CATALOGUE
ST R AC K LI FT AUTOM AT I ON
Controls/Networks 2021
LIFTnet®
2.1 Controls/Networks 2021 LIFTnet
Network software LIFTnet®
LIFTnet Controls/Networks 2021 2.1
Network for lifts
and technical equipment.
®
LIFTnet
LIFTnet is a software system and network, to which as many lifts, escalators, and tech-
nical equipment with new and old systems can be coupled. The connections take place
over modems and/or IP networks.
LIFTnet can be used as disorder center, visualisation, diagnostics, maintenance and
parameterization station as well as an extension for our electronic lift attendant. Third-
party controls are integrated using the MULTiBUS-Coupler.
LIFTnet is database-driven, therefore, statistical evaluations are tabulated and graphi-
cally preparable. All systems are protected by access controls.
With LIFTnet you get a tool with whitch you can minimize your access routes to the
sites at errors, reduce operating costs and improve the availability, security, and docu-
mentation of your lifts.
STRACK LIFT AUTOMATION 3
2.1 Controls/Networks 2021 LIFTnet
In a nutshell:
n software for stand-alone or client-server mode for unlimited installations
n visualize and control remotely via map, building layout and shaft layout
n set of lift controls with well designed windows
n organize and document your maintenance, responsive and time-oriented
n assess driving comfort by driving curve recording directly on the car
n remote evacuate enclosed lift passengers
n supports the electronic lift attendant of the SLC4, SLC4-20 and MULTiBUS
n database-oriented and open via SQL for other applications
n supports redundant servers and hot backup
n runs under Microsoft Windows XP/Vista/7/8/8.1/10 and Server 2003/2008/2012
LIFTnet Controls/Networks 2021 2.1
Product description
System requirements and infrastructure Visualization by building location map and
The number of accessable lifts or technical �loor plans
equipments is practically unlimited. The con- Here you can see your equipment in building lo-
nection to the systems are made individually cation maps, also nested plans without limitati-
via modem or IP networks. The data transfer on are possible. If you want to build e.g. a fault
can be realised wireless or wired also under headquarter for a plant, you can represent the
sharing existing lines. building location plan of the work as the main
image. If an error message is received, the rele-
Client-server variant vant building is highlighted in red. By clicking,
With the client-Cerver variant, you can enable you get a magnified view with more details to
many users access the LIFTnet database and this building, e.g. the layout position of the lifts
your lifts over Internet, intranet and remote and the faulty lift. Follow the markers by simply
access connections. Data integrity when more clicking on the status indicator and evaluate the
than one user is thereby always guaranteed. messages.
Visualization and remote control Diagnosis
Look at the lift from a distance and control him. See lift misconduct at an early stage. Each lift
Special functions you can activate/deactivate sends status messages and error messages if
and conditionally evacuate even trapped peop- anything happens automatically to multiple
le. The presentation is always carried out with LIFTnet stations. The lift control decides also
the specific data of the lift, such as type and depending on the type of message, to which
location of doors, call buttons and labels of the station the message should be sent. Your fault
floors. A setup wizard helps you add a new lift. service can transfer all the information before
visiting the lift such as fault memory, current
Visualization of lift groups operational status, and the history of all swit-
Represent associated lift groups in a common ching of the in-/outputs of the last travels. You
image. You can set group calls and analyze can give calls, record the true travelling cur-
the behavior. Enabled lifts in the lift group are ves of the car and complement it with switch
shown green, deactivated lifts yellow and dis- ing diagrams. By this previous remote diagno-
turbed lifts are marked red. sis your service team can avoid unnecessary
travels to the lift.
STRACK LIFT AUTOMATION 5
2.1 Controls/Networks 2021 LIFTnet
Parameterization Error sending via SMS or Email
Customize control and regulation parame- LIFTnet may transfer failures, warnings, or
ters from a distance and thus save directions. messages immediately via SMS or email to the
All parameters that are functional related, are relevant personnel. Here, the employees data
grouped into tabs and can be easily changed in are freely configurable.
LIFTnet. You can save all parameters in LIFTnet
and on other similar systems transferred com- Integrated IP connections
pletely or in part. The connection of technical systems can be
done via Ethernet and wireless connections.
Maintenance organization This can be used with the existing network.
Organize your maintenance with LIFTnet. You Access to LIFTnet data is optionally enabled
achieve an improvement of system availability over the intranet or Internet.
and system safety. You can control your main-
tenance needs responsive and time-oriented, LIFTnet database
analyze and document with LIFTnet. LIFTnet LIFTnet uses a professional SQL client/server
offers user-friendly tools like e.g. individually database system to store all data according to
customizable electronic maintenance checklist current standards. It is quick and easy to ins-
for each lift. tall, has a high performance, and requires no
database administrator. The database includes
Electronic lift attendant a standard SQL interface, access is controlled
In combination with the control SLC4, SLC4-20 or through user rights. On request, the entire da-
MULTiBUS and organisational measures com- tabase can be encrypted.
pliance you can and are allowed to replace the
human lift attendant. LIFTnet can help you
(see description of „electronic lift attendant“ in
SLC4-20 or MULTiBUS-Coupler).
Documentation
You can log all the data about printers or files.
Of course, you will receive all messages in un-
derstandable writing.
Activation of other trades
With LIFTnet you can monitor additional trades
such as escalators, heating and air conditioning
systems, cranes, lifting platforms, etc. An elabo-
rate adaptation to plant-specific data telegrams
is not required here, if appropriate in-/outputs
can be connect.
6 STRACK LIFT AUTOMATIONLIFTnet Controls/Networks 2021 2.1 Back-up during operation LIFTnet performs an automatic backup of the database upon request during operation. The so-called hot backup allows you to backup your data without compromising the functionality or manual intervention. Decentralized data collection The LIFTnet database server has a secure data replication function, so that local working, e.g. with a notebook, without connecting to the ser- ver can be performed. After completion of work and renewed connection of the notebook to the LIFTnet server database, the new or changed data are automatically matched with the LIFT- net server database. Connection of external controls (see MULTiBUS-Coupler) STRACK LIFT AUTOMATION 7
