Geology Presentation Overview
Introduction – Kalgoorlie Asset Overview
Location and Tenure
Operational Overview
Reserve Resources (as at 30 June 20151)
FY2015 Exploration Results
Geology Strategic Plan
The Evolution of the Project Pipeline
FY2015 Results
Kundana
The Geology of the Kundana Goldfield
Kundana Reserve Resources (as at 30 June 2015)
The Pegasus Discovery Story – Understanding the Upside
3 1 Refer ASX Announcement released 4 August 2015 titled: Northern star grows mine lives significantly with 2.7Moz Increase in resources to 8.9Moz.
GEOLOGY PRESENTATION
PART 1: ASSET OVERVIEW
Kalgoorlie Operations
Kalgoorlie Asset Overview
Land Holding & Operations
CARBINE CAMP
KANOWNA CAMP
KUNDANA CAMP
KB Mill
60km 50km 40km 30km 20km 10km
KANOWNA BELLE
• 5Moz Historic Production
• Refractory Sulphide Orebody
• Sediment/Porphyry Hosted
KUNDANA (RUBICON – RALEIGH) (NST 51%) • Bulk UG Longhole Open Stoping
• ~4Moz Historic Production • FY2015: 658Kt @ 4.8g/t for 101Koz (Mined)
• Narrow Vein High Grade • AISC (FY2015) A$1,021
• Quartz Hosted at Contacts
• Narrow UG Longhole Open Stoping KALGOORLIE
• FY2015: 696Kt @ 9.8g/t for 219Koz (Mined)
• AISC (FY2015) A$711/oz
5
Kalgoorlie Asset Overview
Processing
CARBINE CAMP
KANOWNA BELLE PROCESSING HUB
• 1.8Mtpa Capacity
• Versatile Processing Facility KANOWNA CAMP
- Roaster to Treat Refractory Ores
- Conventional CIP for Free-milling Ores
- Gravity Recovery
KUNDANA CAMP
KB Mill
60km 50km 40km 30km 20km 10km
KANOWNA BELLE
• Refractory Ore
• 92% Recovery Achieved in FY2015
KUNDANA (RUBICON – RALEIGH) (NST 51%) • FY2015 - 766Kt @ 4.3g/t for 105Koz Milled
• Free Milling Ore • FY2015 – 99Koz Poured
• 97% Recovery Achieved in FY2015
• Gravity Recovery >60%
• FY2015 - 621Kt @ 10.2g/t for 203Koz Milled
KALGOORLIE
• FY2015 - 194Koz Poured
6
Kalgoorlie Resources (NST Attributable Ounces, as at 30 June 2015) 7
Kalgoorlie Reserves (NST Attributable Ounces, as at 30 June 2015) 8
GEOLOGY PRESENTATION
PART 2: EXPLORATION RESULTS
Kalgoorlie Operations Exploration
FY2015 - A Year of Delivering Unprecedented and Unrivaled Results
Addressing the Project Pipeline Imbalance
Kalgoorlie Operations Geology 3 Year Strategic Plan
RAPID IDENTIFICATION RAPID CONVERSION
FRAMEWORK
STRATEGIC
REGIONAL
DISCOVERY 3 of
Inferred Resource
2 of 1
Resource to Reserve
Year 1 Accelerated Focus
‘Sustainability, Upside’ ‘Life of Mine Extensions, Profit’ ‘Immediate Mine Extension, Payback’
Geology
Geology
Targeting & Research Projects Conversion by Drilling
KEY ACTIVITIES
Conversion by In-Mine Drilling
Geophysics & Geochemistry Conversion by Modelling / Interpretation
Geology
Conversion by Engineering Design
Geology
Database Project
Non -
Conversion by Engineering Design
Non -
Data Compilation & Integration Conversion by Cost Management
Conversion by Cost Management
Toll Treatment / BD
Database Integration Extensional Drilling of K2, Strzelecki Structures
OPPORTUNITIES
Pegasus (Target for 600KOz added to reserve in 2 years)
Zuleika Early Stage Projects Data cleansing, Remodelling and Mining Re-
Incremental Additions at Kanowna Belle, Rubicon-Hornet
optimisation of historic mining areas and
KEY
Kanowna Regional Projects (Red and possibly Raleigh (1-2 additional levels)
resources (eg. Carbine, Woodline, Strzelecki,
Eye, Golden Eye, 6 Mile etc) Engineering Design Conversion – KB F Block, KB Remnants
Centenary, 6 Mile etc)
Kundana Seismic Lines Dilution Control / Ore Loss Reductions at Operations
Operational cost reductions (reduced cutoff)
10Accelerated Exploration Program
FY2015 Program Metrics (Actual)
FY2015 KALGOORLIE OPERATIONS GEOLOGY BUDGET
BY PIPELINE STAGE
FY2015 Actual Drill Metrics:
Surface Diamond Drilling – 57,800m
Surface RC Drilling – 41,000m
Aircore Drilling – 13,500m
Underground Diamond Drilling (non GC) – 39,030m
TOTAL: 151,330m for the year
64% of expenditure on direct in-ground drilling costs
11FY2015 Exploration Results
Project Pipeline – Before and After
FY2016 FOCUS
(Year 2 of 3 Year
Plan)
TURNING
EXPLORATION
SUCCESS INTO
MINES
KEY RESULTS
Delivered 1.53 Moz of Resources across the Kalgoorlie Region at a cost of $18 per ounce ABOVE DEPLETION (300Koz)
Reserves increased by 266Koz ABOVE DEPLETION. The mining reserves for Kal Ops are now >1Moz
6 potential new discoveries
9 Projects with the potential to deliver Reserves in FY2015 (up from 3)
12 Projects with the potential to deliver Resources in FY2015 (up from 8)FY2015 Exploration Results
Discoveries - Highlights
CARBINE CAMP
GOLDEN EYE (NST 100%)
PARADIGM NORTH (NST 100%) • New vein discovered by field
mapping and sampling
• Potential northern repetition of
the Paradigm Orebody FY2015 Results Include: KANOWNA CAMP
FY2015 Results Include: 5m @ 8.2g/t
197m @ 2.4g/t ,including 3m @ 5.3g/t
18m @ 17.9g/t, & 1m @ 22.0g/t
3.0m @ 25.7g/t
3m @ 50.4g/t
16m @ 6.0g/t KUNDANA CAMP
MILLENNIUM (NST 100%)
60km 50km 40km 30km 20km 10km
• North Plunging Shoot adjacent
AMBITION (NST 51%) to the Centenary Orebody
• New interpretation of old FY2015 Results Include:
mapping, targeting K2 15m @ 6.2g/t
FY2015 Results Include: 2.9m @ 37.4g/t
2m @ 11.3g/t 3.2m @ 26.6g/t
2m @ 9.8g/t
3m @ 5.0g/t DRAKE HIGH GRADE (NST 51%)
IVT VEINS - DISCOVERY • North Plunging Shoot adjacent to
the Centenary Orebody
FY2015 Results Include:
3m @ 18.5g/t
5m @ 5.3g/t
1m @ 25.0g/t
13FY2015 Exploration Results
Project Advancement - Highlights
CARBINE CAMP
SIX MILE (NST 100%)
CARBINE (NST 100%) • Shear hosted mineralisation,
• Veins and disseminated sulphides in sheeted veins in Porphyry
volcanics thrust over sediments KANOWNA CAMP
FY2015 Results Include:
FY2015 Results Include: 4m @ 12.2g/t
4.0m @ 8.2g/t 11m @ 6.0g/t VELVET(NST 100%)
3.0m @ 8.6g/t 3m @ 29.2g/t
3.0m @ 7.8g/t • Following up on historic drilling
CHRISTMAS (NST 100%) KUNDANA CAMP FY2015 Results Include:
45.3m @ 5.6g/t
• Conceptual North Plunging Shoot PODE/K2B (NST 51%) 35.0m @ 3.6g/t
60km 50km
on Strzelecki. Offset of Raleigh 40km 30km 20km 10km
15.3m @ 10.5g/t
• Moderately west dipping vein in
FY2015 Results Include: the HW of K2 Pegasus
1.6m @ 24.4g/t
FY2015 Results Include:
0.9m @ 31.7g/t
4.0m @ 18.9g/t WHITE FEATHER (NST 100%)
1.3m @ 4.3g/t
3.0m @ 20.7g/t
• Narrow Vein High Grade
SKINNERS VEIN (NST 51%) PEGASUS (NST 51%)
RUBICON HORNET (NST 51%) FY2015 Results Include:
• Moderately dipping vein in the • Narrow vein quartz lode at the 1m @ 5,328g/t
• Depth extensions on existing 1m @ 60.3g/t
HW of the Raleigh main vein contacts of the Centenary Shale
operations 0.3m @ 303.1g/t
FY2015 Results Include:
FY2015 Results Include: 2.4m @ 50.2g/t 3m @ 8g/t
FY2015 Results Include:
30.1m @ 14.0g/t 3m @ 18.2g/t
9.1m @ 19.8g/t
8.6m @ 9.5g/t 25m @ 4.2g/t
5.0m @ 13.0g/t
14 Results are downhole width and uncutFY2015 Exploration Results
Resource Addition - Highlights
CARBINE CAMP 1.53Moz of RESOURCE ADDED ABOVE DEPLETION
CARBINE (NST 100%)
• MAIDEN NST RESOURCE SIX MILE (NST 100%)
KANOWNA CAMP
• 5.8Mt @ 1.4g/t for 264Koz • MAIDEN NST RESOURCE
• 173Kt @ 3.6g/t for 20Koz
D to FY2014: +264Koz
D to FY2014: +20Koz
KUNDANA CAMP
60km 50km 40km 30km 20km 10km
ARCTIC (NST 100%) MILLLENNIUM (NST 100%)
• MAIDEN NST RESOURCE • MAIDEN RESOURCE KANOWNA BELLE (NST 100%)
• 565Kt @ 2.2g/t for 41Koz • 1.8Mt @ 5.8g/t for 346Koz • UPGRADED RESOURCE
D to FY2014: +41Koz D to FY2014: +346Koz • 7.7Mt @ 4.4g/t for 1.1Moz
D to FY2014: +74Koz
POPE JOHN (NST 100%) MOONBEAM (NST 100%)
• MAIDEN NST RESOURCE • MAIDEN RESOURCE
• 538Kt @ 11.1g/t for 192Koz • 437Kt @ 5.2g/t for 74Koz
D to FY2014: +192Koz D to FY2014: +74Koz
RUBICON UG (NST 51%) PEGASUS (NST 51%)
• UPGRADED RESOURCE • UPGRADED RESOURCE
• 613Kt @ 9.2g/t for 181Koz • 3.4Mt @ 11.2g/t for 1,225Koz
D to FY2014: +61Koz D to FY2014: +462Koz
15Highlights by Pipeline Stage
Early Stage Conceptual Targets
KANOWNA CAMP Red Eye Regional KUNDANA (NST 100%)
Geochem
Fitzroy Chasers
Numerous Soil CONCEPT TO DELIVERED RESOURCE
IN FY2015: Application of the Pegasus
Anomalies, Golden Moly
including 900m long shoot model to Centenary.
coherent target over
Regional
Golden Eye (max Millennium MAIDEN RESOURCE: 1.8Mt @ 5.8g/t for
101ppb)
Geochem 346Koz (Open in all directions)
Panglington
DISCOVERY:
Maiden drill
program returned: Golden Eye
Western
- 5m @ 8.2g/t
- 1m @ 22.0g/t
Kundana SAM
- 3m @ 5.3g/t West Scotia
CARBINE CAMP KUNDANA EKJV (NST 51%)
Western
CONCEPTUAL REVIEW TO Kundana SAM
RESOURCE IN FY2015: Data
compilation, interpretation
and selective drill targeting. Carbine
Review
Resulted in a delivered Zuleika Seismic
maiden resource of:
5.8Mt @ 1.4g/t for 264Koz
CSIRO Targeting
Carbine East
Regional
Geochem
16Paradigm North (NST 100%)
Potential footwall repetition of the high grade Paradigm mine Coarse gold with high grade
variability
3D View of Paradigm North – FY2015 Drilling
North West Multiple en-echelon quartz
Paradigm Pit
PDDD15010
veins, with up to 6 new veins
197m @ 2.4g/t
including:
interpreted
1m @ 16.0g/t
18m @ 17.7g/t
3m @ 25.6g/t
OPEN
Paradigm UG
OPEN
PDRC15006
PDRC14003
3.0m @ 50.4g/t
50m
16m @ 6.0g/t
17Highlights by Pipeline Stage
Drill Testing Targets
KANOWNA CAMP RESULTS
KUNDANA (NST 100%)
- 45.3m @ 5.6g/t
RESOURCE DELIVERED
550m from KB Mine
975Kt @ 8.5g/t for 266Koz
EXP DECLINE Moonbeam / PJ
COMMENCED Velvet
Rick Snickel Strzelecki
RESULTS
CONCEPT DEMONSTRATED:
- 1m @ 5,328g/t Kurrawang
- 1m @ 60.3g/t Bonnie Charlie Application of the Pegasus shoot
model to the Strzelecki Structure.
- 3m @ 8.0g/t
White Feather - 0.9m @ 31.7g/t
Centenary
- 1.6m @ 24.4g/t
- 1.3m @ 4.3g/t
New Caledonia Christmas POTENTIAL 500m STRIKE
RESULTS
Sims, Troy, KB OFFSET OF RALEIGH NORTH OF
Remnants all advanced KB In Mine Barkers
LUCIFER FAULT
IVT Veins DISCOVERY: K2 Parallel
DISCOVERY
lodes west of Pegasus. KUNDANA EKJV
Repeated en-echelon FW lodes
Pegasus 8m @ 8.52g/t (NST 51%)
disvovered ~200m north of
historic mine EXTENSION: Pegasus remains open, system has >1km of
- 18m @ 17.9g/t Paradigm Pode
strike, 2.4m @ 50.2g/t, 2.4m @ 25.7g/t, 3.0m @ 20.7g/t
- 3m @ 50.4g/t
- 16m @ 6.0g/t
Rubicon-Hornet RESOURCE DELIVERY: Pode extended over 600m north,
- 2m @ 9.6g/t ~300Koz of resource added to Pegasus
Drake
EXTENSION: Rubicon Hornet orebodies extended byGEOLOGY PRESENTATION
PART 3: THE GEOLOGY OF KUNDANA
Unlocking the Potential of the Kundana Goldfield
A lesson in exploration persistence in a ‘mature’ mineral fieldKundana Location & Tenement Holding
Kundana - Operating Mines
26 Kilometres WNW of
Kalgoorlie
The NST Kundana
operations consist of
100% owned ground in
addition to two JV’s
where NST has the
Raleigh
highest equity position (EKJV, NST 51%)
Pegasus
(EKJV,NST 51%)
Northern Star Rubicon-Hornet
(100%) (EKJV, NST 51%)
Kundana Operations Frogs Leg
East Kundana Joint (La Mancha)
Venture
(NST 50/51%)
West Kundana
Joint Venture
Kalgoorlie
(NST 75%) Scale: 5km
See Inset
20The Zuleika Shear Zone
The Kundana ZULEIKA GOLD DEPOSITS
Goldfield is located
within the Zuleika CARBINE (>0.5Moz)
BULLANT (>0.2Moz)
Shear Zone at a
major regional flexure
Golden Mile
KUNDANA (>5Moz)
>65Moz
The Zuleika is a major
crustal scale feature
that separates distinct Zuleika Shear Zone
geological domains
Kalgoorlie
The mapped extent of CAVE ROCKS (>0.7Moz)
35 Kilometres
the zone exceeds See Inset St Ives
130kms >15Moz
21Kundana Goldfield – Local Structural Geology
The Zuleika shear zone at Kundana consists Royal Standard Fault
of a complex array of structures at a regional
flexure in the fault zone
Pope John Fault
There are two major NW trending structures
Barkers Shear
- The K2 Shear
- The Strzelecki Shear
Lucifer Fault
The K2 and Strzelecki structures are the
major hosts of gold mineralisation in the STRZELECKI SHEAR K2 SHEAR
Kundana Goldfield
White Foil Fault
The K2 and Strzelecki structures are offset by
Mary Fault
later D4 NNE trending structures that are 4.5 Kilometres
22
often associated with mineralised shootsKundana Deposits and Past Production
Mineralisation in the Kundana Camp can KUNDANA PRODUCTION (1988 – 2013): 3.34 MILLION OUNCES
be classified based on structural position: North
49Koz
- K2 Line of Lode South/Centenary
Barkers
- Strzelecki – Barkers Line of Lode 288Koz
309Koz
Pope John
- Late D4-Associated Deposits Strzelecki 11Koz
485Koz
Moonbeam
Raleigh 62Koz
The K2 Line of Lode has produced a total 1,019Koz
Kurrawang Pit
of 1.4Moz since 1988 40Koz
Rubicon Hornet
255Koz
The Strzelecki Line of Lode has produced
Frogs Leg
a total of 1.8Moz since 1988 697Koz
White Foil
500K Oz
North
The D4 associated deposits have STRZELECKI K2 LINE OF
produced 0.2Moz since 1988 LINE OF LODE LODE
23Geology of the K2 (East) Line of Lode
Deposit Geology – K2 Line of Lode
Frogs Leg – Hornet – Rubicon – Pegasus – Moonbeam – Pope John – Centenary – North - Ambition
Key Geological Attributes: 6075 LEVEL BACKS (HORNET)
Ore Body Classification - Shear Hosted Archaean Greenstone Lode Deposit
- Variable, but typically hosted at stratigraphic contacts between the
Host Rock
Victorious Basalt, Centenary Shale and Intermediate Volcaniclastics
- Part of the Eastern Zuleika Shear Zone, Possible hinge related shear
Structural Setting
and thrusting. Displaced by late stage NNE trending structures
- Gold hosted in narrow (generally ~2m) crack-seal laminated quartz vein
Vein Style
dipping ~70 degrees west. Locally brecciated in places
- Multiple Generations. Coarse Free-Milling gold associated with minor
(Pegasus K2 – Geological Architecture
Bent Tree Basalt
Mafic Pillowed Basalt Flows
Victorious Basalt
Plagioclase-phyric volcanics
Centenary Shale
Carbonaceous shale with arsenopyrite &
pyrrhotite following primary bedding
Intermediate Volcaniclastics (IVT)
Volcanic sediment derived from intermediate
source, includes crystal tuff
26Deposit Geology – K2 Line of Lode
Frogs Leg – Hornet – Rubicon – Pegasus – Moonbeam – Pope John – Centenary – North - Ambition
HORNET ORE VEIN VEIN TEXTURE
See Inset
Scale: 1m
IMAGE: K2 Ore Vein at the 6005 Level (Hornet) IMAGE: Close up of ore vein in the 6005 Level (Hornet) showing
internal deformation ,brecciation and multiple stages of
27 mineralisationGEOLOGY PRESENTATION
PART 4: PEGASUS DISCOVERY
The Discovery Pegasus Story
A lesson in questioning Geological ‘FACTS’Pegasus – A Major Discovery in a Mature Field
Surface Drilling @ January 2011 KEY TAKEAWAY: ‘Well Drilled’ does not
necessarily mean ‘Well Explored’
K2 Trend – Rubicon/Hornet @ January 2011
2012-2014: PEGASUS
1 Million Ounce Deposit
Grading +10g/t Identified in a
‘well drilled’ area
29Pegasus Resource Growth History
1.2Moz Mid year 2014 the
Resource
1,200,000 Pegasus Resource
NORTHERN STAR
was 763Koz
1,000,000 ACQUISITION
By Mid Year 2015,
RESOURCE OUNCES
800,000
the Reserve was
BARRICK
DIVESTMENT 609Koz.
PROCESS 609Koz
600,000 PEGASUS SHOOT Reserve This is an 80%
CONCEPT
conversion of
400,000 DRILLING
RECOMMENCED
resource to reserve in
200,000
AFTER 6 YEAR HIATUS 1 year.
This is in line with the
0 80% conversion rate
Jun-11 Dec-11 Jun-12 Dec-12 Jun-13 Dec-13 Jun-14 Dec-14 Jun-15 of resource to reserve
Inferred Resource Indicated Resource in the Kundana field
30Exploration History
The Pegasus Prospect was first named in 1999, with the soil geochemistry anomalism first
reported in 1987
Numerous phases of drilling were conducted between 1999 and 2006. A small near-surface
resource was identified, however was removed from the mineral inventory due to the
interpreted limited strike length. PEGASUS CIRCA 2006
Based on the 2006 drilling and the interpreted shoot
orientation of steep north plunging, Pegasus was
thought to have been closed off along strike with
insufficient ounces per vertical metre to develop an
economic underground mine
Scale: 250m2011 – A Geological Awakening
In 2011, a review of the exploration prospectivity of the EKJV tenure was conducted. With the
advancement of geological knowledge in the district, new geological concepts were applied to
historic data.
Pegasus (at 2006)
Frogs Leg Long Section (La Mancha Technical Report 2009)
MIST LODE
DEAD
ZONE
WHAT IF there were multiple shoot orientations at Pegasus?
ROCKET LODE WHAT IF there were dead zones between shoots?
North
COULD THERE BE blind mineralisation at depth?
32
HAS PEGASUS BEEN CLOSED OFF?The Evolution of Pegasus
Pre - 2011
December 2011 July 2012 December 2012 December 2013
500m
Feasibility based on 2013YE Resource
(355Koz) near completion
Decline started in April 2014 and trial
August 2014
mining has begun – First Stope Mined
Resource more than TRIPPLED between
Dec 2013 and June 2015 to 1.2Moz
Other mineralised structures discovered
The Orebody is open in all directions
33 Intersections are downhole and uncutPode Structure – Mineralised Vein
New MINERALISED
structure that continues
to the North of Pegasus
Dips at 45 degrees to the
west
Possible Riedel Shear,
34 or Early Structure?Pegasus Hard Rock 2D Seismic
Seismic section
Pode shows that this
Strzelecki Structure
structure
continues to the
K2 Structure
Strzelecki Fault
Pode Extension
How many more
have not been
K2 Extension recognised?
Au >7g/t
35Pegasus Architecture as an Exploration Model
Two Prominent Shoot
Orientations Observed at
Pegasus:
- South Plunge (fold related)
- North Plunge (fault movement)
South Dipping Zones of vein
thinning
- K2 structure and vein is present,
however metal accumulation
decreases as vein thins
- These appear to be related to
flexures in the structure
North
36KUNDANA: Centenary North – Millennium (NST 100%)
MILLENNIUM
SOUTH PIT / CENTENARY UNDERGROUND MINE (d.1999) Strong South plunge of mineralisation observed at the Centenary
Underground Mine (Similar orientation to Pegasus & Frogs Leg)
Development may have stopped at south dipping low grade
flexures as seen at Pegasus
Unlike Pegasus, the north plunge is absent at Centenary (or is it?)
MILLENNIUM
TARGET
The Millennium target aims to test the theory that the development
North stopped on a low grade flexure and there may be a blind north-
plunging shoot near surface
37KUNDANA : Millennium (NST 100%)
In August 2015 NST announced a maiden resource on Millennium of 1.8Mt @ 5.8gpt for 346koz
38Drake – Applying the Pegasus Learnings (NST 51%)
DRAKE
3m @ 18.3g/t
2m @ 7.8g/t
5m @ 5.3g/t
Intersections are downhole and uncut
39EKJV: Ambition (NST 51%)
AMBITION
2.5kms from North Pit
on the K2 Structure
AMBITION REVISED GEOLOGICAL INTERPRETAION
AMRC14013: 2m @ 11.3g/t AMRC14003: 2m @ 6.0g/t AMRC14012: 2m @ 9.7g/t
AMRC14002: 2m @ 1.8g/t AMRC14011: 3m @ 5g/t
Tungsten in-lag
Anomaly
200m
40KUNDANA: Christmas (NST 100%)
CHRISTMAS LOCATION PLAN
0.7m @ 53.8g/t
CHRISTMAS
CHCD14003: 0.7m @ 31.7g/t
Raleigh
0.6m @ 24.3g/t
2.5m @ 5.8g/t Rubicon Hornet
CHCD14001: TBA CHCD14002: 1.4m @ 24.4g/t
LUCIFER FAULT
NORTH
Targeting the continuation of the Raleigh Vein on the other side of the Lucifer fault.
Testing a potential shallow north plunging ‘Pegasus style’ shoot on the Strzelecki structure
All 3 holes intersected veining and mineralisation
41Questions? 42
Northern Star Resources An Australian Mid Cap gold miner – for global investors Contact Details: Luke Gleeson – Investor Relations +61 8 6188 2100 Email – info@nsrltd.com / Website – www.nsrltd.com August 2015
You can also read
