WANDERLUST
TECHNICAL
DATA
en
D
2021
TECHNICAL DATA
5.99 m
5.41 m
ROADCAMP ROADCAMP R 2WIN
DIMENSIONS in mm
Length (approx.) 5.413 5.413 5.998
Width (approx.) 2.050 2.050 2.050
Height (approx.) 2.580 2.580 2.580
Wheelbase (approx.) 3.450 3.450 4.035
Interior height (approx.) 1.905 1.905 1.905
WEIGHT AND LOAD CAPACITY in kg
Gross vehicle weight (as standard) 3.300 3.300 3.300
Mass in running order (approx.)* 2.720 2.720 2.820
Load capacity with 20 l water (approx.) 580 580 480
Towing capacity unbraked / braked** 750 / 2.500** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
ON-BOARD TECHNICAL EQUIPMENT
Heater Truma Combi 4 Truma Combi 4 Truma Combi 4
Boiler volume in l (approx.) 10 10 10
Fresh water tank in l (approx.) 100 100 100
Wastewater tank in l (approx.) 92 92 92
Gas cylinder box for (kg) 2 x 11 2 x 11 2 x 11
Battery charger in A 18 18 18
Battery 12 V / 95 Ah 12 V / 95 Ah 12 V / 95 Ah
230 V socket 2 2 2
Refrigerator in l (capacity / of which freezer) approx. 100 / 8 approx. 100 / 8 approx. 80 / 5
Absorber / Compressor Compressor Compressor Absorber
LIVING AREA FITTINGS AND FEATURES
Plastic insulating windows (blinds) 4 4 5
Midi Heki with Blackout blinds and flyscreen - 1 1
Miniheki with Blackout blinds and flyscreen 2 - 1
Seats / three-point safety belts 4/4 4/4 4/4
Beds 2 (+1 optional) 2 (+1 optional) 2 (+1 optional)
Rear bed / single bed in mm (approx.) 1.960 x 1.320/1.170 1.960 x 1.320/1.170 1.960 x 1.480/1.420
Bed traverse to sliding door in mm (approx.. 1.960 x 700 1.960 x 700 1.960 x 700
as standard)
Additional bed in the rear (approx.. as standard) - - -
22WIN S 2WIN R P2 RELAX ROADSTAR 600L
5.998 5.998 5.998 5.998
2.050 2.050 2.050 2.050
2.580 2.580 2.580 2.580
4.035 4.035 4.035 4.035
1.905 1.905 1.905 1.905
3.300 3.300 3.300 3.300
2.820 2.820 2.820 2.820
480 480 480 480
750 / 2.500** 750 / 2.500** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
Truma Combi 4 Truma Combi 4 Truma Combi 4 Truma Combi 4
10 10 10 10
100 100 100 100
92 92 92 92
2 x 11 2 x 11 2 x 11 2 x 11
18 18 18 18
12 V / 95 Ah 12 V / 95 Ah 12 V / 95 Ah 12 V / 95 Ah
2 2 2 (+1x 12V) 2
approx. 100 / 8 approx. 84 / 6 approx. 75 / 10 approx. 100 / 8
Compressor Compressor Compressor Compressor
5 5 4 6
1 1 1 1
1 1 1 1
4/4 4/4 2/2 4/4
2 (+1 optional) 2 (+1 optional) 2 2 (+1 optional)
1.960 x 1.550/1.420 1.960 x 1.570/1.450 1.950 x 1.600 (1.900 x 1.400 across) 1.930/1.800 x 829
1.960 x 700 1.960 x 700 - 1.960 x 700
- - - -
3TECHNICAL DATA
6.36 m
ROADSTAR 640 DK ROADCRUISER ROADCRUISER B
DIMENSIONS in mm
Length (approx.) 6.358 6.358 6.358
Width (approx.) 2.050 2.050 2.050
Height (approx.) 2.580 2.580 2.580
Wheelbase (approx.) 4.035 4.035 4.035
Interior height (approx.) 1.905 1.905 1.905
WEIGHT AND LOAD CAPACITY in kg
Gross vehicle weight (as standard) 3.500 3.500 3.500
Mass in running order (approx.)* 2.970 2.970 2.970
Load capacity with 20 l water (approx.) 530 530 530
Towing capacity unbraked / braked** 750 / 2.500** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
ON-BOARD TECHNICAL EQUIPMENT
Heater Truma Combi 4 Truma Combi 4 Truma Combi 4
Boiler volume in l (approx.) 10 10 10
Freshwater tank in l (approx.) 100 100 100
Wastewater tank in l (approx.) 92 92 92
Gas cylinder box for (kg) 2 x 11 2 x 11 2 x 11
Battery charger in A 18 18 18
Battery 12 V / 95 Ah 12 V / 95 Ah 12 V / 95 Ah
230 V socket 2 2 2
Fridge in l (content/of which freezer) approx. 84 / 6 approx. 84 / 6 approx. 84 / 6
Absorber / Compressor Compressor Compressor Compressor
LIVING AREA FITTINGS AND FEATURES
Plastic insulating windows (blinds) 5 6 4
Midi Heki with blackout blinds and fly- 1 1 1
screen
Miniheki with blackout blinds and flyscreen 2 1 1
Seats / three-point safety belts 4/4 4/4 4/4
Beds 2 (+1 optional) 2 (+1 optional) 2 (+1 optional)
Rear bed/Single bed in mm (approx.) 1.960 x 1.510/1.460 1.980/1.930 x 1.900 1.903/1.769 x 1.900
Bed traverse to sliding door in mm (approx.. 1.960 x 700 1.960 x 700 1.960 x 700
as standard)
Additional bed in the rear (approx.. as stan- - - -
dard)
4ROADCRUISER EVOLUTION ROADCRUISER REVOLUTION ROADCRUISER XL
6.358 6.358 6.358
2.050 2.050 2.050
2.580 2.830 2.830
4.035 4.035 4.035
1.905 2.130 2.130
3.500 3.500 3.500
2.970 3.060 3.060
530 440 440
750 / 2.500** 750 / 3.000 750 / 3.000
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
Truma Combi 6 D Truma Combi 4 Truma Combi 4
10 10 10
100 100 100
92 92 92
1 x 2.8 2 x 11 2 x 11
18 18 18
12 V / 95 Ah 12 V / 95 Ah 12 V / 95 Ah
2 2 2
approx. 84 / 6 approx. 84 / 6 approx. 84 / 6
Compressor Compressor Compressor
6 6 6
1 1 1
1 1 1
4/4 4/4 4/4
2 (+1/+2 optional) 2 (+1/+2 optional) 2 (+1 optional)
1.980/1.930 x 1.900 1.980/1.930 x 1.900 1.980/2.080 x 1.900
1.960 x 700 1.960 x 700 1.960 x 700
1.900 x 1.830 1.800 x 1.600 -
5STANDARD EQUIPMENT
BASIC VEHICLE KITCHEN
Fiat Ducato, Citroën Jumper and Peugeot Boxer 3.3/3.5 t Light or 3.5 t Maxi/ Worktop with robust surface and impact-resistant front edge
Heavy Chassis Extra-wide roller bearing-mount kitchen drawers for additional storage
4-cylinder turbo diesel, Euro 6d-Temp, soot particle filter Fold-away worktop extension on the entrance side (layout dependent)
Driver's airbag Refrigerator with integrated freezer compartment
Electronic vehicle immobiliser, remote central locking 2-burner hob with piezo igniter and glass top for additional surface space,
Tyre pressure sensors (not available on Fiat) and splash guard
Disc brakes front and rear, power steering, rev counter Stainless steel sink with glass cover/cutting board
Height-adjustable headlamps
3-point safety belt WASHROOM
Tyres: 215/70R15C; on Heavy/Maxi 225/75R16C Various washroom solutions depending on lay-out to meet every possible
need
Electric windows on driver's and passenger side
Spacious shower with removable shower screen (central washroom
Driver's cab interior lighting design)
Headlamps with integrated daytime running light Partition blind that can also serve as room divider (central washroom
design)
DRIVER'S CAB Hand-held shower head in chrome look
Comfortable swivel driver's seat and front passenger seat, armrests both Single-lever mixer tap with high-grade ceramic sealing
sides Swivel toilet for enhanced comfort
Height-adjustable driver's seat
Spacious overhead storage in the driver's cab, P2 and Trenta with open cab SLEEPING
canopy and with an extra sense of spaciousness
Generously sized rear beds
Central cup holder
Extension of the rear stowage compartment through stackable rear beds
Extra storage space below the rear beds
FITTINGS AND FEATURES Spacious overhead storage cabinets with ample storage space
Softlock close assist sliding door Additional open shelves below the overhead storage cabinets
Wide, electrically retractable and extendable step with acoustic warning
Courtesy lighting TECHNICAL FEATURES
Insect protection sliding door Convenient drainage valve for fresh-water tank
Each hinged window has a flyscreen blind, blackout blind and hinged mount Two service openings in the fresh-water tank for easy cleaning
Optimised multi-layer roof insulation (Styrodur approx. 20 mm, PE foam Service hatch for cassette toilet with practical magnetic holder
approx. 15-20 mm) Powerful Truma Combi heater with 10 l boiler
Optimised floor insulation with closed cell foam (RTM foam approx. 15 mm) Enjoyable sleeping comfort thanks to additional warm air outlet in the rear
Wall insulation with flexible insulation mats (PE foam approx. 10-20 mm) door area
Mini Heki and Midi Heki skylights installed with GRP adapter for optimum Water supply via reliable pump system
fit and sealing Large-sized gas supply capacity in easily accessible gas box
High-end Midi-Heki above the seating area 230 V CEE external socket with circuit breaker
Clear glass Mini Heki in sleeping area (not available in Roadcamp) Electrical control centre easily accessible under the driver's seat
Two additional floor storage compartments in seating area Powerful 95 AH leisure Battery
Mountable in rear stowage compartment Multifunction panel, easy to operate via the entrance door
Adjustable spotlights on rail system under the ceiling cabinets ensure
optimum lighting
LIVING AREA
Living area furniture with easy-care surfaces
Driver's cab seats fully integrable into the living area seating
Some layouts offer generous storage space in the bench seat
Fittings and roller bearing mounts in solid metal design, household quality
Large ceiling cabinets offer generous storage
Practical bin bag mounted with push-buttons in entrance area (lay-out depen-
dent)
6CITROEN / PEUGEOT
BASIS CITROEN JUMPER BASIS 2.2l BlueHDI 88 KW/120 HP 2.2l BlueHDI 102 KW/140 2.2l BlueHDI 121 KW/165
PEUGEOT BOXER HP HP
ROADCAMP 3.3 t
ROADCAMP R 3.3 t
2WIN 3.3 t
2WIN S 3.3 t
2WIN R 3.3 t
P2 RELAX 3.3 t
ROADSTAR 600 L 3.3 t
ROADSTAR 640 DK 3.5 t (Light)
ROADCRUISER 3.5 t (Light)
ROADCRUISER B 3.5 t (Light)
ROADCRUISER EVOLUTION 3.5 t (Light)
ROADCRUISER EVOLUTION 3.5 t (Heavy)
ROADCRUISER XL 3.5 t (Heavy)
FIAT
2.3l Multijet 88 2.3l Multijet 102 2.3l Multijet 118 2.3l Multijet 131
BASE FIAT DUCATO KW/120 HP KW/140 HP KW/160 HP KW/178 HP
ROADCAMP 3.3 t
Roadcamp R 3.3 t
2WIN 3.3 t
2WIN S 3.3 t
2WIN R 3.3 t
P2 RELAX 3.3 t
ROADSTAR 600 L 3.3 t
ROADSTAR 640 DK 3.5 t (Light)
ROADCRUISER 3.5 t (Light)
ROADCRUISER B 3.5 t (Light)
ROADCRUISER EVOLUTION 3.5 t (Light)
ROADCRUISER REVOLUTION 3.5 t (Maxi)
ROADCRUISER XL 3.5 t (Maxi)
CHASSIS EXTRA CHARGES Additional weight
Citroen / Peugeot 3.3 Light to 3.5 Light
Fiat 3.3 Light to 3.5 Light
Citroen / Peugeot 3,3 Light auf 3,5 Heavy 40 kg
Fiat (not available in Roadcamp/Roadcamp R) 3.3 Light on 3.5 Maxi 40 kg
Citroen / Peugeot (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
Fiat (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
7PROMOTION PACKAGES
D-LINE ALL-IN PACKAGE +KG
ESP, ABS, ASR, Hill-Holder -
90 l diesel tank
Fully equivalent spare wheel 24
Climate control in driver's cab, manual 18
Front passenger airbag 3
Electrically operated and heated door mirrors 2
Height-adjustable front passenger seat 1
Driver's cab seat covers same as in living space (not available in P2 Relax) -
Pleated blackout blinds in driver's cab -
Dashboard with chrome surrounds -
25 A charging converter -
Sum 48
8OPTIONAL EXTRAS FOR FITTINGS
ROADCRUISER REVOLUTION
ROADCRUISER EVOLUTION
ROADSTAR 640 DK
ROADCRUISER XL
ROADCRUISER B
ROADSTAR 600L
ROADCRUISER
DESCRIPTION
ROADCAMP R
ROADCAMP
OPTIONAL
P2 RELAX
2WIN R
2WIN S
2WIN
+ KG
Basic version (Calva Apple wood decor) - s s s s s - s s s s s s s
Elegance design (Dakota Oak wood decor with ambient flap) - - o o o o s o o o o o o o
Breeze interior (Basic standard interior, no extra charge) - s s s s s o s s s s s s s
Marais interior (Elegance standard interior, no extra cost) - o o o o o s o o o o o o o
Lime interior as alternative - o o o o o o o o o o o o o
Silver interior as alternative - o o o o o o o o o o o o o
Alternative tabletop 5 s o o o o - o o o o o o o
Bed extension for seating area incl. alternative tabletop 9 o o o o o - o o o o o o o
7-zone premium cold foam mattresses 1 o o o o o o o o o o - - o
Pop-top roof in white 127 o o o o o - o o o o o - -
Pop-top roof in vehicle body colour 127 o o o o o - o o o o o - -
Additional bed in the rear 22 - - - - - - - - - - o o -
2. Control panel for height-adjustable bed - - - - - - - - - - - o o -
Compressor fridge 100 / 8 (capacity in l / of which freezer) - s s - s - - s - - - - - -
Absorber refrigerator 80 / 5 (capacity in l / of which freezer) - - - s - - - - - - - - - -
Slimtower absorber refrigerator 133 / 5 (capacity in l / of which freezer) - - - - - o - - - o - - o -
Thetfort compressor refrigerator 84 / 6 (capacity in l / of which freezer) - - - - - s - - s s s s s s
Compressor refrigerator 75/10 (capacity in l / of which freezer) - - - - - - s - - - - - - -
Additional 95 Ah on-board battery 27 o o o o o o o o o o o o o
Electric package for body unit (230 V, USB sockets) 1 o o o o o s o o o o o o o
Electric package II (USB socket, rear storage area lighting) 3 o o o o o o o o o o o o o
12 V socket in rear stowage compartment 1 o o o o o o o o o o o o o
Rear storage area lighting 2 o o o o o o o o o o o o o
Solar power system pre-installation (not combinable with pop-top roof) 2 o o o o o o o o o o o o o
Loudspeakers included in the interior fittings (only in combination 2 o o o o o - o o o o o o o
with the interiors electrics package )
SAT system pre-installation (not combinable with pop-top roof) 2 o o o o o o o o o o o o o
Flat-screen pre-installation (screen mount) 5 o o o o o - o o o o o o o
Truma Combi heater 6E (gas/electric) (not in combination with CP Plus) 2 o o o o o o o o o o - o o
Truma diesel heater 4 o o o o o o o o o o s o o
Truma CP Plus control unit - o o o o o o o o o o o o o
Gas – Duo Control CS 2 o o o o o o o o o o - o o
Winter package* 15 o o o o o o o o o o - o o
Wastewater tank insulated 2 o o o o o o o o o o - o o
Insulation mat for rear doors 2 o o o o o o o o o o o o o
Framed windows instead of frameless windows o o o o o o o o o o o o o
Window - portholes 3 - - o o o o o - o o o o o
Window - sliding window at the rear on right (instead of hinged 4 - - o o - o o - o o o o o
window)
Windows - sliding window at the rear on right 6 o o - - o - - - - - - - -
Window - Toilet 2 o O o o O O O O O o O O O
Window - at the rear on left (hinged) 5 - - o o s - s s s s s s s
Windows - Rear doors with windows 8 s s s s s s s s s o s s s
Windows - rear doors without window -12 - - - - - - o - o s o o o
Rear bumper painted in same colour as vehicle - o o o o o o o o o o o o o
Body colour painted front bumper (for Maxi/Heavy and fog lights; - o o o o o o o o o o o o o
special colours, Titian Red and Imperial Blue)
Safe for floor storage compartment 10 o o o o o - o o o o o o o
Tie-down system in rear stowage compartment 5 o o o o o o o o o o o o o
Isofix 4 - - - r - - - - - o o o o
Fully electric sliding door 8 o o o o o o o o o o o o o
* Winter package: insulated wastewater tank, with heatable Tank and wastewater pipes, insulated mats for the rear doors
o Available option O Required option - not available s as standard r Only on left-hand side
9TECHNICAL DATA
6.36 m
5.99 m
Trenta 600 Trenta 640
DIMENSIONS in mm
Length (approx.) 5.998 6.358
Width (approx.) 2.050 2.050
Height (approx.) 2.580 2.580
Wheelbase (approx.) 4.035 4.035
Interior height (approx.) 1.905 1.905
WEIGHT AND LOAD CAPACITY in kg
Gross vehicle weight (as standard) 3.300 3.500
Mass in running order (approx.)* 2.820 2.970
Load capacity with 20 l water (approx.) 480 530
Towing capacity unbraked / braked** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
ON-BOARD TECHNICAL EQUIPMENT
Heater Truma Combi 4 Truma Combi 4
Boiler volume in l (approx.) 10 10
Freshwater tank in l (approx.) 100 100
Wastewater tank in l (approx.) 92 92
Gas cylinder box for (kg) 2 x 11 2 x 11
Battery charger in A 18 18
Battery 12 V / 95 Ah 12 V / 95 Ah
230 V socket 2 2
Refrigerator in l (capacity / of which freezer) approx. 70 / 10 approx. 70 / 10
Absorber / Compressor Compressor Compressor
LIVING AREA FITTINGS AND FEATURES
Plastic insulating windows (blinds) 5 3 + 2 portholes
Midi Heki with blackout blinds and flyscreen 1 1
Miniheki with blackout blinds and flyscreen 1 1
Seats / three-point safety belts 4/4 4/4
Beds 2 (+1 optional) 2 (+1 optional)
Rear bed/Single bed in mm (approx.) 1.960/1.470 x 1.300 1.903/1.769 x 1.900
Bed traverse to sliding door in mm (approx.. 1.960 x 700 1.960 x 700
as standard)
Additional bed in the rear (approx.. as standard) - -
10PROMOTION PACKAGES
CITROEN / PEUGEOT
BASIS CITROEN JUMPER BASIS 2.2l BlueHDI 88 KW/120 HP 2.2l BlueHDI 102 KW/140 2.2l BlueHDI 121 KW/165
PEUGEOT BOXER HP HP
TRENTA 600 3.3 t
TRENTA 640 3.5 t (Light)
FIAT
2.3 l Multijet 88 2.3 l Multijet 102 2.3 l Multijet 118 2.3 l Multijet 131
BASE FIAT DUCATO
KW/120 HP KW/140 HP KW/160 HP KW/178 HP
TRENTA 600 3.3 t
TRENTA 640 3.5 t (Light)
CHASSIS EXTRA CHARGES Additional weight
Citroen / Peugeot 3.3 Light to 3.5 Light
Fiat 3.3 Light to 3.5 Light
Citroen / Peugeot 3.3 Light on 3.5 Heavy 40 kg
Fiat 3.3 Light on 3.5 Maxi 40 kg
Citroen / Peugeot (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
Fiat (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
In addition to the standard equipment in the D-Line, the Trenta also offers the following additional features:
Exclusively
ADDITIONAL OPTIONS FOR TRENTA for
Custom-designed Tiberino interior design with matching Pacco special cushions
Two-one overhead lockers underscore the contemporary design.
Unique open-plan interior with loads of headroom and freedom to move, like in a coach-built liner-type motorhome
Open cab canopy and additional backlit storage compartments
High-end upholstery in the seating area
High-grade wall panelling in the seating group and sleeping area (not available on Trenta 640) for an optimal living climate.
Unique light design - Ceiling cabinets with indirect lighting - Indirect lighting underneath the seating area - B- Especially powerful LED lighting tracks
in kitchen and seating area - Canopy with indirect lighting - Kitchen furniture with recessed indirect LED lighting
Powerful refrigerator Powerful compressor refrigerator - can be opened in both directions incl. removable freezer compartment
Slim Kitchen with contemporary design and work surface at optimal working height
Spacious washroom with sliding door and several mirrors
Elegant Trenta design with portholes (only available in Trenta 640) and matching laminate
11OPTIONAL EXTRAS FOR FITTINGS
DESCRIPTION
TRENTA 600
TRENTA 640
OPTIONAL
+ KG
Tiberino wood decor (as standard, no extra charge) – s s
Pacco interior (as standard, no extra charge) – s s
Alternative tabletop 5 o o
Bed extension for seating area incl. alternative tabletop 9 o o
7-zone premium cold foam mattresses 1 o o
Compressor refrigerator 70/10 (capacity in l / of which freezer) – s s
Additional 95 Ah on-board battery 27 o o
Electrics package for interior (230 V, USB sockets) 1 o o
Electric package II (USB socket, rear storage area lighting) 3 o o
12 V socket in rear stowage compartment 1 o o
Rear stowage area lighting 2 o o
Solar power system pre-installation (not combinable with pop-top roof) 2 o o
Loudspeakers included in the interior fittings (only in combination with the interiors electrics package ) 2 o o
SAT system pre-installation (not in combination with pop-top roof) 2 o o
Flat-screen pre-installation (screen mount) 5 o o
Truma Combi heater 6E (gas/electric) (not in combination with CP Plus) 2 o o
Truma diesel heater 4 o o
Truma CP Plus control unit – o o
Gas – Duo Control CS 2 o o
Winter package* 15 o o
Wastewater tank insulated 2 o o
Insulation mat for rear doors 2 o o
Framed windows (all windows will be replaced) - o o
Window - portholes (right, instead of hinged window, standard in Trenta 640) 3 o s
Windows – sliding window at the rear (instead of portholes or hinged windows) 4 o o
Window - Toilet 2 o o
Windows - Rear doors with windows 8 s o
Rear bumper painted in same colour as vehicle – o o
Front bumper painted in vehicle colour (for Maxi/Heavy and fog lights, special colours, Titian Red and Imperial Blue) – o o
Safe for floor storage compartment 10 o o
Tie-down system in rear stowage compartment 5 o o
Isofix (only on left-hand side) 4 o o
Fully electric sliding door 8 o o
* Winter package: insulated wastewater tank, with heatable Tank and wastewater pipes, insulated mats for the rear doors
o Available option O Required option - not available s as standard
TRENTA ALL-IN PACKAGE +KG
ESP, ABS, ASR, Hill-Holder –
90 l diesel tank
Fully equivalent spare wheel 24
Climate control in driver's cab, manual 18
Front passenger airbag 3
Electrically operated and heated door mirrors 2
Height-adjustable front passenger seat 1
Driver's cab seat covers same as in living space –
Pleated blackout blinds in driver's cab –
Dashboard with chrome surrounds –
25 A Power booster –
Sum 48
12DRIVING PLEASURE
13TECHNICAL DATA
6.36 m
5.99 m
5.41 m
SUMMIT 540 SUMMIT 600 SUMMIT 640
DIMENSIONS in mm
Length (approx.) 5.413 5.998 6.358
Width (approx.) 2.050 2.050 2.050
Height (approx.) 2.580 2.580 2.580
Wheelbase (approx.) 3.450 4.035 4.035
Interior height (approx.) 1.905 1.905 1.905
WEIGHT AND LOAD CAPACITY in kg
Gross vehicle weight (as standard) 3.300 3.300 3.500
Mass in running order (approx.)* 2.680 2.835 2.960
Load capacity with 20 l water (approx.)* 620 465 540
Towing capacity unbraked / braked** 750 / 2.500** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
ON-BOARD TECHNICAL EQUIPMENT
Heater Truma Combi 4 Truma Combi 4 Truma Combi 4
Boiler volume in l (approx.) 10 10 10
Freshwater tank in l (approx.) 85 100 100
Wastewater tank in l (approx.) 100 100 100
Gas cylinder box for (kg) 1 x 11 and 1 x 5 1 x 11 and 1 x 5 2 x 11
Battery charger in A 16 16 16
Battery 12V / 95 12V / 95 12V / 95
12/230 V sockets 2/1 2/1 2/1
Refrigerator in l (capacity / of which freezer) approx. 100 / 8 approx. 100 / 8 approx. 80 / 10
Absorber / Compressor Compressor Compressor Compressor
LIVING AREA FITTINGS AND FEATURES
Integrated framed insulating windows 4 (2x suspension mounted in rear) 5 (2x suspension mounted in rear) 4
(blinds)
Skylight with blackout blinds 2 3 3
Seats / three-point safety belts 4/4 4/4 4/4
Beds 2 (+1 optional) 2 (+1 optional) 2 (+1 optional)
Rear bed in mm (approx.) 1.960 x 1.200/1.410 1.960 x 1.560/1.430 2.000/1.900 x 800 alternative:
2.000/1.900 x 1.900
Bed traverse to sliding door in mm (approx.. 1.960 x 500 1.960 x 700 1.960 x 700
as standard)
14TECHNICAL DATA
6.36 m
5.99 m
5.41 m
SUMMIT PRIME 540 SUMMIT PRIME 600 SUMMIT PRIME 640
DIMENSIONS in mm
Length (approx.) 5.413 5.998 6.358
Width (approx.) 2.050 2.050 2.050
Height (approx.) 2.580 2.580 2.580
Wheelbase (approx.) 3.450 4.035 4.035
Interior height (approx.) 1.905 1.905 1.905
WEIGHT AND LOAD CAPACITY in kg
Gross vehicle weight (as standard) 3.300 3.300 3.500
Mass in running order (approx.)* 2.695 2.890 3.010
Load capacity with 20 l water (approx.)* 605 410 490
Towing capacity unbraked / braked** 750 / 2.500** 750 / 2.500** 750 / 2.500**
* Weight specifications with equipment included as standard. For Fiat starting from 160 HP +15 kg.
The vehicle's mass in running order and kerb weight may change with the instalment of optional extras.
** Heavy/Maxi 750/3,000 kg
ON-BOARD TECHNICAL EQUIPMENT
Heater Truma Combi 4 Truma Combi 4 Truma Combi 4
Boiler volume in l (approx.) 10 10 10
Freshwater tank in l (approx.) 85 100 100
Wastewater tank in l (approx.) 100 100 100
Gas cylinder box for (kg) 1 x 11 and 1 x 5 1 x 11 and 1 x 5 2 x 11
Battery charger in A 16 16 16
Battery 12V / 95 12V / 95 12V / 95
12/230 V sockets 2/1 2/1 2/1
Refrigerator in l (capacity / of which freezer) approx. 100 / 8 approx. 100 / 8 approx. 100 / 8
Absorber / Compressor Compressor Compressor Compressor
LIVING AREA FITTINGS AND FEATURES
Integrated framed insulating windows 5 (2x suspension mounted in rear) 5 (2x suspension mounted in rear) 4
(blinds)
Skylight with blackout blinds 2 3 3
Seats / three-point safety belts 4/4 4/4 4/4
Beds 2 (+1 optional) 2 (+1 optional) 2 (+1 optional)
Rear bed in mm (approx.) 1.960 x 1.200/1.410 1.960 x 1.560/1.430 2.000/1.900 x 800 alternative:
2.000/1.900 x 1.900
Bed traverse to sliding door in mm (approx.. 1.960 x 500 1.960 x 700 1.960 x 700
as standard)
15STANDARD EQUIPMENT &
BASIC VEHICLE DRIVER'S CAB
Fiat Ducato, Citroën Jumper and Peugeot Boxer 3.3/3.5 t Light or 3.5 t Comfortable swivel driver's seat and front passenger seat, armrests both
Maxi/Heavy Chassis sides
4-cylinder turbo diesel, Euro 6d-Temp, soot particle filter Height-adjustable driver's seat
Driver's airbag Spacious storage above driver's cab
Electronic vehicle immobiliser, central locking with remote control Central cup holder
Tyre pressure sensors (not available on Fiat)
Disc brakes front and rear, power steering, rev counter LIVING AREA
Height-adjustable headlamps Living area furniture with easy-care surfaces
3-point safety belt Driver's cab seats fully integrable into the living area seating
Tyres: 215/70R15C; on Heavy/Maxi 225/75R16C Fittings and roller bearing mounts in solid metal design, household quality
Electric windows on driver's and passenger side Large ceiling cabinets offer generous storage
Driver's cab interior lighting Bespoke, high-end furniture design
Headlamps with integrated daytime running light Ceiling cabinets with indirect lighting (not available in Summit 540)
FITTINGS AND FEATURES KITCHEN
Courtesy lighting High-grade worktop with robust surface
Integrated framed window (not in rear) Refrigerator with integrated freezer compartment
Insect protection sliding door 2-burner hob with piezo igniter and glass top for additional surface space,
and splash guard
All windows with a flyscreen blind, blackout blind and hinged mount
Stainless steel sink with glass cover
Optimised multi-layer roof insulation
Optimised floor insulation with closed cell foam (RTM foam approx. 20 mm)
WASHROOM
Wall insulation with flexible insulation mats (PE foam)
Hand-held shower head in chrome look
Mini and Midi-Heki skylights installed with GRP adapter for optimum fit and
sealing Single-lever mixer tap with high-end ceramic sealing
Additional floor storage compartment in seating area Variable swing wall for optimum space usage
Mountable in rear stowage compartment Swivel toilet for more comfort and ceramic inlay for easy cleaning
Mirror with indirect lighting and additional light panel in the shower (only in
Summit 540)
TECHNICAL FEATURES
Powerful Truma Combi heater with 10 l boiler
Water supply via reliable pump system
Gas box easily accessible via rear door
230 V CEE external socket with circuit breaker
Easy-to-operate multi-function panel
LED spotlights throughout whole living area
In addition to the standard equipment for D-Line, the Elegance also offers the following additional options:
Exclusively
ADDITIONAL OPTIONS SUMMIT PRIME for
High-grade Prime interior design from the Liner Class with Palisander interior
Pop-up SkyRoof with flyscreen and blackout blind
Storage cabinets with ambient lighting directly above the driver cabin
Unique open-plan interior with loads of headroom and freedom to move, like in a coach-built liner-type motorhome
Front windscreen darkening for optimised forward visibility
Prime kitchen with refrigerator that can be opened in both directions
Powerful compressor refrigerator with removable freezer compartment
Prime lighting concept for exceptional living ambience: - Ceiling cabinets with indirect lighting - Prime lighting ambience panel in the seating area -
powerful reading lamps on the B-pillars - Backlit Heki canopy with additional LED spots
16PROMOTION PACKAGES &
CITROEN / PEUGEOT
BASIS CITROEN JUMPER 2.2l BlueHDI 88 KW/120 HP 2.2l BlueHDI 102 KW/140 HP 2.2l BlueHDI 121 KW/165 HP
BASIS PEUGEOT BOXER
SUMMIT 540 3.3 t
SUMMIT 600 3.3 t
SUMMIT 640 3.5 t (Light)
SUMMIT PRIME 540 3.3 t
SUMMIT PRIME 600 3.3 t
SUMMIT PRIME 640 3.5 t (Light)
FIAT
2.3l Multijet 88 KW/120 2.3l Multijet 102 KW/140 2.3l Multijet 118 KW/160 2.3l Multijet 131 KW/178
BASE FIAT DUCATO HP HP HP HP
SUMMIT 540 3.3 t
SUMMIT 600 3.3 t
SUMMIT 640 3.5 t (Light)
SUMMIT PRIME 540 3.3 t
SUMMIT PRIME 600 3.3 t
SUMMIT PRIME 640 3.5 t (Light)
CHASSIS EXTRA CHARGES Additional weight
Citroen / Peugeot 3.3 Light to 3.5 Light
Fiat 3.3 Light to 3.5 Light
Citroen / Peugeot 3.3 Light on 3.5 Heavy 40 kg
Fiat (not available on Summit 540/540 Prime) 3.3 Light on 3.5 Maxi 40 kg
Citroen / Peugeot (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
Fiat (640 cm long and over) 3.5 Light on 3.5 Heavy 40 kg
SUMMIT & SUMMIT PRIME ALL-IN PACKAGE +KG
ESP, ABS, ASR, Hill-Holder -
90 l diesel tank
Fully equivalent spare wheel 24
Climate control in driver's cab, manual 18
Front passenger airbag 3
Electrically operated and heated door mirrors 2
Height-adjustable front passenger seat 1
Driver's cab seat covers same as in living space -
Driver's cab blackout solution for windscreen -
Dashboard with chrome surrounds
25 A charging converter
Sum 48
17OPTIONAL EXTRAS FOR FITTINGS &
SUMMIT PRIME 540
SUMMIT PRIME 600
SUMMIT PRIME 640
DESCRIPTION
SUMMIT 540
SUMMIT 600
SUMMIT 640
OPTIONAL
+ KG
Rosewood decor - s s s - - -
Oak Copper Bora wood decor alternative - o o o - - -
Palisander wood decor - - - - s s s
Mindoro interior (standard interior) - s s s s s s
Solero interior as alternative - o o o o o o
Samba alternative interior - o o o o o o
Original Captain Chair interior - o o o o o o
Bed extension across for 3rd person 9 o o o o o o
Table with open-out section 15 - s s - s s
Easy Move table with travel function 5 s - - s - -
Pop-top roof in white 127 o o o - - -
Pop-top roof in vehicle body colour 127 o o o - - -
Hinged SkyRoof with backlit canopy and LED spotlights 1 o o o s s s
Compressor refrigerator 80/10 l (capacity/ of which freezer) - - - s - - -
Compressor refrigerator 100/8 l (capacity/ of which freezer) - s s - s s s
Additional 95 Ah on-board battery 30 o o o o o o
Additional 230 V / USB socket set 1 o o o o o o
Solar pre-installation 1 o o o o o o
Loudspeaker in rear area 2 o o o o o o
TV/SAT pre-installation 1 o o o o o o
Truma Combi 6E (only in combination with Truma CP Plus control unit) 1 o o o o o o
Truma CP Plus control unit - o o o o o o
Gas – Duo Control CS 3 o o o o o o
Winter package* 6 o o o o o o
Thermal blind in rear 3 o o o o o o
Windows with blinds in rear doors 8 s s o s s o
Additional windows in the rear left 10 - o s - o s
Electric wastewater valve - o o o o o o
Isofix system for bench seat (only for one seat in 540) 4 o o o o o o
5th seat – bench with integrated single pull-out seat (3.5 t ) 15 o o o o o o
Softlock close assist for sliding door 4 o o o o o o
Omnistep Slide Out step 12 s o o s s s
Fully electric sliding door 8 o o o o o o
Summit sanitation package (garment hooks, mirror with two lights) 2 - o o - - -
Safe under the driver's seat 10 o o o o o o
Driver's cab carpet 2 o o o o o o
Load-securing rails in rear stowage compartment 5 o o o o o o
* Winter package: insulated wastewater tank, with heatable Tank and wastewater pipes, insulated mats for the rear doors
o Available option - not available s as standard
18BASIC VEHICLE OPTIONAL EXTRAS – FOR ALL MODELS
CITROEN FIAT
OPTIO- OPTION NOTE +KG
NAL
"Light" 15 inch alloy wheels 8
"Light" 16 inch alloy wheels (from 3.5 t) (on Citroen from 3.5 t, not 8
available for 120 HP)
"Maxi/Heavy“ 16 inch alloy wheels 8
Dashboard with aluminium details -
9-speed automatic torque converter transmission not available with 120 HP, for 140 PS only 17
in combination with ECO package, Light
only with 16 inch alloy wheels
Cupholder and smartphone holder -
Passenger airbag (included in All-in package) 3
Roof-mounted DAB antenna with loudspeaker For Prime models only in combination -
with DAB antenna in the right rear-view
mirror
DAB antenna in the right rear-view mirror (instead roof-moun- Additional charge for roof antenna -
ted)
Double-leaf spring rear axle 17
ECO package (Start & Stop+ intelligent alternator) Standard for 160 and 180 HP, mandatory 1.5
option for 140 HP Automatic (not available
with Fiat 120 HP)
Rear parking assist 1
Holder for smartphone or tablet on the top part of the central with lockable glove compartment instead -
console of cup holder
Manual climate control (included in All-in package) 18
Automatic climate control 18
Climate control (extra charge for All-in package) -
Leather steering wheel -
Steering wheel remote control -
M+S all-weather tyres (3.5 t and over) only for 16 inch steel wheels
Metallic paint and Campovolo Grey Fiat Special colours subject -
to additional charge
Fog lights not available for painted bumpers 2
Emergency brake system, lane departure warning system, 0.5
high-beam assistant, road traffic sign recognition, rain and
light sensor
Mud flaps front and rear not available with 3.5 t Light 6.40 m 3
Electric folding mirror Extra charge on All-in Package 1
Electrically operated and heated door mirrors (included in All-in package) 2
Webasto auxiliary heater 6
Front bumper painted (except special colours, Titian Red and Not available for Heavy/Maxi and fog lights 1
Imperial Blue)
Black Line style package (radiator grille, skid plate and head- -
light surround in black)
LED daytime running lights -
Cruise control 1
Traction+ 1
Blind spot assist with rear cross path detection
USB port integrated into dashboard -
Underride guard 2
Second ignition key with remote -
19Facebook: facebook.com/poesslreisemobile
Instagram: instagram.com/poessl_original | #pössldasoriginal
Pinterest: pinterest.de/poesslreisemobile
Youtube: youtube.com/poesslmobile
With dealerships in 14 countries – we're ready to assist you!
And of course also at www.poessl-mobile.de
Technical changes and errors excepted. Please note that illustrations in this brochure may contain decorations, alternative designs or special equipment that are not included in the scope of delivery or for which additional costs may be incurred.
All dimensions in millimetres, unless otherwise indicated. Information on technology, water supply and prices can be found in the separate price list. Minor deviations in colour may result due to the printing process. Update 08 / 2020 – Version 3
* According to the EU Directive 97 / 27 EC and EU standard EN 1645-2, the "mass in running order" comprises the kerb weight of the vehicle – incl. driver (75 kg) and filled fuel tank as well as the following standard equipment: water tanks with reduced
volume (20 l), a filled aluminium gas cylinder (15 kg) and a cable reel (4 kg). The gross vehicle weight must not be exceeded by the personal equipment, persons travelling with the vehicle and any optional extras. The installation of special accessories
reduces the maximum recommend load and may reduce the permitted number of persons. The information on the scope of delivery, appearance, performance, dimensions and weight of the vehicles corresponds to the knowledge available at the time of
going to press and the European homologation regulations. These can change until the vehicle is purchased or until delivery. Deviations within the factory tolerances (+ / - 5 % max.) are possible and permissible.You can also read
