PROMOTION 2021 Promotion Singapore
FALCON 401P
Manual focus system
MICRO VICKERS/KNOOP
FEATURES : Electronic force application system
Load cell, closed loop, force feedback
Load range 5gf - 2kgf, 11 load steps
Electronic microscope
6 position motorized turret
1 indenter position installed
Second indenter position optional
Fine adjustable manual Z-axis
Internal memory and USB storage capacity
Embedded Electronics system
I-TOUCH™ controller and touchscreen
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
Objectives 10X and 50X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with 2 pcs 25mm travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Manual focus
Electronic microscope hardness calculation
Conversion to other hardness scales
Limit settings
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 15,995.-
UP TO Excludes local shipping & installation charges
15 YEARS
GLOBAL
WARRANTY
UPON REGISTRATION
Force configuration cannot be changed, extra accessories can be added.
FALCON 401AM
Manual focus / Automatic measurement
MICRO VICKERS/KNOOP
FEATURES : IMPRESSIONSTM software pack
Manual focus /automatic measurement
Electronic force application system
Load cell, closed loop, force feedback
Load range 5gf - 2kgf, 11 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
Second indenter position optional
Fine adjustable manual Z-axis
Data storage on SSD drive, USB or HDD
Embedded electronics & External i-Cube II BOX PC
15’’ Industrial touchscreen, keyboard, mouse
Analogue or digital eyepiece is optional
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
Objectives 10X and 50X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with
2 pcs 25mm travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Manual focus
Automatic measurement (AM)
Conversion to other hardness scales
Manual pattern testing, CHD testing, KiC testing
Limit settings
Report generator
OTHERS : Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 23,495.-
UP TO Excludes local shipping & installation charges
2 YEAR
15 YEARS
GLOBAL
GLOBAL
WARRANTY INCLUDES :
WARRANTY Embedded electronics & External i-Cube II BOX PC.
UPON REGISTRATION
UPON REGISTRATION
15” industrial touchscreen, keyboard and mouse.
Force configuration cannot be changed, extra accessories can be added.
FALCON 501AF
Auto focus & auto measurement
MICRO VICKERS/KNOOP
FEATURES : IMPRESSIONSTM software pack
Auto focus & auto measurement
Electronic force application system
Motorized Z-axis
Load cell, closed loop, force feedback
Load range 5gf - 2kgf, 11 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
Second indenter position optional
CNC motorized ball bearing Z-axis (front controller)
Data storage on SSD drive, USB or HDD
Embedded i7 PC Controller with SSD drive
15’’ Industrial touchscreen, keyboard, mouse
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
Objectives 10X and 50X
UPI traceable certified Micro Vickers indenter
CCD
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with 2 pcs 25mm travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
*Optional: electronic eyepiece (501AF/DC model)
DUAL OPTICAL
DUAL OPTICAL
CHANNEL DUAL OPTICAL
CHANNEL* CHANNEL*
SOFTWARE : Auto focus (AF)
Automatic measurement (AM)
Conversion to other hardness scales
Manual pattern testing, CHD testing, KiC testing
Limit settings
Report generator
DUAL OPTICAL DUAL OPTICAL
CHANNEL* CHANNEL*
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
501AF
UP TO
15 YEARS S$ 26,995.-
GLOBAL
501AF/DC
WARRANTY
UPON REGISTRATION
S$ 29,795.-
Excludes local shipping & installation charges
INCLUDES :
Embedded i7 PC Controller with SSD drive.
15” industrial touchscreen, keyboard and mouse.
Force configuration cannot be changed, extra accessories can be added.
FALCON 501FAP
Fully Automatic System (Motorized X-Y-Z)
MICRO VICKERS/KNOOP
FEATURES : IMPRESSIONSTM software pack
Fully Automatic System (Motorized X-Y-Z)
Electronic force application system
Motorized Z-axis, motorized X-Y stage
Load cell, closed loop, force feedback
Load range 5gf - 2kgf, 11 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
CCD
Second indenter position installed
CNC motorized ball bearing Z-axis (front controller)
Data storage on SSD drive, USB or HDD
Embedded i7 PC Controller with SSD drive
DUAL OPTICAL
DUAL OPTICAL
CHANNEL DUAL OPTICAL
15’’ Industrial touchscreen, keyboard, mouse
CHANNEL* CHANNEL*
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : Objectives 10X and 50X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
DUAL OPTICAL
CHANNEL*
DUAL OPTICAL
CHANNEL*
Precision Motorized, CNC X-Y stage, 267mm x 188mm,
travels 100mm x 100mm (100kg max load)
Axle chuck for small round parts (UN-AXLECHUCK)
*Optional: electronic eyepiece (501FAP/DC model)
SOFTWARE :
Auto focus (AF)
Automatic measurement (AM)
Autofocus zoom overview camera
Conversion to other hardness scales
Automatic pattern testing, CHD testing, KiC testing
Edge detection
Limit settings
Report generator
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
501FAP
UP TO
2 YEAR
15 YEARS
S$ 37,895.-
GLOBAL
GLOBAL 501FAP/DC
WARRANTY
WARRANTY
UPON REGISTRATION
UPON REGISTRATION S$ 39,990.-
Excludes local shipping & installation charges
INCLUDES :
Embedded i7 PC Controller with SSD drive.
15” industrial touchscreen, keyboard and mouse.
Force configuration cannot be changed, extra accessories can be added.
FALCON 459P
Manual focus system
MICRO VICKERS/KNOOP/BRINELL
FEATURES : Electronic force application system
Load cell, closed loop, force feedback
Load range 200gf - 62.5kgf, 22 load steps
Electronic microscope
6 position motorized turret
1 indenter position installed
Second indenter position optional
Fine adjustable manual Z-axis
Internal memory and USB storage capacity
Embedded Electronics system
I-TOUCH™ controller and touchscreen
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : Objectives 10X and 20X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with 2 pcs 25mm travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Manual focus
Electronic microscope hardness calculation
Conversion to other hardness scales
Limit settings
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 17,995.-
Excludes local shipping & installation charges
UP TO
15 YEARS
GLOBAL
WARRANTY
UPON REGISTRATION
Force configuration cannot be changed, extra accessories can be added.
FALCON 459AM
Manual focus / Automatic measurement
MICRO VICKERS/KNOOP/ BRINELL
FEATURES : IMPRESSIONSTM software pack
Manual focus/ automatic measurement
Electronic force application system
Load cell, closed loop, force feedback
Load range 200gf - 62.5kgf, 22 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
Second indenter position optional
Fine adjustable manual Z-axis
Data storage on SSD drive, USB or HDD
Embedded electronics & External i-Cube II BOX PC
15’’ Industrial touchscreen, keyboard, mouse
Analogue or digital eyepiece is optional
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : Objectives 10X and 20X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with 2 pcs 25mm
travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Manual focus
Automatic measurement (AM)
Conversion to other hardness scales
Manual pattern testing, CHD testing, KiC testing
Limit settings
Report generator
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 25,450.-
Excludes local shipping & installation charges
UP TO
2 YEAR
15 YEARS INCLUDES :
GLOBAL
GLOBAL Embedded electronics & External i-Cube II BOX PC.
WARRANTY
WARRANTY 15” industrial touchscreen, keyboard and mouse.
UPON REGISTRATION
UPON REGISTRATION
Force configuration cannot be changed, extra accessories can be added.
FALCON 509AF
Auto focus & auto measurement
MICRO VICKERS/KNOOP/BRINELL
FEATURES : IMPRESSIONSTM software pack
Auto focus & auto measurement
Electronic force application system
Motorized Z-axis
Load cell, closed loop, force feedback
Load range 200gf - 62.5kgf, 22 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
Second indenter position optional
CNC motorized ball bearing Z-axis (front controller)
Data storage on SSD drive, USB or HDD
Embedded i7 PC Controller with SSD drive
15’’ Industrial touchscreen, keyboard, mouse
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : Objectives 10X and 20X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
100mm x100mm X-Y stage with 2 pcs 25mm travel Micrometer heads
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Auto focus (AF)
Automatic measurement (AM)
Conversion to other hardness scales
Manual pattern testing, CHD testing, KiC testing
Limit settings
Report generator
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 27,495.-
UP TO Excludes local shipping & installation charges
15 YEARS
GLOBAL
WARRANTY INCLUDES :
UPON REGISTRATION Embedded i7 PC Controller with SSD drive.
15” industrial touchscreen, keyboard and mouse.
Force configuration cannot be changed, extra accessories can be added.
FALCON 509FAP
Fully Automatic System (Motorized X-Y-Z), with overview camera
MICRO VICKERS/KNOOP/ BRINELL
FEATURES : IMPRESSIONSTM software pack
Fully Automatic System (Motorized X-Y-Z)
Electronic force application system
Motorized Z-axis, motorized X-Y stage
Load cell, closed loop, force feedback
Load range 200gf - 62.5kgf, 22 load steps
5mpx HD CCD camera system
6 position motorized turret
1 indenter position installed
Second indenter position installed
CNC motorized ball bearing Z-axis (front controller)
Data storage on SSD drive, USB or HDD
Embedded i7 PC Controller with SSD drive
15’’ Industrial touchscreen, keyboard, mouse
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
Objectives 10X and 20X
UPI traceable certified Micro Vickers indenter
UPI traceable certified test block +/-400HMV1
Precision Motorized, CNC X-Y stage, 267mm x 188mm,
travels 100mm x 100mm (100kg max load)
Axle chuck for small round parts (UN-AXLECHUCK)
SOFTWARE : Auto focus (AF)
Automatic measurement (AM)
Autofocus zoom overview camera
Conversion to other hardness scales
Automatic pattern testing, CHD testing, KiC testing
Edge detection
Limit settings
Report generator
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
PROMOTIONAL PACKAGE PRICE
S$ 37,595.-
Excludes local shipping & installation charges
UP TO
2 YEAR
15 YEARS
GLOBAL
GLOBAL INCLUDES :
WARRANTY
WARRANTY Embedded i7 PC Controller with SSD drive.
UPON REGISTRATION
UPON REGISTRATION
15” industrial touchscreen, keyboard and mouse.
Force configuration cannot be changed, extra accessories can be added.
FENIX 200ACLP
ANALOGUE Rockwell/Brinell Hardness tester
ROCKWELL/BRINELL
TECHNOLOGY OF TODAY FEATURES : Rockwell & Brinell test forces
Maintenance free, electronic force application system
FORCE Load cell, closed loop, force feedback system
Load range 10kgf - 187,5kgf
Dead weight systems Rockwell scales : A | B | C | D | E | F | G | H | K | L | M | P | R | S | V
Brinell scales : HBW1/10 | HBW1/30 | HBW2.5/31.25
HBW2.5/62.5 | HBW2.5/187.5 | HBW5/25
HBW5/62.5 | HBW5/125 | HBW5/187.5
HBW10/100
d
Electronically controlled
Adjustable dial indicator with 0.5 HR Rockwell units
Force application Digital display for scale indication, dwell time count down
and tester calibration
TIME Start, stop and menu selection buttons
ABS protection cover of the machine base
Load cell, closed loop, INCLUDES :
UPI traceable certified Rockwell C indenter
force feedback system UPI traceable certified test block +/-HRC60
UPI traceable certified test block +/-HRC40
Spindle protection cover
60mm flat Anvil
60mm V-anvil
Adjustable force workpiece clamp
TEST AREA : Working height 260mm
Throat depth 150mm
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
Adjustable clamp included
PROMOTIONAL PACKAGE PRICE
UP TO
15 YEARS
GLOBAL
S$ 8,700.-
WARRANTY Excludes local shipping & installation charges
UPON REGISTRATIONFENIX 200DCLP
DIGITAL Rockwell/Brinell Hardness tester
ROCKWELL/ BRINELL
TECHNOLOGY OF TODAY FEATURES : Rockwell & Brinell test forces
Maintenance free, electronic force application system
FORCE Load cell, closed loop, force feedback system
Load range 10kgf - 187,5kgf
Dead weight systems Rockwell scales : A | B | C | D | E | F | G | H | K | L | M | P | R | S | V
Brinell scales : HBW1/10 | HBW1/30 | HBW2.5/31.25
HBW2.5/62.5 | HBW2.5/187.5 | HBW5/25
HBW5/62.5 | HBW5/125 | HBW5/187.5
HBW10/100
d
Electronically controlled
Large digital, full color, touchscreen indicating test scale,
Force application dwell time, limits, test results, and conversion to other
hardness scales. Extra keypad for dirty environments.
TIME USB connection
Start, stop and menu selection buttons
ABS protection cover of the machine base
Load cell, closed loop,
force feedback system LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
UPI traceable Rockwell C indenter
UPI traceable certified test block +/-HRC60
UPI traceable certified test block +/-HRC40
Spindle protection cover
60mm flat Anvil
60mm V-anvil
ABS protection cover of the machine base
Adjustable force workpiece clamp
TEST AREA : Working height 260mm
Throat depth 150mm
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
Adjustable clamp included
PROMOTIONAL PACKAGE PRICE
UP TO
2 YEAR
15 YEARS
S$ 9,395.-
GLOBAL
GLOBAL Excludes local shipping & installation charges
WARRANTY
WARRANTY
UPON REGISTRATION
UPON REGISTRATIONNEXUS 3100P
Fully automatic test cycle, analogue microscope
BRINELL
FEATURES : Touchscreen Brinell hardness tester & microscope
Maintenance free, electronic force application system
Load cell, closed loop, force feedback
Load range 62.5kgf - 3000kgf
HBW 2.5/62.5 | HBW 2.5/187.5 | HBW 5/62.5 | HBW 5/125
HBW 5/250 | HBW 5/750 | HBW 10/100 | HBW 10/125
HBW 10/250 | HBW 10/500 | HBW 10/1000 | HBW 10/1500
HBW 10/3000
Large digital, full color touchscreen
indicating test scale, dwell time,
limits, test results, and multiple conversion to
other hardness scales. (Rockwell, Vickers Leeb, etc.)
USB connection
Start, stop and menu selection buttons
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES :
UPI traceable certified Ball indenter 10mm
UPI traceable certified test block HB10/3000 +/-300HB
Spindle protection cover
Large square test table 350 x 250mm
TEST AREA : Working height 220mm
Throat depth 220mm
SOFTWARE : I-TOUCH™
Automatic hardness calculator
Conversion to other hardness scales
Limit settings
Report generator
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
OPTIONAL : UN-CLAMP/120
S$ 1,220.-
UP TO
15 YEARS
GLOBAL
WARRANTY PROMOTIONAL PACKAGE PRICE
S$ 10,595.-
UPON REGISTRATION
Excludes local shipping & installation charges
Configuration cannot be changed, extra accessories can be added.NEXUS 3200P
Fully automatic test cycle, BIOS Brinell scanner
BRINELL
FEATURES : Brinell hardness tester with automatic measurement video
system
Maintenance free, electronic force application system
Load cell, closed loop, force feedback
Load range 62.5kgf - 3000kgf
HBW 2.5/62.5 | HBW 2.5/187.5 | HBW 5/62.5
HBW 5/125 | HBW 5/250 | HBW 5/750
HBW 10/100 HBW 10/125 | HBW 10/250 | HBW 10/500
HBW 10/1000 | HBW 10/1500 | HBW 10/3000
Large digital, full color, touchscreen indicating test scale,
dwell time, limits, test results, and multiple conversion to
other hardness scales. (Rockwell, Vickers Leeb, etc.)
USB connection
Start, stop and menu selection buttons
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : UPI traceable certified Ball indenter 10mm
UPI traceable certified test block HB10/3000 +/-300HB
Spindle protection cover
Large square test table 350 x 250mm
TEST AREA : Working height 220mm
Throat depth 220mm
SOFTWARE : BIOS automatic indent scanner
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
Sea and airworthy packing included
OPTIONAL : UN-CLAMP/120
S$ 1,220.-
UP TO
2 YEAR
15 YEARS
GLOBAL
GLOBAL
WARRANTY
PROMOTIONAL PACKAGE PRICE
WARRANTY
S$ 15,595.-
UPON REGISTRATION
UPON REGISTRATION
Excludes local shipping & installation charges
Configuration cannot be changed, extra accessories can be added.NEW HAWK 250RS
Nose type Rockwell hardness tester
AVAILABLE! FEATURES : Maintenance free electronic test force application
Load cell, closed loop, force feedback system
Special promotion edition Test force measurement on indenter position
Direct depth measurement system (unique
Load range 3kgf – 150kgf (187,5kgf with Brinell option)
15 YEARS Rockwell: A|B|C|D|E|F|G|H|K|L|M|P
GLOBAL Superficial Rockwell: 15N | 30N | 45N | 15T | 30T | 45T | 15W | 30W
WARRANTY 45W | 15X | 30X | 45X
UPON REGISTRATION Brinell : HBW1/1 | HBW1/1.25 | HBW1/2.5 | HBW1/5
FOR BOTH MODELS HBW1/10 | HBW1/30
HBW2.5/6.25 | HBW2.5/7.8125 | HBW2.5/15.625
HBW2.5/31.25 | HBW2.5/62.5| HBW2.5/187.5
HBW5/25| HBW5/31.25| HBW5/62.5| HBW5/125
Vickers: (optional) HV1 | HV2 | HV2.5 | HV3 | HV4 | HV5 | HV10 | HV20
HV25 | HV30 | HV40 | HV50 | HV100 | HV120 | HV150
150mm protruding nose, 200mm throat depth
250mm working height
I-TOUCH™ software system, advanced tester control,
industrial touchscreen
Power led next to indenter, integrated in nose
USB access on front and back panel
Optional workpiece clamp and pre-shaped
clamp inserts
LANGUAGE SET : English/Chinese/Japanese language only
INCLUDES : 60mm flat anvil (AS3000-19-04)
63mm V-anvil (UN-ANVIL/006)
UPI Laboratories ISO/ASTM certified Rockwell C indenter
UPI Laboratories ISO/ASTM certified test block +/-60HRC
UPI Laboratories ISO/ASTM certified test block +/- 45HRC
OTHERS : Factory Direct & Indirect ISO/ASTM calibration certificate
Sea & airworthy packing included
OPTIONAL:
Clamp installed
PROMOTIONAL PACKAGE PRICE
S$ 16,950.-
Excludes local shipping & installation charges
Force configuration cannot be changed, extra
accessories can be added.HAWK 400RS-IMP
Nose type
Manual Rockwell
focus hardness
/ Automatic tester
measurement
FEATURES : Maintenance free electronic
FEATURES test force : application
IMPRESSIONSTM software pack
Load cell, closed loop, force feedback system Manual focus/ automatic measurement
Test force measurement on indenter position Electronic force application system
Direct depth measurement system (unique Load cell, closed loop, force feedback
Load range 3kgf – 150kgf (187,5kgf with Brinell Loadoption)
range 200gf - 62.5kgf, 22 load steps
5mpx HD CCD camera system
Rockwell: A | B | C | D | E | F | G | H | K | L | M6| position
P motorized turret
Superficial Rockwell: 15N | 30N | 45N | 15T | 30T | 45T | 15W | 30W
1 indenter position installed
45W | 15X | 30X | 45X
Brinell: HBW1/1 | HBW1/1.25 | HBW1/2.5 | HBW1/5
Second indenter position optional
HBW1/10 | HBW1/30 Fine adjustable manual Z-axis
HBW2.5/6.25 | HBW2.5/7.8125 Data storage on SSD drive, USB or HDD
| HBW2.5/15.625
HBW2.5/31.25 | HBW2.5/62.5| Embedded HBW2.5/187.5 electronics & External i-Cube II BOX PC
HBW5/25| HBW5/31.25| HBW5/62.5| 15’’ Industrial
HBW5/125 touchscreen, keyboard, mouse
Vickers (optional): HV1 | HV2 | HV2.5 | HV3 | HV4 | Analogue HV5 | HV10 | or digital
HV20 | HV25eyepiece is optional
HV30 | HV40 | HV50 | HV100 | HV120 | HV150
English/Chinese/Japanese language only
150mm protruding nose, 200mm throat depth
400mm working heightINCLUDES :
IMPRESSIONS™ work flow control software with
Objectives 10X and 20X
integratedcertified
fanless Micro Vickers indenter
UPI traceable
heavy duty PC, MS Windows 10, 8,5’’ industrial
UPItouchscreen, SSD drives
traceable certified for +/-400HMV1
test block
data storage, connectivity LAN, W-LAN, Multiple
100mm USBx100mm X-Y stage with 2 pcs 25mm
Power led next to indenter, integrated in nose
travel Micrometer heads
Optional workpiece clamp and pre-shaped clamp
Axle chuckinserts
for small round parts (UN-AXLECHUCK)
Clamp provides in clamping workpiece and fully auto starts the process
of loading, testing unloading.
SOFTWARE : Manual focus
Automatic measurement (AM)
LANGUAGE SET : English/Chinese/Japanese language only Conversion to other hardness scales
Manual pattern testing, CHD testing, KiC testing
INCLUDES : Motorized automatic spindle (z-axis) withLimitfastsettings
mode
and auto-start (optional) Report generator
60mm flat anvil (AS3000-19-04)
63mm V-anvil (UN-ANVIL/006)
OTHERS :
Factory Direct & Indirect ISO/ASTM cal. certificate
UPI Laboratories ISO/ASTM certified RockwellSea
C indenter
and airworthy packing included
UPI Laboratories ISO/ASTM certified test block +/-60HRC
UPI Laboratories ISO/ASTM certified test block +/- 45HRC
OTHERS :
Factory Direct & Indirect ISO/ASTM calibration certificate
Sea & airworthy packing included
OPTIONAL:
Clamp installed
PROMOTIONAL PACKAGE PRICE
S$ 20,950.-
Excludes local shipping & installation charges
Force configuration cannot be changed, extra
accessories
Force can be cannot
configuration added. be changed, extra accessories can be added.SOFTWARE FUNCTIONS
The Graphical User interface (GUI), contains Industry preferred applications, and offers easy to learn, advanced
workflow control. A simple test can be set up and conducted in about 3 seconds…IMPRESSIONSTM layout &
functions will match not only your particular application requirements, but also meet the needs and preferences
of your operators. A user level management system maximizes their comfort and efficiency.
The unique in the industry, 15’’ portrait mode, capacitive touchscreen, gives room to all possible applications. Dual
screen: For demanding users, a second vertical 15’’ or 24’’ landscape screen can be connected. For educational
purposes, schools, universities, a full HD projector (beamer) can be connected to the HDMI supported outlet.
With this many options in Hardware and Software configuration, yearly updates and on demand upgrades,
IMPRESSIONSTM is truly the leading software in the industry.
MANUAL ON-SCREEN MEASUREMENT
The crisp camera image of the indent will be surrounded by 4 filar lines. Position the filar lines by
mouse, keyboard or via the touchscreen on the outer lines of the indent.
The system automatically calculates and displays the hardness value and gives individual diameter
values for the indent dimensions.
AUTOMATIC ON SCREEN MEASUREMENT
Directly after the crisp image of the indent shows on the screen, the automatic measurement
software finds the indent and positions the filar lines automatically on the outer lines of the indent.
Manual measurement remains possible. The system automatically calculates and displays the
hardness value and gives individual diameter values for the indent dimensions.
AUTOMATIC FOCUSSING
Right after you bring the workpiece surface within auto focus distance, one push on the auto
focus button makes that the the system finds the best ultra-sharp focus position.
In automatic testing procedures of thousands of indents, the system will find focus ultra-fast and
improves efficiency for the operator.
REPORT GENERATOR
IMPRESSIONS has a built-in report generator that allows you to create measuring data output in a
professional format.
The system is open, which means you can use either the standard report that INNOVATEST included,
modify this or generate a new report that suits your need. Excellent functionality that supports the
computer system data output via USB, wireless or in other ways via quality management systems
like Q-DAS.
USER LEVEL MANAGEMENT
Protect your system against unauthorized users. Different operators have different skills. Lock or
block employees from tampering with the system.The user level management system allows you
to give particular rights to some persons and block others from certain system functions or settings.TEST PATTERN CONFIGURATOR
Embedded in the software is the option to set up patterns of any shape. Think of circles, zig-zag,
straight lines, free style patterns etc.
The motorized stage will run the test patterns automatically while indents are made and the
hardness of a large quantity of points can be evaluated efficiently. The manual stage versions lead
you through the process while you are using the micrometer heads on the stage to position correctly.
CHD, SHD, NHD
The efficiency of sample processing in Core Hardness Depth (CHD) measurements can be enhanced
using increased automation.
This IMPRESSIONS™ function is available for both manual and automatic machines. Setting up
your CHD system has become a simple task while the software leads you through the process and
calculates termination values and CHD values quickly.
AUTOMATIC EDGE DETECTION
The overview camera system and embedded camera provide the image of an embedded sample.
This software rapidly determines the edge of the embedded sample which helps you to set up test
patterns and CHD efficiently.
DRAWING & MEASURING APPLICATION
For more complex tasks you can measure distances between indents or indent locations on the screen.
With just a few mouse clicks the software shows you the distance between clicks or dimensions of
designated areas. A useful tool in combination with the ‘’click and go’’ function for automatic testing.
SNAPSHOT FUNCTIONS
Make pictures of your microscope or overview camera images with just a mouse click and store them
in your testers database or export them to any connected device.
FULL STAGE VIEW SCANNING
This technology allows you to see the full stage surface with the embedded overview camera. In
this way you can set up multiple samples on the stage and program testing of each of them on
the bases of full overview. Very efficient for users that are looking for greater efficiency.
KiC CRACK MEASUREMENT
This software tool allows you to measure the cracks in surfaces after a Vickers hardness test. A tool
that is vital for the testing of brittle materials like porcelain, glass, etc.
CCD
DUAL OPTICAL CHANNEL
Dual Optical Channel includes a electronic digital microscope (with eyepiece) to do manual
optical measurements. This can be used simultaneously with the camera system and software
IMPRESSIONS™.
DUAL OPTICAL DUAL OPTICAL
CHANNEL* CHANNEL*
TMACCESSORIES
ACCESSORIES
VIBRATION ISOLATION OBJECTIVES RING LIGHT
ASSUN-OBJ02.5X BM-05-0003
BM-05-0001 BM-05-0004
SA-05-0013
BM-05-0002 BM-05-0005
UN-AVS-150
EYE PIECES OVERVIEW CAMERA OPTICAL SCANNERS
AS-EYEPIECE/03
UN-OVCAM2C UN-BIOS-1 UN-BIOS-2 AS3001-MICRO/01
AS3001-MICRO/02
AS-EYEPIECE/04
XY-MANUAL STAGES
UN-XYSTAGE/115 IMP-DIGIMIC UN-TESTTABLE/030
UN-XYSTAGE/120
XY-MOTORIZED STAGES
UN-XY561010
UN-XY571210
UN-XY571712
UN-XY572010
UN-XY572212ANVILS
AS3000-19-04 UN-TESTTABLE/002 UN-ANVIL/010 UN-ANVIL/011 UN-ANVIL/016
UN-VBLOCK404050 UN-CROSSBLOCK01 UN-ANVIL/020 UN-ANVIL/005 UN-ANVIL/006 UN-ANVIL/040
UN-ANVIL/045 UN-ANVIL/050 UN-ANVIL/200 UN-CVANVIL680 UN-ANVILSV/105 UN-ANVILSV/106
UN-CVANVIL50200
TEST TABLES
ROUND SQUARE
ASV700-00-20 UN-TESTTABLE/015
UN-TESTTABLE/011 UN-TESTTABLE/016
UN-TESTTABLE/013 UN-TESTTABLE/019
UN-TESTTABLE/014
SAMPLE HOLDERS
UN-ESHI25 UN-ESHI1
UN-ESHI30 UN-ESHI125
UN-ESHI40 UN-ESHI15
UN-ESH1 UN-ESH4 UN-ESH6FIXTURES AND VICES
UN-VICE/210 UN-VICE/215 UN-VICE/220 UN-VICE/230
UN-AXLECHUCK UN-CLAMP/105 UN-CLAMP/115 UN-CLAMP/120 UN-VGROOVE-CLAMP
UN-WIRE/105 UN-JOMFIX1 UN-JOMFIX3 UN-XCNCJOMFIX1 UN-VICE/115
INDENTERS
IN/6003 IN/7603 IN/7000 IN/7010
IN/6004 IN/7606 IN/7006 IN/7015
IN/6005 IN/7703 IN/7005 IN/8105
IN/7503 IN/7706 IN/7011 IN/8205
IN/7506 IN/7806 IN/7001CLAMP & INSERTS
CM-02-0304 CM-02-0314
CM-02-0313 CM-02-0312
CM-02-0311 CM-02-0315
SA-02-0110
MACHINE COVERS
UN-COVER1
UN-COVER4
MACHINE STANDS
UN-STAND/950 UN-STAND/955
UN-STAND/956 UN-STAND/960 UN-STAND/965OTHER MODELS
VICKERS
FALCON 400 FALCON 450 FALCON 500 FALCON 600 FALCON 5000
ROCKWELL
FENIX 300 SERIES VERZUS 720
ROCKWELL
HAWK 650 SERIES NEMESIS 6100 NEMESIS 6200 NEMESIS 9100RSBBRINELL NEXUS 3300(M) NEXUS 3300FA NEXUS 3400(M) NEXUS 3400FA NEXUS 8103RSB NEXUS 8103XLM-RSB NEMESIS 9100RSB UNIVERSAL NEXUS 605U VERZUS 750U NEMESIS 5100 NEMESIS 9100 NEXUS 7700 NEXUS 8100 NEXUS 8100XL NEMESIS 9600
Distributor :
All prices are excluding local: taxes, transportation & installation.
Changes in products and/or product specifications can emerge due to new technologies and continuous development.
We reserve the right to change or modify specifications of products without prior notice.
We recommend you to contact our sales office for up-to-date information.
All dimensions in this catalogue are in mm, approximate. Working heights and or workpiece
accommodation varies depending on the stages and stage
Please contact our sales department for more details.
© All rights reserved
Trademarks:
INNOVATEST®, INNOVATECH®, MASTERBLOCK®, IMPRESSIONS™ are trade names
of INNOVATEST/INNOVATECH Group of Companies.
All other brands and trade names are the unconditional property of their respective owners.
CORPORATE HEAD OFFICE
INNOVATEST Europe BV INNOVATEST SOUTH-EAST ASIA
Manufacturing, Distribution & Service Customer support center, Showroom, Sales & Service
Borgharenweg 140
6222 AA MAASTRICHT 20 Sin Ming Lane
The Netherlands #05-58 Midview City
Singapore 573 968
Phone: +31 43 3520060
Fax: +31 43 3631168 Phone: +65 6451 1123
info@innovatest-europe.com Fax: +65 6452 1011
www.innovatest-europe.com info@innovatest-singapore.com
INNOVATEST Deutschland GmbH INNOVATEST Shanghai Co,. Ltd. INNOVATEST USA Company
Sales & Service Sales & Service Sales & Service
Phone: +49 245 670 59 500 Phone: +86 21 60906200 Phone: +1 267 317 4300
info@innovatest-deutschland.com info@innovatest-shanghai.com info@innovatest-usa.com
www.innovatest-deutschland.com www.innovatest-shanghai.com www.innovatest-usa.com
INNOVATEST Polska sp. z.o.o INNOVATEST Japan Co., Ltd. INNOVATEST Singapore
Sales & Service Sales & Service Sales & Service
Phone: +48 697 099 826 Phone: +81 3 3527 3092 Phone: +65 6451 1123
info@innovatest-polska.pl info@innovatest-japan.com info@innovatest-singapore.com
www.innovatest-polska.pl www.innovatest-japan.com www.innovatest-singapore.comYou can also read
