Imitating Reality
A Moulage Experience
Laerdal SUN Conference
October 2018
Orlando, FL
About SIMETRI SIMETRI designs and develops creative technologies and capabilities for medical training. We are a woman- owned, minority-owned small business founded in 2009 to develop innovative medical training technologies. Headquartered in Winter Park, Florida, SIMETRI is only 7 miles from the University of Central Florida Research Park. SIMETRI’s unique talents in the development of medical training technologies and applications, coupled with strong engineering rigor and experience integrating the latest material science research, are complimentary and uniquely qualified to transform medical training.
SIMETRI’S PROJECTS
About the Presenter
Barry S. Anderson
• Over 30 years experience in fine and commercial art.
• Began career working with a variety of mediums in areas of:
• Industrial mold making
• Commercial design
• Museum wax figures
• Portrait sculpture
• TV and movie special effects
• Experience with forensic crime scene investigation,
workplace safety, military moulage, and medical simulation.
• Have 17+ years with Ripley Entertainment.
• Currently Director of Special Effects Engineering at SIMETRI.
Special Makeup Effects Film Credits
Movie Set Makeup Application
Theme Park Special Effects
Forensic Crime Scenes
Supersleuths - Aileen Wuornos
(2002)
Discovery/The Learning Channel
Dade County Medical
Examiner Department of
Forensic Imaging Bureau
Anthropology Art
Workplace Safety
G&W Railroad Safety Training
Film ProductionHistoric Museum Figure Displays
Portrait Art & Silicone Masks
Imitating Reality – A Moulage Experience
Imitating Reality - Moulage Makeup Knowing Your Materials
Imitating Reality - Moulage Makeup
Creating Fresh Bruising
• Stipple red cream makeup around • Use small amount of purple or dark red cream makeup and
area where bruise will be stipple area to make your outer edges
• Smudge it and rub it in leaving • Blend out carefully using your makeup sponge
middle openImitating Reality - Moulage Makeup
Creating An Aged Bruise
• Stipple green cream makeup
around outer areas and use
purple or dark red and blue
cream makeup
• Finish setting this makeup with
translucent face powderImitating Reality - Moulage Makeup
Creating Cuts
• Using scar wax place a • Mold scar wax into • Using utensil create a cut pulling
small amount and blend shape in the size that is carefully through wax
into skin desired using a spatula • The ends should be narrower and
• Note: Do not place on or craft stick and or tapper leaving center wider
flexible area fingers • Lightly use a stipple sponge over your
wax to give textureImitating Reality - Moulage Makeup
Creating Cuts Continued
• With a small brush, brush deep • Take red cream makeup and go
red cream makeup into the over dark red areas in the center
injury area and tapper color to towards the upper edges
fine line on the ends • Stipple a small of red around
outer injury areaImitating Reality - Moulage Makeup
Creating Cuts Continued
• Finalize the wound with
simulated blood or
simulated gel bloodImitating Reality - Moulage Makeup
Creating Scrapes
• Use cream makeup to create any size scrape • Stipple red cream makeup onto stipple sponge
and go over the area in the same direction
• Place red makeup onto a stipple sponge and pull
sponge across the skin in the direction desired to
make the scrapeImitating Reality - Moulage Makeup
Creating Scrape Continued
• With a fine brush add simulated • For an added effect, coffee • For another added effect, you can
liquid blood or simulated thick grounds can be added for a more add glycerin or lubricant jelly to
blood over top of the scrapes in sever look provide shine
the same direction of injuryImitating Reality - Moulage Makeup
Creating 2nd Degree Burns
• Paint a thin layer of red • Apply 2 layers of liquid latex and allow to dry • Once latex has dried add
cream makeup and in between application 2 more layers in a circular
blend out with sponge • Note: Some people may be allergic to latex pattern leaving center
• Skip this step if you have a latex allergy emptyImitating Reality - Moulage Makeup
Creating Burns Continued
• Make an oval • Stipple red cream • Then stipple purple or dark red cream
opening using your makeup inside the makeup on the rim of the opening
fingers and roll out opening • Carefully blend out colors with sponge
the latex onto itselfImitating Reality - Moulage Makeup
Creating 3rd Degree Burns
• To create a more enhanced 3rd degree burn • Apply a thing layer of gelatin using a craft stick
use powdered gelatin with hot water and mix over the burn area and built up
to dissolve and let cool down • Using end of a brush pull the gelatin around as it
cools in order to create texture
• Add a layer of Vaseline over the top of the gelatinImitating Reality - Moulage Makeup
Creating 3rd Degree Burns Continued
• Take 1 layer of tissue • Using makeup sponge • Repeat a 2nd layer of • Using end of brush
and tear edges carefully stipple 1st latex and let dry begin pulling up
• Place over top of coat of liquid latex tissue exposing
burn and press down matting down all gelatin underneath
edges and let dryImitating Reality - Moulage Makeup Creating 3rd Degree Burns Continued • Using black cream makeup • Stipple a small amount of • Using a brush apply a small or charcoal powder stipple red and purple cream amount of red cream makeup around burn area leaving makeup over top of inside the peeled area center peeled area clean of blackened area • Add vaseline or lubricant jelly black makeup over the red areas
Imitating Reality - Makeup for Moulage
Adding Effects: Suggested Supplies for A Makeup Kit
• 70% or 99% Isopropyl Alcohol
• Makeup Remover Wipes or Baby Wipes
• ½” or 1” Chip Brushes
• Craft Sticks or Tongue Depressors for Mixing
• Paper or Plastic Cups
• Skin Tite Silicone Adhesive
• Ultimate Wound Kit
• Ultimate Blood Kit
• Blood Edition Encore Slim Palette
• Bruise Edition Encore Slim Palette
• Ben Nye Makeup Wheels – Bruise & Abrasions
• Ben Nye Master Disaster Makeup Wheel
• Ben Nye Thick Blood
• Dirt Works PowderImitating Reality - Makeup for Moulage
Adding Effects: Easy Simulated Blood Recipe
Ingredients: Directions:
• 1/2 teaspoon red food coloring • Add flour and red food coloring to the mixing bowl.
• 1 tiny drop blue food coloring • Spritz your tablespoon with cooking spray and use
• 1 tiny drop green food coloring (optional) it to add corn syrup to the mix.
• 1 scant teaspoon flour, sifted • Use the toothpick to add the tiniest drop of blue
• 1 tablespoon corn syrup food coloring. You can always add more. Add the
• 1 small shallow glass or plastic bowl same amount of green food coloring if you need it
• 1 toothpick to be more purple. Stir with a small whisk or spoon
• Cooking spray
until completely blended.
• Water (optional)
• Adjust the recipe using additional food coloring,
• Chocolate sauce (optional)
chocolate sauce, water or laundry detergent if
• Liquid laundry soap (optional)
desired.Imitating Reality - Makeup for Moulage
Learning More: Suggested References
• The Technique of the Professional
Make-up Artist
by Vincent JR Kehoe
• Special Make-up Effects
by Vincent JR Kehoe
• Techniques of Three Dimensional
Makeup
by Lee Baygan
• The Monstrous Make-up Manual
by Mike Spatola
• Hurt’em Reel Good
by Randy DaudlinImitating Reality - Moulage Makeup
Learning More: Suggested Tips and Tricks
• Start with something relatively simple.
• When removing SFX makeup, you can make use of warm towels or soap
and water go a long way.
• Invest in the right products and tools.
• You don’t have to spent a lot of money to get great FX.
• Practice in advance.
• It is always advised to do a patch test before using heavy-duty products like
latex and silicone on the skin or on manikins.
• Make sure that you do not use silicone or latex in the hair, and make use of
vaseline to protect the surrounding hair.
• Remember to have fun!Thank you! www.simetri.us
