System solution choices for major home appliances Cooling, heating, cleaning, washing July, 2020
Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 2
Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 3
Overview of home appliances
› Dishwasher
Major home › Refrigerators and freezers
appliances › Room air conditioners
› Washing machines and Dryers
› Blender, mixer, food processor
Home Small home › Microwave oven
appliances appliances › Vacuum cleaner
› Fans and purifier for air and water
Induction › Tabletop / Multi-hob
› Induction cooker
heating › Induction rice cooker
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 4
Infineon leads incorporation of market trends in appliances
System cost reduction
Low acoustic noise Wireless connectivity
Certification effort
User interface Platform approach
Security
Cloud connectivity Sensor-less FOC
IoT
Space constraints
EMI / robustness
Lifetime improvement
Predictive maintenance
Higher versatile
Energy efficiency
Faster time-to-market
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 5
Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 6
Motor control: iMOTION™ or Microcontroller?
Does the customer want to write or has motor control code?
Is the customer able to write motor control codes?
Yes No
Microcontroller iMOTION™
Ready-to-use motor control or integrate on hardware level
Controller TurnKey MCE + Controller Smart IPM
Microcontroller Motion control engine Motion control engine Motion control engine
Microcontroller Microcontroller
Customer writes his own software
Ready-to-use
with support of advance tools for
Motor controller for Additional MCU for Driver & power stage
BLDC, Brushed DC, PMSM and
variable speed drives customer functionality,
Sensorless FOC
available with Flash and Fully integrated
OTP memory inverter solution
PSoC® 4/6 / FM4 IRMCK099
IMC300 IMM100 / IMD100
XMC™ IMC100
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 7
Microcontrollers for home appliance applications
› PSoC® 6: Highly integrate HMI solution: CapSense touch
and TFT display
Appliances PSoC® 6
› PSoC® 6 + WiFi & BT Comb: providing the total solution of
IoT connectivity & security (Cloud service, Mesh Gateway)
HMI: CapSense
touch & TFT
› Appliance HMI and HMI + Main control (2 in 1 solution):
PSoC® 4 Reliable & stable Cap touch, large pin pitch package,
wide voltage range
System control: › High Reliability and qualified ESD performance on single
MM MCU layer board
2 in 1 (Sys & HMI)
main control › No.1 market share in white goods main control include of 8
bit & FM
› High reliability and low power for the connectivity
WiFi BT combo: Smart home WiFi & BT comb
› Complete eco system for product development and network
BLE & BLE mesh
service: Modus toolbox IDE, Cirrent INI
BT & BLE › Complete portfolio to support BLE node and BLE Mesh
solution
One-stop-shop ICW solutions — HMI, system control and wireless connectivity
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 8Motor control portfolio
› MCU: Best cost/performance MCU, Dual core providing flexible Motor
SW architecture, Integrated with CMP/OPA
PSoC® 6 256K › Solution: >40 KHz PFC carry wave, effective BOM cost for the HPFC &
HPFC & Dual motor Dual motor control
› 1st win business in Air-con in China market with 48 MHz CM0+ Core
Total through optimized Motor SW algorithm
PSoC® 4 S3 solution › Integrated with CMP/OPA, saving BOM cost
LPFC & Single compressor
› Leading technology solution in China WM application: Electrical braking,
Electrical weight, OOB, Pulse spin, Un-stop running, Rotor position
PSoC® 4 S3 angle servo control, High frequency injection
WM DDM/ BLDC/ DD › HW control DDM/BLDC/DD motor through S/W adjusting
Full › Ease of use: Flexible SW benefit the customer individual startup
performance and integrated with FOC & square wave compressor control
design
PSoC® 4 S2 both
support
Fridge compressor › Competitive BOM cost with integrated CMP/OPA
› Control algorithm and solution for the Air-con fan, range hood, air
purifier, coil fan
PSoC® 4 S2 › Competitive BOM cost with integrated CMP/OPA,
Fan control › Small package (QFN32/40) enable us to serve integrated solution inside
motor
Production qualified motor control library & Highly integrated motor-specific peripherals
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 9Solutions for consumer motor drives: Discretes or IPM inverters
Integration
high
Space optimized: IPM Space optimized: IPM
Integrated in motor housing Higher power rated motors
No Heatsink Heatsink
Thermal optimized: IGBT/MOS Assembly optimized: IGBT/Module
Larger PCB space to extend power w/o heatsink Easy HS mounting + isolation
low
Motor power
10 W 100 W 300 W 1 kW 3 kW
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 10Inverter: MOSFETs or IGBTs?
Better
Inverter Better Inverter full load
with light load with Efficiency
MOSFET efficiency IGBT Better
EMI
Output characteristics Diode rev. recovery
Ic [A]
4,0
3,5 CoolMOS™
CE
Conduction losses
3,0
2,5
2,0 CFD
1,5
1,0 IGBT6
0,5
0,0
-0,5
t [ns]
25% load 75% load
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 11IPM solutions – Product application mapping
Applications Current rating CIPOS™ Nano CIPOS™ Micro CIPOS™Mini
1-3 A (500 V) IRSM836-0x5MA IRSM5y5-0x5zA, IM240
Fan
2-4 A (250 V) IRSM836-0x4MA IRSM5y5-0x4zA
Compressor 1-3 A (500 V) IRSM836-084MA IRSM5y5-084zA, IM240
Refigerator (small fridge) 2-4 A (250 V) IRSM807-105MH IRSM5y6-076zA
4 A (600 V) IRSM808-204MH IM231
IGCM04F60yA
Compressor 4-8 A IM231
IGCM06F60yA
Drain pump 1-6 A (500 V) IRSM836-0x5MA IRSM5y5-0x5zA, IM240
Washing machine IKCM10H60yA
Drum motor 8-15 A
IKCM15H60yA
IRSM836-0x5MA
1-3 A (500 V) IRSM5y5-0x5zA, IM240
Indoor unit fan IRSM807-045MH
2-8 A (250 V) IRSM836-0x4MA IRSM5y5-0x4zA
4-10 A (500 V) IRSM807-04(10)5MH IRSM5y5-0x5zA, IM231
Home Outdoor unit fan 4-8 A (250 V) IRSM808-204MH IRSM5y6-076zA
appliances IKCM15L60yA
Compressor 15-30 A IKCM20L60yD
Air conditioner IKCM30F60yD
IFCM20T65GD IFCM20U65GD
PFC 20-30 A
IFCM30T65GD IFCM30U65GD
IFCM10S60GD IFCM10P60GD
PFC + Compressor 10 A, 15 A, 20 A IFCM15S60GD IFCM15P60GD
IM564
IRSM836-0x5MA
1-3 A (500 V) IRSM5y5-0x5zA, IM240
Fan Ceiling & upright fans IRSM807-045MH
2-8 A (250 V) IRSM836-0x4MA IRSM5y5-0x4zA
1-3 A (500 V) IRSM807-045MH, IMM100 IRSM5y5-0x5zA, IM240
Circulation pump Motor 3-7 A (500 V) IRSM836-0x5MA IM231
4-8 A (250 V) IRSM836-0x4MA IRSM5y5-0x4zA
IKCM20L60zu
IKCM30F60zu
Fan pump GPI 4-30 A
IKCM10L60yA
Others
IKCM15L60zu
IM564 (PFC+INV)
IRSM836-0x5MA
1-5 A (500 V) IRSM807-045MH IRSM5y5-0x5zA, IM240
Ventilation Bathroom fan
IMM100
2-8 A (250 V) IRSM836-0x4MA IRSM5y5-0x4zA
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 12Discrete solutions – Product application mapping
Applications Current rating IGBT & MOSFET Gate driver Controller
1-3 A IRMCF171
Fan
(600 V)
IKD03N60RF, IPN/D60R2K0CE 2ED2304S06F, 6EDL04x06, 2EDL05
IRMCF183M
Refrigerator 1-10 A 2ED2304S06F, 6EDL04x06, 2EDL05
Compressor IKD03N60RF, IKD04N60RF, IKD04N60RF, IKA08N65ET6, IRMCF171
(600 V - 2ED2106(4) / 8(4) / 9(4)S06F(J)
(small fridge)
650 V) IKA10N65ET6, IKA15N65ET6, IPD60R1K5CE, IPD65R420CFD 2ED2181(4) / 2(4)/3(4) / 4(4)S06F(J)
IRMCF183M
1-6 A IKD03N60RF, IKD04N60RF, IKD06N60RF, IPN/D60R2K0CE, IRMCF171
Drain pump 6EDL04x06, 2ED2304S06F, 2EDL05
(600 V) IPN/D60R1K4CE IRMCF183M
Washing machine IRMCF171
10-20 A IKD10N60RF, IKD15N60RF, IKB10N60T, IKB15N60T, 6EDL04I06PT, 2EDL23x06J
Drum motor IRMCF183M
(600 V) IKB20N60T, IKP10N60T, IKP15N60T, IKP20N60T 2ED2181(4) / 2(4) / 3(4) / 4(4)S06F(J)
XMC4400-F100
1-6 A IRMCF171
IKD03N60RF, IKD04N60RF, IKB06N60T, IKP06N60T, IKA06N65ET6,
Indoor unit fan (600 V - IRMCF183M
650 V) IPN/D60R2K0CE, IPN/D60R1K4CE 6EDL04x06, 2EDL05, 2ED2304S06F, 2ED2106(4) / XMC1000
4-10 A 8(4) / 9(4)S06F(J) IRMCF171
IKD03N60RF, IKD04N60RF, IKD10N60RF, IKB06N60T, IKP06N60T,
Outdoor unit fan (600 V - IRMCF183M
650 V) IKP10N60T, IPD60R1K5CE, IPD65R420CFD 2EDL23x06, XMC1000
Air conditioner
10-20 A 2ED2181(4) / 2(4) / 3(4) / 4(4)S06F(J) IRMCF171
IKP10N60T, IKP15N60T, IKP20N60T,
Compressor (600 V - IRMCF183M
650 V) IKA08N65ET6, IKA10N65ET6,IKA15N65ET6 XMC4400-F100
Home 10-30 A 1ED44175N01B, 1ED44173N01B,
appliances PFC (600 V - IKW40N65WR5, IKFW40N60DH3E, IPB60R280P7 1ED44176N01F, IRS44273L, IRS4427S, ICE3PCS01G
650 V) 2EDL23I06PJ, 2ED2181 / 2 / 3 / 4S06F
4-8 A IRMCF171
IKD04N60RF, IKD04N60RF, IKB06N60T, IKP06N60T, IKA08N65ET6,
Circulation pump (600 V - IRMCF183M
650 V) IPD60R1K5CE, IPD65R420CFD XMC1000
6EDL04x06, 2EDL05, 2ED2304S06F, 2ED2106(4) /
Dish washer
8(4) / 9(4)S06F(J) IRMCF171
1-6 A IKD03N60RF, IKD04N60RF, IKD04N60RF, IKD06N65ET6, IKB06N60T,
Drain pump IRMCF183M
(600 V) IKP06N60T, IKA06N60FP, IPN/D60R2K0CE, IPN/D60R1K4CE XMC1000
1-10 A IKD03N60RF, IKD04N60RF, IKD06N60RF, IKD10N60RF, IKB06N60T, IRMCF171
Ceiling & upright fans,
Fan
Bathroom fan, Ventilation
(600 V - IKP06N60T, IKA08N65ET6, IKA10N65ET6, IKP10N60T, IPD60R1K5CE, IRMCF183M
650 V) IPD65R420CFD XMC1000
2EDL23x06,
IKD03N60RF, IKD04N60RF, IKD04N60RF, IKB06N60T, IKP06N60T, 2ED2181(4) / 2(4) / 3(4) / 4(4)S06F(J)
IKD10N60R, IKD15N60R, IKD10N60RF, IKD15N60RF, IKB10N60T, IRMCF171
1-20 A
Heating pump, pool IRMCF183M
Pump
pumps
(600 V - IKB15N60T, IKB20N60T, IKP10N60T, IKP15N60T, IKP20N60T, XMC1000
650 V) IKA08N65ET6, IKA10N65ET6, IKA15N65ET6, IPN/D60R2K0CE, XMC4400-F100
IPN/D60R1K4CE
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 13The right security for connected home appliances:
OPTIGA™ product portfolio
Security level
High Connected device security
Programmable
Authentication
OPTIGA™ Trust X
e.g. secure
communication
OPTIGA™ Trust P to the cloud
e.g. Java for
OPTIGA™ Trust E
applications to be added
e.g. certified
OPTIGA™ Trust B authentication of nodes
e.g. authentication
of nodes
Low Single function Advanced
Feature set
Hardware-based security
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 145th generation CoolSET™ for auxiliary SMPS
Auxiliary SMPS in Flyback topology
to perform AC/DC power conversion
to power the various system blocks
in home appliances.
Broad portfolio Ease of design Robustness
› Choice of fixed- frequency or › Numerous design examples › Integrated 700 V or 800 V
quasi-resonant switching covering both indoor and superjunction MOSFET
scheme outdoor aircon › Comprehensive protection
› Highest power delivery up to › Design tools, guide and features
43 W application note › Auto-restart scheme to
› Available in DIP-7 or SMD › Reference designs minimize interruption
DSO-12 package
More information http://www.infineon.com/CoolSET
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 15iMOTION™ solution platform dedicated to motor & PFC control
Right-fit products and highest functional integration Markets
Hardware integration Motion Control Engine
From controller to full inverter in one package MCE - Ready-2-use motor and PFC control algorithm
Major & small home
appliances
+ Less components + Minimized SW coding/test
Industrial pumps & fans
+ Reduced PCB space + Less certification effort
System cost reduction Time to market Less R&D spending
Motion for building
automation
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 16iMOTION™ reduces significantly time & resource needs in the overall motor & PFC
software development cycle
Requirements
Concept
Easy product selection – no matching between MCU
performance/peripherals and system requirements needed
Conventional SW development flow
Implementation
Drivers/ Algorithm Class B
System System
Module Library/ development product &
adaption test
Demo SW incl. test system
Time
to Testing
Market
Class B
product
iMOTION™ System Class B
products adaption
System test
system Time gain
Certification
Development Start
Production
Major benefits – Significant time to market improvement
› Simplified product selection
› State of the art algorithms – production ready & UL/ClassB pre-certified
› RnD cost savings of ~$180k (Assumption: 12 MM a $15k)
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 17Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 18Infineon solution overview for refrigerator
Refrigerator
100 W 200 W 300 W
TRENCHSTOP™ IGBT6 / RCD2 IGBTs
Inverter
switches
CoolMOS™ PFD7
TRENCHSTOP™ / High Speed 3 IGBT
PFC switches
CoolMOS™ P7
650 V SOI Level shift gate driver ICs
Gate driver ICs
600 V JI Level shift gate driver ICs
IPM CIPOS™ Nano/ Micro / Mini
Microcontrollers iMOTION™/ PSoC® 4/6 / XMC™
Driver for PFC & aux Integrated power stage ‒ CoolSET™
supply Linear voltage and DC/DC switching regulators
M. sensors XENSIV™ Hall Switches and angle sensors
C. sensors XENSIV™ - high-precision coreless current sensors for industrial applications
Security OPTIGA™ Trust product family
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 19Microcontroller portfolio for refrigerators
User Case System Controller UI 2-in-1 Capsense only VF compressor
CY8C4126/S2
Cypress CY8C4025/S1 C: CY8C4146 / P4S2
CY8C4127/S3 CY8C4014/S0
part numbers CY8C4126/S2 C+HPFC: P4MC (NPP)
P4S4 (NPP)
Flash: 48K~128K Flash: 32K~64K
BLDC & PMSM motor,
SRAM: 2K~32K SRAM: 4~8K
Product Capsense: 4-8 SPWM, FOC, 1 Shunt, Full
GPIO: 36~80 GPIO: 25~36
characteristics UART or I2C interface Protection, internal AMP/OPA,
UART: 2~5 UART: 1~3
ADC: 8CH Capsense: 4~8
5V power supply, Good Capsense performance Good Capsense performance 32bit M core,
Key features Support OTA, Enable LCD Ease use turnkey Turn-key solution,
32bit M0 core 5V Power supply 5V Power supply CY AE support
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 20Low power drives offerings by market segments: Low-end
"Best fit" Best fit: Low-end segment
standard
Inverter Topology Package Product
components
TRENCHSTOP™
Three phase DPAK IKD03N60RF
IGBTs
CoolMOS™ Three phase SOT223 IPN60R1K0CE
PFC Topology Package Product
TRENCHSTOP™ IGB15N60H5
Single boost D2PAK
IGBTs IGB10N60T
CoolMOS™ Single boost D2PAK IPB60R280P7
Driver Topology Package Product
1ED44175, 1ED44173,
PFC Driver 1ch low side SOT23
IRS44273
2ch low side DSO-8 IRS4427
Three phase DSO-28 IR2136, 6EDL003
High voltage
Level shift IRS2304, 2ED2304S06F
Half bridge DSO-8
2EDL05x06PF
Controller Product
iMOTION™ Turnkey motor control solution ISSOP-38 IMC101T-T038
PSoC® 4 Standard MCU TQFP48 CY8C4146AZI
XMC™ Standard MCU 16-64 pins XMC1300 (Cortex M0)
Inverter output power
50 W 150 W 300 W
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 21Low power drives offerings by market segments: Mid-range
"Regular" Regular: Mid-range segment
price Inverter Topology Package Product
performance TRENCHSTOP™
Three phase DPAK IKD04N60RF
IGBTs
CoolMOS™ Three phase DPAK IPD65R1k4CFD, IPD65R950CFD
PFC Topology Package Product
TRENCHSTOP™
Single boost D2PAK IGB15N60H5, IGB10N60T
IGBTs
CoolMOS™ Single boost D2PAK IPB60R280P7
Driver Topology Package Product
1ch low side SOT23 1ED44175, 1ED44173, IRS44273
PFC Driver
2ch low side DSO-8 IRS4427
Three phase PG-DSO-28 6ED003L06 / 6EDL04I/N06
High voltage Level shift PG-DSO-8 IRS2304S, 2ED2304S06F, 2EDL05x06
Half bridge
PG-DSO-14 IRS2890DS
CPU Product
Single motor control TSSOP-38 IMC101T-T038
iMOTION™
Motor control +
LQFP-64 IMC102T-F064
PFC
PSoC® 4 Single motor control TQFP48 CY8C4146AZI
XMC1300 (Cortex M0)
XMC™ MCU with PFC 16-64 pins
XMC1400 (Cortex M0)
Inverter output power
50 W 150 W 300 W
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 22Low power drives offerings by market segments: High-end
Premium: High-end segment
Inverter Topology Package Product
TRENCHSTOP™ IGBTs DPAK IKD06N60RF
CoolMOS™ Dpak IPD65R420CFD, IPD65R310CFD
Half bridge CIPOS™ Nano
IPMs w/integrated Driver 3-phase CIPOS™ Micro IGCM04F60yA, IGCM06F60yA, IM513, IM512
"Premium" 2/3-phase CIPOS™ Mini
differentiated PFC Topology Package Product
products TRENCHSTOP™ IGBTs Single boost D2PAK IGB15N60H5, IGB10N60T
LCD display,
CoolMOS™ Single boost D2PAK IPB60R280P7
multiple cooling
segments, Driver Topology Package Product
highest efficiency 1ch low side SOT23 1ED44175, 1ED44173, IRS44273
PFC Driver
2ch low side DSO-8 IRS4427
Three phase PG-DSO-28 6EDL04I06, 6EDL04N06
Selection table 2EDL05I06PF, 2ED2304S06F
focusing on PG-DSO-8 2ED2106/8/9/91S06F series
High voltage Level shift 2ED2181/2/3/4S06F series
system control Half bridge
– IRS2890D
PG-DSO-14 2ED21064/84/94S06J series
Connectivity 2ED21814/24/34/44S06F series
and user CPU Product
interface
Single motor control TSSOP-38 IMC101T-F038
require iMOTION™
separate Motor control + PFC LQFP-64 IMC102T-F064
subsystems PSoC® 4 Single / Dual Motor TQFP48 CY8C4146AZI
FM4 Dual Motor and PFC LQFP or BGA S6E2H14
XMC1300 (Cortex M0)
16-64 pins
XMC™ MCU with PFC XMC1400 (Cortex M0)
48-196 Pins
XMC4000 (Cortex M4F)
Inverter output power
50 W 150 W 300 W
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 23Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 24Infineon solution tree for residential air conditioner
Residential air conditioner
50 W 100 W 300 W 1 HP 2 HP 3 HP 6 HP*
TRENCHSTOP™ TP/H3/AI/H5/WR5
PFC
Discretes CoolMOS™ P7
Rapid, SiC Gen 6
Outdoor Fan RCD2 IGBT
Discretes CoolMOS™ CFD/CE
Driver ICs 1200 V JI and SOI / 650-700 V SOI / 600 V JI and SOI Level shift gate driver ICs
Smart IPM /
Ind. Fan IPM
CIPOS™ Micro/ Nano
Outd. Fan IPM CIPOS™ Micro
Compress. IPM
PFC, inverter,
PFC+inverter CIPOS™ Mini (also w/PFC)
Microcontrollers iMOTION™/ PSoC® 4/ 6 / XMC™
Auxiliary
Integrated power stage ‒ CoolSET™
supply
M. sensors Hall Switches and angle sensors , isolated current sensors
Security OPTIGA™ Trust product family
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 25Microcontroller portfolio for air conditioner
Split type IDU Standing type IDU ODU IDU&ODU
User Case
System Controller System Controller UI with Capsense Capsense only Compressor +System 3-in-1 Fan Control
Compressor:
CY8C4547/S3
Cypress CY8C4126/S2 CY8C4126/S2
CY8C4127/S3 CY8C4014/S0 P6-MC(NPP) CY8C4145/S2
part numbers CY8C4127/S3 CY8C4127/S3
C+HPFC:
P4-MC(NPP)
Flash: 32K~128K Flash: 32K ~ 128K
SPWM, FOC, Fast,
SRAM: 2K~16K SRAM: 2K ~ 16K Position observer,1
Flash: 64K ~ 128K Anti-Wind Start up,
shunt, HF carry wave,
SRAM: 8K~16K Capsense: 4-12 Compressor feature + Fast Reversal
Product characteristics GPIO: 27~55 GPIO: 27~48
GPIO: 27~55 UART or I2C interface
field weaken, torque
Fan feature Self-Adjusting Carry
compensation, over
UART: 1~3 Frequency (Norse)
ADC: 8CH ADC: 8CH modulation
Full Promotion
UART: 2~4 UART: 2~4
Good Capsense Good Capsense 32bit M core,
32bit M core, M4/M0 2 cores
5V power supply, 5V power supply, performance performance Turn-key solution,
Key features 32bit M core 32bit M core Ease use turnkey Ease use turnkey
Turn-key solution, CY AE support
CY AE support
CY AE support
5V Power supply 5V Power supply
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 26Total solutions for air conditioner compressors (PFC + inverter)
Power
PFC DISCRETE
Inverter IPM PFC IPM
Inverter IPM
6HP
Lower integration
Higher flexibility PFC 20~50 A
1.5 – 7HP 20~30 A
More design effort
Single boost, Interleaved
interleaved, 2ph / 3ph
PFC DISCRETE
2HP Inverter IPM
totem pole 3-6 kW
IPM 15~30 A
1 ~ 3 kW
Higher integration
1~1.5 HP (PFC + Inv.) IPM
Inverter IPM 20
A Lower flexibility
PFC 20 A
20 kHz – 60 kHz Less design effort
10~20 A
1-2 kW
BOM cost
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 27Residential air conditioner – outlook for smart solutions
Outdoor unit Compressor Outdoor fan
› Main MCU: PSoC® 6/ PSoC® 4/ XMC™ series › Inverter: IPM/CIPOS™ Micro
› Inverter: IPM/ CIPOS™ Mini
› PFC: IGBT/ H5 series, Diode/ Rapid diodes, Gate
IC/1ED44176, IRS44273, IPM/ CIPOS™ Mini
› Precise and quick cooling: Pressure & temperature Indoor fan
sensor combo/ DPS422
› SMPS: CoolSET/ 5QR series › Inverter: IPM/Smart IPM
› Inverter: IPM/CIPOS™ Nano, Micro
Indoor unit HMI & connectivity Human detection
› System host and HMI: PSoC® 6
› People presence detection, counting,
› Bluetooth / WiFi connectivity tracking: Radar sensor / BTG24xTRxx
› Voice assistant: MEMS microphone › Algorithm / IP protection: OPTIGA™ Trust B
› Secured comm / firmware update: OPTIGA™ Trust X
HEPA filter Gas sensor
› Authentication of filter / › CO2 sensor: PAS CO2 sensor / real PAS
accessories: CO2 sensor module – XMC™, MOSFET,
OPTIGA™ Trust B/X PAS sensor
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 28Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 29Infineon solution overview for washing machine
Washing machine
600 W 1000 W 1.5 kW
TRENCHSTOP™ IGBT / RCD2 IGBT /
Switches
IGBT 3 / IGBT6
650 V SOI Level shift gate driver ICs
Gate driver ICs
600 V JI Level shift gate driver ICs
IPM Drum: CIPOS™ Tiny, Mini; Pump: CIPOS™ Micro, Nano
Microcontrollers iMOTION™/ PSoC® 4/ 6/ XMC™
Auxiliary supply Integrated power stage ‒ CoolSET™
M. sensors Hall Switches and angle sensors
Security OPTIGA™ Trust product family
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 30Microcontroller portfolio for washing machines
Front loading Top loading
User Case Motor Control
System Control
System Controller UI 2-in-1 Drive Controller
wi/wo Capsense
CY8C4127/S3 CY8C4025/S1 CY8C4126/S2
Part numbers P4S4(NPP) CY8C4126/S2 CY8C4127/S3
CY8C4126/S2 CY8C4146/S3
Flash: 32K ~ 128K
BLDC motor,
Flash: 128K ~ 256K Flash: 32K ~ 64K SRAM: 4K~32K Flash: 16K ~ 32K
SPWM, FOC, OOB, electronics
SRAM: 16K~32K SRAM: 4K~8K GPIO: 27~55 SRAM: 1K~2K
Product weight
GPIO: 27~55 UART: 1~2 UART: 2~4 GPIO: 12~27
characteristics Motor identification and auto-
UART: 2~4 Capsense: 8~20 ADC: 8CH UART: 1~2
tuning, multi-mode startup
ADC: 8CH Support slides & wheels Capsense: 8~30 ADC: 8 CH
Support slides & wheels
32bit M core,
Good capsense performance Good Capsense performance Turn-key solution,
5V power supply, 5V power supply,
Key features 32bit M core
Ease use turnkey Ease use turnkey
32bit M core
CY AE support,
5V Power supply 5V Power supply Lead tech for the sensorless
inverter
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 31Washing machine drive (600 W – 1.5 kW)
Inverter Topology Package Product
DPAK IKD10N60R, IKD15N60R, IKD10N60RF, IKD15N60RF
Switch
Discrete IGBTs + D2PAK IKB10N60T, IKB15N60T, IKB20N60T
Anti-parallel Diode
TO220 IKP10N60T, IKP15N60T, IKP20N60T
IPMs with integrated driver Three phase Mini IKCM10/15H
Driver Topology Package Product
Three phase PG-DSO-28 6EDL04I06PT, 6EDL04N06PT
2EDL05I06PF 2ED2304S06F
PG-DSO-8 2ED2106/8/9/91S06F series
SOI 2ED2181/2/3/4S06F series
Half bridge
2EDL05I06PJ; 2EDL23x06PJ
PG-DSO-14 2ED21064/84/94S06J series
2ED21814/24/34/44S06J series
Three phase DSO-28 IR2136S, IR2133S
Junction
isolated
Half bridge DSO-14 IRS2890DS
CPU Product
iMOTION™ LQFP-64 IMC101T, IMC102T
XMC™ PG-LQFP-100 XMC4400-F100
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 32Trend in washing machine applications:
Improving energy efficiency and water consumption
Strong focus on the washing program – process control is enabled by inverterized motors
› Reduce size while › Multitude of optimized › Easy remote control and
maximizing drum volume washing programs information about the status
› Multiple drums › High energy efficiency › Remote monitoring and
motors (BLDC) maintenance
› Washing and drying
› Low noise for washing e.g. at › Software updates
night
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 33Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 34Infineon solution overview for Fans and Pumps
Fans and pumps
100 W 200 W 300 W
TRENCHSTOP™ IGBT6 / RCD2 IGBT
Switches
CoolMOS™ PFD7
650 V SOI Level shift gate driver ICs
Gate driver ICs
600 V JI Level shift gate driver ICs
IPM Drum: CIPOS™ Tiny, Mini; Pump: CIPOS™ Micro, Nano
Microcontrollers iMOTION™/ PSoC® 4/ 6 / XMC™
Integrated power stage ‒ CoolSET™
Driver & PFC supply
Linear voltage and DC/DC switching regulators
M. sensors XENSIV™ Hall Switches and angle sensors
Security OPTIGA™ Trust product family
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 35Microcontroller portfolio for Fans and Pumps
User Case 100 W - 400 W Circulation pump Small pump Fan
CY8C4025/S1 CY8C4014/S0 CY8C4025/S1
CY8C4014/S0
Part numbers CY8C4126/S2 CY8C4025/S1 CY8C4126/S2
CY8C4147/S3
CY8C4126/S2 CY8C4127/S3
Flash: 32K~64K Flash: 16K ~ 64K
Flash: 16K, 128K
SRAM: 4K~8 SRAM: 2K~8K Flash: 32K ~ 128K
SRAM: 2K, 16K
UART: 2~4 UART: 1~3 SRAM: 4K~32K
Product characteristics GPIO: 12~55
Capsense: 6~12 Capsense: 4~8 UART: 2
UART: 1~4
Support slides ADC: 4 Capsense: 4~6
Capsense: 4~8
ADC: 3
Good capsense performance
Good capsense performance Good Capsense performance Good Capsense performance,
Ease use turnkey
Ease use turnkey Ease use turnkey Support OTA,
Key features Support OTA,
Enable LCD Support OTA, 5V power supply,
5V power supply,
5V Power supply 5V Power supply 32bit M core
32bit M core
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 36Fans & pumps – product selection tree
Regular: Mid-range segment
Inverter Topology Package Product
DPAK IKDxxN60R, IKDxxN60RF
Discrete IGBTs Three phase
TO-220FP IKAxxN65ET6
CIPOS™ Nano
Half bridge
IPMs with integrated driver CIPOS™ Micro IRSM83x, IM231, IM393
3-phase
CIPOS™ Tiny
Driver Topology Package Product
Three phase PG-DSO-28 6EDL04I06 / 6EDL04N06
2ED2304S06F, 2EDL05I06PF
PG-DSO-8 2ED2106/8/9/91S06F series
High voltage 2ED2181/2/3/4S06F series
level shift
Half bridge
IRS2890DS
2EDL05I06PJ, 2EDL23I06
PG-DSO-14
2ED21064/84/94S06J series
2ED21814/24/34/44S06J
Controller Functionality Package Product
Single motor control TSSOP-38 IMC101T-T038
iMOTION™ Motor control + PFC LQFP-64 IMC102T-F064
Smart IPM PQFN IMM101T, IMM100A
XMC1300 (Cortex M0)
XMC™ Standard MCU 16-64 pins
XMC1400 (Cortex M0)
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 37Agenda
1 What‘s driving the major home appliance market?
2 Solutions for major home appliances
3 Refrigerators compressor and PFC
4 Residential air conditioner
5 Washing machines
6 Fans and pumps
7 Summary
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 38Conclusion and take-aways
Infineon has the most comprehensive portfolio among
competitors: One-stop-shop.
Infineon offers energy efficient solutions, with different levels of
integration to meet any customer needs.
We can offer a competitive and complete system solution for
traditional and new consumer drive applications.
Smart functionality is offered beyond energy efficiency.
Add hardware-based security already at product design and
benefit from Infineon's support for an easy and fast integration.
We are working together with our customers to grow into
the future!
2020-07-01 Copyright © Infineon Technologies AG 2020. All rights reserved. 39You can also read
