E ffec ti ve M arch 2021
SIGN PANEL PRODUCTS
Omega-Bond® Standard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Omega-Bond® Economy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Omega-Bond® Premium. . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Alumalite® NEW THICKNESSES AVAILABLE!. . . . . . . . . . . . . . . . . . 6
Econolite®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
D-Lite TM
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pro-LiteTM NEW THICKNESS AVAILABLE!. . . . . . . . . . . . . . . . . . . . . 9
Omega SignBoard® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
LusterBoard®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SignPly® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Clear Sheets® NEW PRODUCTS AVAILABLE!. . . . . . . . . . . . . . 12
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Color Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Fabrication Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Applications & Production Guide. . . . . . . . . . . . . . . . . . . . . 16
Recommended Applications. . . . . . . . . . . . . . . . . . . . . . . . 17
Product Comparison Chart . . . . . . . . . . . . . . . . . . . . . . 18-19
For more than 50 years, Laminators
Incorporated has manufactured a complete
line of composite panels for the commercial
construction and sign-making industries. Our panels are strong,
quick to fabricate and install, easy to maintain, and made to last.
Laminators Incorporated is committed to providing value through
high quality products, innovative application solutions, and
superior customer service.
Why work with Laminators Incorporated Unique in the industry, Laminators Inc. is a full-service manufacturing company offering complete, innovative, turnkey solutions for your sign panel needs. Laminators Incorporated is committed to providing value through high- quality products, innovative application solutions and superior customer service. Our forward-thinking processes and forward-looking products make us a leader in the industry. You can count on us. QUALITY PRODUCTS For 50 years, Laminators manufactures a full line of digital print-ready sign panel products that are the industry standard for professional sign makers. Our sign boards are strong, durable, and ready to use. Available in a variety of colors, our finished surfaces are smooth and will not crack, chip, flake, or peel even under harsh weather conditions. Our array of cores (corrugated plastic, solid plastic, and furniture-grade exterior plywood) as well as the various thicknesses, sheet sizes, and double/single sided sheets satisfy any sign or fabricated project. KNOWLEDGE AND EXPERIENCE At the core of our sign business is our team of dedicated professionals. For every service and product we offer, we have a team with the necessary experience to ensure the best result. SHORT LEAD TIMES Because of our revolutionary manufacturing process, we can ship our standard Sign products in 1-2 weeks (some restrictions can apply)… quicker than any of our competitors! And, for added convenience, we’ve opened a warehouse in Phoenix, AZ to serve our Northwest, Southwest, and Midwest customers and provide even faster deliveries. FA B R I C AT I O N S E RV I C E S We now offer fabrication services – custom shapes, pre-cut shapes, cut-outs, fastener holes, routing and bending services... we can even quote project specific designs! No minimum quantities – large or small orders accepted. SUPERIOR CUSTOMER SERVICE Every product and service is designed with you in mind and is tailored to your specifications. We remain strong in the industry because we are customer-oriented. STRONG TECHNICAL SUPPORT Our technical support team is there for you every step of the way – from sales to engineering to installation – we have a group of experts to guide you along the way. We also offer a comprehensive Sign Production Guide that covers the best practices from panel handling, storage, prep and set-up to cleaning, cutting, routing and installing/ mounting the panel. The technical guide also outlines how to apply vinyl, films and paints as well as digital and screen printing applications. Lastly, we have tested and profiled our products by various equipment manufacturers making the production easier for you. AFFORDABLE PRICES Our reasonably priced products will meet your budget demands all while exceeding your project expectations.
Omega-Bond ® Standard Solid core aluminum composite panel
CONSTRUCTION
• F eatures double- or single-sided matte painted aluminum bonded to a solid polyethylene core
making them rigid yet lightweight
INTERIOR & EXTERIOR S P E C I F I C AT I O N S
APPLICATIONS
Sizes Finished Approx.
Architectural Signage Available Thickness Faces Colors Sheet Weight
Corporate ID 4' x 8' 2mm 2 sides White/White 20 lbs.
Digital Print 4' x 8' 3mm 1 side White/Mill Finished Backer 25 lbs.
Wall & Fence-mounted Signs 4' x 8' 3mm 2 sides All Colors on Page 13 27 lbs.
Multiple Panel Signs 4' x 10' 3mm 2 sides White, Black 31 lbs.
Dimensional Lettering/Cut-outs 5' x 10' 3mm 2 sides White, Black 39 lbs.
Electrical LED or Neon Signs/ 4' x 8' 4mm 2 sides White 33 lbs.
Channel Letters
4' x 8' 6mm 2 sides White, Black 50 lbs.
Scoreboards
4' x 10' 6mm 2 sides White 62 lbs.
Billboards
Real Estate/Post & Panel Signs Colors and other sizes available by special order
Fascia Signs BENEFITS
Canopies • Optimal for direct digital printing and cutting
ADA Compliant/Wayfinding Signs • Durable, water-resistant construction
POP Displays & Exhibits • Solid core prevents bowing, warping, swelling, and delamination
Kiosks • Flat, smooth surface ready for paint, inks, vinyl letters, and more
Temporary Construction • Ability to bend and rout panels
& Traffic/Regulatory Signs • High-quality, low-cost choice for interior and exterior signage needs
Fine Art Murals • Class A flame spread rating
Fabrication/3D Signs • UL Recognized Component
Omega-Bond ® Economy
INTERIOR & EXTERIOR
APPLICATIONS*
F E AT U R E S
Digital Print • One side gloss/one side matte painted white aluminum
Wall & Fence- • 3mm panel thickness
mounted Signs • Panels available in 4' x 8' sheets
Electrical LED or • Colors available by special order
Neon Signs/Channel Letters
Real Estate/Post & Panel Signs BENEFITS
• Optimal for direct digital printing and cutting
* Laminators does not recommend bending
or folding Omega-Bond Economy panels — • Extremely flat, durable, and moisture-resistant
use for flat signage applications only.
• S olid core composition prevents bowing, warping, swelling,
and delamination
• Flat, smooth surface ready for paint, inks, vinyl letters, and more
CPA
UL File number: E60612 • UL Recognized Component
4
• Class A flame spread rating
Omega-Bond ® Premium Aluminum composite panels
CONSTRUCTION
• F eatures double-sided matte painted aluminum bonded
to a solid polyethylene core designed specifically for
fabrication applications
• T
he .012" Omega-Bond Premium features a .012"
aluminum skin thickness and higher quality plastic
core that is best suited for your fabricated projects
S P E C I F I C AT I O N S
Sizes Skin Overall Panel Finished Approx.
Available Thickness Thickness Faces Colors Sheet Weight
INTERIOR & EXTERIOR
4' x 8' 0.3mm/0.12" 3mm 2 sides White 31 lbs.
APPLICATIONS
5' x 10' 0.3mm/0.12" 3mm 2 sides White 49 lbs.
Architectural Signage
Colors and other sizes available by special order Corporate ID
Digital Print
BENEFITS
Wall & Fence-mounted Signs
• The thicker gauge aluminum is optimal to achieve best results for fabrication
projects. Routing and bending the panels is now easily accomplished Multiple Panel Signs
• Specially treated for optimal flatness before and after bending, by taking out Dimensional Lettering/
all possible tension/stress from the panel itself Cut-outs
• Maximum durability is achieved since the solid polyethylene core has fewer Electrical LED or Neon Signs/
impurities and lesser recycled content. This allows bending and cutting without Channel Letters
breaking the core during the fabrication process
Scoreboards
• The .012" aluminum provides structural
strength and allows 3-dimensional shapes Billboards
to be achieved without an inner support
or frame Real Estate/Post & Panel Signs
• Various architectural signage, decorative Fascia Signs
canopies and cladding solutions can
Canopies
be easily fabricated for retail shops,
restaurants, banks, car dealerships, etc. ADA Compliant/Wayfinding
• Class A flame spread rating Signs
• UL Recognized Component POP Displays & Exhibits
Kiosks
Temporary Construction &
Traffic/Regulatory Signs
Fine Art Murals
Fabrication/3D Signs
CPA
UL File number: E60612
5
Alumalite ® Corrugated plastic core with double-sided aluminum
CONSTRUCTION
Al u m a l i te & E co n o l i te
• S trong, aluminum composite panel with high-density,
corrugated polypropylene (CPP) core that won’t swell,
corrode, rot, wick water, or delaminate even under
prolonged water exposure
• F actory-baked polyester painted aluminum faces add
high-gloss brilliance and rigidity; warranted not to crack,
chip, flake, or peel; Colorfast 10-year limited warranty
S P E C I F I C AT I O N S
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight
4' x 8' 6mm 2 sides 12 Colors* 25 lbs.
4' x 10' 6mm 2 sides 12 Colors* 31 lbs.
INTERIOR & EXTERIOR
APPLICATIONS 4' x 12' 1 6mm 2 sides 12 Colors* 37 lbs.
Architectural Signage 5' x 8' 6mm 2 sides White 31 lbs.
Corporate ID 5' x 10' 6mm 2 sides White 39 lbs.
Digital Print 5' x 12' 1 6mm 2 sides White 47 lbs.
Wall & Fence-mounted Signs 4' x 8' 10mm 2 sides 12 Colors* 32 lbs.
Multiple Panel Signs 4' x 10' 10mm 2 sides 12 Colors* 40 lbs.
Dimensional Lettering/ 5' x 8' 10mm 2 sides White 40 lbs.
Cut-outs
5' x 10' 10mm 2 sides White 50 lbs.
Electrical LED or Neon Signs/
Channel Letters 5' x 12' 1 10mm 2 sides White 59 lbs.
Scoreboards 1
Special order sizes only, minimum order quantities required for all 12' lengths
Billboards *Colors available by special order, minimum order quantities required, refer to page 14 for specific colors
Real Estate/Post & Panel Signs
Fascia Signs NEW! 15mm & 25mm Alumalite ®
Canopies
ADA Compliant/
Wayfinding Signs BENEFITS
POP Displays & Exhibits • A
lumalite and Pro-Lite (page 9) are the only ACM available
with thicknesses greater than 10mm
Kiosks
• Offers ultimate rigidity and maximum flatness
Temporary Construction &
Traffic/Regulatory Signs • Excellent strength-to-weight ratio
Fine Art Murals • 56% greater* flexural rigidity over plywood
• All
the benefits of Alumalite with the structural performance
Fabrication/3D Signs
of plywood
• E xcellent option for applications that require longer,
unsupported spans: tradeshow exhibits, POP displays,
industrial packaging, shipping/storage containers,
CPA
and so much more!
UL File number: E60612
6 *25mm Alumalite onlyEconolite ® A single-sided version of Alumalite
S P E C I F I C AT I O N S
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight
4' x 8' 6mm 1 side 12 Colors* 24 lbs.
4' x 10' 6mm 1 side 12 Colors* 30 lbs.
4' x 12' 1 6mm 1 side 12 Colors* 36 lbs.
5' x 8' 1 6mm 1 side White 30 lbs.
5' x 10' 6mm 1 side White 38 lbs.
5' x 12' 1 6mm 1 side White 45 lbs.
4' x 8' 10mm 1 side 12 Colors* 31 lbs.
4' x 10' 10mm 1 side 12 Colors* 39 lbs.
5' x 8' 1 10mm 1 side White 39 lbs.
INTERIOR & EXTERIOR
5' x 10' 1
10mm 1 side White 48 lbs. APPLICATIONS
5' x 12' 1 10mm 1 side White 57 lbs. Architectural Signage
1
Special order sizes only, minimum order quantities required for all 12' lengths Corporate ID
*Colors available by special order, minimum order quantities required, refer to page 14 for specific colors Digital Print
Wall & Fence-mounted Signs
Multiple Panel Signs
BENEFITS
Alumali te & E con oli te Dimensional Lettering/
• Field-tested through extensive freeze/thaw Cut-outs
cycling tests with no significant structural Billboards
panel failure
Real Estate/Post & Panel Signs
• Ideal for paints, digital inks (both UV or
solvent cured), screen print inks, Fascia Signs
and pressure-sensitive vinyl
Canopies
• Strong and lightweight—same weight
as .040 aluminum sheet metal yet ADA Compliant/
50 times stronger Wayfinding Signs
• Routs and cuts easily with standard POP Displays & Exhibits
carpentry tools; even bends around corners
Kiosks
• Wind resistant—when properly fastened between
two posts can withstand winds over 120 mph
Temporary Construction &
Traffic/Regulatory Signs
• Water-, sun-, and temperature-resistant—
with a “Class A” flame spread rating Fine Art Murals
• UL Recognized Component Fabrication/3D Signs
CPA
UL File number: E60612
7D-Lite™ Corrugated plastic core, painted aluminum face
CONSTRUCTION
• H
igh-density, corrugated polypropylene (CPP) that will not swell, corrode, rot, wick water,
or delaminate—making it perfect for all outdoor or UV-exposed indoor applications
• F inished surface is high-gloss, factory-baked polyester painted aluminum on two sides
or with a coated aluminum backer
• P aint surface is highly reflective and warranted not to crack, chip, flake, or peel; Colorfast
10-year limited warranty
S P E C I F I C AT I O N S
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight
4' x 8' 3mm 1 side or 2 12 Colors* 16 lbs.
4' x 10' 3mm 1 side or 2* 12 Colors* 20 lbs.
4' x 12' 1 3mm 1 side or 2* 12 Colors* 21 lbs.
Special order sizes only, minimum order quantities required for all 12' lengths
1
*2 sides and colors available by special order, minimum order quantities required,
refer to page 14 for specific colors
BENEFITS
• O
ne of our thinnest panels and 10 times more rigid than .040 aluminum,
an economical alternative to aluminum sheet metal
• Available in single and double-sided aluminum finishes
INTERIOR & EXTERIOR • Ideal for paints, pressure-sensitive vinyl, and digital inks (both UV and solvent cured)
APPLICATIONS
Architectural Signage
Corporate ID
Digital Print
Wall & Fence-mounted Signs
Multiple Panel Signs
Dimensional Lettering/
Cut-outs
Billboards
Real Estate/Post & Panel Signs
Fascia Signs
Canopies
ADA Compliant/Wayfinding
Signs
POP Displays & Exhibits
Fine Art Murals
8Pro-Lite™ Single profile core, painted face, single- or double-sided
CONSTRUCTION
• P ainted aluminum faces bonded to a 10mm
single profile core that is resistant to water
and exposure to UV light
• F inished surface is high-gloss,
factory-baked polyester painted
aluminum on two sides or with a
coated aluminum backer
S P E C I F I C AT I O N S
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight
4' x 8' 10mm 1 side or 2 12 Colors* 28 lbs.
4' x 10' 10mm 2 sides 12 Colors* 34 lbs.
5' x 10' 10mm 2 sides White 43 lbs.
*Colors available by special order, minimum order quantities required, INTERIOR & EXTERIOR
refer to page 14 for specific colors APPLICATIONS
Architectural Signage
BENEFITS
Corporate ID
• A 10mm panel that is lightweight and amazingly strong
Digital Print
• Ideal for paints, pressure-sensitive vinyl, and digital inks
(both UV and solvent cured) Wall & Fence-mounted Signs
• Paint will not crack, chip, flake, or peel Multiple Panel Signs
• Class A, ASTM E84 rated Dimensional Lettering/
Cut-outs
Real Estate/Post & Panel Signs
NEW! 25mm Pro-Lite™
Hanging Signs
A-Frame Signs
BENEFITS Temporary Construction &
Traffic/Regulatory Signs
• Pro-Lite and Alumalite (page 6) are the only ACM available with thicknesses
greater than 10mm Fine Art Murals
• Offers ultimate rigidity and maximum flatness Fabrication/3D Signs
• Excellent strength-to-weight ratio
• All the benefits of Pro-Lite with the structural performance of plywood
• Excellent option for applications that require longer, unsupported spans:
tradeshow exhibits, POP displays, industrial packaging, shipping/storage
containers, and so much more!
9Omega SignBoard ®
Exterior high-gloss vinyl over plywood core
CONSTRUCTION
• Hardwood core is composed of a premium,
exterior furniture-grade plywood with smooth,
tight, sanded veneers for optimum surface beauty
• Surface consists of finished, brilliant
white vinyl
• The vinyl surface is impact-resistant
and formulated with high-performance
UV inhibitors to reduce fading
S P E C I F I C AT I O N S
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight
4' x 8' 1/2" 1 side or 2 White 49 lbs.
BENEFITS
• O
ffers a strong, economical sign panel with a glossy, white vinyl surface
that will not flake or peel
• Ideal for the application of pressure-sensitive vinyl
INTERIOR & EXTERIOR
APPLICATIONS • Easy to fabricate with standard carpentry tools
(Must be edge-sealed • Stronger and lighter than MDO panels
for outdoor use)
Digital Print
Wall & Fence-mounted Signs
Dimensional Lettering/
Cut-outs
Scoreboards
Billboards
Real Estate/Post & Panel Signs
Hanging Signs
A-Frame Signs
10LusterBoard ® Painted aluminum bonded to both sides of furniture-grade
exterior plywood core
CONSTRUCTION
• Hardwood core is composed of a premium, exterior furniture-grade plywood,
featuring smooth, tight, sanded veneers for optimum surface beauty
• Factory-baked polyester painted aluminum surfaces cover both sides of the INTERIOR & EXTERIOR
hardwood core, creating a smooth, glossy finish APPLICATIONS
(Must be edge-sealed
for outdoor use)
S P E C I F I C AT I O N S Architectural Signage
Sizes Finished Approx. Digital Print
Available Thickness Faces Colors Sheet Weight
Wall & Fence-mounted Signs
4' x 8' 1/4" 2 sides White* 34 lbs.
Dimensional Lettering/
4' x 8' 1/2" 2 sides 12 Colors 58 lbs. Cut-outs
*Colors available by special order, minimum order quantities required, refer to page 14 for specific colors
Scoreboards
Billboards
BENEFITS Real Estate/Post & Panel Signs
• Features a light yet rigid construction, allowing Hanging Signs
for easier handling and installation
A-Frame Signs
• Available in 12 colors, Colorfast surface is
warranted not to fade, flake, or peel
• Easy to fabricate with standard
carpentry tools
• Stronger and lighter than MDO panels
• Ideal for paints, pressure-sensitive vinyl,
and digital inks (both UV and solvent
cured)
• UL Recognized Component
SignPly® Single-sided version of LusterBoard INTERIOR & EXTERIOR
APPLICATIONS
(see above for construction and benefits)
(Must be edge-sealed
for outdoor use)
Digital Print
S P E C I F I C AT I O N S
Wall & Fence-mounted Signs
Sizes Finished Approx.
Available Thickness Faces Colors Sheet Weight Dimensional Lettering/
Cut-outs
4' x 8' 1/2" 1 side White* 52 lbs.
Electrical LED or Neon Signs/
*Colors available by special order, minimum order quantities required, refer to page 14 for specific colors Channel Letters
Scoreboards
S2S
UL File number: E60612
11Clear Sheets® R igid media for your social distancing needs and more
CONSTRUCTION
• Clear extruded acrylic and polycarbonate
S P E C I F I C AT I O N S
Sizes
Available Thickness Colors
Cut-to-size or 3mm (acrylic only) Transparent
4' x 8' sheets 4.5mm
INTERIOR & EXTERIOR 5.6mm (acrylic only)
APPLICATIONS
BENEFITS
Space separation
& partitions E X T R U DE D AC RY L IC P O LYC A R B O N AT E
• H
ighly transparent with excellent • Virtually unbreakable
Tabletop dividers
color stability • High impact and break resistant
Retail/counter shields • Can be thermoformed and machined • High clarity and light transmission
Impact shields* • Contains no hazardous substances • UV protective layer on 1 side
Medical shields • Durable and adaptable • High flame resistant
Dining partitions • Lightweight, rigid, and weather-resistant • Half the weight of glass
Security barriers • 100% recyclable • Easy to machine, handle and install
• Resistance to weathering and aging
POP display stands • High-quality material with “no bubbles”
• High-quality, virgin-grade material • Resistance to weathering and aging
Signage
• 10-year limited warranty • High-quality, virgin-grade material
• 10-year limited warranty
*Polycarbonate only
12Accessories
A D D I T I O N A L I T E M S F RO M L A M I N ATO R S I N C .
EDGE C A P AN D S E AL AN T
Edge Cap is available as a “U” channel molding in two thicknesses: 1/2" or 1/4".
Choose from a variety of attractive colors to accent the perimeter of your sign.
EDGE C A P S PECI FI CAT I ON S
Product Color
1/4" x 98" Edge Cap White, Black, Red, Green, Blue, Bronze
1/2" x 98" Edge Cap White, Black, Red, Green, Blue, Bronze
3/8" x 98" Edge Cap White, Black
3/4" x 98" Edge Cap White
DOWEL PI N S
Recommended: 1 pin every 6" to 12" along panel joints.
NOTC HI N G TOOL
This heavy-duty hand notching tool cuts a 90° angle.
ROUTER B I T
Laminators custom-designed 1/2" router bit (recommended for routing and bending)
APPROVED SUPPLIES
PANEL A D HES I V E
• Loctite® PL 400® VOC Subfloor & Deck Adhesive
• Loctite® PL Premium® Polyurethane
Construction Adhesive
• LIQUID NAILS® Subfloor & Deck Adhesive
• Titebond® Heavy-Duty Construction Adhesive
SILICON E S E AL AN TS
(for use with corrugated plastic cores only)
• Pecora 890, 860, 896, 895
• GE SilGlaze® II , SilPruf®
• SUREBOND SB-1800 Everflex Bondaprene
WOOD CORE S E AL AN T
• DAP® Alex Plus® Caulk
13Sign Panel Color Chart
ALUMALITE, ECONOLITE, D-LITE, PRO-LITE*
L U ST E R B OA R D, A N D S I G N P LY *
White Ivory Sand Beige Raven Black
Ivy Green Brite Yellow Sunset Red Candy Apple Red
Royal Blue Silver Metallic Regal Bronze Matte Black
OMEGA-BOND
White Light Ivory Silver Black
Green Yellow Red Blue
Brushed Silver Brushed Gold Brushed Bronze Bronze Metallic
Colors shown are as close to actual painted sign panels as possible. Please call for color chip
samples if needed. Colors subject to availability. Check with your local distributor for availability.
Color variation is a characteristic of aluminum composite panels with brushed aluminum and
metallic paint finishes, and can vary on material purchased from different lots. In addition, grain
direction of brushed aluminum and metallic paint finishes must be considered in the design of the
panel installation. Opposing grain directions may create visible patterns and may not be acceptable
in the finished project. Laminators does not warrant a color match for these panels.
*Colors available by special order
14Fabrication Services
Let Laminators handle your sign fabrication services needs. As manufacturers and
fabricators of sign panels, we understand all the nuances of fabricating for time-
and cost-efficiency.
Save on time and labor costs by having us fabricate your digital print-ready
sign panel products. In many cases you may not be utilizing the entirety of
an ACM panel—you're cutting, bending, shaping, contouring, and so much
more. We'll cut, rout, and bend the panels to the exact specifications needed
for the project.
Because the panels are being fabricated by the same company that manufactures
them, we understand the best way to provide superior looking, ready-to-install
panels each and every time.
W H AT C A N L A M I N ATO R S
DO FOR YOU?
• Pre-Cut Shapes
• Custom Shapes
• Cut-Outs
• Fastener Holes
• Routing & Bending Services
• And Much More!
FA B R I C AT E D A- F R A M E S I G N K I T S
Our durable A-Frame sign kits* can be used along the sidewalk or roadside
to advertise specials, promotions, events, and so much more. Capture the
attention of people walking or driving by. These portable A-Frame sign kits
are available in custom sizes and small or large quantities. We can even
provide the handles and hardware!
W H AT A R E T H E B E N E F I T S O F U S I N G L A M I N ATO R S
F O R YO U R FA B R I C AT I O N S E RV I C E S ?
• Reduce time and scheduling issues as well as labor costs
• Minimize weight and shipping costs instead of shipping full sheets
• Rely on the manufacturer’s knowledge and expertise
• If you're a distributor of our panels, you can even
stock various pre-cut shapes that are popular with
your customer base (oval, circular, etc.)
We can even quote project specific designs!
*Graphics not included
15Sign Applications
Choosing the right materials for any sign application can be a major obstacle. The sign products
are a fundamental part of the overall vision. It is important to choose your materials in the
design phase so that you can prepare for any special requirements, such as lighting, mounting,
or curved walls. In addition, exterior signage requires more durable materials that are fade
resistant and can withstand strong weather conditions. The final products should give off a
professional, yet comfortable feel to those that use them.
Laminators sign products do just that! Our panels are easy to install and can be fabricated simply
with standard carpentry tools. Available in multiple colors — factory-baked polyester painted
aluminum faces add high-gloss brilliance and rigidity; warranted not to crack, chip, flake, or peel.
Sign Panel Production Guide
The Sign Panel Production Guide provides updated technical information including additional
illustrations and step-by-step instructions. It covers the best practices from panel handling,
storage, prep and set-up to cleaning, cutting, routing and installing/mounting our panels.
The guide also outlines how to apply vinyl, films and paints as well as digital and screen
printing applications.
Visit LaminatorsInc.com to download the Sign Panel Production Guide.
To speak with a sign panel representative, please call 877.OMEGA.77.
The applications listed in this section are the most commonly used applications
in the sign industry. It does not depict all of the applications we list in the Product
16 Comparison Chart on pages 18-19.Recommended Applications
15mm/25mm
Omega-Bond
Omega-Bond
Omega-Bond
LusterBoard*
Clear Sheets
SignBoard*
Alumalite
Econolite
Economy
Standard
Premium
Products
Sign Application
Pro-Lite
SignPly*
Omega
D-Lite
ADA Compliant/
X X X X X
Wayfinding Signs
A-Frame Signs X X X
Architectural Signage X X X X X X X X
Billboards X X X X X X X X
Canopies X X X X X X
Corporate ID X X X X X X X
Digital Print X X X X X X X X X X X
Dimensional Lettering/
X X X X X X X X X
Cut-Outs
Electrical LED or
Neon Signs/ X X X X X
Channel Letters
Fabrication/3D Signs X X X X X X
Fascia Signs X X X X X
Fine Art Murals X X X X X X
Hanging Signs X X X
Kiosks X X X X X
Multiple Panel Signs X X X X X X X
POP/POS
X X X X X X X X
Displays/Stands
Tradeshow Exhibits X X X X X X X X
Real Estate/
X X X X X X X X X X
Post & Panel Signs
Retail/
X
Counter Shields
Scoreboards X X X X X X X X
Signage
X X X X X X X X X X X X
(Indoor/Outdoor)
Social Distancing/
X X X X X X X X X
Partitions
Temporary Construction
& Traffic/ X X X X X
Regulatory Signs
Wall & Fence-mounted
X X X X X X X X X X X
Signs
*Must be edge sealed for outdoor use.
17Product Comparison Chart
Panel Finished
Construction Sizes Thicknesses Available Colors Faces
Omega-Bond P ainted aluminum 4' x 8' 2mm White, Black, Brushed Gold, Brushed Silver, Single- or
Solid plastic core 4' x 10' 3mm Brushed Bronze, Silver, Yellow, Red, Blue, Double-Sided
Standard (White 4mm Green, Light Ivory, Bronze Metallic Finished Face
and Black) 6mm
5' x 10' Other thicknesses
(White only) available by special order
Omega-Bond Painted aluminum 4’ x 8’ 3mm White Double-Sided
Premium Solid plastic core 5’ x 10’ (.3mm/.012” Finished Face
skin thickness)
Omega-Bond P ainted aluminum 4' x 8' 3mm White Double-Sided
Solid plastic core Finished Face
Economy (Gloss/Matte)
Alumalite P ainted aluminum 4' x 8' 6 mm hite, Candy Apple Red, Sunset Red,
W Double-Sided
Corrugated 4' x 10' 10mm Royal Blue, Ivy Green, Brite Yellow, Finished Face
polypropylene core 4' x 12' 15mm Raven & Matte Black, Silver Metallic,
5' x 8' 25mm Ivory, Regal Bronze, Sand Beige
5' x 10'
Custom
lengths
up to 12'
Econolite P ainted aluminum 4' x 8' 6 mm hite, Candy Apple Red, Sunset Red,
W Single-Sided
Corrugated 4' x 8' 10mm Royal Blue, Ivy Green, Brite Yellow, Finished Face
polypropylene core 4' x 10' Raven & Matte Black, Silver Metallic,
5' x 8' Ivory, Regal Bronze, Sand Beige
Coated aluminum backer
5' x 10'
Custom
lengths
up to 12'
D-Lite P ainted aluminum 4' x 8' 3mm White Single- or
Corrugated 4' x 10' Colors available Double-Sided
polypropylene core Custom by special order Finished Face
lengths
up to 12'
Pro-Lite Painted aluminum 4' x 8' 10mm White Single- or
Corrugated 4' x 10' 25mm Colors available Double-Sided
polypropylene core 5' x 10' by special order Finished Face
Omega Smooth, glossy vinyl 4' x 8'' 1/2" White Single- or
Furniture-grade Double-Sided
SignBoard Finished Face
exterior plywood core
LusterBoard P ainted aluminum 4' x 8'' 1 /4" hite, Candy Apple Red, Sunset Red,
W LusterBoard:
Furniture-grade (LusterBoard Royal Blue, Ivy Green, Brite Yellow, Double-Sided
and SignPly only) Raven & Matte Black, Silver Metallic, Finished Face
exterior plywood core
1/2" Ivory, Regal Bronze, Sand Beige SignPly:
Coated aluminum backer
(SignPly) SignPly in White only. Colors available Single-Sided
by special order. Finished Face
Clear Sheets Clear extruded acrylic Cut to size or 3mm (acrylic only) Transparent N/A
and polycarbonate 4' x 8' 4.5mm
5.6mm (acrylic only)
In many instances we recommend our Omega-Lite architectural panel for all architectural applications because of its superior flatness and 20-year paint
performance, many of our customers still choose to use our sign products for storefront fascias, gas station canopies, and awning-fill or replacement,
usually because of economics. For questions or recommendations, call 877.OMEGA.77 to speak with one of our knowledgeable sign representatives.
18Surface Forming Exterior Usage Average
Fabrication Finishing Techniques Flammability Warranty Application Life
Omega-Bond Circular saw, jigsaw, Digital printing, Rout and bend, Class A, 5-year warranty Long term
drill, shear, punch, screen printing, roll form, ASTM E84 on lamination
Standard hand router, CNC vinyl graphics, reciprocating saw, 5-year Colorfast
router, press brake, sign paint, laser band saw warranty on faces
panel saw, table saw engraving
Omega-Bond Circular saw, Digital printing, Rout and bend, roll Class A, 5-year warranty Long term
Premium reciprocating saw, screen printing, form, reciprocating ASTM E84 on lamination
drill, shear, punch, vinyl graphics, saw, band saw 5-year Colorfast
hand router, CNC sign paint warranty on faces
router, press brake,
panel saw, table saw,
band saw
Omega-Bond Circular saw, Digital printing, eciprocating
R Class A, 5-year warranty Long term
reciprocating saw, screen printing, saw, band saw ASTM E84 on lamination
Economy drill, panel saw, vinyl graphics, 5-year Colorfast
table saw, band saw sign paint warranty on faces
Alumalite Circular saw, jigsaw, Digital printing, Rout and bend, Class A, 5-year warranty Long term
drill, shear, punch, screen printing, reciprocating saw, ASTM E84 on lamination
hand router, CNC vinyl graphics, band saw 10-year Colorfast
router, panel saw, sign paint, laser warranty on faces
table saw engraving
Econolite Circular saw, jigsaw, Digital printing, Rout and bend, Class A, 5-year warranty Long term
drill, shear, punch, screen printing, spot weld to ASTM E84 on lamination
hand router, CNC vinyl graphics, aluminum backer, 10-year Colorfast
router, panel saw, sign paint, laser reciprocating saw, warranty on faces
table saw engraving band saw
D-Lite Circular saw, jigsaw, Digital printing, Rout and bend, Class A, 5-year warranty Long term
drill, shear, punch, screen printing, spot weld to ASTM E84 on lamination
hand router, CNC vinyl graphics, aluminum backer 10-year Colorfast
router, panel saw, sign paint, laser (one-sided panels warranty on faces
table saw engraving only), reciprocating
saw, band saw
Pro-Lite Circular saw, jigsaw, Digital printing, Rout and bend, Class A, 5-year warranty Long term
panel saw, table saw, screen printing, reciprocating saw, ASTM E84 on lamination
drill, hand router, vinyl graphics, band saw 10-year Colorfast
CNC router sign paint
Omega Circular saw, jigsaw, Digital printing, Use like plywood 5-year warranty Medium term
drill, hand router, screen printing, on lamination*
SignBoard CNC router, panel vinyl graphics,
saw, table saw sign paint
LusterBoard Circular saw, jigsaw, Digital printing, Use like plywood Class A, 5-year warranty Medium term
drill, hand router, screen printing, ASTM E84 on lamination*
and SignPly CNC router, panel vinyl graphics, 10-year Colorfast
saw, table saw sign paint, laser warranty on faces
engraving
Clear Sheets Circular saw, jigsaw, Digital printing+, Thermoform and 10-year limited Medium term
band saw, drill, screen printing+, machine bend warranty
hand router, CNC vinyl graphics,
router, table saw sign paint
Mounting Techniques: Bolt or screw, adhesive, or extrusion system * Must be properly edge sealed
+ With proper surface treatment
Check local distributor for availability of colors, sizes, and thicknesses 19Strong, durable, and made to last,
our digital print-ready sign panel products
are the industry standard for professional sign makers.
LaminatorsInc.com
8 7 7.O M E G A .7 7 • F a x : 2 1 5 - 7 2 1 - 4 678 • 32 5 5 P e n n S t r e e t • H a t f i e l d , PA 1 9 4 4 0
(03/2021)You can also read
