COMPANY OVERVIEW September 2018
Presentation
▪ Headquarters : Figline Valdarno (FI) - Italy
▪ Operation Area (new facility) : 500 m2
▪ Turnover 2017 : 1,25 M€
▪ Quality Certification: ISO 9001-2015
▪ Industry Sector:
Railway and Urban Transportation
▪ Technological Expertise:
✓ Electronics
✓ Hydraulics
✓ Pneumatics
✓ Mechanics
2
Presentation
BASIC MILESTONES IN THE GROWTH OF MICROSISTEMI
ANDREA ARDITI had started his experience of global
support for Engineering and Technology.
1980 MICROSISTEMI Srl was founded from an idea of ANDREA
ARDITI and was largely based on his own experience
gained in the railway field in Italy and abroad.
1998
MICROSISTEMI Srl has a new Ownership.
Andrea Arditi is still present as key reference for
Engineering, Technology and Market.
The new Ownership is represented by PAOLO POLI who
2017 gained nearly three decades of experience in the railway
industry sector and is coming from a long entrepreneurial
tradition in his historic family company (POLI Costruzione
Materiali Trazione SpA), now Wabtec.
PAOLO POLI is now conveying into Microsistemi Srl his
own experience, as well as the knowledge of different
products and other areas of the Rail Industry Market.
3
Presentation
The new Ownership wants to guarantee:
▪ Continuity with footprint of the company.
▪ Improvement of operative efficiency by
o moving the working activities into a new plant
(already operative since September 2017)
o best defined functional organization
▪ New opportunities on Italian, European and
worldwide markets through alliances and stretegic
synergies.
▪ New opportunities with new products and COMPANY
applications.
GROWTH AND
EXPANSION
4
Presentation
NEW PLANT OF MICROSISTEMI
5
Presentation
NEW PLANT OF MICROSISTEMI
6
Presentation
FUNCTIONAL ORGANIZATION OF MICROSISTEMI
7
Presentation
TURNOVER PER YEAR: 2012 – 2016 - 2020
8
Our Mission
RESEARCH PRODUCTION
DESIGN
We can create together
Solutions and tailor-made Products
Being a good ‘Supplier’ is not enough for us: our true
Ambition is to become a Partner for our Customers!
Our support is available through all steps of
Design, Validation, Production, Installation, Maintenance,
Overhaul, Revamping…
9
Areas of Experience
ELECTRONICS and ELECTRO-MECHANICS
(developments carried out in the last years):
▪ ECU for electrical doors control
▪ ECU for air suspension levelling system control
▪ Passanger Alarm System (EN-16334)
▪ ECU for safety fuel stopper on diesel traction
▪ Inverter for brushless motor
▪ Driver’s Brake Valve (EN-14033-1:2017)
Repair, maintenance, redesign
and modernization of single boards
or functional sub-systems
10Areas of Experience
▪ Reverse Engineering of functional sub-systems or single
boards, both in obsolescence status.
▪ Complete redesign and full validation in order to
guarantee interchangebility and equivalent performance.
▪ We can guarantee:
MODERNIZATION vs OBSOLESCENCE
11Areas of Experience: Specific Products
INVERTER FOR AUXILIARIES
(Passenger Cars and vehicles with traction)
Design and full production (also according to
customer spec), repair of:
▪ INVERTER CC/CA e CA/CA
▪ Sigle-phase and Three-phase
▪ Power 1 ÷ 4 kW
▪ ACCESSORIES (for any Inverter size)
▪ Autostarter
▪ GPA electronic boards (Pulse
Amplification Group)
▪ Elctronic boards for Control and
Power Supply
12Areas of Experience: Specific Products
ECU for DOORS CONTROL and
AIR CONDITIONING
Repair and full production.
(Coaches Z1, MD, Vicinali, Tram Sirio)
Single ELECTRONIC BOARDS and
complete ECU based on GEMINI 1 or
other platforms.
Repair and full production.
(Passenger Cars, Metro and LRV)
13Areas of Experience: Specific Products
OVEHAUL OR REPAIR OF ELECTRO-
MECHANICAL COMPONENTS FOR
ROLLONG STOCKS:
▪ Driver’s cabin MONITOR
(Tram Sirio e CTR-Minuetto)
▪ Driver’s MANIPULATOR for traction and
braking function
(Tram Sirio)
14Products developed for Customers
▪ Electronic valves for Oerlikon-KB braking System
▪ Redundant antiskid for ETR 500 with Oerlikon-KB
▪ Suspension and levelling electronic control for Lille’s
Tram with AnsaldoBreda
▪ ECU for WSP ATHENA for
Wabtec – FT – Poli
▪ PASSANGER ALARM SYSTEM
compliant to EN 16334) for
Wabtec – FT – Poli
15Microsistemi Products
SANDING SYSTEM
▪ with full logic of control, diagnostics and
adjustable sand flow depending on speed:
0.45 to 3.4 kg/min
▪ simplified version
FUNCTIONS FULL LIGHT
Adjustable sand flow √ X
ON / OFF sand flow X √
Built-in electromagnetic valves (no EP panel) √ √
Internal ventilation: sand heating and drying √ √
Sand ejector heating and final cleaning blow √ √
Sand level sensor √ √
Electronic Control Unit √ X
Complete management of functional logic √ X
Complete diagnositcs √ X
16Microsistemi Products
SANDING SYSTEM - FULL version
Vehicle Sanding Equip.
LRV GreenCity 60 480
Tram R-002 12 96
Tram R-2.65 26 208
One Electronic Control Unit (ECU) per bogie is
managing for all the four sanding device:
▪ functional parameters when sanding command is
activated including adjustable sanding flow
▪ diagnositc signals
17Microsistemi Products
SANDING DEVICE – LIGHT version
▪ No ECU to manage functional parameters and
diagnostics signals that are driven directly by
vehicle logic.
▪ Sand flow is fixed and constant during application,
but it can be regulated during vehicle set-up.
▪ Auxiliaries functions can be implemented as
whole or partial solution:
▪ Sand heating inside the tank
▪ Sand ventilation inside tank
▪ Sand ejection pipe heating
▪ Sand ejection pipe cleaning blow
▪ Sand level inside tank indication
18Microsistemi New Focus
COMPLETE PNEUMATIC SYSTEM TO MANAGE
AUXILIARIES FUNCTIONS ON LRV
▪ Air Generation
and Treatement
▪ Sanding system
▪ Wheel flange
Lubrication
▪ Air suspension
levelling ssytem
▪ Other Auxiliaries
Functions
19Microsistemi New Focus
Air geenration and treatement
by an Oil-Free compressor with
200 l\min @ 7 bar air flow
Sanding device and ECU to
manage functions and
diagnositics with the Air suspension levelling
possibility to have wheel system by levelling valves and
flange lubrication integrated one smart valve to manage
their feeding
20Microsistemi Products
DRIVER’S BRAKE VALVE
(compliant to EN 14033-1:2017)
DOORS CONTROL SYSTEM
Complete with ECU, mechanical and
electrical door actuation, doors
(both single and double door solutions)
21Microsistemi Products
ECU for SAFETY FUEL STOPPER
with data recorder for
diesel traction units.
AIR SUSPENSIONS LEVELLING SYSTEM
with ECU and pneumatic or electro-
pneumatic valves.
22Microsistemi New Developments
Cooling System for power
elements of traction
management chopper
Conversion of conventional HPU
electrical motors into brushless
drive system
23Microsistemi New Focus
OVERHAUL and REPAIR
▪ Hydraulic Power Units
▪ Hydraulic Brake Actuators and
Calipers
SUPPLY, OVERHAUL and
REPAIR
of Magnetic Track Brakes
24Vision for the Future
HOW CAN WE GENERATE TOGETHER
OPPORTUNITIES FOR A COOPERATION ?
▪ REPAIR AND OVERHAUL
▪ PRODUCTION OF SPARE COMPONENTS
▪ PRODUCTION OF SPARE SUB-SYSTEMS
▪ REVERSE ENGINEERING AND MODERNIZATION OF
SIGLE COMPONETS OR FUNCTIONAL SUB-SYSTEMS
▪ DEVELOPMENT OF NEW PRODUCTS
▪ APPLICATION OF EXISTING PRODUCTS
▪ …………………………
