Technical data / Season 2020
Compact Plus DL
www.adria-mobil.com / 13.03.2020 08:18
Technical data / Season 2020
Compact Plus DL
CHASSIS
Emissions rating Euro 6D
Fiat 6D 2,3 120HP 35L X
Fiat 6D 2,3 140HP 35L O
Fiat 6D 2,3 160HP 35L O
DIMENSIONS AND WEIGHTS
Body length (mm) 6990
Total width (mm) 2120
Total height (mm) 2750
Internal height (mm) 1980
Mass in running order (MRO, kg) 2746
Maximum authorized weight (kg) 3500
Maximum towing weight (kg) 2000
Maximum loading weight (kg) 754
Wheel base (mm) 3800
Nr. of homologated seats incl. driver's seat 4
CHASSIS EQUIPMENT
Chassis type special
Corner legs O
Tyre pressure monitoring system FIAT O
Wheel trims- bigger X
FBC&LDWS & HBR &TSR(Full br.con.+line dep. war. sys.+sign and high beam recog.+ traffic sighn recog) O
Lux packet LP1 (inc. LM1,7QP,ADL,6BL) O
ABS + EBD X
Automatic gear box FIAT - AT9 O
Fix&Go Kit (instead of spare wheel) Fiat X
WHITE 249 X
IRON GREY METALIC 691 O
SILVER ALU METALIC 611 O
Metalic colour FIAT O
Colored front bumpers white X
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
Colored shock bumper silver metalic X
Colored shock bumper iron grey metalic 691 X
Colour packet SILVER colour 611 O
Colour packet IRON GREY colour 691 O
Front grille with gloss black paint + black bezel headlamp O
Front fog lights O
Rear fog lights X
Double electric door mirror with demist function O
LED daytime running lights FIAT O
DRL- halogen day time running lights X
Rear main position light LED X
RHD front headlights for LHD models (Japan only) O
Reinforced "camping car" tires X
Front drive X
Fuel tank (l) 75
Ad Blue tank (L) 19
Manual transmission X
Traction + system with HDC O
ESP X
Cruise control with speed limiter FIAT O
Towing hook with el. conn. O
Bicycle carrier preinstalation Fiamma O
Steel wheels 16''(light 35 L version only) O
Alloy wheels 16'' for "L'' version FIAT O
Mud protection for front wheels FIAT O
Mud protection for rear wheels O
CABIN EQUIPMENT
Manual air condition FIAT O
Automatic air condition O
Intergrated DAB car radio high-level CD, MP3 steering wheel controls and navigation FIAT O
Radio controls on steering wheel without car radio FIAT O
Leather steering wheel and gear box knob O
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
Lock "DEAD LOCKING" O
FIAT comf pack CP0 (radio preinst. with laudspeakers,antena int. in mirrors,cover for seats pedest) O
FIAT comfort package CP1 (include 7KM, CJ1, NHR, 4GF) O
FIAT comfort package CP2 (include 140, 041, CJ1, NHR, 4GF) O
Electrical cabine windows (left, right) X
Electric folding wing mirrors O
Cabin seats adjustable in height and deepness X
Cabin seats upholstered in Adria textile/leather X
Front seats Captain chair with double armrest upholstered in Adria textile X
Swiveling cabin seats X
Dasboard Techno trim level aluminium finishing FIAT O
Trip computer X
Driver airbag X
Co-driver airbag O
Driver and codriver sun-visors X
Central cup holder O
Darker cabine windows X
Windscreen obscuration with plise X
Windscreen obscuration for LDW&HBR SEITZ O
Side cabin windows obscuration with plise O
Side windows cabin obscuration with curtain X
BODY
Side wall of polyester white
Bodywork of polyester white
Side wall skirtings in aluminium X
Luggage door on right side (light dimensions, cm) 80x105
Luggage door on left side (light dimensions, cm) 80x105
Body construction COMPREX X
Entrance door 1-part without window X
Entrance door with window, mosquito net, dustbin, central locking, width 500 mm O
Flyscreen for entrance door without window O
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
Windows Seitz S4 with frame and built-in blackout roller blinds and fly screens X
Roof light 700 x 500 mm in bedroom X
Roof light 280 x 280 in toilet X
Panoramic window Polyplastic with lining on the cap X
Gas bottle compartment, integrated 1x 11 kg X
Gas bottle compartment, integrated 2x 11 kg O
Awning O
Entrance step with insulation and light X
Reverse driving sensor X
Poliester outside floor protection X
Third break light X
INTERIOR EQUIPMENT
Number of berths 3+1
Sleeping area, rear berths (l x w, cm) 195x75-65;157x42;193x82
Front dinette (cm) 190x90-80
Third bed at the rear X
Additional seat with seat belt at zofa X
Bed with slatted frame and special foam X
Bed with slatted frame and spring mattress O
Holder at entrance X
Kitchen window lining with LED lightening X
Furniture decor SANDY WHITE
Cupboards doors- colour WHITE
Textile standard MT02L2 PAOL
Textile optional MT02L3 SEVERE
Textile optional MT02H8 ZANNA
Textile optional MT02L5 GAEL
Textile optional MT02K5 NATHAN
Textile optional MT02G2 LEATHER EDVARD
Textile optional MT02L1 LEATHER MATHISSE
Textile optional MT02M7 LEATHER NUBUCK
Cushions SOPHISTICATED CLASSIC O
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
Cushions VIOLET CHICK O
Cushions OCEAN SERENITY O
Cuushions AUTUMN CALMNESS O
Cushions SPRING GARDE O
Cushions CHERRY PUNCH O
Dinette cushions formed - special foam 120 mm X
Decorative cushions 4 pcs. X
Bed coverlet O
Blanket O
Carpets in the living compartment O
Carpets in the cabin O
KITCHEN EQUIPMENT
3-flame gas cooker with electric ignition, glass cover and stainless steel sink X
Sink cover/chopping board X
Drainer O
Extractor fan X
Refrigerator with compressor 90 L
Refrigerator with compressor 152 L O
Oven and grill combination Duplex, electric ignition O
BATHROOM EQUIPMENT
WC chemical, turnable, passive ventilated X
Shower tray X
Swiveling shower wall X
Separate shower faucet X
WATER INSTALLATIONS
Fresh water tank with external inlet and regulation (l) 140
Waste water tank isolated with adjustable heating 85 L / van 70 L X
Waste water omission tube O
Pressure water pump X
ELECTRICITY
Auxiliary batery 100Ah, AGM; k=10 O
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
DC/DC converter O
Power sockets 230 V X
12V socket X
USB power socket in living room and bedroom X
12V and 230V socket in garage X
Main security swich for 230V X
Main electric switch 12V X
Ceiling LED lights X
Spot LED lights X
Ambient LED lights X
Light in wardrobe X
Light in luggage compartment X
Awning LED light X
Electro block X
Preinstallation for satelite dish X
Preinstallation for solar pannels X
Place for the additional battery X
Control panel X
Fire extinguisher O
HEATING/AIR CONDITIONING
Gas heater Truma Combi 4 with boiler X
Gas heater Truma Combi 6 with boiler O
Gas-electric heater Truma Combi 4E with boiler O
Gas-electric heater Truma Combi 6E with boiler O
Digital control panel Truma X
Luggage box - heated X
Electrical floor heating with transformer O
Preinstallation for air condition X
Roof-mounted air conditioning system Truma Aventa Comfort 2400 O
GAS
Gas filter Truma O
Gas regulator Truma MonoControl CS 30 mbar GV X
www.adria-mobil.com / 13.03.2020 08:18Technical data / Season 2020
Compact Plus DL
AUDIO/VIDEO
Preinstallation for TV (230V, 2x 12V, antenna socket) X
Reverse driving camera O
Preinstallations for reverse driving camera X
Alarm device O
TV holder O
TV cupboard / place for TV X
Set ORCA PRO 360 with monitor (4 cameras and 7" monitor) O
