LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
LED LIGHTING

                  BRIGHT
                 STYLISH
               EFFICIENT
                    2020
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
CONTENTS
    LED LIGHTING EXPLAINED                                     4
    LED LIGHTING FIXTURES                                      6
      INDOOR
      DOWNLIGHTS                                               8
      PANEL LIGHTS                                            28
      OYSTER LIGHTS                                           32
      SPOTLIGHTS                                              34
      PENDANT LIGHTS                                          36
      UP/DOWN LIGHTS                                          40
      BATTENS                                                 42
      OUTDOOR
      DECK LIGHTS                                             46
      STEP LIGHTS                                             48
      STARLIGHTS                                              50
      UP/DOWN LIGHTS                                          52
      ADJUSTABLE LIGHTS                                       58
      BUNKER LIGHTS                                           62
      FLOODLIGHTS                                             64
      WORKLIGHTS                                              84

    DIMMERS AND LED COMPATIBILITY                            86
    DOWNLIGHT ACCESSORIES                                    88
    LIGHTING SENSORS                                         88
    INDEX OF PROTECTION                                      89
    LED LIGHTING GLOBES                                      90
    LED GARDEN LIGHTING                                     108
      BENEFITS                                               110
      SPOTLIGHTS                                             112
      POND SPOTLIGHTS                                        124
      BOLLARDS                                               128
      WALL & STEP LIGHTS                                     132
      DECK LIGHTS                                            138
      TRANSFORMERS                                           142
      CABLE & TRANSFORMER CONFIGURATION CHART                146
      CABLES                                                 148
      ACCESSORIES                                            150

2                                          LED LIGHTING CONTENTS 3
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
LED LIGHTING
EXPLAINED                                                                                                                                                                                                OUR QUALITY PROMISE

    LIGHT COLOUR                                                                                                             LIGHT PERFORMANCE
    Expressed in Degrees Kelvin (K), light colours are the key to determining the mood of a room.
                                                                                                                              LIGHT OUTPUT INCANDESCENT HALOGEN                  CFL          LED        DIMMING COMPATIBILITY
                           DEGREES        2700-3000K
                                                                                                                                                                                                           Many of our lights are capable of being
         WARM              DESCRIPTION    SOFTER, WARMER LIGHT                                                                    220 lm            25W             18W         5-7W          3W              dimmed effectively. For optimum
         WHITE                            Comparable to traditional incandescent lighting. Preferred in cooler climates.
                                                                                                                                                                                                            dimming performance and to reduce
                                                                                                                                  420 lm            40W             28W         7-8W         4-5W
                           ROOM           Bedroom, living room, bathroom, kitchen                                                                                                                        flickering, use HPM or Legrand dimmers.
                                                                                                                                  720 lm            60W             42W        11-12W        6-8W            See pages 106-107 for more details.
                           DEGREES        4000K

         COOL              DESCRIPTION    NEUTRAL LIGHT                                                                           930 lm            75W             52W        13-18W        9-13W
         WHITE                            Used for task lighting and preferred in warmer, tropical climates
                                                                                                                                 1300 lm            100W            70W        18-23W       16-20W
                           ROOM           Laundry, garage, study, bathroom, kitchen

                                                                                                                                                                                                             INSULATION RATING
    AVERAGE LAMP LIFE                                                                                                        LUMINOUS EFFICACY (lm/W)                                                       All recessed luminaires included in
                                                                                                                             Picking a lamp fixture based only on wattage or physical size could          this brochure have an insulation rating
                                                          COMPACT FLUORESCENT                                 INCANDESCENT   result in the wrong choice: Wattage (measured in W) represents the               of IC, IC-F, IC-4, CA80 and CA90.
              LED 30,000 HOURS                                                                                               power consumed by the luminaire. The actual output of a lamp is
                                                          10,000 HOURS                                        1,000 HOURS                                                                                         This means insulation may
                                                                                                                             measured in lumens (lm): the more lumens, the more light emitted by
                                                                                                                                                                                                             abut or cover the LED luminaire.
                                                                                                                             the luminaire. A smart criteria for determining the efficiency of a light
    DURABILITY: LEDs are very long-lasting compared to other lighting technologies, with an average 30,000 hours life
                                                                                                                             fixture is its lumens/Watt ratio, which represents how much light the
    expectancy. We use quality components which make our lamps even more durable, being laboratory tested and assessed
                                                                                                                             fixture delivers versus what it consumes to perform. This value is called
    at 30,000 hours life expectancy. That represents approximately 20 years based on 3 to 4 hours usage per day.
                                                                                                                             luminous efficacy, and proves LED lights are more efficient than other
                                                                                                                             light technologies.

    DIMMING COMPATIBILITY
    Critical to a successful installation is an understanding of LED compatibility with dimmers.                             COLOUR RENDERING INDEX (CRI)
    HPM is one of the only major brands on the market to deliver a full solution from dimmers to drivers and LED fixtures.   CRI measures how well a lamp makes colours appear. CRI scores light              NATA ACCREDITED
    Choose the winning combination of HPM LED fixtures and HPM or Legrand dimmers to ensure superior performance –           sources from 1 – 100: a high CRI means that the eye can pick up slight             LABORATORY
    including smooth dimming with no flickering, reliability and long life.                                                  variations in colour, making details in an interior appear sharper and       To ensure the highest possible quality
                                                                                                                             more vibrant. For outstanding colour rendering, opt for our Dalia series
                                                                                                                                                                                                          assurance standards all HPM lighting
                                                                                                                             which boasts a very high 92 index.
                                                                                                                                                                                                           fixtures and lamps are tested in our
                                                                                                                             Our downlights range from 80 to 92, to enhance skin tones, hues and          NATA accredited laboratory in Sydney.
                                                                                                                             textures in rooms.

                                                                            SUPERIOR                                         BEAM ANGLE
                                                                            DIMMING                                          The light effect from a luminaire is determined by its beam angle,
                                                                                                                             that is the shape and direction of light generated by the lamp. Most
                                                                                                                             conventional fixtures deliver a focused light distribution at 35-60°                    IP RATING
                                                                                                                             beam angle, but LED technology can go well above those values,                All our products are assured against
                                                                                                                             while still maintaining a fair pool of light.                                 insects and moisture, with IP ratings
               HPM LED                             HPM & Legrand                                                             Our lights deliver beam angles ranging from 80 to 120° to ensure a           ranging from IP42 to IP65. See IP chart
               fixtures                            dimmers p.106-107                                                         beautiful light is spread throughout a room.                                    on page 109 for more information.

4                                                                                                                                                                                                                           LED LIGHTING FIXTURES 5
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
LED LIGHTING
    FIXTURES

6              LED LIGHTING FIXTURES 7
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
DLI      TRI-COLOUR LED DOWNLIGHT (7W - 10W)
                                                                                                                                UP TO       Power                                        7W            7W            10W
                                                                                                                               1100
                                                                                                                               LUMENS
                                                                                                                                            Lumen output                             90mm              110mm         150mm
                                                                                                                                                                       Warm White    750 lm            690 lm        1000 lm
                                                                                                                                                                       Cool White    840 lm            740 lm        1100 lm
    The functional design and classic finish of the DLI adds a touch of                                                                                                Natural White 840 lm            690 lm        1000 lm
    contemporary lighting. The DLI is ideal for all rooms in the house. At only
                                                                                                                                            Efficacy                                 90mm              110mm         150mm
    7W to 10W the DLI with colour changing switch delivers one product with                                                                                            Warm White    107 lm/W          98 lm/W       100 lm/W
    three light colours - Warm White, Cool White and Natural White.                                                                                                    Cool White    120 lm/W          104 lm/W      110 lm/W
                                                                                                                                                                       Natural White 120 lm/W          98 lm/W       100 lm/W

                                                                                                                                            Colour temperature         Warm White                                      3,000K
                                                                                                                                                                       Cool White                                      4,000K
                                                                                                                               IP44
                                                                                                                             WEATHERPROOF
                                                                                                                                                                       Natural White                                   5,000K

                                                                                                                                            CRI                        80+

                                                                 TIP                                                                        Insulation rating          IC-4 and IC-F
                                                                 Light Colour Selector
                                                                                                                                            Dimming                    Trailing edge dimmers

                                                                                                                              3 YEAR        Lifespan                   35,000 h
                                                                                                                              WARRANTY

                                                                                                                                            Package contents           7W or 10W dimmable downlight with integrated
                                                                                                                                                                       driver. Supplied with flex and plug

                                                                                                                                            Product codes              Ø90mm cut-out
                                                                                                                                                                       White Fascia, Warm White, Cool White
                                                                                                                                                                       and Natural White Light            DLI90TRIWE
                                                                                                                                                                       Ø90mm cut-out
                                                                                                         TIP                                                           Brushed Chrome Fascia, Warm White,
                                                                                                                                                                       Cool White and Natural White Light DLI90TRIBC
                                                                                                         Recessed diffuser
                                                                                                         reduces glare                                                 Ø90mm cut-out
                                                                                                                                                                       Black Fascia, Warm White, Cool White
                                                                                                                                                                       and Natural White Light            DLI90TRIBL
                                                                                                                                                                       Ø110mm cut-out
                                                                                                                                                                       White Fascia, Warm White, Cool White
                                                                                                                                                                       and Natural White Light          DLI110TRIWE
                                                                                                                                                                       Ø150mm cut-out
                                                                                                                                                                       White Fascia, Warm White, Cool White
                                                                                                                                                                       and Natural White Light          DLI150TRIWE

                                                                                                                                             DLI90 SERIES               DLI110 SERIES                  DLI150 SERIES

                                                                                                                                                BEAM                           BEAM                        BEAM
                                                                                                                                              ANGLE 90º                      ANGLE 95º                   ANGLE 95º

                                                                                                                                                                72mm                          72mm                         80mm

                                                                                                                                                   110mm                        138mm                        175mm

                                                                                                                                                                                                             M 50
                                                                                                                                                                               M 10
                         DLI90 SERIES                          DLI110 SERIES             DLI150 SERIES

                                                                                                                                                   M 0
                                                                                                                                                  9
                                                                                                                                                    M

                                                                                                                                                                                M

                                                                                                                                                                                                              M
                                                                                                                                                                              1

                                                                                                                                                                                                            1
                                                                                                                                                  CUT-OUT                    CUT-OUT                        CUT-OUT

8                                                                                                                                                                                                    LED LIGHTING FIXTURES 9
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
DLI      TILT DOWNLIGHT 7W

     A classic and contemporary downlight, but with an adjustable head. The
     DLI TILT Downlight is dimmable, available in a warm and cool white,                                              Power                 7W                                          UP TO

     and is perfect for enhancing walls or feature items in the home by                                                                                                                760
                                                                                                                                                                                       LUMENS
                                                                                                                      Lumen output                                          90mm
     simply tilting the downlight towards the desired object.                                                                               Warm White                      720 lm
                                                                                                                                            Cool White                      760 lm

                                                                                                                      Efficacy                                              90mm
                                                                                                                                            Warm White                    102 lm/W
                                                                                                                                            Cool White                    108 lm/W

                                                                                                                      Colour temperature    Warm White                      3,000K
                                                                                                                                            Cool White                      4,000K

                                                                                                                      CRI                   80+

                                                                                                                      Insulation rating     IC

                                                   Main applications
                                                                                                                      Dimming               Trailing edge dimmers                      IP44
                                                                                                                                                                                     WEATHERPROOF
                                                   Living areas, bedrooms, bathrooms,                                 Lifespan              35,000 h
                                                   & undercover outdoor areas
                                                                                                                      Package contents      7W dimmable downlight with
                                                                                                                                            integrated driver. Supplied with flex
                                                                                                                                            and plug

                                                                                                                      Product codes         Ø90mm cut-out
                                                                                                                                            White Fascia
                                                                                                                                                                                      3 YEAR
                                                                                                                                            Warm White Light      DLI903KTILTWE       WARRANTY

                                                                                                                                            Cool White Light      DLI904KTILTWE

                                                                                                                      DLI90 SERIES

                                                                                                                                                               80mm

                                                                                                                         BEAM
                                                                                                                       ANGLE 85º
                                                                                                                                                  110mm

                                                                                        TIP
                                                                                        Adjustable head - 30° angle
                                                                                        Ideal for sloped ceilings

                                                                                                                            M 0
                                                                                                                            9
                                                                                                                             M
                                                                                                                                             ADJUSTABLE
                                                                                                                        CUT-OUT            HEAD ANGLE 30º

                                  DLI90 SERIES

10                                                                                                                                                                                                  LED LIGHTING FIXTURES 11
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
DLI       DOWNLIGHT SERIES (5W TO 7W)
                                                                                                                                                     UP TO               Power                                5W           7W         7W
                                                                                                                                                    820
                                                                                                                                                    LUMENS               Lumen output                         70mm         90mm       125mm
                                                                                                                                                                                              Warm White      505 lm       700 lm     750 lm
                                                                                                                                                                                              Cool White      515 lm       820 lm     820 lm
     The functional design and classic finish of the DLI adds a touch of
                                                                                                                                                                         Efficacy                             70mm         90mm       125mm
     contemporary lighting. The DLI is ideal for all rooms in the house.                                                                                                                      Warm White      101 lm/W     100 lm/W   107 lm/W
                                                                                                                                                                                              Cool White      103 lm/W     117 lm/W   125 lm/W
     At only 5W to 7W the DLI delivers maximum brightness with limited
                                                                                                                                                                         Colour temperature   Warm White                                   3,000K
     power consumption.                                                                                                                                                                       Cool White                                   4,000K

                                                                                                                                                                         CRI                  80+

                                                                                                                                                                         Insulation rating    IC-4 and IC-F

                                                                                                                                                    IP44
                                                                                                                                                  WEATHERPROOF
                                                                                                                                                                         Dimming              Trailing edge dimmers

                                                                                                                                                                         Lifespan             35,000 h

                                                                                                                                                                         Package contents     5W to 7W dimmable downlight with integrated
                                                                                                                                                                                              driver. Supplied with flex and plug

                                                                                                                                                                         Product codes        Ø70mm cut-out
                                                                                                                                                   3 YEAR                                     White Fascia
                                                                                                                                                   WARRANTY                                   Warm White Light                          DLI7001
                                                                        Main applications
                                                                                                                                                                                              Cool White Light                          DLI7002
                                                                        Living areas, bedrooms, bathrooms,
                                                                                                                                                                                              Black Fascia
                                                                        & undercover outdoor areas
                                                                                                                                                                                              Warm White Light                        DLI7003BL
                                                                                                                                                                                              Cool White Light                        DLI7004BL
                                                                                                                                                                                              Ø90mm cut-out
                                                                                                                                                                                              White Fascia
                                                                                                                                                                                              Warm White Light                          DLI9001
                                                                                                                                                                                              Cool White Light                          DLI9002
                                                                                                                                                                                              Brushed Chrome Fascia
                                                                                                                                                                                              Warm White Light                          DLI9003
                                                                         TIP                                                                                                                  Cool White Light                          DLI9004
                                                                        Sleek, shiny black finish adds
                                                                                                                                                                                              Black Fascia
                                                                        sophistication
                                                                                                                                                                                              Warm White Light                        DLI9003BL
                                                                                                                                                                                              Cool White Light                        DLI9004BL
                                                                                                                                                                                              Ø125mm cut-out
                                                                                                                                                                                              White Fascia
                                                                                                                                                                                              Warm White Light                         DLI12501
                                                                                                                                                                                              Cool White Light                         DLI12502
                                                                                                                                                                                              Brushed Chrome Fascia
                                                                                                             DLI125 SERIES                                                                    Warm White Light                         DLI12503
                                                                                                                                                                                              Cool White Light                         DLI12504

                                                                                                             DLI70 SERIES          DLI90 SERIES          DLI125 SERIES

                                                                                                                BEAM                  BEAM                     BEAM
                                                                                                              ANGLE 90º             ANGLE 85º                ANGLE 90º

                                                                                                                            66mm                  70mm                         76mm

                                                                                                                 94mm                  111mm                     150mm

          DLI70 SERIES                                   DLI90 SERIES

                                                                                                                                                               M 25
                                                                                                                M 0

                                                                                                                                      M 0
                                                                                                               7

                                                                                                                                     9
                                                                                                                 M

                                                                                                                                       M

                                                                                                                                                                M
                                                                                                                                                              1
                                                                                                              CUT-OUT               CUT-OUT                  CUT-OUT

12                                                                                                                                                                                                                       LED LIGHTING FIXTURES 13
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
DLI       DOWNLIGHT NON-DIMMABLE SERIES (5W TO 7W)

     The functional design and classic finish of the DLI adds a touch of
     contemporary lighting. The DLI is ideal for all rooms in the house                                            UP TO       Power                                               5W          7W
     where basic lighting function is needed. At only 5W to 7W the DLI                                            815
                                                                                                                  LUMENS
                                                                                                                               Lumen output                                        70mm        90mm
     delivers maximum brightness with limited power consumption.                                                                                          Warm White               480 lm      740 lm
                                                                                                                                                          Cool White               505 lm      815 lm

                                                                                                                               Efficacy                                            70mm        90mm
                                                                                                                                                          Warm White               96 lm/W     105 lm/W
                                                                                                                                                          Cool White               101 lm/W    116 lm/W

                                                                                                                               Colour temperature         Warm White                             3,000K
                                                                                                                                                          Cool White                             4,000K

                                                                                                                               CRI                        80+

                                                                                                                               Insulation rating          IC-4 and IC-F

                                                                           Main applications                    NON-DIMMABLE   Dimming                    No
                                                                           Living areas, bedrooms, bathrooms,                  Lifespan                   30,000 h
                                                                           & undercover outdoor areas
                                                                                                                  IP44
                                                                                                                WEATHERPROOF
                                                                                                                               Package contents           5W to 7W non-dimmable downlight. Flex and plug
                                                                                                                                                          not supplied.

                                                                                                                 3 YEAR        Product codes              Ø70mm cut-out
                                                                                                                 WARRANTY
                                                                                                                                                          Brushed Chrome Fascia
                                                                                                                                                          Cool White Light                      DLI7008
                                                                           TIP                                                                            Ø90mm cut-out
                                                                           Recessed diffuser reduces glare
                                                                                                                                                          White Fascia
                                                                                                                                                          Warm White Light                      DLI9005
                                                                                                                                                          Cool White Light                      DLI9006

                                                                                                                               DLI70 SERIES                     DLI90 SERIES

                                                                                                                                  BEAM                            BEAM
                                                                                                                                ANGLE 90º                       ANGLE 90º

                                                                                                                                                                               70mm
                                                                                                                                                   66mm

                                                                                                                                                                     111mm
                                                                                                                                     94mm

                                                                                                                                                                     M 0
                                                                                                                                     M 0
                                                                                                                                     7

                                                                                                                                                                  9
                                                                                                                                      M

                                                                                                                                                                      M
                                                                                                                                 CUT-OUT                         CUT-OUT

          DLI70 SERIES                                     DLI90 SERIES

14                                                                                                                                                                              LED LIGHTING FIXTURES 15
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
AZA+         DOWNLIGHT SERIES (8W)

     The AZA+ sits flush with the ceiling blending seamlessly with
     any décor and provides bright and energy saving illumination.                               Power                8W                                         UP TO

                                                                                                                                                                820
                                                                                                                                                                LUMENS
                                                                                                 Lumen output         Warm White                    750 lm
                                                                                                                      Cool White                    820 lm

                                                                                                 Efficacy             Warm White                  93 lm/W
                                                                                                                      Cool White                 102 lm/W

                                                                                                 Colour temperature   Warm White                    3,000K
                                                                                                                      Cool White                    4,000K

                                                                                                 CRI                  80+

                                                                                                 Insulation rating    IC-4 and IC-F

                                                                                                 Dimming              Trailing edge dimmers
                                                                                                                                                                IP44
                                                                                                                                                              WEATHERPROOF
                                                                                                 Lifespan             35,000 h
                                                            Main applications
                                                                                                 Package contents     8W dimmable downlight with               3 YEAR
                                                            Living areas, bedrooms, bathrooms,
                                                                                                                      integrated driver. Supplied with flex    WARRANTY
                                                            & undercover outdoor areas
                                                                                                                      and plug

                                                                                                 Product codes        White Fascia
                                                                                                                      Warm White Light       LDL043KWE
                                                                                                                      White Fascia
                                                                                                                      Cool White Light       LDL044KWE
                                                                                                                      Polished Silver Fascia
                                                                                                                      Warm White Light       LDL043KPS

                                                                                                                                              M 0
                                                                                                                                            9
                                                                                                                                               M
                                                                                                                                 65mm
                                                                                                   BEAM
                                                                                                 ANGLE 95º
                                                                                                                      110mm
                                                                                                                                           CUT-OUT

                     TIP
                    At only 65mm depth, AZA+
                    downlights will fit in most
                    ceiling cavities

16                                                                                                                                                                           LED LIGHTING FIXTURES 17
LED LIGHTING - 2020 BRIGHT STYLISH EFFICIENT - HPM
FLUSH FACE                     TRI COLOUR DOWNLIGHT SERIES

     This downlight, sits flush with the ceiling blending seamlessly with
     any decor and provides bright and energy saving illumination. At only                        Power                7W                                         UP TO

     7W this downlight features a colour changing switch, one product with
                                                                                                                                                                 850
                                                                                                                                                                 LUMENS
                                                                                                  Lumen output         Warm White                    750 lm
     three light colours - Warm White, Cool White and Natural White.                                                   Cool White                    850 lm
                                                                                                                       Natural White                 850 lm

                                                                                                  Efficacy             Warm White                 105 lm/W
                                                                                                                       Cool White                 120 lm/W
                                                                                                                       Natural White              120 lm/W

                                                                                                  Colour temperature   Warm White                    3,000K
                                                                                                                       Cool White                    4,000K
                                                                                                                       Natural White                 5,000K

                                                                                                  CRI                  80+
                                                                                                                                                                 IP44
                                                                                                                                                               WEATHERPROOF
                                                                                                  Insulation rating    IC-4 and IC-F

                                                             Main applications                    Dimming              Trailing edge dimmers
                                                             Living areas, bedrooms, bathrooms,
                                                             & undercover outdoor areas           Lifespan             35,000 h

                                                                                                  Package contents     7W dimmable downlight with
                                                                                                                       integrated driver. Supplied with flex    3 YEAR
                                                                                                                                                                WARRANTY
                                                                                                                       and plug.

                                                                                                  Product codes        White Fascia
                                                                                                                       Warm Light
                                                                                                                       Cool Light
                                                                                                                       Natural Light         LDL90TRIWE
                                                                                                                       Polished Silver Fascia
                                                                                                                       Warm Light
                                                                                                                       Cool Light
                                                                                                                       Natural Light          LDL90TRIPS

                                               90mm
                                               CUT-OUT

                                                                                                                                               M 0
                                                                                                                                             9
                                                                                                                                                M
                                                                                                                                  65mm
                                                                                                    BEAM
                                                                                                  ANGLE 95º
                                                                                                                       110mm
                                                                                                                                            CUT-OUT

18                                                                                                                                                                            LED LIGHTING FIXTURES 19
DALIA           DOWNLIGHT SERIES (15W)

     Equipped with a Citizen LED chip, these superior downlights are our
     brightest and deliver exceptional colour rendering, making details in                      Power                15W                                       UP TO

     an interior space appear sharper and more vibrant. Dalia is a fusion of
                                                                                                                                                              980
                                                                                                                                                              LUMENS
                                                                                                Lumen output         Warm White                    950 lm
     craftsmanship, highest-calibre materials and advanced technology.                                               Cool White                    980 lm

                                                                                                Efficacy             Warm White                 63 lm/W
                                                                                                                     Cool White                 65 lm/W

                                                                                                Colour temperature   Warm White                    3,000K
                                                                                                                     Cool White                    4,000K

                                                                                                CRI                  80+

                                                                                                Insulation rating    IC-4                                     IP44
                                                                                                                                                            WEATHERPROOF

                                                                                                Dimming              Trailing & leading edge, 2 & 3 wire

                                                                                                Lifespan             30,000 h
                                                                                                                                                             6 YEAR
                                                           Main applications                                                                                 WARRANTY

                                                           Living areas, bedrooms, bathrooms,   Construction         Corrosion resistant anodised
                                                           & undercover outdoor areas                                aluminium

                                                                                                Package contents     Dimmable SELV external LED
                                                                                                                     driver and 15W LED sealed fixture.
                                                                                                                     Supplied with flex and plug

                                                                                                Product codes        White Fascia
                                                                                                                     Cool White Light      LDL024KWE
                                                                                                                     Aluminium Fascia
                                                                                                                     Warm White Light       LDL023KPS
                                                                                                                     Aluminium Fascia
                                                                                                                     Cool White Light       LDL024KPS

                                                                                                                                             M 0
                      TIP

                                                                                                                                            M -9
                                                                                                                                         85
                                                                                                                                100mm
                      With an outstanding 92+ CRI, Dalia                                          BEAM
                                                                                                ANGLE 80º
                      downlights illuminate objects and                                                                                  CUT-OUT
                                                                                                                     108mm
                      surfaces in their true colours

20                                                                                                                                                                         LED LIGHTING FIXTURES 21
AZALEA               DOWNLIGHT SERIES (11W)

     A marriage of style and function, our Azalea effortlessly achieves optimum
     lighting performance with impressive economy. With a 48mm depth, it is          UP TO       Power                11W
                                                                                    890
     brilliant for tight ceiling cavities and multi-floor dwellings.                LUMENS
                                                                                                 Lumen output         Warm White                  880 lm
                                                                                                                      Cool White                  890 lm

                                                                                                 Efficacy             Warm White                98 lm/W
                                                                                                                      Cool White                99 lm/W

                                                                                                 Colour temperature   Warm White                  3,000K
                                                                                                                      Cool White                  4,000K

                                                                                                 CRI                  80+

                                                                                                 Insulation rating    IC-4 and IC-F

                                                                                                 Dimming              Trailing & leading edge, 2 & 3 wire

                     Main applications
                                                                                    IP44
                                                                                  WEATHERPROOF
                                                                                                 Lifespan             30,000 h
                     Living areas, bedrooms, bathrooms,
                                                                                                 Construction         Aluminium
                     & undercover outdoor areas
                                                                                   6 YEAR        Package contents     Dimmable SELV external LED
                                                                                   WARRANTY
                                                                                                                      driver and 11W LED sealed fixture.
                                                                                                                      Supplied with flex and plug

                                                                                                 Product codes        White Fascia
                                                                                                                      Warm White Light      LDL013KWE
                                                                                                                      White Fascia
                                                                                                                      Cool White Light      LDL014KWE
                                                                                                                      Aluminium Fascia
                                                                                                                      Cool White Light      LDL014KPS

                                                                                                                                              M 0
                                                                                                                                             M -9
                                                                                                                                  48mm

                                                                                                                                           85
                                                                                                   BEAM
                                                                                                 ANGLE 95º            105mm
                                                                                                                                           CUT-OUT

22                                                                                                                               LED LIGHTING FIXTURES 23
DLS        DOWNLIGHT SERIES (11W)

     Behind the stylish façade, the DLS features a frosted recessed diffuser
     to reduce glare and ensure a perfect light spread across any room.                         Power                11W                                     UP TO

                                                                                                                                                            950
                                                                                                                                                            LUMENS
                                                                                                Lumen output         Warm White                  950 lm
                                                                                                                     Cool White                  950 lm

                                                                                                Efficacy             Warm White                85 lm/W
                                                                                                                     Cool White                85 lm/W

                                                                                                Colour temperature   Warm White                  3,000K
                                                                                                                     Cool White                  4,000K

                                                                                                CRI                  80+

                                                                                                Insulation rating    IC-4 and IC-F

                                                                                                Dimming              Trailing edge dimmers

                                                                                                Lifespan             30,000 h                               IP44
                                                                                                                                                          WEATHERPROOF

                                                        Main applications                       Package contents     Dimmable SELV external LED
                                                        Living areas, bedrooms, bathrooms,                           driver with quick-connect plug and    6 YEAR
                                                                                                                                                           WARRANTY
                                                        & undercover outdoor areas                                   10W LED sealed fixture. Supplied
                                                                                                                     with flex and plug

                                                                                                Product codes        White Fascia
                                                                                                                     Warm White Light          DLS9001
                                                                                                                     White Fascia
                                                                                                                     Cool White Light          DLS9002

                                                                                                                        87.2mm

                                                                                                                                                 M 0
                                                                                                                                                M -9
                                                                                                                                               85
                                                                                                  BEAM                                  55mm
                                                                                                ANGLE 90º
                                                                                                                                               CUT-OUT

                                     Recessed diffuser                      for reduced glare

24                                                                                                                                                                       LED LIGHTING FIXTURES 25
MR16          RETROFIT DOWNLIGHT SERIES (7W TO 9W)

     This patented energy efficient MR16 retrofit LED downlight has been
     designed as a DIY upgrade to existing MR16 halogen downlights. Compatible                               Power                                  7W         9W             UP TO

     with all leading brands of transformers on the market, choose this simple
                                                                                                                                                                             770
                                                                                                                                                                             LUMENS
                                                                                                             Lumen output          Warm White       550 lm     710 lm
     and safe solution for great light output and energy saving.                                                                   Cool White       590 lm     770 lm

                                                                                                             Efficacy              Warm White       78 lm/W 78 lm/W
                                                                                                                                   Cool White       84 lm/W 85 lm/W

                                                                                                             Colour temperature Warm White                     3,000K
                                                                Install it yourself in     3   easy steps.                      Cool White                     4,000K

                                                                                                             Insulation rating     Ø90mm 9W IC abutted & covered
                                  Main applications             1. Remove.
                                                                                                                                   Ø70mm 7W CA80 & CA90 abutted only         IP44
                                                                                                                                                                           WEATHERPROOF
                                  DIY Replacement of existing
                                                                Unplug and remove existing
                                  halogen MR16 downlights.
                                                                MR16 halogen downlight.                      CRI                   80+

                                                                                                             Lifespan              35,000 h                                 3 YEAR
                                                                                                                                                                            WARRANTY
                                   TIP
                                                                                                             Package contents      MR16 LED downlight
                                  Compatible with all leading
                                  brands of transformers on
                                  the market
                                                                                                             Product codes         Ø70mm cut-out 7W
                                                                                                                                   White Fascia
                                                                                                                                   Warm White Light LMR16703KWE
                                                                                                                                   Cool White Light LMR16704KWE
                                                                                                                                   Ø90mm cut-out 9W
                                                                2. Replace.                                                        White Fascia
                                                                                                                                   Warm White Light LMR16903KWE
                                                                Plug-in your new HPM MR16 LED                                      Cool White Light LMR16904KWE
                                                                downlight and install back into ceiling.

                                                                                                                   DLI70 SERIES                 DLI90 SERIES

                                                                                                                      BEAM                         BEAM
                                                                                                                    ANGLE 85º                    ANGLE 95º

                                                                                                                                                                    75mm
                                                                                                                                  75mm

                                                                3. Ready.
                                                                Enjoy great light output, sleek design and              Ø3mm                       Ø110mm

                                                                up to 80% energy saving.

                                                                                                                        M 0

                                                                                                                                                    M 0
                                                                                                                      7

                                                                                                                                                   9
                                                                                                                         M

                                                                                                                                                     M
                                                                                                                     CUT-OUT                      CUT-OUT

26                                                                                                                                                                                        LED LIGHTING FIXTURES 27
NE
                                                     W
     LENKA             FRAMELESS PANEL LIGHT (12W)

     The subtle sophistication of our LENKA LED Panel Light will imbrue your
     space with a stunning ambient light, whilst sitting discretely on your ceiling.         Power                        12W
                                                                                                                                                                             1150
     With LENKA, the statement is in the light’s sleek and simple design. It’s               Lumen output                 Warm White                           1,150 lm       LUMENS

     beauty lies in the light’s simplicity, completely focusing on the illumination          Efficacy                     Warm White                           95 lm/W
     it brings to your space.
                                                                                             Colour temperature           Warm White                             3,000K

                                                                                             CRI                          80+

                                                                                             Dimming                      Yes - with trailing edge dimmer
                                                                                                                          only

                                                                                             Lifespan                     30,000 h

                                                                                             Insulation rating            IC-F and IC-4
                                                                                                                                                                              IP44
                                                                                                                                                                            WEATHERPROOF
                                                                                             Package contents             12W Frameless panel light with
                                                                                                                          quick connect lead and SELV
                                                                                                                          external LED driver. Supplied with                 3 YEAR
                                                                                                                          plug and lead                                      WARRANTY

                                                                                             Product code                 White Finish
                                                                                                                          Warm White Light          LPRD023KWE

                                                                                                                          White Finish
                                                                                                                          Warm White Light            LPSQ023KWE

                           ROUND - LPRD023KWE                                                                    LPRD023KWE
                                                                                                                                             Ø140mm
                                                                                               BEAM
                                                                                             ANGLE 120º

                                                                                                   M 20
                                                                                                    M
                                                                                               1
                                                                                                                 16mm
                                                                                               CUT-OUT           Subtle ceiling
                                                                                                                 obtrusion

                                                                                                                                              Quick connect plug and lead

                                                                                                                 LPSQ023KWE
                                                                                                                                                         130
                                                                                                                                        mm                  mm
                                                                                                                                     130

                                                              SQUARE - LPSQ023KWE

                                                         Main applications
                                                         Living areas, bedrooms, bathrooms
                                                                                                                    18mm
                                                         and undercover outdoor areas                               Subtle ceiling
                                                                                                                    obtrusion

                                                                                                                                             Quick connect plug and lead

28                                                                                                                                                                                         LED LIGHTING FIXTURES 29
LUNA            PANEL LIGHTS (18W)

     Offering the ultimate in discreet lighting, the Luna’s slim depth allows
     it to fit effortlessly into tight ceiling cavities. All the illumination of an                            Power                   18W                                      UP TO

                                                                                                                                                                              1500
     oyster light, none of the obtrusiveness.                                                                  Lumen output            Warm White                 1,440 lm     LUMENS

                                                                                                                                       Cool White                 1,500l m

                                                                                                               Efficacy                Warm White                 80 lm/W
                                                                                                                                       Cool White                 83 lm/W

                                                                                                               Colour temperature      Warm White                   3,000K
                                                                                                                                       Cool White                   4,000K

                                                                                                               CRI                     80+

                                                                                                               Insulation rating       IC

                                                                                                               Dimming                 Trailing & leading edge, 2 & 3 wire

                                                                                                               Lifespan                30,000 h                                IP44
                                                                                                                                                                             WEATHERPROOF

                                                                                                               Construction            Aluminium
                                                                                                                                                                              6 YEAR
                                                                                                                                                                              WARRANTY
                                                                                                               Package contents        Dimmable SELV external LED
                                                                                                                                       driver and 18W LED sealed fixture.
                                                                                                                                       Supplied with flex and plug

                                                                                                               Product code            White Fascia
                                                                                                                                       Warm White Light      LPA013KWE

                                                                                                                                       White Fascia
                                                                                                                                       Cool White Light      LPA014KWE

                                                                                                                                    M 25
                                                                                                                                     M
                                                                                                                                   2
                                                                                                                 BEAM
                                                                                                               ANGLE 103º
                                                                                                                                   CUT-OUT

                                                                                                                                                                      30mm

                                                                                                                                       250mm

                                                                         Main applications
                                                                         Living areas, bedrooms, bathrooms,
                                                                         and undercover outdoor areas.
                                                                         Ideal replacement for oyster lights

30                                                                                                                                                                                          LED LIGHTING FIXTURES 31
ATIS       OYSTER LIGHTS DIMMABLE & NON-DIMMABLE (17W)

     The Atis brings a touch of simple elegance to any room. Providing
     evenly distributed ambient light from the ceiling makes it the ideal                    Power              17W                                        UP TO

                                                                                                                                                         1750
     light for task, general or accent lighting.                                             Lumen output       Warm White              1,650 lm           LUMENS
                                                                                                                                                          DIMMABLE
                                                                                                                Cool White-Dimmable     1,750 lm
                                                                                                                Cool White-Non-dimmable 1,500 lm

                                                                                             Efficacy           Warm White              98 lm/W
                                                                                                                Cool White-Dimmable    104 lm/W
                                                                                                                Cool White-Non-dimmable 90 lm/W

                                                                                             Colour temperature Warm White                   3,000K
                                                                                                                                                         1500
                                                                                                                                                          LUMENS
                                                                                                                                                        NON-DIMMABLE
                                                                                                                Cool White                   4,000K

                                                                                             CRI                80+

                                                                                             Dimming            Trailing edge dimmers                   NON-DIMMABLE

                                                                                             Lifespan           30,000 h

                                                                                             Construction       Metal base with polycarbonate lens       3 YEAR
                                                                                                                                                         WARRANTY

                                                                                             Package contents   17W LED non-dimmable and
                                                                                                                dimmable oyster light, wall plugs
                                                                                                                and screws

                                                                                             Product code       Dimmable
                                                                                                                White Finish
                                                                                                                Cool White Light        LOL014KWE

                                                                                                                Non-Dimmable
                                                                                                                White Finish
                                                                                                                Cool White Light        LOL004KWE

                                                                                             LOL013KWE/LOL014KWE

                                                                                               BEAM
                                                                                             ANGLE 120º                                         110mm

                                                                                                                           Ø328mm

                                                                                             LOL004KWE

                                                                                               BEAM
                                                                                             ANGLE 118º                                         110mm

                                                                                                                           328mm

                                                        Main applications
                                                        Living areas, bedrooms, bathrooms,
                                                        and undercover outdoor areas.

32                                                                                                                                                                     LED LIGHTING FIXTURES 33
LUCITA            ADJUSTABLE SPOTLIGHT (8W)

     With an ultra modern and sleek silver finish, the Lucita spotlights not only look
     great but are functional as well. Ideal for above kitchen benchtops, workspaces                             UP TO       Power                                         8W               16W             24W
                                                                                                                425
     and even adapted for outdoor use, Lucita makes it easy to get light shining in                             LUMENS
                                                                                                                             Lumen output            Warm White            425 lm           850 lm          1275 lm
     areas you need it most.                                                                                                 Efficacy                Warm White            55 lm/W          55 lm/W         55 lm/W

                                                                                                                             Colour temperature      Warm White                                             3,000K
                                                                                                                IP54
                                                                                                              WEATHERPROOF
                                                                                                                             CRI                     80+

                                                                                                               DIE-CAST      Dimming                 Non-dimmable
                                                                                                              ALUMINIUM
                                                                                                              CONSTRUCTION
                                                                                                                             Lifespan                35,000 h

                                                                                                                             Construction            Die-cast aluminium
                                                                                         Main applications
                                                                                                               5 YEAR
                                                                                                               WARRANTY      Package contents        8W to 24W
                                                                                         Ideal for kitchen,
                                                                                         and outdoor areas                   Product codes           Silver 1 head
                                                                                                                                                     Warm White                                          LSP0113KPS
                                                                                                                                                     Silver 2 head
                                                                                                                                                     Warm White                                          LSP0123KPS
                                                                                                                                                     Silver 3 head
                                                                                                                                                     Warm White                                          LSP0133KPS

                                                                                                                                                LSP0113KPS                      LSP0123KPS
                                                                                                                               BEAM               Ø69mm                                 Ø120mm
                                                                                                                             ANGLE 25º
                                                                                                                                                           27mm                                             31mm

                                                                                                                                                                   144mm                                            147mm
                                                                                                                                                           100mm                                            100mm

                                                                                                                                                  Ø55mm                         Ø55mm

                                                                                                                                                LSP0133KPS
                                                                                                                                                                352mm

                                                                                                                                                                                                 30mm

                                                                                                                                                                                                         146mm
                                                                                                                                                                                                 100mm

                                           TIP
                                          360 tilting light head -                                                                                                              Ø55mm

                                          light in every direction

34                                                                                                                                                                                LED LIGHTING FIXTURES 35
PENDI             PENDANT SERIES (8W)

     Add an eye catching factor to your kitchen bench
     tops, bar counters or above your dining table with        Power                8W
                                                                                                                         320
     our contemporary Pendi LED pendant light. The             Lumen output         Warm White                320 lm
                                                                                                                         LUMENS

     warm white light radiated from the pendant creates        Efficacy             Warm White               40 lm/W
     ambience and a mood that is ideal for any living space.                                                            DIE-CAST
                                                               Colour temperature   Warm White                3,000K   ALUMINIUM
                                                                                                                       CONSTRUCTION

                                                               CRI                  80+

                                                               Dimming              Non-dimmable                        3 YEAR
                                                                                                                        WARRANTY

                                                               Lifespan             30,000 h

                                                               Product codes        Silver           LPD033KPS

                                                                 BEAM
                                                               ANGLE 90º                              Lead
                                                                                                      1.5m

                                                                                                      150mm

                                                                                             150mm

                  Main applications
                  Ideal for kitchen benchtops & bar counters

36                                                                                                                                    LED LIGHTING FIXTURES 37
CYLLA            PENDANT SERIES (7W)                                                                                CERSI          PENDANT SERIES (8W)

     Our Cylla pendant light has a                                                                                       Contemporay design, die-cast
     contemporary design, die-cast                         Power                  7W                                     aluminium construction with                           Power                     8W
                                              560                                                                                                               560
     aluminium construction with a            LUMENS
                                                           Lumen output           Warm White                    560 lm   a high quality finish. Perfect         LUMENS
                                                                                                                                                                               Lumen output              Warm White                   570 lm
     high quality finish. Perfect for a                    Efficacy               Warm White                   80 lm/W
                                                                                                                         for subtle light diffusion for                        Efficacy                  Warm White                  80 lm/W
     subtle light diffusion for ambient      DIE-CAST                                                                    ambient lighting.                     DIE-CAST
                                            ALUMINIUM      Colour temperature     Warm White                    3,000K                                        ALUMINIUM        Colour temperature        Warm White                   3,000K
     lighting. Great for kitchen bench      CONSTRUCTION                                                                                                      CONSTRUCTION

                                                           CRI                    80+                                                                                          CRI                       80+
     tops, bars and cafes to add a
                                             3 YEAR        Dimming                Non-dimmable                                                                 3 YEAR          Dimming                   Non-dimmable
     wow factor.                             WARRANTY                                                                                                          WARRANTY

                                                           Lifespan               25,000 h                                                                                     Lifespan                  30,000 h

                                                           Product code           White                  LPD013KWE                                                             Product code              White                 LPD023KWE

                                                                                  Black                  LPD013KBL

                                                                                  Silver                  LPD013KPS

                                                                                    BEAM                                                                                           BEAM
                                                                                  ANGLE 20º                                                                                      ANGLE 130º                                 Lead
                                                                                                                 Lead
                                                                                                                                                                                                                            1.5m
                                                                                                                 1.5m

                                                                                                                 150mm
                                                                                                                                                                                                                            Ø150mm

                                                                                                       Ø60mm

                                                                          Main applications                                                                                  Main applications
                                                                          Ideal for kitchen benchtops & bar counters                                                         Ideal for kitchen benchtops & bar counters

38                                                                                                                                                                                                                  LED LIGHTING FIXTURES 39
KORA          INTERIOR UP/DOWN LIGHT (8.3W)

     Kora throws light up and down to create a beautiful light pattern on walls
     and fill rooms with ambience. The stylish cube design will complement                           Power                      8.3W
                                                                                                                                                                         335
     contemporary interiors with its sleek finish and clean lines.                                   Lumen output               Warm White                     335 lm
                                                                                                                                                                         LUMENS

                                                                                                     Efficacy                   Warm White                    40 lm/W

                                                                                                     Colour temperature         Warm White                     3,000K   UP DOWN
                                                                                                                                                                        LIGHT BEAM

                                                                                                     CRI                        80+

                                                                                                     Lifespan                   30,000 h                                6 YEAR
                                                                                                                                                                        WARRANTY

                                                                                                     Construction               Electroplate with white finish

                                                                                                     Package contents           8.3W LED up/down light fixture,
                                                                                                                                wall plugs and screws

                                                                                                     Product code               White Finish
                                                                                                                                Warm White Light     LWL053KWE

                                                                                  Light flows both
                                                                                    up and down        BEAM
                                                                                                     ANGLE 120º
                                                                                                                        100mm

                                                                                                                                                          m
                                                                                                                                                      0m
                                                                                                                                      10
                                                                                                                                        0m

                                                                                                                                                     10
                                                                                                                                           m

                                              Main applications
                                              Living areas, hallways, entrances

40                                                                                                                                                                                   LED LIGHTING FIXTURES 41
SLIMLINE                LED BATTEN (40W)

     With its 40mm slim design, our Slimline LED Batten is perfect for areas
     where illumination is needed but unobtrusiveness is the key.                                             Power                40W
                                                                                                   4400
                                                                                                   LUMENS
                                                                                                              Lumen output         Cool White                    4400 lm

                                                                                                              Efficacy             Cool White                   110 lm/W

                                                                                                              Colour temperature   Cool White                     4,000K

                                                                    Main applications                         CRI                  80+
                                                                    Ideal for kitchen, garage,
                                                                    laundry & undercover outdoor              Dimming              Non-dimmable

                                                                                                              Lifespan             40,000 h

                                                                                                              Product codes        Cool White               M5FD228LED

                                                                                                   3 YEAR
                                                                                                   WARRANTY                                                          40mm

                                                                                                                                                                     125mm

                                                                                                                                          1190mm

42                                                                                                                                                 LED LIGHTING FIXTURES 43
BLADE            LED BATTEN (36W)

     Batten lights have never looked this stylish. The Blade LED Batten
     features a slimline profile measuring in at 37mm, perfect for                                                  Power                36W
                                                                                                          UP TO
     illuminating the home or office.                                                                    3600
                                                                                                         LUMENS
                                                                                                                    Lumen output         Cool White                    3600 lm

                                                                                                                    Efficacy             Cool White                   100 lm/W

                                                                                                                    Colour temperature   Cool White                     4,000K
                                                                                                         3 YEAR
                                                                                                         WARRANTY
                                                                                                                    CRI                  80+
                                                                    Main applications
                                                                    Ideal for kitchen, study & laundry              Dimming              Non-dimmable

                                                                                                                    Lifespan             35,000 h

                                                                                                                    Product codes        1200mm
                                                                                                                                         Cool White               LLF024K1200

                                                                                                                      BEAM
                                                                                                                    ANGLE 108º

                                                                                                                    LLF024K1200

                                                                                                                                                                           37mm

                                                                                                                                                                           100mm

                                                                                                                                                1200mm

44                                                                                                                                                       LED LIGHTING FIXTURES 45
DECKIA                DECK LIGHT (0.6W)

                                                        Power                                 0.6W
                                                                                                                                                 20
                                                                                                                                                LUMENS
                                                        Lumen output                          Warm White                             20 lm

                                                        Efficacy                              Warm White                          33.3 lm/W
     Constructed in a brushed stainless steel finish,
     this kit has everything you need to illuminate     Colour temperature                    Warm White                            3,000K

     your outdoor space with just the right amount      CRI                                   80+
     of lighting.                                       Lifespan                              30,000 h

                                                        Construction                          Marine Grade Stainless Steel 316

                                                        Weatherproof rating                   IP67                                             IP67
                                                                                                                                              SUBMERSIBLE
                                                                                                                                                UP TO 1M
                                                        Package contents                      4 Pack kit contents:
                                                                                              4 x Deck lights
                                                                                              1 x 15W LED driver
                                                                                              1 x 10m extra low voltage cable                 6 YEAR
                                                                                                                                              WARRANTY

                                                        Product codes                         Polished Aluminium Finish
                                                                                              Single pack
                                                                                              Warm White Light    LDK013K316
                  Main applications                                                           Polished Aluminium Finish
                  Decks and patios                                                            4 pack
                                                                                              Warm White Light     LDR01DECK

                                                        Installation                          Must be installed with driver kit
                                                                                              LDR02D700/18. A minimum of 2
                                                                                              and a maximum of 25 deck lights
                                                                                              must be connected with each
                                                                                              driver. Cable connectors provided
                                                                                              in the kit.
                                                                   Powerpoint
                                                                                15W LED Driver                          10m Cable

                                                                                     Lights    0.6W + 0.6W + 0.6W + 0.6W = 2.4W

                                                           Ø35mm

                                                                                        M 8
                                                                         43mm

                                                                                       2
                                                                                         M
                                                                                     CUT-OUT

                                                        * The 15W LED driver (supplied with LDR01DECK) can take a maximum of
                                                          25 deck lights (LEDK013K316)

46                                                                                                                                                          LED LIGHTING FIXTURES 47
CALLA                  STEP LIGHTS (2.4W)

                                                                                           Power                 2.4W
                                                                                                                                                                  24
     Scale the heights of style with Calla step lights, an illuminating choice             Lumen output          Warm White                            24 lm     LUMENS

     for stairwells or hallways. Whether indoor or outdoor, the Calla excels               Efficacy              Warm White                       10 lm/W

     with its impressive IP65 weatherproof rating.                                         Colour temperature    Warm White                          3,000K

                                                                                           CRI                   80+

                                                                                           Insulation rating     IC

                                                                                           Dimming               Trailing & leading edge, 2 & 3 wire
           Main applications                                                               Lifespan              30,000 h
           Stairs, hallways, corridors
                                                                                           Construction          Anodised Aluminium

                                                                                           Weatherproof rating   IP65                                            IP65
                                                                                                                                                               WEATHERPROOF

                                                                                           Package contents      2.4W LED step light fixture

                                                                                           Product codes         White Finish
                                                                                                                                                                6 YEAR
                                                                                                                                                                WARRANTY
                                                                                                                 Warm White Light              LST013KWE
                                                                                                                 Aluminium Finish
                                                                                                                 Warm White Light              LST013KPS
                                                                                                                 Driver Kit               LDR02D700/18

                                                                                           Installation          Must be installed with driver kit
                                                                                                                 LDR02D700/18. A minimum of 2
                                                                                                                 and a maximum of 6 step lights
                                                     TIP                                                         must be connected with each
                                                    Use every second or third step,                              driver. Cable connectors provided
                                                    approximately 300-350mm above floor                          in the kit.
                                                    level, for the ultimate light spread
                                                                                           Driver kit contents   Plug, lead, driver
                                                                                           LDR02D700/18                  900mm                  100mm
                                                                                                                                      DRIVER

                                                                                                                 Plug coupler (x2)               100mm

                                                                                                                 Socket coupler (x2)
                                                                                                                                               100mm

                                                                                                                 Jumper (x1)

                                                                                                                 Hub (x3)                      300mm

                                                                                                                                                  M 5
                                                                                             BEAM

                                                                                                                                                 4
                                                                                                                                                   M
                                                                                           ANGLE 90º                           54mm

                                                                                                                                                CUT-OUT

                                                                                                                 42mm

48                                                                                                                                                                            LED LIGHTING FIXTURES 49
ZINNIA                STARLIGHTS (2.4W)

                                                                                           Power                 2.4W
                                                                                                                                                                 95
                                                                                                                                                                LUMENS
                                                                                           Lumen output          Warm White                           95 lm

                                                                                           Efficacy              Warm White                      39 lm/W
     A fusion of discretion and efficiency, the Zinnia starlights are an in vogue choice
     for those with an eye for detail. Whether illuminating under cabinets or wall         Colour temperature    Warm White                       3,000K

     features − indoors or outdoors − the Zinnia is the epitome of versatile style.        CRI                   80+

                                                                                           Insulation rating     IC

                                                                                           Dimming               Trailing & leading edge, 2 & 3 wire

                                                                                           Lifespan              30,000 h

                                                                                           Construction          Anodised Aluminium
                                                                                                                                                                IP65
                                                                                                                                                              WEATHERPROOF
                                                                                           Weatherproof rating   IP65

                                                                                           Package contents      2.4W LED starlight fixture                    6 YEAR
                                                                                                                                                               WARRANTY

                 Main applications                                                         Product codes         White Finish
                 Under cabinets, alfresco                                                                        Warm White Light             LST023KWE
                 areas, home theatres. Ideal
                 for illuminating features and                                                                   Aluminium Finish
                 creating ambience                                                                               Warm White Light             LST023KPS
                                                                                                                 Driver Kit             LDR02D700/18

                                                                                           Installation          Must be installed with driver kit
                                                                                                                 LDR02D700/18. A minimum of 2
                                                                                                                 and a maximum of 6 starlights
                                                                                                                 must be connected with each
                                                                                                                 driver. Cable connectors provided
                                                                                                                 in the kit.

                                                                                           Driver kit contents   Plug, lead, driver
                                                                                           LDR02D700/18                  900mm                 100mm
                                                                                                                                     DRIVER
                                                  TIP
                                                 With a slim 35mm depth,                                         Plug coupler (x2)              100mm
                                                 Zinnia fits into almost any
                                                 wall or ceiling cavity
                                                                                                                 Socket coupler (x2)
                                                                                                                                              100mm

                                                                                                                 Jumper (x1)

                                                                                                                 Hub (x3)                     300mm

                                                                                                                                         M 2
                                                                                             BEAM

                                                                                                                                        3
                                                                                                                                          M
                                                                                                                              37mm
                                                                                           ANGLE 45º
                                                                                                                                      CUT-OUT
                                                                                                                 35mm

50                                                                                                                                                                           LED LIGHTING FIXTURES 51
MIKA          EXTERIOR UP/DOWN LIGHT (8W)

     The Mika outdoor wall light features a modern design with smooth curved
     lines perfect for adding a contemporary look to gardens, patios and alfresco                 Power                                   8W (AL)     8W (BL)      UP TO

     areas. This wall light casts light up and down, providing ambient illumination                                                                               350
                                                                                                  Lumen output         Warm White         350 lm      280 lm      LUMENS

     to any outdoor space.                                                                        Efficacy             Warm White         45 lm/W     35 lm/W

                                                                                                  Colour temperature   Warm White         3,000K
                                                                                                                                                                 UP DOWN
                                                                                                                                                                 LIGHT BEAM
                                                                                                  CRI                  80+

                                                                                                  Lifespan             30,000 h

                                                                                                  Constructions        Anodised Aluminium                         IP54
                                                                                                                                                                WEATHERPROOF
                                                                                                  Product codes        Aluminium Finish
                                                                                                                       Warm White Light             LWL063KPS
                                                                                                                                                                 6 YEAR
                                                                                                                       Black Fascia                              WARRANTY
                                                                                                                       Warm White Light             LWL063KBL
                                                                               Light flows both
                                                                                 up and down

                                                                                                                                  187mm

                                                                                                    BEAM
                                                                                                  ANGLE 120º
                                                                                                                                                       59mm

                                                  Main applications                                                                         100mm
                                                  Exterior walls, pillars,
                                                  front entrances and
                                                  alfresco areas

52                                                                                                                                                                             LED LIGHTING FIXTURES 53
KYRA          EXTERIOR UP/DOWN LIGHT (7.5W)

     The multi-talented Kyra represents the ultimate in lighting versatility.
     Fitted with adjustable panels, Kyra effortlessly oscillates from an uplight                                 Power                7.5W

     to a downlight, or even both. Ideal for highlighting entrances or pillars.                                  Lumen output         Warm White                    430 lm     430
                                                                                                                                                                               LUMENS

                                                                                                                 Efficacy             Warm White                   57 lm/W

                                                                                                                 Colour temperature   Warm White                    3,000K

                                                                                                                 CRI                  80+                                     UP DOWN
                                                                                                                                                                              LIGHT BEAM
                                                                                                                 Lifespan             30,000 h

                                                                                                                 Construction         Anodised Aluminium

                                                                                                                 Package contents     7.5W LED up/down light fixture
                                                                                                                                      allen key for mounting, wall plugs       IP54
                                                                                                                                                                             WEATHERPROOF
                                                                                                                                      and screws

                                                                                                                 Product code         Aluminium Finish
                                                                                                                                      Warm White Light          LWL023KPS
                                                                                                                                                                              6 YEAR
                                                                                                                                                                              WARRANTY
                                                                                                                                      White Finish
                                                                                               Light can flow                         Warm White Light          LWL023KWE
                                                                                              up, down or both

                                                                                                                   BEAM
                                                                                                                 ANGLE 120º

                                                                                                                                                                   68mm

                                                                                                                                            13
                                                                                                                                              2m
                                                                                                                                                 m
                                                                                                                                                           mm
                                                                                                                                                         80

                                                                          TIP
                                                                         Use in conjunction with Legrand
                                                                         3 wire outdoor sensors to
                                                                         automatically switch on lights when
                                                                         movement is detected

                                                                         Main applications
                                                                         Exterior walls, pillars,
                                                                         front entrances

54                                                                                                                                                                                          LED LIGHTING FIXTURES 55
PINNA            EXTERIOR UP/DOWN LIGHT (10W)

     Slim, discreet, stylish − Pinna thrives in outdoor spaces. Utilise
     its dual-direction beam to foster an atmosphere of blissful                             Power                 10W
                                                                                                                                                          420
     tranquility. Weatherproof rated IP54 and corrosion resistant.                           Lumen output          Warm White                 380 lm
                                                                                                                                                          LUMENS

                                                                                             Efficacy              Warm White               38 lm/W

                                                                                             Colour temperature    Warm White                 3,000K     UP DOWN
                                                                                                                                                         LIGHT BEAM
                                                                                             CRI                   80+

                                                                                             Lifespan              30,000 h

                                                                                             Construction          Anodised Aluminium                     IP54
                                                                                                                                                        WEATHERPROOF

                                                                                             Package contents      10W LED up/down light fixture,
                                                                                                                   allen key for mounting, wall plugs    6 YEAR
                                                                                                                                                         WARRANTY
                                                                                                                   and screws

                                                                                             Product code          Aluminium Finish
                                                                                                                   Warm White Light     LWL013KPS
                                                                          Light flows both
                                                                            up and down

                                                                                               BEAM
                                                                                             ANGLE 120º                                    90mm

                                                                                                                                   m
                                                                                                                                0m
                                                                                                                              11
                                                                                                                  25
                                                                                                                    mm

                                                         TIP
                                Match Pinna with Legrand
                                     Soliroc weatherproof
                                switches and sockets for a
                               harmonious outdoor theme

                                          Main applications
                                      Exterior walls, pillars,
                              front entrances and backyard
                                       entertainment areas

56                                                                                                                                                                     LED LIGHTING FIXTURES 57
ROTAYA             EXTERIOR ADJUSTABLE LIGHT (9W)

     For a unique and eye-catching design, step out of the box with Rotaya.
     Rotaya dares to be different by merging such contrasting shapes, resulting                  Power                  9W
                                                                                                                                                               600
     in a superb look that draws the eye. This ultra-modern looking light is                     Lumen output           Warm White                 600 lm
                                                                                                                                                               LUMENS

     also ultra-flexible, with a beam angle of 110 degrees. Durable, long-lasting                Efficacy               Warm White                60 lm/W
     and striking in design, Rotaya will be a stand-out from the rest!
                                                                                                 Colour temperature     Warm White                 3,000K

                                                                                                 CRI                    80+
                                                                                                                                                             ADJUSTABLE
                                                                                                 Lifespan               35,000 h                              HEAD 180°

                                                                                                 Construction           Anodised Aluminium

                                                                                                 Package contents       9W LED up/down light fixture,          IP65
                                                                                                                                                             WEATHERPROOF
                                                                                                                        allen key for mounting, wall plugs
                                                                                                                        and screws
                                                                                                                                                              5 YEAR
                                                                                                 Product code           Aluminium Finish                      WARRANTY

                                                                                                                        Warm White Light     LWL083KPS

                                                                              Light flows both     BEAM
                                                                                up and down      ANGLE 110º
                                                                                                                179mm

                                                                                                                              100mm

                                                              Main applications
                                                              Exterior walls, pillars,
                                                              front entrances and
                                                              alfresco areas

58                                                                                                                                                                          LED LIGHTING FIXTURES 59
GLAMA             EXTERIOR ADJUSTABLE LIGHT (10W)

     Modern, elegant and simple, this outdoor LED light makes a statement. Made
     from die-cast aluminium with an exquisite metallic finish, Glama is the perfect           Power                10W
                                                                                                                                                           700
     lighting solution to add a contemporary look and feel to any outdoor space. The           Lumen output         Cool White                 700 lm
                                                                                                                                                           LUMENS

     independent adjustable light allows for light play across multiple levels, working        Efficacy             Cool White                70 lm/W
     as a handy guide for the path, or highlighting a hidden nook from a far. With an
                                                                                               Colour temperature   Cool White                 4,000K     DIE-CAST
     IP55 weatherproof rating and 5 year warranty, this symmetrical beauty will stand                                                                    ALUMINIUM
                                                                                               CRI                  80+                                  CONSTRUCTION
     tall with utmost confidence − rain, hail or shine.
                                                                                               Lifespan             35,000 h

                                                                                               Construction         Anodised Aluminium
                                                                                                                                                           IP55
                                                                                                                                                         WEATHERPROOF
                                                                                               Package contents     10W LED up/down light fixture,
                                                                                                                    allen key for mounting, wall plugs
                                                                                                                    and screws
                                                                                                                                                          5 YEAR
                                                                                                                                                          WARRANTY
                                                                                               Product code         Aluminium Finish
                                                                                                                    Warm White Light      LBD0112PS

                                                                                                 BEAM
                                                                                               ANGLE 70º

                                                                                                                                              600mm
                                                               Main applications
                                                               Driveways, secluded walkways,
                                                               front and back porches

                                                                                                                       150mm           60mm

60                                                                                                                                                                      LED LIGHTING FIXTURES 61
OROYA             OUTDOOR BUNKER LIGHT (12W)

     The Oroya is a great choice as a weatherproof outdoor lighting solution with the
     versatility of being mounted on a wall or in a ceiling. With a weatherproof IP65               Power                12W
     rating, it is the ideal solution as an outdoor oyster light or bunker wall light.                                                                            870
                                                                                                    Lumen output         Cool White                    870 lm     LUMENS

                                                                                                    Efficacy             Cool White                   72 lm/W

                                                                                                    Colour temperature   Cool White                    4,000K
                                                                                                                                                                 WALL OR
                                                                                                    CRI                  80+                                     CEILING
                                                                                                                                                                MOUNTING
                                                                                                    Construction         UV resistant polycarbonate

                                                                                                    Package contents     12W outdoor light fixture,
                                                                                                                         wall plugs and screws
                                                                                                                                                                  IP65
                                                                                                                                                                WEATHERPROOF

                                                                                                    Product codes        White Finish
                                                                                                                         Cool White Light     LBL014KWE
                                                                                                                                                                 3 YEAR
                                                                       Main applications                                 Black Finish                            WARRANTY

                                                                       Outdoor walls and ceilings                        Cool White Light      LBL014KBL

                                                                                                      BEAM                                               95mm

                                                                                                    ANGLE 120º
                                                                                                                                  600mm

62                                                                                                                                                                             LED LIGHTING FIXTURES 63
FINA         SLIM FLOODLIGHT (10W TO 20W)

     The Fina floodlight combines both a contemporay design and high
     performance. The slim profile and sleek tempered glass diffuser                          Power                                          10W              20W               UP TO

                                                                                                                                                                              1900
     bring a touch of modern design. The stunning IP rating allows the                        Lumen output                  Cool White       980 lm           1900 lm          LUMENS

     Fina to be installed fully exposed to the elements.                                      Efficacy                      Cool White       97 lm/W          94 lm/W

                                                                                              Colour temperature Cool White                                   4,000K

                                                                                              CRI                           80+                                              ADJUSTABLE
                                                                                                                                                                              HEAD 90°

                                                                                              Lifespan                      25,000 h

                                                                                              Constructions                 Powdercoated Cast Aluminium body,
                                                                                                                            with Tempered Glass.
                                                                                                                                                                               IP65
                                                                                                                                                                             WEATHERPROOF

                                                                                              Package contents              LED floodlight with mounting bracket,
                                                                          TIP
                                                                                                                            wall plugs, screws and power cable                3 YEAR
                                                                                                                                                                              WARRANTY
                                                                         Super slim profile   Product codes                 10W                        LFL0409WBL
                                                                         blends perfectly                                   20W                        LFL0415WBL
                                                                         into all exteriors

                                                                                                                            LFL0409WBL
                                                                                                BEAM
                                                                                              ANGLE 113º                          138mm

                                                                                                                   95.5mm

                                                                                                                            LFL0415WBL
                                                                                                                                    165mm

                                                                                                                   115mm

                                                                                                                                                      Tempered glass
                                                                                                                                                      for extra safety

                                                                                                    Wall or
                                                                                                    ceiling                                        Vertical adjustment 90°
                                                                                                    mounting
                                                                                                    bracket

                LFL0409WBL                               LFL0415WBL

                                                                                                     Weatherproof IP65

64                                                                                                                                                                                          LED LIGHTING FIXTURES 65
LEANA             SLIM FLOODLIGHT (8W-30W)

     Think 'fabulous alfresco fun' with Leana. With its sleek, contemporary
     design, IP65 weatherproof rating and long-lasting LED globe, Leana is                             UP TO       Power                                                             8W               15W          20W             30W
                                                                                                     3000
     the perfect floodlight for adding sparkle to your outdoor area. The light is                     LUMENS       Lumen output                                  Cool White          650 lm           1200 lm      2000 lm         3000 lm

     also equipped with multiple levels of luminosity to suit all your ambiance                                    Efficacy                                      Cool White          81 lm/W          80 lm/W      60 lm/W         100 lm/W
     needs. Sleek to the eye, low on the power bill and brilliant for creating                       SENSOR        Colour temperature                            Cool White 4,000K
                                                                                                     OPTIONS
     moods, you can't go wrong with Leana.                                                          AVAILABLE
                                                                                                                   CRI                                           70+

                                                                                                                   Lifespan                                      25,000 h
                                                                                                      IP65
                                                                                                    WEATHERPROOF   Construction                                  Die-cast aluminium

                                                                                                                   Tilt angle                                    130° vertical
                                                                                                     5 YEAR        Sensor detection range/angle                  6m (max) 360° scan
                                                                                                     WARRANTY

                                                                                                                   Time delay                                    5 min

                                                                                                                   Sensor type                                   Passive Infrared (PIR)

                                                                                                                   Switching function                            Auto

                                                                                                                   Package contents                              LED floodlight with mounting bracket & 300mm lead, wall plugs,
                                                                                TIP
                                                                                                                                                                 screws and power cable

                                                                               Super slim profile                  Product code                                  8W                                   LFL0510BL
                                                                               blends perfectly                                                                  15W                                  LFL0520BL
                                                                               into all exteriors
                                                                                                                                                                 20W                                  LFL0530BL
                                                                                                                                                                 30W                                  LFL0540BL
                                                                                                                                                                 15W with PIR sensor                  LFS0520BL
                                                                                                                                                                 20W with PIR sensor                  LFS0530BL

                                                                                                                            30W                           20W                               15W                            8W

                                                                                                                   145mm
                                                                                                                                                  120mm
                                                                                                                                                                                     98mm
                                                                                                                                                                                                                    77mm

                                                                                                                                 189mm     52mm              150mm          48mm              121mm         44mm            96mm         42mm

                                                                                                                            20W WITH PIR SENSOR                  15W WITH PIR SENSOR

                                                                                                                    120mm
                                                                                                                                                          98mm

                                                                                                                                150mm    48mm                      121mm      44mm                      BEAM
                                                                                                                                                                                                      ANGLE 110º

                     LEANA SLIM FLOODLIGHT             LEANA SLIM FLOODLIGHT
                     WITHOUT SENSOR                    WITH SENSOR

66                                                                                                                                                                                                                   LED LIGHTING FIXTURES 67
NE
                                                                 W
     JENTA            SINGLE PORTABLE PAR38 FLOODLIGHT (8W)

     Whether you want a stylish wall-mount, an illuminated garden bed, or
     a glowing patio, our JENTA LED floodlights will have you covered. The                                                        Power                         8W
                                                                                                                                                                                                                                              800
     modern aesthetics, low energy usage and reliable operation make this                                                         Lumen output                  Cool White                                                   800 lm           LUMENS

     range a winner on all fronts!                                                                                                Efficacy                      Cool White                                          100 lm/W

                                                                                                                                  Colour temperature            Cool White                                                   4,000K
                                                                                                                                                                                                                                            ADJUSTABLE
                                                                                                                                  CRI                           80+                                                                          HEAD 90°

                                                                                                                                  Lifespan                      30,000 h

                                                                                                                                  Tilt angle                    90°                                                                           IP44
                                                                                                                                                                                                                                            WEATHERPROOF

                                                                                                                                  Adjustable head               90°

                                                                                                                                  Package contents              Floodlight with flex and plug and 1x
                                                                                                                                                                PAR38 LED globe

                                                                                                                                  Product code                  Black Finish
                                                                                                                                                                Cool White Light                            MP38CLLED
                                                                                            Main applications
                                                                                            Outdoor areas, front and                                            Black Finish
                                                                                            back porches, decks, patios                                         Cool White Light                            MP38PFLED
                                                                                            and workshops
                                                                                                                                                                Black Finish
                                                                                                                                                                Cool White Light                      MP38PERMFLED

              MP38CLLED - CLIP                        MP38PFLED
                                                                                                                                    BEAM
                                                                                                                                  ANGLE 90º

                                                                                                                                                               Adjustable                    78mm
                                                                                                                                  MP38PERMFLED                 head 90º

                                                                                                                                                                                                         Wall or
                                                                                                                                                                                                         ceiling
                                                                                                                                                                                                         mount

                                                                                                                                                               mm
                                                   I’M

                                                                                                                                                              145
                                                 EASY T
                                                 INSTALL                                                                                                                                     8W PAR38
                                                                                                                                                                                             LED globe
                                                                                                                                                                    Ø1
                                                                                                                                                                      25m
                                                                                                                                                                         m

                                                                                                                                                                                       145
                                                                                                                                                                                          mm
                                                                     MP38CLLED                                                    MP38PFLED
                                                                                                      mm
                                                                                                   145
                                                                                                                         Ø1

                                                                                                                                                                                    8W PAR38

                                                                                                                                                          m
                                                                                                                          25m

                                                                                                                                                     25m
                                                                                                                                                                                    LED globe
                                                                                                                              m

                                                                                                                                                     Ø1
                                                                                    Adjustable
           MP38PERMFLED - PERMA                                                     head 90º
                                                                                                                                                                                                         Adjustable
                                                                                                                                                                                                         head 90º
                                                                                     70mm

                                                                                                                  8W PAR38
                                                                                                                  LED globe

                                                                                                                                                                                                                   1.8
                                                                                                                                                                                                                                      plu

                                                                                                                                                                                                                                      g
                                                                                                         Handy clamp                                                                                                  m fl
                                                                                                         mounting                                                                                                            ex and

                                                                           1.
                                                                             8m             lu
                                                                                            g

                                                                                  flex and p                                                                                 Wall or ceiling mount
                                                                                                                                                                             with freestanding base

68                                                                                                                                                                                                                                                         LED LIGHTING FIXTURES 69
NE
                                                              W
     JENTA              TWIN PAR38 FLOODLIGHT (8W)

     The JENTA Twin LED Floodlight is renowned for its modern aesthetics and
     low energy consumption. It gives you creative mounting flexibility to suit                                                     Power                                 80W (per lamp)
                                                                                                                                                                                                                                           1600
     your outdoor needs. Now, you can multiply these perks by two, with the new                                                     Lumen output                          Cool White 1600 lm (800 lm per lamp)                              LUMENS

     JENTA LED Twin Floodlight.                                                                                                     Efficacy                              Cool White                                        100 lm/W

                                                                                                                                    Colour temperature                    Cool White                                             4,000K
                                                                                                                                                                                                                                          ADJUSTABLE
                                                                                                                                    CRI                                   80+                                                             TIME-DELAY
                                                                                                                                                                                                                                          & LUX LEVEL

                                                                                                                                    Lifespan                              30,000 h
                                                                                                                                                                                                                                          ADJUSTABLE
                                                                                                                                    Head swivel angle                     110° (per lamp)                                                  HEAD 300°

                                                                                                                                    Sensor detection                      12m / 180°
                                                                    I’M                                                             range/angle

                                                                  EASY T                                                            Sensor time-delay                     10 (±3) seconds to 7 (±2) minutes
                                                                  INSTALL                                                           adjustment                                                                                              IP44
                                                                                                                                                                                                                                          WEATHERPROOF

                                                                                                                                    Sensor type                           Passive Infrared (PIR)
                                   MALC113VPLED                                                                                     Construction                          UV resistant polycarbonate

                                                                                                                                    Package contents                      Floodlight with flex and plug, 2x
                                                                                                                                                                          PAR38 LED globe and screws

                                                                                                                                    Product code                          Black Finish
                                                                                                                                                                          Cool White Light                       MALC113PLED
                                                                                                                                                                          Black Finish
                                                                                                                                                                          Cool White Light                             LFS043KBL
                 TIP
                                                                                                                                                                          Black Finish
                Outdoor areas, front/back porches,                                                                                                                        Cool White Light                          LFSM043KBL
                decks/patios, secluded workshops,
                garages, driveways, cluttered areas,
                indoor security applications, stairways,
                attics and workshops.

                                                                  LFS043KBL
                                                                                                                                      BEAM
                                                                                                                                    ANGLE 110º

                                                                                    MALC113PLED                                                                LFS043KBL / LFSM043KBL

                                                                                            Ø113mm                                                         Ø113mm
                                                                             IP44                           2 × 8W PAR38                      IP44                            2 × 8W PAR38
                                                                    Weatherproof                              LED globes   Ø125mm    Weatherproof                               LED globes      Ø125mm
                                                                          fixture                                                          fixture

                                                                                                                                                                                                               Wall or ceiling mount

                                                                                                                                                                                                         Adjustable head160º
                                                                                                                                                                                                           vertical 300º axial

                                                                                                                                                       Passive infrared
                                                                                          Wall or ceiling mount                                         (PIR) sensor            Deactivates
                                                                                                                                                                                automatically
                                                                                                                                                     Adjustable sensitivity     in daylight
                                                                                    Adjustable head160º
                                                                                      vertical 300º axial                                            Adjustable time delay10
                                                                                                                                                     seconds to 7 minutes
                                     LFSM043KBL                                                                                                      Adjustable lux level

                                                                                                                                                     180° Detection angle

70                                                                                                                                                                                                                                                       LED LIGHTING FIXTURES 71
TWIN FLOODLIGHT WITH SENSOR                                                             (29W)

     This versatile floodlight features dual lights that can be independently
     positioned allowing different areas to be illuminated. Ideal for secluded                       Power                  29W
                                                                                                                                                                   2200
     walkways and driveways the PIR sensor automatically activates lights                            Lumen output           Warm White                 2,200 lm     LUMENS

     when motion is detected within the detection range.                                             Efficacy               Warm White                 75 lm/W

                                                                                                     Colour temperature     Warm White                   3,000K
                                                                                                                                                                  ADJUSTABLE
                                                                                                     CRI                    80+                                   TIME-DELAY
                                                                                                                                                                  & LUX LEVEL
                                                                                                     Lifespan               30,000 h

                                                                                                     Head swivel angle      120°                                    IP44
                                                                                                                                                                  WEATHERPROOF

                                                                                                     Sensor detection       12m / 180°
                                                                                                     range/angle
                                                                                                                                                                   3 YEAR
                                                                                                                                                                   WARRANTY
                                                                                                     Sensor time-delay      10 (±5) seconds to 4 (±1) minutes
                                                                                                     adjustment

                                                                                                     Sensor type            Passive Infrared (PIR)

                                                                                                     Construction           UV resistant polycarbonate

                                                                                                     Package contents       29W Twin LED floodlight with PIR
                                                                                                                            sensor, wall plugs and screws,
                                                                                                                            2x14W PAR38 LED lamps

                                                                                                     Product code           Black Finish
                                                                                                                            Warm White Light         LFS013KBL

                                                                                                       BEAM
                                                                                                     ANGLE 120º
                                                                                                                    140mm

                                                                                                                                         215mm

                                                    TIP
                                                   Passive infrared sensors are sensitive
                                                   to a person’s skin temperature through
                                                   emitted body radiation, in contrast to
                                                   background objects at room temperature.
                                                   No energy is emitted from the sensor,
                                                   thus the name “Passive Infrared” (PIR)
                                                                                                     PAR38 replacement LED lamp
                                                                                                     (LPAR38024KES)

72                                                                                                                                                                               LED LIGHTING FIXTURES 73
SIKA        FLOODLIGHTS (12W TO 25W)

     A great choice for lighting walkways and outdoor areas, this floodlight is
                                                                                                  Power                                     12W                  25W
     a bright energy saver. Its simple design blends seamlessly with any décor                                                                                             UP TO

                                                                                                  Lumen output           Cool White         1,070 lm       2,200 lm      2200
     making it a versatile choice. The Sika with motion sensor switches on                                                                                                LUMENS

     automatically when movement is detected.                                                     Efficacy               Cool White         88 lm/W        89 lm/W

                                                                                                  Colour temperature     Cool White                            4,000K

                                                                                                  CRI                    80+                                            ADJUSTABLE
                                                                                                                                                                        TIME-DELAY
                                                                                                                                                                        & LUX LEVEL
                                                                                                  Lifespan               15,000 h

                                                                                                  Head swivel angle      130° vertical / 180° horizontal

                                                                                                  Sensor detection       12m / 180°
                                                                                                                                                                          IP44
                                                                                                                                                                        WEATHERPROOF
                                                                                                  range/angle

                                                                                                  Sensor time-delay      10 (±5) seconds to 4 (±1) minutes               3 YEAR
                                                                                                  adjustment                                                             WARRANTY

                                                                                                  Sensor type            Passive Infrared (PIR)

                                                                                                  Sensor manual          Yes
                                                                                                  overide

                                                                                                  Construction           Die-cast aluminium body

                                                                                                  Package contents       LED floodlight, wall plugs and screws

                                                                                                  Product code
                                                                                                  Single spot            12W                       LSP0112WBL
                                                                                                  Double spot            25W                       LSP0125WBL
                                                                                                  Single spot            12W with PIR sensor       LSS0112WBL
                                                                                                  Double spot            25W with PIR sensor       LSS0125WBL

                                                                      TIP
                                                                      Ideal for driveways,          BEAM
                                                                                                  ANGLE 120º
                                                                      including walkways, front
                                                                      and back porches
                                                                                                  LSP0112WBL             LSP0125WBL

                                                                                                                170mm

                                                                                                                                                       170mm

                                                                                                        120mm                       240mm

                                                                                                  LSS0112WBL             LSS0125WBL

                                                                                                                 240mm
                                                                                                                                                       240mm

                                                                                                        120mm                       120mm

74                                                                                                                                                                                     LED LIGHTING FIXTURES 75
FORTA            FLOODLIGHTS (10W TO 40W)

     Sporting a slick black, die-cast aluminium body, Forta floodlights look
     fantastic as well as throw a powerful light. The optional PIR sensor                               UP TO       Power                                              10W                 20W                 30W
                                                                                                      3000
     automatically turns on the light when it detects movement, which is                               LUMENS
                                                                                                                    Lumen output              Cool White               730 lm              1,615 lm            2,250 lm
     both a great energy saving and security feature.                                                               Efficacy                  Cool White               73 lm/W             80 lm/W             75 lm/W
                                                                                                      SENSOR
                                                                                                      OPTIONS       Colour temperature        Cool White                                                             4,000K
                                                                                                     AVAILABLE
                                                                                                                    CRI                       80+

                                                                                                                    Lifespan                  15,000 h
                                                                                                       IP44
                                                                                                     WEATHERPROOF
                                                                                                                    Construction              Die-cast aluminium

                                                                                                                    Head swivel angle         180° vertical
                                                                                                      3 YEAR
                                                                                                      WARRANTY      Package contents          LED floodlight with mounting bracket, wall plugs, screws and power cable

                                                                                                                    Product code              10W                                                             LFL0110WBL
                                                                                                                                              20W                                                             LFL0120WBL
                                                                                                                                              30W                                                             LFL0130WBL

                                                                                                                    LFL0110WBL            LFL0120WBL                         LFL0130WBL

                                                                  Main applications
                                                                  Ideal for driveways, secluded                                                                                                       188mm
                                                                  walkways, front and back porches                                 87mm                  140mm

                                                                                                                          115mm              180mm                                 228mm

76                                                                                                                                                                                               LED LIGHTING FIXTURES 77
TORAN             FLOODLIGHT WITH SENSOR (16W)

     Ideal for mounting under eaves or for illuminating driveways, the Toran
     keeps you safe with style. Equipped with a motion sensor for energy                                 Power                16W

     saving and an adjustable head which enables 180° flexibility.                                       Lumen output         Cool White                   1,700 lm
                                                                                                                                                                       1700
                                                                                                                                                                         LUMENS

                                                                                                         Efficacy             Cool White                   106 lm/W

                                                                                                         Colour temperature   Cool White                     4,000K
                                                                                                                                                                         PIR
                                                                                                                                                                       SENSOR WITH
                                                                                                                                                                         MANUAL
                                                                                                         CRI                  80+                                        OVERRIDE

                                                                                                         Lifespan             30,000 h

                                                                                                         Head swivel angle    90° vertical / 120° horizontal            IP44
                                                                                                                                                                      WEATHERPROOF

                                                                                                         Sensor detection     12m / 180°
                                                                                                         range/angle
                                                                                                                                                                       3 YEAR
                                                                                                                                                                       WARRANTY
                                                                                                         Sensor time-delay    10 (±5) seconds to 4 (±1) minutes
                                                                                                         adjustment

                                                                                           Horizontal    Sensor type          Passive Infrared (PIR)
                                                                                          and vertical
                                                                                           adjustable    Sensor manual        Yes
                                                                                             head
                                                                                                         override

                                                                                                         Construction         UV resistant polycarbonate with
                                                                                                                              aluminium heat sink

                                                                                                         Package contents     16W LED floodlight with sensor,
                                                                                                                              wall plugs and screws

                                                                                                         Product code         Black Finish
                                                                                                                              Cool White Light     LFS0316WBL

                                                                                                           BEAM
                                                                                                         ANGLE 100º

                                                                                                                                                   240mm

                                                               Main applications
                                                               Ideal for driveways, secluded
                                                               walkways, front and back porches

                                                                                                                                    180mm

78                                                                                                                                                                                   LED LIGHTING FIXTURES 79
MAXIS          FLOODLIGHT (9W)

     The Maxis provides added security to outdoor areas with an
     integrated PIR motion sensor that lights up automatically                                 Power                9W
                                                                                                                                                               900
     when movement is detected.                                                                Lumen output         Cool White                    900 lm
                                                                                                                                                               LUMENS

                                                                                               Efficacy             Cool White               100 lm/W

                                                                                               Colour temperature   Cool White                    4,000K
                                                                                                                                                             ADJUSTABLE
                                                                                                                                                             TIME-DELAY
                                                                                               CRI                  80+                                      & LUX LEVEL

                                          Horizontal                                           Lifespan             25,000 h
                                         and vertical
                                          adjustable                                           Head swivel angle    90° vertical and horizontal                IP44
                                                                                                                                                             WEATHERPROOF
                                         head up to 90°
                                                                                               Sensor detection     8m / 130°
                                                                                               range/angle                                                    3 YEAR
                                                                                                                                                              WARRANTY

                                                                                               Sensor time-delay    10 (±5) seconds to 4 (±1) minutes
                                                                                               adjustment

                                                                                               Sensor type          Passive Infrared (PIR)

                                                                                               Construction         UV resistant polycarbonate

                                                                                               Package contents     9W LED floodlight with sensor,
                                                                                                                    wall plugs and screws

                                                                                               Product code         Black Finish
                                                                                                                    Cool White Light     LSS0209WBL

                                                                                                 BEAM
                                                                                               ANGLE 120º
                                                                                                                                                     170mm

                                                            Main applications
                                                            Ideal for driveways, secluded
                                                            walkways, front and back porches

                                                                                                                                 160mm

80                                                                                                                                                                          LED LIGHTING FIXTURES 81
BAKRA             FLOODLIGHT (13W TO 14W)

     Illuminate your outdoor space with the Bakra. The functional design
     casts a wide spread of light making outdoor spaces brighter and safer.                        Power                  13W to 14W
                                                                                                                                                                   1100
                                                                                                                                                                   LUMENS
                                                                                                   Lumen output           Cool White                  1,100 lm

                                                                                                   Efficacy               Cool White               100 lm/W

                                                                                                   Colour temperature     Cool White                   4,000K

                                                                                                   CRI                    80+
                                                                                                                                                                 ADJUSTABLE
                                                                                                   Head swivel angle      180° vertical (No sensor)               HEAD 180°
                                                                                                                          90° vertical (Sensor)

                                                                                                   Lifespan               15,000 h (No sensor)
                                                                                                                          30,000 h (Sensor)                        IP44
                                                                                                                                                                 WEATHERPROOF

                                                                Main applications                  Construction           UV Resistant ABS Plastic
                                                                Ideal for driveways, secluded                             aluminium heat sink
                                                                                                                                                                  3 YEAR
                                                                walkways, front and back porches                                                                  WARRANTY
                                                                                                   Sensor detection       8m / 130°
                                                                                                   range/angle

                                                                                                   Sensor time-delay      10 (±5) seconds to 4 (±1) minutes
                                                                                                   adjustment

                                                                                                   Sensor type            Passive Infrared (PIR)

                                                                                                   Sensor manual          No
                                                                                                   override

                                                                                                   Package contents       LED floodlight with mounting
                                                                                                                          brackets, wall plugs and screws

                                                                                                   Product code           Black Finish
                                                                                                                          11W                 LFL0213WBL

                                                                                                     BEAM
                                                                                                   ANGLE 105º

                                                                                                     LFL0214WBL

                                                                                                                        261mm

                                                                                                           210mm

82                                                                                                                                                                              LED LIGHTING FIXTURES 83
FORTA           WORKLIGHTS (10W TO 40W)

     Brighten up a work space on site, at home, in the garage or workshop
     with a high performing Forta LED worklight. Increase visibility and       UP TO       Power                                               10W       20W           30W              2 x 10W      2 x 20W
                                                                             3230
     safety indoors or outdoors with this IP44 weatherproof rated range.      LUMENS
                                                                                           Lumen output                     Cool White         730 lm    1,615 lm      2,250 lm         2 x 730 lm   2 x 1,615 lm

                                                                                           Efficacy                         Cool White         73 lm/W   80 lm/W       75 lm/W          73 lm/W      80 lm/W

                                                                                           Colour temperature               Cool White                                                                    4,000K
                                                                              IP44
                                                                            WEATHERPROOF
                                                                                           CRI                              80+

                                                                                           Lifespan                         15,000 h

                                                                              EASY         Construction                     Die-cast aluminium
                                                                              PLUG-IN
                                                                                           Height adjustment                Yes tripod

                                                                                           Head swivel angle                180° vertical
                                                                             3 YEAR        Weatherproof rating              IP44
                                                                             WARRANTY

                                                                                           Package contents                 LED worklight with flex and plug

                                                                                           Product code                     Portable
                                         Main applications                                                                  10W                                                                   LWK0110WBL
                                         Illuminating work spaces                                                           20W                                                                   LWK0120WBL
                                                                                                                            30W                                                                   LWK0130WBL
                                                                                                                            Tripods
                                                                                                                            2 x 10W                                                               LWK0220WBL
                                          TIP                                                                               2 x 20W                                                               LWK0240WBL
                                         Adjust height to suit
                                         any type of work
                                                                                           LWK0110WBL          LWK0120WBL                   LWK0220WBL                         LWK0240WBL
                                                                                                                  180mm
                                                                                                                                            115mm                               180mm

                                                                                             115mm

                                                                                                                             140mm
                                                                                                      85mm

                                                                                                                                                               Tripod height                             Tripod height
                                                                                                 LWK0130WBL                                                    0.65m min                                 0.65m min
                                                                                                                                                               1.25m max                                 1.25m max
                                                                                                      228mm

                                                                                                                    185mm

84                                                                                                                                                                                  LED LIGHTING FIXTURES 85
DIMMER COMPATIBILITY

                                                                                                                            LEGRAND EXCEL LIFE ™                    LEGRAND ARTEOR™               HPM LINEA™ AND EXCEL              VIVO™
       LED FIXTURE                                     DIMMERS                          MAXIMUM LIGHTS
       RANGE                     DIMMER TYPE           COMPATIBILITY                     PER DIMMER        DIMMING RANGE

                                                       400A3P                                     16       100%-1%
                                                       400A2P                                     16       89%-7%
                                                       250T                                       11       100%-7%
       DLI70 Downlights          Trailing edge only                                                                        EM400A3P (3 wire)                       AR400A3P (3 wire)             400A2P (2 wire)                   EVM400A3* (3 wire)
                                                       400T                                       16       94%-8%          EM400A2P (2 wire)                       AR400A2P (2 wire)             Excel or Linea and 400VA          EVM400A2* (2 wire)
                                                                                                                           Excel Life 400VA all load 2 &           Arteor 400VA all load 2 & 3   (2 wire) electronic               VIVO 400VA all load 2 & 3
                                                       700T                                       28       100%-15%
                                                                                                                           3 wire electronic push-button           wire push-button dimmer       push-button dimmer                wire electronic push button
                                                       1000T                                      40       100%-18%        dimmer mechanism                        mechanism                     mechanism                         dimmer mechanism
                                                                                                                           White: EM400A3PWE                       White: AR400A3PMWE            White: 400A2PWE                   White: EVM400A3WE,
                                                       400A3P                                     12       100%-1%         EM400A2PWE                              AR400A2PMWE                                                     EVM400A2WE
                                                       400A2P                                     12       97%-9%          Urban Grey: EM400A3PUG                  Magnesium:                                                      Grey: EVM400A3GR,
       AZA+ Downlights
                                                                                                                           EM400A2PUG                              AR400A3PMMGN                                                    EVM400A2GR
                                                       250T                                        8       100%-7%
       DLI90, DLI110,           Trailing edge only                                                                                                                 AR400A2PMMGN
       DLI125 & DLI150                                 400T                                       12       100%-7%
       Downlights                                      700T                                       21       100%-13%                                                                              250T / 250L*
                                                                                                                                                                                                 Excel or Linea 250VA 2 wire
                                                       1000T                                      30       100%-16%                                                                              rotary dimmer mechanism
                                                                                                                                                                                                 White: 250LMWE 250TMWE
       Dalia Downlights                                400A3P                                      8       100%-5%         EM250T*                                                               Also available in black & cream
       Azalea Downlights                               400A2P                                      8       100%-10%        Excel Life 250VA 2 wire                 AR400T / AR400L*
                                                                                                                           trailing edge rotary dimmer             Arteor 400VA 2 wire rotary
       Freesia Downlights                              250T / 250L                                 5       100%-10%        mechanism
                                Trailing edge &                                                                                                                    dimmer mechanism
                                leading edge           400T / 400L                                 8       100%-10%        White: EM250TRWE                        White: AR400TMWE
       Luna Panel Lights                                                                                                   Urban Grey: EM250TRUG                   AR400LMWE
                                                       700T / 700L                                14       100%-25%
       Calla Step Lights                                                                                                                                           Magnesium: AR400TMMGN
                                                                                                                                                                                                 400T / 400L*
                                                       1000T / 1000L                              20       100%-25%                                                AR400LMMGN
       Zinnia Starlights                                                                                                                                                                         Excel or Linea 400VA 2 wire
                                                                                                                                                                                                 rotary dimmer mechanism
                                                       400A3P                                      8       100%-10%                                                                              White: 400TMWE 400LMWE
                                                                                                                                                                                                 Also available in black & cream
                                                       400A2P                                      8       100%-10%

                                                       250T                                        5       100%-10%        EM400T*
       DLS Downlights           Trailing edge only                                                                         Excel Life 400VA 2 wire
                                                       400T                                        8       100%-10%        trailing edge rotary dimmer
                                                       700T                                       14       100%-25%        mechanism
                                                                                                                           White: EM400TRWE
                                                       1000T                                      20       100%-25%        Urban Grey: EM400TRUG
                                                                                                                                                                                                 700T / 700L*
                                                                                                                                                                                                 Excel or Linea 700VA 2 wire
     Note: Not all LED lights are dimmable, refer to product details to confirm suitability for dimming.                                                                                         rotary dimmer mechanism
                                                                                                                                                                                                 White: 700TMWE 700LMWE

                                                                                                                           * T = Trailing Edge, L = Leading Edge

                                                                                                                                                                                                 1000T / 1000L*
                                                                                                                                                                                                 Excel or Linea 1000VA 2 wire
                                                                                                                                                                                                 rotary dimmer mechanism
                                                                                                                                                                                                 White: 1000TMWE 1000LMWE

86                                                                                                                                                                                                                                      LED LIGHTING FIXTURES 87
ACCESSORIES                                                                                                                                        INDEX OF PROTECTION
     DOWNLIGHT EXTENSION PLATES
                                                                                                                                                        1. Protection against solid bodies and liquids: IP index of protection
        Cat No.       Image       Description                             Cat No.                 Image         Description
                                                                                                                                         NE                Degrees of protection for enclosures of electrical equipment according to standards:
                                                                                                                                            W              IEC 60529, BS EN 60529 and NF EN 60529
                                  Suitable for hole cut-outs up to                                              Replaceable DLI fascia ring Ø90mm
      LEP120WE                                                            DLIR90CH                                                                      First digit:                                                            Second digit:
                                  Ø120mm                                                                        chrome
                                                                                                                                                        Protection against solid bodies                                         Protection of equipment against ingress of harmful liquids
                                                                                                                                                        (See AS 1939, Clause 5)                                                 (See AS 1939, Clause 6)
                                  Suitable for hole cut-outs up to                                              Replaceable DLI fascia ring Ø90mm
      LEP150WE                                                            DLIR90RO                                                                       IP       Tests                                                    IP    IP           Tests
                                  Ø150mm                                                                        rose gold

                                                                                                                                                         0                        No protection                                  0                              No protection

                                                                                                                Replaceable DLI fascia ring Ø90mm                  Ø 50 mm
                                                                                                                                                                                  Protected against solid bodies larger    A                                    Protected against vertically-falling drops
                                                                          DLIR90PA                                                                                                                                               1
                                                                                                                paintable                                1                        than 50 mm (e.g. accidental contact                                           of water (condensation)
                                                                                                                                                                                  with the hand)
                                                                                                                                                                                                                                                                Protected against drops of water falling at
                                                                                                                                                                                                                                 2
     Suitable for: DLI90, AZA+, Dalia, Azalea, and DLS series             Suitable for: DLI90 series                                                             Ø 12.5 mm                                                                                      up to 15° from the vertical
                                                                                                                                                                                  Protected against solid bodies larger
                                                                                                                                                         2                                                                 B                                    Protected against drops of rain water at
                                                                                                                                                                                  than 12.5 mm (e.g. finger)                     3
                                                                                                                                                                                                                                                                up to 60° from the vertical
     LIGHTING SENSORS                                                                                                                                                             Protected against solid bodies larger                                         Protected against projections of water
                                                                                                                                                                    Ø 2.5 mm                                                     4
     Passive infrared (PIR) sensor                                                                                                                       3                        than 2.5 mm (e.g. tools, wires)          C                                    from all directions
     Sensitive to a person's skin temperature through emitted body radiation, in contrast to background objects at room temperature.
     HPM's range of sensors is suitable for both indoor and outdoor for various locations throughout the house including corridors,                                                                                                                             Protected against jets of water (from all
                                                                                                                                                                                  Protected against solid bodies larger          5
     wardrobes, secluded walkways and garages.                                                                                                                       Ø 1 mm                                                                                     directions)
                                                                                                                                                         4                        than 1 mm (e.g. fine tools and small
     Whether used for extra safety around the house or for convenience indoors, these deliver great energy savings all year round.                                                wires)
                                                                                                                                                                                                                                                                Protected against jets of water of similar
                                                                                                                                                                                                                                 6
                                                                                                                                                                                                                                                                force to heavy seas
                                                              Manual       IP                        Mounting      Detection Detection      Time
        Cat No.       Image        Description      Finish                          Application                                                                                   Protected against dust (no harmful
                                                              override   Rating                        type         range     angle         delay        5                                                                 D
                                                                                                                                                                                  deposit)                                                                      Protected against the effects of
                                                                                                                                                                                                                                 7

                                                                                                                                                                                                                                                      15 cm
                                                                                                                                                                                                                                         1m
                                                                                                                                                                                                                                                                immersion

                                                                                                                                                                                                                                                      mini
                                                                                                    Wall Surface
      630S01BL                  180° PIR Sensor      Black       No       IP44    Indoor/Outdoor                     12m        180°      8s to 7min
                                                                                                     Mounted
                                                                                                                                                         6                        Completely protected against dust                                             Protected against prolonged effects of

                                                                                                                                                                                                                                         m
                                                                                                                                                                                                                                 8
                                                                                                                                                                                                                                                                immersion

                                                                                                    Wall Surface
      630S01WE                   180° PIR Sensor     White       No       IP44    Indoor/Outdoor                     12m        180°      8s to 7min
                                                                                                     Mounted
                                                                                                                                                        2. Protection IK, against mechanical impact.
                                                                                                                                                           According to standards: IEC 62262, BS EN 62262 and NF EN 62262
                                                                                                    Wall Surface
     630SM01BL                   180° PIR Sensor     Black       Yes      IP44    Indoor/Outdoor                     12m        180°      8s to 7min      IK                   Tests                Impact energy (in Joules)      IK                   Tests                   Impact energy (in Joules)
                                                                                                     Mounted
                                                                                                                                                                                                                                                      0.5 kg
                                                                                                                                                         IK 00                                                   0               IK 06                          200 mm                      1
                                                                                                 Wall Surface
     630SM01WE                   180° PIR Sensor     White       Yes      IP44    Indoor/Outdoor                     12m        180°      8s to 7min
                                                                                                  Mounted                                                                     0.2 kg                                                                  0.5 kg
                                                                                                                                                         IK 01                         75 mm                   0.15              IK 07                          400 mm                      2

                                                                                                      Ceiling                                                                 0.2 kg                                                                  1.7 kg
      630S02WE                   360° PIR Sensor     White       No       IP20        Indoor          Surface        8m         360°     10s to 10min
                                                                                                                                                         IK 02                         100 mm                   0.2              IK 08                          295 mm                      5
                                                                                                      mouted

                                                                                                                                                                              0.2 kg                                                                     5 kg
                                                                                                      Ceiling                                            IK 03                         175 mm                  0.35              IK 09                          200 mm                     10
      630R02WE                   360° PIR Sensor     White       No       IP41        Indoor          Surface        8m         360°     10s to 10min
                                                                                                      mounted                                                                 0.2 kg                                                                     5 kg
                                                                                                                                                         IK 04                         250 mm                   0.5              IK 10                          400 mm                     20

                                                                                                      Ceiling                                                                 0.2 kg
      630R01WE                   360° PIR Sensor     White       No       IP20        Indoor          surface        6m         360°     10s to 15min                                                                           • This table can be used to ascertain the resistance of a product to an
                                                                                                                                                         IK 05                         350 mm                   0.7
                                                                                                      mounted                                                                                                                     impact given in Joules from the IK code (graduated from 00 to 10)

                                 Triscan 3-Wire                                                     Wall Surface
      488TRI3W                                       White       Yes      IP66       Outdoor                         8m         120°     8s to 15min
                                 Pir Sensor                                                          Mounted

88                                                                                                                                                                                                                                                                           LED LIGHTING FIXTURES 89
LED LIGHTING
     GLOBES

90              LED LIGHTING FIXTURES 91
NE
                                               W

     A60       LED GLOBE WITH SHAPE (13W)

     The LED Globe with Integrated Shade is ideal for pendant kits
     and batten holders. It is suitable for living areas, bedrooms and                                                           UP TO        Power                 13W
     kitchens and has a strong 1360 lumen output, lighting up any                                                             1360
                                                                                                                                LUMENS
                                                                                                                                              Lumen output          Warm White              1,360 lm
     space in your home.                                                                                                                      Efficacy              Warm White             103 lm/W

                                                                                                                                              Colour temperature    Warm White                3,000K

                                                                                                                                              CRI                   80+
                                                                                                                             UP TO 103 lm/W
                                                                                                                                              Lifespan              25,000 h

                                                     TIP                                                                                      Base                  Bayonet B22
                                                                                                                             BAYONET
                                                    Ideal for pendant kits
                                                    and batten holders
                                                                                                                                 B22          Package contents      A60 LED Globe 13W mounted
                                                                                                                                                                    with Bayonet B22 base

                                                                                                                                              Product code          Warm White BC      LCS013KWEBC

                                                                                                                              3 YEAR
                                                                                                                              WARRANTY

                                                                                                                                                 BEAM
                                                                                                                                               ANGLE 120º

                                                                                                                                                                                              125mm
                                                                                           D9500WE

                                                                                                                                                                   Ø250mm

                                                                                                                       Ideal for
                                                                                                                     pendant kits
                                                                                                                      and batten
                                                                                                                        holders

                                              BAYONET B22 (BC)                            360/W1WE

                                                                             Note: Batten holder & pendant kit not
                                                                                           included

92                                                                                                                                                                             LED LIGHTING FIXTURES 93
A60       LED GLOBES T-SHAPE (12W TO 19W)

     Great for living rooms with low ceilings, this A60 provides an added
     feature that is more than just a globe. Take it to the next level and                                              UP TO       Power                                      12W         19W
     add this contemporary globe to a pendant light.                                                                  1700
                                                                                                                       LUMENS
                                                                                                                                    Lumen output              Warm White      1,100 lm    1,700 lm

                                                                                                                                    Efficacy                  Warm White      91 lm/W     89 lm/W

                                                                                                                                    Colour temperature        Warm White                   3,000K

                                                                                                                                    CRI                       80+
                                                                                                                     UP TO 91lm/W
                                                                                                                                    Lifespan                  20,000 h

                                                    TIP                                                                             Base                      Bayonet B22
                                                                                                                     BAYONET
                                                   Ideal for pendant kits
                                                   and batten holders
                                                                                                                        B22         Package contents          A60 LED Globe 12W or 19W,
                                                                                                                                                              mounted with Bayonet B22 base

                                                                                                                                    Product code              12W Globe
                                                                                                                                                              Warm White BC           LT150013KBC
                                                                                                                     3 YEAR                                   19W Globe
                                                                                                                      WARRANTY
                                                                                                                                                              Warm White BC           LT200013KBC

                                                                                                                                           12W                               19W

                                                                                                                                        BEAM                                BEAM
                                                                                                                                      ANGLE 110º                          ANGLE 110º

                                                                                       D9500WE
                                                                                                                                                       80mm
                                                                                                                                                                                                 95mm

                                                                                                                                           Ø150mm

                                                                                                                                                                             Ø200mm

                                            BAYONET B22 (BC)

                                                                                       360/W1WE

                                                                             Note: Batten holder & Pendant kit not
                                                                                           included

94                                                                                                                                                                       LED LIGHTING FIXTURES 95
You can also read
