IBM Power Systems Update
David Spurway
IBM Power Systems Product Manager
STG, UK and Ireland
Would you like to go fast?
Go faster - win your race
Doing More LESS With
Power 8
POWER8 is the fastest around
Power Systems Range
Operating Systems Hypervisors Management
Scale-out Systems (1 & 2 sockets) Enterprise Systems (4+ sockets)
2014 IBM Power Systems | Announce: April 28, 2014
Power E870 Power E880
Power E850
Power S812L Power S822L
Power S824L Power S822 Announce: May 11, 2015 Announce: October 6, 2014
Power S814 Power S824
OpenPOWER drives industry innovation
Open Development
OpenPOWER enables greater innovation through
both open software and open hardware
Collaboration across multiple thought leaders
Collaborative development model drives collective
thought leadership, simultaneously across multiple disciplines
Performance of leading POWER architecture
Broadens the capability and performance of the POWER platform
The OpenPOWER Foundation creates an open ecosystem,
using the POWER Architecture to share expertise, investment, and
server-class intellectual property to serve the evolving needs of customers.Membership now at >160!
Power System S812LC and S822LC
Introducing a new line of servers for Linux Clouds & Clusters –
IBM Power Systems LC Line
Key Client Value Specifications Advantages vs. Competition
» 2-socket, 2U
Optimize your datacenter for cloud, big data, » Over 2X performance per core than Xeon E5-2600
» Up to 20 cores (2.9-3.3Ghz) v3
and business-critical applications » 1 TB Memory (32 DIMMs)
S822LC with new solutions to deliver superior cloud economics » 40% better price/performance vs Xeon E5-2600
» 230GB/sec memory bandwidth
Commercial through greater efficiency and agility, developed with an open » 2x SFF (HDD/SSD), 2 TB storage
v3-based servers
ecosystem of innovators including members of the » 5 PCIe slots, 4 CAPI enabled I/O available » Over 2X greater memory bandwidth than Xeon
OpenPOWER Foundation » Default 3 yr 9x5 Warranty 100% CRU
E5-2600v3 with fully configured memory capacity
Access all data, build models quickly, iterate faster » 2-socket, 2U
with new solutions to deliver analytics in the cloud at the » Up to 20 cores (2.9-3.3Ghz)
S822LC
speed of data creation. Developed with an » 1 TB Memory (32 DIMMs)
High » 230GB/sec memory bandwidth » Available CAPI-attached accelerators for
open ecosystem of innovators, including OpenPOWER
Performance » 2 integrated NVIDIA GPUs
compute, storage, fabric with lower latency
Foundation members, data scientists can deliver results
Computing » 5 PCIe slots, 2 CAPI enabled I/O available » Over 2X greater memory bandwidth than Xeon
faster with Power Systems, an open platform that tightly
» Default 3 yr 9x5 Warranty 100% CRU E5-2600v3 with fully configured memory capacity
integrates the best acceleration technologies
» 1-socket, 2U
Act faster and make better decisions » Up to 10 cores (2.9-3.3Ghz)
with systems designed for data » 1 TB Memory (32 DIMMs) » Optimized for Spark and Hadoop
S812LC Power Systems unique design for data is built to address the » 115GB/sec memory bandwidth » 16X the memory capacity of Xeon E3 servers, 2X
specific memory and multithreading demands that analytics » 14x 3.5” drives, 112TB Storage 1P Xeon E5 servers
applications built with Hadoop and Spark present » 4 PCIe slots, 2 CAPI enabled
» Default 3 yr 9x5 Warranty 100% CRUIBM Research - 7 Nanometer and Beyond
Carbon Nanotubes
• IBM demonstrated a 10,000 transistor chip
• IBM demonstrated a 9nm transistor
• 5x-10x better performance
Graphene
• IBM demonstrated a 100 GHz transistor
• IBM demonstrated a functional circuit
• 10,000x better performanceThe Bottom Line What would “faster” mean to you?
AIX 7.2
AIX Release Life Cycle View
2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024
AIX Next
GA 4Q2019
TL0 TL1 TL2 TL3
AIX 7.2
GA 12/2015
TL0 TL1 TL2 TL3 TL4 TL5 EOS 4Q27
P8 Entry P8 High End
AIX 7.1 SP SP SP
GA 09/2010 P8 Midrange
TL3 TL4 TL5 EOM 4/2021 EOS 4/22 EOL 4/25
AIX 6.1
GA 11/2007 TL9 EOM 4/16 EOS 4/17 EOL 4/20 IBM
Confidential
Marketed and serviced Fee-based service extension Technology Level (TL) SP Service Pack
Serviced only Web support only
Last TL
New AIX level ships every four years
New Technology Levels (TL) initially ship yearly for new AIX releases, then transition to a TL every two yearsAIX 7.2 Highlights IBM is introducing AIX 7.2, the IBM strategic UNIX operating system for mission-critical, core business applications, with the following features: • AIX Live Update for Interim Fixes. • Cluster Aware AIX (CAA) automation with repository replacement mechanism. • SRIOV-backed Virtual Network Interface Card (VNIC). • RDSv3 over RoCE, which adds support of the Oracle RDSv3 protocol over the Mellanox Connect RoCE adapters. • Flash caching. Workloads can take advantage of a read-only cache. Planned availability date - December 4, 2015
AIX 7.2 Next Generation AIX Live Update Technology
Project Requirements
• Use existing maintenance model and administrative tools (NIM, emgr, installp)
• Start with live AIX kernel replacement for i-fixes, then in future extend to SPs and possibly TLs
• Long term goal is to provide non-disruptive updates for all of AIX (kernel, commands, and Libs)
CEC
Original LPAR Surrogate LPAR
Running Live Migration Running
Workload Workload
Original kernel Virt. ent Virt. ent Updated kernel
VSCSI VSCSI
VIOS SEA
New rootvg New rootvg
Original rootvg Original rootvg
(Alt-disk-install) (Alt-disk-install)
VSCSIAIX 7.2 – Workload Optimization with Flash Key message – Potential performance improvement with caching of SAN data in server-attached Flash storage . No application change is required. All storage solution such as SSD or SAS attached drawer are supported. Additional performance improvements are seen from off-loading SAN traffic closer to the server Target customers: Enterprise customers willing to invest in technology for better I/O performance Typical customer use cases: • I/O intensive workloads with a transactional DB • Data Warehouse applications System requirement: • Standard AIX 7.2 • Requires Flash storage Steps for adoption: • Can be adopted right away. Simple admin set-up required to enable. Flash storage will be required
AIX 7.2 – Simplified and Optimized Oracle RAC on POWER Key message – Infrastructure simplification with users, applications and DB on one topology, eliminates need for specialized interconnect technology, and provides better performance and scaling Target customers: Oracle RAC on POWER customers Typical customer use cases: • Customers who are on or evaluating 40GB ethernet in their data centers • Customers evaluating PurePower which integrates 40 GB into the system System Requirement: • Standard AIX 7.2 • 40 GB Ethernet adapter. This is a feature code in POWER8 • 40GB switch is included in PurePOWER, or can be ordered directly from Mellanox Steps for adoption: • Oracle support of 40GB over IP on AIX was announced on September 1, ready to deploy today on AIX 7.1 and 6.1! • Oracle certification of AIX 7.2 with RDS for improved DB performance is being worked for future growth
AIX 7.2 – vNIC Adapter with SR-IOV Virtualization (Performance Optimized Virtual Networking) Key message – vNIC enables Live Partition Mobility for SR-IOV adapters, SR-IOV adapters provide better QOS controls which allow guaranteed bandwidth to be assigned to each VM and reduced server resource consumption Target customers: Customers that have a need higher performing network adapters, better QOS and that use Live Partition Mobility Typical customer use cases: • Consolidated workloads on large high end servers where some workloads may require larger bandwidth System requirement: • AIX software is part of standard AIX 7.2, and AIX 7.1 TL 4 • PowerVM 2.2.4 is required • SR-IOV adapter is required Steps for adoption: • Can be adopted right away. Simple admin set-up required to enable. • Supported on servers with POWER8 processors running PowerVM
Other AIX 7.2 Features CAA automation with repository replacement mechanism • When the Storage Framework (SFW) detects primary (active) repository disk DOWN, it will notify CAA and CAA will automatically replace the failed repository disk with a user-specified backup repository disk RDSv3 over RoCE adds support of the Oracle RDSv3 protocol over the Mellanox Connect RoCE adapters. Instead of requiring the IB network infrastructure, the feature allows the user to leverage the high-speed Ethernet connect and run the RDSv3 protocol over Oracle RAC cluster for higher performance. AIX Dynamic System Optimizer is now included as part of AIX 7.2. IBM BigFix Lifecycle provides an automated, simplified patching process that is administered from a single console. It provides near real-time visibility and enforcement to deploy and manage patches to all distributed endpoints. This offering will ship with AIX Enterprise editions.
AIX Enterprise Edition AIX Enterprise Edition V1.1 includes the following offerings: • Dynamic System Optimizer V1.1 (5765-PWO) (AIX 7.1 Only as included in AIX 7.2) • IBM PowerSC Std Ed V1.1 (5765-PSE) • PowerVC Standard Edition V1 (5765-VCS) • Cloud Manager with OpenStack V4.3 (5765-CMO) • ITM V6.3 • IBM BigFix Lifecycle • Mozilla Firefox (ESD only)
