CATALOGUE
THERMAL AND
NIGHT VISION
DEVICES
THERMAL IMAGERS
MO series BI series CLI series SCO series
Thermal monocular Thermal binoculars Thermal Clip-on Thermal scopes
Sensor: VOx 50Hz,
HUNTING OUTDOORS
SPECIFICATIONS
PRODUCT MO-335 MO-355 MO-655 MO-675
SENSOR
Sensor type VOx, 12µm VOx, 12µm
MO series Resolution 384x288 640x512
Frame rate 50 Hz 50 Hz
Thermal monocular Thermal sensitivity, NETD
Shutterless calibration
< 40 mK (0.040º)
Yes
< 40 mK (0.040º)
Yes
OPTICAL
Thermal monocular designed for many applications starting from Lens F1.0/35 mm F1.0/55 mm F1.0/55 mm F1.0/75 mm
hunting and surveillance to police and border control during Eyepiece +/-4 diopter
day/nighttime. Supplied with different lenses and sensors it allows FOV 7.5°x5.7° 5.1°x3.8° 12.5ºх10º 9.2°x7.3°
increase viewing distance up to 2.8 km. MO series uses latest Optical Magnification 3.5X 5.5X 2.3X 3.2X
12µm thermal technology combined with appropriate lens to Digital Magnification X2, X3, X4 X2, X3, X4
achieve outstanding resolution and performance. Range of detection (1.7m x 0.5m) 1305 m 2050 m 2500 m 2800 m
SYSTEM
Display resolution (pixels) OLED 1024x768
Color patterns 6
Built in video record Yes
Built in memory 8 Gb
Battery type 2xCR123 (rechargeable)
Battery life (20°C) 8h
External power supply 4.3-15 V
PHYSICAL & OPERATIONAL
Body Aluminum
Level of protection IPx6 (IP67 optional)
Operating temperature -20°С…+50°С
Dimensions, mm 160х80х65 175x80x65 175х80х65 195х83х83
Weight, kg 0,58 0,68 0,68 0,75
Warranty 2 years
MO-655
SPECIFICATIONS
PRODUCT CLI-335 CLI-355 CLI-655
SENSOR
Sensor type VOx, 12µm VOx, 12µm
CLI series Resolution 384x288 640x512
Frame rate 50 Hz 50 Hz
Thermal Clip-on Thermal sensitivity, NETD
Starting time
< 40 mK (0.040º)
SPECIFICATIONS
PRODUCT SCO-335 SCO-355 SCO-655
SENSOR
Sensor type VOx, 12µm VOx, 12µm
SCO series Resolution 384x288 640x512
Frame rate 50 Hz 50 Hz
Thermal sensitivity, NETD < 45 mK (0.040º) < 40 mK (0.040º)
Thermal rifle scope Starting time
SECURITY SURVEILLANCE
SPECIFICATIONS
PRODUCT HYB-S340 HYB-S640 Digital infrared
SENSOR
Sensor type VOx CMOS SONY 1/2"
HYB-S series Resolution 384x288 640x512 1280х720
Frame rate 50 Hz
Pixel pitch 12 µm
Short range Thermal + Day/Night Thermal sensitivity < 40 mK 0.0001 lux
Spectral range 8 … 14 µm 0.4…1 µm
monocular Shutterless calibration Yes
OPTICAL
Lens F1.0/40mm F1.8/50mm
Dual-channel monocular HYB-S is the multi-purpose device for
Eyepiece +/-4 diopter
short range all-weather and 24/7 surveillance within a wide FOV 6.6°×5.0° 10.9°x8.8° 12.5°
spectral range from 0.4 to 1.1 microns and from 8 to 14 microns. Magnification 2.7X 1.6X 4.2X
Low light CMOS sensor and bolometer with digital processing Digital zoom 2X, 4X - -
Range of detection (1.7m x .5m) 1500m 200m (night)
delivers high quality imagery in IR and LWIR. Combination of
SYSTEM
narrow FOV Infrared channel for identification and wider FOV Display resolution (pixels) 1xOLED, 1024x768 pixels
thermal imager for detection delivers 2 in 1 functionality in less Color patterns 6 1
than a 800g weight device. Built in video record Yes
Built in memory 8 Gb
Battery type 2x18650 (rechargeable)
Battery life (20°C) 8h
External power supply 4.3-15 V
PHYSICAL & OPERATIONAL
Body Aluminum
Level of protection IPX6 (IP67)
Operating temperature -20°C to +50°C
Dimensions, mm 175×120×80
Weight, kg 0.8
Warranty 2 Years
HYB-S340
SPECIFICATIONS
PRODUCT HYB-L355 HYB-L675 Digital infrared
SENSOR
Sensor type VOx CMOS SONY 1/2"
HYB-L series Resolution 384x288 640x512 1280х720
Frame rate 50 Hz
Pixel pitch 12 µm
Long range Thermal + Day/Night Thermal sensitivity
Spectral range
< 40 mK
8 … 14 µm
0.0001 lux
0.4…1 µm
binoculars Shutterless calibration time
OPTICAL
1.5 s
Lens F1.0/55mm F1.0/75mm F1.8/10-120mm
Dual-channel binocular HYB-L is the multi-purpose long range Eyepiece +/-4 diopter
device for all-weather and round-the-clock surveillance within a FOV 5.1°x3.8° 9.2°x7.3° 2°…16°
wide spectral range from 0.4 to 1.1 microns and from 8 to 14 Magnification 1.4X 2.8X 1X-10X
Digital zoom X2, X3, X4 -
microns. Low light CMOS sensor and bolometer with digital
Range of detection (1.7m x .5m) 2000m 2500m 1000m (E=0.05 lux)
processing delivers high quality imagery in IR and LWIR. Specially SYSTEM
designed IR zooming systems with active illumination allows to Display resolution (pixels) 2xOLED, 1024x768 pixels
identify hot bodies seen on LWIR channel at 2000m distance. This Color patterns 6 1
Built in video record Yes
detect and identify method works in all-weather situation and gives 8 Gb
Built in memory
awareness to any user. Battery type 2x18650 (rechargeable)
Battery life (20°C) 8h
External power supply 4.3-15 V
PHYSICAL & OPERATIONAL
Body Aluminum
Level of protection IPX6 (IP67)
Operating temperature -20°C to +50°C
Dimensions, mm 240×210×80
Weight, kg 2.2
Warranty 2 Years
HYB-L675
SPECIFICATIONS
PRODUCT BI-355 BI-375 BI-655 BI-675
SENSOR
Sensor type VOx, 12µm VOx, 12µm
BI series Resolution 384x288 640x512
Frame rate 50 Hz 50 Hz
Thermal binoculars Thermal sensitivity
Shutterless calibration
< 40 mK (0.040º)
Yes
< 40 mK (0.040º)
Yes
OPTICAL
Designed for round-the-clock supervision, search&rescue, and Lens F1.0/55 mm F1.0/75 mm F1.0/55 mm F1.0/75 mm
video registration of objects during adverse weather conditions. Eyepiece +/-4 diopter
There are number of models featuring various magnifications and FOV 5.1°x3.8° 3.5°x2.8° 8.5ºх6.7º 5.9ºx4.6º
sensitivity options. Suitable for short- or long-range surveillance Optical Magnification 3.9X 5.2X 2.3X 2.6X
and target detection up to 3km. Incorporating user-selectable Digital Magnification X2, X3, X4 X2, X3, X4
reticles, digital magnetic compass, zoom function and video Range of detection (1.7m x 0.5m) 2050 m 2800 m 2500 m 3500 m
recording capability, this device suits any security professional. SYSTEM
Display resolution (pixels) 2xOLED, 1024x768 pixels
Color patterns 6
Built in video record Yes
Built in memory 8 Gb
Battery type 2x18650 (rechargeable)
Battery life (20°C) 8h
External power supply 4.3-15 V
PHYSICAL & OPERATIONAL
Body Aluminum
Level of protection IPx6 (IP67 optional)
Operating temperature -20°С…+50°С
Dimensions, mm 150x150x65 170×160×90 170x150x65 200×160×90
Weight, kg 1.5 1.8 1.5 1.8
Warranty 2 years
BI-6100 with laser range finderSPECIFICATIONS
PRODUCT NIBI-21
SENSOR
Sensor type CMOS SONY 1/2"
NIBI- 21 Resolution 1280x1024, 5.2 μm
Frame rate 50 Hz
Sensitivity 0.0001…30 000 lux
Digital long-range night vision Spectral range
OPTICAL
0.4…1 µm
binocular Lens
FOV
F1.5/10–210mm
35°-1.5°
Diopter adjustment +/- 4dpt
NIBI-21 are digital binoculars designed for low light observation & Magnification 1x…21x
photo/video surveillance. Binocular device is equipped with high Range of detection (1.7m x 0.5m) 1500m
gain, high resolution low light CMOS sensor. Combining optics SYSTEM
Display resolution (pixels) 2xOLED, 1024x768 pixels
and sensor viewing distance of different objects is up to 1500 Built in video record Yes
meters. It can be supplied with laser range finder for precise for Built in memory 8 Gb
distance measurements. Battery type 2x18650 (rechargeable)
Battery life (20°C) 4h
External power supply 4.3-15 V
PHYSICAL & OPERATIONAL
Body Aluminum
Level of protection IPX6 (IP67)
Operating temperature -20°C to +50°C
Dimensions, mm 300×150×110
Weight, kg 2.1
Warranty 2 Years
NIBI-21SPECIFICATIONS
Model NIMO-1 NIMO-3 NIMO-5
IMAGE INTENSIFIER TUBE
IIT Generation 2+ or 3
NIMO Resolution
OPTICAL
>57 lp/mm;SPECIFICATIONS
Model GOG-1 GOG-3 GOG-5
IMAGE INTENSIFIER TUBE
IIT Generation 2X 2+ or 3
GOG Resolution
OPTICAL
>57 lp/mm;LASER RANGE FINDER attachable (Digital Night Vision + Thermal)
Measurement range Up to 1200m
Wavelength 905nm
Accuracy +/-1m
ACCESSORIES Laser class 1
Dimensions 90x65x50mm
Weight 210g
All night and thermal vision devices can be assembled with ILLUMINATORS (Night Vision)
optional accessories to improve awareness and extend the Model IR15-850 IR25-850 IR30-850
duration of equipment working time. To increase the capability of Optical power 150mW 250mW 300mW
detection or identification matched with appropriate illuminator, Wavelength 850nm
Divergence angle 0.5°-20° 0.5°-20° 1°-10°
sensor, or lens.
Range 800m 900m 1000m
Power 1 x 16340, 3.7V 1 x 16340, 3.7V 1 x 16340, 3.7V
Battery life 4-20 h 4-20 h 5-10 h
Protection IPX6
Dimensions, mm 110x30x30 dia30x140 95x55x30
Weight 90 g. 115 g. 100 g.
BATTERY PACK (Night Vision + Thermal)
Voltage 4V 8V
Operating time 6h 10h
Weight, g 125 284
Dimensions, mm 92x40x30 102x62x34
Temperature range -20°C …+50°C
Protection IPX6
F1.0/55mm IR15-850 Battery type Li-ion (1×18650) Li-ion (2×18650)
THERMAL LENSES (Germanium)
Lenses F1.0/35mm F1.0/55mm F1.0/75mm F1.0/100mm
RANGE PERFORMANCE with LENS (theoretical) with 12um sensor
Human (H1.7m x W0.5m)
Detection 1305m 2050m 2800m 3730m
Recognition 325m 510m 700m 930m
Identification 200m 320m 430m 580m
Vehicle (H2.3m x W2.3m)
Detection 3800m 5270m 7200m 9580m
Recognition 960m 1100m 1800m 2400m
Identification 600m 820m 1120m 1500m
LRF – laser range finderADOS-TECH, UAB Mokslininku st. 2A, LT-08412 Vilnius, Lithuania Tel: +370 5 270 6407 Fax: +370 5 210 0067 info@ados-tech.com www.ados-tech.com
