Ticker: VLS.L Kick-starting adoption September 2014
Important notice
This company presentation (the “Presentation”) has been prepared by its advisors assume no obligation to update any forward-looking
Velocys plc (“Company”). The Presentation has not been reviewed or statements or to conform these forward-looking statements to the
registered with, or approved by, any public authority, stock exchange Company’s actual results. Investors are advised, however, to inform
or regulated market place. themselves about any further public disclosures made by the
Company, such as filings made with the London Stock Exchange or
The Company makes no representation or warranty (whether express press releases.
or implied) as to the correctness or completeness of the information
contained herein, and neither the Company nor any of its subsidiaries, This Presentation has been prepared for information purposes only.
directors, employees or advisors assume any liability connected to the This Presentation does not constitute any solicitation for any offer to
Presentation and/or the statements set out herein. This presentation is purchase or subscribe any securities and is not an offer or invitation to
not and does not purport to be complete in any way. sell or issue securities for sale in any jurisdiction, including the United
States. Distribution of the Presentation in or into any jurisdiction where
The information included in this Presentation may contain certain such distribution may be unlawful, is prohibited.
forward-looking statements relating to the business, financial
performance and results of the Company and/or the industry in which it Neither the issue nor delivery of this Presentation shall under any
operates. Forward-looking statements concern future circumstances circumstance create any implication that the information contained
and results and other statements that are not historical facts, herein is correct as of any time subsequent to the date hereof or that
sometimes identified by the words “believes”, expects”, “predicts”, the affairs of the Company have not since changed, and the Company
“intends”, “projects”, “plans”, “estimates”, “aims”, “foresees”, does not intend, and does not assume any obligation, to update or
“anticipates”, “targets”, and similar expressions. The forward-looking correct any information included in this Presentation.
statements contained in this Presentation, including assumptions,
opinions and views of the Company or cited from third party sources This Presentation is subject to English law, and any dispute arising in
are solely opinions and forecasts which are subject to risks, respect of this Presentation is subject to the exclusive jurisdiction of
uncertainties and other factors that may cause actual events to differ English courts.
materially from any anticipated development. None of the Company or
its advisors or any of their parent or subsidiary undertakings or any
such person’s affiliates, officers or employees provides any assurance
that the assumptions underlying such forward-looking statements are
free from errors nor does any of them accept any responsibility for the
future accuracy of the opinions expressed in this Presentation or the
actual occurrence of the forecasted developments. The Company and
2
Velocys
Leader in smaller scale GTL
• Leader in smaller scale gas-to-liquids technology
— 15 years and >$300 million invested in product development
— Exhaustive global patent protection (>7,500 granted GTL patent claims)
• First class partners offering a complete GTL solution
— Haldor Topsøe, Ventech, Hatch, Toyo, Mourik, SGS, Shiloh
• Commercial roll-out underway
Solena GreenSky London
GTL JV Ashtabula GTL
• Well capitalised with strong resources
— Commercial center in Houston, Texas; technical centers near Columbus,
Ohio and Oxford, UK
— Permanent pilot plant in operation
3
The gas-to-liquids (GTL) process
Chemical conversion of gas to refined products
Reforming Fischer-Tropsch (FT) Hydro-processing
Natural gas
Syncrude Clean synthetic
Syngas
fuels & chemicals
(carbon monoxide (synthetic (diesel, jet fuel,
+ hydrogen) crude oil) lubricants etc.)
e.g. e.g.
LNG / CNG = physical compression.
Product remains natural gas Smaller scale GTL:
gas-based mini-
GTL = chemical conversion into refinery
refined products (petroleum
equivalent)
4
Market environment
Ripe for smaller scale GTL
• Shale revolution ushering age
of gas surplus
• Growing demand for liquid
fuels, especially diesel and jet
• Long-term stability of gas-oil
arbitrage expected
• Decentralized production
underpinned by poor
transportability of gas
• Environmental benefits e.g. lower emissions, flare elimination and
carbon footprint reduction (bio-to-liquids)
• Strong location-specific economic and strategic factors
• Shell and Sasol plants in Qatar showcase viability of GTL
5
Large-scale economics at smaller scales
Velocys enables smaller plants
Velocys FT reactor
Conventional slurry reactor
Velocys microchannel reactor
$k/bpd capacity
Cost advantage
Conventional FT Reactor
Velocys microchannels − cost range
0 2000 4000 6000 8000 10000 12000 14000
2,000 6,000 10,000 15,000
Plant capacity (bpd)
Conventional FT e.g. Sasol
Microchannel technology offers strong benefits at smaller scales
6
GTL for the mainstream of the industry
Velocys modular GTL
• Broader range of sites
— 1,500-15,000 barrels per day
— Suitable for remote locations
• Lower risk
— Smaller investments
— Less risk of cost over-runs
• Reduced costs
— Standardised modules and reactors
— Possible integration with existing facilities
• Easier to execute and expand
— Quicker plant construction (18-24 months) 1,400 bpd FT process unit
— Easier to permit, supply and build designed by Ventech Engineers
90 ft L x 46 ft H x ~40 ft W
— Additional trains can be added later
7
Many applications
From low-value gas to high-value fungible products
• Source of new demand for abundant shale
gas in North America
• Economic route to market for stranded
gas
• Solution to problem of associated gas
• Valuable products for existing and new
applications
— Ultra low-sulfur diesel (70 cetane) & jet
— Waxes, lubricants and solvents
• Not just gas: also biomass and coal
8
Huge market opportunity
Shale, associated and stranded gas
• Much shale gas is distributed scale / remote. Estimated at as much as 3,300
TCF in North America and over 6,500 TCF worldwide
• 4.9 TCF of gas flared every year + 6.5 TCF reinjected to avoid flaring alone
• Only 5% of the world’s conventional stranded gas fields can
be monetised by large scale GTL / LNG; distributed
Conventional 4 >50 (in tcf)
scale could unlock up to 50% of remaining fields LNG / GTL
73 5-50
337 1-5
• Distributed scale GTL opportunity size Velocys 0.5-1
347
GTL
— Unconventional gas*: 18 million bpd 719 0.25-0.5
1,043 0.1-0.25
— Associated gas: 2.7 million bpd
3,922 gas fields 25 million bpd Distribution of conv. gas fields outside US
* Assumes monetisation over 100 yrs
9
Velocys enables winning economics
Taking the plant to the opportunity
$150
Premium from sale of diesel
Oil (WTI) Increased
OPEX product value
Costs & proceeds ($/barrel of liquid
$125 if specialties
Depreciation e.g. lubricants /
Natural gas waxes or if
$100 producing
refined products
Co-location reduces
in remote
products)
capex & opex e.g.
locations
downstream
$75
Lower gas
costs if
stranded or
$50 associated Added value
from unlocking
restrained oil
$25 production
$0
Costs of Velocys enabled Proceeds from production of
GTL plant liquid fuels
10Complete GTL solution
Together with world-class partners
Catalyst supply partners
FT reactor not yet announced
and catalyst
suppliers Customer’s choice.
Recommended partners:
Smaller
Engineering
Technology scale Procurement
licensors &
GTL - Construction
onshore
Field
services
Catalyst change out Reactor inspection
11JV with Waste Management, NRG Energy and Ventech
Monetising renewable gas with natural gas through GTL
• WM (Fortune 500)
— North America’s leading provider of
comprehensive waste management
services
— Role: renewable gas and certain locations
• NRG (Fortune 500)
— Owns largest independent power generation
portfolio in US
— Role: project development and management
• Ventech
— Global leader in design and construction of
modular refineries
— Role: engineering, fabrication, EPC
12First JV project ‒ Go-ahead received
Adjacent to WM East Oak landfill in Oklahoma City, USA
Existing pilot plant and lab
Site of GTL plant
Landfill
• Final Investment Decision made to proceed (July 2014):
— Upfront engineering complete; permits received; all major contracts
signed; Velocys technology supply at market rates
— Construction begun; fully operationalOther public-domain commercial projects announced
Pipeline growing and progressing
Solena GreenSky London
Ashtabula GTL Red Rock Biofuels
• 2,800 bpd plant supplied • 1,100 bpd biomass-to- • 2,500 bpd waste-to-liquids
from Marcellus; future liquids plant in Oregon, plant at former Coryton oil
expansion planned to USA refinery in Thurrock,
10,000 bpd Essex, UK
• FEED study complete
• Pre-FEED complete, now
• Initial engineering entering FEED
complete; permits received • DOD decision on $70
million construction
grant expected shortly • BA signed offtake for all jet
• FID expected 2015 fuel from facility (worth
$500m)
14Summary
Right product, right place, right time
• The time has come for smaller scale GTL
— Gas arbitrage, shale gas reserves, flare gas, stranded gas, remote
locations, energy security, cleaner fuels legislation
• Huge market opportunity
— 25 million bpd of synthetic fuel could be made by distributed scale GTL
• Velocys: leaders in advanced smaller scale GTL technology
— 15 years and >$300 million invested in its unique innovative technology
— Exhaustive global patent protection (>7,500 granted GTL claims)
— First class partners
• Commercialisation underway
— Waste Management JV, Ashtabula, GreenSky/BA, Red Rock Biofuels
15Changing the way fuels are made
