British Columbia Water and Waste Association 2018 Student Design Competition Problem Statement ELLIS CREEK INTEGRATED WATER MANAGEMENT PLAN FINAL V1 – DECEMBER 14, 2017
Contents
1. Problem Statement ............................................................................................................................... 3
2. Background ........................................................................................................................................... 3
2.1. Overview ............................................................................................................................................ 3
2.2. Reservoirs........................................................................................................................................... 4
2.3. Water Demand ................................................................................................................................... 4
2.4. Flow Records ...................................................................................................................................... 5
2.5. Flood and Erosion History .................................................................................................................. 6
2.6. Habitat................................................................................................................................................ 6
2.7. Additional Resources ......................................................................................................................... 6
3. Objectives.............................................................................................................................................. 8
3.1. Scope of Work .................................................................................................................................... 8
3.2. Design Considerations and Constraints ............................................................................................. 9
3.3. Deliverables...................................................................................................................................... 10
Figures
Figure 1: Ellis Creek Neighboring Lots
Figure 2: Ellis Creek Watershed
Attachments – Provided Separately Upon Registration
1. Creek and Irrigation Flow Data (2009-2017)
2. Ellis Creek Reservoir Information
a. Dam Safety Reviews
b. Annual Management Data
c. Assessment Reports
3. Ellis Creek Cross Sections
a. Shape files, AutoCAD drawing files, and excel point data of regular creek cross sections
b. PDF, AutoCAD drawing files, and excel point data for sediment basin
4. Spatial Data
a. City of Penticton parcels and utilities
b. Data BC (road atlas, parcels, and municipal boundaries)
5. 2008 Preliminary Water Management Plan for Ellis Creek
6. Ellis and Penticton Watershed Overview Map
7. Background and History of Water Management of Okanagan Lake and River
8. Design Brief on the Floodplain Mapping Study Okanagan River
9. Ellis Creek Inundation Study (2006)
10. City of Penticton Bridge Inspection Report (2016)
11. Fish Passage Requirements
12. Penticton Creek Draft Master Plan
1
Questions
For information or questions related to the Student Design Competition or the Problem Statement,
please contact:
Email: SDC@bcwwa.org
Student Design Competition Chairs:
• Chair - Michael Thiessen, EIT
• Vice Chair - Stephen Bertulli, EIT
• Municipal Sponsor Coordinator - Allison Matfin, EIT
Acknowledgements
This problem statement is the result of collaboration between the City of Penticton, Mould Engineering,
and the Ministry of Forests, Lands, Natural Resource Operations, and Rural Development (MFLNRORD),
with assistance from the BCWWA Student Design Competition Committee. Sincere thanks to all who
put time and effort into creating this document for the benefit of future leaders in engineering.
Specific Thanks to:
• Len Robson (City of Penticton)
• Ian Chapman (City of Penticton)
• Brent Edge (City of Penticton)
• Mitch Moroziuk (City of Penticton)
• Stu Mould (Mould Engineering)
• Tara White (Ministry of Forests, Lands, Natural Resource Operations, and Rural Development)
• Camille Rivard-Sirois (Okanagan Nation Alliance)
Disclaimer
The project statement is intended only for use during the 2018 BCWWA Student Design Competition.
Information provided in this document may not reflect actual conditions or requirements, and is
provided for the sole purpose of providing context for the design competition. Supporting information
remains the property of the City of Penticton and MFLNRORD.
2
1. Problem Statement
Students interested in entering the 2018 BC Water & Waste Association (BCWWA) Student Design
Competition (SDC) are encouraged to form teams to:
Complete analysis and design for upgrades to Ellis Creek in the City of Penticton to, in the context of
climate change, improve:
• hydraulic capacity,
• flood and erosion protection,
• irrigation water security, and
• fish passage and aquatic habitat.
Students are to provide real-world solutions that are practical and creative while thinking critically about
the constraints and design goals.
2. Background
Communities around British Columbia are looking to the future and planning for climate change impacts
to their water resource infrastructure including increased flood frequencies and lower summer flows.
The goal is to achieve a balance between the often-competing objectives of development, flood
protection, environmental flows, and agriculture. The Ellis Creek project will include assessment and
design to balance these objectives for a changing climate. The City of Penticton is currently in the
process of implementing a similar project for Penticton Creek focusing on flood protection, fish habitat,
and repair of failing infrastructure, and the draft Master Plan for Penticton Creek has been included as
reference in Attachment 12.
It is each team’s responsibility to review the information and data provided. It is not mandatory to use
all of the data provided in analysis, and as much data as possible was provided to allow for teams to
decide the level of detail required for the project. It is highly recommended that teams review all of
the information provided in the attachments, as some key design data and information is provided
only in the attachments. Refer to the competition guidelines for policies regarding questions on project
scope, objectives, and information.
2.1. Overview
Ellis Creek drains an area of land east of the City of Penticton that includes urban and natural
sub-catchments. Above the City of Penticton, Ellis Creek has a relatively steep natural channel. Two
reservoirs are located in the upper watershed of Ellis Creek, which are used to store water for irrigation,
and a diversion dam is located above the City of Penticton that diverts water to an irrigation system.
Within the City of Penticton, Ellis Creek is generally channelized with a shallower slope. There are
several crossings of Ellis Creek within the City, which include both bridges and culverts. The creek
discharges into the Okanagan River Channel just south of Fairview Road, and a sediment basin for debris
removal is located 90 m upstream of the confluence.
Residential and commercial developments abut the creek bank in many locations, which makes it critical
for the creek to have hydraulic capacity for the design flood event. As a result of the close development,
3
the creek is generally channelized with minimal riparian area setback. Figure 1 shows the creek reach
through the City of Penticton, and Figure 2 shows an overview of the watershed.
2.2. Reservoirs
The Ellis System contains two reservoirs (Ellis 2 and Ellis 4) and the Ellis Intake/Diversion. Locations are
shown on the enclosed Figure 2: Ellis Creek Watershed. The following are some of the key features of
the reservoir system.
• Ellis 2 Reservoir: Located on the South fork of Ellis Creek with a capacity of 333 ML. Stored water
from Ellis 2 is released for use from mid-July to mid-August on average. Water discharges from
Ellis 2 via a low-level outlet with a slide-gate or via an unlined spillway. The gate is normally closed
in the Spring to collect runoff and opened late July or August to provide irrigation water and base
flows.
• Ellis 4 Reservoir: Located on the North fork of Ellis Creek with a capacity of 918 ML. Stored water
from Ellis 4 is released for use mid-August to the end of October when the irrigation system is shut
down. Typically, 310 ML remains in the reservoir at the end of the season. Water discharges from
Ellis 4 via a low-level outlet with a screw-gate or via a concrete and riprap lined spillway.
• Ellis Intake/Diversion: Located above the City of Penticton on Ellis Creek with a capacity of 6 ML.
The North and South forks of Ellis Creek join upstream of the intake/diversion dam. Water
discharges from the diversion dam via a low-level sluiceway with a control slide-gate, irrigation
intake, or concrete spillway. At the intake, the water is diverted for irrigation to service the
Valleyview area. The remainder continues down the creek through Penticton. Each year
approximately 300-750 ML is drawn from Ellis Creek for irrigation.
The enclosed documents include background reports and documents concerning the Ellis Creek
reservoir system (Attachment 2).
2.3. Water Demand
Irrigation water is stored in the two reservoirs and released downstream to be extracted from the creek
at the diversion dam located at the east end of the City of Penticton. Water for irrigation from Ellis
Creek is supplied from April to October each year, with irrigation use ranging from 300-750 ML per year.
Information on current and expected irrigation demands can be found in the following table, based on a
previous Irrigation Master Study completed for the city using climate change models CGCM2.A2 and
CGCM2.B2 (Urban Systems, 2009).
4Table 1: Ellis Creek Irrigation Demand
Current Climate Climate Change b
Irrigation
Existing Higher Water Existing Crops Higher Water Full System
Demand
Crops Demand Crops Demand Crops Buildout
Annual 400 503 503– 587 639 – 761 1,417 – 1,159
(ML/year)
Peak Monthly 113 151 134 – 144 175 – 191 327 – 360
(ML/month) a
a) Peak flows occur in July-August.
b) Crop change and climate change result in nearly 100% increase in water demand in June, July, and
September and increases of 300-500% for the shoulder months of May and October.
The City of Penticton holds most of the water licenses on Ellis Creek for the purposes of storage (in the
reservoirs), irrigation, and waterworks supply (domestic use). The City does not currently use any water
for domestic use. Teams are to assume that the water will only be withdrawn from Ellis Creek by the
City of Penticton for irrigation. The total licensed irrigation volume per year is 2,559.4896 ML, well
above historical irrigation withdrawals.
Two water licenses are held by local residents for domestic use totaling 4.274 m3/day. These licenses,
combined, represent a small portion of the overall demand. Information on those licenses can be found
online from the Government of BC (see additional resources). Teams are to assume that these demands
are extracted at the same location as the irrigation demand and will continue, unchanging, in perpetuity.
2.4. Flow Records
The City of Penticton has provided flow data (2007-2017) to support analysis (Attachment 1). The flow
data was collected approximately 90 m downstream of the Industrial Avenue crossing of Ellis Creek. It is
important to note that this gauge was installed and has been calibrated for relatively low-flows in the
creek, and no flow measurements and calibration have been completed for high flows. As a result, this
flow record is expected to be accurate for low to moderate flows only. In addition, Environment Canada
has had gauges on Ellis Creek in the past, with several years of historic data available through their
online historic hydrometric system. Regional creeks in the area have longer and more consistent
periods of record for regional analysis through the Water Survey of Canada (including Penticton Creek,
see Attachment 12).
The minimum environmental flows at the current gauge location are as follows (minimum flows are not
regulated outside of the months below):
• July – August 31: 84 L/s
• September – December 31: 126 L/s
In the Winter, the reservoirs gates are static and water is not stored, and as a result the City has no
ability to control the flow, while in the Spring creek flows are typically well above minimum flows due to
snowmelt.
52.5. Flood and Erosion History
The 2017 freshet in the southern interior of British Columbia was an above-average event, which
resulted in flooding and damage to infrastructure across the province. While Ellis Creek did not
experience flooding in 2017, high creek flows resulted in scour that damaged two utility crossings of the
creek (at Dartmouth Road and near the upstream end of Okanagan Avenue), which are being repaired.
Due to the limited reservoir capacity, storage and reservoir operation cannot eliminate flood risk.
Historically, flooding has been a concern near the upper reaches of the creek below the reservoirs and
between Dartmouth Road and Main Street.
Existing bank erosion protection consists of riprap in isolated locations downstream of Dartmouth Road.
There is an existing steep and eroding bank of fine material between the reservoirs and the City that is a
known contributor of substantial volumes of sediment. Erosion is also a noted concern from the upper
(east) end of Okanagan Avenue to Dartmouth Road (see Figure 1).
Erosion in Ellis Creek has resulted in reduced capacity in the downstream reaches of the channel, due to
sediment, gravel and cobble deposition in the channel and culverts. Sediment is periodically removed
from culverts to ensure adequate capacity is maintained. Large woody debris is periodically removed
from the creek when it obstructs culverts; however, large amounts of woody debris are not produced by
the watershed and are generally not a hydraulic concern. There is an existing sediment basin 90 m
upstream of the creek mouth that is operated and maintained by the provincial government (see
Attachment 3 for 2017 survey).
2.6. Habitat
Ellis Creek is a fourth-order stream that has records of resident populations of longnose dace and
resident and adfluvial populations of rainbow trout, and the lower reaches of Ellis Creek support
kokanee spawning habitat. Through the City, Ellis Creek has large cobble and boulder substrate that
provides minimal habitat for fish. The lower reaches of Ellis Creek have been restricted due to
development and road crossings resulting in a limited potential for aquatic and riparian habitat.
Fisheries management objectives for Ellis Creek are to provide permanent fish passage for kokanee,
rainbow trout, steelhead, and salmon stocks. A four-foot high concrete structure which houses the City
of Penticton’s sewer pipeline (located 300 m upstream of the mouth) was a permanent barrier until
2015, when funding was secured to construct a fish bypass around the concrete sewer pipe structure.
This bypass provided access to 28 km of quality habitat for kokanee & sockeye spawning, as well as
rainbow trout rearing & spawning. Within 2 hours of opening up the by-pass, kokanee spawners had
migrated upstream (Oct. 2015).
The rock weir at the outlet of the Ellis Creek sediment basin (80 m upstream of the mouth) is a seasonal
barrier to fish passage (low flow and drought years), and the diversion dam is a year-round fish barrier.
Moving forwards, improvements are planned in the near future by the Okanagan Nation Alliance to
ensure passage at the rock weir to allow for fish passage year-round.
2.7. Additional Resources
Below is a list of additional references with further background on Ellis Creek and guidelines which
students may consider for the project.
6Background Resources
Students are encouraged to conduct background research to understand previous reports, studies, and
analysis done for Ellis Creek and the Okanagan region. Below is a list of useful resources to start this
process. This list is not intended to be comprehensive; student teams are encouraged to complete their
own literature review.
• Pacific Climate Impact Consortium:
o https://www.pacificclimate.org/
• Online GIS database for BC
o https://www2.gov.bc.ca/gov/content/data/geographic-data-services/web-based-
mapping/imapbc
o https://data.gov.bc.ca/
• Existing Water License Database:
o https://www2.gov.bc.ca/gov/content/environment/air-land-water/water/water-
licensing-rights/water-licences-approvals/water-rights-databases
• Watershed Risk Assessment for Ellis Creek:
o http://a100.gov.bc.ca/appsdata/acat/documents/r18497/Hydrology_Ellis_Final_127671
1606210_c82c0be0fbeb44c65b1501f25d6a9c4eb0636d717ca7017d2e3038ef76833871.
pdf
• Climate Summary for the Thompson Okanagan Region:
o https://www.pacificclimate.org/sites/default/files/publications/Climate_Summary-
Thompson-Okanagan_0.pdf
• Agricultural Water Demand Model – Report for the Okanagan Basin:
o https://www2.gov.bc.ca/gov/content/industry/agriculture-seafood/agricultural-land-
and-environment/water/water-management/agriculture-water-demand-model
Guidelines & Regulations
The below guidelines represent a small sample that may be beneficial for consideration during design
and analysis. Students are encouraged to research other relevant guidelines to inform design and
analysis.
• Floodplain Mapping Guidelines:
o https://www.egbc.ca/getmedia/8748e1cf-3a80-458d-8f73-94d6460f310f/APEGBC-
Guidelines-for-Flood-Mapping-in-BC.pdf.aspx
• World Meteorological Association Manual on Low Flow Estimation and Prediction:
o http://www.wmo.int/pages/prog/hwrp/publications/low-
flow_estimation_prediction/WMO%201029%20en.pdf
• Riprap Design and Construction Guide:
o http://www.env.gov.bc.ca/wsd/public_safety/flood/pdfs_word/riprap_guide.pdf
• Fish Passage Guidelines:
o https://www.for.gov.bc.ca/hfp/fish/fishpassage.html
• Riparian Area Regulations:
o https://www2.gov.bc.ca/gov/content/environment/plants-animals-
ecosystems/fish/riparian-areas-regulation
73. Objectives
The objectives of the project are to complete analysis and design for Ellis Creek to improve hydraulic
conveyance, flood protection, irrigation water security, and aquatic habitat, considering an integrated
approach and balance between different objectives.
Student teams are required to complete and prepare two conceptual design options as described below;
however, student teams may consider innovative or alternative approaches to those outlined:
1. Option 1 - Naturalize
a. Bioengineering erosion protection
b. Hydraulic capacity improvements to convey the design flood by providing greater capacity
and attenuation in the creek (channel improvements, dedicated floodways, floodplain
benches, ponds for attenuation in or off line of the creek)
c. Maximize environmental improvements (include fish passage and consider large woody
debris structures, riffles and pools, wetlands, and other improvements)
2. Option 2 - Structurally Protect
a. Riprap erosion protection
b. Hydraulic capacity improvements by structural measures (dikes or floodwalls)
c. Minimal environmental improvements (include fish passage and minor improvements only)
Consider and evaluate the options using quantitative and qualitative criteria, sensitivity analyses, and a
triple bottom line analysis, and present the recommended approach and design with justification. The
deliverables will be judged considering: depth and robustness of analysis, selection of integrated and
creative designs, practicality of implementation, operation and maintenance needs, and use of natural
systems.
3.1. Scope of Work
The required scope of work for the above objectives is described below.
• Climate Change Analysis:
o Conduct sufficient research, analysis, and calculations to estimate flows in Ellis Creek in
2100 to support further analysis (low-flow and flood frequency).
• Flood Protection and Hydraulic Conveyance:
o Complete a frequency analysis for extreme flood events considering climate change to
determine the design flood discharge;
o Complete a hydraulic assessment of the existing creek’s ability to convey the design flood
and erosion risk;
o Develop design improvements for the two options outlined above to provide sufficient
hydraulic capacity and erosion protection, considering risk transfer implications to
neighboring properties.
• Irrigation Water Security:
o Complete a frequency analysis for low-flow events considering climate change;
o Based on the 10-year and 50-year return frequency monthly low flows, complete an annual
water balance to determine if the existing reservoirs have sufficient storage volume for
8irrigation under climate change conditions, considering minimum environmental flows for
Ellis Creek;
o Comment if there will be sufficient water during low-flow years to meet the irrigation
demand and minimum environmental flows and potential options that could be considered
to mitigate shortfalls (no design).
• Aquatic Habitat
o Complete a hydraulic assessment of the existing creek’s ability to allow fish passage;
o Design improvements to allow for fish passage at the rock weir at the sediment pond outlet
and improve fish passage in other locations if deemed pertinent;
o Design improvements for enhanced and/or increased aquatic and riparian habitat area and
quality in accordance with the two options outlined above, balancing cost with
environmental improvements.
• Class D Cost Estimate
o For the proposed upgrades, develop Class D capital and operation and maintenance costs
for the project lifespan (2018-2068) to determine the present value of the project.
• Comparative Analysis
o Discuss alternatives considered for analysis methodology, design strategy, and selection
methodology.
o Complete a triple bottom line (environmental, social, financial) analysis of Options 1 and 2
and recommend one design option.
3.2. Design Considerations and Constraints
• The design flood event is defined as the 200-year return period peak flow event for the year
2100 climate change scenario, to be determined and justified by student teams.
• Reservoir operations on Ellis Creek will not change over the project’s lifetime. Gates will
continue to be opened and allowed to flow naturally in the Winter and regulated manually to
provide irrigation and creek base flows in the Spring, Summer, and Fall.
• Sufficient hydraulic capacity is defined as 0.3 m of vertical freeboard above the HGL resulting
from the design flood event 200-year peak instantaneous flow, or 0.6 m of vertical freeboard
above the 200-year peak daily flow, to the nearest property line, top of berm, or top of bank,
whichever is closest.
• Sufficient erosion protection is defined as no erosion occurring during the design flood.
• Climate change analysis is to estimate conditions for the year 2100.
• For the low flow analysis, a frequency analysis shall be completed to determine the monthly
low flows for 10-year and 50-year recurrence intervals as the basis for the irrigation supply
assessment.
• Minimum environmental flow in Ellis Creek is that which is required for fish passage, which
must be maintained at the levels described previously.
• Irrigation water demand is assumed to follow the existing and predicted flow rates provided.
9• Fish passage is defined as only during the period of fish migration for the species described.
• Project extent for design shall include Ellis Creek within the City of Penticton municipal
boundaries, the dam locations, and works at the sediment basin at the creek mouth (limited to
work on the rock weir at the outlet only).
• Project footprint for design solutions must consider the available land along the creek without
infringement on private property (use of existing municipal land). Design solutions may consider
land acquisition or development of rights-of-way for works if required, though limited land
impacts are preferable in design solutions.
• Project lifespan for analysis shall be 2018-2068 (50 years) with consideration for climate change
impacts to 2100 and a discount rate of 5%.
3.3. Deliverables
1) Progress Report (1-2 pages);
2) Design Notebook (Formatted according to the Competition Guidelines). Containing the
following:
a) Summary of Ellis Creek current condition, challenges faced, and project approach;
b) Basis for design:
i) Review data used for assessment and design, include assumptions and adjustments to
provided information;
ii) Requirements of design, including relevant guidelines and regulations;
c) Hydrologic and hydraulic analysis
i) Describe hydrologic and climate change analysis and results, include assumptions, data
sources, sensitivity analysis, and justification of methodology;
ii) Describe hydraulic analysis and design methodology, include assumptions, data sources,
sensitivity analysis, and justification of methodology;
iii) Describe the methodology and results of the irrigation demand assessment and discuss
alternatives for future consideration;
iv) Provide figures illustrating the key results of the hydrologic and hydraulic analyses.
d) Conceptual design of two options:
i) Design description;
ii) Hydraulic profile;
iii) Plan figures or drawings illustrating design concepts;
iv) Typical design cross sections.
e) Recommendation of preferred solution:
i) Options evaluation;
ii) Lifecycle cost estimate and NPV assessment;
iii) Triple bottom line assessment and option recommendation.
3) Oral Presentation.
10e E Gahan Ave Fores Sendero
±
t Av tb
Joy
r oo k P
Legend
On
Rd
Ma
rd l n Cres
k ha ticto
d
oa
tar
Ec Pen e
rtin
Bird
r
Latim
Jam t
kD
Vic
r
PE CR
i
r oo Av
Hull
oS
ss
St
Orillia
estb
St
Carmi Rd
S
Municipal Boundary
Pl
to
S
rail
ce
For
d
ve
St
es
M
NT EE
t
nA
nR
e
t
er S
ar
ria
n
ac
my Av
Win
tin
ail T
le
Jer n
G
lde
PMBC Parcels
y
Dr
St to
IC K
ilit
t
tic
nipe
Ho
Wood
yR
ut
n
TO
ruff Pe
King
Ave
alle
OWNER TYPE
gS
n Ave
N
n Av
e to
Pentic
d
eV
ont o
t
Ke
Kil
R
S
Edm ve
t
on A CROWN AGENCY
tl
ck Rd
win
Syer
ns i
Nels ve
Ket
Scott
Kil
s
Qu e e
Ave Cre eA ve
ng
nin
lar
all al eA CROWN PROVINCIAL
ed
ton
nd c
ne
D ebe
gS
Ke g en
Lyon
ve Rid
n St
Wind
St
on A wr
yS
St
s or Nels
St
nt o
r
La
t
Ave
dD
Toro FEDERAL
King
Argyle
Ave Preston Ave Edna
t
Ave
w oo
Ave
Regina E D unc an
Pine
St
MIXED OWNERSHIP
Man
ve
St
e
C onk Ave pal A
Allison St
Edg
lin Av ici
Mun
Columbia St
e e
ito
tt Av
C hur
Woodlands Pl MUNICIPAL
r
e Naish Dr
Benn
nds D
ba S
St
D oug Ave
las Av ttle Calgary
ch
NONE
e Ke lley ail or
Cleland Dr
Man e Hatfield Ave
t
dl a
D ew d
Bracewell Dr
Va l Tr ve
Pine St
Av oss A
Dart t
Hastin e
i Park R ave Av PRIVATE
Balfo
gs Av
Woo
Cres
e Ra MacCle
Leir
m ou
Main
ney
Dunant Cre
S
Wi
Halif
s
w Rd
u
lt UNKNOWN
Cre on
r St
St
ve
th
nc an A par
d
S
W Du s
ax S
acc king
nR
t
Fairvie
Clark Ca
e rm
roa ss
lde
Ave i
n Dr
t
Wate d Ave
Ho
rlo o Ave Granby Ave Granby
Comm
Dartmouth Rd
Carm
e
Ave ercial
Commercial Way
Salik
Phoenix Ave Pl
Governm
i Ave
Flow Gauge Huth Ave Industrial Ave Upper Limit of Erosion in City
E
Scot
Fairf
town
Amh
Rose e
e nt S t
St
Okanagan Ave E
Dr
ia
Av
or d
eW
e
Ch ky
al Av
rs t S
us t r i
an
Suma
Ind
P
Atkin Bruce
BC W at er and Wa ste A ss oc iat io n
ne
St
t
iew Dr
l C h a n Ok a n a g l
Westv
C am
e
Fairf
ry Av
c
agan
s on S
C her
ELL
STU D E NT D E S IG N COMPE TITIO N
Ok a n W
P
s
Rogers Cre IS C
Ok Ave
k
r os e
Ave
o
Crt
nel
y
R
rd Dr
Barn
an E
Wyle
EEK
t
Parkw
s Armstrong Dr
Qu e b
ag
ve E
Chan Trail
Cres
St
r en A
an
e
War
s St
r
tt D
ec S Troy
ay
Main
Ave
ne
R oy
an
rbi
al l
t
Co
oug Ave
S
R oy on lvd
t
D
Mc Ave ws
Pl
B
Ave W Da e
es
en Ave ilts res res
Cr
Warr W
OKANAGAN
C C
Wiltse Dr
ns
n ks cks
Dr
el y c
ve
Bra es o to
St S
e
r een
RIVER
Cr
St
tse
st P l
Secre
Rd
Wil
Pl
g
Ever
C han
ak e
Dartmouth Dr
ve e
ey A t Av
Pky
Kinn cr e s Corry
Dr
ha L
Ave
S Ma
Se
nel
Balsa
atrick
Taber
Ga r d n e
k p Pl m Ave
hor n
Rd
ir
Satikw
K
d Ska
Crt
C
in St
St
Ba
w Rd
H aw t
hanne
McG
ie
Pinev
d
nzie
s
Ave
r
a
rR
Galt
kin
eR
h
Dr
Ska
ra
da
e
Source: Esri, DigitalGlobe, GeoEye, Earthstar
St
Galt
lP
McK
Lak
w St
Ave
Ce
ky
Fig ur e 1: E lli s Cr e e k Ne i gh bo r ing L o ts
Author: AMatfin
200 0 200
(m) Note: Airphoto provided by City of Penticton
Upd a t ed: D ece mb er, 2 0 17EEK
±
R
LL C
TUR
NB U
Legend
K
EE
KE
CR Municipal Boundary
R
NG
CR
CA
RI
EE
SP
MP
K
N
Dams
BE
SO
HN
LL
JO
CR
E EK
TT CR
EE
STRU
RE
EK
Watershed
K
C
R RIS
HA
Ellis Creek
RANDOLPH CREEK
K
EE
CR
N
TO
IC
NT
PE
STE
WAR
EK
DC RE E
K
RE
SC
LLI
HE
RT
NO
CREEK Ellis4
Ellis_Diversion
LE
SHING
OKANA
G
AN RIV
ELLIS CREEK
ER
EK
RE
RC
BC W at er and Wa ste A ss oc iat io n
GAN
U NIE
RIVER
SA
OKANA
STU D E NT D E S IG N COMPE TITIO N
EK
E EK
SKAHA CR
CRE
RIS
EK
RE
MOR
SC
SO
LIE
GIL
U TH
K
EE
EL
CR
LIS
ON
CR
ES
EE
TH
K
Ellis2
MA
FELIS CREEK
K
EE K
EE
CR
CR
Y
NZ
S
RE
MA
D E
O
TH
CRE E R
ZO K
EK
MAURICE
TU EE
CREEK
KILM
Sourc e: Esri, DigitalGlobe, GeoEye, Earthstar Geographics, CNES/Airbus DS, USDA, USGS, AeroGRID, IGN, and the GIS User Community
CR
Fig ur e 2: E lli s Cr e e k W at e r sh e d
Author: AMatfin
1,000 0 1,000
(m) Note: Airphoto provided by City of Penticton
Upd a t ed: D ece mb er, 2 0 17You can also read
