HAGOR Products GmbH has been developing and produ-
cing high-quality mounting systems for media and pre-
sentation equipment since 1996 already.
The solid basis of our range is a combination of our own
product lines - Made in Europe -, customized special so-
lutions and selected commercial articles which we are
constantly optimizing.
With Sascha Hahndorf, the next generation already suc-
ceeds into the management and provides for valuable in-
novation incentives with his sustainable approaches and
fresh perspectives. So, HAGOR is fit for the future!
Horst Hahndorf Sascha Hahndorf
We look forward to co-operations based on partnership Managing director Managing director
and would like to invite you to visit our state-of-the-art
production and logistics centre in Bad Oeynhausen.
FAIR | FLEXIBLE | VERSATILE | PROFESSIONAL
2
Table of Contents
CON-Line® Media Furniture 4-7 Video Wall Trolleys 46
HATURA® Stand Systems, Wood Appearance 8 VWS Cube 47 - 49
Stand Systems, counterbalanced 9 Bracled-3D-Frame, LED mounting systems 50
Stand Systems, motorized 10 - 13 ScreenOut® Outdoor Totems 51
Stand Systems, Info Tower Series 14 - 15 ScreenOut® Outdoor Enclosures 52
Stand Systems 16 - 22 ScreenOut® Industrial Protective Enclosures 53
Wall Mounts, fixed 23 - 24 Fire Protection Enclosures 54
Wall Mounts, tiltable 25 - 26 Fire Protection Totems 55
Wall Mounts, fully moveable 27 - 29 vis-it, Indoor totems 56 - 58
Wall Mounts, rotatable 30 Indoor Enclosures 59
Wall Mounts with PC compartment 31 Projector Mounts 60 - 62
Wall Mounts, height-adjustable 32 Tablet Protective Enclosures 63
Mounting Systems, depending on display 33 - 36 References 64
Special Mounts 37
Ceiling Mounts 38 - 39
Adapters & Accessories 40
Table Stands 41
Video Wall Mounts 42 - 45
3
Media Furniture
CON-Line® ST1
Media furniture
- electromotive height-adjustment
- cable routeing via cable drag chain
- collision prevention
- integrated plugbar with safety switch
- push-button for mounting
under the screen, for instance
- mobile thanks to robust castors
(2x with lockable brake)
- manoeuvrable through room doors
- height: 1185 min. to 1685 mm max. (centre of screen)
- circumferential edge protection
- doors and drawers with softclosing dampers
- decor customizable on request
500 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1897 CON-Line ST1 55 - 86“ | 140 - 218 cm VESA 800 x 600 mm 140 kg
4 Visit www.hagor.de for detailed information
Media Furniture
CON-Line® T2
Media furniture
- screen height can be selected in
detents (tool needed)
- height: 1250 min. to 1600 mm max.
(centre of screen)
- internal cable routeing
- mobile thanks to robust castors
(2x with lockable brake)
- manoeuvrable through room doors
- circumferential edge protection
- doors and drawers with softclosing dampers
- removable tower cover
- optionally extendable to VESA 900 x 600 mm
- decor customizable on request
Exemplary installation with Room Kit Adapter
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1952 CON-Line T2 55 - 86“ | 140 - 218 cm VESA 600 x 400 mm 100 kg
CON-Line® T2-Dual-Serie
Media furniture
- for 2 screens „side-by-side“
- screen height can be selected in
detents (tool needed)
- height: 1250 min. to 1600 mm max.
(centre of screen)
- internal cable routeing
- mobile thanks to robust castors
(2x with lockable brake)
- manoeuvrable through room doors
- circumferential edge protection
- doors and drawers with softclosing dampers
- removable tower cover
- optionally extendable to VESA 900 x 600 mm
- decor customizable on request
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1953 CON-Line T2-Dual 2x 46 - 55“ | 116 - 140 cm VESA 600 x 400 mm 100 kg (2x 50 kg)
2102 CON-Line T2-Dual XL 2x 65“ | 165 cm VESA 600 x 400 mm 100 kg (2x 50 kg)
Visit www.hagor.de for detailed information 5
Media Furniture
CON-Line® T1
Media furniture
- screen height can be selected in detents (tool needed)
- height: 1250 min. to 1600 mm max. (centre of screen)
- internal cable routeing
- mobile thanks to robust castors with lockable break
- manoeuvrable through room doors
- circumferential edge protection
- doors and drawers on the right side with softclosing dampers
- removable tower cover
- optionally extendable to VESA 900 x 600 mm
- decor customizable on request
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1954 CON-Line T1 55 - 75“ | 140 - 191 cm VESA 600 x 400 mm 80 kg
CON-Line® T1-Dual
Media furniture
- for 2 screens „side-by-side“
- screen height can be selected in detents (tool needed)
- height: 1250 min. to 1600 mm max. (centre of screen)
- internal cable routeing
- mobile thanks to robust castors with lockable break
- manoeuvrable through room doors
- circumferential edge protection
- doors and drawers on the right side with softclosing dampers
- removable tower cover
- decor customizable on request
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1956 CON-Line T1-Dual 2x 46 - 55“ | 116 - 140 cm VESA 600 x 400 mm 80 kg (2x 40 kg)
CON-Line® W1
Media furniture
- for wall installation
- screen height can be selected in
detents (tool needed)
- internal cable routeing
- doors and drawers on the right side
with softclosing dampers
- removable tower cover
- optionally extendable to VESA 900 x 600 mm
- decor customizable on request
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1955 CON-Line W1 55 - 75“ | 140 - 191 cm VESA 600 x 400 mm 60 kg
6 Visit www.hagor.de for detailed information
Media Furniture
CON-Line® KA-1 LS-1 Plus XL
Camera shelf available as an option Sound bar mounting fixture
- usable with media furniture - adaptation for sound bar
of CON-Line series (T1, T2 and W1) - adaptation on any
- with universal oblong hole VESA universal holder
to lock the camera in position - maximum load: 10 kg
- continuously height adjustable - width individually adjustable
(tool needed)
- can be mounted above
and beneath the screen Exemplary installation
- maximum load: 10 kg
Item recommended Item recommended
Item name Size Colour Item name Load (max.) Colour
no.: screen size no.: screen size
1374 CON-Line KA-1 up to 75“ | 191 cm max. B 324 x D 250 mm 7781 LS-1 Plus XL 65 - 86“ | 165 - 218 cm 10 kg
Cisco Room Kit Adapter CON-Line® ST1 KA L / XL
Universal adapter Camera shelf available as an option
- suitable for: Codec in case of Plus version - can be used with media furniture
- Cisco Webex Room Kit Mini CON-Line ST1
- Cisco Webex Room Kit - various hole patterns
- Cisco Webex Room Kit Plus to fix a camera
- continuously height adjustable - height adjustable via oblong hole
- powder-coated - retaining straps
- can be mounted above and - maximum load: 10 kg
beneath the screen
Exemplary
Cisco Room Kit Adapter Dual
Item recommended Item
Item name VESA (max.) Colour Item name recommended screen size Colour
no.: screen size no.:
1925 Room Kit Adapter 55 - 75“ | 140 - 191 cm VESA 800 mm 2108 CON-Line ST1-KA L 55 - 75“ | 140 - 191 cm
2115 Room Kit Adapter Dual 2x 55 - 75“ | 140 - 191 cm VESA 800 mm 2114 CON-Line ST1-KA XL 75 -84“ | 191 - 213 cm
Visit www.hagor.de for detailed information 7
Stand Systems, Wood Appearance
HATURA® Elia 115 HATURA® Elia 115
Free-standing stand system Free-standing stand system
- column height: 1150 mm - column height: 1150 mm
- foot: W 850 x D 440 mm - foot: W 850 x D 440 mm
- internal cable routeing - internal cable routeing
- TV holding fixture ±8° rotatable - TV holding fixture ±8° rotatable
- high-quality nut-tree - high-quality wild oak
appearance appearance
recommended recommended
Item no.: Item name VESA (max.) Load (max.) Item no.: Item name VESA (max.) Load (max.)
screen size screen size
1772 HATURA Elia 115 32 - 55“ | 81 - 140 cm 600 x 400 mm 40 kg 1771 HATURA Elia 115 32 - 55“ | 81 - 140 cm 600 x 400 mm 40 kg
HATURA® Elia 160 HATURA® Elia 160
Free-standing stand system Free-standing stand system
- column height: 1650 mm - column height: 1650 mm
- foot: W 1150 x D 640 mm - foot: W 1150 x D 640 mm
- internal cable routeing - internal cable routeing
- TV holding fixture ±8° rotatable - TV holding fixture ±8° rotatable
- high-quality nut-tree - high-quality wild oak
appearance appearance
recommended recommended
Item no.: Item name VESA (max.) Load (max.) Item no.: Item name VESA (max.) Load (max.)
screen size screen size
1770 HATURA Elia 160 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1769 HATURA Elia 160 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg
HATURA® Stainless steel base cover HATURA® AV shelf
Optional accessory: stainless steel cover Optional accessory: AV shelf
- height individually selectable
along column (tool needed)
- floor space required:
W 320 x D 220 mm
- powder-coated
Item no.: Item name Size
1762 Abdeckung für HATURA Elia 115 B 850 x D 440 mm Item no.: Item name Size VESA (max.) Load (max.)
1761 Abdeckung für HATURA Elia 160 B 1150 x D 640 mm 1800 HATURA AV-Ablage B 320 x D 220 mm 600 x 400 mm 10 kg
8 Visit www.hagor.de for detailed information
Stand Systems, counterbalanced
M Counterbalanced Trolley
Mobile stand system with height adjustment
- installation in landscape format
- manual height-adjustment thanks to adjustable
to device weight mechanism
- very smooth adjustability
- 400 mm travel way
- screen stays safely in desired height
- lock-type smooth-running castors
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
9740 M Counterbalanced Trolley 55 - 75“ | 140 - 191 cm VESA 800 x 700 mm 35 - 60 kg
M Counterbalanced Trolley HD
Mobile stand system with height adjustment
- installation in landscape format
- manual height-adjustment thanks to adjustable
to device weight mechanism
- very smooth adjustability
- 500 mm travel way
- screen stays safely in desired height
- lock-type smooth-running castors
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
9741 M Counterbalanced Trolley HD 75 - 100“ | 191 - 254 cm VESA 900 x 800 mm 60 - 90 kg
Visit www.hagor.de for detailed information 9
Stand Systems, motorized
Mobile Lift Pro Light Black & White
Mobile, height-adjustable lift system for XXL screens
- electromotive height adjustment
- height adjustable from
968 min to 1618 mm max. (centre of screen)
- cable management via cable drag chain
- wired remote control
- castors with lock-type brake (TENTE)
- incl. lockable media cabinet, height adjustable
camera holder and laptop shelf (on the back)
- inside dimensions of the media cabinet:
H 459 x W 393 x D 163 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
7696 Mobile Lift Pro Light Black 42 - 100“ | 107 - 254 cm VESA 800 x 400 mm 120 kg
7697 Mobile Lift Pro Light White 42 - 100“ | 107 - 254 cm VESA 800 x 400 mm 120 kg
Lift Pro Light Dual Adapter
VESA universal holder for 2 screens „side-by-side“
- usable with Mobile Lift Pro Light and Wall Lift Pro Light II
- 2x 40 - 65“ | 102 - 165 cm
- VESA 200 x 200 mm, VESA 600 x 400 mm max. Item no.:
- maximum load: 50 kg 7793
10 Visit www.hagor.de for detailed informationStand Systems, motorized
Wall Lift Pro Light I
Height-adjustable lift system
- floor-to-wall mounting
- electromotive height adjustment
- height adjustable from
995 mm min. to 1645 mm max. (centre of screen)
- wired remote control
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
7790 Wall Lift Pro Light I Black 42 - 55“ | 107 - 140 cm VESA 400 x 400 mm 60 kg
7800 Wall Lift Pro Light I White 42 - 55“ | 107 - 140 cm VESA 400 x 400 mm 60 kg
Wall Lift Pro Light II
Height adjustable lift system for XXL screens
- floor-to-wall mounting
- electromotive height adjustment
- height adjustable from
995 mm min. to 1645 mm max. (centre of screen)
- cable management via cable drag chain
- wired remote control
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
7791 Wall Lift Pro Light II Black 42 - 86“ | 107 - 254 cm VESA 600 x 400 mm 120 kg
7801 Wall Lift Pro Light II White 42 - 86“ | 107 - 254 cm VESA 600 x 400 mm 120 kg
Mobile Lift Pro Flip L/P
Mobile, height adjustable lift system with
rotatable holder, especially for XXL screens
- rotatable in landscape or portrait format (no tools needed)
- electromotive height adjustment
- height adjustable from 1120 mm min. to 1620 mm max.
- wired remote control
- 4 heavy-duty castors, 2 of them with lock-type brake
- cable management by cable clips on the back
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1831 Mobile Lift Pro Flip L/P 42 - 86“ | 107 - 218 cm VESA 800 x 600 mm 125 kg
Visit www.hagor.de for detailed information 11Stand Systems, motorized
Lift Pro Series
Height adjustable lift systems for XXL screens
- electromotive height adjustment
- wired touch control
- cable management by cable clips on the back
- lots of accessories available as add-ons
Wall Lift Pro
Mobile Lift Pro II Floorbase Lift Pro
Item no.: Item name Description recommended screen size VESA (max.) Load (max.) adjustable height (centre of screen) Colour
7550 Mobile Lift Pro II mobile, height adjustable lift system 42 - 100“ | 107 - 254 cm 800 x 600 mm 150 kg 1120 min. - 1620 mm max.
7551 Floorbase Lift Pro free-standing, height-adjustable lift system 42 - 100“ | 107 - 254 cm 800 x 600 mm 150 kg 1190 min. - 1690 mm max.
7552 Wall Lift Pro height-adjustable wall lift system 42 - 100“ | 107 - 254 cm 800 x 600 mm 150 kg 1190 min. - 1690 mm max.
Mobile Lift Pro Matrix
Height adjustable lift system for a 2 x 2 video wall
- electromotive height adjustment
- travel way of lift: 700 mm
- wired touch control
- fine-adjustment of screens via adjusting screws
on the VESA holder (height, depth, width)
- cable management via cable drag chain
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
2104 Mobile Lift Pro Matrix 46 - 55“ | 117 - 140 cm 600 x 400 mm 25 kg per screen
12 Visit www.hagor.de for detailed informationStand Systems, motorized
Touch Lift Pro Lift Pro - Cisco Webex Adapter
Mobile stand system with electrical Special adapters available as an option
height and tilt angle adjustment
- can be used with lift systems
- electromotive tilt angle
of the Lift Pro series
adjustment 0 - 90°
(except Touch Lift Pro and
- height adjustable from 886 mm Mobile Lift Pro Flip LP)
min. to 1386 mm max.
- special hole pattern for
(centre of screen)
Cisco Webex Board series
- wired touch control
- rubberized smooth-running
castors 2 of them with lock-type
brake
Item no.: Item name VESA Colour
Item recommended VESA Load 7560 Adapter for Cisco Webex Board 55“ 1114 x 645 mm
Item name Colour
no.: screen size (max.) (max.)
7558 Touch Lift Pro 42 - 86“ | 107 - 218 cm 800 x 600 mm 150 kg 7561 Adapter for Cisco Webex Board 70“ 1455 x 862 mm
Lift Pro - Frontshelf Lift Pro - Sideshelf
AV shelf available as an option AV shelf available as an option
- can be used with lift systems of the Lift Pro series, except Touch Lift Pro - can be used with lift systems of the Lift Pro series
- shelf for AV equipment - shelf for AV equipment
- variable in height (tool needed) - variable in height (tool needed)
Exemplary installation Exemplary installation
Item no.: Item name Size Load (max.) Colour Item no.: Item name Size Load (max.) Colour
7553 Lift Pro - Frontshelf W 428 x D 258 mm 5 kg 7554 Lift Pro - Sideshelf W 250 x D 100 mm 5 kg
Lift Pro - Camera Holder L / XL Lift Pro - PC Holder
Camera shelf available as an option PC holder available as an option
- can be used with lift systems of the - can be used with lift systems of the Lift Pro series
Lift Pro series (except Touch Lift (except Touch Lift Pro and Mobile Lift Pro Flip LP)
Pro and Mobile Lift Pro Flip LP) - holding fixture for a mini PC
- various hole patterns to fix a camera - for mounting behind the screen holder
- height-adjustable
- retaining straps
- maximum load: 10 kg
Item no.: Item name recommended screen size Colour Exemplary installation
2103 Lift Pro - Camera Holder L 55 - 75“ | 140 - 191 cm Item no.: Item name Size Load (max.) Colour
7555 Lift Pro - Camera Holder XL 75 -84“ | 191 - 213 cm 7556 Lift Pro - PC Holder W 220 x D 80 mm 5 kg
Visit www.hagor.de for detailed information 13LUM
L OUTDO A
Stand Systems, Info Tower Series
A
FUL
OR
26,98
2
Info Tower Series RO
LLABL -AS
PRE
Mobile stand system
E
- screen height selectable in detents
in 50-mm steps (tool needed)
- internal cable routeing
- invisibly mounted set of castors
- removable tower cover
- installation in portrait or landscape format
possible (depending on screen)
Info Tower Dual L Info Tower Single L
Item no.: Item name recommended screen size VESA (max.) Load (max.) Floor space required Height Colour
1522 Info Tower Single 32 - 55“ | 81 - 140 cm 400 x 400 mm 80 kg B 700 x D 500 mm 900 - 1200 mm
1566 Info Tower Single L 46 - 84“ | 116 - 213 cm 800 x 600 mm 100 kg B 1000 x D 700 mm 450 - 1830 mm
1523 Info Tower Dual 2x 40 - 55“ | 102 - 140 cm 600 x 400 mm 2x 35 kg B 1000 x D 700 mm 900 - 1200 mm
1572 Info Tower Dual L 2x 40 - 55“ | 102 - 140 cm 600 x 400 mm 2x 35 kg B 1000 x D 700 mm 450 - 1830 mm
1822 Info Tower Dual XL 2x 55 - 65“ | 140 - 165 cm 600 x 400 mm 2x 40 kg B 1000 x D 700 mm 450 - 1830 mm
Info Tower CL Info Tower Wall
Mobile stand system Stand system for floor-to-wall installation
- screen height selectable in detents - screen height selectable in detents
in 50-mm steps (tool needed) in 50-mm steps (tool needed)
- internal cable routeing - internal cable routeing
- invisibly mounted set of castors - removable tower cover
- removable tower cover - installation in portrait or
- incl. lockable cabinet landscape format possible
- installation in portrait or - incl. wall mounting adapter
landscape format possible - maximum load: 80 kg
- maximum load: 60 kg
Item no.: Item name recommended screen size VESA (max.) Colour Item no.: Item name recommended screen size VESA (max.) Colour
1578 Info Tower CL 32 - 65“ | 81 - 165 cm 800 x 600 mm / 1801 Info Tower Wall 46 - 84“ | 116 - 213 cm 800 x 600 mm
14 Visit www.hagor.de for detailed informationStand Systems, Info Tower Series
Info Tower Mediabox Info Tower Codec Shelf Series
Media box available as an option Codec shelf available as an option
- can be used with stand - can be used with stand
systems of the Info Tower systems of the Info Tower series
series (as from L) - holder for common
- height adjustable codecs or mini PCs
(tool needed)
- incl. magnetic lock
- maximum load: 7.5 kg
Item Item name Size (inside) Load (max.) Colour
no.:
Item no.: Item name Size Colour
1524 Info Tower Codec Shelf W 320 x H 200 x D 35 mm 2,5 kg
outside: W 565 x H 190 x D 290 mm
1795 Info Tower Mediabox / 1624 Info Tower Codec Shelf L W 320 x H 200 x D 130 mm 2,5 kg
inside: W 525 x H 155 x D 250 mm
Info Tower / Elia SB Glass Shelf Info Tower WH series
Glass shelf available as an option Tiltable TV holder available as an option
- can be used with stand - can be used with stand
systems of the Info Tower systems of the Info Tower
series (as from L) and of series
the Elia SB series
- height-adjustable
(tool needed)
Item recommended
Item name VESA (max.) Load (max.) Colour
no.: screen size
Item Item name Size Load (max.) Colour 1792 WH 50 T - HD 32 - 55“ | 81 - 140 cm 400 x 400 mm 125 kg
no.:
2406 Info Tower / Elia SB Glass Shelf W 500 x D 300 mm 15 kg 1793 WH 85 T - HD 55 - 110“ | 140 - 280 cm 800 x 600 mm 125 kg
Info Tower KA-1 Info Tower Mounting Adapter with Plugbar
Camera shelf available as an option Mounting adapter available as an option
- can be used with stand - can be used with stand
systems of the Info Tower systems of the Info Tower
series series
- with universal oblong hole - can be hooked in on the
to fix the camera in position rear side of the InfoTower
- continuously height - height-adjustable
adjustable (tool needed) (tool needed)
- can be mounted above and - incl. 4-fold plugbar
beneath the screen with safety switch
- up to 75“ | 165 cm max. - plugbar with 180 cm
supply cable
Item Item name Size Load (max.) Colour Item no.: Item name Size Colour
no.:
1316 Info Tower KA-1 W 324 x D 250 mm 10 kg 1821 Info Tower mounting adapter W 270 x H 150 mm
Visit www.hagor.de for detailed information 15Stand Systems
BrackIT® Stand Single BrackIT® Stand 80
Mobile stand system Mobile stand system
- -5 to +15° continuously tiltable - screen holder
and by 90° rotatable 0 - 90° tiltable
- TV holding fixture, height-adjustable - multiple switched socket-
along the column (tool needed) outlet on rear side
- portrait and landscape installation - cable management
(rotatable) by cable clips
- multiple switched socket-outlet on rear side - castors with
- cable management by cable clips lock-type brake (TENTE)
- castors with lock-type brake (TENTE) - dimensions (in case of table position):
H 800 x W 1130 x D 940 mm
- dimensions:
H 1800 x W 1130 x D 940 mm
Item recommended VESA Load Item recommended VESA Load
Item name (max.) Colour Item name
no.: screen size (max.) no.: screen size (max.) (max.) Colour
7693 BrackIT Stand Single 46 - 65“ | 116 - 165 cm 800 x 500 mm 60 kg 7776 BrackIT Stand 80 32 - 55“ | 81 - 140 cm 700 x 400 mm 60 kg
BrackIT® Stand Dual
Mobile stand system
- for 2 screens „side-by-side“
- TV holding fixture, height-adjustable along
the column (tool needed)
- -5 to +12° continuously tiltable
- multiple switched socket-outlet on rear side
- cable management by cable clips
- castors with lock-type brake (TENTE)
- dimensions:
H 1800 x W 2100 x D 940 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
7782 BrackIT Stand Dual 40 - 60“ | 102 - 152 cm 2x 800 x 400 mm 2x 50 kg
BrackIT® Stand Dual XL
Mobile stand system
- for 2 screens „side-by-side“
- TV holding fixture, height-adjustable along
the column (tool needed)
- multiple switched socket-outlet on rear side
- cable management by cable clips
- castors with lock-type brake (TENTE)
- dimensions:
H 2100 x W 2500 x D 1100 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
7591 BrackIT Stand Dual XL 50 - 77“ | 127 - 196 cm 2x 800 x 600 mm 250 kg
16 Visit www.hagor.de for detailed informationStand Systems
BrackIT® Stand Camera Holder BrackIT® Stand Frontshelf
Camera shelf available as an option AV shelf available as an option
- can be used with BrackIT - can be used with BrackIT
Stand Single Stand series
- with universal oblong hole - height-adjustable V-shelf for
to fix the camera in position AV components
- continuously height adjustable - continuously height adjustable
(tool needed) (tool needed)
- can be mounted above the screen - depth-adjustable wings
Item no.: Item name Size Load (max.) Colour Item no.: Item name Size Load (max.) Colour
BrackIT Stand BrackIT Stand W 255 x H 44 x
7258 W 229 x H 500 x D 223 mm 10 kg 7259 10 kg
Camera Holder Frontshelf D 280 min. / 380 mm max.
BrackIT® Stand Codec Shelf BrackIT® Stand Cable Hook
AV shelf available as an option Wind-up aid for cable available as an option
- can be used with BrackIT - can be used with BrackIT
Stand series Stand series
- for mini PCs and codecs - keeps cables safe and
- continuously height adjustable neatly together
(tool needed) - independently height adjustable
Item no.: Item name Size Load (max.) Colour Item no.: Item name Size Load (max.) Colour
BrackIT Stand BrackIT Stand
7269 W 420 x D 260 mm 10 kg 7321 W 28 x H 146 x D 78 mm 5 kg
Codec Shelf Cable Hook
BrackIT® Stand Media box Optional accessories, suitable for
Media box available as an option BrackIT Stand Single
- can be used with BrackIT Stand BrackIT Stand Dual
series (except BrackIT Stand 80) BrackIT Stand Dual XL
- safe storage space for AV
components, for instance
- incl. openings for cables &
ventilation
- continuously height adjustable
(tool needed)
Item no.: Item name Size Load (max.) Colour
BrackIT Stand
7267 W 530 x H 204 x D 391 mm 10 kg
Mediabox
Visit www.hagor.de for detailed information 17Stand Systems
HP Twin Trolley
ProduktItem HD XXL
name HP Twin Trolley
ProduktItem HD XXL Cabinet
name
Mobile stand system
Produktart Media cabinet available as an option
Produktart
- - height adjustable via detents (spring bolts)
Produktspezifikation - - can be used with HP Twin Trolley HD XXL
Produktspezifikation
along the column
- Produktspezifikation - - lockable
Produktspezifikation
- integrated cable management
Produktspezifikation Produktspezifikation
- perforated sheet steel construction
- - set
Produktspezifikation
of castors with lock-type brake - Produktspezifikation
- good ventilation, perfect for AV equipment
Produktspezifikation Produktspezifikation
- incl. shelf and height - - integrated cable management
- Produktspezifikation Produktspezifikation
adjustable camera holder
Produktspezifikation Produktspezifikation
- - dimensions:
Produktspezifikation - Produktspezifikation
H 1390 - 1740 x
W 1305 x D 696 mm
- landscape or portrait
installation (depending
on display size)
Exemplary installation
Item no.: Description / Size Befestigung Item no.: Description / Size Befestigung
Item 1234 Item name recommended
Lorem ipsum VESAVESA xxxLoad
- xxx Item no.:
1234 Item name
Lorem ipsum Size VESA xxx - xxx Colour
Colour
no.: screen size (max.) (max.)
5678HP Twin Trolley Lorem ipsum VESA xxx - xxx HP Twin Trolley Lorem
HD XXLipsum
9730 60 - 100“ | 152 - 254 cm 1000 x 600 mm 90 kg 97355678 W 573 x H 650 x DVESA xxx - xxx
340 mm
HD XXL Cabinet
HP Twin Trolley HD HP Twin Trolley
Mobile stand system Mobile stand system
- height adjustable via detents (spring bolts) - height adjustable via detents (spring bolts)
along the column along the column
- incl. set of castors with lock-type brake - incl. set of castors with lock-type brake
- height-adjustable - height-adjustable
1350 min. to 1650 mm max. 1200 min. to 1500 mm max.
- dimensions: - dimensions:
H 1350 - 1650 x H 1200 - 1500 x
W 1000 x D 680 mm W 850 x D 600 mm
- incl. shelf and height- - incl. shelf and height-
adjustable camera holder adjustable camera holder
- landscape or portrait - landscape or portrait
installation (depending on installation (depending
display size) on display size)
- cable management inside - cable management inside
the telescopic tubes the telescopic tubes
Item recommended VESA Load Item recommended VESA Load
Item name Colour Item name Colour
no.: screen size (max.) (max.) no.: screen size (max.) (max.)
HP Twin HP Twin
9723 55 - 84“ | 140 - 213 cm 800 x 500 mm 90 kg 9720 32 - 55“ | 81 - 140 cm 600 x 400 mm 50 kg
Trolley HD Trolley
18 Visit www.hagor.de for detailed informationStand Systems
Braclabs® Stand Series
Stand system
- quick and easy assembly
- VESA mounting fixture for use in either
landscape or portrait format
- easy hanging in and out of the
screen via keyholes
- locking of column height by
pin screw on the back
- internal cable management
- incl. handle on the back for easy
adjustment of the column
Braclabs Stand Mobile
Braclabs Stand Floor base
Braclabs Stand Floor mount
Braclabs Stand Front shelf
incl. handle height adjustable portrait or landscape
Item no.: Item name recommended screen size VESA (max.) Load (max.) Height (centre of screen) Colour
1981 Braclabs Stand Floor base 32 - 55“ | 81 - 140 cm 600 x 400 mm 35 kg 1195 - 1635 mm
1982 Braclabs Stand Floor mount 32 - 55“ | 81 - 140 cm 600 x 400 mm 35 kg 1195 - 1635 mm
1983 Braclabs Stand Mobile 32 - 55“ | 81 - 140 cm 600 x 400 mm 35 kg 1275 - 1715 mm
Item no.: Item name Size Load (max.) Colour
1984 Braclabs Stand Front shelf W 450 x D 260 mm 7,5 kg
Visit www.hagor.de for detailed information 19Stand Systems
Elia SB Series VY D
Heavy-duty stand system EA U
TY
H
- installation in landscape format
- incl. VESA universal holding fixture LUM
L OUTDO A
A
- screen height selectable in detents in
FUL
OR
26,981
50-mm steps (tool needed) 2|
- concealed cable routeing inside the column
- removable tower cover S
RO
LLABL -AS
PRE
E
Elia SB, also as B2B version
Elia SB HD Touch
Item no.: Item name Description recommended screen size VESA (max.) Load (max.) Floor space required Colour
4873 Elia SB, black Heavy-duty stand system up to 86“ | 218 cm max. 800 x 600 mm 125 kg W 900 x D 600 mm
4874 Elia SB, silver Heavy-duty stand system up to 86“ | 218 cm max. 800 x 600 mm 125 kg W 900 x D 600 mm
4875 Elia SB, white Heavy-duty stand system up to 86“ | 218 cm max. 800 x 600 mm 125 kg W 900 x D 600 mm
4876 Elia SB Back-to-Back Heavy-duty stand system for 2 screens 2x 75“ | 191 cm 800 x 600 mm 125 kg W 900 x D 600 mm
4872 Elia SB HD Touch Heavy-duty stand system for touch applications up to 86“ | 218 cm max. 800 x 600 mm 125 kg W 900 x D 600 mm
Elia SB Set of castors Info Tower / Elia SB Glass Shelf
Optional set of castors Optional glass shelf for AV equipment
- can be used with Elia SB - height can be selected
stand columns (tool needed)
- set consisting of 6 parts - dimensions: W 500 x D 300 mm
- castors with soft tread for low - material: clear glass
noise emission and good grip - several glass shelves can be
mounted one above the other
Item no.: Item name Size Item no.: Item name Size Load (max.)
2407 Elia SB Set of castors H 70 mm 2406 Info Tower / Elia SB Glass shelf W 500 x D 300 mm 15 kg
20 Visit www.hagor.de for detailed informationStand Systems
Elia 115 | 160
Free-standing stand system
- installation in landscape format
- incl. VESA universal holding fixture
- TV holder ± 20° swivelling
- incl. hang out protection
- internal cable routeing
- clean, clear appearance
- floor space required: W 800 × D 550 mm
- available in two heights -
120 cm and 165 cm (centre of screen)
- available in 3 colours - black, silver and white
Elia 115
Elia 160
glass shelf, optional set of castors (4 pcs.) optional PLW holder, included
Item no.: Item name recommended screen size VESA (max.) Load (max.) Height (centre of screen) Colour
4854 Elia 115, black 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1200 mm
4863 Elia 115, silver 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1200 mm
4864 Elia 115, white 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1200 mm
4856 Elia 160, black 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1650 mm
4865 Elia 160, silver 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1650 mm
4866 Elia 160, white 32 - 55“ | 81 - 140 cm 600 x 400 mm 60 kg 1650 mm
Item no.: Item name Size Load (max.) Colour
4858 Elia Glass shelf W 500 x D 300 mm 15 kg
4869 Elia Glass shelf W 500 x D 300 mm 15 kg
4870 Elia Glass shelf W 500 x D 300 mm 15 kg
2403 Set of castors for Elia 115 | 160 H 70 mm 60 kg
Visit www.hagor.de for detailed information 21Stand Systems
Elia Stainless Steel series
Free-standing columns
- TV holding fixture ± 180° rotatable
(tool needed)
- with lateral turn limiter ± 30°
- internal cable routeing
- base plate: Ø 530 mm
- screen height adjustable
(tool needed)
Elia 160 Stainless Steel Elia 115 Stainless Steel
Item no.: Item name Description recommended screen size VESA (max.) Load (max.) Height (centre of screen) Colour
4849 Elia 115 Stainless Steel free-standing column 32 - 55“ | 81 - 139 cm 400 x 400 mm 35 kg 700 min. - 1000 mm max.
4877 Elia 160 Stainless Steel free-standing column 32 - 55“ | 81 - 139 cm 400 x 400 mm 35 kg 700 min. - 1700 mm max.
Item no.: Item name Description Load (max.) Size Colour
4850 EliaStainless Steel shelf optional shelf; continuously height adjustable (tool needed) 5 kg W 350 x D 250 mm
HP Stand 55 HP Stand 55 Glass shelf
Mobile stand system Glass shelf available as an option
- TV holding fixture ± 90° rotatable - can be used with HP Stand 55
- TV holding fixture tiltable from -5 to +15° - continuously height adjustable
- internal cable routeing (tool needed)
- incl. set of castors with - several glass shelves can be
lock-type brake mounted one above the other
- floor space required:
W 1000 × D 500 mm
- screen height adjustable
(tool needed) (centre of screen)
1160 mm min. / 1800 mm max.
- incl. glass shelf, W 455 x D 325 mm
recommended VESA Load
Item no.: Item name Colour Item no.: Item name Size Load (max.) Colour
screen size (max.) (max.)
9425 HP Stand 55 37 - 65“ | 94 - 165 cm 800 x 500 mm 40 kg 1926 HP Stand 55 glass shelf W 455 x D 325 mm 15 kg
22 Visit www.hagor.de for detailed informationWall Mounts, fixed
BL Fixed 100 BL Fixed 200
Wall mount, fixed Wall mount, fixed
- screen can be installed in portrait - screen can be installed in portrait
or landscape format or landscape format
- slide-in system - slide-in system
from above for secure fit from above for secure fit
- incl. hang out protection - incl. hang out protection
- distance to wall: 14 mm - distance to wall: 19 mm
recommended VESA Load recommended VESA Load
Item no.: Item name Colour Item no.: Item name Colour
screen size (max.) (max.) screen size (max.) (max.)
9615 BL Fixed 100 15 - 24“ | 38 - 61 cm 100 x 100 mm 25 kg 9614 BL Fixed 200 15 - 32“ | 38 - 81 cm 200 x 200 mm 30 kg
BL Fixed 400 BL Fixed 800
Wall mount, fixed Wall mount, fixed
- screen can be installed in portrait - screen can be installed in
or landscape format landscape format
- incl. quick release device via - incl. quick release device via
rope-drawn spring-loaded latch, rope-drawn spring-loaded latch,
with magnets for invisible fixing with magnets for invisible fixing
on the wall mount on the wall mount
- integrated spirit level - integrated spirit level
- distance to wall: 22 mm - distance to wall: 22 mm
recommended VESA Load recommended VESA Load
Item no.: Item name Colour Item no.: Item name Colour
screen size (max.) (max.) screen size (max.) (max.)
9613 BL Fixed 400 32 - 46“ | 81 - 116 cm 400 x 400 mm 40 kg 9612 BL Fixed 800 46 - 65“ | 116 - 165 cm 800 x 600 mm 60 kg
BL Superslim 400 BL Superslim 600
Wall mount, fixed Wall mount, fixed
- exact fine adjustment of height - exact fine adjustment of height
by means of screws (± 8 mm) by means of screws (± 8 mm)
- incl. spirit level - incl. spirit level
- VESA adapter can be randomly - VESA adapter can be randomly
positioned on the wall plate positioned on the wall plate
- incl. quick release device via - incl. quick release device via
rope-drawn spring-loaded latch, rope-drawn spring-loaded latch,
with magnets for invisible fixing with magnets for invisible fixing
on the wall mount on the wall mount
- distance to wall: 18 mm - distance to wall: 18 mm
Item recommended VESA Load Item recommended VESA Load
Item name Colour Item name
no.: screen size (max.) (max.) no.: screen size (max.) (max.) Colour
9733 BL Superslim 400 32 - 55“ | 81 - 140 cm 400 x 400 mm 35 kg 9734 BL Superslim 600 55 - 100“ | 140 - 254 cm 600 x 400 mm 35 kg
Visit www.hagor.de for detailed information 23Wall Mounts, fixed
WH 50 F - HD
Fixed wall mount (heavy duty)
- especially for portrait installation
- distance to wall: 32 mm
- integrated spirit level
- screen position can be horizontally
adjusted after assembly thanks to
oblong mounting holes VY D
- incl. height compensation up to 10 mm
EA U
TY
H
- incl. optionally usable lock
IN
LUM 13U
UTD(max.)
L OLoad O AI
M
A
Item no.: Item name recommended screen size VESA (max.) Colour
FUL
OR
26,9815 g/mol
1790 WH 50 F - HD 32 - 55“ | 81 - 140 cm 400 x 400 mm 125 kg 2|8|3
1469 VESA Adapter 800 55 - 75“ | 140 - 190 cm 800 mm 125 kg
SEM
RO
LLABL -AS
BL
PRE
E
ED
WH 85 F - HD
Fixed wall mount (heavy duty)
- portrait or landscape installation possible
- distance to wall: 32 mm
- integrated spirit level
- screen position can be horizontally
adjusted after assembly thanks to
oblong mounting holes VY D
EA U
- incl. height compensation up to 10 mm
TY
H
- incl. optionally usable lock
IN
LUM 13U
L OUTDO AI
M
A
FUL
OR
26,9815 g/mol
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
2|8|3
1791 WH 85 F - HD 55 - 110“ | 140 - 279 cm 800 x 600 mm 125 kg
SEM
RO
LLABL -AS
BL
PRE
E
ED
WH 85 F - HD 1200 x 900
Fixed wall mount for XL screens
- two-part mounting fixture for landscape
or portrait installation
- fine adjustment for height and width
- distance to wall: 39 mm
- incl. quick release device via
rope-drawn spring-loaded latch,
VY D
with magnets for invisible fixing EA U
TY
on the wall mount
H
- landscape VESA 1200 x 900 mm max.
IN
LUM 13U
portrait VESA 600 x 900 mm max.
L OUTDO AI
M
A
FUL
OR
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
26,9815 g/mol
2|8|3
portrait as of 65“ | 165 cm portrait 600 x 900 mm
9742 WH 85 F - HD 1200 x 900 125 kg
landscape as of 75“ | 191 cm landscape 1200 x 900 mm
SEM
RO
LLABL -AS
BL
PRE
E
ED
24 Visit www.hagor.de for detailed informationWall Mounts, tiltable
BL Tilt 100 BL Tilt 200
Wall mount, tiltable Wall mount, tiltable
- screen can be installed in - screen can be installed in
portrait or landscape format portrait or landscape format
- -5 to +12° continuously tiltable - -5 to +12° continuously tiltable
- incl. quick release device via - incl. quick release device via
rope-drawn spring-loaded latch, rope-drawn spring-loaded latch,
with magnets for invisible fixing with magnets for invisible fixing
on the wall mount on the wall mount
- distance to wall: 42 mm - distance to wall: 42 mm
Item recommended VESA Load Item recommended VESA Load
Item name Colour Item name Colour
no.: screen size (max.) (max.) no.: screen size (max.) (max.)
9611 BL Tilt 100 15 - 24“ | 38 - 61 cm 100 x 100 mm 20 kg 9610 BL Tilt 200 15 - 32“ | 38 - 81 cm 200 x 200 mm 20 kg
BL Tilt 400 BL Tilt 800
Wall mount, tiltable Wall mount, tiltable
- screen can be installed in - screen can be installed in
portrait or landscape format landscape format
- 0 to 12° continuously tiltable - 0 to 12° continuously tiltable
- incl.hang out protection - incl.hang out protection
- incl. quick release device via - incl. quick release device via
rope-drawn spring-loaded latch, rope-drawn spring-loaded latch,
with magnets for invisible fixing with magnets for invisible fixing
on the wall mount on the wall mount
- integrated spirit level - integrated spirit level
- distance to wall: 35 mm - distance to wall: 35 mm
Item recommended VESA Load Item recommended VESA Load
Item name Colour Item name Colour
no.: screen size (max.) (max.) no.: screen size (max.) (max.)
9609 BL Tilt 400 32 - 49“ | 81 - 124 cm 400 x 400 mm 40 kg 9608 BL Tilt 800 46 - 65“ | 116 - 165 cm 800 x 600 mm 60 kg
BL Superslim Tilt 400 BL Superslim Tilt 600
Wall mount, tiltable Wall mount, tiltable
- exact fine adjustment of height - exact fine adjustment of height
by means of screws (± 8 mm) by means of screws (± 8 mm)
- incl. spirit level - incl. spirit level
- VESA adapter can be randomly - VESA adapter can be randomly
positioned on the wall plate positioned on the wall plate
- tiltable from 0 to 12° - tiltable from 0 to 12°
- incl. quick release device via - incl. quick release device via
rope-drawn spring-loaded latch, rope-drawn spring-loaded latch,
with magnets for invisible fixing with magnets for invisible fixing
on the wall mount on the wall mount
- distance to wall: 30 mm - distance to wall: 30 mm
Item recommended VESA Load Item recommended VESA Load
Item name Colour Item name Colour
no.: screen size (max.) (max.) no.: screen size (max.) (max.)
9731 BL Superslim Tilt 400 32 - 55“ | 81 - 140 cm 400 x 400 mm 35 kg 9732 BL Superslim Tilt 600 40 - 75“ | 81 - 191 cm 600 x 400 mm 35 kg
Visit www.hagor.de for detailed information 25Wall Mounts, tiltable
WH 50 T - HD
Tiltable wall mount (heavy duty)
- especially for portrait installation
- distance to wall: 65 mm
- ± 10° continuously tiltable
- detachable spirit level
- screen position can be horizontally adjusted
VY D
after assembly thanks to oblong mounting holes
EA U
TY
- incl. height compensation up to 10 mm
H
- incl. optionally usable lock
IN
LUM 13U
UTD(max.)
L OLoad O AI
M
A
Item no.: Item name recommended screen size VESA (max.) Colour
FUL
OR
26,9815 g/mol
1792 WH 50 T - HD 32 - 55“ | 81 - 140 cm 400 x 400 mm 125 kg 2|8|3
1469 VESA Adapter 800 55 - 75“ | 140 - 190 cm 800 mm 125 kg
SEM
RO
LLABL -AS
BL
PRE
E
ED
WH 85 T - HD
Tiltable wall mount (heavy duty)
- distance to wall: 65 mm
- ± 10° continuously tiltable
- detachable spirit level
- screen position can be horizontally
adjusted after assembly thanks to
VY D
EA U
oblong mounting holes
- incl. height compensation up to 10 mm
TY
H
- incl. optionally usable lock
IN
LUM 13U
L OUTDO AI
M
A
FUL
OR
26,9815 g/mol
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
2|8|3
1793 WH 85 T - HD 55 - 110“ | 140 - 279 cm 800 x 600 mm 125 kg
SEM
RO
LLABL -AS
BL
PRE
E
ED
WH 85 T - HD 1200 x 900
Tiltable wall mount for XL screens
- two-part mounting fixture for landscape
or portrait installation
- fine adjustment for height and width
- distance to wall: 75 - 113 mm
(depending on tilt angle)
- incl. quick release device via rope-drawn
VY D
spring-loaded latch, with magnets for invisible EA U
TY
H
fixing on the wall mount
- landscape VESA 1200 x 900 mm max.
IN
portrait VESA 600 x 900 mm max.
LUM 13U
L OUTDO AI
M
A
FUL
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
OR
26,9815 g/mol
2|8|3
portrait as of 65“ | 165 cm portrait 600 x 900 mm
9744 WH 85 T - HD 1200 x 900 125 kg
landscape as of 75“ | 191 cm landscape 1200 x 900 mm
SEM
RO
LLABL -AS
BL
PRE
E
ED
26 Visit www.hagor.de for detailed informationWall Mounts, fully moveable
BrackIT® L
Tiltable and swivelling wall mount
- screen can be installed in portrait or
landscape format
- no tools needed to set tilt angle,
can be locked by means of a rotary
handle on the side
- incl. cable clips for decent cable management
- distance to wall: 63 min. to 703 mm max.
- -2 to +12° continuously tiltable
- ± 90° swivelling, depending on screen size
- ± 5° subsequent levelling
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1985 BrackIT L 32 - 55“ | 81 - 140 cm 600 x 400 mm 30 kg
BrackIT® L HD
Tiltable and swivelling wall mount
- screen can be installed in portrait or
landscape format
- no tools needed to set tilt angle,
can be locked by means of a rotary
handle on the side
- incl. cable clips for decent cable management
- distance to wall: 60 min.to 500 mm max.
- -2 to +12° continuously tiltable
- ± 45° swivelling, depending on screen size
- ± 5° subsequent levelling
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1986 BrackIT L HD 32 - 55“ | 81 - 140 cm 600 x 400 mm 40 kg
BrackIT® XL HD
Tiltable and swivelling wall mount
- screen installation in landscape format
- no tools needed to set tilt angle,
can be locked by means of a rotary
handle on the side
- incl. cable clips for decent cable management
- distance to wall: 60 min. to 500 mm max.
- -2 to +12° continuously tiltable
- 45° swivelling, depending on screen size
- ± 5° subsequent levelling
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
1987 BrackIT XL HD 40 - 86“ | 102 - 218 cm 800 x 600 mm 80 kg
Visit www.hagor.de for detailed information 27Wall Mounts, fully moveable
WH-Synchron XXL-HD Short
VY D
Tiltable and swivelling wall mount (heavy duty) EA U
TY
H
- screen installation in landscape format
IN
- continuously extractable from 85 min. to 355 mm max. LUM 13U
L OUTDO AI
M
A
- ± 20° max.continuous swivelling range
FUL
OR
- no tools needed to set tilt angle -5 / +15° 26,9815 g/mol
2|8|3
- incl. cable clips for decent cable management
SEM
RO
LLABL -AS
BL
PRE
E
ED
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
9754 WH-Synchron XXL-HD Short 55 - 110“ | 140 - 280 cm 600 x 400 mm 125 kg
WH-Synchron XXL-HD
VY D
Tiltable and swivelling wall mount (heavy duty) EA U
TY
H
- screen installation in landscape format
IN
- large distance to wall possible, LUM 13U
continuously extractable from L OUTDO AI
M
A
84 min. to 710 mm max.
FUL
OR
26,9815 g/mol
2|8|3
- ± 45° max. continuous swivelling range
- no tools needed to set tilt angle -5 / +15°
SEM
- incl. cable clips for decent cable management
RO
LLABL -AS
BL
PRE
E
ED
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
9755 WH-Synchron XXL-HD 55 - 110“ | 140 - 280 cm 600 x 400 mm 125 kg
WH-Synchron XXL-HD Adapter Set
Optional extension
- can be used with WH-Synchron XXL-HD series
- extends VESA standard to 1200 x 900 mm
- VESA standards: 600 x 600, 800 x 400, 800 x 600,
800 x 800, 800 x 900, 900 x 600, 900 x 800,
900 x 900, 1200 x 600, 1200 x 800, 1200 x 900 mm
Item no.: Item name VESA (max.) Load (max.) Colour
9604 WH-Synchron XXL -HD Adapter Set 1200 x 900 mm 125 kg
28 Visit www.hagor.de for detailed informationWall Mounts, fully moveable
BL Full Motion Series
Tiltable and swivelling wall mount
- screen installation in landscape
or portrait format
- variable distance to wall
- integrated spirit level
- incl. cable clips for decent
cable management
- -5 to +10° tiltable
Item no.: Item name recommended screen size VESA (max.) Load (max.) Wall distance Swivelling range Colour
9607 BL Full Motion 200-I 15 - 32“ | 38 - 81 cm 200 x 200 mm 25 kg 48 mm ± 15°
9606 BL Full Motion 200-II 15 - 32“ | 38 - 81 cm 200 x 200 mm 25 kg 50 - 225 mm ± 45°
9605 BL Full Motion 200-III 15 - 32“ | 38 - 81 cm 200 x 200 mm 25 kg 52 - 342 mm ± 90°
WH Synchron 41
Tiltable and swivelling wall mount
- screen installation in landscape or
portrait format
- variable distance to wall possible,
continuously extractable from 45 min. to 484 mm max.
- ± 90° max.continuous swivelling range
- no tools needed to set tilt angle -2 / +12°
- incl. cable clips for decent cable management
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
2061-1 WH Synchron 41 32 - 50“ | 81 - 127 cm 400 x 400 mm 30 kg
WH Synchron 51
Tiltable and swivelling wall mount
- screen installation in landscape or
portrait format
- variable distance to wall possible,
continuously extractable from 50 min. to 465 mm max.
- ± 45° max.continuous swivelling range
- no tools needed to set tilt angle -2 / +12°
- incl. cable clips for decent cable management
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
2062 WH Synchron 51 40 - 65“ | 102 - 165 cm 600 x 400 mm 45 kg
Visit www.hagor.de for detailed information 29Wall Mounts, rotatable
WH Turn M
Rotatable universal wall mount
- freely rotatable by 90° - locks in final position
- clicks in place in the respective final position (0 or 90°)
- little effort needed thanks to spring mechanism
- tilting possible (0° / -2.5° / -5°)
- continuous change of screen format with no tools needed
- distance to wall: 67 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
5760 WH Turn M 46 - 55“ | 117 - 140 cm 400 x 400 mm 45 kg
WH Turn L
VY D
Rotatable universal wall mount EA U
TY
H
- freely rotatable by 90° - locks in final position
IN
- continuous change of screen format LUM 13U
with no tools needed L OUTDO AI
M
A
FUL
- little effort needed thanks to spring mechanism
OR
26,9815 g/mol
2|8|3
- distance to wall: 74.5 mm
SEM
RO
LLABL -AS
BL
PRE
E
ED
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
5693 WH Turn L 55 - 75“ | 140 - 191 cm 600 x 400 mm 65 kg
WH Turn Basic
Rotatable wall mount
- landscape and portrait installation
- 360° rotatable in 90° snap steps
- simple snap lug mechanism,
not suitable for permanent rotation
- distance to wall: 46 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
9714 WH Turn Basic 32 - 70“ | 81 - 178 cm 600 x 400 mm 50 kg
30 Visit www.hagor.de for detailed informationWall Mounts with PC compartment
WH 75 FPC
Fixed wall mount with PC compartment
- installation in landscape or portrait
format (depending on screen size)
- incl. innovative pull-out mechanism,
e.g. for mini PC
- access to e. g. mini PC guaranteed,
even during running operation
- incl. locking function for mini PC
(adjustable to size)
- incl. lock for the pull-out mechanism for
protection against unauthorized access
Item no.: Item name recommended screen size VESA (max.) Load (max.) Wall distance Colour
2220 WH 75 FPC 40 - 65“ | 102 - 165 cm 600 x 400 mm 80 kg 92,5 mm
- For other screensizes available on request. -
WH PC Box Tilt
Tiltable display mount with content player compartment
- tiltable from 0 to 10°
- dimensions of enclosure
inside: W 246 x H 249 x D 57 mm
outside: W 318 x H 252 x D 89,5 mm
- optionally lockable
Item no.: Item name recommended screen size VESA (max.) Load (max.) Wall distance Colour
9719 M PC Box Tilt 32 - 55“ | 81 - 140 cm 400 x 400 mm 30 kg 89 mm
Visit www.hagor.de for detailed information 31Wall Mounts, height-adjustable
WH Moto 80 WH Moto 160
Electrical wall mount with height adjustment Electrical wall mount with height adjustment
- installation in landscape format - installation in landscape format
- electromotive, continuous height adjustment - electromotive, continuous height adjustment
- 500 mm travel way - 500 mm travel way
- incl. wired touch control - incl. wired touch control
- dimensions: - dimensions:
H 1005 x W 1148 x D 127 mm H 1005 x W 1148 x D 127 mm
Item recommended Item recommended
Item name VESA (max.) Load (max.) Colour Item name VESA (max.) Load (max.) Colour
no.: screen size no.: screen size
9621 WH Moto 80 84 - 110“ | 213 - 279 cm 800 x 900 mm 80 kg 9623 WH Moto 160 84 - 110“ | 213 - 279 cm 800 x 900 mm 160 kg
9622 WH Moto 80 84 - 110“ | 213 - 279 cm 800 x 900 mm 80 kg 9624 WH Moto 160 84 - 110“ | 213 - 279 cm 800 x 900 mm 160 kg
HP Counterbalanced Wall HP Counterbalanced Wall HD
Wall mount with height adjustment Wall mount with height adjustment
- installation in landscape format - installation in landscape format
- manual height-adjustment thanks - manual height-adjustment thanks
to adjustable to device weight to adjustable to device weight
mechanism mechanism
- very smooth adjustability - very smooth adjustability
- 400 mm travel way - 500 mm travel way
- screen stays safely in - screen stays safely in
desired height desired height
recommended recommended
Item no.: Item name VESA (max.) Load (max.) Colour Item no.: Item name VESA (max.) Load (max.) Colour
screen size screen size
HP Counter- 55 - 75“ | HP Counter- 75 - 100“ |
9736 800 x 700 mm 35 - 60 kg 9737 900 x 800 mm 60 - 90 kg
balanced Wall 140 - 191 cm balanced Wall HD 191 - 254 cm
32 Visit www.hagor.de for detailed informationMounting Systems, depending on display
Mounting systems for OMN-D series
Especially for Samsung OMN-D series
- flexible positioning
- can be positioned close to the shop window
- cable routeing inside the frame
- impact and scratch proof powder coating
- optionally available as
- floor stand with tilt-proof base plate and
levelling via adjusting screws
- floor mount with base plate to fix on the floor
- ceiling mount with 30° tiltable ceiling flange,
height adjustable in detents from 600 mm min.
to 1000 mm max. (tool needed),
frame assembly directly on the ceiling possible
(no use of the extension)
Floor Mount OMN-D
Ceiling Mount OMN-D
Floor Stand OMN-D
Item no.: Item name recommended screen size Load (max.) Size Colour
1901 Floor Stand OM46N-D Samsung OM46N-D 35 kg H 2103 x W 891 x D 500 mm
1902 Floor Stand OM55N-D Samsung OM55N-D 45 kg H 2296 x W 970 x D 500 mm
1917 Floor Mount OM46N-D Samsung OM46N-D 35 kg H 2073 x W 891 x D 240 mm
1918 Floor Mount OM55N-D Samsung OM55N-D 45 kg H 2265 x W 970 x D 240 mm
1899 Ceiling Mount OM46N-D Samsung OM46N-D 35 kg H 2339 x W 680 x D 80 mm
1900 Ceiling Mount OM55N-D Samsung OM55N-D 45 kg H 2530 x W 788 x D 80 mm
Visit www.hagor.de for detailed information 33Mounting Systems, depending on display
ScreenOut® OHF-Serie
Outdoor totem for Samsung OHF series
- stainless steel outdoor totem (powder-coated)
- portrait installation
- with corrosion-resistant plastic powder coating,
highly weather resistant
- concealed cable routeing with power supply inside the totem
- incl. connecting terminals for potential equalisation
- matching screen mount for Samsung OHF displays
- quick removal of top cover and trim panels thanks to central lock
- air inlets and outlets specifically adapted to the display size
- ambient temperature range from -30°C to +50°C
- designed according to Samsung guidelines for OHF-series
Item no.: Item name recommended screen size Size Colour
1630 ScreenOut OH46F Samsung OH46F H 1889 x W 736 x D 206 mm
1631 ScreenOut OH55F Samsung OH55F H 2081 x W 844 x D 206 mm
- Also available as 75“and 85“ version on request. -
WH OHF series
Wall mount for Samsung OHF series
- specific mounting hole pattern
- portrait or landscape installation
- hang out protection via theft-resistant screw
(on the back)
- incl. resistorx tool (theft preventing)
- material: stainless steel (powder-coated)
- with corrosion-resistant plastic powder-
coating, highly weather-resistant
- designed according to Samsung
guidelines for OHF-series
Item no.: Item name recommended screen size Load (max.) Size Colour
5750 WH OH46F Samsung OH46F 48 kg H 576 x W 1055 x D 95 mm
5752 WH OH55F Samsung OH55F 63 kg H 635 x W 1246 x D 94 mm
- Also available as 75“and 85“ version on request. -
34 Visit www.hagor.de for detailed informationMounting Systems, depending on display
WH SA Flip
Rotatable and tiltable wall mount for Samsung WM55H/R
- developed for Samsung WM55H/R (Flip)
- freely rotatable by 90°
- stays securely in the respective final position
- final position release with little effort
thanks to spring mechanism
- tilting possible (0° / -2.5° / -5°)
- continuous change of
screen position with no tools needed
- distance to wall: 67 mm
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
5690 WH SA Flip Samsung WM55H/R 400 x 400 mm 45 kg
- Colour similar to SAMSUNG Flip series -
ST SA Flip
Mobile stand system for Samsung WM55H/R (Flip)
- freely rotatable by 90°
- stays securely in the respective final position
- final position release with little effort thanks to spring mechanism
- tilting possible (0° / -2.5° / -5°)
- continuous change of screen position with no tools needed
- dished supporting column (no stumbling)
- concealed set of castors, 2 lock-type castors
- manoeuvrable through room doors
Item no.: Item name recommended screen size VESA (max.) Load (max.) Colour
5691 ST SA Flip Samsung WM55H/R 400 x 400 mm 45 kg
- Colour similar to SAMSUNG Flip series -
Flip adapter 65“
Adapter for Samsung WM65R (65“- Flip 2)
- can be used with ST SA Flip or WH SA Flip
- set consisting of 2 adapter bars
- incl. all mounting material
Ga
FO lvaniz
AD R FL ed
(2 APTE IPBO
PC
S) RS ARD
VE
SA - 65
40 "
0
Ga
FO lvaniz
AD R FL ed
(2 APTE IPBO
PC
S) RS ARD
VE
SA - 65
40 "
0
M8
HE
(4 XAGO
PC
NU S) N
1:1
TS
M8
M8 HE x30
HE HE AD
(4 XAGO (8 XAGOCAP
PC PC SC
S) N NU S) N RO RE
1:1
TS
1:1 UN W
DE
D
M8
HE x30
HE AD
(8 XAGOCAP
PC SC
S) N RO RE
1:1
UN W
DE
D
AD
AP
TE
RS
VE
Item no.: Item name recommended screen size VESA (max.) Colour
Mo SA
un 40
tin 0 FO
g ex R
am FL
ple IP
BO
ARAD
D AP
- 65TE
RS
" Ga
VE
lva
Mo SA
niz
un ed40
tin 0 FO
g ex R
am FL
ple IP
BO Co
AR de
Re D : 59
v. - 65 67
: " Ga
5761 Flip adapter 65“ Samsung WM65R 400 x 400 mm
Da lva
te niz
: 31 ed
/10
/20
19
Co
de
Re : 59
v. 67
:
Da
te
: 31
/10
/20
19
Visit www.hagor.de for detailed information 35Mounting Systems, depending on display
WH Cisco Webex Board Cisco Room Kit Adapter 55 - 75“
Wall mount for Cisco Webex Board 55“, 70“ and 85“ Universal adapter for Cisco Room Kit models
- installation in landscape format - easy installation between screen and any suitable
- TV holding fixtures suitable for Webex models 55“, 70“, 85“ universal screen mounting up to VESA 800 max.
- incl. keyhole bores for easy installation - can be mounted above and beneath screen
- small distance to wall - suitable for:
- Cisco Webex Room Kit Mini
- Cisco Webex Room Kit
- Cisco Webex Room Kit Plus
- continuously height adjustable
- powder-coated
Codec in case of Plus
recommended
Item no.: Item name VESA (max.) Load (max.) Colour
screen size
WH Cisco Webex
5758 depending on display for Cisco Webex Board 55“ Exemplary installation
Board 55“
WH Cisco Webex
5759 depending on display for Cisco Webex Board 70“
Board 70“ Item no.: Item name recommended screen size Colour
WH Cisco Webex
5762 depending on display for Cisco Webex Board 85“ 1925 Cisco Room-Kit Adapter 55 - 75“ 55 - 75“ | 140 - 191 cm
Board 85“
PLW-PANA-TH98LQ70LW M QLED Wall Mount series
Fixed wall mounts for Panasonic LQ series Wall mounts for Samsung QLED Q7 / Q8 / Q9
- installation in landscape format - fine adjustment of tilt
- TV holding fixture measuring 1512 x 1053 mm - variable wall distance
- incl. keyhole bores for easy installation version - M -: 17 - 92 mm
version - L -: 18 - 86 mm
- small distance to wall
- incl. cable management
- dimensions:
W 1632 x H 1130 mm x D 25 mm - slim design
M QLED Wall Mount M
M QLED Wall Mount L
Item no.: Item name recommended screen size Load (max.) Colour
Item no.: Item name recommended screen size Load (max.) Colour
9728 M QLED Wall Mount M 49 - 65“ | 124 - 165 cm 50 kg
PLW-PANA- Panasonic TH-98LQ70
5035 120 kg 9729 M QLED Wall Mount L 75“ | 191 cm 50 kg
TH98LQ70LW Panasonic TH-98LQ70L
36 Visit www.hagor.de for detailed informationYou can also read
