Switching/dimming actuators
for lighting control
For switching and dimming of lighting groups with
electronic ballasts
Smart home
and building
solutions.
Global. Secure.
Connected siemens.com/gamma
Lighting control unit can be configured for the dimming Diagnostic functions:
with 1 to 10 volts range. Switch-on/off delays can be used Switch cycle and operating hour
The new switching/dimming actuators to enable functions such as stepless counting with threshold monitoring
N 536D31 and N 536D51 are expanding switching of the lighting. Integrated supports optimal maintenance of the
the DIN rail-mounted device family to scene control makes it possible to call lamps. Numerous status messages
the application of lighting control via up customized lighting moods. Seven provide reliable information about
a 1–10 V control interface. The DC override functions with configurable the state of the lighting system.
1...10-volt control outputs can be used priority levels are available to override
to control dimmable electronic ballasts the lighting.
and LED drivers. The switch contacts
Highlights
enable direct on/off switching of four to Intuitive front control field
eight light groups. Direct control on the front control field
• High lighting quality through switching
makes it possible to test the installation and dimming of LEDs and fluorescent
Optimal lighting control using status LEDs and buttons. lamps via 1- to 10-volt control outputs
With their extensive control functions, The lighting can be switched and dimmed
• Optimal lighting for exceptional conve-
the actuators enable the switching and individually for each channel with the nience through configurable dimming
dimming of lighting as well as the setting press of a button. The switching states behavior
of brightness values using different fade are signaled for each channel individually.
• Simple testing of the installation via
times. The configuration option of the front control field
predefined and user-defined dimming
• Maintenance-free terminals for the
curves enables optimal dimming
reduction of the installation time
behavior. Individual threshold values
Use of the new switching/
dimming actuators
High convenience, productivity, and creativity in the workplace in offices and
conference rooms requires optimal lighting!
High lighting convenience with dimmable ECG Switching and dimming LEDs via LED drivers
Lighting types that cannot be dimmed directly are controlled The use of switching/dimming actuators N 536D together
by way of electronic ballasts (ECG). For example, fluorescent with the suitable LED driver offers the possibility of
lamps are dimmed via ECG featuring a 1...10 V control input. creating pleasant lighting moods with LEDs. The control
The new switching/dimming actuators N 536D offer the of fluorescent lamps and LEDs via the corresponding
corresponding control output. ballasts enables optimal workplace lighting in offices
and conference rooms.
AC 230 V
AC 230 V
I201_19739a
I201_19740a
LED-Treiber
EVG KNX 1 ... 10 V
KNX 1 ... 10 V LED
Vorschaltgerät LeuchtstofflampeExtensive automation
functions
The switching/dimming actuators offer extensive
control, override, and diagnostic functions that can
be activated in the ETS without additional modules
or controllers, i.e., in the same device.
Lighting such as LED and fluores-
cent lamps can be switched and
dimmed via display and control
devices or through the evaluation
of sensor data.
Display and Sensor data
control
devices
Control functions:
For the control and switching of
lighting and motors, both on/off 1 &
switch commands and time, scene, t
and logic functions are available. 0 1
Dimming Control value Time Logic module Day/night
function
Override functions: Lighting can
be overridden on a user-defined
basis, through evaluation of sensor 1
data, manually, or via a centralized
function. 0
Control value Manual Lock Central
override function override
Diagnostic functions:
Lighting
The switching actuator diagnostic
and analysis functions are used to
test the device functions, device
installation, and switch cycles. 1 2 3
The minimum and maximum
dimming values and dimming Status Configure Test Switch cycles Operating
curves can also be configured. dimming hours
curves
All diagnostic functions can be
displayed via operating and display
devices.
MonitoringHardware characteristics Type N 536D31 N 536D51 Enclosure data Design N N DIN rail-mounted device for installation on rail TH35 DIN EN 60715 Dimensions Width (1MW = 18 mm) 6 MW 8 MW Display control elements On-site operation via membrane keypad Switch position display via LEDs Power supply Voltage supply of electronics via bus voltage Bus connection Integrated bus coupler Bus connection via bus terminal block Outputs (load outputs) Potential-free relay contacts 4 8 Contact voltage Contact rated voltage, AC [V] 230 Contact current Contact rated current, AC [A] 16 AC1 operation (cos ∅ = 0.8) [A] 16 Maximum inrush current (t = 150 µs) [A] 400 Maximum inrush current (t = 250 µs) [A] 320 Maximum inrush current (t = 600 µs) [A] 200 Fluorescent lamp load AX [A] 10
Load specifications Type N 536D31 N 536D51 Service life Mechanical service life (operating cycles in millions) 1 Electrical service life (operating cycles in millions) 0.1 Power loss Maximum power loss per device at rated output [W]** 12 Switching capacities/load types, loads Resistive load [W]* 3680 Minimum switching capacity [V/mA] 12/100 Maximum DC1 breaking capacity [V/A] 24/10 Maximum capacitive load [µF] 140 Incandescent lamps Incandescent lamp [W]* 2500 Halogen lamp 230 V [W]* 2500 NV halogen lamp with conventional transformer (inductive) [VA] 500 Fluorescent lamps T5/T8 Uncompensated [VA] 2300 Parallel compensated (at max. possible C) [W] 1300 DUO switching [VA] 2300 Compact fluorescent lamp Uncompensated [VA] 1600 Parallel compensated (at max. possible C) [W] 1100 Outputs (control outputs, 1…10 V) Number of control voltage outputs DC 1...10 V (passive) 4 8 Maximum current per control output [mA]* 94 Control output, max. number of ECGs & drivers (2 mA per EVG)* 47 * Restrictions for rated current (device) and derating information: • 16 A resistive in switching actuator mode; dimming current = 0 mA; independent of installation position and temperature • 10 AX is switching/dimming actuator mode; dimming current = 94 mA max. with standard installation position and + 25 °C • 10 AX is switching/dimming actuator mode; dimming current = 74 mA max. with standard installation position and + 45 °C
All important data
at a glance
Shared Functions
characteristics per device
Switching/dimming actuator N 536D Control functions Override functions
• One relay contact per output as • Selectable operating mode: normal • Manual override ON
a switching element mode, 1- or 2-level timer mode, • Permanent OFF
• Contact rated current voltage flashing • Lock mode
AC 230 V • Configurable control value input for • Central override
• Contact rated frequency ON/OFF switching depending on • Forced switch-on/off
50 / 60 Hz threshold values
• A control voltage output of DC...10 V • Configurable on/off switch delay Diagnostic functions:
per channel for the control of • Central switching with separately
• Counting of operating hours with
dimmable electronic control gear configurable on/off delay
threshold monitoring
• Manual control function for each • Logic operations (AND, OR, NOT AND,
• Counting of switching cycles with
channel on the device for switching EXCLUSIVE OR, NOT OR, FILTER,
threshold monitoring
and dimming and activating direct TRIGGER)
• Status messages
operation • Switching the output on/off via
• Maintenance-free terminals for dimming brighter/darker
connecting and looping through • Dimming curves for optimization of
solid, stranded, and fine-stranded dimming behavior of lamps configu-
conductors, 0.5 to 2.5 mm2 rable
• At least one phase connection • Maximum and minimum dimming
terminal per output values configurable via parameters
• Operation of electronics via bus and object
voltage – night mode object for time-limited
• Integrated bus coupler, bus connec- switching on of the output at night
tion via bus terminal block can be added
• Red LED for displaying the activation • Retriggering of ON time (ON time
of address mode and readiness for extension) during timer mode up to
operation a configurable maximum extension
• Housing Plastic; color: with repeated (2x, 3x, 4x, 5x)
RAL 7035 (light gray); N-dimension retriggering
• DIN rail-mounted device for installa- • Integrated 8-bit scene control with up
tion on rail TH35 DIN EN 60715 to 8 scene assignments per output
• Protection type: IP 20 • Configurable switching state for bus
• Switching construction site function voltage failure and starting value of
• Object for monitoring device func- the switching object for when bus
tionality voltage is recovered
• Object for targeted call-up of status • Addable night mode object for
values time-limited switch-on of the output,
i.e., the lighting
Type Design OC Order no. PE PKG/ PG Price
(ST, SZ, M) VPE (€)
N 536D31 Switching/dimming actuator 4 x AC 230 V, 10 AX, A 5WG1536-1DB31 1 1
1…10 V
N 536D51 Switching/dimming actuator 8 x AC 230 V, 10 AX, A 5WG1536-1DB51 1 1
