Shower Spaces DEALER PRICE GUIDE
SMOTM COLOURS
Please note some of the colours shown many not be an exact reflection due to the printing process.
Every Ab retailer has samples of all material finishes available for perusal and approval. Only select your
colour from real colour swatch sets in the showroom.
200* - Gloss White 201 - Matt White Satin 206* - Mulberry Galaxy 212* - Artic Galaxy Gloss 214* - Silver Galaxy Gloss
Gloss
218* - Platinum Galaxy Gloss 226* - Nougat Galaxy Gloss 234* - Blizzard Galaxy Gloss 245 - Greige Satin 258* - Granite Galaxy Gloss
267 - Nougat Satin 268* - Nougat Gloss 294* - Cognac Galaxy Gloss 304* - Sonora Galaxy Gloss 314 - Glacier Galaxy Satin
315 - Ivory Satin 316 - Pewter Galaxy Satin 317 - Kaolin Satin T213 - Polaris
* Gloss Colours
ALTIMAX ONLY
Prices quoted are UK RRP including VAT. For the purpose of continual
improvement, Ambiance Bain reserves the right to modify the
characteristics of our products at any time without prior notice.
Errors and omissions excepted.
Ambiance Bain Terms & Conditions available on request.
Any reproduction, even partial of this document is not allowed unless
prior agreement from Ambiance Bain has been granted.
*NB. CARRIAGE COSTS ARE INCLUDED FOR ALL SHOWER TRAYS,
WALL PANELS AND ANCILLARY ITEMS ORDERED TOGETHER.
221 - Lava Satin RAL - Classic
Individually ordered wastes, adhesives and ancillaries will incur
RAL : Allow an additional 3 weeks delivery + 30% a £10 P&P charge.
choices
ABOUT US ........................................................... 4
Family Spirit ..........................................5
Master the Material ............................ 6
YOUR PROJECT................................................... 8
PRODUCT SELECTION GUIDE.......................... 12
SHOWER TRAYS
ALTIMA UK STOCK TRAYS................................. 14
Altimax................................................ 20
Oka Portrait & Landscape............... 26
Universal............................................. 32
Elegance............................................. 38
MATCHING WALL PANELS
Altimax................................................ 44
Elegance............................................. 48
COMPLEMENTARY ITEMS & ACCESSORIES.... 52
THE FEATURES OF SMO™................................. 56
INSTALLING A SHOWER SPACE....................... 58
SHOWER SPACES 2021 3
4 AMBIANCE BAIN 2021
2021 Manuel and Stefan (grandsons of the founder, Jean) currently
head-up the family business, which has grown into a 200-strong
business.
.
1956
Jean Ghirardello opens a cabinet-
making company in Soyons, in
the Ardèche region in France.
SMO ™
While some brands merely purchase
FAMILY
from other manufacturers, we have
developed SMO™, an exclusive material
that allows us to produce our own
THE SPIRIT OF THE
one piece moulded basins and shower
spaces, conceived and created as a
single piece since 1997.
Family values and a family commitment!
Ambiance bain derives its true strength from our values of work, technique,
knowledge transmission and business commitment, which have driven our
family and business for over 60 years. We are constantly working to improve
our service, our processes and our quality so that we deliver outstanding
products to our customers that will exceed their expectations.
SHOWER SPACES 2021 5
Over 200
colours
& finishes
Designed specifically to co-ordinate. Our shower
trays and matching wall panels are manufactured
entirely in our own workshops.
Whereas some brands are limited to assembling other manufacturers
components, we have developed SMOTM, an exclusive material that we use
to manufacture our own shower trays with matching wall panels, worktops
and basins for a completely harmonious look.
6 AMBIANCE BAIN 2021
A SOLID
MATERIAL
SMO™
material
EXPERT
A solid material cast From one-off parts to Meticulously finished
in one single piece production runs by hand, down to the
last detail
SMOTM is a mixture of natural We have developed a There’s nothing better than a
stone and a binder covered with manufacturing process for craftsman’s skill and know-how.
a 1mm thick surface gel coat to SMOTM that enables us to Even when produced in runs,
ensure a perfect, long-lasting produce individual shower trays every SMOTM item is sanded and
finish, unlike other painted shower and panels within bespoke polished by hand. This gives them
tray products. configurations as well as small a natural feel and finish in over
and large runs for our collections 200 satin or gloss colours.
With no seals or bonding, our trays and major projects.
and panels are cast in moulds
designed by our development
team.
SHOWER SPACES 2021 7
Finishing Panel.
+
+
Standard panels or
customised made to
measure.
Wide Panel (Up to 140 cm).
+
Recessed Tray.
+
+
Seat Bench.
MADE TO MEASURE ESPECIALLY FOR YOU
8 AMBIANCE BAIN 2021
All four edges are +
finished during
moulding. A line
of silicone allows a
perfect watertight
seal.
A special dedicated offering
to customise your bathroom
and match your style.
Design your shower space. Everything is
adjustable to suit your needs: Shower Trays,
Wall Panels, Seats. Create the showering
made to
space of your desires and we can help
provide the solutions to deliver.
measure SHOWER SPACES
RECESSED INSTALLATION SURFACE MOUNTED RAISED WITH A PLINTH
SHOWER SPACES 2021 9
renovation
solution
ADJUSTABLE SHOWER TRAYS & WALL PANELS
10 AMBIANCE BAIN 2021BATH REPLACEMENT
A RANGE OF ADAPTABLE PRODUCTS WITH EASY INSTALLATION
Whatever the initial configuration
(any corner or even between 2 walls)
- Shower Trays & Wall Panels available in many different sizes.
- Made to measure, cut to size at our factory or adjustable on site,
the choice is yours.
- Easy to install, watertight solutions.
Installation is simple & quick onto or into the floor
- Install the Shower Tray.
-T he Shower Tray can be fitted directly onto existing floor.
-T rimming of trays and wall panels can be done on site.
-T he ALTIMA Range is available from UK Stock for quick delivery (p. 14)
ALTIMA
AVAILABLE
Choose from up to 20 FROM
colours & 2 textures UK STOCK
A co-ordinated bathroom in total
harmony with matching vanity
units, accessories and
Shower Spaces.
SHOWER SPACES 2021 11shower trays & wall panels
Adjustable
Adjustable shower trays can be factory cut
to your required dimensions or trimmed on site by your installer
ALTIMA P. 14 ALTIMAX P. 20 OKA P. 26
SURFACE MOUNTED OR RECESSED SURFACE MOUNTED OR RECESSED SURFACE MOUNTED OR RECESSED
30mm THICKNESS 30mm THICKNESS 33mm THICKNESS
FINISH FINISH FINISH
SHOWER TRAYS SHOWER TRAYS SHOWER TRAYS
STONE EFFECT STONE EFFECT SMOOTH
ASSOCIATED WALL PANELS ASSOCIATED WALL PANELS ASSOCIATED WALL PANELS
WALL PANELS WALL PANELS WALL PANELS
ALTIMAX ELEGANCE ALTIMAX ELEGANCE ELEGANCE
P. 44 P. 48 P. 44 P. 48 P. 48
COLOURS AVAILABLE COLOURS AVAILABLE COLOURS AVAILABLE
5 COLOURS 20 COLOURS 19 COLOURS
PRICING EXAMPLES (£RRP) PRICING EXAMPLES (£RRP) PRICING EXAMPLES (£RRP)
A : 120 x 80 cm £649 A : 120 x 80 cm £649 A : 120 x 80 cm £699
B : 120 x 90 cm £699 B : 120 x 90 cm £699 B : 120 x 90 cm £749
C : 180 x 80 cm £899 C : 180 x 80 cm £899 C : 180 x 90 cm £1099
12 AMBIANCE BAIN 2021shower trays & wall panels
Made to measure
Trays manufactured and cast
to the exact required dimensions 70-120 x 70-200 cm
UNIVERSAL P. 32 ELEGANCE P. 38
SURFACE MOUNTED OR RECESSED RECESSED OR RAISED WITH PANELS
40mm THICKNESS 20mm THICKNESS
FINISH FINISH
SHOWER TRAYS SHOWER TRAYS
product
selection
SAND EFFECT SAND EFFECT
guide
ASSOCIATED WALL PANELS ASSOCIATED WALL PANELS
WALL PANELS WALL PANELS
ELEGANCE ALTIMAX ELEGANCE ALTIMAX
P. 48 P. 44 P. 48 P. 44
COLOURS AVAILABLE COLOURS AVAILABLE
19 COLOURS + RAL 19 COLOURS + RAL
PRICING EXAMPLES (£RRP) PRICING EXAMPLES (£RRP)
A : 120 x 80 cm £899 A : 120 x 80 cm £899
B : 120 x 90 cm £929 B : 120 x 90 cm £929
C : 180 x 80 cm £1039 C : 180 x 80 cm £1039
PRODUCT SELECTION GUIDE 13UK stock ALTIMA
Altima is available in 5 colours from UK stock for quick delivery. Altima shower tray flexibility allows floor mounted or recessed
installation with the included waste and stainless steel cover positioned to the right or left.
OVER 50 MODELS 5 COLOUR AVAILABLE
OF SHOWER TRAY OPTIONS WITHIN 3-5 DAYS
Widths 80 / 90 / 100 cm
Length 90 / 120 / 140 /
160 / 180 / 200 cm
IN STOCK
(See P.17 for matrix)
DIMENSIONS : STANDARD INSTALLATION: FLOOR MOUNTED OR RECESSED
WASTE POSITION : RIGHT OR LEFT HAND WEIGHT PER m2 : 41 KG
LIGHTER
WEIGHT
INCLUDED : STAINLESS STEEL GRILL & WASTE (BONDJA90)
14 AMBIANCE BAIN 2021UK STOCK
ALTIMA
FINISH
STONE EFFECT TEXTURE
5 COLOURS
ALTIMA UK STOCK 15ALTIMA - UK STOCK
Waste included - BONDJA90
PRICES RRP (INC. VAT)
K
SHOWER TRAYS DIMENSIONS PRODUCT CODE PRICE
80 x 120 cm ZBDEC80120 £649
80 x 140 cm ZBDEC80140 £749
80 x 180 cm ZBDEC80180 £899
90 x 90 cm ZBDEC9090 £599
90 x 120 cm ZBDEC90120 £699
90 x 140 cm ZBDEC90140 £799
90 x 160 cm ZBDEC90160 £899
90 x 180 cm ZBDEC90180 £1049
90 x 200 cm ZBDEC90200 £1099
100 x 120 cm ZBDEC100120 £749
100 x 140 cm ZBDEC100140 £849
MATCHING WALL PANELS AVAILABLE FOR FACTORY ORDER - SEE PAGE 44 - 47
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS SEALANT FOR JOINTS
Hybrid single-component high-tack adhesive. Waterproof, flexible, fungicidal
Can be repositioned within 40 mins.
Colour white.
Apply a vertical line every 20 cm across the width. JOINPAN - - - £20
Approx. 1 tube per panel
- - - Add colour choice (eg. JOINPAN 267)
COLLPAN £25
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 245 Greige
All Colours 201 Matt White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 245 Greige Satin
Corresponding 267 Nougat Satin
SMOTM
Colour Gloss : anti-slip PN6
COLOURS Colour Matt : anti-slip PN24
201 212* 214* 245 267
Matt White Satin Artic Galaxy Gloss Silver Galaxy Gloss Greige Satin Nougat Satin
* Gloss Colours
16 AMBIANCE BAIN 2021 All prices are RRP including VATUK STOCK
ALTIMA
ALTIMA - UK STOCK
SHOWER TRAY AVAILABILITY
STONE EFFECT
Artic
DIMENSIONS PRODUCT CODE Matt White Satin
Galaxy Gloss
Silver Galaxy Gloss Greige Satin Nougat Satin
80 x 120 cm ZBDEC80120 • • • • •
80 x 140 cm ZBDEC80140 • • • • •
80 x 180 cm ZBDEC80180 • • • • •
90 x 90 cm ZBDEC9090 • • o • •
90 x 120 cm ZBDEC90120 • • • • •
90 x 140 cm ZBDEC90140 • • • • •
90 x 160 cm ZBDEC90160 • • • • •
90 x 180 cm ZBDEC90180 • • • • •
90 x 200 cm ZBDEC90200 • • • o •
100 x 120 cm ZBDEC100120 • o o o •
100 x 140 cm ZBDEC100140 • o o o •
• 3-4 DAY DELIVERY (UK STOCK) • 1-2 WEEK DELIVERY (FRENCH STOCK) o 3-4 WEEK DELIVERY (MADE TO ORDER)
SIT ON INSET
ALTIMA shower trays have Thanks to their low height (3
a flat base so they can be cm), ALTIMA shower trays can be
installed directly onto the fitted onto flooring joists and inset
existing floorboards or tiles. into the floor for a level access
wetroom look.
HOW TO ORDER
• Indicate the shower tray reference followed by the chosen colour code
• EXAMPLE:
ZBDEC80180214 = shower tray width 80, length 180, colour Silver Galaxy Gloss
ALTIMA UK STOCK 17ALTIMA - UK STOCK
TECHNICAL SPECIFICATIONS
cm
2 00
GTH 80 / 3 cm thick
LEN 60 / 1 45 cm
/1 Ø 9 cm
/ 140
/ 120
90 11,8 cm 11,8 cm
160 cm
WIDT
80 /
90 / H
100 cm
Flat drying area beyond 160 cm length. Gradient on 160 cm maximum.
EQUILIBRE. Pose encastrée
INSTALLATION EQUILIBRE. Pose encastrée
RECESSED
Allow a 3.5 cm recess over the entire area of the shower tray.
H: min gap height depending on the waste.
Largeur du receveur l.
H = 8.5 cm BONDJA90 Horizontal Largeur du receveur l.
H = 12.5 cm BONDJA90 Vertical Largeur du receveur l.
H = 4.5 cm SLIMEXP 1/2 Width Axe de la bonde Axe de la bonde
H = 6.5 cm BONDEVIEGA90
1/2 Width Axe de la bonde Axe de la bonde
3.5 cm
3.5 cm
en fonction de la bonde. H
en fonction de la bonde. H
tale
etale 20 cm
e 20 cm Prévoir une réserve carrée de 20 cm minimum
Allow a waste area of 20 cm minimum.
Prévoir une réserve carrée de 20 cm minimum
EQUILIBRE. Pose au sol Prévoir une réserve carrée de 20 cm minimum
FLOOR STANDING EQUILIBRE. Pose au sol
H: min gap height depending on the waste.
Largeur du receveur l.
H = 8.5 cm BONDJA90 Horizontal Largeur du receveur l.
H = 12.5 cm BONDJA90 Vertical
H = 4.5 cm SLIMEXP 1/2 Width Axe de la bonde
H = 6.5 cm BONDEVIEGA90 1/2 Width Axe de la bonde
en fonction de la bonde. H
en fonction de la bonde. H
tale
Allow a waste area of 20 cm minimum.
etale 20 cm Prévoir une réserve carrée de 20 cm minimum
e 20 cm Prévoir une
Prévoir une réserve
réserve carrée
carrée de
de 20
20 cm
cm minimum
minimum
Prévoir une réserve carrée de 20 cm minimum
18 AMBIANCE BAIN 2021UK STOCK
ALTIMA
ALTIMA - UK STOCK
CUTTING INFORMATION
Shower trays can be cut on-site. In case of trimming, place the cut edge REPAIR KIT : for repairing marks and scratches
against a wall or flush-fit. For a better finish, treat the cut edge with the that have altered the surface of the gel coat and for
KITSMO repair kit. optional treating of edges trimmed on site.
KITSMOC - - - £89
- - - Add colour choice (eg. KITSMOC 267)
Please read and follow the instructions carefully.
MATCHING WASTE & COVER - INCLUDED
STAINLESS STEEL GRILL BONDJA90UK
cm
11.4
11.4
cm
included
Included
Ø 90 mm Ø 90 mm
Ø 40 mm
8 cm
12 cm
Ø 40 mm
WASTE UPGRADES
SLIMEXP BONDEVIEGA90
Waterless Rubber Membrane Trap
To upgrade from BONDJA90UK To upgrade from BONDJA90UK
Additional Cost £20 Additional Cost £40
Ø 110 mm
Ø 112,5 mm
Ø sortie40 mm Øsortie
40 mm 40 mm
Ø 110,5 mm
6 cm
4 cm
100 mm
110 mm
27 L/min 33 L/min
All prices are RRP including VAT ALTIMA UK STOCK 19altimax SHOWER TRAYS
Altimax offers all of the features of Altima but in a wider choice of up to 20 beautiful gloss, satin or sparkly Galaxy colours.
Adjustable to suit your exact requirements, any dimensional adjustment cuts can be fulfilled at our factory before despatch.
ADJUSTABLE TO THE FLAT STONE EFFECT
NEAREST mm BASE FINISH
The Shower Tray size is cut Floor standing or built in. Natural and warm
and the edge re-gelcoated Ideal for renovations and bath surface pattern, similar to
in our factory for a pefect replacement projects. stone.
seal.
DIMENSIONS : ADJUSTABLE INSTALLATION: FLOOR MOUNTED OR RECESSED
WASTE POSITION : RIGHT OR LEFT HAND WEIGHT PER m2 : 41 KG LIGHTER
WEIGHT
INCLUDED : STAINLESS STEEL GRILL & WASTE (BONDJA90)
20 AMBIANCE BAIN 2021SHOWER TRAYS
ALTIMAX
FINISH
STONE EFFECT TEXTURE
20 COLOURS
ALTIMAX SHOWER TRAYS 21SHOWER TRAYS
ALTIMAX
Waste included - BONDJA90
PRICES RRP (INC. VAT)
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
70 - 80 cm 100 - 110 cm ZBDEC80120 £649
111 - 120 cm ZBDEC80120 £649
B
121 - 130 cm ZBDEC80140 £749
A
131 - 140 cm ZBDEC80140 £749
160 - 170 cm ZBDEC80180 £899
171 - 180 cm ZBDEC80180 £899
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
81 - 90 cm 80 - 90 cm ZBDEC9090 £599
91 - 100 cm ZBDEC90100 £629
B
101 - 110 cm ZBDEC90120 £699
A
111 - 120 cm ZBDEC90120 £699
121 - 130 cm ZBDEC90140 £799
131 - 140 cm ZBDEC90140 £799
141 - 150 cm ZBDEC90160 £899
151 - 160 cm ZBDEC90160 £899
161 - 170 cm ZBDEC90180 £1049
171 - 180 cm ZBDEC90180 £1049
181 - 190 cm ZBDEC90200 £1099
191 - 200 cm ZBDEC90200 £1099
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
91 - 100 cm 100 - 110 cm ZBDEC100120 £749
111 - 120 cm ZBDEC100120 £749
B
121 - 130 cm ZBDEC100140 £849
A
131 - 140 cm ZBDEC100140 £849
141 - 150 cm ZBDEC100160 £999
151 - 160 cm ZBDEC100160 £999
161 - 170 cm ZBDEC100180 £1099
171 - 180 cm ZBDEC100180 £1099
181 - 190 cm ZBDEC100200 £1199
191 - 200 cm ZBDEC100200 £1199
Gloss Colours : anti-slip PN6
COLOURS Matt Colours : anti-slip PN24
200* 201 206* 212* 214* 218* 221 226* 234* 245 258*
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Lava Satin Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss
267 268* 294* 304* 314 315 316 317 T231
Nougat Satin Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris
* Gloss Colours
SELECTION OF ADHESIVE & SEALANT AVAILABLE- P. 25
All prices are RRP including VAT
22 AMBIANCE BAIN 2021SHOWER TRAYS
ALTIMAX
CUTTING INFORMATION
SHOWER TRAYS
ALTIMAX
45 cm
REPAIR KIT : for repairing marks and scratches
that have altered the surface of the gel coat and for
optional treating of edges trimmed on site.
KITSMOC - - - £89
Possible cutting areas. - - - Add colour choice (eg. KITSMOC 267)
Please read and follow the instructions carefully.
• Cutting is available on request in our factory and re-gelcoated for a
perfect seal and protection.
• Re-gelcoating is in the same colour or to match the shower tray.
However, slight differences in shade may occur.
• Always place the trimmed side against a wall.
• Always flush-fit the tray if it has been cut on 2 long sides (trimming
more than 5 cm) or widthways.
• The on-site fitter can make any further adjustments as required.
Please Note:
Any cut over 5cm from the edge may encroach into the gradient showering area.
SIT ON INSET
ALTIMAX shower trays have Thanks to their low height (3 cm),
a flat base so they can be ALTIMAX shower trays can be
installed directly onto the fitted onto flooring joists and inset
existing floorboards or tiles. into the floor for a wetroom look.
HOW TO ORDER
PLEASE PROVIDE A DRAWING
• Indicate the shower tray reference FOR FACTORY CUTS
• The final size required 178 cm
• Add the code for your colour choice
• Specify the waste type (if not specified you will receive ref. BONDJA90)
• E XAMPLE:
ZBDEC90180214 87 x 178 = shower tray width 87, length 178, waste
87 cm
BONDJA90, colour Silver Galaxy Gloss.
• PLEASE PROVIDE A DRAWING FOR FACTORY CUTS
Show waste position - (R/H Shown)
ALTIMAX SHOWER TRAYS 23SHOWER TRAYS
ALTIMAX
TECHNICAL SPECIFICATIONS
cm
00
/2
N GTH / 180 45 cm
3 cm thick
E
L 160
/ Ø 9 cm
/ 140
0
/ 12 11,8 cm
90 11,8 cm
160 cm
WIDT
80 /
90 / H
100 cm
Flat drying area beyond 160 cm length. Gradient on 160 cm maximum.
EQUILIBRE. Pose encastrée
INSTALLATION EQUILIBRE. Pose encastrée
RECESSED
Allow a 3.5 cm recess over the entire area of the shower tray.
H: min gap height depending on the waste.
Largeur du receveur l.
H = 8.5 cm BONDJA90 Horizontal Largeur du receveur l.
H = 12.5 cm BONDJA90 Vertical Largeur du receveur l.
H = 4.5 cm SLIMEXP 1/2 Width Axe de la bonde Axe de la bonde
H = 6.5 cm BONDEVIEGA90
1/2 Width Axe de la bonde Axe de la bonde
3.5 cm
3.5 cm
en fonction de la bonde. H
en fonction de la bonde. H
tale
etale 20 cm
e 20 cm Prévoir une réserve carrée de 20 cm minimum
Allow a waste area of 20 cm minimum.
Prévoir une réserve carrée de 20 cm minimum
EQUILIBRE. Pose au sol Prévoir une réserve carrée de 20 cm minimum
FLOOR STANDING EQUILIBRE. Pose au sol
H: min gap height depending on the waste.
Largeur du receveur l.
H = 8.5 cm BONDJA90 Horizontal Largeur du receveur l.
H = 12.5 cm BONDJA90 Vertical
H = 4.5 cm SLIMEXP 1/2 Width Axe de la bonde
H = 6.5 cm BONDEVIEGA90 1/2 Width Axe de la bonde
en fonction de la bonde. H
en fonction de la bonde. H
tale
Allow
Allowaawaste area
square gapofof2020cm
cmminimum.
minimum.
etale 20 cm Prévoir une réserve carrée de 20 cm minimum
e 20 cm Prévoir une
Prévoir une réserve
réserve carrée
carrée de
de 20
20 cm
cm minimum
minimum
Prévoir une réserve carrée de 20 cm minimum
24 AMBIANCE BAIN 2021SHOWER TRAYS
ALTIMAX
WEIGHT ADHESIVE / SEALANT
SHOWER TRAYS
ALTIMAX
SEALANT FOR JOINTS
DIMENSIONS PRODUCT CODE WEIGHT (WITH PACKAGING) Waterproof, flexible, fungicidal
80 x 120 cm ZBDEC80120 37 KG (43 KG)
80 x 140 cm ZBDEC80140 47 KG (53 KG) JOINPAN - - - £20
80 x 180 cm ZBDEC80180 57 KG (64 KG)
90 x 90 cm ZBDEC9090 31 KG (35 KG) - - - Add colour choice (eg. JOINPAN 267)
90 x 120 cm ZBDEC90120 40 KG (46 KG)
90 x 140 cm ZBDEC90140 49 KG (55 KG)
90 x 160 cm ZBDEC90160 57 KG (63 KG)
90 x 180 cm ZBDEC90180 65 KG (72 KG)
90 x 200 cm ZBDEC90200 74 KG (83 KG)
100 x 120 cm ZBDEC100120 46 KG (52 KG)
100 x 140 cm ZBDEC100140 55 KG (61 KG)
100 x 160 cm ZBDEC100160 63 KG (70 KG)
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 221 Lava 245 Greige
100 x 180 cm ZBDEC100180 73 KG (80 KG)
100 x 200 cm ZBDEC100200 82 KG (89 KG) All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 221 Lava 245 Greige Satin
Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
STAINLESS STEEL GRILL
ZBSTAGRILLE ADHESIVE FOR WALL PANELS
Hybrid single-component high-tack adhesive.
cm Can be repositioned within 40 mins.
11.4 Colour white.
Apply a vertical line every 20 cm across the width.
Approx. 1 tube per panel
11.4
cm
COLLPAN £25
Included
WASTES
BONDJA90 SLIMEXP BONDEVIEGA90
Waterless Rubber Membrane Trap
To upgrade from BONDJA90UK To upgrade from BONDJA90UK
Included Additional Cost £20 Additional Cost £40
Ø 90 mm Ø 90 mm
Ø 112,5 mm Ø 110 mm
Ø sortie40 mm Øsortie
40 mm 40 mm
Ø 110,5 mm
6 cm
4 cm
Ø 40 mm
8 cm
12 cm
Ø 40 mm 100 mm
110 mm
31 L/min 27 L/min 33 L/min
All prices are RRP including VAT ALTIMAX SHOWER TRAYS 25oka
PORTRAIT & LANDSCAPE SHOWER TRAYS
With elegant and dynamic lines Oka’s channel waste follows the gentle slopes of the Shower Tray. Available with a Portrait or
Landscape waste in 3 waste finishes to match your shower fittings. Floor mounted or recessed, Oka can be adjusted to your
desired dimensions.
ELEGANT AND 3 WASTE PORTRAIT AND
DYNAMIC LINES FINISHES LANDSCAPE
The channel waste follows the To match with your Portrait or Landscape waste options,
gentle slopes of the Shower Tray. accessories. adjustable in length and width to
suit your individual requirements
DIMENSIONS : ADJUSTABLE INSTALLATION : FLOOR MOUNTED OR RECESSED
WASTE POSITION : ON THE LONG OR SHORT SIDE WEIGHT PER m2 : 45 KG LIGHTER
WEIGHT
INCLUDED : STAINLESS STEEL GRILL AND WASTE
26 AMBIANCE BAIN 2021SHOWER TRAYS
OKA
FINISH
SMOOTH TEXTURE
19 COLOURS
OKA SHOWER TRAYS 27SHOWER TRAYS
OKA
Waste Included - BONDCARA
PRICES RRP (INC. VAT)
B
A
OKA LANDSCAPE SHOWER TRAYS
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
Up to 80 cm 110 - 120 cm ZBOKA80120 £699
130 - 140 cm ZBOKA80140 £799
170 - 180 cm ZBOKA80180 £949
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
81 - 90 cm 110 - 120 cm ZBOKA90120 £749
130 - 140 cm ZBOKA90140 £849
150 - 160 cm ZBOKA90160 £949
170 - 180 cm ZBOKA90180 £1099
190 - 200 cm ZBOKA90200 £1199
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
91 - 100 cm 110 - 120 cm ZBOKA100120 £849
130 - 140 cm ZBOKA100140 £949
B Prices include Stainless Steel Grill. For Matt White or Matt Black, see page 30
A
OKA PORTRAIT SHOWER TRAYS
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
70 - 80 cm 110 - 120 cm ZBOKP080120 £699
130 - 140 cm ZBOKP080140 £ 799
170 - 180 cm ZBOKP080180 £ 949
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
81 - 90 cm 110 - 120 cm ZBOKP090120 £749
130 - 140 cm ZBOKP090140 £849
150 - 160 cm ZBOKP090160 £949
170 - 180 cm ZBOKP090180 £1099
Prices include Stainless Steel Grill. For Matt White or Matt Black, see page 30
Colour Gloss : anti-slip PN6
COLOURS Colour Matt : anti-slip PN24
200* 201 206* 212* 214* 218* 226* 234* 245 258* 267
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss Nougat Satin
268* 294* 304* 314 315 316 317 T231
Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris
*Gloss Colours
28 AMBIANCE BAIN 2021 All prices are RRP including VATSHOWER TRAYS
OKA
CUTTING INFORMATION
LANDSCAPE PORTRAIT
x 10 cm max
m ma
5c
SHOWER TRAYS
x
cm
ma
6.8
OKA
max
m
5c
5 cm
• Cutting is available on request in our factory and re-gelcoated for a perfect seal and protection.
• Re-gelcoating is in the same colour or to match the shower tray. However, slight differences in shade may occur.
• Always place the trimmed side against a wall.
• Always flush-fit the tray if it has been cut on 2 long sides (trimming more than 5 cm) or widthways.
• The on-site fitter can make any further adjustments as required.
Please Note:
Any cut over 5cm from the edge may encroach into the gradient showering area.
SIT ON INSET
OKA shower trays have a flat Thanks to their low height (3.3 cm),
base so they can be installed OKA shower trays can be fitted
directly onto the existing onto flooring joists and inset into
floorboards or tiles. the floor for a wetroom look.
HOW TO ORDER
PLEASE PROVIDE A DRAWING
• Indicate the shower tray reference FOR FACTORY CUTS
• The final size required 155
178cm
cm
• Add the code for your colour choice
• Specify the waste cover (if not specified you will receive Stainless Steel)
• E XAMPLE:
ZBOKA020160317 shower tray width 88, length 155 cm, colour 317 Kaolin.
88
87cm
cm
• PLEASE PROVIDE A DRAWING FOR FACTORY CUTS
Show waste position
OKA SHOWER TRAYS 29SHOWER TRAYS
OKA
TECHNICAL SPECIFICATIONS
LANDSCAPE
Ø 7 cm 3.3 cm thick
cm
.8
8.9 48
cm
m
0c
20
to
110 Ø 7 cm
3.3 cm thick
75/10 8.9
0 cm PORTRAIT cm
48.8 cm
cm
o 180
110 t
70/90 cm
INSTALLATION
RECESSED
Allow a 3.8 cm drop on the entire surface of the Shower Tray.
H : minimum height depending on the waste.
H = 8.5 cm BONDCARA Horizontal
H = 12.5 cm BONDCARA Vertical
OKA. Pose encastrée
Shower Tray Length Shower Tray Width
l. l.
1/2 Length Axe deWaste position.
la bonde 19 cm Axe deWaste position.
la bonde
8 cm
3.8 cm
eceveur
ini en fonction de la bonde.
H
OKA. Pose encastrée
A horizontale
A verticale
l. l.
16 cm 16 cm
1/2 Length Axe de la bonde 19 cm Axe de la bonde
Provide a square area of 16 cm minimum. Provide a square area of 16 cm minimum.
cm
3.8 cm
eveur
H
i en fonction de la bonde.
horizontale
FLOOR STANDING
verticale
OKA. Pose au sol
16 cm 16 cm
H : minimum height depending on the waste.
l. l.
1/2 Length 19 cm Axe de la bonde
H = 8.5 cm BONDCARA Horizontal Axe de la bonde
H = 12.5 cm BONDCARA Vertical
H OKA. Pose au sol
ini en fonction de la bonde.
A horizontale Shower Tray Length Shower Tray Width
A verticale
16l. cm Waste position. 16 cm Waste positiion. l.
1/2 Length Axe de la bonde 19 cm Axe de la bonde
H
i en fonction de la bonde.
horizontale
verticale
16 cm 16 cm
Provide a square area of 16 cm minimum. Provide a square area of 16 cm minimum.
30 AMBIANCE BAIN 2021SHOWER TRAYS
OKA
WASTES
GROKAINOX BONDCARA
Stainless Steel
cm
8.3 48.6 c
m
SHOWER TRAYS
OKA
Included Included
ØØ70
90mm
mm ØØ90
70mm
mm
GROKABL
Lacquered Stainless Steel Matt White
Ø 40 mm
8 cm
12 cm
Ø 40 mm
31 L/min 34 L/min
Additional Cost £39
Specify when ordering.
GROKANO
Lacquered Stainless Steel Matt Black
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS
Hybrid single-component high-tack adhesive.
Can be repositioned within 40 mins.
Additional Cost £79 Colour white.
Apply a vertical line every 20 cm across the width.
Approx. 1 tube per panel
Specify when ordering.
Spare, replacement or additional waste covers are charged at: COLLPAN £25
GROKABL Matt White £119
GROKANO Matt Black £159
GROKAINOX Stainless Steel £99
Individual ordered wastes, adhesives and ancillaries will incur £10 P&P charge
SEALANT FOR JOINTS
Waterproof, flexible, fungicidal
REPAIR KIT
JOINPAN - - - £20
- - - Add colour choice (eg. JOINPAN 267)
REPAIR KIT : for repairing marks and scratches
that have altered the surface of the gel coat and
for optional treating of edges trimmed on site.
KITSMOC - - - £89 JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 245 Greige
All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 245 Greige Satin
- - - Add colour choice (eg. KITSMOC 267) Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
Please read and follow the instructions carefully.
OKA SHOWER TRAYS 31universal
SHOWER TRAYS
Manufactured and cast to your exact dimensions, Universal Shower Trays offer a perfect finish. The centre waste position
allows the water to flow effectively away and being only 33kg per m² they are easy to install.
4 CAST LARGEST RANGE EASY TO FIT
FINISHED EDGES OF SIZES All on the same level, or
No retouching ensures a From 70 to 120 cm wide and inset on joists, Universal is
perfect finish. from 70 to 200 cm long. ideal for renovations or bath
replacement projects.
Manufactured to your exact
dimensions
DIMENSIONS : MADE TO MEASURE INSTALLATION :
FLOOR MOUNTED OR RECESSED ON JOISTS
WASTE POSITION : CENTRE WEIGHT PER m2 : 33 KG LIGHTER
WEIGHT
WASTE : NOT INCLUDED
32 AMBIANCE BAIN 2021SHOWER TRAYS
UNIVERSAL
FINISH
SAND TEXTURE
19 COLOURS + RAL
UNIVERSAL SHOWER TRAYS 33SHOWER TRAYS
UNIVERSAL
PRICES RRP (INC. VAT) Waste not included, see p 41
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
70 - 80 cm 70 - 80 cm ZBSR408080 £789
81 - 90 cm ZBSR408090 £799
91 - 100 cm ZBSR4080100 £829
B 101 - 110 cm ZBSR4080110 £849
A 111 - 120 cm ZBSR4080120 £899
121 - 130 cm ZBSR4080130 £919
131 - 140 cm ZBSR4080140 £939
141 - 150 cm ZBSR4080150 £949
151 - 160 cm ZBSR4080160 £969
161 - 170 cm ZBSR4080170 £989
171 - 180 cm ZBSR4080180 £1039
181 - 190 cm ZBSR4080190 £1059
191 - 200 cm ZBSR4080200 £1079
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
81 - 90 cm 70 - 80 cm ZBSR409080 £799
81 - 90 cm ZBSR409090 £829
91 - 100 cm ZBSR4090100 £849
B 101 - 110 cm ZBSR4090110 £899
A 111 - 120 cm ZBSR4090120 £929
121 - 130 cm ZBSR4090130 £949
131 - 140 cm ZBSR4090140 £969
141 - 150 cm ZBSR4090150 £989
151 - 160 cm ZBSR4090160 £1039
161 - 170 cm ZBSR4090170 £1059
171 - 180 cm ZBSR4090180 £1079
181 - 190 cm ZBSR4090190 £1099
191 - 200 cm ZBSR4090200 £1129
Trays manufactured and cast to exact dimensions required 70-120 x 70-200 cm
Colour
ColourGloss
Gloss:: anti-slipPN6
anti-slip PN6
COLOURS Colour
ColourMatt
Matt:: anti-slipPN24
anti-slip PN24
200* 201 206* 212* 214* 218* 226* 234* 245 258* 267
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss Nougat Satin
RAL : Allow an
additional 3
weeks delivery
+ 30%
268* 294* 304* 314 315 316 317 T231 RAL CLASSIC
Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris All colours
*Gloss Colours
SELECTION OF ADHESIVE & SEALANT AVAILABLE - P. 37
34 AMBIANCE BAIN 2021 All prices are RRP including VATSHOWER TRAYS
UNIVERSAL
PRICES RRP (INC. VAT) Waste not included, see p 41
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
91 - 100 cm 70 - 80 cm ZBSR4010080 £829
81 - 90 cm ZBSR4010090 £849
91 - 100 cm ZBSR40100100 £899
B 101 - 110 cm ZBSR40100110 £929
A 111 - 120 cm ZBSR40100120 £949
121 - 130 cm ZBSR40100130 £979
131 - 140 cm ZBSR40100140 £999
141 - 150 cm ZBSR40100150 £1049
151 - 160 cm ZBSR40100160 £1079
161 - 170 cm ZBSR40100170 £1099
171 - 180 cm ZBSR40100180 £1129
181 - 190 cm ZBSR40100190 £1149
191 - 200 cm ZBSR40100200 £1199
LENGTH (A) PRODUCT CODE PRICE
SHOWER TRAYS
WIDTH (B)
UNIVERSAL
101 - 110 cm 70 - 80 cm ZBSR4011080 £849
81 - 90 cm ZBSR4011090 £899
91 - 100 cm ZBSR40110100 £929
B 101 - 110 cm ZBSR40110110 £959
A 111 - 120 cm ZBSR40110120 £979
121 - 130 cm ZBSR40110130 £1039
131 - 140 cm ZBSR40110140 £1059
141 - 150 cm ZBSR40110150 £1089
151 - 160 cm ZBSR40110160 £1119
161 - 170 cm ZBSR40110170 £1139
171 - 180 cm ZBSR40110180 £1199
181 - 190 cm ZBSR40110190 £1219
191 - 200 cm ZBSR40110200 £1249
WIDTH (B) LENGTH (A) PRODUCT CODE PRICE
111 - 120 cm 70 - 80 cm ZBSR4012080 £899
81 - 90 cm ZBSR4012090 £929
91 - 100 cm ZBSR40120100 £949
B 101 - 110 cm ZBSR40120110 £979
A 111 - 120 cm ZBSR40120120 £1039
121 - 130 cm ZBSR40120130 £1069
131 - 140 cm ZBSR40120140 £1099
141 - 150 cm ZBSR40120150 £1129
151 - 160 cm ZBSR40120160 £1179
161 - 170 cm ZBSR40120170 £1209
171 - 180 cm ZBSR40120180 £1239
181 - 190 cm ZBSR40120190 £1269
191 - 200 cm ZBSR40120200 £1299
HOW TO ORDER
• Indicate the shower tray reference
• The final size required
• Add the code for your colour choice
• Specify Waste
• EXAMPLE : ZBSR4090120214, 85 X 118 = Shower Tray width 85, length 118, and colour Silver Galaxy Gloss 214.
: BONDVEIGA 90 = VEIGA 90mm Shower Waste
All prices are RRP including VAT UNIVERSAL SHOWER TRAYS 35SHOWER TRAYS
UNIVERSAL
TECHNICAL SPECIFICATIONS
from 70 to
120 cm
cm
00
o2 4 cm thick
0t
m7
fro
Ø 90 mm
No Waste Supplied
Universal footprint with waste always in the centre of the tray.
Drainage slope over entire surface regardless of size.
Trays manufactured and cast to exact dimensions required 70 up to 120 cm wide x 70 up to 200 cm long
H : hauteur de réserve mini en fonction de la bonde.
H = 8,5 cm BONDJA90 horizontale
H = 12,5 cm BONDJA90 verticale
H = 4,5 cm SLIMEXP
INSTALLATION
UNIVERSEL. Pose au sol.
FLOOR STANDING
H: min gap height depending on the waste.
H = 8 cm WASTE90
H = 8.5 cm BONDJA90 Horizontal H
H = 12.5 cm BONDJA90 Vertical
H = 4.5 cm SLIMDOU
Allow a waste
Prévoir gap of 16ronde
une réserve cm de 16 cm maxi.
16 cm
Prévoir une réserve ronde de 16 cm maxi.
RECESSED
H
H: min gap height depending on the waste.
Allow a waste gap of 16 cm
H = 8 cm WASTE90 16 cm
H = 8.5 cm BONDJA90 Horizontal and BONDOU
H = 12.5 cm BONDJA90 Vertical
H = 4.5 cm SLIMDOU
36 AMBIANCE BAIN 2021SHOWER TRAYS
UNIVERSAL
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS SEALANT FOR JOINTS
Hybrid single-component high-tack adhesive. Waterproof, flexible, fungicidal
Can be repositioned within 40 mins.
Colour white.
Apply a vertical line every 20 cm across the width. JOINPAN - - - £20
Approx. 1 tube per panel
- - - Add colour choice (eg. JOINPAN 267)
COLLPAN £25
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 245 Greige
All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 245 Greige Satin
Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
SHOWER TRAYS
UNIVERSAL
WASTES
WASTE90 SLIMDOU BONDJA90
PRICE £49 PRICE £60 PRICE £50
Ø 90 mm Ø 90 mm
Ø 112.5 mm
Ø 40 mm
7.8 cm
Ø 110.5 mm
4 cm
Ø 40 mm
8 cm
12 cm
Ø 40 mm
Waterless Rubber Membrane Trap
29 L/min 33 L/min 31 L/min 34 L/min
All prices are RRP including VAT UNIVERSAL SHOWER TRAYS 37elegance SHOWER TRAYS
Tough and durable, Elegance Shower Trays meet all accessibility standards. Manufactured and cast to your exact dimensions,
the huge choice of size options and a centre waste offers complete installation flexibility.
MADE TO HUGE TOUGH &
MEASURE CHOICE DURABLE
Moulded to your exact From 70 to 120 cm wide 2cm thickness. Elegance meets
dimensions in a single piece and 70 to 200 cm long. all accessibility standards.
for a perfect finish.
Manufactured to your exact
dimensions
DIMENSIONS : MADE TO MEASURE INSTALLATION : RECESSED OR RAISED WITH PLINTH PANELS
WASTE POSITION : CENTRE WEIGHT PER m2 : 31 KG LIGHTER
WEIGHT
WASTE : NOT INCLUDED
38 AMBIANCE BAIN 2021SHOWER TRAYS
ELEGANCE
FINISH
SAND TEXTURE
19 COLOURS + RAL
ELEGANCE SHOWER TRAYS 39SHOWER TRAYS
ELEGANCE
PRICES RRP (INC. VAT) Waste not included, see p 47
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
70 - 80 CM 70 - 80 cm ZBSI8080 £789
81 - 90 cm ZBSI8090 £799
91 - 100 cm ZBSI80100 £829
101 - 110 cm ZBSI80110 £849
B
111 - 120 cm ZBSI80120 £899
A 121 - 130 cm ZBSI80130 £919
131 - 140 cm ZBSI80140 £939
141 - 150 cm ZBSI80150 £949
151 - 160 cm ZBSI80160 £969
161 - 170 cm ZBSI80170 £989
171 - 180 cm ZBSI80180 £1039
181 - 190 cm ZBSI80190 £1059
191 - 200 cm ZBSI80200 £1079
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
81 - 90 cm 70 - 80 cm ZBSI9080 £799
81 - 90 cm ZBSI9090 £829
91 - 100 cm ZBSI90100 £849
101 - 110 cm ZBSI90110 £899
B
111 - 120 cm ZBSI90120 £929
A
121 - 130 cm ZBSI90130 £949
131 - 140 cm ZBSI90140 £969
141 - 150 cm ZBSI90150 £989
151 - 160 cm ZBSI90160 £1039
161 - 170 cm ZBSI90170 £1059
171 - 180 cm ZBSI90180 £1079
181 - 190 cm ZBSI90190 £1099
191 - 200 cm ZBSI90200 £1129
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
91 - 100 cm 70 - 80 cm ZBSI10080 £829
81 - 90 cm ZBSI10090 £849
B
91 - 100 cm ZBSI100100 £899
A
101 - 110 cm ZBSI100110 £929
111 - 120 cm ZBSI100120 £949
121 - 130 cm ZBSI100130 £979
Trays manufactured and cast to exact dimensions required 70-120 x 70-200 cm
Colour Gloss : anti-slip PN6
COLOURS Colour Matt : anti-slip PN24
200* 201 206* 212* 214* 218* 226* 234* 245 258* 267
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss Nougat Satin
RAL : Allow an
additional 3
weeks delivery
+ 30%
268* 294* 304* 314 315 316 317 T231 RAL CLASSIC
Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris All colours
*Gloss Colours
SELECTION OF ADHESIVE & SEALANT AVAILABLE - P. 43
40 AMBIANCE BAIN 2021 All prices are RRP including VATSHOWER TRAYS
ELEGANCE
PRICES RRP (INC. VAT) Waste not included, see p 47
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
91 - 100 cm 131 - 140 cm ZBSI100140 £999
141 - 150 cm ZBSI100150 £1049
B
151 - 160 cm ZBSI100160 £1079
A
161 - 170 cm ZBSI100170 £1099
171 - 180 cm ZBSI100180 £1129
181 - 190 cm ZBSI100190 £1149
191 - 200 cm ZBSI100200 £1199
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
101 - 110 cm 70 - 80 cm ZBSI11080 £849
81 - 90 cm ZBSI11090 £899
91 - 100 cm ZBSI110100 £929
101 - 110 cm ZBSI110110 £959
B
111 - 120 cm ZBSI110120 £979
A
121 - 130 cm ZBSI110130 £1039
131 - 140 cm ZBSI110140 £1059
141 - 150 cm ZBSI110150 £1089
151 - 160 cm ZBSI110160 £1119
161 - 170 cm ZBSI110170 £1139
171 - 180 cm ZBSI110180 £1199
181 - 190 cm ZBSI110190 £1219
SHOWER TRAYS
ELEGANCE
191 - 200 cm ZBSI110200 £1249
LENGTH (A) PRODUCT CODE PRICE
K WIDTH (B)
111 - 120 cm 70 - 80 cm ZBSI12080 £899
81 - 90 cm ZBSI12090 £929
91 - 100 cm ZBSI120100 £949
101 - 110 cm ZBSI120110 £979
B 111 - 120 cm ZBSI120120 £1039
A 121 - 130 cm ZBSI120130 £1069
131 - 140 cm ZBSI120140 £1099
141 - 150 cm ZBSI120150 £1129
151 - 160 cm ZBSI120160 £1179
161 - 170 cm ZBSI120170 £1209
171 - 180 cm ZBSI120180 £1239
181 - 190 cm ZBSI120190 £1269
191 - 200 cm ZBSI120200 £1299
PLINTH
L HxL PRODUCT CODE PRICE
15 x 200 cm ZPAS015200 £299
H
Thickness 15 x 250 cm ZPAS015250 £299
1 cm
Trays manufactured and cast to exact dimensions required 70-120 x 70-200 cm
HOW TO ORDER
• Indicate the shower tray reference
• The final size required
• Add the code for your colour choice
• Specify Waste
• E XAMPLE : ZBSI90120214, 85 X 118 = Shower Tray width 85 x length 118 cm, and colour 214 Silver Galaxy Gloss.
: BONDVEIGA 90 Shower Waste
All prices are RRP including VAT ELEGANCE SHOWER TRAYS 41SHOWER TRAYS
ELEGANCE
TECHNICAL SPECIFICATIONS
Supplied with removable, adjustable supporting feet. from 70 to
The number will vary depending on size. 120 cm
cm
00
o2 2 cm thick
0t
m7
fro
Ø 90 mm
Universal footprint with waste in the centre of the tray. No Waste Supplied
ELEGANCE. Pose encastrée
Drainage slope over entire surface regardless of size.
Trays manufactured and cast to exact dimensions required 70-120 x 70-200 cm
5 cm
ELEGANCE. Pose encastrée
INSTALLATION
r de réserve mini en fonction de la bonde. H
cm ELEGANCE. Pose encastrée
BONDJA90 horizontale et BONDOU 5 cm
ELEGANCE shower trays are not flat on underside. They cannot be installed directly onto a flat floor. They should be installed as shown
BONDJA90 verticale
Pieds de soutien réglables jusqu’à 16 cm
SLIMDOU below. For flat floor surface installation use UNIVERSAL
Ou prévoir shower trays.Pieds de soutien réglables jusqu’à 16 cm
plots maçonnés.
r de réserve mini en fonction de la bonde. H Ou prévoir plots maçonnés. 5cm minimum
5 cm support
m Ceinture périphérique obligatoire
BONDJA90 horizontale et BONDOU épaisseur mini 5 cm. Ceinture périphérique obligatoire
BONDJA90 verticale RECESSED Pieds de soutien réglables jusqu’à 16 cm
épaisseur mini 5 cm.
r deSLIMDOU
réserve mini en fonction de la bonde. H
m Ou prévoir plots maçonnés. Pieds de soutien réglables jusqu’à 16 cm
min gap height
BONDJA90H:horizontale depending on the waste.
et BONDOU Ou prévoir plots maçonnés.
BONDJA90 verticale
Piedsépaisseur
de soutien réglables
mini 5 cm.
ELEGANCE. Pose au sol
Ceinture périphérique obligatoire
jusqu’à 16 cm Ceinture périphérique obligatoire
SLIMDOU
H = 8 cm WASTE90 Ou prévoir plots maçonnés. Piedsépaisseur
Supporting feet adjustable de soutien
from 16réglables
8.5 tominicm. jusqu’à
Or use
5 cm. 16 cm
masonry blocks.
H = 8.5 cm BONDJA90 Horizontal Ou prévoir plots maçonnés.
Ceinture périphérique obligatoire
H = 12.5 cm BONDJA90 Vertical épaisseur mini 5 cm. Compulsory minimum
Ceinture5périphérique
cm peripheralobligatoire Plage d’appui au sol mini 5 cm 5 cm
support required.
H = 4.5 cm SLIMDOU ELEGANCE. Pose au sol
épaisseur miniPlage d’appui au sol mini 5 cm
5 cm.
Meets all accessibility standards
Minimum 5 cm supporting area on floor.
r de réserve mini en fonction de la bonde. H
cm
BONDJA90 horizontale et BONDOU
ELEGANCE. Pose au sol Plage d’appui au sol mini 55cm
cmminimum
5 cm support
Plage d’appui au sol mini 5 cm
BONDJA90 verticale
SLIMDOU Pieds de soutien réglables jusqu’à 16 cm
RIM MOUNTED
r de réserve mini en fonction de la bonde. H Plage d’appui au sol mini 5 cm
Ou prévoir plots maçonnés 5 cm
m Plage d’appui au sol mini 5 cm
min gap height
BONDJA90H:horizontale depending on the waste.
et BONDOU
BONDJA90 verticale
r deSLIMDOU
réserve mini en fonction de la bonde. H
m H = 8 cm WASTE90 Supporting feet adjustable
Piedsfrom 8.5 to 16réglables
de soutien cm. Or use masonry
jusqu’à blocks.
16 cm
BONDJA90Hhorizontale Ou prévoir plots maçonnés
= 8.5 cm et BONDOUBONDJA90 Horizontal
BONDJA90Hverticale
= 12.5 cm BONDJA90 Vertical Compulsory minimum 5 cm peripheral support required.
SLIMDOU
H = 4.5 cm SLIMDOU
ELEGANCE.Pieds
Pose surélevée
de soutien réglables jusqu’à 16 cm
Ou prévoir plots maçonnés Meets all accessibility standards
5cm minimum support
5 cm
ELEGANCE. Pose surélevée
RAISED
r de plinthe mini en fonction de la bonde. H
cm
min gap height
BONDJA90H:horizontale depending on the waste.
et BONDOU
ELEGANCE. Pose surélevée 5 cm
BONDJA90 verticale
SLIMDOU H = 8 cm WASTE90 Piedsfrom
Supporting feet adjustable de soutien
8.5 to 16réglables jusqu’à
cm. Or use 16 cmblocks.
masonry
r de plinthe mini
H =en8.5
fonction
cm de laBONDJA90
bonde. Horizontal H Ou prévoir plots maçonnés. 5 cm
m
H = 12.5 cm
BONDJA90 horizontale et BONDOU BONDJA90 Vertical Prévoir un retrait pour épaisseur de la
Ceinture périphérique
Compulsory minimum obligatoire
5 cm peripheral support required.
BONDJA90Hverticale
= 4.5 cm SLIMDOU épaisseur mini 5 cm.
plinthe.
r deSLIMDOU
plinthe mini en fonction de la bonde. H
Prévoir un retrait pour épaisseur de la plinthe.
m Pieds de soutien réglables jusqu’à 16 cm
BONDJA90 horizontale et BONDOU Ou prévoir plots maçonnés.
BONDJA90 verticale Prévoir un retrait pour épaisseur de la
SLIMDOU Ceinture périphérique obligatoire
42 AMBIANCE BAIN 2021 Piedsépaisseur
de soutien réglables plinthe.
mini 5 cm. jusqu’à 16 cm
Ou prévoir
Prévoirplots maçonnés.
un retrait pour épaisseur de la plinthe.SHOWER TRAYS
ELEGANCE
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS SEALANT FOR JOINTS
Hybrid single-component high-tack adhesive. Waterproof, flexible, fungicidal
Can be repositioned within 40 mins.
Colour white.
Apply a vertical line every 20 cm across the width. JOINPAN - - - £20
Approx. 1 tube per panel
- - - Add colour choice (eg. JOINPAN 267)
COLLPAN £25
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 245 Greige
All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 245 Greige Satin
Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
WASTES
WASTE90 SLIMDOU BONDJA90
SHOWER TRAYS
ELEGANCE
PRICE £49 PRICE £60 PRICE £50
Ø 90 mm Ø 90 mm
Ø 112.5 mm
Ø 40 mm
7,8 cm
Ø 110.5 mm
4 cm
Ø 40 mm
8 cm
12 cm
Ø 40 mm
Waterless Rubber Membrane Trap
24 L/min 33 L/min 31 L/min 34 L/min
All prices are RRP including VAT ELEGANCE SHOWER TRAYS 43altimax WALL PANELS
Available in two standard heights – 2.1m or 2.4m, Altimax Shower Panels have a natural warm surface similar to stone in a
choice of 20 beautiful colours.
2 STANDARD 4 FINISHED 20 COLOURS AND
HEIGHTS EDGES STONE EFFECT
FINISH
Available in 2 heights No added profiles and no re- Natural and warm surface
2.1 m, 2.4 m and 0.9 m or 1.2 m touching for a perfect finish. similar to stone.
wide.
DIMENSIONS : STANDARD WEIGHT PER m2 : 12 KG LIGHTER
WEIGHT
THICKNESS : 0.6 cm
44 AMBIANCE BAIN 2021WALL PANELS
ALTIMAX
FINISH
STONE EFFECT TEXTURE
20 COLOURS
ALTIMAX WALL PANELS 45WALL PANELS
ALTIMAX
PRICES RRP (INC. VAT)
PANEL HEIGHT 210 CM
90, 100 or 120 cm
210 cm
0.6 cm thick
WIDTH PRODUCT CODE PRICE
UP TO 90 cm ZPDEC21090 £499
UP TO 100 cm ZPDEC210100 £549
UP TO 120 cm ZPDEC210120 £599
COLOURS
200* 201 206* 212* 214* 218* 221 226* 234* 245 258*
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Lava Satin Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss
267 268* 294* 304* 314 315 316 317 T231
Nougat Satin Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris
*Gloss Colours
46 AMBIANCE BAIN 2021 All prices are RRP including VATWALL PANELS
ALTIMAX
PRICES RRP (INC. VAT)
PANEL HEIGHT 240 CM
90 or 120 cm
0.6 cm thick 240 cm
WIDTH PRODUCT CODE PRICE
UP TO 90 cm ZPDEC24090 £549
UP TO 120 cm ZPDEC240120 £649
WALL PANELS
ALTIMAX
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS SEALANT FOR JOINTS
Hybrid single-component high-tack adhesive. Waterproof, flexible, fungicidal
Can be repositioned within 40 mins.
Colour white.
Apply a vertical line every 20 cm across the width. JOINPAN - - - £20
Approx. 1 tube per panel
- - - Add colour choice (eg. JOINPAN 267)
COLLPAN £25
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 221 Lava 245 Greige
All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 221 Lava 245 Greige Satin
Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
All prices are RRP including VAT ALTIMAX WALL PANELS 47elegance WALL PANELS
The smooth finish and 1cm thickness ELEGANCE Wall Panels make them ideal for renovations, particularly where you need to
cover service ducts or create shelf features. Made to measure, custom moulded panels up to 250cm high and 140cm wide,
ELEGANCE adds a touch of luxury to any Shower Space.
CUSTOM THICKNESS 4 FINISHED
MOULDED 10 MM EDGES
Made to measure up to Ideal for renovations. Suitable for No added profiles and no
250 cm high and 140 cm covering service ducts and can be re-touching for a perfect
wide. used to create shelves. Adjustable finish every time.
on site, depending on installation
requirements.
DIMENSIONS : MADE TO MEASURE WEIGHT PER m2 : 20 KG LIGHTER
WEIGHT
THICKNESS : 1 cm
48 AMBIANCE BAIN 2021WALL PANELS
ELEGANCE
FINISH
SMOOTH FINISH
19 COLOURS + RAL
ELEGANCE WALL PANELS 49WALL PANELS
ELEGANCE
MADE TO MEASURE WALL PANELS
Product Code ZPAN - Custom made from 7 to 140 cm wide and 7 to 250 cm high
7 to 140 cm
7 to
250 cm
Thickness 1 cm
ATTENTION : Before ordering, remember to check accessibility on site for large panels.
HOW TO ORDER
• Use the reference ZPAN followed by the dimensions (height then width). Add the code of the chosen colour and
specify the exact dimensions of the Wall Panel.
• E XAMPLE : ZPAN230100214, 225 x 98 = Panel Height 225, width 98, and colour 214 Silver Galaxy Gloss.
COLOURS
200* 201 206* 212* 214* 218* 226* 234* 245 258* 267
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Nougat Galaxy Gloss Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss Nougat Satin
RAL : Allow an
additional 3
weeks delivery
+ 30%
268* 294* 304* 314 315 316 317 T231 RAL CLASSIC
Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris All colours
*Gloss Colours
SELECTION OF ADHESIVE & SEALANT AVAILABLE - P. 51
50 AMBIANCE BAIN 2021WALL PANELS
ELEGANCE
PRICES RRP (INC. VAT) MADE TO MEASURE PANELS
WIDTH (CM)
31-40 41-50 51-60 61-70 71-80 81-90 91-100 101-110 111-120 121-130 131-140
31-40 cm 285 290 305 310 325 330 340 350 360 370 380
41-50 cm 290 305 315 330 340 350 360 375 385 400 410
51-60 cm 305 315 330 350 360 375 385 400 415 425 445
61-70 cm 310 330 350 360 375 400 410 425 440 460 470
71-80 cm 325 340 360 375 400 415 430 450 470 490 505
81-90 cm 330 355 375 400 415 435 450 475 500 515 535
91-100 cm 340 360 385 405 430 450 475 495 520 540 565
101-110 cm 350 375 400 425 450 475 495 525 550 575 600
111-120 cm 360 385 415 440 470 495 520 550 575 600 630
121-130 cm 370 400 425 460 490 515 540 575 600 630 665
HEIGHT
131-140 cm 375 410 445 470 505 535 565 600 630 665 695
141-150 cm 385 425 455 489 520 555 585 625 655 690 720
151-160 cm 400 430 470 510 540 580 610 650 685 720 755
161-170 cm 405 445 485 520 560 600 635 670 710 750 785
171-180 cm 420 455 495 535 580 620 653 695 740 780 820
181-190 cm 425 470 510 555 600 640 680 720 765 805 850
191-200 cm 435 475 520 565 610 655 705 745 790 835 880
201-210 cm 445 490 540 585 630 675 725 775 820 870 915
211-220 cm 455 500 555 600 650 700 745 800 850 895 945
221-230 cm 465 515 565 620 670 720 770 825 875 925 980
231-240 cm 475 525 580 630 690 740 790 850 900 955 1005
241-250 cm 480 540 590 650 700 760 815 875 925 985 1035
Wall panels manufactured and cast to exact dimensions required 7-140 wide x 7-250cm high
ADHESIVE / SEALANT
ADHESIVE FOR WALL PANELS SEALANT FOR JOINTS
Hybrid single-component high-tack adhesive. Waterproof, flexible, fungicidal
Can be repositioned within 40 mins.
Colour white.
Apply a vertical line every 20 cm across the width. JOINPAN - - - £20
Approx. 1 tube per panel
- - - Add colour choice (eg. JOINPAN 267)
COLLPAN £25
JOINPAN Colours 100 Transparent 200 White 267 Nougat 214 Silver 245 Greige
All Colours 200 Gloss White 212 Artic Galaxy Gloss 214 Silver Galaxy Gloss 245 Greige Satin
WALL PANELS
ELEGANCE
Corresponding 201 Matt White 267 Nougat Satin 316 Pewter Galaxy Satin
SMOTM 314 Glacier Galaxy Satin 268 Nougat Gloss
All prices are RRP including VAT ELEGANCE WALL PANELS 51COMPLEMENTARY PRODUCTS & ACCESSORIES
SEATS
CORNER SEATS
WxH PRODUCT CODE PRICE
49 X 45 cm ZSIAR £549
120 cm SMO™ seat
100 cm SMO™ lite trim
delivered with metal
frame and bracket.
MADE TO LENGTH SEAT
PRODUCT
LxHxD PRICE
CODE
L 40 to 120 cm x H 45 cm x D30 cm
ZSI £599
2 open ends
L 40 to 120 cm x H 45 cm x D30 cm
ZSIEG £649
Left end closed
L 40 to 120 cm x H 45 cm x D30 cm
ZSIED £649
Right end closed
120 cm
Seat length can be customised from 40 to 120 cm.
100 cm
Height and depth cannot be modified.
Delivered with mounting bracket.
STANDARD SEAT
LxHxD PRODUCT CODE PRICE
85 x 45 x 30 cm ZBANF85 £749
120 cm
100 cm
2 closed ends
52 AMBIANCE BAIN 2021 All prices are RRP including VATCOMPLEMENTARY PRODUCTS & ACCESSORIES
PLINTHS
VERTICAL PANEL
L
Vertical panel for covering service ducts.
H
LxH PRODUCT CODE PRICE
20 x 250 cm ZPAS250020 £299
Thickness. 1 cm
HORIZONTAL PLINTHS
L
Horizontal plinth for fitting raised shower tray
H
Thickness 1 cm
LxH PRODUCT CODE PRICE
200 x 15 cm ZPAS015200 £299
250 x 15 cm ZPAS015250 £299
COLOURS
FINISH
200* 201 206* 212* 214* 218* 226*
COMPLEMENTARY PRODUCTS
Gloss White Matt White Satin Mulberry Galaxy Gloss Artic Galaxy Gloss Silver Galaxy Gloss Platinum Galaxy Gloss Nougat Galaxy Gloss
& ACCESSOIRES
234* 245 258* 267 268* 294* 304*
Blizzard Galaxy Gloss Greige Satin Granite Galaxy Gloss Nougat Satin Nougat Gloss Cognac Galaxy Gloss Sonora Galaxy Gloss
RAL : Allow an
additional 3
weeks delivery
+ 30%
314 315 316 317 T231 RAL CLASSIC
Glacier Galaxy Satin Ivory Satin Glacier Galaxy Satin Kaolin Satin Polaris All colours SMOOTH TEXTURE
*Gloss Colours
All prices are RRP including VAT COMPLEMENTARY PRODUCTS & ACCESSORIES 53COMPLEMENTARY PRODUCTS & ACCESSORIES
WASTES
WASTES
WASTE90 SLIMDOU
Ø 112.5 mm
Ø 40 mm
Ø 110.5 mm
7,8 cm
4 cm
29 L/min 33 L/min Waterless Rubber Membrane Trap
PRICE £49 PRICE £60
BONCARA BONDJA90
ØØ70
90mm
mm ØØ90
70mm
mm Ø 90 mm Ø 90 mm
Ø 40 mm Ø 40 mm
8 cm
8 cm
12 cm
12 cm
Ø 40 mm Ø 40 mm
31 L/mIn 34 L/mIn 31 L/mln 34 L/mIn
PRICE £50 PRICE £50
SLIMEXP BONDEVIEGA90
Ø 110 mm
Ø 112,5 mm
Ø sortie40 mm Øsortie
40 mm 40 mm
Ø 110,5 mm
6 cm
4 cm
100 mm
110 mm
27 L/min Waterless Rubber Membrane Trap 33 L/min
PRICE £60 PRICE £80
*NB. CARRIAGE COSTS ARE INCLUDED FOR ALL SHOWER TRAYS AND WALL PANELS.
Individually ordered wastes, adhesives and ancillaries will incur a £10 P&P charge.
54 AMBIANCE BAIN 2021 All prices are RRP including VATYou can also read
