Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas


Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Dialight LED Lighting Catalogue - EMEA
for Industrial and Hazardous Areas

                                     February 2018
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Cost-Effective
   Low maintenance integrated
  design, high efficiency, and an
 industry leading warranty equal
significant time and cost savings.

Sustainable
    A strategic focus on                                                       The Dialight
                                                                                Difference
  environmentally friendly
  LED technology and a
 commitment to helping all
  organizations, including
 our own, reach corporate
    sustainability goals.

     Convenient
    Fixtures deliberately designed
       with no field replacement
      parts for the lifespan of the
     fixture and easy retro-fit kits
        to make installation and
         maintenance turn-key.

                                              Safe
                                        Solutions designed for the
                                         world’s most demanding
                                                                                                                          Trusted
                                      industrial environments. Fully
                                   integrated designs and extensive               Intelligent                        Deep expertise exclusively in
                                                                                                                     LED lighting technology and
                                       testing ensure that you can          Controlled lighting solutions that       decades of experience as a
                                      count on our solutions every            can seamlessly integrate with         partner to many of the world’s
                                            minute of the day.               existing factory automation and          leading organizations has
                                                                            building management systems to          helped us achieve the largest
                                                                             conveniently optimize work site          installed base of industrial
                                                                                  safety and productivity.             LED fixtures in the world.

Dialight’s Industry Leading 5, 7 and 10 Year Warranties
At Dialight, we take great pride in the design and robust engineering of our products. We deeply understand the harsh environments that our
customers depend on our fixtures to illuminate each day. That’s why our fixtures are built specifically for longevity in these conditions.

We are the only industrial LED lighting supplier with fully-integrated products built for industrial applications, featuring custom in-house power
supplies designed for long-life with superior temperature tolerance, vibration resistance and built-in surge protection. Additionally, our sealed
fixtures prevent moisture and contaminants from causing failures or reducing lifespan.

We stand behind our industry leading warranties with proven real-world results in the world’s most challenging environments and extensive
quality control testing. Additionally, whilst some other manufacturers may require a minimum threshold of 10% or more of LED components to
fail in order for a product to be defective, we do not require this because the safety and productivity of your work site is of paramount importance
to us.

If you would like to learn more about our warranties, please find the full warranty terms & conditions available on our website www.dialight.com

2                                                                                                                          www.dialight.com
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Before                                                                                                After

About Dialight
With over 80 years of industrial LED lighting experience and the largest installed base in the world, Dialight’s
extensive network of support staff, distributor and channel partners are ready to help you select among our
wide range of products to identify a lighting solution that meets your specific needs.

Vigilant®
•   LED lighting for general industrial applications
•   10 year warranty

DuroSite®
•   LED lighting for general industrial applications
•   5 & 10 year warranty

SafeSite®
•   LED lighting for hazardous area applications
•   5 & 10 year warranty

www.dialight.com                                                                                              3
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Maintenance Comparison
                         10 years

      Typical
    non-Dialight
    LED product

High Pressure
   Sodium

    Fluorescent

    Metal Halide

4
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Table of Contents
Hazardous Area Ratings			                                     12
Corrosion Protection and Coating Process			                   13

Vigilant ® LED Lighting for Industrial Applications
Vigilant® LED High Bay			                                  14-19
Vigilant® LED Low Bay			                                   20-23
Vigilant® LED High Bay - High Output			                    24-25
Vigilant® LED Dual Floodlight			                           26-27
Vigilant® LED Area Light			                                28-29
Vigilant® LED Conveyor Light 			                           30-31

DuroSite® LED Lighting for Industrial Applications
DuroSite® LED Floodlight			                                32-33
DuroSite® LED Linear - Low Profile			                      34-35
DuroSite® LED Stainless Steel Linear, Emergency Model			   36-37
DuroSite® LED Bulkhead, Emergency Model			                 38-41

SafeSite® LED Lighting for Hazardous Applications
SafeSite® LED High Bay			                                  42-43
SafeSite® LED Stainless Steel Linear, Emergency Model			   44-45
SafeSite® LED Area Light			                                46-47
SafeSite® LED Bulkhead, Emergency Model			                 48-51

SafeSite LED Transportable Lighting
for Hazardous Applications
SafeSite® LED Transportable High Bay			                      52
SafeSite® LED Transportable Bulkhead			                      53

StreetSense® LED Fixture for Infrastructure Solutions
StreetSense® LED Street Light - ATEX, IECEx                54-55

Obstruction LED Lighting
ICAO			                                                    56-57

                                                                   5
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Overview| Industrial Applications

Vigilant® LED Lighting Fixtures
for Industrial Applications
                                                            LED High Bay
                                                            Wattage Range: 		                                      80-186W
                                                            Lumen Output Range:		                                  10,500-27,000
                                                            Lumens per Watt:		                                     Up to 145
                                                            Input Voltage:			                                      100-277 VAC, 120-250 VDC
                                                            Mounting:                                              Overhead, Ceiling, Suspended
                                                            Mounting Height:                                       Up to 12m

                                                            LED High Bay - Wiring Box with Occupancy Sensor
                                                            Wattage Range: 		                                      80-186W
                                                            Lumen Output Range:		                                  10,500-27,000
                                                            Lumens per Watt:		                                     Up to 145
                                                            Input Voltage:			                                      100-277 VAC, 120-250 VDC
                                                            Mounting:                                              Overhead, Ceiling, Suspended, Wall
                                                            Mounting Height:                                       Up to 12m

                                                            Low Bay - Corded Models
                                                            Wattage Range: 		                                      42-154W
                                                            Lumen Output Range:		                                  3,500-18,000lm
                                                            Lumens per Watt:		                                     Up to 123
                                                            Input Voltage:			                                      100-277 VAC
                                                            Mounting:                                              Overhead, Ceiling, Suspended, Wall
                                                            Mounting Height:                                       Up to 7m

                                                            Low Bay - Wiring Box with Occupancy Sensor
                                                            Wattage Range: 		                                      42-154W
                                                            Lumen Output Range:		                                  3,500-18,000lm
                                                            Lumens per Watt:		                                     Up to 123
                                                            Input Voltage:			                                      100-277 VAC
                                                            Mounting:                                              Overhead, Ceiling, Suspended, Wall
                                                            Mounting Height:                                       Up to 7m

                                                            Low Bay - Integrated Wiring Box
                                                            Wattage Range: 		                                      42-154W
                                                            Lumen Output Range:		                                  3,500-18,000lm
                                                            Lumens per Watt:		                                     Up to 123
                                                            Input Voltage:			                                      100-277 VAC
                                                            Mounting:                                              Overhead, Ceiling, Suspended, Wall
                                                            Mounting Height:                                       Up to 7m

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

6                                                                                                                                                                        www.dialight.com
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Overview | Industrial Applications

Vigilant® LED Lighting Fixtures
for Industrial Applications

                                                           LED High Bay - High Output
                                                           Wattage Range: 		                                      360-480W
                                                           Lumen Output Range:		                                  42,000-60,000
                                                           Lumens per Watt:		                                     Up to 125
                                                           Input Voltage:			                                      120-277 VAC
                                                           Mounting:                                               Suspended
                                                           Mounting Height:                                       Up to 30m

                                                           LED Dual Floodlight
                                                           Wattage Range: 		                                      385W
                                                           Lumen Output Range:		                                  54,000-56,000
                                                           Lumens per Watt:		                                     Up to 145
                                                           Input Voltage:			                                      120-277 VAC, 120-250 VDC
                                                           Mounting:                                               Structure, Pole
                                                           Mounting Height:                                       Up to 25m

                                                           LED Area Light
                                                           Wattage Range: 		                                      40-66W
                                                           Lumen Output Range:		                                  5,500-9,000
                                                           Lumens per Watt:		                                     Up to 143
                                                           Input Voltage:			                                      100-277 VAC, 120-250 VDC
                                                           Mounting:                                               Ceiling, Wall, Pole
                                                           Mounting Height:		                                     Up to 10m

                                                           LED Conveyor Light
                                                           Wattage:                     		                        64W
                                                           Lumen Output:			                                       6,700
                                                           Lumens per Watt:		                                     Up to 106
                                                           Input Voltage:			                                      100-277VAC, 120-250 VDC
                                                           Mounting:                                               34mm pole mount
                                                           Mounting Height:                                       Up to 6m

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    7
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Overview| Industrial Applications

DuroSite® LED Lighting Fixtures
for Industrial Applications

                                                      LED Floodlight
                                                      Wattage Range: 		                                      106-140W
                                                      Lumen Output Range:		                                  10,500-15,000
                                                      Lumens per Watt:		                                     Up to 111
                                                      Input Voltage:			                                      100-277 VAC
                                                      Mounting:                                              Structure, Pole
                                                      Mounting Height:                                       Up to 15m

                                                      LED Linear - Low Profile
                                                      Wattage Range: 		                                      33W-66W
                                                      Lumen Output Range:		                                  3,300-6,700
                                                      Lumens per Watt:		                                     Up to 102
                                                      Input Voltage:			                                      100-277 VAC
                                                      Mounting:                                              Overhead, Wall
                                                      Mounting Height:                                       Up to 6m

                                                      LED Stainless Steel Linear & Emergency Battery Backup
                                                      Wattage Range: 		                                      34W-76W (Standard), 35W-70W (Emergency)
                                                      Lumen Output Range:		                                  2,600-5,100
                                                      Lumens per Watt:		                                     Up to 76
                                                      Input Voltage:			                                      100-277 VAC (Standard), 230/240 VAC (Emergency)
                                                      Mounting:                                              Overhead, Wall, Pole
                                                      Mounting Height:                                       Up to 6m

                                                      LED Bulkhead & LED Emergency Bulkhead
                                                      Wattage Range: 		                                      34W (Standard), 36W (Emergency)
                                                      Lumen Output Range:		                                  2,250
                                                      Lumens per Watt:		                                     Up to 66
                                                      Input Voltage:			                                      100-277 VAC (Standard), 207-264 VAC (Emergency)
                                                      Mounting:                                              Wall, Ceiling, Stanchion, Adjustable
                                                      Mounting Height:                                       Up to 4m

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

8                                                                                                                                                                        www.dialight.com
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Overview | Hazardous Applications

SafeSite® LED Lighting Fixtures
for Hazardous Area Applications

                                                          LED High Bay - High Efficiency
                                                          Wattage Range: 		                                      235W
                                                          Lumen Output Range:		                                  9,650-23,500
                                                          Lumens per Watt:		                                     Up to 110
                                                          Input Voltage:			                                      100-277 VAC
                                                          Mounting:                                              Pole, Overhead, Ceiling, Wall
                                                          Mounting Height:                                       Up to 12m
                                                          Zone:                       		                         Zone 1, 21 and Zone 2, 22

                                                          LED Linear & LED Emergency Linear - Stainless Steel
                                                          Wattage Range: 		                                      34W-76W (Standard), 35W-70W (Emergency)
                                                          Lumen Output Range:		                                  2,600-5,100
                                                          Lumens per Watt:		                                     Up to 76
                                                          Input Voltage:			                                      110-250 VAC (Standard), 230-240 VAC (Emergency)
                                                          Mounting:                                              Overhead, Ceiling, Wall, Pole
                                                          Mounting Height:                                       Up to 6m
                                                          Zone:                       		                         Zone 1, 21 and Zone 2, 22

                                                          LED Area Light
                                                          Wattage Range: 		                                      22-58W
                                                          Lumen Output Range:		                                  2,200-6,000
                                                          Lumens per Watt:		                                     Up to 109
                                                          Input Voltage:			                                      100-277 VAC
                                                          Mounting:                                              Overhead, Ceiling, Wall, Pole
                                                          Mounting Height:                                       Up to 10m
                                                          Zone:                       		                         Zone 1, 21 and Zone 2, 22

                                                          LED Bulkhead & LED Emergency Bulkhead
                                                          Wattage Range: 		                                      34W (Standard), 36W (Emergency)
                                                          Lumen Output Range:		                                  2,250
                                                          Lumens per Watt:		                                     Up to 66
                                                          Input Voltage:			                                      100-277 VAC (Standard), 207-264 VAC (Emergency)
                                                          Mounting:                                              Wall, Ceiling, Stanchion, Adjustable
                                                          Mounting Height:                                       4m and lower
                                                          Zone:                       		                         Zone 1, 21 and Zone 2, 22

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    9
Dialight LED Lighting Catalogue - EMEA - for Industrial and Hazardous Areas
Overview| Industrial and Hazardous Applications

SafeSite® LED Transportable Range
for Hazardous Area Applications

                                                         SafeSite LED Transportable High Bay
                                                         Wattage Range: 		                                      144W
                                                         Lumen Output Range:		                                  16,000
                                                         Lumens per Watt:		                                     Up to 110
                                                         Input Voltage:			                                      100-277 VAC
                                                         Zone:                      		                          Zone 1, 21 and Zone 2, 22

                                                         SafeSite LED Transportable Bulkhead
                                                         Wattage Range: 		                                      34W
                                                         Lumen Output Range:		                                  2,250
                                                         Lumens per Watt:		                                     Up to 66
                                                         Input Voltage:			                                      100-277 VAC
                                                         Zone:                      		                          Zone 1, 21 and Zone 2, 22

StreetSense® LED Street Light
for Industrial and Hazardous Area Applications

                                                         StreetSense LED Street Light - CE and ATEX Zone 2
                                                         Wattage Range: 		                                      65-252W
                                                         Lumen Output Range:		                                  5,500-20,250
                                                         Lumens per Watt:		                                     Up to 85
                                                         Input Voltage:		                                       100-277 VAC
                                                         Zone:				Zone 2

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

10                                                                                                                                                                       www.dialight.com
Overview| Industrial and Hazardous Applications

Obstruction LED Lighting Solutions
ICAO
                                                           Vigilant LED Based ICAO Type A
                                                           High Intensity (White / Red) Strobe
                                                           Effective Intensity:		 White Day – 200,000 cd
                                                           				White Twilight- 20,000 cd
                                                           				                   White or Red Night- 2,000 cd
                                                           Wattage: 			 White day - 160W
                                                           				White twilight - 30W
                                                           				White Night - 23W
                                                           				Red Night - 30W
                                                           Input Voltage: 			                                     208-277 VAC

                                                           Vigilant LED Based ICAO Type A/Type B
                                                           Medium Intensity (White/Red) Strobe - Infrared (IR) available
                                                           Effective Intensity:		 White Day- 20,000 cd
                                                           				White Night- 2,000 cd
                                                           				Red Night- 2,000 cd
                                                           Wattage: 			 White Day- 36W (system = 75W)
                                                           				White Night- 4W (system = 10W)
                                                           				         Red Night- 12W (system = 25W)
                                                           Input Voltage: 			                                     120-240 VAC or +/- 48 VDC

                                                           Vigilant LED Based ICAO Type B/Type C
                                                           Medium Intensity (Red) Beacon - Infrared (IR) available
                                                           Effective Intensity:		                                 2,000 cd
                                                           Wattage: 			 3.3W (16.7% duty circle)- standard
                                                           				7.0W (16.7% duty circle)- IR model
                                                           				         20 flashes per minute with 0.5 sec. on time
                                                           Input Voltage: 			                                     120-240 VAC or 24-48 VDC

                                                           Vigilant LED Based ICAO Type B/Type E
                                                           Low Intensity (Red) RTO Side Light - Infrared (IR) available
                                                           Effective Intensity:		                                 32.5 cd
                                                           Wattage Range: 		                                      1.5-9.0W
                                                           Input Voltage:			                                      12-48 VDC, 120-240 VAC, 277 VAC

                                                           Vigilant LED Based ICAO Type B/Type E
                                                           Low Intensity (Red) Side Light
                                                           Effective Intensity:		                                 32.5 cd
                                                           Wattage Range: 		                                      13-24W
                                                           Input Voltage:			                                      12-48 VDC, 120 VAC, 230 VAC

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    11
Hazardous Area Ratings
Fixed and portable fixtures for installation and use in hazardous areas.

Zones
The zone defines the probability of hazardous material being present in an explosive concentration in the atmosphere.
        Zone                                             Hazardous Material in Surrounding Atmosphere
       Zone 0, 20                   Area in which an explosive gas / dust mixture is continuously present or present for long periods
       Zone 1, 21                 Area in which an explosive gas / dust mixture is likely to occur for short periods in normal operation
       Zone 2, 22              Area in which an explosive gas / dust mixture is present for a very short time due to an abnormal condition

Protection Types
The protection types are used to denote the protection concept utilised in the devices.
          Ex                                      Presence of Hazardous Material                                                    Zones
          Ex d                                   Flameproof (Explosion proof) Enclosure                                           1, 21, 2, 22
          Ex e                                               Increased Safety                                                     1, 21, 2, 22
         Ex m                                                 Encapsulation                                                       1, 21, 2, 22
       Ex n or N                            Non incendive or/and normally no sparking circuits                                       2, 22

Temperature Ratings
Certified equipment is tested for maximum temperature rating by approval agencies.
Equipment for Group II receives a temperature code indicating the maximum temperatures of the product.
  Temperature Rating
          T1                                                                     450°C
          T2                                                                     300°C
          T3                                                                     200°C
          T4                                                                     135°C
          T5                                                                     100°C
          T6                                                                      85°C

Groups (Gas & Dust)
Equipment is tested for suitability in specified gas groups and dust groups.
Gas groups IIA, IIB, IIC. Dust groups IIIA, IIIB, IIIC

        Group                                            Hazardous Material in Surrounding Atmosphere
       Group IIA                                                              Propane group
       Group IIB                                                              Ethylene group
       Group IIC                                                            Hydrogen group
       Group IIIA                                                         Combustible flyings
       Group IIIB                                                         Non-conductive dust
       Group IIIC                                                           Conductive dust

12                                                                                                                          www.dialight.com
Corrosion Protection and Coating Process

Surface Preparation

Industry-Standard
   • Acid etch iron phosphate conversion
   • Rinse
   • Acid seal

                                                                                          Industry standard product after
                                                                                           3000 hour Salt Spray Testing
                                                                                                   (ASTM B117)
Dialight
   • Proprietary alkaline etching
   • Multiple reverse osmosis rinse removing calcium and minerals
   • Proprietary surface conversion for chemical and mechanical bond to powder
   • Final clean rinse using pure reverse osmosis water

                                                                                          Industry standard product after
                                                                                           3000 hour Salt Spray Testing
                                                                                                   (ASTM B117)

Powder Coat

Industry-Standard
   • Single layer hybrid epoxy - standard polyester powder coat

Dialight (2 coats)
   • 1st coat
		     Epoxy primer base coat (much better bonding to the aluminium than polyester)
   • 2nd coat
		     Super durable polyester (better UV, chemical, salt and environmental resilience)

www.dialight.com                                                                                                        13
Industrial Applications| High Bay

 Vigilant® LED High Bay
 Technical Specification
                                                                                                                  Certifications & Ratings:
                                                                                                                  EN 60598-1:2015                             IP66 to EN 60529
                                                        Mechanical Information:                                   EN 60598-2-1 (ed.1), IEC                    IK10 to EN 50102
                                                        Fixture weight:                                           60598-2-1 (ed.8)                            (Polycarbonate lens)
                                                        8.2 kg (18 lbs)
                                                                                                                  EN 60598-2-24:2013                          IK06 to EN 50102 (Acrylic lens)
                                                        Shipping weight:
                                                                                                                  EN 62471:2008, EN                           IK05 to EN 50102 (Glass lens)
                                                        10.9 kg (24 lbs)
                                                                                                                  62778:2014                                  D-Marking to EN 60598 2-24
                                                        Mounting:
                                                                                                                  EN 62493:2015                               ENEC
                                                        Stainless Steel Hook
                                                                                                                  IEC60068                                    L70 >150,000 hours @ 25oC
                                                        Power Cord:
                                                                                                                  Salt spray testing - severity               ambient
                                                        3 meters, H07RN-F Heavy Duty
                                                                                                                  Variable Dimming as Standard:
                                                        Prefix: HEE
 Corded Model                                                                                                     Variable Dimming Control:		 0-10 VDC

                                                                                                                  Dimming Range:		 10 VDC = 100% light output
                                                                                                                  		 0 VDC =  0.9
                                                        11.8 kg (26 lbs)
                                                        Mounting:
                                                        Various Kits (see page 17)                                Construction:
                                                        Wiring Box Cable Entries:                                 Housing:                               Copper-free aluminium
                                                        M25 x 3
                                                                                                                  Finish:                                Superior dual coat finish
                                                        Terminals:                                                                                       -Sealed polyester topcoat
                                                        4mm2 x 5                                                                                         -Chemical-resistant epoxy primer
                                                        Prefix: HWE                                               Lens:                                  See table
 Integrated Wiring Box
                                                                                                                  Photometric Information:
                                                                                                                  CRI:                                   80

                                                                                                                  CCT:                                   5000K (cool white)
                                        Comparison
                                                                                                                                                         4000K (neutral white)
                                          Warranty                           L70
 Dialight LED High Bay                     10yr                           >150,000
  Metal Halide                              1                              15,000                                 All values typical unless otherwise stated (tolerance +/- 10%)
  High Pressure Sodium                      1                              20,000

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 14                                                                                                                                                                     www.dialight.com
Industrial Applications| High Bay

Vigilant® LED High Bay
Dimensional Drawings

                                                                             Corded Model with Hook Mount

                                                                                                                                                   14.3
                                                                                                                                                  [.56]

                                                                                                                                                                                              261
                                                                                                                                                                                            [10.3]

                                                                                                       406
                                                                                                      [16]

                                                                           Wiring Box with Occupancy Sensor

                                                                                                                         174
                                                                                                                        [6.9]

                                                                                                             616
                                                                                                           [24.3]                                                                             292
                                                 154                                                                                                                                        [11.5]
                                                [6.1]

                                                                                                      439
                                                                                                    [17.3]

                                                                                    Integrated Wiring Box

                                                                                                                           174
                                                                                                                          [6.9]

                                                    154                                                                                                                              269    292
                                                   [6.1]                                                                                                                           [10.6] [11.5]

                                                                                                                                                        499
                                                                                                                                                      [17.3]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    15
Industrial Applications| High Bay

 Vigilant® LED High Bay                                                                                                                                                                      = 0O
 Beam Distribution & Accessories                                                                                                                                                             = 90O

 Medium                                                                                                   Oval

                                HBXW3-SSL-316M                                                                                                                            HBXSBDK
                                                                                                     HBXCAB48
                                                                                                                                                                          • Sand blast kit
                                HBXW3-SSL-304M                                                       • 48” long stainless steel
                                                                                                                                                                            (dome lens)
                                • Stainless steel bracket                                              safety rope (for use with
                                                                                                       safety bracket)                                                    HBXSBDL
                                                                                                                                                                          • Sacrificial dome lens

                                HBXW3-SSL-304FTM                                                                                                                          HBXSBK
                                • 304 stainless steel                                                HBXSB Safety Tabs                                                    • Sand blast kit
                                  forward throw bracket                                              • 316 stainless steel                                                  (flat lens)
                                HBXW3-SSL-316FTM                                                     • Includes 4 tabs                                                    HBXSBL
                                • 316 stainless steel
                                                                                                                                                                          • Sacrificial flat lens
                                  forward throw bracket

                                HBXW3                                                                HBXGS                                                               HBXFSIRREMOTE
                                • Powder-coated                                                      • Glare shield (internal                                            • Remote for
                                  aluminium swivel bracket                                             use only, for use with                                              occupancy sensor
                                                                                                       flat lens)

                               HBXW3EUHOOK
                               • Swivel bracket with
                                 hanging hook

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 16                                                                                                                                                                     www.dialight.com
Industrial Applications| High Bay

Vigilant® LED High Bay
Ordering Information
                                                      Integrated Wiring Box - comes standard with bracket HBXW3
                                  Legacy Part                                                                                                                                          Beam
      Part Number                                         Lumens         Watts       lm/W                   Voltage                   CCT       CRI              Lens
                                    Number                                                                                                                                          Distribution
  HWE7MC2EDANNGN                HEEGMC4PNJNG                27,000         186        145       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass               Medium

  HWE4MC2EDANNGN                 HEE2MC4PNJNG               26,000         186        140       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate            Medium
                                                                                                                                                            Diffused Domed
  HWELMC2EDANNGN                 HEELMC4PNJNG               25,000         186        134       100-277 VAC, 120-250 VDC             5000K       80                                     Medium
                                                                                                                                                             Polycarbonate

  HWE7EC2EDANNGN                 HEEGEC4PNJNG               27,000         186        145       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                 Oval

  HWE4EC2EDANNGN                 HEE2EC4PNJNG               26,000         186        140       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate              Oval
                                                                                                                                                            Diffused Domed
  HWELEC2EDANNGN                 HEELEC4PNJNG               25,000         186        134       100-277 VAC, 120-250 VDC             5000K       80                                       Oval
                                                                                                                                                             Polycarbonate

  HWE7MC2CDANNGN                HEEGMC4KNJNG                19,500         129        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass               Medium

  HWE4MC2CDANNGN                 HEE2MC4KNJNG               18,750         129        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate            Medium
                                                                                                                                                            Diffused Domed
  HWELMC2CDANNGN                 HEELMC4KNJNG               18,000         129        130       100-277 VAC, 120-250 VDC             5000K       80                                     Medium
                                                                                                                                                             Polycarbonate

  HWE7EC2CDANNGN                 HEEGEC4KNJNG               18,000         129        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                 Oval

  HWE4EC2CDANNGN                 HEE2EC4KNJNG               17,250         129        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate              Oval
                                                                                                                                                            Diffused Domed
  HWELEC2CDANNGN                 HEELEC4KNJNG               16,750         129        130       100-277 VAC, 120-250 VDC             5000K       80                                       Oval
                                                                                                                                                             Polycarbonate

  HWE7MC2BDANNGN                HEEGMC4GNJNG                14,250         102        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass               Medium

  HWE4MC2BDANNGN                 HEE2MC4GNJNG               13,750         102        135       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate            Medium
                                                                                                                                                            Diffused Domed
  HWELMC2BDANNGN                 HEELMC4GNJNG               13,500         102        132       100-277 VAC, 120-250 VDC             5000K       80                                     Medium
                                                                                                                                                             Polycarbonate

  HWE7EC2BDANNGN                 HEEGEC4GNJNG               14,250         102        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                 Oval

  HWE4EC2BDANNGN                 HEE2EC4GNJNG               13,750         102        135       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate              Oval
                                                                                                                                                            Diffused Domed
  HWELEC2BDANNGN                 HEELEC4GNJNG               13,500         102        132       100-277 VAC, 120-250 VDC             5000K       80                                       Oval
                                                                                                                                                             Polycarbonate

  HWE7MC2ADANNGN                HEEGMC4DNJNG                11,250         80         141       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass               Medium

  HWE4MC2ADANNGN                 HEE2MC4DNJNG               10,750         80         134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate            Medium
                                                                                                                                                            Diffused Domed
  HWELMC2ADANNGN                 HEELMC4DNJNG               10,500         80         131       100-277 VAC, 120-250 VDC             5000K       80                                     Medium
                                                                                                                                                             Polycarbonate

  HWE7EC2ADANNGN                 HEEGEC4DNJNG               11,250         80         141       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                 Oval

  HWE4EC2ADANNGN                 HEE2EC4DNJNG               10,750         80         134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate              Oval
                                                                                                                                                            Diffused Domed
  HWELEC2ADANNGN                 HEELEC4DNJNG               10,500         80         131       100-277 VAC, 120-250 VDC             5000K       80                                       Oval
                                                                                                                                                             Polycarbonate

 Notes

 Note 1: Models in chart above are 5000K CCT. For 4000K CCT change the 6th character from C to N & deduct 3% from the lumen table.

 Note 2: Models with integrated wiring box are upgradeable to DALI & Wireless controls. Consult local Dialight sales office for availability.

 Note 3: Flat clear acrylic lens available, consult local Dialight sales office for availability.

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    17
Industrial Applications| High Bay

 Vigilant® LED High Bay
 Ordering Information

                                                                Standard model with 3 Meter Cable & Hook Mount
                                   Legacy Part                                                                                                                                          Beam
       Part Number                                        Lumens        Watts       lm/W                    Voltage                    CCT       CRI               Lens
                                     Number                                                                                                                                          Distribution
   HEE7MC2EDHWNGN               HEEGMC4PNHNG               27,000         186         145        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass               Medium

   HEE4MC2EDHWNGN                HEE2MC4PNHNG              26,000         186         140        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate            Medium
                                                                                                                                                             Diffused Domed
   HEELMC2EDHWNGN                HEELMC4PNHNG              25,000         186         134        100-277 VAC, 120-250 VDC             5000K        80                                    Medium
                                                                                                                                                              Polycarbonate

    HEE7EC2EDHWNGN               HEEGEC4PNHNG              27,000         186         145        100-277 VAC, 120-250 VDC             5000K        80           Clear Glass                Oval

    HEE4EC2EDHWNGN               HEE2EC4PNHNG              26,000         186         140        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate              Oval
                                                                                                                                                             Diffused Domed
    HEELEC2EDHWNGN               HEELEC4PNHNG              25,000         186         134        100-277 VAC, 120-250 VDC             5000K        80                                      Oval
                                                                                                                                                              Polycarbonate

   HEE7MC2CDHWNGN               HEEGMC4KNHNG               18,000         129         140        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass               Medium

   HEE4MC2CDHWNGN                HEE2MC4KNHNG              17,250         129         134        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate            Medium
                                                                                                                                                             Diffused Domed
   HEELMC2CDHWNGN                HEELMC4KNHNG              16,750         129         130        100-277 VAC, 120-250 VDC             5000K        80                                    Medium
                                                                                                                                                              Polycarbonate

   HEE7EC2CDHWNGN                HEEGEC4KNHNG              18,000         129         140        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass                 Oval

   HEE4EC2CDHWNGN                HEE2EC4KNHNG              17,250         129         134        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate              Oval
                                                                                                                                                             Diffused Domed
   HEELEC2CDHWNGN                HEELEC4KNHNG              16,750         129         130        100-277 VAC, 120-250 VDC             5000K        80                                      Oval
                                                                                                                                                              Polycarbonate

   HEE7MC2BDHWNGN               HEEGMC4GNHNG               14,250         102         140        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass               Medium

   HEE4MC2BDHWNGN                HEE2MC4GNHNG              13,750         102         135        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate            Medium
                                                                                                                                                             Diffused Domed
   HEELMC2BDHWNGN                HEELMC4GNHNG              13,500         102         132        100-277 VAC, 120-250 VDC             5000K        80                                    Medium
                                                                                                                                                              Polycarbonate

   HEE7EC2BDHWNGN                HEEGEC4GNHNG              14,250         102         140        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass                 Oval

   HEE4EC2BDHWNGN                HEE2EC4GNHNG              13,750         102         135        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate              Oval
                                                                                                                                                             Diffused Domed
   HEELEC2BDHWNGN                HEELEC4GNHNG              13,500         102         132        100-277 VAC, 120-250 VDC             5000K        80                                      Oval
                                                                                                                                                              Polycarbonate

   HEE7MC2ADHWNGN               HEEGMC4DNHNG               11,250          80         141        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass               Medium

   HEE4MC2ADHWNGN                HEE2MC4DNHNG              10,750          80         134        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate            Medium
                                                                                                                                                             Diffused Domed
   HEELMC2ADHWNGN                HEELMC4DNHNG              10,500          80         131        100-277 VAC, 120-250 VDC             5000K        80                                    Medium
                                                                                                                                                              Polycarbonate

   HEE7EC2ADHWNGN                HEEGEC4DNHNG              11,250          80         141        100-277 VAC, 120-250 VDC             5000K        80          Clear Glass                 Oval

   HEE4EC2ADHWNGN                HEE2EC4DNHNG              10,750          80         134        100-277 VAC, 120-250 VDC             5000K        80     Clear Polycarbonate              Oval
                                                                                                                                                             Diffused Domed
   HEELEC2ADHWNGN                HEELEC4DNHNG              10,500          80         131        100-277 VAC, 120-250 VDC             5000K        80                                      Oval
                                                                                                                                                              Polycarbonate

  Notes

  Note 1: Models in chart above are 5000K CCT. For 4000K CCT change the 6th character from C to N & deduct 3% from the lumen table.

  Note 2: Flat clear acrylic lens available, consult local Dialight sales office for availability.

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 18                                                                                                                                                                     www.dialight.com
Industrial Applications| High Bay

Vigilant® LED High Bay
Ordering Information

                                                   Occupancy Sensor Models - comes standard with bracket HBXW3
                                  Legacy Part                                                                                                                                          Beam
     Part Number                                         Lumens         Watts       lm/W                   Voltage                   CCT       CRI               Lens
                                    Number                                                                                                                                          Distribution
 HWE7MC2EMANNGN                 HEEGMC4PKJNG               27,000         186        145       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                Medium

 HWE4MC2EMANNGN                 HEE2MC4PKJNG               26,000         186        140       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate             Medium
                                                                                                                                                           Diffused Domed
 HWELMC2EMANNGN                 HEELMC4PKJNG               25,000         186        134       100-277 VAC, 120-250 VDC             5000K       80                                      Medium
                                                                                                                                                            Polycarbonate

 HWE7EC2EMANNGN                 HEEGEC4PKJNG               27,000         186        145       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                  Oval

 HWE4EC2EMANNGN                 HEE2EC4PKJNG               26,000         186        140       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate               Oval
                                                                                                                                                           Diffused Domed
 HWELEC2EMANNGN                  HEELEC4PKJNG              25,000         186        134       100-277 VAC, 120-250 VDC             5000K       80                                        Oval
                                                                                                                                                            Polycarbonate

 HWE7MC2CMANNGN                 HEEGMC4KKJNG               19,500         129        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                Medium

 HWE4MC2CMANNGN                 HEE2MC4KKJNG               18,750         129        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate             Medium
                                                                                                                                                           Diffused Domed
 HWELMC2CMANNGN                 HEELMC4KKJNG               18,000         129        130       100-277 VAC, 120-250 VDC             5000K       80                                      Medium
                                                                                                                                                            Polycarbonate

 HWE7EC2CMANNGN                 HEEGEC4KKJNG               18,000         129        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                  Oval

 HWE4EC2CMANNGN                 HEE2EC4KKJNG               17,250         129        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate               Oval
                                                                                                                                                           Diffused Domed
 HWELEC2CMANNGN                 HEELEC4KKJNG               16,750         129        130       100-277 VAC, 120-250 VDC             5000K       80                                        Oval
                                                                                                                                                            Polycarbonate

 HWE7MC2BMANNGN                 HEEGMC4GKJNG               14,250         102        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                Medium

 HWE4MC2BMANNGN                 HEE2MC4GKJNG               13,750         102        135       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate             Medium
                                                                                                                                                          Diffused Domed
 HWELMC2BMANNGN                 HEELMC4GKJNG               13,500         102        132       100-277 VAC, 120-250 VDC             5000K       80                                      Medium
                                                                                                                                                           Polycarbonate

 HWE7EC2BMANNGN                 HEEGEC4GKJNG               14,250         102        140       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                  Oval

 HWE4EC2BMANNGN                 HEE2EC4GKJNG               13,750         102        135       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate               Oval
                                                                                                                                                           Diffused Domed
 HWELEC2BMANNGN                 HEELEC4GKJNG               13,500         102        132       100-277 VAC, 120-250 VDC             5000K       80                                        Oval
                                                                                                                                                            Polycarbonate

 HWE7MC2AMANNGN                 HEEGMC4DKJNG               11,250          80        141       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                Medium

 HWE4MC2AMANNGN                 HEE2MC4DKJNG               10,750          80        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate             Medium
                                                                                                                                                           Diffused Domed
 HWELMC2AMANNGN                 HEELMC4DKJNG               10,500          80        131       100-277 VAC, 120-250 VDC             5000K       80                                      Medium
                                                                                                                                                            Polycarbonate

 HWE7EC2AMANNGN                 HEEGEC4DKJNG               11,250          80        141       100-277 VAC, 120-250 VDC             5000K       80           Clear Glass                  Oval

 HWE4EC2AMANNGN                 HEE2EC4DKJNG               10,750          80        134       100-277 VAC, 120-250 VDC             5000K       80      Clear Polycarbonate               Oval
                                                                                                                                                           Diffused Domed
 HWELEC2AMANNGN                 HEELEC4DKJNG               10,500          80        131       100-277 VAC, 120-250 VDC             5000K       80                                        Oval
                                                                                                                                                            Polycarbonate

 Notes

 Note 1: Models in chart above are 5000K CCT. For 4000K CCT change the 6th character from C to N & deduct 3% from the lumen table.

 Note 2: Models with integrated wiring box are upgradeable to DALI & Wireless controls. Consult local Dialight sales office for availability.

 Note 3: Flat clear acrylic lens available, consult local Dialight sales office for availability.

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    19
Industrial Applications| Low Bay

 Vigilant® LED Low Bay
 Technical Specifications

                                                      Mechanical Information:
                                                      Fixture weight:                                    Certifications & Ratings:
                                                      8.2 kg (18 lbs)
                                                                                                         EN 60598:2015                                   IP66 to EN 60529
                                                      Shipping weight:                                                                                   IK10 to EN 50102
                                                                                                         EN 60598-2-1 (ed.1), IEC 60598-
                                                      10.9 kg (24 lbs)                                                                                   (Polycarbonate lens)
                                                                                                         2-1 (ed.8)
                                                      Mounting:                                                                                          IK06 to EN 50102 (Acrylic lens)
                                                      Stainless Steel Hook                               EN 60598-2-24:2013
                                                                                                                                                         IK05 to EN 50102 (Glass lens)
                                                      Power Cord:                                        EN 62471:2008, EN 62778:2014                    D-Marking to EN 60598 2-2
                                                      3 meters, H07RN-F Heavy Duty                       EN 62493:2010                                   ENEC
                                                                                                         IEC60068                                        L70 >150,00 hours @ 25oC
                                                      Prefix: LEE                                        Salt spray testing - severity 1                 ambient
                                                                                                         Variable Dimming as Standard:
Corded Models                                                                                            Variable Dimming Control: 0-10 VDC

                                                                                                         Dimming Range:                          10 VDC = 100% light output
                                                  Mechanical Information:                                                                        0 VDC =  0.9
                                                     11.8 kg (26 lbs)
                                                     Mounting:                                           Construction:
                                                     Various Kits (see page 17)                          Housing:                                Copper-free aluminium
                                                     Wiring Box Cable Entries:
                                                                                                         Finish:                                 Superior dual coat finish
                                                     M25 x 3
                                                                                                                                                 -Sealed polyester topcoat
                                                     Terminals:                                                                                  -Chemical-resistant epoxy primer
                                                     4mm2 x 5
                                                                                                         Lens:                                   See table
                                                     Prefix: LWE

Integrated Wiring Box                                                                                    Photometric Information:
                                                                                                         CRI:                                    80

                                                                                                         CCT:                                    5000K (cool white)
                                        Comparison                                                                                               4000K (neutral white)
                                          Warranty                          L70
   Dialight LED Low Bay                    10yr                          >150,000
   Metal Halide                             1                             15,000                         All values typical unless otherwise stated (tolerance +/- 10%)
   High Pressure Sodium                     1                             20,000

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 20                                                                                                                                                                     www.dialight.com
Industrial Applications| Low Bay

Vigilant® LED Low Bay
Dimensional Drawings

                                                                             Corded Models with Hook Mount

                                                                                                                                                14.3
                                                                                                                                               [.56]

                                                                                                                                                                                               261
                                                                                                                                                                                             [10.3]

                                                                                                       406
                                                                                                     [16.0]

                                                                          Wiring Box with Occupancy Sensor

                                                                                                                           174
                                                                                                                          [6.9]

                                                                                                              616
                                                                                                            [24.2]                                                                           373
                                               154
                                              [6.1]                                                                                                                                        [14.7]

                                                                                                      439
                                                                                                    [17.3]

                                                                                    Integrated Wiring Box

                                                                                                                                         174
                                                                                                                                        [6.9]
                                               154
                                              [6.1]
                                                                                                                                                                                               373
                                                                                                                                                                                             [14.7]

                                                                       439
                                                                     [17.3]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    21
Industrial Applications| Low Bay

 Vigilant® LED Low Bay
 Mounting Accessories & Beam Distribution
                               HBXW3-SSL-316M                                                                                     HBXCAB48
                               HBXW3-SSL-304M                                                                                     • 1.21M long stainless steel safety rope
                               • Stainless steel bracket                                                                            (for use with safety bracket)

                               HBXW3-SSL-304FTM
                               • 304 stainless steel forward                                                                      HBXSB
                                 throw bracket                                                                                    • 316 stainless steel
                               HBXW3-SSL-316FTM                                                                                   • Includes 4 tabs
                               • 316 stainless steel forward
                                 throw bracket

                               HBXW3                                                                                              HBXFSIRREMOTE
                               • Powder-coated aluminium                                                                          • Remote for occupancy sensor
                                 swivel bracket

                               HBXW3EUHOOK
                               • Swivel bracket with hanging
                                 hook

 Ultra Wide

                              = 0O
                              = 90O

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 22                                                                                                                                                                     www.dialight.com
Industrial Applications| Low Bay

Vigilant® LED Low Bay
Ordering Information

                                 Legacy Part                                                                                                                                           Beam
     Part Number                                       Lumens         Watts        lm/W                     Voltage                     CCT        CRI             Lens
                                   Number                                                                                                                                           Distribution

                                                              Standard Models with 3m Cable & Hook Mount
                                                                                                                                                             Diffused Domed
             LEELUC2CDHWNGN                              18,000         154         117         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LEELUC2BDHWNGN                              14,000         114         123         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
              LEELUC29DHWNGN                              9,000          80         122         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
  LEELUC26DHWNGN                 LBW1C1DEUH               6,000          56         116         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
  LEELUC24DHWNGN                 LBW1C5AEUH               4,000          42         101         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate

                                                 Integrated Wiring Box - comes standard with bracket HBXW3
                                                                                                                                                             Diffused Domed
             LWELUC2CDANNGN                              18,000         154         117         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LWELUC2BDANNGN                              14,000         114         123         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
              LWELUC29DANNGN                              9,750          80         122         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
              LWELUC26DANNGN                              6,500          56         116         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
              LWELUC24DANNGN                              4,250          42         101         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate

                                                              Integrated Wiring Box with Occupancy Sensor
                                                                                                                                                             Diffused Domed
             LWELUC2CMANNGN                              18,000         154         117         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LWELUC2BMANNGN                              14,000         114         123         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LWELUC29MANNGN                               9,750          80         122         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LWELUC26MANNGN                               6,500          56         116         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate
                                                                                                                                                             Diffused Domed
             LWELUC24MANNGN                               4,250          42         101         100-277 VAC, 120-250 VDC                5000K        80                               Ultra Wide
                                                                                                                                                              Polycarbonate

Notes

Note 1: Models in chart above are 5000K CCT. For 4000K CCT change the 6th character from C to N & deduct 3% from the lumen table.

Note 2: Models with integrated wiring box are upgradeable to DALI & Wireless controls. Consult local Dialight sales office for availability.

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    23
Industrial Applications| High Bay

Vigilant® LED High Bay - High Output
Technical Specifications
                                                                                                                                              Ratings and Certifications
                                                                                                                          • 10 year warranty
                                                                                                                          • L70 >125,000 hours @ 25oC ambient
                                                                                                                          • CE
                                                                                                                          • IP66
                                                                                                                          • IK05 (glass and acrylic lens)
                                                                                                                          • 0-10V dimming as standard
                                                                                                                        *All features not available on every model. Please refer to product part
                                                                                                                        number pages for model specifics.

              Mechanical Information                                                                                        Specifications

  Fixture weight:          26.8 kg (59 lbs)                                                     120-277 VAC                                  Housing:        Copper-free aluminium

                                                                     Voltage options:                                                                        Superior dual coat finish
  Shipping weight: 33.1 kg (73 lbs)                                                             415 VAC (consult sales)                      Finish:         - Sealed polyester topcoat
                                                                                                                                                             - Chemical-resistant epoxy prime
  *Note: Wire box installed separately from housing
                                                                     Operating temp:            -40°C to +65°C                               Lens:           See Table
                           Hook mount
  Mounting:
                           316 Stainless steel
                                                                     Power factor:              >0.9                                         CRI:            80
  Cable Entry:             M25 x 4
                                                                     THD:                       125,000                       45,000                   360                  125                      Up to 20m
 Metal Halide                                  1                          15,000
 High Pressure Sodium                          1                          20,000

                                                                                            Dimensions

                                                                                                                                                                          Dimensions in mm [inches]

                                                                                        Beam Distribution

                                              Narrow                                                                                             Medium
When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 24                                                                                                                                                                     www.dialight.com
Industrial Applications| High Bay

Vigilant® LED High Bay - High Output
Ordering Information & Mounting Accessories

                                                                                                                        Colour                                                        Beam
        Part Number                     Lumens            Wattage         lm/W               Voltage                                                         Lens
                                                                                                                    Temperature (CCT)                                              Distribution
                                                                             Standard Models - 120-277 VAC
      H6EGMC44D-HNNG                     60,000               480           125           120-277 VAC                  5000K (cool white)              Tempered glass                 Medium

      H6EGNC44D-HNNG                     60,000               480           125           120-277 VAC                  5000K (cool white)              Tempered glass                  Narrow

     H6EGMC4WD-HNNG                      45,000               360           125           120-277 VAC                  5000K (cool white)              Tempered glass                 Medium

     H6EGNC4WD-HNNG                       45,000              360           125           120-277 VAC                  5000K (cool white)              Tempered glass                  Narrow

All values typical unless otherwise stated (tolerance +/- 10%).
415 VAC options available, please consult local Dialight sales office for availability.
Acrylic and polycarbonate lens options available on made-to-order basis, please consult local Dialight sales office for availability.

                                H6XCAB72
                                • 1.8M stainless steel safety rope

                                                                                      Mounting Options

                                          Wiring Box                                                                                        Top Hat Hinge

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    25
Industrial Applications| Floodlight

 Vigilant® LED Dual Floodlight
 Technical Specifications
                                                                                                                                             Ratings and Certifications
                                                                                                                         • 10 year warranty
                                                                                                                         • CE
                                                                                                                         • IP66
                                                                                                                         • L70 >150,000 hours @ 25°C ambient
                                                                                                                         • Glass = IK05
                                                                                                                         • Polycarbonate = IK10
                                                                                                                       *All features not available on every model. Please refer to product part
                                                                                                                       number pages for model specifics.

               Mechanical Information                                                                                         Specifications
   Fixture weight:          25.4 kg (56 lbs)                                                       120-277 VAC, 50/60Hz
                                                                        Voltage:                                                          Housing:           Copper-free aluminium
                                                                                                   120-250 VDC
   Shipping weight: 27.2 kg (60 lbs)

   EPA (sq.m):              0.25 sq. m (2.69 sq. ft)                                                                                                         Superior dual coat finish
                                                                        Operating temp:            -40°C to +65°C                         Finish:            - Sealed polyester topcoat
                            304 stainless steel trunnion                                                                                                     - Chemical-resistant epoxy primer
   Mounting:                mounting bracket included
                                                                        Power factor:              >0.9                                   Lens:              Tempered glass
   Entries:                 M20 x 2
                                                                                                                                          CRI:               80
                                   2                                    THD:                       150,000                                                                                                 Up to 25m
                                                                                                           54,000                   385                  140
  Metal Halide                              1                           15,000
  High Pressure Sodium                      1                           20,000

                                                                                            Dimensions

                                                                                                                                                                            Dimension in mm [inches]

                                                                                       Beam Distribution

                                        92o Beam Angle                                                                                      35o Beam Angle

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

 26                                                                                                                                                                     www.dialight.com
Industrial Applications| Floodlight

Vigilant® LED Dual Floodlight
Ordering Information & Mounting Accessories

                             Fixture                                                                                    Colour                                                Beam          Field
   Part Number                               Wattage          lm/W                      Voltage                                                            Lens
                             Lumens                                                                                 Temperature (CCT)                                         Angle         Angle

   FLEB66MC2NG                56,000             385            145          120-277 VAC, 120-250 VDC                  5000K (cool white)            Tempered Glass              35°          108°

   FLEBM0MC2NG                54,000             385            140          120-277 VAC, 120-250 VDC                  5000K (cool white)            Tempered Glass              92°          120°

All values typical unless otherwise stated (tolerance +/- 10%).

                                 HZXCBL2
                                 • Stainless steel safety cable kit

                                                                           Dual Floodlight Mounting Options

                                                                Factory-Installed Mounting Bracket Dimensions

                                                                                                                                                                          Dimension in mm [inches]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                     27
Industrial Applications| Area Light

 Vigilant® LED Area Light
 Technical Specifications

                                                                                                                                            Ratings and Certifications
                                                                                                                      • 10 year warranty
                                                                                                                      • L70 >300,000 hours @ 65°C ambient
                                                                                                                      • CE/ENEC
                                                                                                                      • IP66/67
                                                                                                                      • IK07 (glass lens) / IK10 (polycarbonate lens)
                                                                                                                    *All features not available on every model. Please refer to product part
                                                                                                                    number pages for model specifics.

           Mechanical Information                                                                                       Specifications
                                                             Voltage:                   100 - 277 VAC 50/60Hz, 120-250 VDC Housing: Copper-free aluminium
   Fixture weight:          5.2 kg (11.5 lbs)
                                                                                                                                                               Superior dual coat finish
                                                             Operating temp:            -40°C to +65°C                                        Finish:          - Sealed polyester topcoat
   Shipping weight: 6.1 kg (13.5 lbs)
                                                                                                                                                               - Chemical-resistant epoxy primer
                            316 Stainless steel              Power factor:              >0.9                                                                   Polycarbonate
   Mounting:                                                                                                                                  Lens:
                            mounting bracket
                                                             THD:                       300,000                                7,300                    52                   140
  Metal Halide                           1                            15,000                                 5,700                    40                   143                                3m
  High Pressure Sodium                   1                            20,000

                                                                                            Dimensions
                                                             213
                                                         �-- 213
                                                         �--                                                                             2x M20xl
                                                                                                                                            M20xl .5
                                                                                                                                                   .5 ENTRIES
                                                                                                                                                      ENTRIES
                                                                                                                                         2x
                                                              [8.4]
                                                             [8.4]

                                                              94
                                                             94
                                                             [3.7J
                                                             [3.7J                                                                                                                  50, 22
                                                                                                                                                                                   50,
                                                                                                                                                                                   [1.98]
                                                                                                                                                                                  [1.98]

                                                                                                         33 00 II
                                                                                                          [11.8J
                                                                                                         [11.8J
                                                                                                    202
                                                                                                    202
                                                                                                     [8.0]
                                                                                                    [8.0]
                                                                                                 ll
                                                                                             77 77
                                                                                              [3.0 JJ
                                                                                              [3.0

                                                    ----2 77 22
                                                    ----2
                                                         [10.7 JJ
                                                        [10.7                                                                                    II II 4,
                                                                                                                                                       4, 33
                                                                                                                                                   [4.50 JJ
                                                                                                                                                  [4.50                                      6I73
                                                                                                                                                                                              6I73
                                                                                                                                                    58, 77
                                                                                                                                                    58,                                         [.265]]
                                                                                                                                                                                               [.265
                                                                                                                                                     [2.31]
                                                                                                                                                    [2.31]

                                                                                                                                                                                      8, 5I
                                                                                                                                                                                      8,  5I
                                                                                                                                                                    1.40
                                                                                                                                                                    1.40   XX
                                                                                                                                                                                           [.335]
                                                                                                                                                                                 ..5566 [.335]
                                                                                                                                                          63, 55
                                                                                                                                                                    SLOT
                                                                                                                                                                    SLOT
                                                                                                                                                          63,                          33 5,
                                                                                                                                                                                           5, II
                                                                                                      �---3 00 II
                                                                                                      �---3                                               [2.50]
                                                                                                                                                          [2.50]                        [[1.38
                                                                                                                                                                                          1.38 JJ
                                                                                                          [[11.8
                                                                                                            11.8 JJ                                                             Dimension in mm [inches]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

28                                                                                                                                                                         www.dialight.com
Industrial Applications| Area Light

Vigilant® LED Area Light
Ordering Information

                            Legacy Part                                                          Colour                                   Beam                                       Hardware
    Part Number                                  Lumens         Wattage          lm/W                                       Lens                      Mounting Options
                              Number                                                         Temperature (CCT)                            Angle                                     Accessories

                                                                                     CE with Junction Box
                                                                                                                                                        316 stainless steel
 ALE7AC26DBJUGN             STJW8C2GEU             5500             40            138          5000K (cool white)            Glass         180°                                      Junction box
                                                                                                                                                        adjustable bracket
                                                                                                                                                        316 stainless steel
 ALE7AC27DBJUGN             STJWEC2GEU             7100             52            137          5000K (cool white)            Glass         180°                                      Junction box
                                                                                                                                                        adjustable bracket
                                                                                                                                                        316 stainless steel
           ALE7AC29DBJUGN                          8800             66            133          5000K (cool white)            Glass         180°                                      Junction box
                                                                                                                                                        adjustable bracket
                                                                                                                                                        316 stainless steel
 ALE7BC26DBJUGN             STJW9C2GEU             5700             40            143          5000K (cool white)            Glass         360°                                      Junction box
                                                                                                                                                        adjustable bracket
                                                                                                                                                        316 stainless steel
 ALE7BC27DBJUGN             STJWFC2GEU             7300             52            140          5000K (cool white)            Glass         360°                                      Junction box
                                                                                                                                                        adjustable bracket
                                                                                                                                                        316 stainless steel
           ALE7BC29DBJUGN                          9000             66            136          5000K (cool white)            Glass         360°                                      Junction box
                                                                                                                                                        adjustable bracket

All values typical unless otherwise stated (tolerance +/- 10%).
Neutral white option available, please consult local Dialight sales office for availability.
3m cable gland lead options available on made-to-order basis, please consult local Dialight sales office for availability.

                                                                                      Beam Distribution

                                      180° Beam Angle                                                                                     360° Beam Angle

                                                                Factory-Installed Mounting Bracket Dimensions

                                                                                                                                                                          Dimension in mm [inches]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.
www.dialight.com                                                                                                                                                                                    29
Industrial Application| Area Light

 Vigilant® LED Conveyor Light
 Technical Specifications

                                                                                                                                           Ratings and Certifications
                                                                                                                     • 10 year warranty
                                                                                                                     • L70 >300,000 hours @ 65°C ambient
                                                                                                                     • CE/ENEC
                                                                                                                     • IP66/67
                                                                                                                     • IK10 (polycarbonate lens)
                                                                                                                    *All features not available on every model. Please refer to product part
                                                                                                                    number pages for model specifics.

               Mechanical Information                                                                                          Specifications
                                                                    Voltage options:           100-277 VAC 50/60Hz, 120-250 VDC                       Housing: Copper-free aluminium
  Fixture weight:              6.8 kg (15 lbs)
                                                                                                                                                                    Superior dual coat finish
  Shipping weight:             7.7 kg (17 lbs)                      Operating temp:            -40°C to +65°C                                         Finish:       - Sealed polyester topcoat
                                                                                                                                                                    - Chemical-resistant epoxy prime
                               34mm slip-fit stanchion              Power factor:              >0.9                                                   Lens:         Polycarbonate
  Mounting:
                               mount
                                                                    THD:                       300,000
  High Pressure Sodium             1                                   24,000
  Metal Halide                     1                                   15,000

                                             Dimensions                                                                                        Beam Distribution

                                                                          Dimension in mm [inches]                                                       Wide

                                                                                        Mounting Options

                                                                       34 mm Slip-Fit Stanchion Mount Junction Box

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.
30                                                                                                                                                                       www.dialight.com
Industrial Application| Area Light

Vigilant® LED Conveyor Light
Ordering Information

                                                            Beam
      Part Number                Lens Material                                 CCT          CRI            Lumens               Wattage                 lm/W              Mounting Options
                                                         Distribution

 ALE5WC27DYNUGN                   Polycarbonate               Wide            5000K          80              6,700                   64                  106              34mm slip-fit adapter

All values typical unless otherwise stated (tolerance +/- 10%).
Neutral white option available, please consult local Dialight sales office for availability.

                                                                                         Spacing Table

                      6,700 fixture light levels               6,700 fixture light levels                6,700 fixture light levels
                      Mounting height - 3m                     Mounting height - 3m                      Mounting height - 3m
                      Spacing - 8m                             Spacing - 12m                             Spacing - 15m
                      Average illuminance - 112 lux            Average illuminance - 78 lux              Average illuminance - 65 lux
                      Light loss factor - 0.85                 Light loss factor - 0.85                  Light loss factor - 0.85

                       Mounting Options                                                                                Conveyor Light Spacing

    Dialight Luminaire
    Conveyor Light Wall
    Mount with Pole
    Adapter

               3m
            Installed
             Height

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.
www.dialight.com                                                                                                                                                                                    31
Industrial Application| Floodlight

DuroSite® LED Floodlight
Technical Specifications

                                                                                                                                            Ratings and Certifications
                                                                                                                      • 10 year warranty
                                                                                                                      • L70 >150,000 hours @ 25°C ambient
                                                                                                                      • CE
                                                                                                                      • IP66/67
                                                                                                                      • IK07 (glass lens), IK10 (polycarbonate lens)
                                                                                                                    *All features not available on every model. Please refer to product part
                                                                                                                    number pages for model specifics.

                     Mechanical Information                                                                                       Specifications
  Fixture weight:
                                                                                  Voltage options: 100-277 VAC, 50/60Hz                       Housing: Die cast aluminium
  13,500 - 15,000 lm:              13.6 kg (30 lbs)
  10,750 - 11,500 lm:              12.2 kg (27 lbs)                                                                                                          Superior dual coat finish
                                                                                  Operating temp: -40°C to +65°C                              Finish:        - Sealed polyester topcoat
  Shipping weight:
                                                                                                                                                             - Chemical-resistant epoxy prime
  13,500 - 15,000 lm:              15.4 kg (30 lbs)
                                                                                                                                                             Tempered glass
  10,750 - 11,500 lm:              14.1 kg (31 lbs)                               Power factor:            >0.9                               Lens:
                                                                                                                                                              Polycarbonate
  EPA (sq.m)                        0.05 sq. m (0.55 sq. ft)
                                                                                  THD:                     150,000
                                                                                                  Metal Halide                                 1                               15,000
                                                                Dimension in mm [inches]          High Pressure Sodium                         1                               20,000

                                                                                        Beam Distribution

                 Field Angle = 140° x 115°                                          Field Angle = 115° x 140°                                               Field Angle = 115°

                       Field Angle = 93°                                                  Field Angle = 52°                                                  Field Angle = 23°

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

32                                                                                                                                                                       www.dialight.com
Industrial Application| Floodlight

DuroSite® LED Floodlight
Ordering Information & Mounting Accessories

                                                                                                      Colour Temperature                                              Beam                Field
  Part Number              Lumens            Wattage           lm/W              Voltage                                                        Lens
                                                                                                             (CCT)                                                    Angle               Angle

   FLE466MC4NG               15,000             135              111          100-277 VAC                 5000K (cool white)              Tempered glass                 45°               115°

   FLE476MC4NG               14,750             135              109          100-277 VAC                 5000K (cool white)              Tempered glass             105° x 70°        140° x 115°

   FLE467MC4NG               14,750             135              109          100-277 VAC                 5000K (cool white)              Tempered glass             70° x 105°        115° x 140°

   FLE455MC4NG               14,500             140              104          100-277 VAC                 5000K (cool white)              Tempered glass                 27°                93°

   FLE444MC4NG               14,500             140              104          100-277 VAC                 5000K (cool white)              Tempered glass                 26°                52°

   FLE422MC4NG               13,500             140               96          100-277 VAC                 5000K (cool white)              Tempered glass                 12°                23°

   FLE276MC2NG               11,500             106              108          100-277 VAC                 5000K (cool white)              Tempered glass             105° x 70°        140° x 115°

   FLE266MC2NG               11,250             106              106          100-277 VAC                 5000K (cool white)              Tempered glass                 45°               115°

   FLE255MC2NG               11,000             106              104          100-277 VAC                 5000K (cool white)              Tempered glass                 27°                93°

   FLE244MC2NG               10,500             106               99          100-277 VAC                 5000K (cool white)              Tempered glass                 26°                52°

   FLE222MC2NG               10,750             106              101          100-277 VAC                 5000K (cool white)              Tempered glass                 12°                23°

All values typical unless otherwise stated (tolerance +/- 10%).
Polycarbonate lens available, please consult local Dialight sales office for availability.

                              HZXSAFECBLS
                              • Stainless steel safety cable kit

                                                                Factory-Installed Mounting Bracket Dimensions

                                                                                                                                                                          Dimension in mm [inches]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.
www.dialight.com                                                                                                                                                                                    33
Industrial Application| Linear

DuroSite® LED Linear - Low Profile
Technical Specifications

                                                                                                                                           Ratings and Certifications
                                                                                                                     • 5 year warranty
                                                                                                                     • L70 >100,000 hours @ 25°C ambient
                                                                                                                     • CE
                                                                                                                     • IP66/67
                                                                                                                     • IK07
                                                                                                                    *All features not available on every model. Please refer to product part
                                                                                                                    number pages for model specifics.

             Mechanical Information                                                                                       Specifications
   Fixture weight:                                                 Voltage options:           100-277 VAC                                     Housing: Copper-free aluminium
   1.2 m:                     5.9 kg (13 lbs)
                                                                                                                                                             Superior dual coat finish
   0.6 m:                     4.5 kg (10 lbs)
                                                                   Operating temp:            -40°C to +65°C                                  Finish:        - Sealed polyester topcoat
   Shipping weight:                                                                                                                                          - Chemical-resistant epoxy prime
   1.2m:                      8.2 kg (18 lbs)
   0.6m:                      6.8 kg (15 lbs)                      Power factor:              >0.9                                            Lens:          Diffused Polycarbonate

                              Factory-installed 316                THD:                       100,000
  Fluorescent                            1                          24,000                             3,300                    33                   100                           3m

                                                    Dimensions                                                                                         Beam Distribution

                                                                                            Dimension in mm [inches]                                       Medium Pattern

                                                                                       Mounting Options

                              Side Mount - LPXW4 (included)                                                                        Top Mount - LPXW4 (included)

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

34                                                                                                                                                                      www.dialight.com
Industrial Application| Linear

DuroSite® LED Linear - Low Profile
Ordering Information & Mounting Accessories

                                                                                                                     Colour
   Part Number                Lumens           Wattage        lm/W         Length            Voltage                                                   Lens                  Beam Distribution
                                                                                                                   Temperature

      LPE3C4B2W                 3,300              33           100         0.6m          100-277 VAC            5000K (cool white)           Diffused polycarbonate                 Medium

      LPE3C4H2W                 6,700              66           102         1.2m          100-277 VAC            5000K (cool white)           Diffused polycarbonate                 Medium

All values typical unless otherwise stated (tolerance +/- 10%).

                               LPXW4LP                                                                                               LPXW4 (included)
                               • 316 Stainless steel low profile                                                                     • 316 Stainless steel mounting
                                 mounting bracket, can be angled                                                                       bracket, can be angled at 0°, 30°,
                                 at 0° and 15°                                                                                         45°, 60°, & 90°

                               LTXENDCAPKIT                                                                                          LTXSAFEKIT
                               • 304 Stainless steel chain mount                                                                     • Stainless steel safety cable kit for
                                 and secondary retention bracket                                                                       secondary retention

                                                                       LPXW4 Mounting Bracket Dimensions

                                                                                                                                                                      Dimension are in mm [inches]

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    35
Industrial Application| Linear

DuroSite® LED Stainless Steel Linear
Technical Specifications

                                                                                                                                            Ratings and Certifications
                                                                                                                      • 5 year warranty
                                                                                                                      • L70 >150,000 hours @ 25°C ambient
                                                                                                                      • CE
                                                                                                                      • IP66/67
                                                                                                                      • IK09
                                                                                                                    *All features not available on every model. Please refer to product part
                                                                                                                    number pages for model specifics. Emergency options available, please
                                                                                                                    consult your local Dialight sales office.

             Mechanical Information
                   Standard:
                   1308mm - 11.3 kg (25 lbs)                                                                                    Specifications
                   708mm - 6.8 kg (15 lbs)
  Fixture weight:                                                            Voltage            Standard: 100-277 VAC                   Housing:          316 Marine grade stainless steel
                   Emergency:
                   1450mm - 14.1 kg (31 lbs)                                 options:                                                                     High impact resistant diffused
                   850mm - 9.1 kg (20 lbs)                                                      Emergency: 230, 240 VAC                 Lens:
                                                                                                                                                          polycarbonate
                   Standard:
                   1308mm - 14.1 kg (31 lbs)                                                    Standard: -20°C to +60°C                CRI:              70
                                                                             Operating
                   708mm - 9.1 kg (20 lbs)                                   temp:                                                                  5000K (cool white)
  Shipping weight:                                                                              Emergency: -20°C to +60°C               CCT:
                   Emergency:                                                                                                                       4000K (neutral white)
                   1450mm - 17.2 kg (38 lbs)                                 Power                                                      Surge
                   850mm - 11.3 kg (25 lbs)                                                                                                         EN 61000-4-5
                                                                                                >0.9
                                                                             factor:                                                    protection: 1kV line-to-line, 2kV line-to-ground
  Mounting:                 (2) M8 fixing points
                                                                                                                             Emergency Models
                            M25 x 2 cable entries at both
  Entry:                    ends, through wired as standard.                 Battery:            3.6V 10Ah NiMH                         Duration:         @ 25°C ambient - est. >3 hours
                            M20 options - consult sales
                                                                             Expected
  Terminals:                4mm2 x 7                                                             4 years
                                                                             battery life:

                                  Comparison                                                        Lumens                 Wattage                lm/W                  Mounting Heights
                                     Warranty                      L70                                5,100                    67                   80                            6m
  Dialight LED Linear                   5yr                    >150,000
  Fluorescent                            1                       24,000                               2,600                    34                   86                            3m

                              Standard Model Dimensions                                                                         Emergency Model Dimensions

                                                                                                                                                                                     Dimension in mm

                                                                                        Beam Distribution

                                                                                                Medium
When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

36                                                                                                                                                                       www.dialight.com
Industrial Application| Linear

DuroSite® LED Stainless Steel Linear
Ordering Information & Mounting Accessories

                                                                                                                        Colour                                                       Beam
       Part Number                  Lumens          Wattage           lm/W                 Voltage                                                           Lens
                                                                                                                    Temperature (CCT)                                             Distribution

                                                                             Standard Model - 100-277 VAC
       EL-1C6R-SSCB4                  5,100             67              76               100-277 VAC                   5000K (cool white)                Polycarbonate                Medium

       EL-1C6M-SSCB4                  2,600             34              76               100-277 VAC                   5000K (cool white)                Polycarbonate                Medium

                                                                             Emergency Model - 230-240 VAC
       ELE-2C7R-SSCB4                 5,100             70              73               230-240 VAC                   5000K (cool white)                Polycarbonate                Medium

      ELE-2C7M-SSCB4                  2,600             35              74               230-240 VAC                   5000K (cool white)                Polycarbonate                Medium

All values typical unless otherwise stated (tolerance +/- 10%).
M20 cable entry options available, please consult local Dialight sales office for availability.
Neutral white options available, please consult local Dialight sales office for availability.

                                                                                                  ELXPCSS42                                                           ELXWMBSS30
                              ELXCMBSS
                                                                                                  • 40 - 45mm                                                         • 30° 316 Marine Grade
                              • 316 Marine Grade                                                    range 316 Marine                                                    Stainless steel wall
                                Stainless steel ceiling                                             Grade Stainless                                                     mount kit
                                mount kit                                                           steel pole clamp

                                                                                                  ELXPCSS47                                                           ELXWMBSS45
                                                                                                  • 47 - 51mm range                                                   • 45° 316 Marine Grade
                                                                                                    316 Marine Grade                                                    Stainless steel wall
                              ELXEYESS                                                              Stainless steel pole                                                mount kit
                              • 316 Marine Grade                                                    clamp
                                Stainless steel eyelet kit
                                                                                                  ELXPCSS54                                                           ELXWMBSS60
                                                                                                  • 54 - 57mm range                                                   • 60° 316 Marine
                                                                                                    316 Marine Grade                                                    Grade tainless
                                                                                                    Stainless steel pole                                                steel wall mount kit
                                                                                                    clamp

                              ELX-BATT-KIT
                              • 3.6V NiMH battery kit                                             ELXPCSS59                                                           ELXWMBSS90
                                                                                                  • 59 - 62mm                                                         • 90° 316 Marine
                                                                                                    range 316 Marine                                                    Grade Stainless
                                                                                                    Grade Stainless                                                     steel wall mount kit
                                                                                                    steel pole clamp

                                                                                      Mounting Options

         Wall Mount Bracket 30°                              Wall Mount Bracket 45°                           Wall Mount Bracket 60°                           Wall Mount Bracket 90°

                                            Pole Clamp                                     Ceiling Mount                                          Eyelet

When ordering please refer our website www.dialight.com to view the current versions of all relevant product documentation, including the most up-to-date product data sheets.
For the avoidance of doubt, in the event of any discrepancy between the contents of this document and information provided on our website, the information provided on our website shall prevail.

www.dialight.com                                                                                                                                                                                    37
You can also read
Next slide ... Cancel
