EUROFINS PRODUCT SERVICE GMBH
Yo u r i n d u s t r y, o u r f o c u s
Innotesting 2020 EIN LABOR
27.02.2020
Michael Lüdke STELLT SICH VOR
Yo u r i n d u st r y, o u r f o c u s
Eurofins group
-2-
Key facts Eurofins group
Yo u r i n d u st r y, o u r f o c u s
*Status quo: 2018 http://www.eurofins.com/en/about-us/eurofins-fact-sheet.aspx
-3-
World map Eurofins group
Yo u r i n d u st r y, o u r f o c u s
-4-
Yo u r i n d u st r y, o u r f o c u s
Eurofins Product Service GmbH
Reichenwalde
-5-
Key facts Eurofins Reichenwalde
Yo u r i n d u st r y, o u r f o c u s
• Test lab since 1997
• 60 employees
• Test lab: DIN EN ISO/IEC 17025:2005 [1]
• 963 accredited tests on DAkkS Scope
• 154 accredited tests on A2LA Scope
• Certification department: DIN EN
ISO/IEC 17065:2013 [1]
[1] https://www.eurofins.de/electrical-and-electronics/über-uns/akkreditierungen/
-6-
Business fields
Yo u r i n d u st r y, o u r f o c u s
Device category Example of standard
IT/ Multimedia equipment EN 55035/-32, CISPR 32 / 35, EN IEC 62368
Industrial appliance IEC 60255, EN/IEC 60730
Medical devices EN/IEC 60601
Measurement devices EN/IEC 61010
Household appliance EN/IEC 60335
Automotive ECE R 10 / 116 / 118, IEC 61851
OEM standards
Aviation RTCA DO 160 G
Railway EN 50155
Maritime DNVGL-CG-0339
-7-
Certification departments
Yo u r i n d u st r y, o u r f o c u s
European Union
North America
Asia DIN EN ISO/IEC 17065:2013
Australia
ITA
-8-
Certification services
Yo u r i n d u st r y, o u r f o c u s
• Notified Body (RED 2014/53/EU)
• Notified Body Medical Device (Directive 93/42/EEC)
• FCC TCB (USA)
• ISED FCB (Canada)
• IECEE CB Scheme
Industry
• GS Body Canada
• KBA (E1) // NSAI (E24)
• MET Laboratories Inc. (NRTL)
• Lectures, Seminars, Technical Meetings
-9-
Laboratory departments
Yo u r i n d u st r y, o u r f o c u s
EMC
DIN EN ISO/IEC 17025:2005
Radio/Wireless 10 % Certification
3%
Electrical Safety 9% 36%
11%
Medical Devices
14%
17%
Environmental Simulation
Field Services
- 10 -EMC department
Yo u r i n d u st r y, o u r f o c u s
- 11 -EMC department
Yo u r i n d u st r y, o u r f o c u s
Test facilities: Test Basisstandard
Conducted Emission
• Semi anechoic chambers Conducted Emission I/O
•
Radiated Emission
10m measuring distance Harmonics IEC/EN 61000-3-2/-12
• 3m measuring distance Flicker IEC/EN 61000-3-3/-11
• Shielded room
ESD
Radiated Immunity
IEC/EN 61000-4-2
IEC/EN 61000-4-3
• CISPR 25 (Automotive) Burst Mains IEC/EN 61000-4-4
Burst I/O IEC/EN 61000-4-4
• ESD
Surge Mains IEC/EN 61000-4-5
• Transient immunity testing Surge I/O IEC/EN 61000-4-5
• Burst / Surge Conducted Immunity Mains IEC/EN 61000-4-6
Conducted Immunity I/O IEC/EN 61000-4-6
• Automotive pulse Magn. Field IEC/EN 61000-4-8
V-Dips / Interruptions IEC/EN 61000-4-11
- 12 -Radio/Wireless department
Yo u r i n d u st r y, o u r f o c u s
- 13 -Radio/Wireless department
Yo u r i n d u st r y, o u r f o c u s
Test facilities: Radio technologies:
• Fully anechoic chamber • Bluetooth • GNSS/GPS
• European standards • LoRa/ZigBee • NB IoT
• Semi anechoic chamber • WLAN 2.4GHz/5GHz • UWB
• North American standards • LTE • RFID
• BT conformance testing • UMTS • WPT
• BT SIG conformance • GSM/GPRS/EGPRS • ULP-AMI
testing
• SAR robot Daisy
- 14 -Electrical Safety department
Yo u r i n d u st r y, o u r f o c u s
- 15 -Electrical Safety department
Yo u r i n d u st r y, o u r f o c u s
Test facilities:
• Ecodesign directive
• Ball pressure tests
• Glow wire tests
• Heating tests
• High voltage tests
• Lifetime and permanent load tests
• Luminous flux measurement
• Material tests
• …
- 16 -Electrical Safety department
Yo u r i n d u st r y, o u r f o c u s
- 17 -Environmental Simulation department
Yo u r i n d u st r y, o u r f o c u s
- 18 -Environmental Simulation department
Yo u r i n d u st r y, o u r f o c u s
Test Parameters
Temperature / humidity -72 °C / +220 °C
Under pressure Up to 10 mbar
Over pressure Up to 5 bar
Vibration 61.7 kN, 100g
Mechanical Shock 123.4 kN, 200g
Salt fog / Corrosion V = 1,5 m3
Mixed / single gas H2S / NO2 / Cl2 / SO2
IP Up to IP 68 (IP X8 (100m)
Flammability Vertical / horiz. / Needle flame /
500 W burner
- 19 -Automotive Scope OEM
Yo u r i n d u st r y, o u r f o c u s
EMC/ Electrical tests Environmental simulation tests
E-01 Langzeit Überspannung E-13 Unterbrechung Pin M-01 Freier Fall K-10 Wasserschutz – IPX0 bis IPX6K
E-02 Transiente Überspannung E-14 Unterbrechung Stecker M-02 Steinschlagprüfung K-11 Hochdruck-/Dampfstrahlreinigung
E-03 Transiente Unterspannung E-15 Verpolung M-03 Staubprüfung K-12 Temperaturschock mit
Schwallwasser / K-13 Temperaturschock
E-04 Jumpstart E-16 Masseversatz M-04 Vibrationsprüfung Tauchen
E-05 Load Dump E-17 Kurzschluss Signalleitung und M-05 Mechanischer Schock K-14 Feuchte Wärme konstant
Lastkreise
E-06 Überlagerte Wechselspannung M-06 Mechanisches Dauerschocken K-15 Betauungs- und Klimaprüfung
E-18 Isolationswiderstand
E-07 Langsames Absenken und Anheben K-01 Hoch-/Tieftemperaturlagerung / K- K-16 Temperaturschock (ohne Gehäuse)
der Versorgungsspannung E-19 Ruhestrom 02 Stufentemperaturtest / K-03
Tieftemperaturbetrieb K-17 Sonnenbestrahlung
E-08 Langsames Absenken, schnelles E-20 Durchschlagfestigkeit
Erhöhen der Versorgungsspannung K-04 Nachlackiertemperatur K-18 Schadgasprüfung
E-21 Rückspeisungen
E-09 Resetverhalten K-05 Temperaturschock (Komponente) C-01 Chemische Prüfungen
E-22 Überströme
E-10 Kurze Unterbrechungen K-06 Salzsprühnebelprüfung mit Betrieb,
Außenraum
E-11 Startimpulse L-01 Lebensdauerprüfung
K-07 Salzsprühnebelprüfung mit Betrieb, mechanisch/hydraulischer Dauerlauf
E-12 Spannungsverlauf bei Innenraum
Bordnetzregelung L-02 Lebensdauerprüfung
K-08 Feuchte Wärme, zyklisch Hochtemperaturdauerlauf
K-09 Feuchte Wärme, zyklisch (mit Frost) L-03 Lebensdauerprüfung
Temperaturwechseldauerlauf
- 20 -Aviation Scope DO 160
Yo u r i n d u st r y, o u r f o c u s
EMC/ Electrical tests Environmental simulation tests
Section 15 – Magnetic Effect Section 4 – Temperature and Altitude
Section 16 – Power Input Section 5 – Temperature Variation
Section 17 – Voltage Spike Section 6 – Humidity
Section 18 – Audio Frequency Conducted Susceptibility Section 7 – Operational Shocks and Crash Safety
– Power Inputs
Section 8 – Vibration
Section 19 – Induced Signal Susceptibility
Section 9 – Explosion Proofness
Section 20 – Radio Frequency Susceptibility (Radiated
Section 10 – Water Proofness
and Conducted)
Section 11 – Fluids Susceptibility
Section 21 – Emission of Radio Frequency Energy
Section 12 – Sand and Dust
Section 22 – Lightning Induced Transient Susceptibility
Section 13 – Fungus Resistance
Section 23 – Lightning Direct Effects
Section 14 – Salt Spray
Section 25 – Electrostatic Discharge (ESD)
Section 24 – Icing
Section 26 – Flammability
- 21 -Most Exciting EUT
Yo u r i n d u st r y, o u r f o c u s
• Toilet with wireless technology
• Heated jacket with wireless technology
• Body sensors with wireless technology
• Orthoses / prostheses / heart pacemakers with wireless technology
• Life-support-machines
• Geo information systems
- 22 -Lab Strength
Yo u r i n d u st r y, o u r f o c u s
Overall: Products should be on the market, not in the test lab.
• Local and world wide service
• Flexibility regarding customer test plans
• Minilab: tests during product development
• Fail results will be explained (solutions oriented)
• Factory inspections (GS, MET US), CB audits
• Versatile and longstanding expertise
- 23 -Contact
Yo u r i n d u st r y, o u r f o c u s
Eurofins Product Service GmbH
Storkower Str. 38c
15526 Reichenwalde
Germany
Michael Lüdke (Dipl.-Ing.)
Customer Service Manager
+49 33631 888 126
MichaelLuedke@eurofins.de
Website: www.eurofins.de/ee
- 24 -THANK YOU FOR YOUR ATTENTION
Yo u r i n d u s t r y, o u r f o c u s
