2021 LINE Art by: Russ Pope
2021 BICYCLES AND FRAMES LINE index 04 - 2021 LINE RESUME 08 - ROAD PERFORMANCE 24 - ROAD ATELIER 40 - GRAVEL PERFORMANCE 44 - GRAVEL SPORT 46 - GRAVEL E-BIKE 48 - GRAVEL ATELIER 52 - SINGLESPEED PERFORMANCE 54 - SINGLESPEED SPORT 58 - SINGLESPEED ATELIER 62 - TRAVEL URBAN 64 - TRAVEL EXPEDITION 68 - TRAVEL EXPLORER
ph: Alessandro Trovati
2021 BIKE K E E P O N B I K I N ’
ROAD GR AVEL
PERFORMANCE ATELIER PERFORMANCE SPORT E-BIKE ATELIER
PRESSURE p. 08 NEMO ZAGATO p. 24 KING ZYDECO p. 40 ZYDECO LALA p. 44 ZYDECO ELECTRIC MUD p. 46 NEMO TIG GRAVEL p. 48
SUPERSTAR DISC p. 10 XCR p. 26
ZYDECO p. 42
SUPERSTAR p. 12 NEMO TIG DISC p. 28
VELTRIX DISC p. 16 NEMO TIG p. 32
VELTRIX p. 18 SUPERCORSA p. 34
VIGORELLI DISC p. 20 LASER MIA p. 36 ph: Alessandro Trovati
I N T H E F R E E W O R L D
COLLECTION
SINGLESPEED TR AVEL
PERFORMANCE SPORT ATELIER URBAN EXPEDITION EXPLORER
VIGORELLI SHARK p. 52 TUTTO PLUS p. 54 SUPERCORSA PISTA p. 58 GAZZETTA DELLA STRADA p. 62 HOBOOTLEG p. 64 HOBOOTLEG EASY TRAVEL p. 68
GAZZETTA p. 56 HOBOOTLEG GEO p. 66 HOBOOTLEG INTERRAIL p. 70
available with custom assembly. Check with commercial office.
ph: Chiara Redaschi ph: Alessandro Trovati
ROAD PERFORMANCE
ph: Alessandro Trovati
990 g 390 g BB 30 PRO COMPETITION
PRESSURE FRAME
WEIGHT (M)
FORK
WEIGHT
86,5
PRESS FIT
mm
MAX TYRE
AERODYNAMIC
FRAME KIT / CUSTOM ASSEMBLY
CLIMB
Born to race, this monocoque high modulus carbon T700
fiber aero road bike is designed to cut through the air. REACTIVITY
Password: integrate! The new born Cinelli aerodynamic racing
frame integrates anything possible: the special aero seat tube,
the custom colour FSA Vision Metron 5D ACR fully integrated COMFORT
aero handlebar, with integrated headset, cockpit and fork, for
the cleanest cable routing solution and fastest racing geometry
ever. The bicycle natural choice is for electronic groupset.
COLOR: Rock The White
8 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.
Disc brake and thru axle with the dropped seat stays design increase the
T1
aerodynamics alongside with the global stiffness of the frame, for best reactivity and
T b°
maximum control. Pressure. Double check the bottom bracket to fully appreciate the
a° power and meaning of this racing machine. A hint? London Calling? Smashed fender
u be
reach
P-bass? More than enough to guess. In Italo flagship design colours.
dT
TOTAL INTEGRATED SOLUTION Vision Metron 5D handlbar’s ACR system, with
H ea
fully integrated bar, cockpit headset and fork, coupled with the use of PU Molds in
the curing for the cleanest and most efficient internal wire passage, emphatize the
stack
purest aesthetic and Pressure artwork. Remember to always smile while steering.
k
For
AERO SECTION ELEMENTS Aero seat tube and dropped seat stays are functional to
S1
S
best aerodynamics and stiffness and join forces with the other aero elements of the
frame for best control and power.
R E DYNAMIC RACING GEOMETRY The thru axle and disc brake choice with internal
F C wire routing allows for the cleanest and fastest design, in an overall geometry which
WB leads to the most compact and aerodynamic position of the rider.
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK STACK REACH
XS 460 444 518 504 110 71 73,5 45 410 571 971 68 374 512 366
S 490 472 530 518 125 71,5 73,5 45 410 579 979 68 374 528 374
M 520 503 545 538 135 72 73,5 45 410 590 990 68 374 539 385
L 550 535 560 556 155 72,5 73,5 45 410 600 1001 68 374 560 394
XL 580 567 575 573 175 73 73,5 45 410 611 1011 68 374 581 403
assembly frame SPECS
RED ETAP axs DURA-ACE DISC DI2 ULTEGRA DISC DI2 ULTEGRA DISC Sizes XS (46) - S (49) - M (52) - L (55) - XL (58)
Drivetrain Sram Red Etap AXS Shimano Dura-Ace 9170 Shimano Ultegra 8070 Shimano Ultegra 8020 Cockpit XS 90x400 - S 100x400 - M 110x420 - L 120x420 - XL 130x440 Included
Handlebar FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR Material Columbus Carbon Monocoque T800
Stem / / / / Headset IS 52/28,6 | IS 52/40 FSA ACR 1-1/2” (included)
Seatpost Integrated Integrated Integrated Integrated Seatpost Aero (included) / Carbon Rail Comp. / L 300 (XS) - L 350 (S-M-L-XL)
Shifters Sram Red Etap AXS Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8020 Seat Clamp Hidden (included)
Brakes Sram Red Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8070 BB Shell Press Fit 86,5 x 41 mm
Rotors Sram Centerline XR 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Ft. derailleur Braze-On
Ft. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Routing Full Internal - Di2/EPS Compatible
R. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Color Rock The White
Crankset Sram Red Etap AXS 48/35t* Shimano Dura-Ace R9100 52/36t* Shimano Ultegra R8000 52/36t* Shimano Ultegra R8000 52/36t* Tyre Clear. up to 700x30 mm
Cassette Sram Red Etap AXS 10/28t* Shimano Dura-Ace R9100 11/30t* Shimano Ultegra R8000 11/30t* Shimano Ultegra R8000 11/30t* Fork Columbus Disc 1-1/2” Carbon Monocoque Internal Cable Routing
Chain Sram Force Flathead Shimano Dura-Ace R9100 Shimano Ultegra R8000 Shimano Ultegra 8000 Weight Frame 990g (size M) - Fork 390g (uncut)
Wheelset Fulcrum Wind 550 DB Fulcrum Wind 550 DB Fulcrum 600 DB Fulcrum 600 DB Brake Flat Mount Disc Brake, Rotor Size Up To 160 mm
Tyres Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Dropouts ST Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x120
Saddle SSM Shortfit SSM Shortfit SSM Shortfit SSM Shortfit Highlights Extra hanger / Di2 / EPS Cable Inserts / F-R Skewers
*Different option available
9
1140 g 440 g BB 28 PRO COMPETITION
SUPERSTAR DISC FRAME
WEIGHT (M)
FORK
WEIGHT
86,5
PRESS FIT
mm
MAX TYRE
AERODYNAMIC
FRAME KIT / CUSTOM ASSEMBLY
CLIMB
Carbon innovation in its finest form: frame in high
modulus monocoque carbon fiber, with flat mount REACTIVITY
disc brake setup and 12 mm thru axle. Added rear
clearance allows wheels of up to 28mm and discs up
to 160mm. COMFORT
The Superstar features the new Columbus Futura
Disc fork 1-1/8 – 1-1/2”, equipped with thru axle
for maximum control and ride safety.
COLOR: Black Cat
10 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.GCD The special horizontal curve allows that the angling of the
T1 head tube is consistent even when met with strong vertical forces
T b° on the frame, which typically cause a deformation of the wheel
a°
Tub
e reach
base when met with a road obstacle or a sudden burst out of the
saddle. GCD improves control as well as the overall predictability
d
of the bike.
Hea
CCL The absence of corners on the frame surface allows for full
use of the carbon layers, optimizing the overall stiffness of the
stack
structure while improving performance.
k
For
S1
S
OCR The internal cable routing is designed to avoid pinch points
in the hydraulic system, while maintaining maximum efficiency in
E
system operation.
R
F
C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 460 407 515 500 110 71 75 45 415 577 982 70 368 768 509 373
S 480 430 533 517 120 72 74 45 415 581 987 70 368 717 522 383
M 510 460 550 533 145 72,5 73,5 45 415 590 995 70 368 816 548 387
L 540 498 566 550 160 73 73 45 415 595 1001 70 368 845 564 393
XL 570 523 585 568 185 73,5 72,5 45 415 604 1009 70 368 872 590 399
assembly
RED ETAP axs DURA-ACE DISC DI2 ULTEGRA DISC DI2 ULTEGRA DISC frame SPECS
Drivetrain Sram Red Etap AXS Shimano Dura-Ace 9170 Shimano Ultegra 8070 Shimano Ultegra 8020 Sizes XS (46) - S (48) - M (51) - L (54) - XL (57)
Handlebar FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR Material Columbus Carbon Monocoque T700
Stem / / / / Headset IS 42/28,6 | IS 52/40 Columbus Compass 1-1/2” incl.
Seatpost Integrated Integrated Integrated Integrated Seatpost Ø 27,2 mm
Shifters Sram Red Etap AXS Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8020 Seat Clamp Ø 31,8 mm
Brakes Sram Red Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8070 BB Shell Press Fit 86,5 x 41 mm
Rotors Sram Centerline XR 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Ft. derailleur Braze-On
Ft. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Routing Internal - Di2/EPS compatible
R. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Color Black Cat / Grey Street
Crankset Sram Red Etap AXS 48/35t* Shimano Dura-Ace R9100 52/36t* Shimano Ultegra R8000 52/36t* Shimano Ultegra R8000 52/36t* Tyre Clear. up to 700x28 mm
Cassette Sram Red Etap AXS 10/28t* Shimano Dura-Ace R9100 11/30t* Shimano Ultegra R8000 11/30t* Shimano Ultegra R8000 11/30t* Fork Columbus Futura Disc 1-1/8” 1-1/2” Carbon Monoc.
Chain Sram Force Flathead Shimano Dura-Ace R9100 Shimano Ultegra R8000 Shimano Ultegra 8000 Weight Frame 1140 g. (size M) Fork 440 g. (uncut)
Wheelset Fulcrum Wind 550 DB Fulcrum Wind 550 DB Fulcrum 600 DB Fulcrum 600 DB Brake Flat mount disc brake, rotor size up to 160mm
Tyres Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Dropouts ST Rear TA Ø 12x142mm - M12x173 / Front TA Ø 12x100mm - M12x119
Saddle SSM Shortfit SSM Shortfit SSM Shortfit SSM Shortfit Highlights Extra hanger / Di2 / EPS cable inserts / F-R Skewers
*Differenti opzioni diponibili
11920 g 350 g BB 28 PRO COMPETITION
SUPERSTAR FRAME
WEIGHT (M)
FORK
WEIGHT
86,5
PRESS FIT
mm
MAX TYRE
AERODYNAMIC
FRAME KIT / CUSTOM ASSEMBLY
CLIMB
Superstar is the monocoque carbon bicycle, perfect
either for granfondo & climbs, mounting rim brake REACTIVITY
system and Shimano ultegra 11s full and rim
brake. Internal cable routing and compatibility with
electronic groupsets from Shimano and Campagnolo. COMFORT
28mm tyre clearance and new Columbus Futura
Caliper 1-1/8 - 1-1/2”fork.
COLOR: Red Hot
12 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.UCI APPROVED FRAME AND FORK The Superstar frame and fork obtained the
T1 UCI Approval Label that allows this pure racing machine to take part in the top level
T b°
professional races like the Tour de France, the Giro d’Italia and all the famous classic
a°
ube
reach
races.
INTERNAL PU MOLDS The Superstar utilizes Internal PU Molds, stay inside the
dT
Hea
head tube and bottom bracket during the carbon curing process. This technique
increases the carbon fiber compression and lowers the amount of resin needed.
In addition the possibility of air being trapped in the carbon structure is greatly
reduced while guaranteeing minimal residue within the frame housing walls.
stack
k
For
TEAM BIKE Racing teams riding Superstar:
S1
S
Team Colpack Ballan Team Stabbia Rush Team
Cinelli Team Deka Rider Team Lovelo Squadra Donne
Energy Team Team MGKVIS Team Crimson Performance UK
R E
F
Team LVF Team Jadan
C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 460 407 515 500 110 71 75 45 407 577 974 70 368 768 509 373
S 480 430 533 517 120 72 74 45 407 581 978 70 368 717 522 383
M 510 460 550 533 145 72,5 73,5 45 407 590 986 70 368 816 548 387
L 540 498 566 550 160 73 73 45 407 595 992 70 368 845 564 393
XL 570 523 585 568 185 73,5 72,5 45 412 604 1005 70 368 872 590 399
assembly
ULTEGRA frame SPECS
Drivetrain Shimano Ultegra 8000 Sizes XS (46) - S (48) - M (51) - L (54) - XL (57)
Handlebar Cinelli Vai Material Columbus Carbon Monocoque T700
Stem Cinelli Vai Headset IS 42/28,6 | IS 52/40
Seatpost Cinelli Vai Ø 27,2 Seatpost Ø 27,2 mm
Shifters Shimano Ultegra R8000 Seat Clamp Ø 31,8 mm
Brakes Shimano Ultegra R8000 BB Shell Press Fit 86,5 x 41 mm
Rotors / Ft. derailleur Braze-On
Ft. derailleur Shimano Ultegra R8000 Routing Internal - Di2/EPS compatible
R. derailleur Shimano Ultegra R8000 Color Black Diamond / Red Hot
Crankset Shimano Ultegra R8000 52/36t* Tyre Clear. up to 700x28 mm
Cassette Shimano Ultegra R8000 11/30t* Fork Columbus Futura Caliper 1-1/8” 1-1/2” Carbon Monoc.
Chain Shimano Ultegra 8000 Weight Frame 920 g. (size M) Fork 350 g. (uncut)
Wheelset Fulcrum Racing 600 Brake Standard Rim Brake
Tyres Vittoria Zaffiro pro 700x28 Dropouts ST Rear QR 130mm - Front QR 100mm
Saddle Cinelli SSM Squadra Highlights Extra hanger / Di2 / EPS cable inserts
*Different option available
13SUPERSTAR COLPACK TEAM EDITION FRAME KIT / CUSTOM ASSEMBLY SPECS ON REQUEST
wysiwyg team edition
FRAME KIT
SPECS ON REQUEST
159 Kg BSA 28 PRO COMPETITION
VELTRIX DISC BIKE
WEIGHT (M)
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
COMPLETE BIKE
CLIMB
Veltrix is a carbon monocoque frame born for the
competition: fast, reactive and performing. Its easy REACTIVITY
handling makes it suitable for multiple uses, perfect
for the pros but also suitable for those who want to
ride at a smooth pace. The wise use of carbon fiber COMFORT
along with an optimal sizing of the sections of the
frame elements make it a particularly performing
machine.
COLOR: Blue In Green
16 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.DYNAMIC RACE GEOMETRY Veltrix geometry is designed with the horizontal tube / seat
T1 tube best ratio, to achieve the best position on the bicycle. The rider’s centre of gravity is
a°
most efficient: best push on the pedals on steep climbs and intense shots alongside with
reach
be T b° excellent control on the fastest descents.
d Tu
Hea
1,5” MEGAHEAD The 1” 1/2 oversized fork with tapered head tube guarantees the best
driving precision even at higher speeds, making Veltrix incomparable in direction changes.
The cable passage is completely internal either for mechanical or electronic assemblies,
stack
improving aerodynamics and frame aesthetics.
k
For
S1
S
LOW SIGMA TRANSITION The BSA Bottom Bracket Shell is oversized to increase the
lateral stiffness of the frame in order to maximize the pedaling efficiency and transmit
R E
to the wheel all the power generated by the cyclist as well as for structural reasons,
F C minimizing the tensions in a deeply stressed area. The result is that of reducing the weight
WB
and increasing the frame durability.
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 500 440 500 491 115 71 75 43 415 566 971 70 368 744 515 364
S 520 466 520 511 135 71,5 74,5 43 415 577 983 70 368 764 534 373
M 540 481 540 530 155 73 73,5 43 415 578 975 70 368 784 551 382
L 568 500 567 552 180 73 73,5 43 415 600 1005 70 368 804 584 395
XL 584 515 583 567 200 73,5 73,5 43 415 614 1019 70 368 821 598 405
assembly
SHIMANO 105 mix 22 SPEED
Handlebar Cinelli 6061 Ø 31,8 Drop 130 mm Reach 80 mm / XS 40 - S 40 - M 42 - L 42 - XL 42 frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / XS 90 - S 100 - M 100 - L 110 - XL 110 Sizes XS (50) - S (52) - M (54) - L (56) - XL (58)
Seatpost Cinelli 6061 Ø 31,6 L 350 Material Columbus Carbon Monocoque
Shifters Shimano 105 / ST-R7020. BR 7070 / RESIN Pad (SM-BH90) Headset IS 42/28,6 | IS 52/40
Brakes Shimano 105 BR-R7070 Hydraulic Disc Seatpost Ø 31,6 mm
Rotors Front MT-800 160 mm / Rear MT-800 140 mm Seat Clamp Ø 34,9 mm
Ft. derailleur Shimano 105 FD-R7000-L / 11 Speed / Braze On / 46-53t BB Shell BSA 68 mm
R. derailleur Shimano 105 FD-R7000 / 11 Speed / Direct Attachment / Black Ft. derailleur Braze-On
Crankset Shimano FC-RS510 / 11 Speed / 50-34t / XS 170 - S 172,5 - M 172,5 - L 172,5 - XL 175 Routing Internal - Di2/EPS compatible
B. Bracket Shimano / BSA 68 mm Color Blue In Green
Cassette Shimano 105 CS-R7000 / 11 Speed / 11-28t Tyre Clear. up to 700x28 mm
Chain Kmc X11 Fork Columbus Disc 1-1/8” 1-1/2” Carbon Monoc.
Wheelset Shimano RS-170Disc / 28H / Center Lock / 11 Speed Weight Frame 1250 g. (size M) Fork 500 g. (uncut)
Tyres Vittoria Zaffiro fold / 25-662 700x25c Brake Flat Mount Disc Brake, rotor size up to 160 mm
Saddle Cinelli SSM Monza Dropouts ST Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x119
Tape Cinelli Cork Highlights Di2 / EPS cable inserts / F & R skewers
178,6 Kg BSA 28 PRO COMPETITION
VELTRIX BIKE
WEIGHT (M)
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
COMPLETE BIKE
CLIMB
Veltrix is a carbon monocoque frame born for the
competition: fast, reactive and performing. Its easy REACTIVITY
handling makes it suitable for multiple uses, perfect
for the pros but also suitable for those who want to
ride at a smooth pace. The wise use of carbon fiber COMFORT
along with an optimal sizing of the sections of the
frame elements make it a particularly performing
machine.
COLOR: Blue In Green
18 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.DYNAMIC RACE GEOMETRY The geometry of Veltrix has been designed to have the
T1 best ratio between the length of the horizontal tube and that of the seat tube, for the best
a° reach
position on the saddle. This allows a better aerodynamic position and an optimal balance
ube of the cyclist’s center of gravity: best push on the pedals in the steepest climbs or intense
b°
T
dT
shots together with an excellent control in fastest descents.
Hea
1,5” MEGAHEAD The 1” 1/2 oversized fork with tapered head tube guarantees the best
driving precision even at higher speeds, making Veltrix incomparable in direction changes.
The cable passage is completely internal either for mechanical or electronic assemblies,
k
stack
For
improving aerodynamics and frame aesthetics.
S1
S
LOW SIGMA TRANSITION The BSA Bottom Bracket Shell is oversized to increase the
lateral stiffness of the frame in order to maximize the pedaling efficiency and transmit
R E
to the wheel all the power generated by the cyclist as well as for structural reasons,
F C
minimizing the tensions in a deeply stressed area. The result is that of reducing the weight
WB
and increasing the frame durability.
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 500 440 500 491 115 71 75 43 409 575 975 68 371 744 510 362
S 520 466 520 511 135 71,5 74,5 43 409 587 986 68 371 764 532 372
M 540 481 540 530 155 73 74 43 409 579 978 68 371 784 551 382
L 568 500 565 552 180 73 73,5 43 409 601 1000 68 371 804 583 394
XL 584 515 583 567 200 73 73 43 409 615 1015 68 371 821 601 406
assembly
SHIMANO 105 mix 22 SPEED
Handlebar Cinelli 6061 Ø 31,8 Drop 130 mm Reach 80 mm / XS 40 - S 40 - M 42 - L 42 - XL 42 frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / XS 90 - S 100 - M 100 - L 110 - XL 110 Sizes XS (50) - S (52) - M (54) - L (56) - XL (58)
Seatpost Cinelli 6061 Ø 31,6 L 350 Material Columbus Carbon Monocoque
Shifters Shimano 105 / ST-R7000 11s Headset IS 42/28,6 | IS 52/40
Brakes Shimano 105 BR-R7000 Seatpost Ø 31,6 mm
Rotors / Seat Clamp Ø 34,9 mm
Ft. derailleur Shimano 105 FD-R7000-L / 11 Speed / Braze On / 46-53t BB Shell BSA 68 mm
R. derailleur Shimano 105 FD-R7000 / 11 Speed / Direct Attachment Ft. derailleur Braze-On
Crankset Shimano FC-RS510 / 11 Speed / 50-34t / XS 170 - S 172,5 - M 172,5 - L 172,5 - XL 175 Routing Internal - Di2/EPS compatible
B. Bracket Shimano / BSA 68 mm Color Blue In Green
Cassette Shimano 105 CS-R7000 / 11 Speed / 11-28t Tyre Clear. up to 700x28 mm
Chain Kmc X11 Fork Columbus Caliper 1-1/8” 1-1/2” Carbon Monoc.
Wheelset Shimano WH-RS-100 / 20Hfr. 24Hre. / 11 Speed Weight Frame 1200 g. (size M) Fork 460 g. (uncut)
Tyres Vittoria Zaffiro fold / 25-662 700x25c Brake Standard Rim Brake
Saddle Cinelli SSM Monza Dropouts ST Rear QR 130mm - Front QR 100mm
Tape Cinelli Cork Highlights Di2 / EPS cable inserts
199,6 Kg BSA 28 PRO COMPETITION
VIGORELLI DISC BIKE
WEIGHT (M)
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
COMPLETE BIKE
CLIMB
Vigorelli Road Disc: the road version of the Criterium
fixed-gear frame. Vigorelli Track steel, the Cinelli Team REACTIVITY
bike now with disc brakes. The success of the Vigorelli
track steel continues in the road version, maintaining
the characteristics loved by riders of the highest level COMFORT
criterium: Columbus Thron triple-butted tubes, 20mm
higher bottom bracket, steeper seat tube, combined with
road head tube and Columbus Futura Disc road fork. The
through axle guarantees maximum stability and safety.
Performance and responsiveness for an unconventional
bike.
COLOR: Electron Blue
20 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.HYBRID GEOMETRY From track to road: a hybrid geometry that, thanks to
T1
T Columbus Thron triple-butted steel tubes, guarantees optimal control of the bike in
b°
a° the extreme conditions. Disc brakes for fast sprints to the last metre and sudden
reach
turns and, thanks to the 20mm higher bottom bracket, you never stop pedalling.
Internal cable routing for greater aerodynamics and easy frame cleaning.
1,5” MEGAHEAD The oversized head tube increases frontal stiffness and allows
stack
for making the most of the power of disc brakes, returning precise directions in
high-speed downhill and cornering. The 1” ½” Columbus Futura Disc monocoque
S1
S
fork provides very precise handling and extremely low weight.
THRU AXLE DROPOUTS The rear stays is equipped with micro-cast dropouts
R
E
and thru axle; the special curving of the chain stays allows a flat mount disc brake
F C installation with adequate clearance for 28mm tyres: urban circuits can be tackled
WB at the maximum performance.
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK STACK REACH
XS 470 435 512 502 100 72,5 75 45 415 568 977 53 368 498 379
S 500 465 535 526 114 73,5 74,5 45 415 578 987 53 368 515 392
M 530 495 550 543 136 73,5 74 45 415 589 999 53 368 533 397
L 560 525 562 556 156 73,5 73,5 45 415 596 1006 53 368 5524 399
XL 590 555 575 571 174 74 73 45 415 599 1008 53 368 571 400
assembly
SRAM APEX1 MIX
Handlebar Cinelli 6061 Ø 31,8 Drop 130 mm Reach 80 mm / XS 40 - S 40 - M 42 - L 42 - XL 42 frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / XS 90 - S 100 - M 100 - L 110 - XL 110 Sizes XS (47) - S (50) - M (53) - L (56) - XL (59)
Seatpost Cinelli 6061 Ø 31,6 L 350 Material Columbus Thron tubeset
Shifters Sram Apex1 (BL-APX-A1) Brake Only / Sram Apex22 (SB-APX-B1) Shift Brake 11s Headset ZS 44/28,6 | EC 44/40 included
Brakes Trp Spyre (MD-C610C-F/R) Seatpost Ø 31,6 mm
Rotors Trp TR160 160 mm Disc (front & rear) Seat Clamp Ø 33,5 mm
Ft. derailleur / BB Shell BSA 68 mm
R. derailleur Sram Apex1 - Long Cage - 11 Speed Ft. derailleur Clamp-On Ø 33 mm
Crankset Fsa Omega MegaExo 42t / XS 170 - S 172,5 - M 172,5 - L 172,5 - XL 175 Routing External / Internal Hydraulic Brake Housing
B. Bracket Fsa (BB 4000) MegaExo Color Electron Blue
Cassette Microshift 11-32t Tyre Clear. up to 700x28 mm
Chain Kmc X11 Fork Columbus Futura Disc 1-1/8” 1-1/2” Carbon Monoc.
Wheelset Vision Team 30 TL Disc 24 h front / 28 h rear Weight Frame2200 g. (size M) Fork 440 g. (uncut)
Tyres Vittoria Zaffiro rigid / 25-662 700x25c Brake Flat Mount Disc Brake, rotor size up to 160 mm
Saddle Cinelli SSM Monza Dropouts ST Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x119
Tape Cinelli Cork Frame Kit Seat Clamp / Headset - Expander / BB Guide / 1X Cable Passage Hole Cap
21ROAD ATELIER
ph: Federico Stanzani
1850 g 440 g BSA 28 PRO COMPETITION
NEMO zagato FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
COMPLETE BIKE
CLIMB
Columbus and Zagato celebrate 100 years
since their foundation in 1919 with a new
superlative product: REACTIVITY
CINELLI NEMO ZAGATO.
COMFORT
Cinelli Nemo Zagato, the bicycle realized by Cinelli a one hundred piece limited
edition, to celebrate the collaboration between the two historical brands, is
made of a Columbus Cento custom drawn tubeset, the special 100 years edition,
lighter thanks to the TIG welding and the naked nature of the colour, a superthin
deposit of shiny nickel to highlight the perfect manufacturing of the surface.
24 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.The singular points of coupling are reinforced with silver brazed steel plates, to improve
the strength of the frame without increasing its weight.
The bicycle set up is completed by the Carbon Monocoque Columbus Futura Disc straight
blade fork with conical CNC’d head tube, to guarantee comfort and superior handling.
Selle San Marco contribute with their know how in
terms of materials and finish to produce an exclusive
saddle, consistent with the historical references of
Cinelli Nemo Zagato.
Campagnolo supplies high-end Super Record mechanical
groupset with disc brakes and Bora high profile and
wind tunneloptimized wheels, with dedicated graphics
celebrating the double centenary: Zagato logo goes
alongside with the brand of the producer of components
who made the history of cyclism worldwide.
Pirelli supplies the P ZERO ™ Velo tires produced according to the
technologies developed from a hundred-year experience in the world of
motorsport.
251650 g 350 g BSA 28 PRO COMPETITION
xcr FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
FRAME KIT
CLIMB
The Cinelli crown jewel: our most advanced steel
frame, made with the best materials and the highest REACTIVITY
technological quality. The Columbus XCr tubing is
a seamless tube in bi-phasic stainless steel, ideal
to create a light, unparalleled vibration-absorbing, COMFORT
eternal bicycle frame. Pure state of the art. Available
in 5 standard sizes as well as custom sizing.
COLOR: Magic Mirror
26 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.XCR STAINLESS STEEL The austenite parts in the martensite structure generate a
T1 particular elastic response of the tubes of the frame, for unique handling that creates
T a more direct, spontaneous bond with the road, especially in downhill stretches
a° b°
and at high speeds. The XCR steel has better weight/stiffness ratio compared to
ube
reach
aluminum and titanium alloys. Oversize head tube with the 1,5” Columbus Futura
dT
Caliper monocoque fork increases the front stiffness and the control of the bike.
Hea
ULTRA LIGHT WINGED DROPOUTS Forged stainless steel 316L tig welded
stack
dropouts. Beside an attractive design inspired to the Cinelli winged logo, these
k
For
handcraft dropouts enable an easy-wheel fitting, furthermore the integrated hanger
S1
S
guarantees a fast and ultra precise shifting in any conditions. Completely hand built,
in Italy.
R E
F C
OVERSIZE HEADTUBE Oversized 44mm head tube to join the 1.5” Columbus
WB Futura Caliper monocoque fork
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 450 415 515 498 98 71,5 74,5 45 403 570 962 73 368 725 491 378
S 480 435 525 509 104 72 74 45 405 572 966 73 368 738 498 382
M 500 465 545 530 121 73 73,5 45 405 579 974 71 368 762 516 390
L 530 495 560 544 139 73,5 73 45 408 583 981 71 368 787 535 396
XL 560 525 580 564 172 73,5 72,5 45 408 599 997 68 368 816 560 403
frame SPECS
Sizes 48 to 62 (1 cm) - Made to Measure
Material Columbus Xcr Tubeset
Headset ZS 44/28,6 | EC 44/40
Seatpost Ø 31,6 mm
Seat Clamp Integrated
BB Shell BSA 68 mm
Ft. derailleur Clamp Ø 33 mm
Routing External
Color Magic Mirror
Tyre Clear. up to 700x28 mm
Fork Columbus Futura Caliper 1-1/8” - 1-1/2” Carbon Monocoque
Weight Frame 1650 g. (size M) Fork 350 g. (uncut)
Brake Standard Rim Brake
Dropouts ST Front QR 100 mm - Rear QR 130 mm
Highlights Frame / Fork / Ft. Derailleur Clamp
271850 g 440 g BSA 28 PRO COMPETITION
NEMO TIG DISC FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
FRAME KIT / CUSTOM ASSEMBLY
CLIMB
Custom geometries, entirely Made in Italy with the
legendary Columbus Spirit triple butted tubes. Flat REACTIVITY
mount disc brakes and enhanced wheel passages
for amazing gravel adventures and crazy downhill
descents at top speed. Steel is back to satisfy the COMFORT
needs of the demanding rider that desire the most
updated technologies with an eye to tradition.
COLOR: Orange Blossom Special
28 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.T1
INTEGRATED SEAT CLAMP The lug with the integrated Nemo seat clamp permits the
T best connection between the seat stays and the horizontal tube offering an ideal weld
b°
a° surface and avoiding any stress concentration.
be
d Tu reach
TAPERED HEAD TUBE & COLUMBUS FUTURA DISC FORK The 1” 1/2 oversized
Hea
fork with tapered head tube guarantees the best driving precision even at higher speeds,
making Veltrix incomparable in direction changes. The cable passage is completely
internal either for mechanical or electronic assemblies, improving aerodynamics and frame
aesthetics.
stack
k
For
WINGED DROPOUTS Dropouts’s winged shape recall Cinelli Italo Lupi’s iconic winged C.
S1
S
Design, function and heritage merge in one single detail. The beautiful ‘C’ Winged logo has
been casted into the Nemo stainless steel dropouts to create a unique and elegant effect
that increases the originality of this Italian Made frame. The dropout design is provided
R E
with a curved surface that allows an optimum tig welding of the rear stays and the
F C
possibility to adapt to all frame sizes.
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 480 455 510 506 110 71 74,5 45 405 572 967 70 368 735 510 369
S 510 485 520 516 120 71,5 74 45 405 573 968 70 368 760 520 371
M 540 515 535 531 145 72,5 73,5 45 405 575 969 70 368 782 547 373
L 560 535 550 545 160 73 73,5 45 405 585 980 70 368 799 564 383
XL 590 565 575 570 185 73 73 45 408 605 1003 70 368 823 587 395
xXL 610 585 590 584 210 73,5 72,5 45 410 609 1005 70 368 845 643 397
assembly
RED ETAP axs DURA-ACE DISC DI2 ULTEGRA DISC DI2 ULTEGRA DISC frame SPECS
Drivetrain Sram Red Etap AXS Shimano Dura-Ace 9170 Shimano Ultegra 8070 Shimano Ultegra 8020 Sizes XS (48) - S (51) - M (54) - L (56) - XL (59) - XXL (61) / Made to Measure
Handlebar FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR FSA Metron 5D ACR Material Columbus Spirit HSS Tubeset
Stem / / / / Headset IS 42/28,6 | IS 52/40
Seatpost Integrated Integrated Integrated Integrated Seatpost Ø 27,2 mm
Shifters Sram Red Etap AXS Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8020 Seat Clamp Integrated
Brakes Sram Red Shimano Dura-Ace R9170 Shimano Ultegra R8070 Shimano Ultegra R8070 BB Shell BSA 68 mm / Press Fit 86,5 x 41 (Custom)
Rotors Sram Centerline XR 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Shimano 160 - 140 mm Ft. derailleur Clamp Ø 31,7 mm
Ft. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Routing External / Internal Hydraulic Disc Brake Housing
R. derailleur Sram Red Etap AXS Shimano Dura-Ace R9150 Shimano Ultegra R8050 Shimano Ultegra R8000 Color Orange Blossom Special (+3 Custom colors and +33 Colors matt or glossy)
Crankset Sram Red Etap AXS 48/35t* Shimano Dura-Ace R9100 52/36t* Shimano Ultegra R8000 52/36t* Shimano Ultegra R8000 52/36t* Tyre Clear. up to 700x28 mm
Cassette Sram Red Etap AXS 10/28t* Shimano Dura-Ace R9100 11/30t* Shimano Ultegra R8000 11/30t* Shimano Ultegra R8000 11/30t* Fork Columbus Futura Disc 1-1/8” - 1-1/2” Carbon Monoc.
Chain Sram Force Flathead Shimano Dura-Ace R9100 Shimano Ultegra R8000 Shimano Ultegra 8000 Weight Frame 1850 g. (size M) Fork 440 g. (uncut)
Wheelset Fulcrum Wind 550 DB Fulcrum Wind 550 DB Fulcrum 600 DB Fulcrum 600 DB Brake Flat Mount Disc Brake, rotor size up to 160 mm
Tyres Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Vittoria Zaffiro pro 700x28 Dropouts ST Rear TA Ø 12x142mm - M12x173 / Front TA Ø 12x100mm - M12x119
Saddle SSM Shortfit SSM Shortfit SSM Shortfit SSM Shortfit Highlights Frame / Fork / Ft. Derailleur Clamp / Ft. & Re. Skewers / Headset
29ph: Alessandro Trovati
NEMO TIG SPECIAL COLORS
NEMO TIG, NEMO TIG DISC & NEMO TIG GRAVEL COLORS /
GLOSSY FINISH ONLY
rainbow green pink gold pink
DECALS COLOR OPTION: BLACK OR WHITE
NEMO TIG FACTORY COLORS
black dog anthracite silver silver bullet pearl white champagne
deep red cherry bomb radiant orange racing red copper brown
moka eggplant marc purple haze deep pink pink
blue turquoise light blue watergreen sugar paper sun
green special emerald green olivegreen green lime green yellow moon
NEMO TIG, NEMO TIG DISC & NEMO TIG
GRAVEL COLORS / GLOSSY OR MATT FINISH
gold grey room blue sky orange blossom special
DECALS COLOR OPTION: BLACK OR WHITE
311800 g 350 g BSA 28 PRO COMPETITION
NEMO TIG FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
FRAME KIT / CUSTOM ASSEMBLY
CLIMB
Steel is back with this competition frame made
with legendary Columbus Spirit triple-butted tubes. REACTIVITY
Entirely Made in Italy.
A classic look for this machine with contemporary
details, from the head tube to the monocoque carbon COMFORT
fork and molded chainstays to contrast transmission
force. The Tig welding technique increases the frame
stiffness and allows for custom geometries.
COLOR: Yellow Moon
32 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.INTEGRATED SEAT CLAMP The lug with the integrated Nemo seat clamp permits the
T1
best connection between the seat stays and the horizontal tube offering an ideal weld
T b°
a°
surface and avoiding any stress concentration.
e
Tub reach
TAPERED HEAD TUBE & COLUMBUS FUTURA FORK The 1.5” tapered head tube with
d
Hea
the Columbus Futura Caliper monocoque fork increases the reactivity of the frame and the
handling of the bike.
WINGED DROPOUTS The beautiful ‘C’ Winged logo has been casted into the Nemo
stack
k
stainless steel dropouts to create a unique and elegant effect that increases the originality
For
of this Italian Made frame. The dropout design is provided with a curved surface that
S1
S
allows an optimum tig welding of the rear stays and the possibility to adapt to all frame
sizes.
R E
F C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 480 455 510 506 110 71 74,5 45 405 572 967 70 368 735 510 369
S 510 485 520 516 120 71,5 74 45 405 573 968 70 368 760 520 371
M 540 515 535 531 145 72,5 73,5 45 405 575 969 70 368 782 547 373
L 560 535 550 545 160 73 73,5 45 405 585 980 70 368 799 564 383
XL 590 565 575 570 185 73 73 45 408 605 1003 70 368 823 587 395
xXL 610 585 590 584 210 73,5 72,5 45 410 609 1005 70 368 845 643 397
CUSTOM assembly
ULTEGRA frame SPECS
Drivetrain Shimano Ultegra 8000 Sizes XS (48) - S (51) - M (54) - L (56) - XL (59) - XXL (61) / Made to Measure
Handlebar Cinelli Vai Material Columbus Spirit HSS Tubeset
Stem Cinelli Vai Headset IS 42/28,6 | IS 52/40
Seatpost Cinelli Vai Ø 27,2 Seatpost Ø 27,2 mm
Shifters Shimano Ultegra R8000 Seat Clamp Integrated
Brakes Shimano Ultegra R8000 BB Shell BSA 68 mm / Press Fit 86,5 x 41 (Custom)
Rotors / Ft. derailleur Clamp Ø 31,7 mm
Ft. derailleur Shimano Ultegra R8000 Routing External
R. derailleur Shimano Ultegra R8000 Color Yellow Moon (+3 Custom colors and +33 Colors matt or glossy)
Crankset Shimano Ultegra R8000 52/36t* Tyre Clear. up to 700x28 mm
Cassette Shimano Ultegra R8000 11/30t* Fork Columbus Futura Calipoer 1-1/8” - 1-1/2” Carbon Monoc.
Chain Shimano Ultegra 8000 Weight Frame 1800 g. (size M) Fork 350 g. (uncut)
Wheelset Fulcrum Racing 600 Brake Standard Rim Brake
Tyres Vittoria Zaffiro pro 700x28 Dropouts ST Front QR 100 mm - Rear QR 130 mm
Saddle Cinelli SSM Squadra Highlights Frame / Fork / Ft. Derailleur Clamp / Headset
*Differenti opzioni diponibili
331830 g 670 g ITA 25 PRO COMPETITION
SUPERCORSA FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
FRAME KIT
CLIMB
The legend, racing for more than 40 years, with all the
technological updates. REACTIVITY
A modern steel classic and always at the top of the range.
For true connoisseurs of traditional diamond frame with
horizontal top tube. While many claim roots to cycling’s COMFORT
storied past, the Supercorsa stays true to itself. Made in
Italy in 17 sizes as well as custom sizes, and 8 colorways.
34 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.T
CINELLI SPOILER Microcast Cinelli “Spoiler”bottom bracket.
a° b°
reach Unmistakable!
COLUMBUS STEEL Original fastback seat stay designed by Cino Cinelli. Columbus
top-range steel, enriched with Niobium and drawn in traditional diameters.
stack
ARTISAN DETAILS Jewelry-finish chromium-plated lugs with artisan attention to
S
detail.
R E
F C
WB
Colori di serie:
BIANCO PERLA BLACK TIE
AZZURRO LASER BLU CHINA
TITANIUM GREY GIALLO CURRY
VERDE JAGUAR ROSSO FERRARI
GEOMETRy
T A B R C F WB E STACK REACH
48 510 72 74,5 50 401 557 984,5 66 486 374
49 515 72 74,5 50 402 571 963 69 495 377
50
51
520 72,5 74,5
525 72,5 74
50
50
402
402
573
573,2
964,5
964
70
73
505
513
379
377
frame SPECS
Sizes 48 to 64 (1 cm) - Made to Measure
52 535 72,5 74 50 403 583 975 73 523 384
Material Columbus SL Double Butted Tubeset
53 540 73 74 45 405 579 972,5 73 533 387 Headset EC 30/25,4-24TPI | EC 30/26
54 545 73 73,5 45 405 579,3 973 73 541 383 Seatpost Ø 27,2 mm
55 550 73 73,5 45 405 584 978 73 550 387 Seat Clamp Integrated
56 560 73 73,5 45 405 594 988 73 560 394 BB Shell ITA 70 mm
57 565 73 73,5 45 406 599 994 73 570 396 Ft. derailleur Braze-On
58 570 73 73 45 407 599,5 995 73 578 393 Routing Rear Brake Internal Routing -Downtube Shifter Bosses
575 73 73 45 408 604 1001 73 587 396 Color Rosso Ferrari-Bianco Perla-Azzurro Laser-Titanium Grey-Verde Jaguar-Black Tie-Blu China-Giallo Curry
59
Tyre Clear. up to 700x25 mm
60 580 73 73 45 409 609 1007 73 597 398
Fork Columbus SL 1” Threaded
61 580 73 73 45 409 609 1007 73 606 395
Weight Frame 1830 g. (size M) Fork 670 g. (uncut)
62 590 73 73 45 409 619 1017 73 616 402 Brake Standard Rim Brake
63 590 73 73 45 410 619 1018 73 626 399 Dropouts ST Front QR 100 mm - Rear QR 130 mm
64 595 73 73 45 410 620 1019 73 635 401 Highlights Frame / Fork
35980 g 380 g BSA 25 PRO COMPETITION
LASER MIA FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
AERODYNAMIC
FRAME KIT
CLIMB
Since 1981 the Cinelli Laser has represented the pinnacle
of made-to-measure custom Italian framebuilding, winning REACTIVITY
more track and team time trial world and Olympic gold
medals than any other bicycle in the history of the sport.
The new Laser Mia is the first-ever hi-modulus aerospace COMFORT
carbon fiber Cinelli Laser to be made available to the
general public. The frame has been designed by the original
Laser team and is 100% made in Italy, combining avant-
garde material technologies and construction methods with
artisanal mastery that no mass production can imitate.
COLOR: Azzurro Laser
36 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.Like every Laser frame that has preceeded it, the heart of the Laser Mia’ s
performance innovation lies in the radical construction of the bottom bracket area,
which allows for the production of the signature Laser stiffness and extremely
responsive ride quality, at a far lower weight (980 g) than any other custom carbon
fiber frame currently available on the market.
T1
T
a° b°
reach ICONIC ELEMENTS: All of the iconic elements identifying the Laser are maintained:
ube
the fin under the bottom bracket, the fittings of the joints and the passage of the rear
dT
wheel housed in the seat tube. An anodized aluminum cap is positioned under the
Hea
bottom bracket fin to allow easy access for routing.
CNC DROPOUTS: The rear aluminum CNC dropouts sandwich wrap the central
stack
k
carbon part fully integrated to the rear stays.
For
S1
S
R E
F C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
48 500 480 510 504 95 71,5 74,5 45 405 567 961 70 368 733 495 373 frame SPECS
49 510 490 515 509 100 72 74,5 45 405 568 962 70 368 743 501 376
Sizes XS (45) - S (48) - M (50) - L (53) - XL (56)
50 520 500 520 514 110 72,5 74,5 45 405 569 963 70 368 753 512 378
Material High Modulus Carbon Fibre
51 530 530 525 518 120 72,5 74,5 45 405 572 967 70 368 762 522 378 Headset IS 42/28,6 | IS 42/40
52 540 520 530 523 130 73 74,5 45 405 572 967 70 368 772 533 379 Seatpost Ø 27,2 mm
53 550 530 535 527 140 73 74 45 405 575 970 70 368 781 543 380 Seat Clamp Ø 31,8 mm (Included)
54 560 540 545 536 150 73 73,5 45 405 580 975 70 368 790 552 381 BB Shell BSA 68 mm
55 570 550 550 541 160 73 73,5 45 405 585 980 70 368 799 562 384 Ft. derailleur Braze-On
56 580 560 555 546 170 73 73,5 45 405 590 985 70 368 809 571 386 Routing Internal - Di2/EPS compatible
Color Azzurro Laser
57 590 570 565 555 180 73 73 45 405 595 990 70 368 818 581 387
Tyre Clear. up to 700x25 mm
58 600 580 570 560 190 73 73 45 405 600 995 70 368 827 591 389
Fork Cinelli Laser Monocoque 1/8”
59 610 590 580 570 200 73 73 45 405 610 1005 70 368 837 600 397
Weight Frame 980 g. (size 52 with fittings) Fork 380 g. (uncut)
60 620 600 590 579 210 73,5 73 45 405 614 1009 70 368 847 611 403 Brake Standard Rim Brake
61 630 610 600 588 220 73,5 72,5 45 405 618 1013 70 368 855 621 404 Dropouts ST Front QR 100 mm - Rear QR 130 mm
62 640 620 605 592 225 74 72,5 45 405 618 1013 70 368 865 628 407 Highlights /
37GRAVEL
ph: Alessandro Trovati
1000 g 550 g BB 700X47c PERFORMANCE
KING ZYDECO FRAME
WEIGHT (M)
FORK
WEIGHT
86,5X46
PRESSFIT
650bX2,1”
MAX TYRE
GRAVEL
FRAME KIT / CUSTOM ASSEMBLY
TRAIL
This unique frame allows you to ride fast on different BIKE RADAR AWARD
surfaces: asphalt, white roads and rough terrain thanks to COMFORT
the possibility of assembling 700c and 650b wheels with
tires up to 2,1”. The carbon monocoque construction and
its racing geometry make this frame light and extremely
fast. Perfectly suitable for long distance gravel races and
also ready for bike packing explorations.
COLOR: Deep Waters
40 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.T1
T
reach
b° NEW COLUMBUS FUTURA CROSS FORK The new Columbus Futura Cross
a°
ube
monocoque fork is suitable for thru axle flat mount disc, with internal cable
dT
routing and wheel passage up to 650b x 2,1” or 700 x 47c. The special dropouts
Hea
allow to change the rake from 47 to 52mm to achieve the best tuning of the
bike.
KEVLAR SHIELD Zydeco King is made to ride fast on all kind of terrains. The
k
For
possibility to use MTB style tires can rise small debris form the terrain that can
stack
impact the lower front part of the frame. For this reason a shield of Kevlar has
S1
S
been laid to protect the carbon structure from any damage.
E
DOUBLE RESPONSE SYSTEM The special design of the down tube which
R
F
continues below the BB area increases the stiffness of the lower part of the
C frame for an improved efficiency of the pedaling, while the continuous design of
WB the rear stays into the top tube raises the comfort and allows to ride for hours
with the best feel.
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
S 480 435 530 513 100 70 73 47/52 430 588 1010 70 395 745 519 371
M 510 468 550 530 130 71,5 73 47/52 430 595 1018 70 395 776 550 380
L 530 493 570 550 150 72,5 72,5 47/52 430 602 1024 70 395 800 576 389
XL 550 506 590 568 175 72,5 72,5 47/52 430 621 1044 70 395 821 599 400
SETUP COMPATIBILITY
MIN MAX REAR DERAILLEUR
1x flat ring size 46 T 50 T Long Cage Only
1x sram ring size 42 T 46 T Long Cage Only
2x ring size 46/36 T 52/36 T Long Cage Only
assembly & custom assembly
GRX 1X MIX ULTEGRA DISC RIVAL 1X frame SPECS
Drivetrain Shimano GRX Shimano Ultegra 8020 Sram Rival 1x11 Disc Sizes S (48) - M (51) - L (53) - XL (55)
Handlebar Cinelli Handlebar 6061 - Ø 31,8 - Drop 120mm(40) 130mm(42) - Reach 70mm - Flare Angle 12° / S 42 - M 42 - L 44 - XL 44 Cinelli Vai Cinelli Vai Material Columbus Carbon Monocoque
Stem Cinelli 6061 Stem - Ø 31,8 - Angle 6° - H 40mm / S 90 - M 100 - L 100 - XL 110 Cinelli Vai Cinelli Vai Headset IS 42/28,6 | IS 52/40 Columbus Compass 1-1/2” (Included)
Seatpost Cinelli Seat Post 6061 - Ø 27,2 - L350 Cinelli Vai Ø 27,2 Cinelli Vai Ø 27,2 Seatpost Ø 27,2 mm
Shifters Shimano GRX ST-RX600 Shimano Ultegra R8020 Disc Sram Rival Seat Clamp Ø 31,8 mm (Included)
Brakes Shimano GRX BR-RX400 Shimano Ultegra R8070 Flat Mount Sram Rival Hydro Disc BB Shell BB386EVO 86,5 x 46 mm
Rotors Shimano SM-RT64 160 mm Shimano 160 mm front - 160 mm rear Centerline 160 mm Ft. derailleur Clamp Ø 31,8 mm
Ft. derailleur / Shimano Ultegra R8000 / Routing Internal - Di2/EPS Compatible
R. derailleur Shimano GRX RD-RX812 Shimano Ultegra R8000 Sram Rival Long Cage Color Deep Water
Crankset Shimano GRX FC-RX810-1 - 42T / S 170 - M 172,5 - L 172,5 - XL 175 Shimano Ultegra R8000 46/36t Sram Rival 42t Tyre Clear. up to 700x47 C / 27,5x2.1 inc
Cassette CS-M7000 SLX - 11 Speed 11-42T Shimano Ultegra R8000 11/32t Sram Rival 11/42t Fork Columbus Futura Cross 1-1/8” - 1-1/2” Carbon Monoc.
Chain KMC X11 EPT Shimano Ultegra 8000 Sram Rival Weight Frame 1000 g. (size M) Fork 550 g. (uncut)
Wheelset Fulcrum Racing 600 DB Fulcrum Rapid Red 500 DB Fulcrum Rapid Red 500 DB Brake Flat Mount Disc Brake, rotor size up to 160 mm
Tyres WTB Riddler 700x37 Tan Sidewall WTB Riddler 700x37 Tan Sidewall WTB Riddler 700x37 Tan sidewall Dropouts ST Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x132
Saddle SSM Shortfit Startup Wide SSM Shortfit SSM Shortfit Highlights Extra Hanger / Di2 - EPS Cable Insert / Ft. & Re. Skewers
4110,3 Kg BSA 40 PERFORMANCE
ZYDECO BIKE
WEIGHT (M)
BOTTOM
BRACKET
mm
MAX TYRE
GRAVEL
COMPLETE BIKE
TRAIL
Zydeco keeps providing the best for gravel, representing a
unique union of road, touring and gravel seeking. Say Zydeco COMFORT
and you say gravel. And Zydeco keeps up with promises,
always evolving while keeping truel to its soul. In this faithful
claim for novelty, the improved braking efficiency of thru axle
and the hydraulic braking system join the gravel specific Shimano GRX
groupset, featuring increased reliability in terms of gear efficiency with
its Shadow RD+ chain stabilization system and the most ergonomic
leverage with curved shape and anti-slip coating for ideal control on all-
terrain. New San Marco Era saddle with matching Zydeco colors.
COLOR: Chasing After Rainbows
42 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.BIKE PACKING READY The new Zydeco frame make further steps toward gravel and bike
T1 packing universe. The increased wheel base allows an easy use of fenders reducing the risk
T of toe overlap and the 2 extra rivets on the top tube allows the best and secure assembly
a° reach b°
e of node bags.
Tub
d
Hea
COLUMBUS FUTURA GRAVEL MONOCOQUE FORK Zydeco is provided with the new
Columbus Futura Gravel monocoque fork 1” 1/4, with internal cable routing, flat mount
disc up to 160mm, thru axle, tyre passage up to 40c and the possibility of assembling a
k
mudguard: the perfect gravel machine that can quickly turn into a travel companion.
stack
For
S1
S
GRAVEL KIT The frame of the new Zydeco allows internal cable passages for the rear disc
brake and front/rear shifters resulting in a clean configuration under any aspects, visual
R E and mechanical.
F C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK ST.OV STACK REACH
XS 490 447 510 504 100 70,5 74,5 47 440 58 1010 71 382 748 510 371
S 510 467 520 514 120 71 74,5 47 440 58 1017 70 382 768 530 375
M 540 497 539 530 140 71,5 74 47 440 59 1025 70 382 793 551 380
L 560 517 560 549 160 72 73,5 47 440 60 1037 70 382 813 572 390
XL 590 547 580 570 180 72,5 73 47 440 61 1047 70 382 907 837 399
assembly
Handlebar
SHIMANO GRX 2X10 SPEED
Cinelli 6061 / Ø 31,8 / Drop 120mm(40) 130mm(42) - Reach 70mm / Flare Angle 12° / XS 40 - S 40 - M 42 - L 42 - XL 42
frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / XS 90 - S 90 - M 100 - L 110 - XL 110 Sizes XS (49) - S (51) - M (54) - L (56) - XL (59)
Seatpost Cinelli 6061 Ø 31,6 L 350 Material Columbus Zonal Triple Butted Alloy
Shifters Shimano GRX ST-RX400 Headset IS 42/28,6 | IS 47/33
Brakes Shimano GRX BR-RX400 Seatpost Ø 31,6 mm
Rotors Shimano SM-RT64 160mm Seat Clamp Ø 34,9 mm
Ft. derailleur Shimano GRX FD-RX400 BB Shell BSA 68 mm
R. derailleur Shimano GRX RD-RX400 Ft. derailleur Clamp Ø 34,9 mm
Crankset Shiamno GRX FC-RX600 46/30 / XS 170 - S 170 - M 172,5 - L 172,5 - XL 175 Routing Internal
B. Bracket Shimano SM-BB52 Color Chasing After Rainbows
Cassette Shimano CS-HG500-10 / 10 Speed / 11-32t Tyre Clear. up to 700x40 mm
Chain Kmc X10 Fork Columbus Futura Gravel 1-1/8” - 1-1/4” Carbon Monocoque
Wheelset Shining (A250) 32h Shimano Hub (RS-470) front & rear Weight Frame 1760 g. (size M) Fork 450 g. (uncut)
Tyres WTB Riddler 700x37c Tan Sidewall Brake Flat Mount, Rotor Size Up to 160 mm
Saddle Cinelli SSM Era Dropouts ST Rear TA Ø 12x142mm - M12x165 / Front TA Ø 12x100mm - M12x119
Tape Cinelli Cork Highlights Front & Rear Fenders / Rear Rack Eyelets / Extra Hanger / Fast Fuel Eyelets
4310,9 Kg BSA 42 PERFORMANCE
ZYDECO LALA BIKE
WEIGHT (M)
BOTTOM
BRACKET
mm
MAX TYRE
GRAVEL
COMPLETE BIKE
TRAIL
Zydeco LaLa is the new member of the Zydeco gravel family.
The frame is made of triple-butted Columbus Zonal aluminium COMFORT
tubes, fitted with Shimano Sora and two front chain rings for
those who prefer them to 1x set up. Columbus Futura Disc
1-1/8” fork, flat mount mechanical disc brakes with discs up
to 160mm. External cable routing facilitate the maintenance
of this machine designed to conquer new riders to the
increasingly popular discipline of gravel.
COLOR: Orange Juce Blues
44 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.CABLE EASY ACCESS Designed for adventure, the choice of full cable guide protection
T1 of the control cables to easily fit bags to the frame when bike packing, but you can also
T
a° reach b° opt for the classic rack that can be fixed to the special studs provided on the frame. The
ube possibility to mount mudguards integrates the versatility of Zydeco LaLa.
dT
Hea
COLUMBUS ZONAL TUBES The frame is made of triple-butted Columbus Zonal
aluminium tubes, making it light and resistant: ready to hit dirt tracks or long trips with
bags on board.
k
stack
For
FLATMOUNT DISC & THRU AXLE The flat mount disc brakes combined with the through
S1
axle ensure total control of the bike even when descending with a full load.
S
R E
F C
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK STACK REACH
XS 490 450 510 501 90 69,5 74,5 45 440 585 1015 71 390 508 369
S 510 470 520 515 110 70 74,5 45 440 592 1023 70 390 528 374
M 540 500 540 535 130 70,5 74 45 440 604 1034 70 390 549 383
L 560 520 560 553 150 71 73,5 45 440 615 1045 70 390 570 391
XL 590 550 580 574 170 71,5 73 45 440 625 1055 70 390 590 400
assembly
Handlebar
SHIMANO SORA 9V
Cinelli 6061 Ø 31,8 Drop 120 mm (40) 130 mm (42) - Reach 70 mm - Flare angle 12° / XS 40 - S 40 - M 42 - L 42 - XL 42
frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / XS 90 - S 90 - M 100 - L 110 - XL 110 Sizes XS (49) - S (51) - M (54) - L (56) - XL (59)
Seatpost Cinelli 6061 Ø 31,6 L 350 Material Columbus Zonal Triple Butted Alloy
Shifters Shimano Sora (ST-R3000) Headset ZS 44/28,6 | ZS 44/30
Brakes Tektro (MD-C510) / Mechanical front & rear Seatpost Ø 27,2 mm
Rotors 160 mm Disc (front & rear) Seat Clamp Ø 31,8 mm
Ft. derailleur Shimano Sora (FD-R3000) BB Shell BSA 68 mm
R. derailleur Sram Apex1 - Long Cage - 11 Speed Ft. derailleur Clamp Ø 31,8 mm
Crankset FSA Omega MegaExo 48/32t / XS 170 - S 170 - M 172,5 - L 172,5 - XL 175 Routing External (Bike Packing Ready)
B. Bracket Fsa (BB 4000) / BSA 68 mm Color Orange Juice Blues
Cassette Sunrace / 9s / 11-34t Tyre Clear. up to 700x42 mm
Chain Kmc X9 Fork Columbus Disc 1-1/8” Alu/Carbon
Wheelset Shining (A250) 32h Formula Hub (RX-812) front / Shining (A250) 32h Formula Hub (RX-142) rear Weight Frame 1760 g. (size M) Fork 740 g. (uncut)
Tyres Kenda Flintridge 700x35c Brake Flat Mount, Rotor Size Up to 160 mm
Saddle Cinelli SSM Era Dropouts ST Rear TA Ø 12x142mm - M12x160 / Front TA Ø 12x100mm - M12x119
Tape Cinelli Cork Highlights Front & Rear Fenders / Rear Rack Eyelets / Extra Hanger / Fast Fuel Eyelets
4512,8 Kg BB 700X44 PERFORMANCE
ZYDECO electric mud BIKE
WEIGHT (M)
86,5
PRESSFIT
650bX48
MAX TYRE
GRAVEL
COMPLETE BIKE
TRAIL
When the paved road ends leaving the path to the dirt road,
the real fun begins with the new Zydeco E-Mud, equipped COMFORT
with the Mahler Ebikemotion X35 engine integrated in the
rear wheel hub. The bike, with Columbus carbon monocoque
frame and clean aesthetics, has been designed and engineered
to make you experience the most natural assisted ride. The
engine system, 250Wh battery included, weights just 3.5 kg.
The climbs, whether on asphalt or dirt roads, will be the most
exciting experience ever!
COLOR: Fullcolor
46 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.MAHLER EBIKEMOTION X35 MOTOR with 45Nm torque and integrated 250Wh battery,
T1
allows you to extend the range housing an additional external battery (210Wh) in the seat
b°
a° tube bottle-cage.
ub e
dT reach
BIKE PACKING READY thanks to the double rivets positioned on the horizontal tube and
H ea
the possibility of mounting drybag holders on the fork blades. Ready for mounting a rear
rack.
rk
stack
MONOCOQUE CARBON FIBER FRAME is extremely light and responsive and thanks to
Fo
the particular sloping geometry, allows an optimal and comfortable positioning for a wide
S1
S
range of cyclists (men and women). Possibility to mount wheels with tires up to 44mm for
the version with 700 rims and 48mm with 650B rims.
R E
F C
WB
GEOMETRy
S1 S T1 H/T A B R C F WB E STACK REACH
S 450 390 529 125 70,5 73 47 423 598 1009 75 556 373
M 480 420 553 150 71 73 47 423 611 1023 75 582 382
L 510 450 576 175 71,5 73 47 423 624 1036 75 608 392
XL 550 490 600 200 72 73 47 423 636 1048 75 633 401
assembly
Handlebar
SHIMANO GRX MIX 1X11
Cinelli 6061 Ø 31,8 Drop 120 mm (40) 130 mm (42) - Reach 70 mm - Flare angle 12° / S 40 - M 42 - L 42 - XL 42
frame SPECS
Stem Cinelli 6061 Ø 31,8 Angle 6° H 40 mm / S 90 - M 100 - L 110 - XL 110 Sizes S (45) - M (48) - L (51) - XL (55)
Seatpost Cinelli 6061 Ø 27,2 L 350 Material Columbus Carbon Monocoque
Shifters Shimano GRX ST-RX400 1X11 Headset IS 42/28,6 | IS 52/40
Brakes Shimano GRX 400 BR-RX400 Seatpost Ø 27,2 mm
Rotors Shimano SM-RT70 160mm Center Lock Seat Clamp Ø 31,8 mm Included
Ft. derailleur / BB Shell Press Fit 86,5x41
R. derailleur Shimano GRX RD-RX812 Ft. derailleur Braze-on
Crankset Shimano GRX 600 FC-RX600-1 / 40T/ S 170 - M 172,5 - L 172,5 - XL 175 Routing Internal - Di2/EPS compatible
B. Bracket Shimano Pressfit 86,5X41 mm Color Fullcolor
Cassette Shimano SLX CS-M8000 / 11-42 / 11s Tyre Clear. up to 700x44 / 650x48
Chain Shimano CN-HG601 Fork Columbus Disc tapered 1-1/2” Carbon Monocoque
Wheelset HY-NDR30AC Weight Frame 1420 g. (size M) Fork 450 g. (uncut)
Tyres CST PIKA 700x38C Brake Flat Mount, Rotor Size Up to 160 mm
Saddle Selle Italia X3 BOOST Dropouts ST Front TA Ø12x100mm / M12x1,5 L125mm skewer (included) Rear Ebikemotion axle standard O.L.D. 136mm
Tape Cinelli Cork Highlights Di2/EPS cable inserts / Front skewer / Rear carrier eyelets
471900 g 450 g BSA 40 PERFORMANCE
NEMO TIG GRAVEL FRAME
WEIGHT (M)
FORK
WEIGHT
BOTTOM
BRACKET
mm
MAX TYRE
GRAVEL
FRAME KIT / CUSTOM ASSEMBLY
TRAIL
Custom geometry, 100% Made in Italy with the
legendary Columbus Spirit HSS triple thickness COMFORT
steel tubes. Flat mount disc brakes, increased wheel
passage for great gravel adventures and high speed
downhill. Steel is back. Steel is back to meet the
needs of sophisticated riders who demand the most
advanced technology with an eye to tradition.
COLOR: Green Special
48 The image has the sole purpose of presenting the product.
Some assembly specifications may vary.INTERNAL CABLE ROUTING & FAST FUEL Gravel version of the Cinelli Nemo Tig frame,
T1 made in Italy with Columbus Spirit HSS tube set, best meet the needs of comfort, strength
T
b° and lightness required by Gravel competitions. Internal cables and rivets pass through the
a°
be reach
horizontal tube to quickly transform the bike into an elegant means of transport for bike
d Tu
packing travelling. The Columbus Futura Gravel monocoque fork also allows the installation
Hea
of comfortable mudguards.
GRAVEL WIDER CLEARANCE & LONGER CHAIN STAYS The geometry of the frame
stack
has been revised to increase the wheel passage and allow fitting of tyres up to 40mm. The
k
For
extended rear stays ensures greater stability of the bike in the fastest dirt tracks.
S1
S
WINGED DROPOUTS New design for the 12mm through axle dropouts: the engraving of
R E the famous ‘C’ wing enhances the frame and the through axle facilitates fitting disc brakes
F C while maintaining the wheels alignment.
WB
GEOMETRy
S1 S T1 T H/T A B R C F WB E FORK STACK REACH
XS 480 455 514 507 100 71 75 47 430 582 1003 68 382 508 373
S 510 482 525 520 115 71 75 47 430 594 1015 68 382 522 380
M 540 513 540 535 140 72 74 47 430 597 1018 68 382 550 382
L 560 536 554 550 150 73 74 47 430 596 1017 68 382 563 387
XL 590 565 579 575 175 73 73 47 430 616 1036 68 382 587 400
xXL 610 585 594 587 200 73 73 47 430 620 1041 68 382 613 400
CUSTOM assembly
ULTEGRA DISC RIVAL 1X frame SPECS
Drivetrain Shimano Ultegra 8020 Sram Rival 1x11 Disc Sizes XS (48) - S (51) - M (54) - L (56) - XL (59) - XXL (61) / Made to Measure
Handlebar Cinelli Vai Cinelli Vai Material Columbus Spirit HSS Tubeset
Stem Cinelli Vai Cinelli Vai Headset IS 42/28,6 | IS 47/33
Seatpost Cinelli Vai Ø 27,2 Cinelli Vai Ø 27,2 Seatpost Ø 27,2 mm
Shifters Shimano Ultegra R8020 Disc Sram Rival Seat Clamp Integrated
Brakes Shimano Ultegra R8070 Flat Mount Sram Rival Hydro Disc BB Shell BSA 68 mm / Press Fit 86,5 x 41 (Custom)
Rotors Shimano 160 mm front - 160 mm rear Centerline 160 mm Ft. derailleur Clamp Ø 31,7 mm
Ft. derailleur Shimano Ultegra R8000 / Routing External / Internal Hydraulic Disc Brake Housing
R. derailleur Shimano Ultegra R8000 Sram Rival Long Cage Color Green Special (+3 Custom colors and +33 Colors matt or glossy)
Crankset Shimano Ultegra R8000 46/36t Sram Rival 42t Tyre Clear. up to 700x40 mm
Cassette Shimano Ultegra R8000 11/32t Sram Rival 11/42t Fork Columbus Futura Gravel 1-1/8” - 1-1/4” Carbon Monoc.
Chain Shimano Ultegra 8000 Sram Rival Weight Frame 1900 g. (size M) Fork 450 g. (uncut)
Wheelset Fulcrum Rapid Red 500 DB Fulcrum Rapid Red 500 DB Brake Flat Mount Disc Brake, rotor size up to 160 mm
Tyres WTB Riddler 700x37 Tan Sidewall WTB Riddler 700x37 Tan sidewall Dropouts ST Rear TA Ø 12x142mm - M12x173 / Front TA Ø 12x100mm - M12x119
Saddle SSM Shortfit SSM Shortfit Highlights Frame / Fork / Ft. Derailleur Clamp / Ft. & Re. Skewers / Headset
49You can also read
