www.novotech.it
Company Overview
2021 NOVOTECH Proprietary
Background & Mission
Novotech is an engineering innovation partner for companies operating in aerospace field and
advanced technology sectors, founded in 1992 as spin-off from the Department of Aerospace
Engineering of the University of Naples “Federico II”.
The Company has developed a specific - and nowadays well consolidated know-how especially
focused on design, production and certification of aircrafts and part of them, including signal
processing, static and dynamic experimental testing.
Novotech can count also on advanced capabilities in automated composites fabrication
processes.
Novotech is located in
Campania (Casoria) and
in Puglia (Avetrana). Production Plant (Avetrana): 1600 m2 + 200 m2 (offices)
It covers a strategic
business position in the
centre of the
Mediterranean sea.
Production Plant (Casoria): 800 m2 2
2021 NOVOTECH Proprietary
Background & Mission
Novotech s.r.l. can be considered as a private and independent research center
focused on the development of new methods and technologies mainly for aerospace
sector, specialized on automated OoA composite manufacturing processes
3- DESIGN &
0-IDEATION 1-PROPOSAL 2-DEVELOPMENT 4-VALIDATION 5-LAUNCH
VERIFICATION
Customer Quote Concept Product Product
Down-Selection Engineering Validation Production
Call for Proposal
Market Research
IP Studies
Positioning
Feasibility Studies Concept (M&P) Design Design Validation Production Pre-Production
Development Development & Process Toolings & preparation
Verification Equipment process
Analysis Innovation Engineering, Validation, Refinement & Consolidation
3
2021 NOVOTECH Proprietary
Relevant Technologies
▪ Manufacturing, Curing, Machining and Repair of Composites
AFP Cell
ABB IRB-6640/205/2.75
standard robot 8-fibre
placement head with 2-T
synchronised positioner,
developed by Coriolis
Composites s.a.s. (France),
mounted on a linear axis with a
working length of 3m. Material Vertical Machine Center ACR3 Dual Zone Hot
heating can be performed by a Hot Press for Continuous Forming – MV214-P12B from Quaser (Lathe). Bonder - with SR
3kW laser or IR lamp. Variable Temperature (up to 400°C) and Blanket kit from
Variable Pression (up to 20 bar) in different BriskHeat Corporation
zones, Working Area [m] 4.0*0.7.
Infuser Servo injector for HP-RTM/VARTM molds,
up to 4000cc per shot
Hypaject MKIII injection system thermostatted up to
Hot Press for RTM and CM Nr. 2 Composite Curing Ovens 10 bar injection pressure for RTM.
with plates of [m] 1.2 x 1.8, 400°C T=400°°C, size [m] 1.0 x 1.0 x 2.0 with Vacuum lines.
Insulated Plates. T= 250°C, size [m] 3.5x2x2 with Vacuum lines.
▪ Virtual Product Development
4
2021 NOVOTECH Proprietary
Work force and main Financial data
Financial data Workload Distribution
800.000,00 € 60%
R&D Engineering Manufacturing
700.000,00 €
50%
600.000,00 €
40%
500.000,00 €
400.000,00 € 30% 35%
300.000,00 €
20%
200.000,00 € 55%
10%
100.000,00 € 10%
- € 0%
2017 2018 2019
Turnover Return on Capital Employed
Work force
• Total : 27
• PhD: 2 Engineers and other graduates: 8
• Technicians: 12 Administrative: 5
5
2021 NOVOTECH Proprietary
R&I involvement
Networking and
Nr. of R&D proposal submitted/year (average) 15 Specialization
Nr. of quotations prepared/year (average) 70 across EU
On-going R&D projects 6
H2020 "Smart Green Integrated Transport“ and
Clean Sky 2 2
Italian Minister of Economical Development 1
Ministry of Education, University and Research. 2
On-going engineering & mnfg projects 7
6
2021 NOVOTECH Proprietary
Markets and main Partners
Markets
Partners
7
2021 NOVOTECH Proprietary
Work performed: Design & Structural verification
SPLICE STRAP
ENGINE FAIRING
WING
INTERFACE
8
2021 NOVOTECH Proprietary
Work performed: Design & Structural verification
Buckling Analysis (SOL 105) Fatigue Analysis
9
2021 NOVOTECH Proprietary
Work performed: Design & Manufacturing of Composite Aerostructures
by AFP Process - LAMITECH Project
DOUBLE CURVATURE COMPOSITE CONCEPT, DESIGN AND FEASIBILITY STUDY
PANEL WITH RAMP
MANUFACTURING
10
2021 NOVOTECH ProprietaryWork performed: Design & Manufacturing of Composite Aerostructures
by AFP Process - SPIA Project
M-346 FUSELAGE PORTION (scale 1:1)
NGTP VERTICAL FIN PORTION
(2.5mtx1.5mt)
A/C TAIL CONE PORTION (1/2 & 1/4)
including stringers laydown by AFP
process
11
2021 NOVOTECH ProprietaryWork performed: Design & Manufacturing of Composite Aerostructures
by RTM Process - Clean Sky 1 (as subco x REGIONAL Turboprop platform)
12
12
2021 NOVOTECH ProprietaryWork performed: Topology optimization-guided stiffening of composites
realized through Automated Fiber Placement
13
2021 NOVOTECH ProprietaryWork performed: Production of Technological demonstrators by AFPM
14
2021 NOVOTECH ProprietaryWork performed: Development of Cryogenic Tank for space applications
15
2021 NOVOTECH ProprietaryWork performed : NHYTE - H2020 (Smart, Green and Integrated Trasport)
New HYbrid THErmoplastic composite aerostructures manufactured by out of
autoclave continuous automated technologies (www.nhyte-h2020.eu)
16
2021 NOVOTECH ProprietaryWork performed : NHYTE - H2020 (Smart, Green and Integrated Trasport)
NHYTE project has developed new concepts and methodologies enabling the
realization of innovative and green integrated aero-structures made by a new
material thermoplastic material.
Such new material does not require autoclave consolidation (improved
cycle times and lower energy consumptions, greener production).
from Concept to Creation... Continuous Forming press developed by
NOVOTECH (Avetrana plant)
17
2021 NOVOTECH ProprietaryWork performed : NHYTE - H2020 (Smart, Green and Integrated Trasport)
Stringers produced by CF process
Curved Demo produced by ISC AFP (skin) and CF (stringers)
NHYTE material
18
2021 NOVOTECH ProprietaryMain on-going R&I Project: AIRGREEN 2 - H2020 (EU Clean Sky 2)
TOPIC: Advanced wing for regional A/C -
Technologies Development, Design and
Manufacturing for FTB#1
BriskHeat online 950 mm
monitoring equipment
(LRI process)
Topic Manager:
19
2021 NOVOTECH ProprietaryMain on-going R&I Project: TRINITI - H2020 (EU Clean Sky 2)
Multi-Material Thermoplastic high pressure Nitrogen Tanks for aircraft
24 months
01-OCT-19
JTI-CS2-2018- 819.071,25
CfP09-SYS-01-14
Type of Action: IA
650.000€
Topic Manager:
20
2021 NOVOTECH ProprietaryMain on-going R&I Project: TRINITI - H2020 (EU Clean Sky 2)
Multi-Material Thermoplastic high pressure Nitrogen Tanks for aircraft
21
2021 NOVOTECH ProprietaryMain on-going R&I Project: SWING - H2020 EU MISE
SWING- Smart WING for new generation civil UAV
PIAGGIO P180
22
2021 NOVOTECH ProprietaryMain on-going R&I Project: SWING - H2020 EU MISE
SWING- Smart WING for new generation civil UAV
NOVOTECH has contributed by re-designing and manufacturing of the P180 forward wing using highly
integrated (1 stage manufacturing process) and OoA production processes as Automated Fiber
placement for preforming followed by LRI.
23
2021 NOVOTECH ProprietaryMain on-going R&I Project: SEAGULL Aircraft (partial funding received by
Italian Ministry of Economic Development Call law 808/85)
The SEAGULL is a breakthrough with respect to the current transportation systems, a high
performing ultralight seaplane , easy and economical, operating from any infrastructure in
complete autonomy.
Patent n. 102017000131163 deposit November 16th, 2017.
Patent Title: Mechanisms for transforming an ultra-light aircraft into a sailing and motor-powered vessel.
24
2021 NOVOTECH ProprietaryMain on-going R&I Project: SEAGULL Aircraft (partial funding received by
Italian Ministry of Economic Development Call law 808/85)
Digital Twin based Approach
25
2021 NOVOTECH ProprietaryMain on-going R&I Project: SEAGULL Aircraft (partial funding received by
Italian Ministry of Economic Development Call law 808/85)
Wing static loading
26
2021 NOVOTECH ProprietaryMain on-going R&I Project: SEAGULL Aircraft (partial funding received by
Italian Ministry of Economic Development Call law 808/85)
27
2021 NOVOTECH ProprietaryMain on-going R&I Project: SEAGULL Aircraft (partial funding received by
Italian Ministry of Economic Development Call law 808/85)
Estimated Technical data
Performance Validation tests are ongoing as well as
LSA certification process
28
2021 NOVOTECH ProprietaryThank you
for your attention
If You Want To Go Fast, Go Alone.
If You Want To Go Far, Go Together.
