2021 WaveRunner Line-up
Yamaha Motor Europe
(Sept 2020)
EX Series
New Model for 2021 EX series
EX Limited
EX Series
Total Storage Volume 29L
EX SPORT
NEW COLOR AND GRAPHICS!
New bright hull and deck colors
Under seat storage = 8L Glove Box = 14L Front 3wet storage = 7L
EX Series
EXR
The EXR is a lightweight pocket rocket type experience on the water. It has a super agile and responsive attitude
which makes it one of the most fun to ride PWC ever.
EX Series
Predictable and User Friendly! True 3 passenger capability!
Compact, Lightweight Fun! Stable towing performance!
EX Limited: EX Sport: EXR:
• RiDE • Mechanical Reverse • RiDE
• Two-tone cut and sew seat • Reboarding step • Two-tone cut and sew seat
• Advanced graphics package • Mirrors • Advanced graphics package
• Nano 2 Hull and Deck • Metallic paint colors • Nano 2 Hull and Deck
• Larger sponsons • Advanced graphics package • 10% more power
• Limited Kit • Pump extension
• Custom mat • Custom mat
• 3D YAMAHA Emblem • 3D YAMAHA Emblem
EX Series
Deeper Bow storage* 12V Outlet* Custom Cover*
- Color matched
-Zipper opening at glove box
Pull Up Cleats(x2)
Rope bag*
(compression-molded)
Audio
(2 self-powered)
Larger Sponsons for
more stability while towing
*) T.b.c., depending on YMUS / Custom mats
2 x PWC fenders*
Page 6 P & A Division Development
EX Series
RiDE on EXR and EX Ltd. models
Easy access for
routine maintenance
Separate lower seat
base with easy
engine access
Roomy true 3 pass design
Re-board step (Deluxe, Sport)
EX Series
Mirrors Standard on Sport, EX
LTD & EXR models
Extra large Swim platform on all EX models
Easy to read LCD instrumentation
Ski tow eyelet Standard on all EX models
2021 FX Series
2021 FX Series
2021 FX CRUISER SVHO2021 FX Series
2021 FX CRUISER HO2021 FX Series
2021 FX SVHO2021 FX Series
2021 FX HO2021 FX Series
2021 FX Series2021 FX Series
Multi-mount 12V Outlet*
Adapter*
Custom Cover*
Dedicated Cooler Bag*
Upgraded Tow Hook
Next generation FX Speaker*
2 EXOGEAR Water Proof / *) T.b.c., depending on YMUS / 2 x PWC fenders*
4 x Pull up Cleats
Blue tooth Audio Speakers* P & A Division Development2021 FX Series
…THE MOST STABLE, CONFIDENCE-INSPIRING HANDLING TO-DATE
- Better Towing Ability / No Tilting at any speed
- Predictable handling
- More Comfort,
- Better dynamic stability,
- Better Static stability2021 FX Series
FX ENGINE OPTIONS
■ 1,812cc supercharged/DOHC 16 valve
■ Largest displacement in the industry
■ High power and big torque
■ 1,812cc natural aspirated/DOHC 16 valve
■ Largest displacement in the industry
■ Highest performance NA engine
■ Great fuel consumption and range2021 FX Series RiDE comes standard on all FX models
2021 FX Series
FX SERIES FEATURES
Industry -1st 4.3” LCD color touch screen meter
MENU
SCROLL
ALARM
MUTE
Page 192021 FX Series
The Next Generation of L-Mode:
• Pre-set top speed limit
• Pre-set acceleration curve
Use when towing tubes or wakeboards
Use for optimum fuel economy on longer trips
Lock in lower settings for beginner riders2021 FX Series Customizable settings Additionally, press and hold Settings menu to see multiple diagnostics
2021 FX Series
CONNEXT SCREEN DISPLAY OPTIONS
Adjust brightness based on conditions
Change screen accent colors
-Go to setting
Color change -Select display
-Use the slider to change the color2021 FX Series
CONNEXT SECURITY SYSTEM
- Security level is same as previous models
- If you forgot PIN code, reset it by the meter while
YDIS connecting
- No YDIS version upgrade required.2021 FX Series
REVERSE ASSIST FUNCTION
Use when backing off a trailer and need more RPM2021 FX Series
Electronic Trim/TDE on all FX models
Trim level indication on
Connext Screen2021 FX Series
ULTRA SLOW SPEED MANEUVERING MODE
Thrust directional enhancement (TDE) made possible with Drive By Wire
• Use when approaching docks
• Use when tying up to other boats2021 FX Series
FX series No Wake Mode/Cruise Assist
Consistent speeds through no-wake zones; no throttle required – hands-off operation
Can set and adjust a desired speed2021 FX Series
One ¼ 20 threaded
mount standard with
FX HO & FX Cruiser
HO
One ¼ 20 threaded
mount and one cup
holder extension
standard with FX
SVHO & FX Cruiser
SVHO2021 FX Series
• Footwell drains
• Addresses long-time customer and
dealer request2021 FX Series
FX SERIES STORAGE What do you store under the seat?* Items to keep
dry; not requiring fast access:
• Registration
• Insurance papers
• Flares, flag
• Tools
• Owner’s manual
• Fresh t-shirt!
*Asked in FX Owner Survey
Stern Storage
2.7 gal.
What do you store in the stern storage?*
Fast access items that can get wet:
• Dock line
• Ski rope
• Gloves
• Engine flush kit
• Snorkel
• Flip Flops!
*Asked in FX Owner Survey
Watertight Storage
8,7LPage 302021 FX Series
What do you store in the bow storage?*
FX SERIES STORAGE Larger items not requiring fast access:
• Cooler/drinks/food
• Extra PFDs
• Towels
• Extra ropes
• Anchor
• Fenders/bumpers
• Storage cover
*Asked in FX Owner Survey
Integrated cooler recess for 24 can soft-
Page 31
side cooler, included with FX Limited2021 FX Series
FX SERIES STORAGE
Extra Large
Watertight
Glove Box Storage
What do you store in the glove box?*
Quick access items and items to keep
dry:
• Phone
• Wallet
• Keys
• Sunscreen
• Glasses
• Bottled water or sports drink
• Multi tool
• Lanyard (when not in use)
• Hat
• Etc.
*Asked in FX Owner Survey
Page 322021 FX Series
• The FX has dual re-board
handles, and a wide padded step
that is deeper, flatter, and softer
for easy re-boarding
Page 332021 FX Series
FX Cruiser Seat is the industry’s only true
three passenger cruiser seat
Page 342021 FX Series
Adjustable Tilt Handlebar Position
Adjustable handlebar
position for improved
ergonomics:
• When cruising
• Standing up while
riding
• When used by
family/friends of
different heights or
riding styles2021 FX Series PULL UP CLEATS
2021 FX Series
FX series Key features
FX HO Cruiser: FX SVHO: FX SVHO Cruiser:
FX HO :
• 1.8L 4 cylinder NA engine • 1.8L 4 cylinder NA engine • 1.8L 4 cylinder Supercharged • 1.8L 4 cylinder Supercharged
• RiDE • RiDE engine engine
• Electronic Trim • Electronic Trim • 160 mm pump • 160 mm pump
• TDE Low speed handling • TDE Low speed handling • RiDE • RiDE
• Connext 4.3 LCD meter • Connext 4.3 LCD meter • Electronic Trim • Electronic Trim
• Drive Control • Drive Control • TDE Low speed handling • TDE Low speed handling
• No Wake/Cruise assist • No Wake/Cruise assist • Connext 4.3 LCD meter • Connext 4.3 LCD meter
• Adjustable Tilt handlebars • Adjustable Tilt handlebars • Drive Control • Drive Control
• Multi function mounts • Multi function mounts • No Wake/Cruise assist • No Wake/Cruise assist
• NanoXcel hull/deck • NanoXcel hull/deck • Adjustable Tilt handlebars • Adjustable Tilt handlebars
• Footwell drains • Footwell drains • Multi function mounts • Multi function mounts
• Wide padded remount step • Wide padded remount step • NanoXcel hull/deck • NanoXcel hull/deck
• Industry leading storage • Industry leading storage • Footwell drains • Footwell drains
• Cruiser Seat • Wide padded remount step • Wide padded remount step
• 2 pull up cleats • Industry leading storage • Industry leading storage
• NanoXcel 2 hull/deck • NanoXcel 2 hull/deck
• Cruiser Seat
• 2 pull up cleats2021 VX Series
2021 VX Series
ALL NEW DECK DESIGN!
• Improved Ergonomics & Styling
• Greater Storage Capacity
• Updated Dashboard Instrumentation
• New Factory Installed Audio system2021 VX Series
All New VX All New VX-C
Available in White/Lime Yellow Available in White/Lime Yellow2021 VX Series
All New VX Deluxe All New VX Cruiser
Available in Black/Torch Red Available in Lime Green
standard audio standard audio2021 VX Series
All New VX Cruiser HO
Available in Lime Yellow
Standard audio2021 VX Series
・ Better ergonomics and comfort
New
handgrips
Footwell drains
Narrower
seat
Deeper
footwells
Improved ergonomics compared to MY20 VX2021 VX Series
Connext
Touch pad
Connext 4.3” LCD Meter
SETTINGS Trip/Fuel Info Operation Info Drive Control Security/Eng. Lock2021 VX Series
Integrated Multi-mount feature2021 VX Series
Greater Storage Capacity
BOW LOCKER GLOVE BOX UNDER SEAT 113.9 L Total
MY21 VX 92 L 16.5 L 5.4 L
• New watertight glove box is largest in industry
• Dedicated area for your smartphone (right side)
• Comes with USB port & 12V power outlet
• Blue LED illumination
• Improved bow lid operation
• Dedicated area for cooler bag
• Storage compartment under the seat is also
larger2021 VX Series
ALL NEW FACTORY INSTALLED, FULLY
INTEGRATED AUDIO SPEAKERS!!!
• 4.5” marine grade premium speakers
• 50 watts per channel
• IP67 waterproof
• Strategically integrated into unit’s footwells
• Control touchpad located above glovebox for convenient,
easy access and control
• Bluetooth connectivity—ready to pair up to rider’s
smartphone
• Factory-installed—no hassle at the dealership!
Four tips to get the most from your new audio system!
1. Always use a high quality music source. Non-compressed, native files provide the best
sound quality when downloaded to your phone or device.
2. When using streaming services (Apple Music, Spotify, Pandora, etc.), review app settings to
ensure “high-quality” options are selected. Low quality settings and poor signal can
significantly reduce the quality of your audio. Note that certain streaming services may
require a premium subscription for high quality streaming or download access.
3. Check the settings on your phone or device to ensure high quality settings are selected
and to make sure phone EQ options are turned off for best results.
4. Video apps like You Tube and Vimeo may not provide a quality audio experience.2021 VX Series
RiDE Dual Throttle Control System Two Award-Winning Engine
Options
Making docking &
maneuverability a breeze!
1049cc three-cylinder TR-1 HO engine
(available on VX, VX-C, VX Deluxe, VX Cruiser & VX Limited)
1.8L 1812cc four-cylinder
High Output marine engine
(available on VX Cruiser HO & VX
HO Ltd.)2021 VX Series
No Wake Mode Cruise Assist
A little finger movement is acceptable
NO WAKE + 1
- Adjustable levels by speed control switches - Press Cruise SET switch at the rpm
- Activated by push "NO WAKE MODE" and You want to set
set "SPEED CONTROL UP/DOWN" switch - Drive control can be used together
VX Cru HO NWM + 1 - Release throttle lever
VX Ltd HO Default - A little finger movement is acceptable for setting
NWM -1
* VX Cru, VX Dlx, VX, VX-C (3cyl. Model has no adjustment)2021 VX Series
Reverse assist for VX series * Other than VX/VX-C
RiDE lever full throttle
*VX GP follows My 19 FX
SPEED
UP
SPEED
DOWN
Function overview
- When launching Waverunner from trailer,
We can get higher reverse thrust than previous models.
Level.2
- After the engine start and once move forward,
The function could not activate because of safety reason.
Level.1
How to use
- RiDE lever fully open, and rpm up by SPEED CONTROL switch.
- 2 levels are set by the switch. Level.0
RiDE Fully open
How to cancel
- Release RiDE lever/Reset to STEP0 by SPEED CONTROL DOWN
/ Grip throttle lever/Activate "No Wake Mode"2021 VX Series
T.D.E. / Thrust Directional Enhancer] for VX series
Low speed maneuverability VX
1.Slight Forward
TRIM/T.D.E.
2.Slight Reverse *VX GP follows My 19 FX
Function overview
- When idling status, we can get slight forward/reverse thrust by adjust reverse bucket
How to use
- Position “N ”, and
- TRIM/T.D.E. UP switch to slight forward
- TRIM/T.D.E. DOWN switch to slight reverse
How to cancel
- When slight forward (reverse) movement, push TRIM/T.D.E. DOWN (UP) switch
/ Grip throttle lever or RiDE lever/Activate "No Wake Mode"
Others
- T.D.E. is activated only Neutral position. UP/DOWN switches are activated as a Trim in other timing.
- Only can use idling rpm
* Other than VX base, VX-C2021 VX Series
New Feature for VX Series * Other than VX-C
Integrated Start/Stop in one button
*VX GP follows My 19 FX
Only one push! (0.5 sec)
- Keep pressing switch 0.5 sec at least
- If the starting condition is satisfied,
cranking starts automatically
- It will work until engine starts (about 4sec.)
- When the engine did not start and keep pressing the
start switch, it works about 5sec.
- Starter motor will not work
➔ When the voltage is under 12 V,
voltage icon will flashing on the meter
*not available on VX-C2021 VX Series
Upgraded Remount ladder for VX series
* Other than VX base, VX-C2021 VX Series
VX Base Features
• RiDE
• Remount Step
• EX style meter
*not available on VX-C2021 ALL NEW GP1800R HO GP1800R SVHO
2021 GP1800R HO
GP1800R HO GP1800R SVHO2021 GP Series
World Championship Hull design2021 GP Series
All New Deck Design2021 GP Series
・ New Race Style handlebars
With 4 position Tilt adjustability2021 GP Series
GP series ENGINE OPTIONS
■ 1,812cc supercharged/DOHC 16 valve
■ Largest displacement in the industry
■ High power and big torque
Need photo
■ 1,812cc natural aspirated/DOHC 16 valve
■ Largest displacement in the industry
■ Highest performance NA engine
■ Great fuel consumption and range2021 GP Series
・ Better ergonomics and comfort
35 mm narrower
40 mm
Deeper
25 mm Wider
Foot well drain2021 GP Series
Increased Storage capacity
22% more
Storage than
MY20 GP2021 GP Series
・ Remount boarding ladder2021 GP Series
Connext
Touch Pad
Connext 4.3” LCD Meter
SETTINGS Trip/Fuel Info Operation Info Drive Control Security/Eng. Lock2021 GP Series
No longer need remote Fob Drive Control Functions * Other than VX/VX-C
- Speed/Acceleration
- Auto Trim
New Auto Trim feature with
Improved turning ability
Cornering and Launch Control
- Speed : 88kmh 72 kmh, 56 kmh
- Accel. : NORMAL, SLOW (GP Series & VX HO only)
Launch control for better acceleration2021 GP Series AutoTrim mode (AT mode) AutoTrim mode (AT mode) works independently form the traditional electrically controlled trim (manual trim – MT mode). When selected, the AT mode activates cornering control (CC control) and launch control (LC control). Trim Switch can also be operated manually when autotrim is on Cornering control (CC control) When activated, CC control automatically shifts the trim into the D2 position on deceleration (throttle lever returned), thereby achieving smooth cornering and racy riding. When the EXU detects throttle off and engine rpm goes down rapidly from middle speed the ECU will set the trim angle to D2 automatically this will put the bow down smoothly for assisting in quick cornering. Launch control (LC control) When activated, LC control automatically shifts down the trim at low speed, preventing bow-up on acceleration and providing comfortable boat behavior (D2) When ECU detects throttle on (Acceleration) and engine rpm is increasing rapidly from idle rpm. ECU controlled trim angle to D2 automatically which will help in quick acceleration.
2021 GP Series
Cornering control (CC control)
To realize smooth cornering, thereby providing racy riding.
Outline
Works when the AT mode is selected.
①Automatically shifts the trim into the D3 position on deceleration (throttle lever returned).
②Count timer automatically restores the previous trim position (previous value).
③The previous trim position may be restored either by the count timer or the trim SW-UP operation.
AUTO TRIM mode
System determines accelerationSystem determines there
Straight
Pre-turn deceleration immediately following turn. was no turn.
travel Turning Restored
Th. acceleration op＋ or No Th. op
TRIM : N (rpm, Th. deceleration＞threshold) count timer (3.5sec.) Cancels in 1.5sec. TRIM : N
TRIM : DW32021 GP Series
Launch control (LC control)
To prevent bow-up in sudden acceleration from low speed, thereby providing comfortable boat behavior.
Outline
①It works when the AT mode is selected.
②When selected, the trim is automatically shifted to the D2 position 5sec after low speed is detected.
③Cancellation：2sec after sudden acceleration is detected or boat accelerates beyond about 25km/h(※１).
Shifts to previous value (note) on Trim SW_UP operation.
※１：More precisely, at 3500 or higher in smoothed rpm. Riding over a hump.
TRIM : N eTRIM : N TRIM : N
Manual mode
Sudde
n
accel. Loss by bow-up!
TRIM : D2 TRIM : D2 TRIM : N
AutoTrim mode
Sudde
n Smooth acceleration!
accel.2021 GP Series
5 position Electronic Trim2021 GP Series
No Wake Mode Cruise Assist
A little finger movement is acceptable
NO WAKE + 1
- Adjustable levels by speed control switches - Press Cruise SET switch at the rpm
- Activated by push "NO WAKE MODE" and You want to set
set "SPEED CONTROL UP/DOWN" switch - Drive control can be used together
GP SVHO NWM + 1 - Release throttle lever
GP HO Default - A little finger movement is acceptable for setting
VX Cru HO NWM -1
- In case of CRUISE SET while both of throttle and
* VX Cru, VX Dlx, VX, VX-C (3cyl. Model has no adjustment)
RiDE levels, at that time rpm will be set.2021 GP Series
Reverse assist for GP series
RiDE lever full throttle
SPEED
UP
SPEED
DOWN
Function overview
- When launching Waverunner from trailer,
We can get higher reverse thrust than previous models.
Level.2
- After the engine start and once move forward,
The function could not activate because of safety reason.
Level.1
How to use
- RiDE lever fully open, and rpm up by SPEED CONTROL switch.
- 2 levels are set by the switch. Level.0
RiDE Fully open
How to cancel
- Release RiDE lever/Reset to STEP0 by SPEED CONTROL DOWN
/ Grip throttle lever/Activate "No Wake Mode"2021 GP Series
T.D.E. / Thrust Directional Enhancer] for GP series
Low speed maneuverability GP
1.Slight Forward
TRIM/T.D.E.
2.Slight Reverse
Function overview
- When idling status, we can get slight forward/reverse thrust by adjust reverse bucket
How to use
- Position “N ”, and
- TRIM/T.D.E. UP switch to slight forward
- TRIM/T.D.E. DOWN switch to slight reverse
How to cancel
- When slight forward (reverse) movement, push TRIM/T.D.E. DOWN (UP) switch
/ Grip throttle lever or RiDE lever/Activate "No Wake Mode"
Others
- T.D.E. is activated only Neutral position. UP/DOWN switches are activated as a Trim in other timing.
- Only can use idling rpm2021 GP Series * Other than VX-C
・ Engine
【One Push Start】 start style changes more simple and easy
MY20 MY21
Only one push! (0.5sec)
Keep pushing
How to start the engine
- Keep pressing the switch until engine start - Keep pressing switch 0.5 sec at least
- If the starting condition is satisfied,
cranking starts automatically
Starter motor drive
- It will work while pressing start switch- It will work until engine starts
- When the engine did not start, it works about 4 sec.
- When the engine did not start and keep pressing the
start switch, it works about 5 sec.
When the Battery voltage is low,
- Starter motor drives weakly - Starter motor did not work
➔ Be aware the low voltage ➔ When the voltage is under 12V,
voltage icon will flashing on the meter2021 GP Series ＊VX GP follows MY19FX * Other than VX-C
・ More simple and smart security! Remocon Free.
MY20 MY21
【Security system】
* These photos may differ from the actual design
How to set security
- Set lock/unlock by remote control - Input PIN code at meter and switching lock/unlock
ECU lock/unlock status
- Follows the receiver status - Follows the meter status
Others
- If the remocon had lost, need to re-register - Security level is same as previous models
in the entry box - If you forgot PIN code, reset it by the meter while
YDIS connecting
- Immobilizer dark current almost none2021 GP Series * Other than VX-C
・Adjustable for each rider’s skill, support towing accelerator work
【Drive control】
MY20 MY21
* These photos may differ from the actual design
Function overview
- Save engine output to 70%(L-MODE) - Can be set max speed and Accel. combination
- While L-MODE had set, - We can fix the setting same as L-MODE
cannot be used with Cruise assist by input PIN code and set drive control “lock”
How to use - Cruise assist can be used together
- Keep pressing remocon button - Set by connext meter button
Who can change setting
Unlock status: anyone can change the setting
- Anyone with the remote control
Lock status : who knows PIN code
Pattern
- Speed : 55mph, 45mph, 35mph
- 70% of engine output - Accel. : NORMAL, SLOW (GP Series & VX HO only)
* The speed will throttle opening control, so it may differ from the situation.2021 GP Series
2021 GP Series
【No Wake Mode】
・ More comfortable cruising adjustable Wake Mode
MY20 MY21
NO WAKE ＋1
Function overview
- Keep 8 km/h * It may vary depending on conditions. - Adjustable levels by speed control switches
- Activated by push “NO WAKE MODE” - Activated by push “NO WAKE MODE” and
set “SPEED CONTROL UP/DOWN” switch
GP SVHO NWM+1
GP HO
VX Ltd HO
Default
VX Cru HO NWM-1
* VX Cru, VX Dlx, VX, VX-C (3 cyl. Model has no adjustment )
Adjustable roughly ±1mph from default speed
by UP/DOWN switch2021 GP Series * Other than VX, VX-C
・ Unintended finger movement is acceptable for Cruise Assist
【Cruise Assist】
MY20 MY21
A little finger movement releases Cruise assist mode A little finger movement is acceptable
Function overview
- Press Cruise SET switch at the rpm - Press Cruise SET switch at the rpm
you want to set you want to set
- Drive control can be used together
Cancellation condition
- Release throttle lever - Release throttle lever
- A little finger movement possibility to - A little finger movement is acceptable for setting
cancel the mode
Others
- In case of CRUISE SET while both of throttle and
RiDE levers, at that time rpm will be set.2021 GP Series * Other than VX-C
・ Easy launching from trailer by add 2 levels reverse power
【Reverse Assist】
MY20 MY21
RiDE lever full throttle
SPEED
UP
SPEED
DOWN
Function overview
- When launching Waverunner from trailer,
we can get higher reverse thrust than previous models. Level.2
- After the engine start and once move forward,
the function could not activate because of safety reason.
Level.1
How to use
- RiDE lever fully open, and rpm up by SPEED CONTROL switch.
- 2 levels are set by the switch. Level.0
RiDE Fully open
How to cancel
- Release RiDE lever / Reset to STEP 0 by SPEED CONTROL DOWN
/ Grip throttle lever / Activate “ No Wake Mode”2021 GP Series * Other than VX, VX-C
・ Support slow speed maneuvering and dynamic positioning!
MY20 MY21
1.Slight Forward
TRIM/T.D.E.
2.Slight Reverse
Function overview
- When idling status, we can get slight forward/reverse thrust by adjust reverse bucket
How to use
- Position “N”, and
- TRIM/T.D.E. UP switch to slight forward
- TRIM/T.D.E. DOWN switch to slight reverse
How to cancel
- When slight forward(reverse) movement, push TRIM/T.D.E. DOWN(UP) switch
/ Grip throttle lever or RiDE lever/ Activate “No Wake Mode”
Others
- T.D.E. is activated only Neutral position. UP/DOWN switches are activated as a Trim in other timing.
- Only can use idling rpm
- This “T.D.E.” system is same name but different from Sport Boat.2021 ALL NEW SuperJet
2021 SuperJet
ALL NEW 2021SuperJet2021 SuperJet
23cm shorter & 60 kg lighter than the competition
made in Japan2021 SuperJet
Adjustable Nozzle angel pivot
L-mode (switch)
New Feature Map 3-position adjustable Pole
Large foot tray
Reboarding grip
New TR-1 Engine Hydro-turf mat
Lightweight ventilation hatch
Gauge
Easy fuel filler
144mm DIA. Jet pump
w/ unique impeller
Top loader intake grate
VaRTM body
Front wide performance hull2021 SuperJet
Body material and production method
Made in Japan
Aluminum pole
Super lightweight composite engine hatch
Plastic Injection hatch
Conventional 9.2kg → New 7.5kg
Reduced by 1.7kg
VaRTM FRP Deck
Lightweight closed molded FRP Hull/Deck
VaRTM FRP Hull
VaRTM method
FRP : Fiberglass Reinforced Plastics
VaRTM : Vacuum Assisted Resin Transfer Molding
Hull mold Intake area2021 SuperJet
Conventional SuperJet NEW SuperJet
Performance 1. Speed (feeling)
5 2. Acceleration
14. Predictability
(feeling)
4
13. Fun Factor 3. Turning (feeling)
3
2
12. Visibility 1 4. Agility (feeling)
0
11. Engine 5. Comfort/Ergonomics
Acceleration & Speed 10. Feel of stiffness 6. Stability
100
9. Appearance 7. Operability
speed km/h
8. Noise/Vibration
80
60
Conventional SuperJet Front wide performance hull
40 NEW SuperJet
Competiter
20
L-MODE
(Approx. 70km/h @ 6300rpm)
time sec
0
0 5 10 15 202021 SuperJet
100
speed km/h
80
54.5 mph
60
44.4 mph
Conventional SuperJet
40
NEW SuperJet
20
time sec
0
0 5 10 15 202021 SuperJet
Gauge
WARNING indication Fuel gauge
100
L-mode indication
speed km/h
80
60 STOP/ L-mode switch
NEW SuperJet
40
20 L-MODE
time sec
0
0 5 10 15 20
L-mode activation procedure:
1)Briefly press the start switch to activate the gauge.
2)Press the stop switch three times.
3)Check L-mode indication in the gauge.
Return to the normal mode in the same procedure.
When L-mode is activated, MAX rpm is reduced around 20%
compared with normal mode.2021 SuperJet • 3-position adjustable Pole • Wider foot tray • Re-boarding holder • Race inspired handlebars
2021 SuperJet
• Wider performance hull
• Race designed ride plate
• Top loader intake grate
• Adjustable steering angle
Nozzle turn angle Nozzle turn angle
16° 19°2021 SuperJet
Adjustable Nozzle Angel
Joint bowl location: Inside Joint bowl location: Outside
Steering Colum
Nozzle turn Nozzle turn
angle angle
16° 19°2021 SuperJet
Large foot tray
340 mm
Conventional
SUPERJET
380 mm
440 mm
NEW
SUPERJET
Reboarding grip
It’s about 20% wider than conventional SJ.2021 SuperJet
Conventional New
K SX-R
SUPERJET SUPERJET
Specifications Length mm 2,24 2,43 2,655
Width mm 680 762 765
Height mm 660 780 840
Length 2,430 mm
Dry kg 139 170 235
Width 762 mm
Height 780 mm
Dry Weight 170 kg
Weight w/ Gas & Battery 190 kg
762mm
680mm
765mm
Max. loading weight 80 kg
Fuel Tank 20 L
Engine Type 4-stroke, 3-cyl.
Displacement 1,049 cc 2655mm
2430mm (-225mm, +190mm)
Output / rpm 74.6 kW/7,300rpm 2240mm
Engine Weight 71 kg
Max. Speed (Reference) 85 km/h
K-SX-R
New SUPERJET
Conventional SUPERJETMY2021 European Line-up Summary
Model Body/EG Code Color Hull Material Hull Platform Note
FX F3X/6HL F3X700-050A Red
FC1800A-W NanoXcel 2 FX
CRUISER SVHO F3X/6HL F3X700-050B Black
FC1800-W FX SVHO F3X/6HL F3X800-050A Black NanoXcel 2 FX
FB1800A-W FX CRUISER HO F3V/6HM F3V500-050B Blue NanoXcel FX
FB1800-W FX HO F3V/6HM F3V600-050A White NanoXcel FX
F4P/6JN F4P100-050A Blue
GP1800A-W GP1800R SVHO NanoXcel 2 VX
F4P/6JN F4P100-050B Black
GP1800B-W GP1800R HO F4M/6JP F4M100-050B Black NanoXcel 2 VX
VX1800B-W VX CRUISER HO F4S/6JR F4S200-050A Yellow NanoXcel VX with Audio
VX1050B-W VX CRUISER F4N/6JS F4N200-050A Green NanoXcel VX with Audio
VX1050E-W VX DELUXE F4N/6JS F4N500-050B Red NanoXcel VX
VX1050F-W VX F4N/6JS F4N600-050A Yellow SMC VX
VX1050G-W VX-C F6G/6JT F6G100-050A Yellow SMC VX
ER1050-W EXR F4L/6GY F4L301-050A Yellow NanoXcel 2 EX
EX
EX1050D-W LIMITED F3Y/6GA F3YN01-050A White SMC EX only Factory Options
EX
EX1050B-W F3Y/6GA F3YL01-050A Green SMC EX
SPORT
SJ1050-W Super Jet F4R/6JF F4R100-050A White SMC SJ
* Audio OPT is available for FX & EX SeriesThanks
for your attention
YME Marine TeamYou can also read
