WELCOME TO JCB POWER SYSTEMS                          GLOBAL MANUFACTURING PARTNER

INVESTING IN THE
BEST FACILITIES
                                                      RECOGNISING THE NEED
                                                      FOR ENGINE SOLUTIONS
JCB Power Systems has invested in the best
manufacturing facilities on two continents to
ensure a secure and efficient supply of Off-Highway
                                                      FOR ALL MARKETS.
Diesel Engines that are produced at the right cost
and with the most efficient technology approach       JCB has a long and successful history of machine
for all markets. The UK factory is a purpose-built,   production in India, dating back to 1979 when
multi-million pound, manufacturing plant and          it was one of the first manufacturers to spot the
assembly line situated in Foston, Derbyshire.         opportunity of this emerging market. Now, with
                                                      four world-class factories producing a vast range of
A state-of-the art Research and Development
                                                      equipment, JCB has become the country’s largest
Centre, which features over 20 ultra-efficient
                                                      manufacturer of construction machinery and India
test cells, keeps the company at the forefront of
                                                      has become one of the largest single markets for
Off-Highway Diesel Engine innovation. Capable
                                                      JCB equipment worldwide.
of testing engines up to 300kW (402hp) each
cell features the latest measurement and test         In 2011 with the growth of JCB’s machine
equipment systems.                                    business in India and other emerging economies
                                                      around the world, JCB Power Systems took the
Continued investment has recently allowed the
                                                      step to become an engine manufacturer with a
company to manufacture its own cylinder heads,
                                                      global footprint and installed a dedicated engine
engine blocks and bedplates for the first time
                                                      manufacturing and assembly line – identical to the
ensuring that the most reliable, productive and
                                                      UK factory – at JCB’s Indian HQ in Ballabgarth.
efficient products are brought to market in the
most expedient manner. The new CNC machining          Today JCB Power Systems India produces the
centres and associated automated processes have       most technologically advanced and reliable
been installed to provide outstanding accuracy of     4 cylinder diesel engines available in the Indian
manufacture, boost efficiency and ensure ultimate     market achieving best-in-class fuel efficiency
control over specification, quality and cost.         and whole life costs.                                  JCB’s Indian factories mirror JCB’s proven production facilities in the UK.
