Technology Portfolio Overview
High voltage Low voltage
IGBT Power Bipolar
Power MOSFET Power MOSFET
Planar and IGBT Power Bipolar
STripFETTM
MDmeshTM -100V to 200V 600V, 650V, 1200V, 1250V 15V to 1700V
250V to 1700V
Intelligent
Silicon Carbide GaN Power RF Hi-Rel & Space Power Module
Power Module
R-H
RF
SiC MOSFET GaN-on-Si LDMOS, DMOS Rad-Hard Bipolar SLLIMMTM ACEPACKTM
650V, 1200V, 1700V 100V, 650V 28V, 1000V and MOSFET 500V, 600V 650V, 1200V
60V, 200V
Motor Control / Home Appliances 3
IGBT Trench Field Stop “HB, HB2” family
(Complete current range 650V)
Tailored trade-off Vcesat - Eoff.
Compressor PFC
ACEPACK
(600V – 1200V) Compressor
Six Pack and Converter Inverter Brake
SuperJunction MDmesh DM2 & DM6 series Inverter Half Bridge
To complement offer in various motor control
application (500V to 650V)
IPM SLLIMM & SLLIMM-nano
(complete product portfolio up to 3KW)
IGBT & MOSFET Super-Junction enabling higher
efficiency for both Motor and compressor drives
Motor Indoor FAN
Outdoor FAN
Home Appliance MKT 4
ST IGBT/IPM Growth & MKT SHARE
YTD ST sales Growth
% YTD E-MKT share
% %
YTD IGBT Discrete E-MKT share
+32.0 10.5 13.6
Source: Major Home Appliance Market Report 2017- Global Major Home Appliance Market
IGBT “series” positioning 5 Dice Discrete packages IPMs ACEPACK SMIT
650V HB2 series IGBTs 6
Best performance in high-speed applications
Outstanding performance and power density to address high efficiency demand
Key Benefits Key Features
• 650V TFS IGBT
• High flexibility • Wide frequency range, from 16 to 60kHz
• Low power losses
• Low VCEsat = 1.55V @ICN
• High system efficiency
• High robustness and reliability • Low gate charge
• Maximum operating TJ = 175°C
• Three different diode options
• Automotive eligible (AEC-Q101)
BV IC Package
Part number Diode
[V] [A] TO-247 LL Typical Applications
STGWA40HP65FB2 Protection WA
• PFCs
STGWA40H65DHFB2 650V 40 Half-rated WA • Welding machines
STGWA40H65DFB2 Full-rated WA • Solar inverters
• UPS
* Series in enlargement with a current range from 15 to 100 A.
HB2 vs HB comparison 7
3kW single-phase welding machine
Test conditions Benchmark HB2HB
• Input voltage: Single-phase/220Vac, 50 Hz
• Tamb ≈ 25°C
• Fsw = 48 kHz
• Resistive load about 145 mΩ
• Max input power = 3kW
Two-switch forward topology
VCE(sat) e EOFF
comparison shows that
the HB2 40 A IGBT
device offers important
benefits in terms of
efficiency, achieving the
lowest temperatures
and power losses in pin-
to-pin conditions
Trench technology tsc > 10µs @ 1000V
4–12 kHz
IGBT
8
1700V M
Roadmap
1600V IH2
16–60 kHz
1350V 16–60 kHz IH2
IH
1250V 4–20 kHz tsc > 10µs @ 600V Motor Drives, UPS
8–30 kHz
M < 8 kHz
1200V H MS DC-DC, PFC
S < 8 kHz HB2 20–100 kHz
tsc > 5µs @ 900V Solar
tsc > 5µs @ 600V
1100V IH2 16–60 kHz
2–20 kHz Home Appliance
750V tsc > 6µs @ 400V EM
4–20 kHz
16–60 kHz M** tsc > 3µs @ 400V
IH* Induction Heating
650V HB** 16–60 kHz
50–100 kHz HB2*/**
8–30 kHz Automotive
4–20 kHz
600V V
H HN
tsc > 3µs @ 360V tsc > 2µs @ 400V
*in enlargement product portfolio
2016 2019 2020 2021 2022 2023
**AG eligible
PTD SLLIMM™ 9
Small Low-Loss Intelligent Molded Module
SLLIMM SLLIMM SLLIMM
nano series nano 2nd series 2nd series
600 V IGBT 600 V IGBT 600 V IGBT
500 V MOSFET 600 V SJ-MOSFET 600 V SJ-MOSFET
1 up to 3 A 3 up to 8 A 8 up to 35 A
NDIP (TH) SDIP2F-26L
NSDIP (SMD) N2DIP (TH) SDIP2B-26L
12.45 x 29.15 x 4.10 mm
12.45 x 29.15 x 3.10 mm 24 x 38 x 3.5 mm
20W 100W 500W 3000W
Power
SLLIMMTM - nano Series 10
Small Low-Loss Intelligent Molded Modules
Package options that help minimize overall size and design complexity
Key Benefits Key Features
• High flexibility and robustness • IGBT and MOSFET based technologies
• Improved efficiency and reliability • Optimized voltage drop in conduction
• Package compactness • Through-hole (TH) and SMD packages
• Temperature monitoring • In line or zig-zag leads
• Protection embedded inside the power module • NTC thermistor option
• Comparator, UVLO, Interlocking function
Typical Applications
• Small fans
• Roller shutters
Switch type MOSFET IGBT MOSFET IGBT • Dish washer
Voltage rating
• Compressor
500 V 600 V 500 V 600 V
• Pumps
Current capability 1A, 2A 3A 1A, 2A 3A • Refrigerators
Package NDIP (12.45x29.15) NSDIP (12.45x29.15)SLLIMMTM – nano 2nd Series 11
Small Low-Loss Intelligent Molded Modules
Best solution to increase the efficiency and isolation performance
Key Benefits Key Features
• High flexibility, robustness and improved efficiency • TFS IGBT and SJ-MOSFET based technologies
• Improved isolation voltage up to 1.5 kVrms/min • Optimized voltage drop in conduction
• Package compactness and thermal performances • In line or zig-zag leads w/wo stand-off option
• Temperature monitoring • Slots for heatsink screw
• Protection embedded inside the power module • NTC thermistor option
• High efficiency at low load applications • Comparator, UVLO, Interlocking function
• Isolation voltage rating up to 1.5 kVrms/min
• UL recognition: UL 1557, file E81734
Typical Applications
• Small fans
• Roller shutters
Switch type SJ-MOSFET IGBT(planar, TFS) • Dish washer
Voltage rating 600 V
• Compressor
• Pumps
Current capability 3A, 5A 3A, 5A, 8A • Refrigerators
Package N2DIP (12.45x29.15) • Washing machinesSLLIMMTM 2nd Series 12
Small Low-Loss Intelligent Molded Modules
Compact and high-performance AC motor drives for simple and rugged designs
Key Benefits Key Features
• TFS IGBT and SJ MOSFET
based technologies
• Improved thermal performances
• High current scalability
• Best Rth value in the market
• Full molded and DBC package
• Temperature monitoring
• Thermal sensor and NTC thermistor option
• Protection embedded inside the power module
• Comparator, UVLO, Shutdown function
• High efficiency at low load applications
• Isolation voltage rating up to 1.5 kVrms/min
• UL recognition: UL 1557, file E81734
Typical Applications
• Refrigerators
• Pumps
• Compressor
Switch type IGBT SJ MOSFET • Washing machines
Voltage rating 600 V
• Air conditioners
• Servo motors
Current capability 8A, 10A, 15A 12A, 15A, 20A, 25A, 35A 10A,15A
• Any inverter system up to 3kW
Package SDIP2F-26L SDIP2B-26LST PowerStudio 13
The dynamic electro-thermal simulation software dedicated to ST power devices
* Available in the next releasesHigh Voltage Power MOSFET 14
Breakdown Voltage
Superjunction Technology
600V 650V 800V – 1700V
MDmesh series
M2 M6 DM2 DM6 M5 DM2 DM6 K5
Focus Applications
Flyback, Flyback,
Half/full bridge Half/full bridge Half/full bridge Half/full bridge ZVS,
PFC/LLC PFC/LLC high Hi-end-power PFC
topologies, ZVS, LLC high topologies, ZVS, LLC high efficiency Flyback topology
resonant efficiency and hard switching
ZVS, LLC efficiency LLC topologies LED driver, LED
converter – resonant topologies
Solar, Server, topologies High power level High power level lighting, auxiliary
Charger converter – Solar, Server,
Telecom SMPS Solar, Server, Solar, Server, Solar, Server, SMPS
adapters Led Charger Telecom SMPS
Telecom SMPS Telecom SMPS Telecom SMPS
lighting adaptersMDmeshTM DM2:
The fast recovery diode Super-Junction MOSFET family 15
Complete Product Portfolio
The FAST Solution for HV MOSFET
• The most complete series of fast diode
HV MOSFET ( 500V - 600V - 650V)
• Targeted for ZVS & LLC Bridge
topologies
• Improved intrinsic diode reverse
recovery time: lower Trr, Qrr, Irrm and
better softness
• Higher dv/dt capabilityMDmeshTM DM2:
a good solution on motor control applications 16
MDmeshTM DM2: fast recovery diode solution at 600V
MOSFET vs IGBT
The ideal switch to boost efficiency
• Best Silicon performances up to 100W
• Enables higher energy efficiency label
on fridge Compressor
• Multiple package options
(Discrete and Module)
IGBT solution
MOSFET solutionMDmeshTM M6:
The latest step-up Super-Junction MOSFET family 17
600V - 650V - 700V MDmeshTM M6: the right MOSFET for high efficiency topologies
The ideal switch to boost efficiency
• The latest series for HV MOSFET (600V
- 650V - 700V)
• Targeted for ZVS & LLC Bridge
topologies
• Improved efficiency at light load
conditions
Power Telecom Solar
Management Power650V SiC MOSFETs range
18
The real boost for efficient designs
Lower losses, Higher efficiency, Reduced footprint: A breakthrough in High Voltage converters
650V SiC MOSFETs @ st.com Key Features
VDS [V] RDS-ON [Ω] Id [A] Package CPN
• Lead to new technology platform with awesome Figure Of Merit
SCTH35N65G2V-7
HiP247,
0.045 45
H2PAK–7
SCTH35N65G2V-7AG • Outstanding system efficiency and reduced cooling requirements
SCTW35N65G2V (*)
• Very low on-state resistance
650 SCTW90N65G2V • 200oC maximum junction temperature
0.018 110 HiP247, H2PAK–7 SCTH90N65G2V-7
• Very fast and robust intrinsic body diode
0.020 95 H2PAK-7 SCTH100N65G2-7AG • Industrial and Automotive Grade qualified
0.020 100 HiP247 SCTW100N65G2AG
Note * : Under Development
AG: Automotive Grade Typical Applications
RDS-ON , typical at 25ºC
• Charger Stations and On Board Chargers
• PFC - SMPS for Industrial, Telecom & Class-D Audio Amplifiers
H2PAK-7L HiP247 LL HiP247-4L • Traction inverters in HEV and BEV
• HiP-247: TJ max = 200°C • Motor Drives
• HiP247-4L, with kelvin source: coming soon
• H2PAK-7L, SMD with kelvin source: TJ max = 175°C • DC-DC converters1200V SiC MOSFETs range
19
The real boost for efficient designs
Lower losses, Higher efficiency, Reduced footprint: A breakthrough in High Voltage converters
1200V SiC MOSFETs @ st.com
VDS [V] RDS-ON [Ω] Id [A] Package CPN
0.500 12 HiP247 SCT10N120 Key Features
SCT10N120AG
0.170 20 HiP247, SCT20N120 • Lead to new technology platform with awesome Figure Of Merit
HiP247 LL SCT20N120AG
SCTWA20N120
• Outstanding system efficiency and reduced cooling requirements
1200 • Very low on-state resistance
0.080 45 HiP247, SCT30N120
HiP247 LL SCTWA30N120 • 200oC maximum junction temperature
0.052 65 HiP247, SCT50N120 • Very fast and robust intrinsic body diode
HiPAK LL SCTWA50N120
• Industrial and Automotive Grade qualified
HiP 247 SCTW70N120G2V*
0.025 90 HiP 247- 4L SCTWA70N120G2V-4*
H2PAK-7L SCTH70N120G2V-7*
Typical Applications
0.03 80 HiP247 SCTW100N120G2AG*
H2PAK-7L SCTH100N120G2-AG* • Charger Stations • Motor Drives
• PV Inverter • OBC
Note * : Under Development • UPS • Traction
AG: Automotive Grade
RDS-ON , typical at 25ºC • 3ph SMPS
H2PAK-7L HiP247 LL HiP247-4L
• HiP-247: TJ max = 200°C
• HiP247-4L, with kelvin source: coming soon
• H2PAK-7L, SMD with kelvin source: TJ max = 175°CSiC Power Mosfets
20
The Enabling Technology for Professional Appliances
Air Conditioning System
GROWTH DRIVERS
• Smaller form factor with high power density Dryers
• Higher system efficiency at high frequency
• Reduced size/cost of passive components
• Low power losses at high temperatures Refrigerators & Cold rooms
• Compact design and cost-effective system approach
• Simpler topologies
650V SiC MOSFETs
Professional Appliances 2 - 5 kW power domain
Air Purifier &Filtering
SiC
VDS [V] RDS-ON [Ω] Id [A] Package CPN
SCTH35N65G2V-7
HiP247,
0.045 45 SCTH35N65G2V-7AG
H2PAK–7 SCTW35N65G2V (*)
650 0.018 110 HiP247, H2PAK–7
SCTW90N65G2V
SCTH90N65G2V-7
0.020 95 H2PAK-7 SCTH100N65G2-7AG Washing Machine
Dish washer
0.020 100 HiP247 SCTW100N65G2AG
Note * : Under Development
AG: Automotive Grade Power Fan
RDS-ON , typical at 25ºCLV MOSFETs
21
STripFET evolution
H6/F6 technology
Standard trench
• BVDss -100÷80V F7 technology
• switching frequency up to 150KHz
Charge coupled trench
• BVDss 40÷120V*
• BVDss 60÷100V Logic Level*
• Wide SOA dedicate technology*
45V Coming in Sep ’19
• Switching frequency up to 250KHz
40V Coming in Dec ’19
• Soft switching & higher current capability
30V Coming in Q1 ‘20
• Optimized soft body-diode F8 technology
• EMI reduction 100V Coming in Q1 ‘20
• RDS(on) x Area ~ -30% Vs F6 2nd gen charge coupled trench
• BVDss 30÷150V
• Tailored for high switching frequency >500KHz
• Extremely high power density
• RDS(on) x Area ~ -40% Vs F7
AG qualified AG compliant *Technology not yet in full production
2016 Power Consumption 2019
TodayLV MOSFETs
22
STripFET F8 programs
BVDss Best RDS(on)
# lines # PNs Timing Industrial Qualification
[V] in PowerFLAT 5x6
30 8 17LV MOSFETs 23
Applications STripFET F8
• Power Tools
• SMPS
• Fork Lifts
• Adapter/Battery Charger
• Electric Light
• UPS
Transportation
• Solar Inverter
• Telecom and Servers
• Lighting/Display
Features Benefits
• Lower RDS(on) x Area (-40% Vs. F7) • Reduced conduction power losses
• Extremely Low Qg/Qgd • Reduced switching losses and passive sizes
• Qrr & Soft switching F7 like • Reduced noise immunity
• Extremely low thermal resistance • Improved current capability and power dissipation
• Low EMI & turn on losses
• Extended package offer to enhance silicon performances
20W 3000W
3000W
Under developmentLV MOSFETs
24
Package Roadmap
Power rating
PowerSO-10TM
H2PAK-7
D2PAK TO-LL
H2PAK-2
DPAK
LFPAK 5x6
PowerFLATTM 5x6
PowerFLATTM 5x6 DSC
SOT223
LFPAK 3.3x3.3 *
SO-8 PowerFLATTM 5X6 d.i. LFPAK 8x8 *
PowerFLATTM 3.3x3.3
SOT23-6L
PowerFLATTM 2x2
SOT23-3L
Production Coming ...
* Under feasibility studyLV MOSFETs 25
F7 vs. F8 technologies in motor control application
STL260N4LF7 (short circuit) STL320N4F8 (short circuit)
35 V
27 V
STL320N4LF8 shows overall better performance:
Higher efficiency in the whole current range
Lower Vds spike during short circuit event
Regular blocked rotor waveforms, without switching noiseIFAV
ST 二极管技术及产品简介 26
针对空调PFC，
Power Schottky diodes
600V15A/30A/
60A
Ultrafast bipolar rectifiers
Field-effect
rectifiers
SiC diodes
Signal Schottky
diodes VRRMST 二极管技术及产品简介 27
AC Series Packages :
TO-220AB : T
STTH xx AC yy C zz TO-220FP : FP
TO-247 : W
• Blank: single diode TO-247LL : WL
Bipolar Current AC series Voltage
• C: dual-diode with Package TO-3P : P
diode (from 15A to 60A) (600V)
common cathode TO-3PF : PF
AC systems power mapping:
Primary PFC rectification diode
current ratings
60A
STTH60AC06CP
STTH60AC06CPF
STTH60AC06CW
30A
STTH30AC06CP
STTH30AC06CPF
15A STTH30AC06CWL
STTH15AC06CT
STTH15AC06CFP
1kW 1.5kW 2kW
AC system Output PowerST 二极管技术及产品简介 28
特点
VF 低正向导通压降VF，有效减小损耗，减小二极管温升
Qrr 反向恢复电荷Qrr, 更小的恢复损耗
IR 低反向漏电流，更高可靠性
Tj 最大耐175度结温SiC
SiC diodes
29
Si
Towards Highly Demanding Markets
Smart Industry Smart Home & City Smart Driving
APPLICATIONS
Factory Automation EV & HEV
UPS Telecom Base station DC/DC converters
Renewable Energy Servers OBC, Traction InvertersSiC
650V SiC Diode Portfolio
30
Si
2018 Releases
SiC Diodes in new packages
TO247 TO-220 TO-220I D2PAK D²PAK HV DPAK PowerFLAT™ 8x8 HV
TO-247 NC
Low VF High Surge Capability
40A STPSC40065C
20A STPSC20065 STPSC20H065C
STPSC16H065A D²PAK HV
16A STPSC16H065C
IFAV (A)
STPSC12H065
12A STPSC12065
STPSC12H065C
10A STPSC10065 STPSC10H065
STPSC8H065
8A STPSC8065 PowerFLAT8x8
STPSC8H065C K
6A STPSC6H065
A A NC NC
4A STPSC4H065
650VST Thyristor: Triac, AC Switch, SCR 31
Rank # 1 with pro-active leadership
Key Benefits of
using ST
Deliver new solutions for emerging Served segments:
applications: smart grid, digital Automotive, Home Appliance,
appliance, vehicle / bike electrification Power Management, Industrial
Contribute to robust applications: Customers development support
High Speed Commutation (x2) with our committed Application &
High EFT noise immunity (x5) System lab’s
Extended product range:
Bring design flexibility with Auto / Medical grade technology
largest catalog and wide tools set Up to 1400V and 80A
SMD and isolated packages
STMicroelectronics - Thyristor & AC SwitchesIN THE CONNECTED HOME 32
ST’S THYRISTORS FOR RESIDENTIAL AC LOAD
Roof Detector
Light Dimmer Sensitive SCR
High Dimming Range P0102BL
BTA12-600TW Water Heater
Thermal Perf.
Thermostat T3050H-6I
Turn-off Perf.
ACST830-8FP Rolling Shutter
Compact Designs
Irrigation
T1235T-8G
Overvoltage Prot.
ACS108-8SN
Smart Plug
Compactness Room Heater
T3035H-6G
Thermal Perf.
T3035H-6T
STMicroelectronics - Thyristor & AC
SwitchesThyristor & AC Switch Product Portfolio 33
Over voltage proof AC Switch
Application Robustness
(ACS/ACST)
High Voltage H Series
Triacs ---- (TxxH)
T Series
(TxxT)
Standard & Snubberless™
(BTA/BTB/Txx/Zxx)
Thermal Efficiency
Bidirectional Conducting
The most complete VDRM : 600 V to 1200 V
ITRMS : 0.2 A to 40 A
TRIAC portfolio IGT : 3 mA to 50 mA
TJ : 125 oC and 150 oC
STMicroelectronics - Thyristor & AC SwitchesThyristor & AC Switch Product Portfolio 34
VDRM
1200
High Temperature
(TNxxH)
800
Standard Gate
(TYN, TXN, TN & BTW)
600
Sensitive Gate
(X, P, TS)
IT
0.25 12 80
Bidirectional Blocking
The most innovative VDRM : 400 V to 1200 V
ITRMS : 0.25 A to 80 A
SCR portfolio IGT : 5 µA to 50 mA
TJ : 125 oC and 150 oC
STMicroelectronics - Thyristor & AC SwitchesWEB support 35
ST App finder
MOSFET
IGBT
Brand new finders, to allow an easier and faster recollect of the most important
information about any power transistor in ST’s portfolio.Thank You！
You can also read
