P_2014_00841 Revised Flood Risk Assessment Received 04.12.14
Peak Associates Environmental
Consultants Ltd
North West Office
38 Padgate Lane
Padgate
Warrington
WA1 3RU
SITE CONDITION REPORT
(For Permit Application Stage)
For The
Willshee’s Skip Hire Site
At
Glensyl Way,
Burton upon Trent
Document Prepared On Behalf of Willshee’s Skip Hire
Paul Palgrave BSc (Hons) ARSM MSc C.Geol FGS
Date: October 2013
Report QA No. 13079
QA Auditor: Jo Matthew BSc (Hons) MScWillshee’s Glensyl Way. Burton upon Trent Contents Page No 1.0 SITE DETAILS 1 2.0 CONDITION OF THE LAND AT PERMIT ISSUE 1 2.1 Introduction 1 2.2 Site Description Prior To Commencement Of Permitted Activity 2 2.3 Site Drainage 2 2.4 Site Environmental Setting 3 2.4.1 Geology 3 2.4.2 Hydrogeology 3 2.4.3 Surface Water 3 2.4.4 Landfills and Other Waste Sites 3 2.5 Pollution Incidents 3 2.6 Historical Land Uses & Associated Sources of Potential Contamination 4 2.7 Intrusive Ground Investigation Works 4 2.7.1 Introduction 4 2.7.2 Scope Of Investigation 4 2.7.3 Strata Encountered 5 2.7.4 Groundwater Observations 6 2.7.5 Visual and Olfactory Evidence Of Hydrocarbon Contamination 6 2.7.6 Groundwater Level Monitoring Visits 6 2.7.7 Laboratory Chemical Testing 6 2.7.8 Soil Test Results 7 2.7.9 Groundwater Test Results 8 2.7.10 Summary Of Ground Conditions At Application Stage 9 3.0 PERMITTED ACTIVITIES 10 DRAWINGS Site Location Plan 588/002 Borehole Location Plan APPENDICES Appendix 1: Photographs Appendix 2: Local Authority Environmental Search Report Appendix 3: Borehole Logs Appendix 4: Chemical Laboratory Test Certificates Appendix 5: Tier 1 Contamination Assessment Screening Values Peak Associates Environmental Consultants Ltd Site Condition Report 38 Padgate Lane, Warrington QA No. 13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent
1.0 SITE DETAILS
Name of the applicant Willshee’s Skip Hire
Activity address Glensyl Way
Burton upon Trent.
DE14 1LX
National Grid Reference 425143, 323868
Site Condition Report:
Doc. Ref/Date at permit application 13xxx , October 2013.
stage:
Doc. References for site plans: 13485/10 Site Location Plan
588/002 Borehole Location Plan
2.0 CONDITION OF THE LAND AT PERMIT ISSUE
2.1 Introduction
A Site Condition Report (SCR) is required for any facility regulated under the
Environmental Permitting Regulations where there may be a significant risk to land or
groundwater.
This document describes and records the condition of the soil and groundwater
beneath the site prior to commencement of the permitted activity, and is intended to
satisfy the requirement of the application part of the SCR to accompany the
environmental permit application.
This SCR will require updating during the lifetime of the permit and further details
will need to be added to enable permit surrender at a later date, including the
condition of the land and groundwater at the time of permit surrender. If the soil and
groundwater are not in a satisfactory state, the application to surrender the
environmental permit may not be accepted without remedial works.
This part of the Site Condition Report provides a point of reference (or ‘baseline’) at
the start of the permitted operations, so that when surrender of the permit is to be
undertaken a decision regarding whether any additional contamination of the site
during the operation of the permit has occurred, and to ensure that the condition of the
land and groundwater are in a “satisfactory state” when an application to surrender the
permit has been made.
The site has an existing permit for part of the site, and this report is intended to
support the application for a permit to cover the entire site area.
Peak Associates Environmental Consultants Ltd 1 Site Condition Report.
38 Padgate Lane, Warrington QA No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent 2.2 Site Description Prior To Commencement Of Permitted Activity The site comprises an irregular shaped area of land, of approximately 0.6 hectares. It is situated within an industrial area of Burton-on-Trent (see Site Location Plan 1). The site is located at the end of Glensyl Way and is accessed via Wharf Road and The Maltings. The rear of the site backs onto Coor’s brewery and other adjacent/local businesses include car repairs, an auto shop, engineering and casting repairs. An Arriva depot/bus wash and a coffee shop plus a granite workshop are located at the junction of Wharf Road and The Maltings. Photographs of the site are presented in Appendix 1. The site currently operates as a waste sorting and recycling facility. The site layout is shown on the Exploratory Hole Location drawing (588/001) and identifies a number of structures along the south eastern boundary, used for sorting general waste, sorting plastics and sorting paper waste. Both construction and domestic waste are accepted at the site; however deliveries are checked on arrival and any hazardous waste is rejected and returned. Waste is initially sorted, then cardboard, paper and plastics are baled and despatched for recycling. Brick and rubble are re-used for road stone. The site has two office buildings; one is a two storey portacabin, which is located alongside the site weighbridge (photos 7-11). The second is a brick building located immediately to the left of the site entrance (photos 14 and 15). A sub-station is located within the east of the site and an above ground bunded diesel fuel tank to the rear of the site office, as identified on Drawing 588/001. The site surface is covered with concrete and is relatively level, with the entrance area being around 44.7m AOD, rising to 44.9m AOD towards the rear (west) of the site (adjacent to Coor’s) and around the area proposed for the new building. The site is approximately 350 metres west from the River Trent, which flows from the south towards the north past the site. The site owners intend to erect a new building at the western end of the site that backs onto the brewery. The building is intended for use for shredding of currently non- recyclable waste and will be constructed adjacent to the existing concrete boundary wall (photos 4 and 6) 2.3 Site Drainage As shown on Drawing 588/001 the storm water is collected in two gullies and directed towards a sealed interceptor in the west of the site. The site surface water drainage is self contained and the interceptor emptied periodically by tanker. There is another gully in the west of the site, and an ACO drain present in the east in front of the general waste sorting building, but drainage connections to these features have not been proven as part of this exercise. Peak Associates Environmental Consultants Ltd 2 Site Condition Report. 38 Padgate Lane, Warrington QA No.13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent 2.4 Site Environmental Setting East Staffordshire Borough Council was commissioned to prepare an Environmental Information Report on the site, based on the records they hold for the area. A copy of the report is presented in Appendix 2. The Local Authority report forms the basis for the consideration of the environmental setting and sensitivity, and in relation to the potential for contamination from current and historical activity on and surrounding the site to have impacted beneath the site. 2.4.1 Geology The published geological information shows the site to be underlain by sand and gravel deposits (Holme Pierrepont Sand and Gravel Member), overlying mudstone belonging to the Mercia Mudstone Group. Alluvium associated with the River Trent is shown to the east of the site. Made Ground is also shown to be present on the site and surrounding area. 2.4.2 Hydrogeology The superficial deposits and bedrock beneath the site are classified as a Secondary ‘A’ aquifer comprising permeable layers capable of supporting water supplies at a local rather than strategic scale, and in some cases forming an important source of base flow to rivers. These are generally aquifers formerly classified as minor aquifers. The site is located within a groundwater abstraction source protection zone ‘SPZ’ 2, defined by a 400 day travel time from a point below the water table. This zone now has a minimum radius of 250 or 500 metres around the source, depending on the size of the abstraction. Bass Brewers Limited has three recorded licensed abstractions to the east of the site for process water, evaporative cooling and spray irrigation. It is anticipated that these would be taken from depth below the Mercia Mudstone from the Permian Sandstone aquifer. 2.4.3 Surface Water The River Trent is located approximately 350m to the east of the site, flowing from the south to north. There are no known surface water courses adjacent to the site or beneath the site. 2.4.4 Landfills and Other Waste Sites The Local Authority has no record of landfills within 250m of the site. 2.5 Pollution Incidents The Environment Agency records show no pollution incidents associated with the site or adjacent to the site. The nearest recorded incident is shown 750m south west of the site, and was a major incident on the railway resulting in loss of oil and fuel in May 2005. Peak Associates Environmental Consultants Ltd 3 Site Condition Report. 38 Padgate Lane, Warrington QA No.13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent 2.6 Historical Land Uses & Associated Sources of Potential Contamination The Local Authority report includes a search of the historical maps for potentially contaminated sites, on and within 250m of the site. The results are presented in the report with Appendix 2. In summary, the site previous and current use place it within a ‘medium risk’ area usage, bordered by medium and very low risk areas. The earliest historical OS plans from the late 19th Century show that the site was occupied by a railway junction, with Malt Houses shown to the north east. Little change occurred until the railway junction was abandoned, leaving the site as undeveloped for many decades until sometime between the late 1970’s and late 1980’s when the industrial estate was constructed and the site forms part of the industrial estate. Railway engineering works and engine sheds are recorded to the south and south west of the site, but not on site. The site was the location of a railway junction historically and it would be envisaged that such use would result in the presence of boiler ashes often used beneath the rail ballast, which tends to become oily and greasy over time due to the rolling stock and maintenance of the points. Such contamination would tend to include predominantly toxic and phytotoxic heavy metals, mineral oil, and polycyclic aromatic hydrocarbons. Post redevelopment as an industrial estate with corresponding hard cover by floor slabs and pavement would be expected to have protected the ground from surface contamination to some degree. The on-site fuel tank is also a potential source of diesel contamination. The non-hazardous nature of the materials brought onto site, combined with the drained hardcover suggests that contamination of the ground associated with the current use will be unlikely. 2.7 Intrusive Ground Investigation Works 2.7.1 Introduction Peak Associates have undertaken an intrusive ground investigation to satisfy the requirement for the Site Condition Report to provide a baseline for the ground conditions beneath the site prior to commencement of the permitted activity. 2.7.2 Scope Of Investigation The investigation comprised essentially the drilling of 6 No. windowless sample boreholes using a small tracked percussive rig on the 18th July 2013. The works were supervised by staff from Peak Associates Environmental Consultants Limited. Peak Associates Environmental Consultants Ltd 4 Site Condition Report. 38 Padgate Lane, Warrington QA No.13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent
The following schedule of exploratory holes explains the purpose of each exploratory
borehole:
Table 2.7.1: Schedule of Exploratory Holes
Exploratory Hole
Purpose of Exploratory Hole
References
WS1 (S/P) Target potential contamination associated with former diesel tank. Install standpipe at
down gradient end of site, assuming groundwater flow is generally south to north, or south
west to north east towards the river Trent.
WS2 (S/P) General site coverage and to install standpipe at down gradient end of site.
WS3 (S/P) General site coverage and standpipe installation.
WS4 (S/P) General site coverage and to install standpipe at down gradient end of site.
WS5 (S/P) Install standpipe at up gradient end of site.
WS6 (S/P) General site coverage and standpipe installation down gradient of interceptors.
S/P = Standpipe Installation for groundwater sampling.
Drawing 588/002 shows the locations of the exploratory holes. The borehole logs are
presented in Appendix 3.
The concrete surfacing was cored through at the locations of all boreholes.
Soil samples were stored in amber glass jars and plastic tubs supplied by the
laboratory, and placed in cooler boxes with ice packs. All samples were collected by
courier at the end of the day and delivered to the laboratory of QTS Environmental
Limited in Kent the following morning.
Particular care was taken to ensure sampling tools were cleaned between sampling
positions to minimise the potential for cross contamination.
On completion of the boreholes a 50mm diameter slotted standpipe was inserted to
the base with pea gravel surround to within 1.0m of the underside of the surfacing. A
bentonite plug was used to prevent surface water ingress into the standpipe. A rubber
bung was inserted into the standpipe and a flush fitting steel cover used to protect the
installation.
A return visit to site was undertaken on 25th July 2013, to take groundwater samples
after purging the standpipes to remove three times the volume of water stored within
the standpipe (with the exception of WS2). The samples were stored in amber glass
jars and vials and placed in cooler boxes with ice packs to await collection at the end
of the day by courier for delivery to the laboratory of QTS, Kent.
2.7.3 Strata Encountered
Made Ground
The concrete is 210mm to 280mm thick above granular made ground extending to
depths of between 0.6m and 2.30m below ground level.
The made ground comprises predominantly black gravel sized material including
brick, concrete and clinker/ash, and locally including whole bricks.
Peak Associates Environmental Consultants Ltd 5 Site Condition Report.
38 Padgate Lane, Warrington QA No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent Natural Soils The natural deposits encountered beneath the made ground include locally beds of clay, varying in thickness, where proven from 100mm to 500mm including very soft gravely clay, soft clay/silt, soft to firm gravely clay, and soft to firm sandy clay. The clay was not encountered in boreholes WS3 or WS5. All borehole encountered red coarse sand and gravel of quartzite, with occasional cobbles, below the made ground and/or clay beds, at depths of between 1.20m to 2.40m bgl, proven to the base of the investigation at depths of between 3.0m and 4.0m below ground level. 2.7.4 Groundwater Observations Groundwater was observed whilst drilling in all 6 exploratory holes from depths of between 1.7m and 2.0m bgl in the granular fill or the sand and gravel deposits. 2.7.5 Visual and Olfactory Evidence Of Hydrocarbon Contamination There was an odour of diesel in the soils recovered from WS1 from 0.41m to 2.30m bgl through the made ground, the thin clay layer and impacting the upper part of the sand and gravel deposits. In WS2, at a depth of 0.25m, the gravel appeared to be coated in green paint having a hydrocarbon odour (i.e. an ‘oil’ based paint). Samples of the impacted soils from both boreholes were subject to analysis for hydrocarbons. 2.7.6 Groundwater Level Monitoring Visits A return visit was made on 25th July to take groundwater samples from the standpipes using low flow techniques (peristaltic pumping). The groundwater levels were measured as follows: WS1: 1.71m bgl WS2: 2.00m blg WS3: 1.88m bgl WS4: 1.58m bgl WS5: 1.77m bgl WS6: 1.62m bgl 2.7.7 Laboratory Chemical Testing The chemical testing suite adopted was based on the known use of the site as railway land with engineering works to the south and south west, and the presence of hydrocarbon odours in the soils locally associated with the diesel fuel storage tank near to borehole WS1 and the ‘green paint’ occurrence in WS2. On this basis, the following suite of tests was adopted: Peak Associates Environmental Consultants Ltd 6 Site Condition Report. 38 Padgate Lane, Warrington QA No.13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent
Soils: pH, toxic heavy metals, polycylic aromatic hydrocarbons (contained within
fuels), petroleum hydrocarbons (banded and speciated).
Groundwaters: pH, petroleum hydrocarbons (speciated) including ‘BTEX’ (benzene,
toluene, ethyl benzene and xylenes), glycols and volatile organic compounds (VOC’s,
in case solvents are used to remove oil and grease).
The laboratory chemical test result certificates are presented in Appendix 4.
2.7.8 Soil Test Results
In order to provide an indication of the current degree of contamination present
beneath the site at present, prior to commencement of the permitted operation, the test
results have been compared against the typical available Tier 1 Generic Assessment
Criteria or ‘screening values’ (refer to Appendix 5) typically used to identify
contaminants that may potentially present a risk to the current users of the site, or
controlled waters. The Tier 1 Generic Assessment Criteria (GAC) for an industrial or
commercial use is considered appropriate for the purposes of the assessment: -
The soil test results are summarised below: -
Table 2.7.2: Summary of Soil Test Results
Determinant Range Tier 1 Samples Comments
mg/kg Screening exceeding Tier
Value 1 screening
mg/kg value
Arsenic 26-126 640 0
Water Soluble 0.6-5.4 192000 (3)(i) 0 Potentially phytotoxic
Boron in 3 samples.
Barium 313-527 - -
Beryllium 2.6-14.6 420 0
Cadmium 0.6-2.5 230 0
Chromium 13-18 30400 0 Screening value is for
Cr (III).
Copper 159-364 71,700 (130)(i) 0 All 4 samples slightly
exceed recommended
maximum concentration
for new planting.
Lead 137-364 750 0
MercuryWillshee’s Glensyl Way. Burton upon Trent The individual Polycyclic Aromatic Hydrocarbon (PAH) compounds are all below the GAC for industrial/commercial use, and are also below the residential use Two samples from borehole WS1, located adjacent to the fuel tank, were subject to banded petroleum hydrocarbon analysis. The sample from a depth of 1.70m to 2.00m returned a total concentration of 299 mg/kg with the majority of the results within the (DRO) diesel range organic hydrocarbon range. The sample below in WS1 taken from a depth of 2.00m to 2.20m contained
Willshee’s Glensyl Way. Burton upon Trent
Source of
Quality Range Detected Screening
Determinant Standard (µg/l) µg/l Concentration
PAH's
Napthalene 10Willshee’s Glensyl Way. Burton upon Trent down the river valley of the River Trent which is over 350m to the east at its closest with more industrial land between the site and the river which presents a higher risk to groundwater quality due to past uses including a gas works. However, in order to protect the ground beneath the site from impact associated with the permitted activity, it is recommended that the quality of the site surface is maintained to provide a continuous, drained hard surfaced working area and any spillages are drained to the interceptor and prevented from seeping into the ground. The re-fuelling activities associated with the diesel fuel bund appear to have caused localised impact to the ground, and it is recommended that the concrete is inspected to ensure that leaks and spills are not able to enter the ground through cracks or at the edge of the slab, and consideration be given to constructing a perimeter drain around an area of improved surfacing to catch spills and direct them to the interceptor. 3.0 PERMITTED ACTIVITIES Permitted Activities Waste Transfer on part of site. Non-Permitted Activities N/A Document References Licence Reference No. 5C930550. 9/8/2005 Peak Associates Environmental Consultants Ltd 10 Site Condition Report. 38 Padgate Lane, Warrington QA No.13079 WA1 3RU
Willshee’s Glensyl Way. Burton upon Trent
DRAWINGS
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent
APPENDIX 1
Photographs
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent
APPENDIX 2
Local Authority
Environmental Search Report
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent
APPENDIX 3
Borehole Logs
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent
APPENDIX 4
Chemical Laboratory Test Certificates
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
WA1 3RUWillshee’s Glensyl Way. Burton upon Trent
APPENDIX 5
Tier 1
Contamination Assessment
Screening Values
Peak Associates Environmental Consultants Ltd Site Condition Report
38 Padgate Lane, Warrington Report No.13079
