Design and Construction of Domestic
Sewage and Industrial Wastewater
Treatment Plants
HYDROTECH ENVIRONMENTAL
COMPANY PROFILE
&
TECHNOLOGY PRESENTATION
MARCH 2019
1
COMPANY HISTORY
Established in 1979
HYDROTECH ENVIRONMENTAL is a group of
specialized Greek Companies in the field of
environmental protection and especially in the study,
design, construction and operation of domestic sewage
and industrial wastewater treatment plants. The
company group consists of Hydrotech S.A., two
personal companies of George and Andreas
Ganatsios as well as Hydrotech Environmental A.
Ganatsios & Co E.E.
The founding member of the companies is Dr George
Ganatsios, Chemical Engineer, with experience of at
least 35 years in the field of environmental protection.
Since 2007, HYDROTECH ENVIRONMENTAL has
implemented the Ydro Process® in various wastewater
treatment units and by altering parameters has
achieved the pioneering and unique method invention
of sludge elimination, simultaneously achieving plant
optimization and cost reduction.
HYDROTECH ENVIRONMENTAL has entered into
various strategic cooperation's offering solutions in this
area. 2
ACTIVITIES & SCOPE
The basic activities of Hydrotech
Environmental are:
1) Study and Design of municipal &
industrial wastewater treatment plants
2) Construction of turn-key municipal &
industrial wastewater treatment plants
3) Operation and Optimization of
Wastewater treatment plants
4) Implementation of the Ydro Process ®
for elimination of the excess sludge
production in wastewater treatment plants
3
The Ydro Process ®
The Ydro Process ® creates the suitable and optimum conditions for the
growth, the reproduction and the operation of the microbial product which
contains:
1. Hydrolyzing Enzymes
2. Facultative cultures
3. Aerobic cultures
4. Micronutrients
5. Bio-enhancers
The combination of the Ydro Process ® and the addition of the suitable
microbial product results in:
1. Total degradation and elimination of the excess sludge
2. Improvement of the effluent of the plant (BOD,COD,SS,TN,TP etc)
3. Liquefaction and elimination of FOG (fats, oils and grease) in the treatment
plants and in pumping stations
4. Elimination of odors
5. Possible reduction of the energy consumption in the aeration stage
6. Possible increase in the biogas production with a simultaneous increase of
methane content in it
7. Significant reduction of micropollutants
8. Higher resistance to incoming organic shocks 4
The Ydro Process ®
• The Ydro Process ® is the continuous adaptation of the microbial population to the
conditions of each process according to the targets.
• The added bacteria become dominant and the existing ones are adapted and
assimilated to coexist and collaborate.
• In suitable conditions the added microorganisms produce enzymes which enhance the
biological process.
• The degradation of complex organic molecules, oils and greases into simple ones leads
to the production of Volatile Fatty Acids (VFAs), i.e. Acetic, Butyric, Propionic Acid etc.
• The VFAs are then easily converted to Carbon Dioxide (CO2) and water (H2O) in aerobic
conditions, methane (CH4) and hydrogen (H2) in anaerobic conditions and free available
energy.
• The breakdown and molecule destruction occurs up to 80% of the total biomass
through the metabolic pathway called Catabolism. Only 20% of the total biomass is
utilized for the synthesis of new bacteria.
• The Ydro Process ® requires less oxygen supply as the Ammonia (NH4+) is converted
to Nitrites (NO2-) and then Nitrogen (N2) without first being converted to Nitrates (NO3-)
where the largest consumption of Oxygen occurs depending on operational conditions.
5
The Ydro Process ®
6
The Ydro Process ®
7
The Nitrogen Cycle with the Ydro Process ®
8
Applications Ydro Process ®
The Ydro Process ® has been successfully applied in:
Municipal wastewater treatment plants
Sewer grid systems, large hotel groups and septic tanks
Composting and fertilizer production sites
Breweries
Milk and dairy industries
Organic residue treatment plants and anaerobic digesters
Slaughterhouses and poultry industries
Fish and aquaculture industries
Textiles and tanneries
Fruit, juice and soft drinks industries
Olive processing industries
Steel and aluminum industries
Oil and gas industries and refineries
Landfills
Papermills and wood processing industries
Lakes, ponds and lagoons
Agricultural applications, greenhouse and flower farming
Closed loop cooling water systems
9
Interesting facts on the Ydro Process ®
The Ydro Process ® :
The most important control parameters for this method are: ORP (Oxidation
Reduction Potential), Dissolved Oxygen, degree of hydrolysis, Intracellular ATP
(measure of active biomass) and Extracellular ATP (released from dead
microorganisms) and Total ATP.
All technical documents follow our products i.e. MSDS, Biodegrability
certificate.
The Ydro Process ® is currently applied at more than 100 municipal
wastewater treatment plants in Europe and Asia and more than 15 large scale
and multinational industries.
The total current elimination of sludge with the use of The Ydro Process ® is
900 tons per day (ca a Population Equivalent of 6.000.000).
10The Ydro Process ® Pyramid
Ydro Process ®
11Excess Sludge Reduction with Ydro Process ®
Excess Sludge Reduction %
100
90
80
70
60
% 50
40
30
20
10
0
0 1 2 3 4 5 6 7 8 9 10
Months
12Ydro Process ® in the sewer grid Applying the Ydro process in the sewer grid: Eliminates the city odors (grid, manholes, pumping stations) Degrades Fats/Oils/Grease Cleans out the grid, manholes and pumping stations and no cleaning or unclogging is required The sewer system is turned into a pre-treatment reactor where facultative/aerobic conditions allow the degradation of the organic load which can occur up to 80% (
Product Characteristics
Our microbial products:
Are naturally occurring bacteria
Contain no animal derived material
Are not genetically manipulated
Include additional strains according to the treated
waste
Require a maturation time of at least 8 hours
Each gram of our bacterial product contains 109 c.f.u.
During the maturation time duplicate their population
every 20 minutes
Require no additional chemical analysis from
conventional when applied
Require no additional equipment in order to be applied
14Product physical properties & technical information
Physical State Solid (Powder)
Color Brown
Odor Yeast like odor
Relative Density 0.6 – 0.8 gr/cm3
pH Neutral
Carrier % > 99%
Carrier material Bran
Type Single cell
Nutrients Included
Maturation time > 6 hours
15Countries of the Ydro Process ® implementation
The Ydro Process ® has been successfully applied in the following countries:
Greece Turkey United Arab Emirates
Germany Slovenia Serbia
U.S.A. Bulgaria F.Y.R.O.M.
Canada Hungary Montenegro
Switzerland Croatia Bosnia-Herzegovina
Italy Singapore Ecuador
Romania
The Ydro Process ® has also expanded with cooperators and potential customers
and very soon will be applied in the following countries:
France Cyprus India
Austria Ukraine Pakistan
United Kingdom Albania Kuwait
Russia Poland Saudi Arabia
Brazil Moldova Bahrain
Spain Latvia Iraq
Lithuania Czech Republic Oman
Estonia Slovakia Qatar
Belarus Kosovo
16LICENSEES
Hydrotech Environmental has been expanding and implementing the Ydro Process ®
directly to wastewater plants or by licensees according to each case in terms of quality
and quantity of the treated waste as well as the plant location. The main licensees are:
EDIAS Greece
EDIAS DEUTSCHLAND Germany, Austria, Switzerland
TRADEWORKS Inc. USA, Canada, U.A.E., India, Pakistan
L.N.W. D.o.o. Slovenia Italy
Romania, France, Hungary, Czech Republic, Slovakia, Estonia,
TEMACO IMPEX S.r.l.
Latvia, Lithuania, Russia, Ukraine, Belarus, Moldova
DCA BIOTECHNOLOGIES L.t.d. Bulgaria
KOMET A.T.E. Serbia, Montenegro, Bosnia-Herzegovina, Croatia, Kosovo
MSM BIOWASTE RECYCLING Turkey
MEBIKA L.t.d. Greece in specific anaerobic systems
SMS INNSE Worldwide in steel industry
17CASE STUDY: VERIA W.W.T.P.
Case Study VERIA W.W.T.P
Location Northern Greece
Target Sludge Elimination
Population Equivalent 60.000
Flowrate 11.000 – 13.000 m3/day
Treated wastewater Municipal
Project Initiation 15/7/2012
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 400 The plant also receives up to 100 tn/day of
external sludge from other wastewater treatment
COD mg/lt 500 plants, which is equivalent to a population of
15 – 20 0 100 %
500.000 people
TN mg/lt 75 The electricity consumption in the aerobic zone
has been reduced to at least 50% after the
TP mg/lt 15 application of our bacterial products 18CASE STUDY: VERIA W.W.T.P.
DECLARATION OF THE OPERATORS (PUBLIC
CORPORATION OF WATER AND WASTEWATER)
During the period of time between 15/03/2013 -
4/12/2013 it was verified that:
• There was an increased consumption of
organic load in the biological stage (aeration
tanks), with the suspended solids (MLSS)
remaining constant at a concentration of 3.500 –
4.000 mg/lt.
• Zero excess sludge was produced (EWC code
19 08 05), while during the same period of time
and at a conventional operation without the
application of bioaugmentation 4.800 tonnes
(mean average daily production 20 tonnes/day)
of excess sludge would have been produced.
The WWTP of Veria also processes external
sewage sludge produced from other municipal
sewage treatment plants. The following table
shows the quantities and origin of the sludge
processed.
19CASE STUDY: VERIA W.W.T.P.
European Waste Quantity
No Sludge Producer Sludge
Code (Tons in 2015)
1 Industrial Area of Thessaloniki – Plant A Industrial 19 08 12 5.810
2 Municipality of Kozani Municipal 19 08 05 3.365
3 Venus Growers Peach Industry 02 03 05 1.903
4 Municipality of Igoumenitsa Municipal 19 08 05 845
5 Alexander Ltd Peach Industry 02 03 05 630
6 Kiagias O.E. Olive Industry 02 03 05 440
7 Industrial Area of Thessaloniki – Plant B Industrial 19 08 12 332
8 Municipality of Nafpaktos Municipal 19 08 05 302
9 Industrial Area of Larissa Industrial 19 08 12 273
Municipality of Thessaloniki –
10 Municipal 19 08 05 244
Angelochori
11 Municipality of Lavrio Municipal 19 08 05 230
12 Hellenic Catering S.A. Food Industry 02 03 05 173
13 Industrial Area of Kozani Industrial 19 08 05 165
14 Alterra S.A. Fruit & Vegetable Industry 02 03 05 131
15 Arabatzis S.A. Food Industry 02 03 05 95
16 Hotel Sani S.A. Municipal 19 08 05 52
17 Mevgal S.A. Milk/Dairy Industry 02 05 02 42
18 Municipality of Edessa Municipal 19 08 05 25
19 Municipality of Florina Municipal 19 08 05 22
20 Industrial Area of Sindos Industrial 19 08 12 22
TOTAL 15.101 20CASE STUDY: SOUTHERN GREECE W.W.T.P.
Case Study SOUTHERN GREECE W.W.T.P
Location Southern Greece
Target Sludge Elimination
Population Equivalent 200.000
Flowrate 38.000 – 40.000 m3/day
Treated wastewater Municipal
Project Initiation 10/2013
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 100 The total reduction of excess sludge occurred with
the anaerobic digestion stage not in operation
COD mg/lt 400 The electricity consumption in the aerobic zone
30 – 35 0 100 % has been reduced to approximately 15% after the
TN mg/lt 70 application of our bacterial products
The SVI values in the sedimentation tanks were
TP mg/lt 7 improved 21CASE STUDY: SOUTHERN GREECE W.W.T.P.
Case Study SOUTHERN GREECE W.W.T.P
Location Southern Greece
Target Sludge Elimination
Population Equivalent 180.000
Flowrate 33.000 m3/day
Treated wastewater Municipal
Project Initiation 1/2015
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 400 The total reduction of excess sludge occurred with
the anaerobic digestion stage not in operation
COD mg/lt 500
30 – 35 0 100 % The odour problem was totally solved
TN mg/lt 85 The SVI values in the sedimentation tanks were
improved
TP mg/lt 20 22CASE STUDY: NORTHERN GREECE W.W.T.P.
Case Study NORTHERN GREECE W.W.T.P
Location Northern Greece
Target Sludge Elimination
Population Equivalent 75.000
Flowrate 12.000 m3/day
Treated wastewater Municipal
Project Initiation 12/2014
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 300 Total reduction of excess sludge
The electricity consumption in the aerobic zone
COD mg/lt 600
12 – 18 0 100 %
has been reduced to approximately 15% after the
application of our bacterial products
TN mg/lt 70
The SVI values in the sedimentation tanks were
TP mg/lt 10 improved
23CASE STUDY: DAIRY INDUSTRY
Case Study DAIRY INDUSTRY
Location Northern Greece
Target Sludge Elimination
Population Equivalent 80.000
Flowrate 2.500 m3/day
Treated wastewater Industrial – Dairy
Project Initiation 7/2015
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 80 Total reduction of excess sludge
The output parameters were improved
COD mg/lt 2.500
2–3 0 100 % The odour problem was totally solved
TN mg/lt 110 The SVI values in the sedimentation tanks were
improved
TP mg/lt 50 24CASE STUDY: BREWERY
Case Study BREWERY
Location Northern Greece
Target Sludge Elimination
Population Equivalent 30.000 – 50.000
Flowrate 700 – 1.500 m3/day
Treated wastewater Industrial – Brewery
Project Initiation 7/2015
SLUDGE SLUDGE
PRODUCTION PRODUCTION
Input BEFORE AFTER
Parameter Units Reduction
(Average) Application Application
(Average) (Average)
tn /day tn/day
Remarks
Suspended
Solids
mg/lt 150 Total reduction of excess sludge
The energy consumption of the plant was
COD mg/lt 2.500 significantly reduced
2 – 10 0 100 %
The odour problem was totally solved
TN mg/lt 45
The SVI values in the sedimentation tanks were
TP mg/lt 12 improved
25CASE STUDY: LAKE REHABILITATION
Case Study LAKE REHABILITATION
Location Northern Greece
Target Water Quality Improvement &
Odor Control
Volume 280.000 m3
Flowrate < 30 m3/hr
Treated wastewater Surface & Treated sewage water
Project Initiation 2/2017
Remarks
Two lakes in series were treated.
Lake No1 approximate volume 30.000 m3 and Lake No2 of 250.000 m3
The inflow is surface water and effluent from a wastewater treatment plant
The target of the implementation the overall rehabilitation of the two lakes
A combination of Facultative Microorganisms were used throughout three months
An increased dosage was used during the cultivation period (first month of application)
The total microbial product quantity used was approximately 110 kg
All monitored parameters (Turbidity, TN, TP etc.)were improved and the rehabilitation was achieved
26You can also read
