Product Portfolio
For over 130 years Avon Protection has been at the forefront
of supplying specialist respiratory protection devices and
equipment to military forces, civil and first line defence troops,
emergency service teams and industrial, marine, mineral and
oil extraction site personnel. They all put their trust in Avon’s
products to shield them from every possible threat, whether
land, air or sea based.
With an unrivalled pedigree in mask design dating back to the
1920’s, Avon Protections’ advanced products are the first choice
for Personal Protective Equipment (PPE) users worldwide and
are placed at the heart of many international defence and
tactical PPE deployment strategies. With extensive knowledge
of customer needs, Avon Protection’s innovations are designed
with the user in mind.
2
CONTENTS
Advance
M50 ………………………………………………………………… 06
FM53 ………………………………………………………………… 08
M53AI ………………………………………………………………… 10
FM54 ………………………………………………………………… 12
ST53 ………………………………………………………………… 14
ST53SD ……………………………………………………………… 16
AVONAIR INTEGRATION SYSTEM…………………………………… 18
EZAIR ………………………………………………………………… 20
MP-PAPR ……………………………………………………………… 22
CS-PAPR ……………………………………………………………… 24
CS-ELITE ……………………………………………………………… 26
MCM100 ……………………………………………………………… 28
MDC150 ……………………………………………………………… 30
ADVANCE APPLICATIONS …………………………………………… 32
Protect
M69 ………………………………………………………………… 36
FM12 ………………………………………………………………… 38
PC50 ………………………………………………………………… 40
C50 …………………………………………………………………… 42
HMK150 ……………………………………………………………… 44
TT-TYPE ……………………………………………………………… 46
P-TYPE ……………………………………………………………… 48
ARGUS RANGE ……………………………………………………… 50
Mi-TIC E ……………………………………………………………… 52
Mi-TIC S ……………………………………………………………… 54
DELTAIR ……………………………………………………………… 56
PROTECT APPLICATIONS …………………………………………… 58
Escape
NH15 ………………………………………………………………… 62
NH15 COMBO ……………………………………………………… 64
CRS15 ………………………………………………………………… 66
ESCAPE APPLICATIONS ……………………………………………… 68
ACCESSORIES ………………………………………………………… 70
3
4
M50 ST53 EZAIR
FM53 ST53SD MP-PAPR
M53AI MCM100 CS-PAPR
FM54 MDC150 CS-ELITE
ADVANCE
5
M50
Developed with the US Department of Defense, the M50 is the next generation of Avon COMMUNICATION
Protection’s CBRN full face masks. Specifically designed to meet the latest military mask n Electronic Communication Port (ECP) allows a Voice Projection
requirements, the M50 delivers the lowest profile CBRN twin filter system on the market. Unit (VPU) to be safely connected in a CBRN environment to an
internal microphone.
n Additional communication systems can be attached via this ECP
using an appropriate lead.
FILTRATION
n Twin filter design significantly reduces breathing resistance and
improves weight distribution.
n Bayonet fit provides quick and efficient filter attachment.
n Filters can be replaced without breaking the protective seal
through self sealing valves.
USER COMFORT
n Available in 3 sizes.
n Chlorobutyl rubber and silicone blend giving the mask a high
degree of flexibility and comfort for extended use.
n Reflex seal with low profile brow for helmet compatibility.
n Extended chin flap for CBRN garment compatibility.
n High flow fail safe drinking device enables connection to a
canteen or bladder type system.
VISION
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
n Fully optically correct.
n Panoramic visor design gives maximum field of vision and
wearer recognition.
6
Over 2 million 50 series respirators issued.
7
FM53
The ‘first to market’ combination respirator, developed to meet the technically advanced needs COMMUNICATION
of global special forces, the FM53 delivers positive pressure SCBA, PAPR and negative pressure n Electronic pass-through for external radio use.
capability. All of these capabilities are available from one mask platform without the need to n Electronic Communication Port (ECP) allows a Voice Projection
change components. Unit (VPU) to be safely connected in a CBRN environment to an
internal microphone.
INTEGRATION
n Mask integrates with NFPA Class 2 and 3 suits.
n Reduced buckle size for suit/helmet integration.
n Extended chin flap for CBRN garment compatibility.
MULTIPLE MODES
n Functions as both a negative and positive pressure mask.
n VREU lever for easy switching between negative and positive
pressure modes.
USER COMFORT
n Available in 4 sizes.
n Interchangeable silicone nosecups for custom fit.
n Low profile design for superior weapons integration.
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
8
When the user needs to adapt to ever changing
operational conditions.
9
M53A1
Based on the US Government Joint Services General Purpose Mask (JSGPM) program, the COMMUNICATION
M53A1 was specifically designed to meet the unique requirements of Special Mission Units n Electronic pass-through for external radio use.
while providing the maximum operational flexibility. n Electronic Communication Port (ECP) and a Voice Projection Unit
(VPU) safely connected as standard.
n Additional communication systems can be attached via this ECP
using an appropriate lead.
USER COMFORT
n Available in 4 sizes.
n Interchangeable silicone nosecups for custom fit.
n Low profile design for superior weapons integration.
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
MULTIPLE MODES
n Functions as both a negative and positive pressure mask.
n VREU lever for easy switching between negative and positive
pressure modes.
10One mask with operational adaptability for all missions.
11FM54
Building on the proven pedigree of the FM53, the Avon FM54 delivers enhanced flame COMMUNICATION
hardening, coupled with improved passive speech performance, the FM54 provides Specialist n Electronic Communication Port (ECP) allows a Voice Projection
Operators maximum level of protection to the face, eyes and respiratory tract from CBRN, Riot Unit (VPU) to be safely connected in a CBRN environment to an
Agents, TICS and Toxic Industrial Materials while maintaining extreme user flexibility. internal microphone.
n Additional communication systems can be attached via this ECP
using an appropriate lead.
USER COMFORT
n Available in 4 sizes.
n Chlorobutyl rubber and silicone blend giving the mask a high
degree of flexibility and comfort for extended use.
n Reflex seal with low profile brow for helmet compatibility.
n Extended chin flap for CBRN garment compatibility.
n High flow fail safe drinking device enables connection to a
canteen or bladder type system.
VISION
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
n Fully optically correct.
n Panoramic visor design gives maximum field of vision and
wearer recognition.
12Built on the proven pedigree of the FM53, the FM54 is our most elite mask.
13ST53
The ST53 combines Avon Protection’s FM53 mask technology with a lightweight, scalable, tactical COMPACT DEMAND VALVE
SCBA set. The system can be combined with AvonAir to deliver adaptable protection factor n 1st breath activated for ‘instant on’.
through positive pressure, powered air and negative pressure modes from a single unit. n Rugged, compact design delivers high flow rates.
n Screw-on-design allows for DIN 40 thread filters.
GAUGE AND WHISTLE
n Located on shoulder straps for easy access.
n Positioned for high noise environments and easy gauge reading.
n Illuminated gauge for low-light situations.
STEALTH DESIGN
n Black low profile design.
n Lightweight compared to traditional SCBA units.
n Silent operation for critical missions.
USER COMFORT
n Ergonomically contoured backframe for comfort.
n Adjustable harness allows for quick donning/doffing.
n Padded shoulder straps for comfort.
n Low profile backframe.
14The most advanced flexible multi-mode CBRN respiratory solution.
15ST53 SD
Developed for high activity, dynamic operations, the ST53SD is the most advanced, COMPACT DEMAND VALVE
lightweight CBRN respiratory solution on the market. It enables a fast response to changing n 1st breath activated for ‘instant on’.
operational conditions in one complete modular system for short-term tactical operations. n Rugged, compact design delivers high flow rates.
n Screw-on-design allows for DIN 40 thread.
GAUGE AND WHISTLE
n Option of either a remote whistle and pressure gauge or a single
pressure gauge attached directly to the regulator body.
STEALTH APPEARANCE
n Black low profile design.
n Silent operation for critical missions.
USER COMFORT
n 1 or 2 litre cylinder options.
n Excellent integration with other personal equipment.
16The world’s smallest, most compact CBRN hardened demand valve.
17AvonAir is revolutionising the CBRN environment, delivering user configurable modules,
adaptable protection factor, increased time on task, reduced physiological burden and
lowest cost of ownership, through the systems lifetime. AvonAir is built around four
flexible and adaptable modules; EZAir, MP-PAPR, CS-PAPR and CS-Elite. Common to the
range is Avon’s intelligent EZAir blower motor, which automatically adjusts its flow rate,
depending on the number of available filters and the system configuration.
This patented design delivers maximum operational flexibility through interchangeable
components, allowing for rapid selection between breath assist, powered air and
self-contained breathing apparatus as the mission dictates. In addition to adaptable
protection factors, the AvonAir range also delivers a number of benefits to the wearer
including a cooling effect form the powered air, compatibility with our high flow
hydration system and a wide range of carriage options, to ensure that the user is able to
optimally distribute AvonAir, depending on mission loads. Included within the AvonAir
patented design is our unique hose management technology, delivering outstanding
levels of comfort, unrestrained movement and crushproof hosing to maintain operator
agility, superior weapons sighting, integration of mask worn communications systems
and compatibility with the widest range of helmet and body armour options including
EOD, riot control and tactical vests and helmets.
AvonAir places the user at the core, delivering a substantially smaller, lighter and quieter
scalable protection system, that is ergonomically adaptable to meet the needs of the
operator and the mission.
18THE FIRST ADAPTABLE POWERED AIR SYSTEM
19EZAIR
Avon EZAir is the newest generation of single filter airflow system, substantially smaller and CONTROL SYSTEMS
lighter than traditional powered air units. Avon EZAir also provides the adaptable smart motor n Automatic flow control adjusts to filter type.
for all configurations of the AvonAir range. n Low flow and battery alarms alert.
n Dual speed function – automatically increases flow rate.
INTEGRATION
n Integrated MOLLE panel and belt options.
n S-Shape hose with crush proof technology delivers superior
integration.
MATERIAL TECHNOLOGIES
n One size lightweight and flexible hose.
n Crush proof hose with dual wall construction.
n Military pedigree plastics used for superior resistance.
OPERATIONAL FLEXIBILITY
n Battery life up to 8 hours.
n Constant flow rate through filter reduces inhalation resistance.
n Hot swap battery for rapid exchange.
n Multiple mounting options.
20The smallest and lightest breath assist.
21MP-PAPR
A departure from traditional rigid plastic construction systems, the Avon multi-position CONTROL SYSTEMS
PAPR is the world’s first flexible powered air unit, constructed from the same field proven n Automatic flow control adjusts to filter type.
chlorobutyl rubber, as used for the Avon 50 series mask range. n Low flow and battery alarms alert.
n Dual speed function – automatically increases flow rate.
INTEGRATION
n Ergonomically back mounted carrier system with integrated
hydration option.
n Integrated MOLLE panel and belt options.
n S-Shape hose with crush proof technology delivers superior
integration.
MATERIAL TECHNOLOGIES
n One size lightweight and flexible hose.
n Crush proof hose with dual wall construction.
n Military pedigree plastics used for superior resistance.
OPERATIONAL FLEXIBILITY
n Battery life >8 hrs running at a flow rate of 120lpm.
n Constant flow rate through filter reduces inhalation resistance.
n Hot swap battery for rapid exchange.
n Increased protection factor up to 5 times more than APR.
22The world’s first scalable and flexible powered air unit.
23CS-PAPR
The Avon combination system is the newest generation of modular CBRN Powered Air AUTO FILTER COVERS
Purifying Respirator (PAPR). Designed for use with Combination Unit Respirators (CURs) the n Quick fit onto existing Avon MP-PAPR filter mount.
CS-PAPR enables the user to select the level of protection dependent on the threat, providing n Pneumatically operated by the combination hose.
increased duration on target and safer operation.
n Indicator for status updates.
n Integrated rubber impact bumper.
COMBINATION HOSE
n Press and turn rotary selector prevents accidental actuation.
n PAPR automatically powered up/down when selector rotated.
n Ability for user to switch modes in one simple action.
n ‘Fail-Safe’ pneumatic operation of hose.
INTEGRATION
n Optional carrier module allows wearer to rapidly remove
SCBA portion.
n Crush resistant ‘S-Shape’ hose with low profile hose end.
OPERATIONAL FLEXIBILITY
n Re-configurable to work as Avon EZAir or MP-PAPR.
n Quick connect interface delivers ‘Dry-Decon’ filter option.
n Short duration escape cylinders integrate with CS-PAPR.
24Adapt the protection to meet the threat in seconds.
25CS-ELITE
The CS-Elite has been developed to provide special operations with a flexible and advanced, STEALTH
slimline profile, hybrid breathing system. Coupled with the Avon FM54 mask and patented Avon n Low pressure warning system.
Combination Hose Module the wearer can seamlessly switch between APR, PAPR and SCBA modes n Slim profile.
of protection.
COMBINATION HOSE
n Press and turn rotary selector prevents accidental actuation.
n PAPR automatically powered up/down when selector rotated.
n Ability for user to switch modes in one simple action.
n ‘Fail-Safe’ pneumatic operation of hose.
AUTO FILTER COVERS
n Quick fit onto existing filter mount.
n Pneumatically operated by the combination hose.
n Indicator for status updates.
n Integrated rubber impact bumper.
BREACHING SYSTEM (OPTIONAL EXTRA)
n Quick attachment rods.
n Unique 9V battery power ignition.
n Fast, reliable and no Hazmat constraints.
26The most compact versatile and reliable hybrid system on the market.
27MCM100
The MCM100 is a configurable platform to meet multiple military Underwater Breathing ADVANCED ELECTRONICS
Apparatus (UBA) requirements. It is a fully closed circuit, electronically controlled, mixed gas n Multiple redundant electronics and rechargeable batteries.
rebreather CE tested to 100m, suitable for a large range of military or tactical diving disciplines n Advanced digital oxygen sensors with voting logic and
such as Mine Countermeasure (MCM), Explosive Ordnance Disposal (EOD) shallow or deep, Mine ‘bad sensor’ removal.
Investigation and Exploitation (MIE) and Special Operations Forces (SOF). n Moisture tolerant carbon dioxide sensor.
n Data acquisition facility with Bluetooth capability.
n Backlit colour handset with automated pre-dive and command
based alarms.
EASY BREATHING
n Extremely low work of breathing (WOB).
n High-performance open circuit Bailout valve (BOV) as standard.
n Automatic diluent gas addition valve.
n Manual diluent and oxygen gas bypass valves.
OPERATIONAL FLEXIBILITY
n High pressure composite cylinders as standard.
n Water tolerant breathing circuit and water removal systems.
n Three carbon dioxide absorbent cartridge options.
n Reduced mission set up time.
STEALTH TECHNOLOGY
n A discreet LED Heads up Display (HUD) indicating
equipment status.
n Low magnetic signature and low noise.
28Greater than 4 hours duration at extreme work rates and depths.
29MDC150
The next generation of military dive computer with real-time data/decompression logging and a ADVANCED DIVING
custom interface which is fully reconfigurable allowing reprogramming as requirements change. The n Supports Air, Nitrox, Trimix and Heliox gases
multiple algorithm capability allows for end user decompression system inclusion. The robust and n Open Circuit (OC), Closed Circuit (CC) and Semi-Closed (SC)
ergonomic form has been specifically designed for use in demanding military diving applications. configurations.
n Multiple decompression algorithms.
n Underwater gas switching capability.
EXTERNAL CONNECTIONS
n Bluetooth connectivity for dive download and firmware
reprogramming.
n Sealed and protected depth sensor.
n Wireless HP sensor option.
n Rechargeable/replaceable battery.
USER INTERFACE
n Large colour and backlit LCD.
n Three backlit switches with tactile feedback.
n Visual and audible alarms.
n User selection of dive functionality.
n Multiple language configurations.
30High resolution graphics provides enhanced resolution and backlighting for
ultra-clear messaging in the most demanding environments.
31APPLICATIONS
Applications Sub-Applications M50 FM53 M53A1 FM54 ST53 ST53SD MCM100 MDC150 EZAIR MP-PAPR CS-PAPR CS-ELITE
Military Aircrew Protection l l l l
Operations
Decontamination l l l l l l
EOD & Search (Land) l l l l l l l l l l
EOD & Search (Sea) l l l l l l l l l l
Fixed Site Protection l l l l l l
Generalist CBRN l l l
Mine Clearance (Sea) l l
Specialist CBRN l l l l l l l l
Counter Counter Smuggling & Search (Land) l l l l l l
Narcotics
Counter Smuggling & Search (Sea) l l l l l l l l
Operations
Deep Rummage & Search l l l l l l l l
Drug Enforcement l l l l l l l l l
Illicit Drug Laboratories l l l l l l l l l
Special Breaching & Entry Teams l l l l l l l
Operations
Combat Diver l l
Counter-Piracy l l l l l l l l l l
Counter Proliferation l l l l l l l l l
Covert Operations l l l l l l l
Hostage Rescue l l l l l l l l l l
VIP Protection l l l l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 58-59 and 68-69.
32Applications Sub-Applications M50 FM53 M53A1 FM54 ST53 ST53SD MCM100 MDC150 EZAIR MP-PAPR CS-PAPR CS-ELITE
Law Enforcement Border Protection l l l l l l l l l l
Operations
Correction facilities l l l l l l l l l l
Crowd Control l l l l l
First Responders l l l l l
Specialist CBRN l l l l l l l l l
Specialist Fire Arms l l l l l l l l l l
First Responders HAZMAT l l l l l l l
Carbon Monoxide Protection l l l l l l l l
Disaster Relief l l l l l l l l l
Emergency Preparedness l l l l l l
Mine Rescue l l l l l l l
Nuclear Decontamination l l l l l l l
Search and Rescue l l l l l l
Critical National Embassy l l l l l l
Infrastructure
High Value Sites l l l l l l
Protection
Nuclear Sites & Decommissioning l l l l l
Oil & Gas l l
Power Facilities l l
Transport Infrastructure l l
Water Treatment l l l
Other High Networth Individuals l l l
Media l l l
Private Security l l l l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 58-59 and 68-69.
3334
PC50 TT-TYPE
FM12 DELTAIR
C50 MI-TIC E
HMK150 MI-TIC S
P-TYPE M69
PROTECT
35M69
Based on the proven FM53 specialist mask platform, the M69 has been specifically developed CBRN PROTECTION
to meet the unique requirements of aircrew wearers who require CBRN respiratory protection n Optional connection system to aircraft oxygen supply.
at all altitudes up to 40,000ft (12,000m). n NBC or CBRN Cap 1 filter options with additional post filter module.
INTEGRATION
n Low profile butyl hose remote mounts filter.
n Compatible with most aircraft communication systems, voice
amplifier and radio lead options.
n Integrates fully with combat uniform, helmets and ballistic vests.
SIMPLE OPERATION
n Miniature compensation exhale valve allows mask use on ground and
up to 40,000 ft (12,000m).
n Fail safe hydration system, compatible with canteens and bladders.
n Integrated valsalva allows wearer to equalize during sudden
pressure changes.
n Soft elasticated harness allows forDeveloped from proven FM53 platform to include specialist features
for use in multi-engine and rotary wing airframes.
37FM12
The FM12 mask, initially developed for NATO operations, has become the most widely COMMUNICATION
adopted respirator across the world by numerous military and law enforcement organisations. n Speech Horn for clear direct communication.
n Secondary Speech Transmitter (SST) to connect
communications equipment.
FILTRATION
n Side mounted filter mount.
n Left or right mounting for tactical specialists.
n 40mm standard NATO thread.
HYDRATION
n High flow fail safe drinking device.
n Connection to hydration systems.
USER COMFORT
n 6 buckle fit allows for excellent seal.
n Quick donning and doffing.
n Available in 3 sizes.
38The mostly widely adopted respirator in the world.
39PC50
The Avon PC50 is based on the widely deployed 50 Series masks and is designed and approved as a AIR MANAGEMENT
NON-CBRN respiratory device, providing protection in dangerous and contaminated environments, n Low inhalation resistance.
against solid and liquid respirable particles, gases, vapours and splashes of liquid chemicals. n Heat build-up minimized.
n Low-re-breathed carbon dioxide.
COMMUNICATION
n External communications systems can be attached to the mask.
n Standard communication port.
USER COMFORT
n 3 face piece sizes for improved fit.
n Chlorobutyl rubber and silicone blend mask.
n Six point, easy to adjust head harness.
VISION
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
n Fully optically correct.
n Panoramic visor design gives maximum field of vision and
wearer recognition.
40Designed for the lowest cost of ownership.
41C50
The Avon C50 protective mask is based on the U.S. M50/JSGPM (Joint Services General AIR MANAGEMENT
Purpose Mask) and shares key technologies, providing maximum operational flexibility to n Low inhalation resistance and excellent de-mist properties.
counter multiple threat scenarios, including chemical, biological, nuclear and radiological
n Heat build-up minimized.
(CBRN) agents, Toxic Industrial Chemicals (TICs), and Toxic Industrial Materials (TIMs).
n Low-re-breathed carbon dioxide.
COMMUNICATION
n Front mounted exhale valve allows clear direct communication.
n For enhanced communication an optional VPU is available.
n External communications systems can be attached to mask.
USER COMFORT
n 3 face piece sizes for improved fit.
n Chlorobutyl rubber and silicone blend mask.
n Reflex seal with low profile brow for helmet compatibility.
VISION
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
n Fully optically correct.
n Panoramic visor design gives maximum field of vision and
wearer recognition.
42Building on the success of the US Military Joint Services General Purpose Mask.
43HMK150
The HMK150 is a revolutionary Helmet Mask Kombination System specifically designed for CBRN DUAL WEAR MODES
and Riot Control. Avon has teamed with Schuberth to provide flawless integration of our HM50 n Provides complete head and respiratory protection.
Respirator to the Schuberth P100N Helmet. Based on the widely deployed 50 Series mask platform, n Respirator can be donned without removing the helmet.
the HM system brings the pedigree of a mask proven for use in the harshest environments.
SCHUBERTH P100N HELMET
n 3 different shell sizes.
n Flame-retardant lining.
n EPS inner shell for optimized shock absorption properties.
USER COMFORT
n 3 face piece sizes for improved fit.
n Chlorobutyl rubber and silicone blend mask.
n Reflex seal with low profile brow for helmet compatibility.
VISION
n Unique polyurethane visor is highly flexible plus scratch and
impact resistant.
n Fully optically correct.
n Panoramic visor design gives maximum field of vision and
wearer recognition.
44A combination of two cutting edge products designed to the highest standard.
45TT-TYPE
The TT-Type thermal imaging (TI) camera is specifically designed for specialist search applications. CONNECTIVITY
Unlike traditional TI surveillance cameras, the TT is optimised to give high contrast images in the n Standard video out connector for streaming video directly.
most demanding of environments including total darkness, smoke and obscuration, confined n Images and video are stored on a removable microSD card.
space and hazardous missions.
n Evidence can be retrieved whilst camera in action.
CUSTOMISABLE START-UP SCREEN
n Organisation names and logos can be displayed at power-up.
n Enables asset tracking and/or personalisation.
INTEGRATED TORCH
n Both torchlight and thermal functionality.
n Torchlight can be enabled even when the thermal image is not.
UNPARALLELED IMAGE QUALITY
n 320 x 240 sensor option provides highest detail.
n Enhanced with proprietary signal processing algorithms.
46Specialist search modes offering unparalleled
operational capability.
47P-TYPE
The P-Type is a robust, self-contained, and simple to-operate thermal imaging camera with IMAGE QUALITY
interchangeable lenses allowing the camera to be used effectively for differing operational n 320×240 sensor option provides the highest detail.
distances from 230-1750m. It is lightweight and ergonomic, capable of withstanding harsh n Enhanced with proprietary signal process algorithms.
environments and contains many of the most advanced features available for any thermal
imaging camera. SHUTTERED OLED DISPLAY
n Shuttered eye-cup, ensures no light given off.
n Superb clarity OLED display.
n Provides true black as backlights are not required.
LENS OPTIONS
n Interchangeable lenses adapt to range of situations.
n Identify and capture images over 1,000m away.
F E D C B
Recognition 165m 115m 90m 50m 24m
Identification 460m 460m 350m 190m 90m
Detection 1750m 1250m 950m 500m 230m
48Thermal imaging technology developed by argus.
49The Mi-TIC Range of thermal imaging cameras includes the lightest and smallest NFPA 1801:2013
compliant camera available on the market.
Whether it is the safest battery technology, unmistakeable application of colours or the highest
available dynamic temperature range, our innovations are always specifically designed with
firefighter safety in mind.
3.5” 3.5”
2.7” 2.7”
50Picatinny rail mount (Mi-TIC
E and Mi-TIC 320) – add
picatinny accessories such as
flashlight or laser
Built in laser pointer
(Mi-TIC S only)
Retractable lanyard
attachments
Pocket clip
Powered by the new
Field replaceable
Germanium lens
Rubberized display
protection
High grip rubber
over molding On/Off / NFPA TI Basic
Button
Charger latching point User configurable
NFPA1901:2016 Compliant buttons
Standard
2 hour battery
Optional
Charging, programming, and 5 hour battery
data access connections
51Mi-TIC E
Lightweight size up imager – an affordable interior structural firefighting camera. The combination EASE OF USE
of low cost and long list of features make this the perfect tool for any fire department. n Single button available.
n Small and wearable at just 765g (1lb 11oz).
n High grip rubber on molding.
START-UP
n 5 second start up.
n Customisable start-up screen.
IMAGE QUALITY
n Dynamic Scene Enhancement.
n Tri-Mode Sensitivity.
n Direct Temperature Measurement.
POWERED BY IGNIS ENGINE
n Enhanced image quality.
n Latest sensor technology.
n Class leading battery technology.
52The most affordable NFPA certified camera for firefighting.
53Mi-TIC S
Premium lightweight thermal imaging with industry leading dynamic range and oversized IMAGE QUALITY
display for top performance in the most extreme firefighting environments. n High dynamic temperature range of 2000°F (1100°C).
n 320x240 resolution.
ADDITIONAL FEATURES:
n Laser pointer.
n Electronic compass.
n Hot / Cold spot indicator.
EASE OF USE
n User programmable buttons.
n 3.5” display screen.
n Small and wearable at 870g (1lb 15oz).
POWERED BY IGNIS ENGINE
n Enhanced image quality.
n Latest sensor technology.
n Class leading battery technology.
54The most advanced thermal imager for firefighting.
55DELTAIR
Developed to deliver ruggedness and reliability, Deltair has been tested to a variety of NFPA, AIR MANAGEMENT
NIOSH, and MIL Spec standards to ensure it meets and exceeds the tough demands required n Simple single action to activate positive pressure.
by fire fighters and damage control parties. n Double action required to stop the flow of air.
n Best practice for air management.
COMMUNICATION
n Loudest communications.
n Clearest communications.
n Most efficient operations.
USER COMFORT
n Wide shoulder straps.
n Wide waist straps.
n Place weight over larger surface area.
VISION
n Double curved lens.
n Optically correct lens.
n Low profile regulator further improves FOV.
WARRANTY
n Market leading 15 year warranty covering pneumatics, electronics,
rubber and elastomeric parts.
56Unprecedented level of reliability, durability and ease of use.
57APPLICATIONS
Applications Sub-Applications M69 FM12 PC50 C50 HMK150 TT-TYPE P-TYPE MI-TIC E MI-TIC S DELTAIR
Military Operations Aircrew Protection l l l
Decontamination l l
EOD & Search (Land) l l l
EOD & Search (Sea) l l l
Fixed Site Protection l l l l
Generalist CBRN l l l l
Specialist CBRN l l
Counter Narcotics Counter Smuggling & Search (Sea) l l l
Operations Deep Rummage & Search l l l l
Drug Enforcement l l l l l
Illicit Drug Laboratories l l
Special Operations Breaching & Entry Teams l l
Counter-Piracy l l l l l
Counter Proliferation l l
Covert Operations l
Hostage Rescue l l l l l
Law Enforcement Border Protection l l l l l
Operations Correction facilities l l l l l
Crowd Control l l l l
First Responders l l l l l
Scenes of Crime l l l
Specialist CBRN l l l l l
Specialist Fire Arms l l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 32-33 and 68-69.
58Applications Sub-Applications M69 FM12 PC50 C50 HMK150 TT-TYPE P-TYPE MI-TIC E MI-TIC S DELTAIR
First Responders HAZMAT l l l l
Carbon Monoxide Protection l
Disaster Relief l l l l l l l l
Emergency Preparedness l l l l l l l
Forest Fire l l l l
Marine Firefighting l l l
Mine Rescue l l l l l
Nuclear Decontamination l l l l l l
Overhaul l l l l
Search and Rescue l l l l l l
Structural Firefighting l l l
Critical National Embassy l l l
Infrastructure High Value Sites l l l
Protection
Nuclear Sites & Decommissioning l l
Oil & Gas l l l l l
Power Facilities l l l l
Transport Infrastructure l l
Water Treatment l l
Other High Networth Individuals l
Hotels & Multi-storey Buildings l
Mail Handling l l
Media l l l
Private Security l l l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 32-33 and 68-69.
5960
NH15
NH15 COMBO
CRS15
ESCAPE
61NH15
The Avon NH15 CBRN Air Purifying Escape Respirator is the smallest and most compact CBRN COMPACT
escape hood on the market, approved to carry NIOSH and CE marking. Its low cost makes it ideal n Low profile filters to reduce snagging.
for military, first responders, security and protection teams seeking immediate or emergency n Streamlined design.
respiratory protection in a CBRN scenario.
COST OF OWNERSHIP
n No fit test requirements.
n No replaceable parts.
n No maintenance or inspections.
FIT AND COMFORT
n Close fit filters.
n Self-adjusting harness.
n 3 sizes.
SEE AND BE SEEN
n Clear range of vision.
n Reflective label.
CBRN TIC CO
3 3
62The smallest and most compact CBRN certified
escape hood on the market.
63NH15 COMBO
Built on the proven technology of the NH15, the smallest and lightest NIOSH and CE certified COMPACT
air purifying escape hood ever developed, the NH15 Combo delivers the proven performance n Low profile filters to reduce snagging.
and functionality of the NH15 and adds an advanced media to provide carbon monoxide (CO) n Streamlined design.
protection. Providing a high level of respiratory, eye and face protection for a minimum of fifteen
minutes, the NH15 Combo not only protects against all airborne CBRN and CO threats but also COST OF OWNERSHIP
protects the face from liquid agent splashes. n No fit test requirements.
n No replaceable parts.
n No maintenance or inspections.
FIT AND COMFORT
n Close fit filters.
n Self-adjusting harness.
n 3 sizes.
SEE AND BE SEEN
n Clear range of vision.
n Reflective label.
CBRN TIC CO
3 3 3
64Building on the success of the NH15,
now providing full CBRN and Carbon
Monoxide protection.
65CRS15
The CRS15 pack provides respiratory and touch protection from a broad range of CBRN, TIC threats CONTENTS
and all current riot control gases, together with products for immediate self-decontamination. The n Discreet packing.
equipment is discreetly contained in a rucksack, allowing the user to rapidly respond to an incident or n Branded and unbranded options available.
event and escape from the hazardous area.
EASE OF USE
n User friendly.
n Clear instructions and operating procedures.
COMPLETE SYSTEM
n Leading edge decontamination capability.
n Full respiratory protection provided utilizing the NH15.
n Full skin, hand and touch protection.
66Lightweight self-contained equipment package for individual protection
and decontamination when exposed to a CBRN incident.
67APPLICATIONS
Applications Sub-Applications NH15 NH15 COMBO CRS15
Military Operations EOD & Search (Land) l l
EOD & Search (Sea) l l
Generalist CBRN l l
Counter Narcotics Operations Counter Smuggling & Search (Land) l l
Counter Smuggling & Search (Sea) l l
Deep Rummage & Search l l
Drug Enforcement l l
Illicit Drug Laboratories l l
Special Operations Counter-Piracy l l
Covert Operations l l l
Hostage Rescue l l
VIP Protection l l l
Law Enforcement Operations Border Protection l l l
Correction facilities l l
First Responders l l l
Scenes of Crime l
Specialist CBRN l l
Specialist Fire Arms l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 32-33 and 58-59.
68Applications Sub-Applications NH15 NH15 COMBO CRS15
First Responders HAZMAT l l
Carbon Monoxide Protection l
Disaster Relief l l l
Emergency Preparedness l l l
Forest Fire l l
Marine Firefighting l
Mine Rescue l
Nuclear Decontamination l l
Overhaul l
Search and Rescue l l
Structural Firefighting l
Critical National Infrastructure Protection Embassy l l l
High Value Sites l l l
Nuclear Sites & Decommissioning l l l
Oil & Gas l l
Power Facilities l l
Transport Infrastructure l l
Water Treatment l l l
Other High Networth Individuals l l l
Hotels & Multi-storey Buildings l l
Mail Handling l l l
Media l l l
Private Security l l l
l Optimised for the application. l Appropriate for the application. More applications / products on pages 32-33 and 58-59.
69ACCESSORIES
VISION
Clear Outsert Sunlight Outsert BlueBlocker Outsert Laser Outsert Shade 5 Cutting Outsert Mirrored Outsert Vision
Assembly Assembly Assembly Assembly Assembly Assembly Correction
FILTERS
MILCF50 CTCF50 CBRNCF50e CTCF50e Dust/Decon Filter Covers
CBRNF12CE CSCF50 GPCF50 FM61 Filter Mount Converters
70CARRIERS HYDRATION SYSTEMS
Mask Carrier Universal Carrier Individual Equipment Carrier Multi-Cam Carriers
CBR50i 3L Reservoir
COMMUNICATIONS
FM53/FM54 Voice Projection Unit C50/FM50 Voice Projection Unit Savox VA-30 Voice Projection Unit Water Canteen
with Tube Imic Microphone Assembly with Dynamic Mic and Microphone Assembly with E-Mic
71The Americas
t: +1 888 286 6440
e: customerservice@avon-protection.com
Europe, Middle East, Asia, Africa & Australasia
t: +44 (0) 1225 896705
e: protection@avon-protection.com
GR03372-01
www.avon-protection.comYou can also read
