of configurations
     • A grand total of 9 outputs in      configurations                    • User-defined output options
       1080P 50/60, 6x SDI and 3x       • 4 SDI and 2 HDMI output             on 6 SDI and 2 HDMI output
       HDMI                               channels                            channels
     • Up to 8x picture in picture by   • 2x PIP and 2x DSK with a setup    • 6x6 SDI Genlocked Matrix
       Flex Source support                choice of basic Luma key or       • 2 PIP and 1 DSK with a set up
     • 4x upstream keyers, 2x DSK and     alpha channel                       choice of basic Luma key or
       2x independent logos or dual     • Built-in graphic overlay system     alpha channel
       chroma keyer                       for HDMI title input, software    • Built-in graphic overlay system
     • Built-in animated stinger          included                            for HDMI title input, software
       transitions and virtual set                                            included
       backgrounds

12
DIGITAL VIDEO SWITCHERS

        SE-1200MU                                RMC-260                                      SE-650                                  SE-500HD                                  SE-500MU
     6 Input HD Switcher                 SE-1200MU Remote Controller                     4 Input HD Switcher                    4 Input Mixed Resolution                  4 Input Mixed Resolution
                                                                                                                                        Switcher                                  Switcher
• Supports 6 HD inputs                    • A switcher style keyboard for          • 4 channel HD video switcher             • 4 channel mixed resolution                • Rack mounted video switcher
• 2x DSK and 2x PiP with dual               controlling the SE-1200MU                with audio mixer                          video switcher with audio mixer           • Built-in video scaler for mixed
  chromakeyer                             • Supports user memory keys              • Full size control panel and             • Full size control panel and                 resolution/standards inputs
• 2 SDI and 2 HDMI output                 • RS-232 interface for                     hardware faders                           hardware faders                             up to 1080p
  channels                                  communication between RMC-             • DSK, PiP and dual chromakeyer           • 1 Luma-key and PIP                        • Control via app – Available
• Switch over IP, external control          260 and SE-1200MU                      • 1 SDI and 2 HDMI output                 • Built-in video scaler for mixed             for Windows, Mac OS, iOS,
  or RMC-260 control panel                                                           channels                                  resolution/standards inputs up              and Android
• Built-in animated stinger                                                        • Built-in animated stinger                 to 1080p                                  • IP or RS-232 control
  transitions and virtual set                                                        transitions and virtual set             • Allows external audio
  backgrounds                                                                        backgrounds                               connection for embedding
                                                                                                                               audio into HDMI video

                                     All the Datavideo switchers are designed for seamless switching with multiple keying options amongst other features. The complete
                                            switcher lineup features internal Gen-lock for all inputs, and are equipped with a mixer supporting audio-follow-video.

                                                                                                                                                                                                             13
14
4K VIRTUAL MULTICAMERA PROCESSORS

             KMU-100                                  RMC-185                                          KMU-50
        2 Input 4K Virtual                      KMU-100 Remote Controller                         1 Input 4K Virtual
       Multicamera Processor                                                                     Multicamera Processor
    • Generates up to eight cutouts             • Provides easy and intuitive                • Generating 4 cutouts from one
      out of one or two 4K inputs                 control of the KMU-100                       4K Camera
    • 12G-SDI, Quad 3G-SDI or                   • Easily pan, tilt and zoom using            • Create motion paths for
      HDMI 2.0 inputs                             the joystick to create the user              automatic panning
    • 8 channel switcher to switch                defined windows on the 4K                  • 4 HDMI outputs
      between cutouts                             signal                                     • RS-422 Control Interface
    • Create speed sensitive motion
      paths
    • Control through RMC-185
      hardware controller

          Datavideo KMU series are specially designed for generating up to 8 HD user-defined outputs from two 4K cameras
                              and supports 3840 x 2160p video input / 1920 x 1080p video output.

                                                                                                                               15
TLM-170P/PM/PR                        TLM-170L/LM/LR
        17.3” HD/SD Monitor                  17.3” HD/SD Monitor

     • 17.3” Full HD 1920x1080 panel      • 17.3” Full HD 1920x1080 panel
       resolution; Industrial standard;     resolution
       Application life 50,000hrs         • 1 x 3G/HD/SD-SDI, 2 x HDMI
     • 1 x 3G/HD/SD-SDI, 2 x                Video Inputs
       HDMI, 1 x HD/SD-YUV, 2 x CV        • 1 x 3G/HD/SD-SDI Loop
       Inputs.                              Through
     • 1 x 3G/HD/SD-SDI, 1 x              • Tally Light
       Composite Video Loop Through       • 3G-SDI Support, Blue Only,
     • 3x Mono RCA Inputs Stereo            Safe Frame, Pixel Zoom up to 8x
       Speakers
     • PIP, Blue Only, Audio Level
       Indicator, Safe Frame, Pixel
       Zoom up to 8x, Network IP
       Remote, SDI Time Code Display,
       Tally Light

16
MONITORS
                                       Broadcast Quality LCD Monitors

          TLM-700K                             TLM-700HD                           TLM-430                           TLM-102
         7" 4K Monitor                      7” HD/SD Monitor                4.3" Look-Back Monitor                Dual 10” Monitor

• 1920x1200 panel resolution           • 7” HD 800x480 panel              • 4.3" 480x272 panel resolution    •1280x800 panel resolution
• 4K 25/30P HDMI input and               resolution                       • 2x CVBS Inputs                   • 1 x 3G/HD/SD-SDI, 1 x HDMI
  loop out                             • 1 x HD/SD-SDI, 1 x HDMI, 1 x     • Tally Light                        inputs and loop outs
• Power available by batteries           HD/SD-YUV, 1 x CV Inputs         • Remote Controllable by           • Support column (YRGB peak),
• Support Focus assist, False Color,   • Blue Only, Safe Frame, SDI         Datavideo RMC-200                  time code, waveform, vector
  Histogram, Exposure, Zoom,             Time Code Display, Audio Level   • Power available by adapter and     scope & audio level meter,
  Pixel to Pixel, Underscan, Check       Indicator, Safe Frame, Image       battery                            peaking, zoom, pix to pix,
  Field                                  Flip                                                                  underscan, check field
                                       • Tally Light                                                         • SDI, HDMI cross conversion
                                       • Power available by batteries

                                                                                                                                             17
DAC-70                                DAC-60
             Up Down Cross                           SDI to VGA

     • Convert video signals from VGA,     • Supports 3G/HD/SD-SDI to
       HDMI, SDI with Audio input to         VGA conversion
       3G/HD/SD SDI and HDMI               • SDI loop through is unaffected
       ouptuts                               by the adjustments to the VGA
     • 3G-SDI technology with full 10        signal
       bit processing and low SDI jitter
     • RCA audio embedding

18
CONVERTERS
                                        Signal To Signal Perfection

        DAC-50S                               DAC-45                               DAC-9P                              DAC-8P
    HD-SDI to Analogue                    4K Up Down Cross                        HDMI to SDI                         SDI to HDMI

• Converts 3G/HD-SD SDI              • Supports VGA/HDMI/SDI to           • Supports HDMI to 3G/HD/           • Supports 3G/HD/SD-SDI to
  input to analogue video and          4K HDMI/3G-SDI multi-format          SD-SDI conversion                   HDMI conversion
  2 unbalance analogue audio           up/down/cross conversion           • Audio can be embedded within      • Loop through SDI output with
  channels                           • Support 3G-SDI Level A/B             SDI output signal                   embedded audio
• Two available output               • Reference input (Black Burst and   • Supports YUV and RGB color        • Supports YUV and RGB color
  combinations:                        Tri-Level Sync.)                     space                               space
 - 1 x YUV output & 1 x CV output    • Built-in De-interlacer and
 - 1 x S-Video (Y/C) output & 2 x      Interlacer (I/P conversion)
   CV outputs                        • RCA audio embedding
• Supports PAL/ NTSC output

                    Datavideo DAC series converters are made to last. With ultra durable protective metal housings that can
                                                withstand any abuse that you throw at them.

                                                                                                                                               19
CONVERTER ACCESSORIES

               MB-4                                MB-5                               RMK-2
      DAC Series Battery Holder            DAC Series Tripod Mount             2U Rackmount Kit for DAC

     • Supports Sony, Panasonic,         • Attach to a tripod leg/table leg   • Rackmount Frame to hold up to
       Canon, and JVC 14.4V or 7.2V        with a velcro strap                  8 DAC Converters
       battery                           • Plate slides onto the bottom of    • Built-in power distributor for up
     • Plate slides onto the bottom of     the DAC                              to 8 converters
       the DAC

20
DISTRIBUTION AMPLIFIERS

         VP-840                              VP-597                            VP-445
    1x4 4K HDMI Splitter                2x6 3G-SDI Splitter                1x4 HD-SDI Splitter

• 1 x HDMI input and 4x HDMI       • 2 x 3G/HD/SD-SDI inputs           • 1 x HD/SD-SDI inputs
  outputs                          • 6 x 3G/HD/SD-SDI distribution     • 4 x HD/SD-SDI distribution
• Supports 4K2K@60 4:4:4 8bits       outputs                             outputs
• Supports High Dynamic Range,     • Supports embedded audio SDI       • Supports embedded audio SDI
  which is 4K2K@60 4:2:0 10bits    • Two input video can be
• HDMI 2.0a compliant, HDCP          controlled by A/B switch or GPI
  2.2 and 1.4 compliant              remote
• Supports Dolby Digital, DTS-HD
  and Dolby TrueHD audio

                                                                                                       21
22
PTZ CAMERAS
                                                State Of The Art Cameras

           PTC-200                                     PTC-150                                     PTC-150T                                       PTC-140T
          4K Camera                                  1080P Camera                            1080P HDBaseT Camera                           1080P HDBaseT Camera

• 1/2.3 inch CMOS sensor, 4K                 • 1/2.8 inch CMOS sensor.                    • 1/2.8 inch CMOS sensor.                     • 1/2.8 inch CMOS sensor.
  UHD 3840 x 2160 resolution                   1920x1080px Full HD                           1920 x1080px Full HD                         1920x1080px Full HD
• 12x Optical Zoom,                            resolution, 60fps                            resolution, 60fps                             resolution, 60fps
• 1x 3G-SDI, 1x HDMI video                   • 30x Optical Zoom                           • 30x Optical Zoom                            • 20x Optical Zoom, 10x Digital
  output                                     • 1x 3G-SDI, 1x HDMI, 1x CVBS                • 1x 3G-SDI, 1x HDMI, 1x CVBS                   Zoom
• Digital noise reduction function             video output                                 video output from camera                    • HDBaseT technology
  (DNR)                                      • Digital noise reduction function           • HDBaseT technology, HDMI                    • Advanced 2D/3D noise
                                               (DNR)                                        output from Receiver                          reduction technology
                                                                                          • Digital noise reduction function            • H.264/H.265 video
                                                                                            (DNR)                                         compression for streaming

                                Datavideo cameras are designed to blend into their environment. They are available in black and white and
                                                                   can be mounted in various positions.

                                                                                                                                                                          23
24
NIGHTHAWK CAMERA
 State Of The Art Cameras

             NH-100
             Datavideo NH-100 Nighthawk is a revolutionary camera made for
             high-end EFP, live events, and stage performances. A Micro Four
             Thirds lens mount ensures the user of a large number of compatible
             lenses currently available. The NH-100 features a 4/3”CMOS
             sensor that is capable of capturing real-time HDR images. This
             camera can achieve stunning results in low-light environments.
             Datavideo NH-100 Nighthawk is truly one of the best performing
             cameras in its class.

             • 4/3” CMOS sensor with full
               HD1080p24/25/29.97/50/59.94 video format
             • High Dynamic Range, and 3D noise reduction execellent for low
               light filming
             • 12-bit processing, captures more color information
             • MFT lens mount
             • 2x SDI and 1x HDMI video output, 2x XLR audio in

                                                                                  25
26
BLOCK CAMERAS
                           State Of The Art Cameras

           BC-200                              BC-80                                 BC-50
          4K Camera                         1080P Camera                       1080P Camera with
                                                                                Streaming Encoder
• 1/2.3 inch CMOS sensor, 4K         • 1/2.8 inch CMOS sensor.            • 1/2.7 inch CMOS sensor.
  (3840 x 2160, UHD) 25/30P            1080p HD resolution                  1080p Full HD resolution
  video resolution                   • 30x optical zoom                   • 20x optical zoom, 16x digital
• 12x optical zoom                   • Digital Noise Reduction Function     zoom
• Digital Noise Reduction Function     (DNR)                              • 3G-SDI output
  (DNR)                              • 1x 3G-SDI, 1x HDMI video           • 3.5mm audio line in
• 2x HDMI video output                 output                             • H.264/H.265/Motion-JPEG
• Controllable by VISCA/DVIP         • Controllable by VISCA/DVIP           compression and IP streaming
                                                                            through RJ-45 connection
                                                                          • Controllable by VISCA/
                                                                            Pelco-C/ Pelco-D

                                                                                                            27
CAMERA ACCESSORIES
                                                                 Make It Single Wire

          HBT-11                            HBT-10                               RMC-300C                             RMC-180                               SLD-1
     HDBaseT Receiver Box             HDBaseT Transmitter Box              Multi Camera Controller                   PTZ Camera                       Shoulder Mount Rig
                                                                                                                      Controller

• HDBaseT Receiver                  • HDBaseT Transmitter               • Remote Control via Ethernet      • Remote control up to 4              • Light & robust aluminum die-cast
• Transmit up to 4K video           • Transmit up to 4K video           • Able to control up to 24           Datavideo PTC/BC cameras              body
• Extend video transmission up to   • Extend video transmission up to     Datavideo PTC/BC cameras         • Control of Pan, Tilt and Zoom       • Power supply from V-mount
  100m (Full HD Mode)                 100m (Full HD Mode)               • Works together with an iPad or     as well as Iris, Focus, Gain, and     battery
• Transmit video, audio, DVIP       • Transmit video, audio, DVIP         Android tablet                     other functions
  Ethernet control, RS-422/232        Ethernet control, RS-422/232      • User friendly interface          • Control via CAT5/CAT6 cable
  and POE from a single               and POE from a single             • Firmware upgrade, tablet           with RJ45 connectors
  Cat.5e/6/6a/7 cable                 Cat.5e/6/6a/7 cable                 charging by USB                  • Compatible with Datavideo's
• Supports DVIP Control Protocol    • Supports DVIP Control Protocol                                         switcher tally indicators
• Supports RS-422/232 Control       • Supports RS-422/232 Control
  Protocol                            Protocol

28
CAMERA CONTROL
                                                                     Ultimate Control From A Distance

        WM-1                             MCU-100J/P/S                               RMC-230                          CCU-100J/P/S                           AD-2P/S/J
Wall Mount for PTC Camera              Multi-camera Control Unit                  MCU Iris/Shutter                  Camera Control Unit                  CCU-100 Transmission
                                                                                   Control Box                                                                Adaptor

• Can be positioned upside-down      • Control and configure up to 4       • Supports Iris / Shutter control   • Connection between CCU-100           • Control camera from a distance
  or rightside-up                      cameras                             • Supports power cascade of           and up to 4 AD-2’s to control 4        between the cameras and the
• Made of steel for durability and   • Transmission up to 300m               multiple RMC-230                    cameras                                CCU Control Unit
  endurance                          • Provides major camcorder            • Can be used with MCU series       • Supports video, camera remote
                                       control functions and operations      for multi-camera control            control, tally and intercom,
                                       such as recording, Iris, Shutter,   • Compatible with Sony camera         power supply, look back,
                                       Gain, Black/white balance,                                                camera view finder data
                                       Pedestals                                                                 transmission
                                                                                                               • Remote control of camera
                                                                                                                 functions including Iris, Shutter,
                                                                                                                 Gain, Master pedestal etc by
                                                                                                                 MCU series

                                                                                                                                                                                    29
HRS-30                           HDR-90
         Fieldside Hand Carry              ProRes Video Recorder
                Recorder                     1U Rackmountable

     • Hard drive based video           • 3G / HD / SD-SDI and HDMI
       recorder with 10.1" monitor        input, output with embedded
     • Record with MPEG-2 4:2:2           audio
       NTFS file system on SSD drives   • Records Compressed in ProRes
       up to 125Mbps                    • Records on two 2.5" SSDs
     • HD/SD-SDI input, output and      • Support DVIP (Ethernet), GPI
       loop through with embedded         and RS-232 control
       audio                            • Supports close caption
     • HDMI output with embedded
       audio
     • V mount Battery and Anton
       Bauer battery supported
     • Genlock, black burst and time
       code supported

30
RECORDERS
                                         Capture Your Creativity

         HDR-80                           HDR-70                            HDR-60                             HDR-1
   ProRes Video Recorder          HD/SD Digital Video Recorder      HD/SD Digital Video Recorder          H.264 USB Recorder
          Desktop                     1U Rackmountable                       Desktop

• Large 5" LCD Touch screen for   • Hard drive based video          • Hard drive based video          • Capture HD Video up to
  operating and monitoring          recorder up to 125 Mbps           recorder up to 125Mbps            20Mbps
• 3G / HD / SD-SDI and HDMI       • HD/SD SDI input, output and     • HD/SD-SDI input, output and     • Record video to USB flash drive
  input, output with embedded       loop through with embedded        loop through with embedded        with NTFS file format
  audio                             audio                             audio                           • Record as MP4 (H.264+AAC)
• Records Compressed in ProRes    • HDMI output with embedded       • HDMI output with embedded         format
• Records on two 2.5" SSDs          audio                             audio                           • Redundant Power recorder
• Support DVIP (Ethernet), GPI    • Record with MPEG-2 4:2:2        • Record with MPEG-2 4:2:2          (UPS)
  and RS-232 control                NTFS file system in MOV or        NTFS file system in MOV or
• Supports close caption            MXF formats                       MXF formats
                                  • Genlock, black burst and time   • Genlock, black burst and time
                                    code supported                    code supported

                                                                                                                                          31
32
REPLAY
Play It Again...And Again...And Again

              HDR-10                            RMC-400
           Instant Replay                     Replay Controller

   • Supports 1080p/1080i/720p         • Control up to 4 HDR-10 Instant
     video resolutions                   Replay at the same time through
   • Internal 4GB (30sec.) Buffer to     USB
     capture and review the event      • Short-cut keys to allow mark-in/
   • GPI interface allows other          out points and save clips
     devices such as switcher to       • T-bar allows speed of replay
     trigger the playback              • Jog wheel allows you to find in
   • RMC-400 or SH-1 as a control        and out points of the replay
     input device required

                                                                            33
34
TV WALL PROCESSOR

TWP-10
                     • Auto stitching display matrix controller for video walls
                     • Distribute a single HDMI input (up to 4K60 resolution) to a 2x2
                       video wall
                     • Four HDMI outputs with resolution up to 1920x1200
4K Video             • HDCP compliant
                     • Software control through USB and Ethernet

Wall Processor 2x2

                                                                                         35
NVS-40
      4 Channel Streaming Encoder/ Recorder

     • Quad input encoder (4 x HDMI, Channel 1
       SDI/HDMI selectable)
     • External audio inputs
     • Supports IP switching
     • Supports Quad View, Full Screen, PiP, PBP, POP
       mode
     • Dual quality encoding per input up to 30 Mbps
     • SSD drive recording

36
ENCODERS                                                                         DECODERS

        NVS-30                                        NVS-25                              NVD-35                                         NVD-30
   H.264 Video Encoder                           H.264 Video Encoder                SDI IP Video Decoder                           HDMI IP Video Decoder
         HDMI                                     SDI/HDMI/CVBS

• 1x HDMI input and output                   • 1x SDI / HDMI / CVBS input       • Decodes video from Datavideo                  • Decodes video from Datavideo
• Streaming videos in RTMP and               • 1x RCA L/R, 2x XLR audio input     encoders, Youtube and Vimeo                     encoders, Youtube and Vimeo
  RTSP formats                               • Streaming videos in RTSP /       • STB functionality for use as a set-           • STB functionality for use as a set-
• Up to 20Mbps Streaming and                   RTMP / HLS formats                 top-box                                         top-box
  30Mbps Recording                           • H.264 / AVC video CODEC,         • Seamless integration with                     • Seamless integration with
• Record on SD card, USB thumb                 up to High Profile Level 4.0       Datavideo DVS-200 streaming                     Datavideo DVS-200 streaming
  drive or network drive                     • Record on USB thumb drive          platform                                        platform
                                                                                • Available in SDI                              • Available in HDMI

   Datavideo encoders are feature rich and easy to configure. Simple looking                   Datavideo decoders decode all different common IP
    Web UI controls ensure you of maximum control over various parameters.                   streams. They form a perfect pair together with our NVS
   Datavideo encoders come in 1 to 4 channels and can stream seamlessly to                 series IP encoders. When used together with DVS-200 they
     Facebook, YouTube, Twitch, UStream and Datavideos own DVS-200.                         can also be used as a set top box featuring a channel list.

                                                                                                                                                                        37
38
STREAMING SERVERS

                 DVS-200                                          NVS-200
             Streaming Server                                  Streaming Server
                in the Cloud                                   on Local Network

• Media Encoding, Decoding, Recording and         • 2RU computer system with built-in DVS-200
  Streaming Platform in the Cloud                   and your choice of a video capture card.
• Stream directly to devices with our white       • Video capture card options: 4 HDMI, 8
  labelled web player                               HDMI, 4 SDI, or 8 SDI
• Stream to content delivery networks like        • Media Encoding, Decoding, Recording and
  Youtube Live, Facebook and more                   Streaming Platform on Local Network
• Distribute streams to other instances of DVS-   • Stream directly to devices with our white
  200                                               labelled web player
• Record streams in DVS-200 for later on-         • Stream to content delivery networks like
  demand playback                                   Youtube Live, Facebook and more
• Run a multi-channel on-demand IPTV network      • Distribute streams to other instances of DVS-
• Real time transcoding options                     200
                                                  • Record streams in DVS-200 for later on-
                                                    demand playback
                                                  • Run a multi-channel on-demand IPTV network
                                                  • Real time transcoding options

                                                                                                    39
INTERCOM

                ITC-100                            ITC-200E
            Intercom System                 Intercom Expansion Unit

     • 1U Rackmountable 8 channels       • Additional 8 channels to ITC-
       Intercom System                     100
     • Communication distance up to
       200 meters
     • Selectable channel talk,
       broadcast to all or mute
     • Bi-colour tally light indicator

40
INTERCOM ACCESSORIES

   ITC-100SL              TD-3                  TB-5                   TB-20                      HP-1
    Belt Pack           Tally Light     Tally Box Converter    Tally Box Converter for     Single-Side Headset
                                                                 Panasonic Switcher

      HP-2                HP-2A                HP-3                    CB-3                       CB-4
Dual-Side Headset   Dual-Side Headset   Single-side Headset   20m 5-Pin Intercom Cable   50m 5-Pin Intercom Cable
                     with 3.5mm Jack    with XLR Connector

                                                                                                                    41
42
VIRTUAL STUDIO SYSTEMS

       TVS-2000A                                                TVS-1200A                                                  TVS-1000A
3D 2 Input 3G-SDI Tracking                               2D 2 Input 3G-SDI Trackless                                 2D 1 Input HDMI Trackless

• Supports Tracking and Trackless                        • Supports 2x SDI and 1x HDMI                             • Supports 2x HDMI video
  Virtual Studio simultaneously                           video input/output                                        input/output
• Supports Datavideo PTZ camera                          • 200 free virtual sets included                          • 200 free virtual sets included
  as a tracking camera
• Supports 2x SDI and 1x HDMI
  video input/output
• 30 free virtual sets included

   Datavideo virtual studios instantly give your production that professional edge you are looking for. With various lifesaving features such as
    a chromakeying wizard and one-click chromakeying. Also included is an easy to use virtual studio creation studios that will easily create
     your own backgrounds. If you want to buy additional virtual backgrounds you can use our portal on www.datavideovirtualset.com All
                            Datavideo virtual studios feature built-in streaming encoding, recording, and CG options.

                                                                                                                                                      43
44
VIRTUAL INTERACTIVE BOARD

          VGB-500
    Pro Presentation System                      MGB-5                                       FS-210
                                        Webinar Presentation System                        Foot Switch
• Combine talent’s image and           • Main system for VGB-500                • Allows user to start and stop
  powerpoint materials as foreground   • 1x SDI and 2x HDMI input/output          program recording at any time
  and background
• High quality Chromakey function
  delivers perfect keying
• live streaming and recording
  simultaneously
• Interactive pen to make notes,
  drawing on the powerpoint slide
• Easy to produce video by talent
  his/herself
• MGB-5, 22” lookback kit, and foot
  switch included
                                                     IEPEN                                   LBK-1
                                           Interactive Electronic Pen                     Look Back Kit
                                       • Allows writing on PowerPoint slides,   • Allows user to view the camera
                                         making notes and flipping pages          image with tally light included

                                                                                                                    45
CHROMAKEYER

                       DVK-300HD
                     HD/SD Chromakey

      • Supports SD and HD resolutions up to 1080P 50/60
      • Foreground supports 1x 3G/HD/SD-SDI, 1x HDMI
      • Background supports 1x 3G/HD/SD-SDI, 1x DVI-I
      • Controlled via PC

46
CHROMAKEYER ACCESSORIES

       MAT-2                     MAT-5                     MAT-6                    MAT-7
Green Color Plastic Mat   Green Color Plastic Mat   Blue Color Plastic Mat   Blue Color Plastic Mat
    1.8M x 27M                1.8M x 54M                1.8M x 27M               1.8M x 54M
      Floor Use                 Wall use                  Floor Use                Wall use

       TA-1                      TA-2                      TA-3
  Green Color Tape          Green Color Tape          Blue Color Tape
   48mm x 25M                96mm x 25M               48mm x 18.3M

                                                                                                      47
48
SAMPLING VECTORSCOPES

          VS-100                                VS-150                              MB-6
    Portable Vectorscope                  Desktop Vectorscope               VS-100 Battery Mount Kit

• HD/SD-SDI input                    • HD/SD-SDI input                    • VS-100 Battery Mount kit
• HD/SD-SDI and HDMI loop            • HD/SD-SDI and HDMI loop            • Perfect to be used in the field
  through output                       through output                     • Support for various battery
• Supports video formats from        • Supports video formats from          plates
  576i to 1080p30                      576i to 1080p30
• Menu choice of Vectorscope,        • Menu choice of Vectorscope,
  Histogram, Waveform and              Histogram, Waveform and
  Parade displays                      Parade displays
• Embedded SDI audio peak            • Embedded SDI audio peak
  meter with selectable monitoring     meter with selectable monitoring
  for four stereo pairs                for four stereo pairs

                                                                                                              49
AD-200                            AD-100M
          Audio Delay Box                      Audio Delay Box
         with Level Adjustment

     • Two in one: Audio Mixer and       • RCA & XLR inputs
       delay                             • Output volume attenuating
     • Support up to 3 sec audio           0-60dB
       delay adjustment for each input   • Audio delay time from 0-700ms
       channel                             1KHz tone output
     • 6-CH Audio mixer and matrix       • Supports XLR mic in and +48V
       router to 4-CH audio outputs        phantom power
     • Audio level adjustment of each    • Built-in balanced or unbalanced
       input                               audio conversion

50
AUDIO MIXING AND MANAGEMENT

          AM-100                              BAC-03                               DAC-80                              DAC-90                            DAC-91
         Audio Mixer                    Balanced/Unbalanced               Audio Isolation Transformer           SDI Audio De-embedder               SDI Audio Embedder
                                           Audio Converter

• Audio level indicator display      • Built-in balanced or unbalanced   • Very low distortion and close to   • De-Embed Audio from SDI         • Auto detects SD and HD signals
• Supports A+V function, the audio     output interchange function         zero attenuation                     Signal                          • Auto sets compatible formats to
  can be switched simultaneously     • Stereo Balanced Audio In / Out    • No Power needed                    • Auto detects video format,        embed external sound sources
  with the video                       via XLR connectors                                                       support up to 1080P 50/60         to SDI output
• Supports XLR microphone input      • Stereo Unbalanced Audio In /                                           • Assignable De-embedded          • Supports SMPTE and EBU
  and +48V phantom power               Out via RCA connectors                                                   audio signal                    • 4 x Analogue Audio inputs (Mini
• Supports Tally signal input        • Robust Metal Construction                                              • Audio level indicator display     XLR x 2, RCA x 2)
                                                                                                              • SMPTE and EBU Audio level       • Audio level indicator display
                                                                                                                switchable                        and adjustment
                                                                                                              • Loop through SDI output

                                                                                                                                                                                51
DVP-100                                TP-650                              TP-500
       DV Prompter Pro Wireless            Large Screen Prompter Kit                  DSLR Prompter
          Prompting System                     for ENG Cameras

     • Keep multiple prompter screens    • Easy to use tablet teleprompter    • Easy to use tablet teleprompter
       in perfect sync                   • iOS and Android app available      • iOS and Android app available
     • Control multiple prompters from   • Suitable for tablets up to 15.6"   • Suitable for tablets up to 11.6"
       one controller                    • Optional wireless remote           • Optional wireless remote
     • Remote control and script           available (WR-500)                   available (WR-500)
       management over IP (WiFi/         • Available in various sizes and     • Available in various sizes and
       Ethernet)                           configurations                       configurations
     • Compatible with any device that
       has an HTML5 compliant web
       browser
     • iOS app available

52
TELEPROMPTERS

           TP-300                              TP-150                               WR-500                             LBK-1                             LBK-2
        Tablet Prompter                  Teleprompter system                 Bluetooth Teleprompter                 Look Back Kit                Look Back Kit for Monitor
                                       dedicated to PTZ cameras                    Remote Control

• Easy to use tablet teleprompter    • PTZ Teleprompter Kit for iPad &   • Bluetooth wireless remote for   • Allows users to view the camera   • Allows users to mount monitors
• iOS and Android app available        Android Tablets                     teleprompters                     image with tally light included     up to 32" with VESA mounting
• Suitable for tablets up to 11.6"   • Remote by bluetooth or wired      • Compatible with Apple and                                             interface
• Optional wireless remote             connection                          Android tablets
  available (WR-500)
• Available in various sizes and
  configurations

                                                                                                                                                                              53
54
CHARACTER GENERATORS
                                                      Slap A Title On It

          CG-500                             CG-350                                     TC-200                         TC-100
      HD/SD Graphic &                 HD/SD Character Generator                     SDI Title Creator               HDMI Title Creator
     Character Generator                     Software

• Timeline based CG (ability to       • Supports PNG sequence                 • Portable title creator        • Portable title creator
   have different objects appear        animations and video clips            • Compatible with CG-200, CG-   • Compatible with CG-200, CG-
   and disappear at different times   • Independent banner crawl                300, and CG-500                 300, and CG-500
   on a single page)                  • Supports lower third titles, text     • Supports downstream and up    • Supports Luma Key, Title overlay
• Supports lower third titles, text     crawls, and text rolls                  stream (key and fill) keys      and Logo overlay function
   crawls, and text rolls             • Layer based CG (ability to have       • Supports HDMI, HD/SD-SDI      • Supports HDMI connections
• 3D and 2D transitions can be          multiple layers per page)               connections
   applied to each object             • Import PNG images with alpha
• Import PNG images with alpha          channel
   channel                            • Import text from an excel file
• Import text from CSV or TXT file    • Supports text variable substitution
                                      • Supports clock, count down,
                                        and count up timer

                                                                                                                                                   55
56
POWER DISTRIBUTION

         PD-6                               PD-4A                               PD-2A                           DDC-4012H
   Camera Power Center               Redundant Power Center                   Power Center                 DC to DC 12/7.2V 4.0A
                                                                                                                   Converter

• Automatically adjusts to work    • Two AC power supplies,           • Combine up-to 10 power           • Automatically accepts input
  with 50Hz or 60Hz supplies       • Supply energy even if one          supplies into a single power       voltages between 15 and
  between 100-240 VAC                power source fails                 connection                         50V DC to provide regulated
• 8 DC 48V outputs with            • Output : 3 x 5A + 2 x 10A 12V    • Output connections: 4 x 3A + 2     7.2/8.4/12V DC output
  a combined total power             XLR DC Female                      x 5A + 2 x 10A 12V XLR DC          depending on its output switch
  consumption of 360W              • Built-in time delay power-                                            setting
• Provide both DC & AC overload      on control to initiate each DC                                      • 2.1 mm Locking Collar DC
  protection                         output terminal                                                       Output switch
                                                                                                         • Max power output 48W / 4A
                                                                                                         • Options for either 4pin XLR
                                                                                                           or 5.5mm PSU type output
                                                                                                           connections

                                                                                                                                            57
58
REPEATERS

       VP-781                             VP-737                                 VP-634                              VP-633                              VP-605H
 HD/SD-SDI and Intercom           Composite Signal Repeater                  100m SDI Repeater                   100m SDI Repeater               All In One Cable Extender
     Repeater Box                                                              (Unpowered)                          (Powered)

• Extended HD/SD-SDI, Intercom   • Wired composite video                • Supports 3G/HD/SD-SDI             • Supports 3G/HD/SD-SDI             • All in one signal repeater
  and Tally signal up to 200m      transmission as far as 200 meters    • Each extended SDI signal up       • Each extended SDI signal up       • Extended cable runs up to 200m
• Cascade CB-46/47/48/50         • Completely adaptive - quick,           to 200m, allowing runs of up to     to 200m, allowing runs of up to   • Supports HD/SD-SDI, CV,
  All in one cable for signal      easy installation and setup, no        1000m                               1000m                               Talkback, Tally & DC input/
  extension                        configuration required               • Requires VP-633 in chain to                                             output
                                 • Cat5e extension design make            supply power                                                          • Supports SDI Embedded Audio
                                   use of existing Cat5e or better
                                   wiring infrastructure

                                                                                                                                                                             59
ALL IN ONE CABLES

         CB-22H                      CB-23H                  CB-24                       CB-30                       CB-31
  HD/SD 30m 4-in-1 Cable      HD/SD 50m 4-in-1 Cable   SD 100m 3-in-1 Cable   HD/SD 30m 4-in-1 Cable      HD/SD 50m 4-in-1 Cable
(HD-SDI/ITC/CV/DC Power)    (HD-SDI/ITC/CV/DC Power)     (SDI/ITC/CVBS)        for Multi-Camera Control    for Multi-Camera Control
                                                                              (HD-SDI/ITC/CV/Cat-5)       (HD-SDI/ITC/CV/Cat-5)

           CB-43                     CB-44                   CB-45                   CB-46                       CB-47
     30m All in one Cable      50m All in one Cable    80m All in one Cable   HD/SD 30m 2-in-1 Cable      HD/SD 50m 2-in-1 Cable
          for CCU                   for CCU                 for CCU               (HD-SDI/ITC)                (HD-SDI/ITC)

60
CABLES

        1066                        CA-64                       CAD-02                DVM2266                         CB-2
IEEE1394 DV Cable-10m   IEEE 1394 4-Pin to 6-Pin Adapter   XLR 4-Pin to DC Jack   1.8m 6-Pin to 6-Pin DV   S-Video to Dual BNC Cable
                                                                                         Cable

       CB-7                        CB-8                          CB-9                   CB-10                     CB-14
   1.2m GPI Cable         3.5mm Jack to XLR Adapter            DVI Cable           HD YUV Cable-3m         YUV 4*BNC-4BNC Cable

                                                                                                                                       61
CABLES

           CB-15D                        CB-15U                      CB-17                              CB-19                       CB-20
0.3m IEEE 1394 Down Angle DV   0.3m IEEE 1394 Up Angle DV   17cm 3.5mm to Dual Earphone            1.8m DVI-D Cable          1.8m DVI to HDMI Cable
             Cable                        Cable                       Cable

            CB-25                       CB-26                             CB-27                           CB-28                        CB-29
φ3.5 EARPHONE(M) TO D-SUB        1-5 cable for TLM-430      Tally cable for SE-2000 Intercom   Tally cable for SE-2800/SE-   Tally cable for SE-3000 to
      9P(F) CABLE L:1.2M             breakout cable                                             2850 to ITC and AM-100            ITC and AM-100

62
CABLES

                CB-40                                                          CB-41                                 CB-51                             CB-59
   Mini Din 9P To 4*BNC Plug Cable                                    XLR 3P-F*2 to XLR 3P-M*2              D-Sub 9P(F) TO Mini-Din 8P   Intercom / Tally Connection Cable
                                                                                                                   Cable 15M                 for SE-1200MU to ITC-100

                 CB-60                                                        CB-61                                 CB-62                             CB-64
         HDMI Active Optical Cable                                   HDMI Active Optical Cable              HDMI Active Optical Cable       Mini Din 6P-M to 6P (10H)
                  - 30m                                                       - 50m                                 - 100m                       PT:2.0 L:400mm

Disclaimers of Product and Services
This brochure is intended as a guide only. We reserve the right to change specifications and availability
without prior notice. While we strive for complete accuracy,
be aware that it may contain errors and omissions. Prior to purchase, please check with your local
Datavideo office or authorised distributor.

                                                                                                                                                                             63
@DatavideoUSA    @DatavideoAsia      @Datavideo          @DatavideoUSA   @DatavideoUSA
@DatavideoEMEA @DatavideoIndia2016   @Datavideo_EMEA     @DVTWDVCN       @DatavideoEurope
@DatavideoTaiwan @Datavideojapan     @Datavideo_Taiwan
                                                                                            180704
You can also read
